OPERATION
MANUAL
128-8312
HR7008PKG
Two Specific Vehicle Headrests
With 7" LCD Monitors Touch Screen control
and Built-In
DVD Player for Rear Seat Entertainment

Licensed under one or more of the following patents,
Patent NOS. 5,775,762 and 5,927,784
2
IMPORTANT
Installation of headrest products require careful planning and preparation. Be extremely careful of seats that have airbags built into them.
Keep wiring away from any air bag wiring (usually identified by yellow connectors and yellow wire jackets). Damage to air bag wiring can
result in personal injury to vehicle occupants. If you have any questions regarding wire routing or installation in a vehicle, please contact
Audiovox Technical Support at 1-800-225-6074.
When connecting power and ground in a mobile video installation, insure that the ACC wire is fused at the point where it is connected to
the vehicle ACC wiring. Failure to do so can result in damage to the vehicle if a short circuit develops between the vehicle connection point
and the mobile video product.
An LCD panel and/or video monitor may be installed in a motor vehicle and visible to the driver if the LCD panel or video monitor is used
for vehicle information, system control, rear or side observation or navigation. If the LCD panel or video monitor is used for television
reception, video or DVD play, the LCD panel or video monitor must be installed so that these features will only function when the vehicle is
,
in "park" or when the vehicle s parking brake is applied.
An LCD panel or video monitor used for television reception, video or DVD play that operates when the vehicle is in gear or when the
,
parking is not applied must be installed to the rear of the driver s seat where it will not be visible, directly or indirectly, to the operator of the
motor vehicle.

3
HR7008PKG
The HR7008PKG contains two vehicle specific head-rests. Each has a 7" Monitor with touch screen control and built-in DVD Player. This
,
system allows the users to either watch individual DVD s or watch the same DVD on both monitors. Both users can also share others program.
The full function remote control can operate either unit by selecting MI or M2 on the remote.
Quick Start Guide
1. Turn on the M1 monitor, push the center tab at the top of the screen, screen down.
2. Insert a DVD, CD or MP3 disc into the slot, disc label toward driver.
3. The disc will start playing.
4. Tilt the monitor to a comfortable viewing position (the headrest itself can be tilted forward to help achieve a comfortable
viewing position).
5. Each wireless headphone has a CH A/CH B switch. When sitting in front of the M1 screen, use the CH A switch setting. When sitting
sitting in front of the M2 screen, use the CH B switch setting. Set the headphone to the proper channel and press the Power
On/Off switch. The power indicator will light up red. Turn the volume down to its lowest setting before putting them on your head.
6. When the DVD menu appears, select the menu item using the cursor keys and touch the OK or Play button.
7. If audio playback through the vehicle radio is preferred, use the FM transmitter On/Off button on the remote control. Set the vehicle
radio to the channel selected on the M1 monitor. If interference with a local radio station occurs, set the FM modulator to one of the
other 16 radio frequencies using the CHANNEL SELECT button on the remote control.
8. Turn on the M2 Monitor using the power button on the front of the screen or remote control.
9. Tilt the screen to a comfortable viewing position (the headrest itself can be tilted forward to help achieve a comfortable viewing position).
10. Touch the screen and touch on M1 or use remote control to press SOURCE to view program from M1 or select from the other
available sources DVD, MEMORY CARD, USB, A/V IN or SMART PORT AUX for M2 Monitor.
NOTE: To operate the M1 screen, press M1 on the remote control.
To operate the M2 screen, press M2 on the remote control.

