LCM1041TV
Owner’s Manual
CHANNEL
AP
TV/AV
PIC.
SEL.

Important Notice
It is unlawful in most jurisdictions for a person to drive a motor vehicle which is equipped with a
television viewer or screen that is located in the motor vehicle at any point forward of the back of the
driver’s seat, or that is visible, directly or indirectly, to the driver while operating the vehicle. In the
interest of safety, the LCM1041TV should never be installed where it will be visible, directly or indirectly,
by the operator of the motor vehicle.
Please note that the state of Rhode Island forbids the installation of such a device in a motor vehicle.
Television Reception
This entertainment system is designed primarily for viewing pre-recorded movies or playing video
games. Television reception in a moving vehicle will be limited and in some areas will not be possible
due to weak and variable signal strength. Television viewing in a stationary vehicle will result in an
improvement, but may still be marginal due to strength. The quality of the picture will not be consistent
with home TV reception. Reception may be affected by the weather and distance from the TV station. A
weak signal may cause the picture to roll, be snowy, or cause some color loss.
Congratulations on your purchase of the Flexvision LCM1041TV drop down TV/Video monitor. The
LCM1041TV has been designed to give you and your family many years of video entertainment in the
mobile environment. Please read the directions that follow to familiarize yourself with the product and to
ensure that you obtain the best results from your equipment. Please note: Installation options vary, see
the individual owner’s manuals for each component in your system to obtain a full understanding of
each component’s operation.
Safety Precaution
For safety reasons, when changing video tapes it is recommended that the vehicle is not in motion, and
that you do not allow children to unfasten seat belts to change tapes or make adjustments to the system.
System adjustments can be accomplished using the remote control unit, while seat belts remain

fastened. Enjoy your Flexvision entertainment system but remember- safety of all passengers remains
the number one priority.
FEATURES
•10.4” TFT (Thin Film Transistor) Active Matrix LCD (Liquid Crystal Display) Monitor
•OSD (On Screen Display) for control of Picture Quality and Functions
•Remote Control
•Television Tuner
•Plug in RF Transmitter for wireless RF Headphones
•Remote Sensor eye
•Three Audio / Video Sources
•Speaker Amplifier
•Back-lit Controls for Low Light Operation

FRONT PANEL FEATURE
Figure 1
CHANNEL
AP
TV/AV
PIC.
SEL.
1
23
4
5
6
7
8

FRONT PANEL FEATURES – See Figure 1
1. Sensor Eye – Allows the remote control to operate the LCM1041TV’s OSD system (On Screen
Display), volume to wired headphone jacks (and optional external speakers), and for control of Video
Cassette Player and other accessories.
2. Power Button – (Bright red when system is ON, dim when system is OFF).
3. Channel Up/Down – Changes the TV channel.
4. Auto Program – Press this button, the TV will automatically scan and memorize the broadcasting
signal channels.
5. Screen Release – Slides in the direction of the arrow to release the drop down screen.
6. TV/AV – Used to select one of the three A/V sources.
7. Picture Tuning Up/Down – Adjust picture control level Up or Down, if required.
8. Picture Select – To select contrast, Brightness, Color and Tint for desired level adjustment.
BATTERY INSTALLATION
Before attempting to operate your Remote Control, install the batteries as described below.
1) Turn the remote control face down. Press down on the ridged area of the battery cover, and slide it
off.
2) Install two “AAA” batteries as shown. Make sure that proper polarity (+ or -) is observed.
3) Slide the cover back until it clicks into position.
The remote control will operate the LCM1041TV, Flexvision Televisions and Video Cassette Players. It
is not a universal remote control and will not control equipment from other manufacturers.

If a universal remote control is used with the LCM1041TV, choose the remote control encoding scheme
for Action Televisions when programming the remote.
TV/VIDEO
MUTE
1 2 3 CH
CH
4
5
6
7
8
9
VOL
VOL
0
1--
AUTO
MEMORY
ERASE/
WRITE
SKIP/SEARCH
PLAY
STOPREPLAYF.FWDREW
TV POWER
VCP POWER
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15

Remote Controlled TV Functions
1. POWER ON/OFF
Press this button to turn the LCM1041TV on. The channel number or current video source will be
displayed on screen, and the picture will appear in a few seconds. Press the button again to turn the
LCM1041TV off.
2. DIRECT ACCESS (0-9) BUTTONS
Use these buttons to make a direct channel selection. The channel number chosen will be displayed
on the screen for about 4 seconds. To select channels 0-99, press two number buttons. For
example, to select channel 8, press 0, 8. To select channels above 100, press the 1-- button, then the
number buttons for the last two digits of the channel. For example, to select channel 115, press 1--, 1,
5.
3. CHANNEL UP/DOWN BUTTONS
Use these buttons to advance to the next higher or lower channel.
4. VOLUME UP/DOWN BUTTONS
Use these buttons to raise or lower the volume level of the external speaker if installed.
5. TV / VIDEO BUTTON
Any video equipment connected to the AUDIO/
VIDEO inputs can be used with the TV by pressing
this button. Each time the button is pressed, the
Audio/Video source will change in the following
sequence VIDEO 1, VIDEO 2 and TV.
6. MUTE BUTTON
Press this button to turn TV sound off. Press again
to restore sound to the previously set level. Mute
may also be released by pressing the VOLUME +/-
buttons.

7. SKIP / SEARCH BUTTON
This button selects between SKIP and SEARCH mode. In “SKIP mode” the TV only stops on
channels that are programmed into memory when the CHANNEL UP/DOWN buttons are used. When
SKIP is turned off, the TV will only stop on all active channels.
8. ERASE / WRITE BUTTON
When tuned to a channel, press this button to store or erase the channel from memory. The stored
channel numbers are displayed in green on the screen, and the non-stored channels are in red.
When skip mode is on, the LCM1041TV will tune to only the stored channels when using the
CHANNEL UP/DOWN buttons.
9. AUTO PROGRAM BUTTON
When the AUTO PROGRAM button is pressed, the
TV screen will show an important information screen
and all the channel numbers for TV will be scanned.
When the AUTO PROGRAM button is pressed, the TV screen will show
an IMPORTANT information screen, all the channel
numbers for TV or CABLE TV will be scanned. The
broadcasting signals will be detected and
automatically stored.
REMOTE CONTROLLED VCP FUNCTIONS
These features can only be used with a Flexvision Video Cassette Player, if this option was installed with
your video package.
10. VCP POWER BUTTON
This button is used to turn the VCP on and off.
11. “REW” REWIND BUTTON
If this button is pushed while the tape is stopped, the
tape will rewind. If this button is pushed while the
tape is playing, the VCP will go into rewind search

mode. For more information consult the VCP owner’s
manual.
12. PLAY BUTTON
Press this button to activate play mode while a tape is
loaded into the VCP. This button may also be used to
disengage search and pause modes. For more
information, consult the VCP owner’s manual.
13. “FFWD” FAST FORWARD BUTTON
If this button is pushed while the tape is stopped, tape
will fast forward. If this button is pressed while the
tape is playing, the VCP will go into fast forward
search mode. For more information on the search
feature of the VCP, consult the VCP owner’s manual.
14. STOP BUTTON
Press this button to stop the tape.
15. REPLAY BUTTON
During playback, press this button to rewind the tape
to the beginning and to begin PLAY mode from there.
CHANNEL TUNING SETUP
In order to easily access all available channels, it may be necessary to perform channel auto-
programming whenever the vehicle’s geographic location has changed, i.e. city to city, weak signal area.
1. Press the AUTO MEMORY button on the remote
control unit. You will see the TV cycle through all it’s
channels. The built-in microprocessor will
automatically note each channel that is actively
broadcasting in your area.
2. (A) To tune only strong clear channels with the
CHANNEL UP/DOWN buttons, press the
SKIP/SEARCH button on the Remote Control Unit
until “SKIP MODE ON” is displayed on the bottom
of the screen. The TV will now tune only to strong

active channels when the CHANNEL UP/DOWN
buttons are used on the monitor or the remote
control. (B) To tune to weak or marginal channels
with the CHANNEL UP/DOWN buttons, press the
SKIP/SEARCH button on the Remote Control Unit
until “SKIP MODE OFF” is displayed on the bottom
of the screen. Tune to the desired channel using
the CHANNEL UP/DOWN buttons or go directly to
the channel by using the 0-9 buttons on the Remote
Control.
3. To ERASE a channel, press the ERASE/WRITE
button on the Remote Control Unit until “MANUAL
MEMORY XX ERASE” is displayed on screen. To
STORE a channel, press the button until the
MANUAL MEMORY XX ADD is displayed on
screen.
Note: Please refer to page 2 for more information on TV reception.
TURNING THE LCM1041TV ON OR OFF
1. Sliding the screen release lock forward will
unlock the LCD screen and it will drop down
slightly. (Pivot the screen downward until a
comfortable angle is reached). After the unit has
been turned on and is displaying a picture,
adjustment to the viewing angle can be made by
pivoting the screen to optimize the picture quality.
The friction hinges will hold the screen in
position while the system is in use.
2. Pressing the power button on the pod or remote
will alternately turn the system on or off. When in