1) The HR7008PKG SYSTEM is a versatile audio / video system with built-in DVD player HR7008M1/M2 which includes two touch screen monitors,
that can accept an Audio / Video input and independent AUX input. A separate audio output is provided for connecting an optional FM Modulator
to the vehicle's radio.
2) The M1 Monitor (HR7008M1) is comprised of a 7" touch screen TFT LCD monitor with built-in DVD player that allows the user to select from the
DVD/SD/USB, Source from M2, AV input, Smart Port/AUX, and the Game source. The M1 monitor has a built-in infrared audio transmitter (CH A)
for use with the optional two-channel wireless headphones (CH A).
3) The M2 Monitor (HR7008M2) is comprised of a 7" touch screen TFT LCD monitor with build in DVD Player that allows the user to select from the
DVD /SD/USB, Source from M1, AV input and Smart Port. The M2 monitor has a built-in infrared audio transmitter (CH B) for use with the optional
two channel wireless headphones (CH B).
4) The monitors will show all of the functions with the comprehensive OSD and touch screen UI OSD.
5) The optional two-channel wireless Headphone sets have an A-B switch that allow the user to select the audio from either M1 (HR7008M1, CH A)
or M2 (HR7008M2,CH B).
6) Using different IR codes, the M1 Monitor will only respond to the remote control unit when the Monitor Select (M1) button on remote control is
pressed. The M2 Monitor will only respond to the Remote Control unit when the Monitor Select (M2) button on remote control is pressed.
7) The wired headphones allow the user to listen to audio from the system.
8) The M1 (HR7008M1) and M2 (HR7008M2) Monitor will accept an audio / video input through the 1/8" jack located on the front of the unit. The
audio / video device could be a video game system, video camera, or other input device.
HR7008PKG SYSTEM OVERVIEW
SMART PORT
HR7008M1/HR7008M2
4
WIRED HEADPHONE
USBSMART
PORT
TOUCH SCREEN UI OSD

9) Pivot the screen until a comfortable viewing angle reached. The internal lock limits the screen to a maximum adjustment of 19 degrees from closed
position, the headrest itself can be tilted forward to help achieve a comfortable viewing position.
10) Insert/Eject disc and SD Card
5
19 degrees
Insert/Eject disc
Insert/Eject
SD Card
shaft angle
Inner Ring
Hook
Closed Position
SMART
PORT
PULL UP
USB
JACK
WIRED HEADPHONE
JACK
PUSH UP
19 degrees

6
Control Function Descriptions for M1 and M2 Monitor
CONTROLS AND INDICATORS DIAGRAM
M1 / M2 Panel Control
1. DVD disc insertion slot
2. EJECT Button - Press this button to eject the disc.
3. SD Card
4. MENU/POWER Button with Power Indicator LED
5. Smart Port
6. IR Transmitter LEDS
7. USB
8. Wired Headphone Jack
9. IR Senser
10. OSD Type Touch Screen
SMART PORT
1
2
3
4
5 6 7 8
9
10

7
OSD Touch Screen for HR7008 M1/M2
Main page
To turn on the unit by pressing
the power button at left
bottom.
i) Touch the panel to call the
MENU display or press
power button again.
ii) Screen turn on in blue
screen with
M1 unit:
DVD, M2, PICTURE
CONTROL, MEMORY
CARD, A/V IN, SCREEN
MODE, USB, SMART
PORT AUX, MUTE, GAME
& FM MODULATOR.
M2 unit:
DVD, M1, PICTURE
CONTROL, MEMORY
CARD, A/V IN, SCREEN
MODE, USB, SMART
PORT AUX & MUTE.
DVD
Touch the DVD icon to call the DVD display then insert DVD into
slot with label face toward front. The disc will load and read
automatically.
MAIN PAGE
M1
M2
MEMORY CARD
Insert Memory Card / SD Card into SD CARD slot.
Touch the screen or MENU to select the MEMORY CARD display.
M2
Touch the screen or MENU to select M2 display and link with M2
unit display for sharing video & audio.
USB
Plug the devices to USB interface.
Touch the screen or MENU to select the USB display.
A/V IN
Touch the screen or MENU to select A/V IN display and link to
external audio & video supply.
SMART PORT AUX
Touch the screen or MENU to select SMART PORT AUX display.
M1
Touch the screen or MENU to select M1 display and link with M1
unit display for sharing video & audio.