use the internal back lighting will illuminate the
controls.
3. Remember to turn the unit off and pivot the LCD to
the locked position when not in use.
Remote Sensor
The LCM1041TV incorporates an infrared sensor, which relays the signals from the remote control to
allow the LCM1041TV and VCP to be controlled simply by pointing it’s remote control at the remote
sensor. This provides control of auxiliary equipment such as a Flexvision Video Cassette Player. The
infrared sensor can relay signals from any manufacturer’s remote control to it’s respective component
connected to the Video 1 and 2 inputs, such as a DVD player. In this case you must use the remote
control supplied with the DVD player.
Remote Sensor
CHANNEL
AP
TV/AV
PIC.
SEL.
OPTIONAL ACCESSORIES
Wireless Headphones
The LCM1041TV includes a RF transmitter (P/N WTXRF02) for use with optional Flexvision wireless
headphones. Tuning the headphone switch on, and wearing them activates the internal micro switch,
(which includes a tuning knob to tune into the preset frequency on the RF transmitter), which will activate
the internal RF receiver. The volume can be adjusted separately with the controls on the headset. See
the documentation accompanying your Flexvision wireless headphones.

Auxiliary A/V Stereo Inputs Jack
The LCM1041TV may be equipped with an auxiliary A/V stereo input connector (optional).
These inputs are provided to facilitate the temporary connection of optional audio/video equipment, such
as a camcorder or video game system. To play a source with these inputs, an RCA patch cord is
required to connect the audio/video signals to their respective jacks. Mono audio sources will require
the use of an RCA Y-cable (P/N 0892165) to connect to both right and left inputs. If patch cords are
installed into the AUX inputs, the AUX INPUT 2 will be temporarily bypassed. Once the connections
have been made, turn the LCM1041TV on and press the source button on the LCM1041TV or the
TV/Video button on the remote control until “Video 2” is displayed on the screen. The unit will now play
the audio and video signals from the accessory connected. The remote control will not operate the
accessory components.
Wired FM Modulator (P/N 0190730)
Your video system may be equipped with an RF modulator, that allows you to listen to the LCM1041TV’s
audio signal by tuning your vehicle’s radio to the selected frequency, (88.7 or 89.1- check with your
installer) and tuning on the remote mounted RF modulator switch. (In most cases this toggle switch will
be located underneath the driver’s side of the dash, check with your installer for the exact location.)
Whenever the RF modulator is on, broadcast radio reception will be poor. Turning the remote mounted
toggle switch off will allow for normal radio reception.
Video Output
The LCM1041TV provides a video output for an optional video monitor(s). This output will provide a
video signal that duplicates the signal displayed by the LCM1041TV to an additional monitor or video
display. Please see your installer for more information.

Flexvision Video Cassette Player (Aux Video 1)
In most installations a VCP will be connected to the “Video 1” input. To view a video cassette, turn the
AVP7000/ AVP7285 on and press the source button on its control panel or the TV/Video button on the
remote control unit until “Video 1” is displayed on the screen. The VCP may also be operated with the
remote control or the buttons on its face. Inserting a tape into the VCP will turn it on and automatically
activate the play mode. If a rewound tape had been loaded into the VCP, prior to its activation press
play on the VCP or the remote control to view the tape. For more information see the owner’s manual
accompanying your VCP.
Yellow (Video out)
Red (Audio Out R)
White (Audio Out L)
Yellow RCA(Video)
White RCA(Audio Left)
Red RCA(Audio Right)
4 PIN
Power
Connector
2 PIN IR
Connector
Accessory
Harness
DIN 1
PIN 3 – Audio(L)Out/Grey
PIN 4 – Audio GND/Black
PIN 5 – Audio(R)Out /Green
PIN 1 – Power/Red
PIN 2 – Power GND/Black
To FM Transmitter
DIN 2
TYPICAL SYSTEM CONNECTIONS
Antenna