GAME
Touch the screen or MENU to select GAME display. (For M1 only)
The GAME selection is controlled by wireless game controller.
PICTURE CONTROL
Touch the screen or MENU to
select PICTURE CONTROL display.
The contents are selecting BRIGHTNESS, CONTRAST, COLOR,
TINT, RESET & OK.
For adjustment at bottom key by touching +(higher) or
- (lower) then touch OK to exit page.
SCREEN MODE
Touch the screen or MENU to select SCREEN MODE display.
Select and touch the screen WIDE(16:9), NORMAL(4:3) or
SCREEN OFF then touch OK to exit page.
MUTE
Touch the screen or MENU and touch MUTE to attenuate audio
and turn on audio back to normal by touching MUTE again.
FUNCTION KEY CONTROL
Touch the screen to appear function key as shown.
i) Left side key for volume control by touching speaker icon at
above to tone up and bottom to tone down.
ii) Right side key for title/subject selection by touching UP,
RIGHT, LEFT & DOWN then touch "OK".
iii) Bottom key for playback
control by touching
PLAY/PAUSE, FAST
BACKWARD, FAST
FORWARD, BACK, NEXT &
STOP.
touching UP, RIGHT, LEFT
& DOWN then touch "OK".
RESET
BRIGHTNESS CONTRAST COLO
RTINT
OK
BRIGHT NE SS 1 6
FM MODULATOR
Touch the screen or MENU to
select FM MODULATOR display.
(For M1 only)
To turn on FM Modulator by
touching FMM MOD ON then select frequency transmission by
touching -(lower) or +(higher) [88.1MHz ~ 91.1MHz] then touch
OK.
To turn off FM Modulator function by touching FMM MOD OFF
then touch OK to exit page.
8

9
REMOTE CONTROL WITH
WIRELESS GAME CONTROLLER OPERATION
Battery Installation
Before attempting to operate your Remote Control, install the
batteries as described below.
1) Turn the Remote Control face down. Using your finger, slide
the battery cover off in the direction of the arrow.
2) Install Three "AAA" batteries. Make sure that proper polarity
(+ or -) is observed.
3) Align the cover tabs with the remote control and slide the
cover until it locks.
The remote control will operate the HR7008M1/HR7008M2. It is not
a universal remote control and will not control equipment from other
manufacturers.
Battery Cover
WIRELESS
1. Use the GAME/REMOTE selector switch to Game position.
2. Use the Select button (page up & page down) to display the
games (1-32). Then use the direction buttons to move the
arrow to the desired game. Press Start to select the game.
3. Press Start to begin the game. Press Start again at any time
to pause the game.
4. Press RESET to return to the game menu.
5. P1/P2 selector switch is use for playing 2 player games. P1
is for M1 player, P2 is for M2 player.
6. M1/M2 selector switch to M1 position is for M1 & M2 player.
7. Use the GAME/REMOTE selector switch to Remote position
after use
GAME CONTROLLER FUNCTIONAL
DESCRIPTION
.
DIRECTION KEYS
P1/P2
RESET
SELECT
START
GAME/REMOTE
SELECTOR SWITCH
TB
TA
A
B
Back View
M1/M2

10
Function control is available on the unit or touch screen and the
remote control.
Function not available in this model.
*
**
1.
2.
3.
4.
5.
6.
POWER Button*
Press this button to turn the unit ON and OFF.
MONITOR SELECT
M1 Button - Change the remote control code to enable the control
of HR7008M1 Monitor.
M2 Button - Change the remote control code to enable the control
of HR7008M2 Monitor.
TV Mode Select Button**
Switches certain function keys on the remote control for TV
functions.
DVD Mode Select Button
Switches certain function keys on the remote control for DVD
functions.
SYSTEM MENU Button**
Allow the user to access the system menu. Press cursor (pq)
buttons to select desired screen mode, OSD language and source
default on power up.
SOURCE Button*
For M1: Each time the button is pressed, the audio /video source will
change in the following sequence: DVD > M2 > AV IN >
SMART PORT / AUX > GAME
For M2: Each time the button is pressed, the audio /video source will
change in the following sequence: DVD > M1 > AV IN >
MAIN FUNCTION DESCRIPTION
POWER
FMM
ON/OFF
SUBTITLE
DVD
SOURCE
DVD
TV
MUTE
SYSTEM
MENU
RETURN
IRT
ON/OFF
SOURCE
AUTO
MEMORY
SKIP/
SEARCH
ERASEL
WRITE
123
456
78 9
0
EJECT
CHANNEL
SELECT
DAY
NIGHT PIX
OK
AUDIO
REPEAT ZOOM A-B
MENU SETUP
M1 M2
DISPLAY
1
VOLUME
2
3
4
37
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
36
35
34
33
32
31
30
29
28
27
26
25
24
23
22

11
7.
8.
9.
10.
11.
12.
13.
14.
AUTO MEMORY Button (AUTO PROGRAM Button)**
When the AUTO MEMORY button is pressed, all channels are searched and channels that are detected with signals of sufficient levels are
automatically stored in memory.
SKIP / SEARCH Button**
This button selects between SKIP and SEARCH mode. In "SKIP mode" the TV tuner will tune and stop on channels that are programmed
into memory when the CHANNEL UP / DOWN buttons are used. When the SKIP mode is disable, the TV will stop on all active channels.
ERASE / WRITE Button**
While tuned to a channel, pressing this button will alternately store or erase the channel from memory.
DISPLAY
Press to display current disc information while the disc is playing. Press cursor (pq) buttons to select the Title or Chapter.
For Title/Chapter selection use the numeric buttons to enter the desired Title Chapter selection.
FMM ON / OFF Button*
Turns the wireless FM Modulator on or off.
CHANNEL SELECT Button*
Selects the wireless FM Modulator Frequency (CH1 88.1MHz, CH2 88.3MHz, CH3 88.5MHz, CH4 88.7MHz, CH5 88.9MHz, CH6 89.1MHz,
CH7 89.3MHz, CH8 89.5MHz, CH9 89.7MHz, CH10 89.9MHz, CH11 90.1MHz, CH12 90.3MHz, CH13 90.5MHz, CH14 90.7MHz,
CH15 90.9MHz, CH16 91.1MHz)
RETURN Button
Press Return Once : Go to disc menu.
Press Return Twice : Go to movies playback.
REPEAT Button
Allows the user to repeat a selected title, chapter, or track.

12
AUDIO Button
Press to display and select the available AUDIO languages in DVD mode. Each time you press the button, the language changes.
Note: The languages for audio vary from disc to disc.
MENU Button
Allows the user to access the DVD (DVD MODE).
SUBTITLE Button
Press to display and select the available subtitle language in DVD mode. Each time you press the button, the subtitle language changes.
Note: The type and number of languages for subtitle vary from disc to disc.
PAUSE (II) Button*
Allows the user to pause the playback. Pressing pause again or pressing the Play Button will resume normal playback.
PREVIOUS (9) Button*
Press to return to the previous chapter or track.
STOP (<) Button*
Press to stop playback.
SCAN BACKWARD (7) Button*
Press to search in a backward direction. Press repeatedly to change the search speed from 2, 4, 8, and 16 times the normal speed.
PLAY Button*
Press to activate the play mode when a disc is loaded in the disc compartment.
SCAN FORWARD (8) Button*
Press to search in a forward direction. Press repeatedly to change the search speed from 2, 4, 8, and 16 times the normal speed.
NEXT (:) Button*
Press to skip to the next chapter or track.
15.
16.
17.
20.
21.
19.
22.
23.
24.
18.

13
OK Button (ENTER)*
Used to implement a selected setting or menu option.
CURSOR / CHANNEL UP DOWN (pqtu) *
Use these buttons to navigate the menu selections on the screen.
Use the CHpto increase the channel number and use CHqto decrease the channel number. **
SETUP Button
Press to display the Setup Menu which allows the user to change the DVD player options such as TV DISPLAY, OSD LANGUAGE,
PARENTAL CONTROL etc. Refer to the settings and Adjustments section for more information.
ZOOM Button
Press this button to enlarge the picture when playing a DVD disc.
A-B Button
Allow user to repeat the playback from point A to point B.
Press A-B buttonOn-Screen DisplayDVD player
IRT ON/OFF Button
Turns the Infrared Transmitter IRT ON or OFF for IR Wireless Headphones. Pressing M1 then IRT ON/OFF will control the IR
Transmitter for M1.
29.
Once
Twice
3 times
4 times
Press ZOOM button
Enlarge the picture 1 times of the original size
Enlarge the picture 2 times of the original size
Enlarge the picture 3 times of the original size
Picture is returned to original size
DVD player perform
25.
26.
28.
Once
Twice
3 times
Repeat A-
Repeat AB
AB Off
Mark the beginning of the section to repeat (Set point A)
Mark the end of the section to repeat (Set point B)
Cancel the A-B repeat function
27.
30.

14
31. MUTE Button*
Press this button to mute all the audio.
Pressing the button again restores the sound to the previously set level.
DAY / NIGHT Mode Button**
This control toggles the unit between "Day" and "Night" LCD illumination modes. In the "Day" mode, the LCD backlit intensity is at
maximum. In "Night" mode, the LCD backlit is dimmed to a preset level that is more suitable for low light operation.
PIX Button (Picture Select)*
Each time this button is pressed, the on screen picture adjustment displays the "adjustment bar" for BRIGHTNESS, CONTRAST,
COLOR, TINT or RESET. Once the desired adjustment bar is displayed, use the VOLUME(+)/ VOLUME(-) button to adjust the setting.
The display will automatically turn off if no adjustments are made within 6 seconds, or is any other button is pressed.
VOLUME DOWN (-) or UP (+)*
Press to decrease or increase the level of the picture adjustments.
NUMBER Buttons
Allow the user to enter numbers 0 to 9 for selection of selection of CD tracks, DVD chapters and password.
DVD Source*
This button is only active when remote control is in DVD mode. Each time the button is pressed one of the source (DVD, Card Reader
and USB) will be selected. If the Card Reader and USB are not plugged in, it will remain on DVD Source. Press to change source in
sequence of DVD > SD > USB.
EJECT (?) Button**
This button is used to eject the disc.
34.
32.
33.
35.
36.
37.

15
SETTINGS AND ADJUSTMENTS
The Setup Menu contains features and options that let you customize your DVD player. For example, you can set a language for the on-
screen display or prevent DVD playback for children.
Using the Setup Menu
1. Press the SETUP button on the remote. The Setup Menu appears on the screen as shown per diagram.
Subtitle
Audio
OSD Language : English
: Off
: English
Language
Video
Rating
Misc
2. In order set the desired option, move the highlight into the setup area using the cursor button .
3. After entering the setup area, highlight the desired option using the cursor button por q.
4. Press uto move the highlight to the different options for the selected item. Press por qto select the desired options, and then press
ENTER to confirm the selection.
5. Repeat steps 3~4 to continue setting the options that reside on the same Setup Page.
6. To change to another Setup page, press tuntil the highlight moves back to the icon on the top part of the Setup Menu.
Then, repeat steps 2~5.
Exiting the Setup Menu
Press the SETUP button again only.
u

16
TV type
TV display 4:3
16:9
Language
Video
Rating
Misc
Subtitle
Audio
OSD Language English
French
Spanish
German
Italian
Language
Video
Rating
Misc
LANGUAGE SETUP
Language for On-Screen Display
OSD MENU: The OSD MENU setup allows you to select the language for the on-screen display.
The user can either select English, French, Spanish, German or Italian for the OSD language.
SUBTITLE SETUP
select "SUBTITLE" using pqbutton, then press ubutton to enter the Sudmenu. Select the subtitle you
desire using pqbutton, then press "OK" to confirm the setting. Press tbutton to return.
Note: The subtitle selection is only available for discs that are recorded in the above listed languages. If the selected,
language is not available, the player will play and display on the screen the original language contained in the disc.
AUDIO SETUP
select "AUDIO" using pqbutton, then press ubutton to enter the Sudmenu. Select the audio you desire
using pqbutton, then press "OK" to confirm the setting. Press tbutton to return.
Note: The audio selection is only available for discs that are recorded in the above listed languages. If the selected,
language is not available, the player will play and display on the screen the original language contained in the disc.
VIDEO SETUP
TV Display
The TV DISPLAY setup allows you to adjust screen setting (aspect ratio).
4:3 This displays the wide picture with black bands on the upper and lower portions of the screen.
16:9 This displays a wide picture with black bands on the upper and lower portion of the screen.
The bandwidth will vary, depending on the aspect ratio of the disc.
Subtitle
Audio
OSD Language English
French
Spanish
German
Italian
Japanese
Chinese
Thai
Off
Language
Video
Rating
Misc
Subtitle
Audio
OSD Language
English
French
Spanish
German
Italian
Japanese
Chinese
Thai
Language
Video
Rating
Misc

17
The rating level can only be changed when the displayed lock is open. For first time use to change parental
control, using cursor ubutton to enter parental mode, key in the default password (3308) and press OK.
Press OK button again to select the parental level, select the level and press OK. To change the password to
your own password press "Change Password" mode and enter the default password (3308) and press OK.
Press OK button and again and key in a new four digit password. After complete press OK button to end the
process.
RATING SETUP
Rating
This item allows you to limit the content of movie playback from G to Adult. The lower the value, the more strict the control.
G
PG
PG - 13
R
NC - 17
Adult
Note: The Default Password is 3308. This password is always effective even after you have selected your own password and changed it. To avoid the possibility
of others using the default password to set the parental level and change the password, you can record this default password in another area and delete it from
this manual. Some discs can be limited depending on the age of users while some discs cannot.
TV Type
The TV TYPE setup allows you to select the system to fit to the color system of the TV to be connected.
NTSC - Select this type for NTSC TV
PAL - Select this type for PAL TV
Multi - Select this type for multi-system TV
Parental : 6.Adult
Password
Enter Password
Language
Video
Rating
Misc
Parental : 6.Adult
Password
Language
Video
Rating
Misc

18
Screen Saver : On
Load Factory
Language
Video
Rating
Misc
Screen Saver
Load Factory
Load Factory
Yes No
Language
Video
Rating
Misc
Misc SETUP
select "MISC" using pqbutton, then press ubutton to enter the Miscmenu. Select the subtitle you desire
using pqbutton, then press "ENTER" to confirm the setting. Press tbutton to return.
Load Factory
Load Factory allows you to reset all options to factory settings.
* This function will not affect the Rating control settings.
Screen Saver Off
Load Factory
On
Language
Video
Rating
Misc
Screen Saver
ON -Screen saver will appear
OFF -Screen saver will not appear
Note: The DVD player will enable the Screen Saver mode if the unit is inactive for approximately 2 minutes.
Playing DVDs
1. Press the DISPLAY button on the remote control to display the status banner. The banner includes title, chapter, angle, audio, subtitle, title
selection & chapter selection.
2. Title Selection
Press numeric(0~9) buttons to initiate a change of title selection. Then press OK button to implement the selection.
3. Chapter selection
Press numeric(0~9) buttons to initiate a change of chapter selection. Then press OK button to implement the selection.
As you toggle through the options, the repeat option changes at that time. The track, for example, repeats once that track has ended. The
selected repeat option loops repeatedly until you turn it off.

19
Playing MP3 Discs
MP3 is a format for storing digital audio. An audio CD-quality song can be compressed into the MP3 format with very little loss of quality,
while taking up much less space. CD-R discs that have been encoded in MP3 format can be played on your DVD player. The DVD player
plays the songs in the order they were burned on to the disc.
When playback is started the elapsed time of the track that is playing will be displayed.
00:00:01
03/13 /myf /001.MP3
Music Play ing
Repeat
Mode
: All
: Shuffle
Edit Mod e
Mp
001
002
003
004
005
1/12
Repeat : of f
Mp
001
002
003
004
005
Flat Mod e
Filter A ud io
Vid eo
Selecting Folders and Songs
When a device containing MP3 files is loaded in the player, the navigation menu appears automatically.
1. Press por qto move the highlight to the desired folder (if present) on the left side of the menu and press
OK. The songs in the folder will be displayed on the screen.
2. Press por qto move the highlight to the desired track containing the song and press OK to begin track
playback.
Skipping Songs
Use the Next (:) button on the remote control to move to the next song. Use the Previous (9) button to move to the previous song.
The Filter function applies th the following formats:
Audio - Audio data format (MP3, WMA)
Photo - Photo data format (JPEG)
Video - Video data format (MPEG , )
Selecting a Play Mode
Filter (For MP3 & JPEG only)
Fliter Mode enables or disables the display of files contained on the media based on their file extension.
Music Play ing

20
1/12
Mp
001
002
003
004
005
Repeat : Of f
Mode : No rm al
Flat Mod e
1/12
Mp
001
002
003
004
005
Repeat : Of f
Mode : No rm al
Flat Mod e
Flat Mode: play the entire disc
This mode is always on (default). During the Flat Mode all the data folders with Mp3, JPEG & movies will be
played in sequence. If the Flat Mode function is off, it will only play the selected folder; other folders are disabled.
Repeat: play repetitive
Repeat function has 4 options: Off, Single, Folder, All. Move cursor to Repeat function and press OK,
Off/Single/Folder/All are displayed in that order. Repeat default is Off;
Off Turn of repeat function
Single Repeat the song being played until STOP is pressed.
Folder Play all songs in a folder repetitively
All Play all songs on the disc repetitively
Mode: play mode
The Mode function has 4 options: Normal, Shuffle, Music Intro. Move cursor to the desired Mode function and press OK;
Normal/Shuffle/Random/Music Intro are selected in that order. The Mode function default status is Normal.
Normal: Play all songs in folder once
Shuffle: Play songs in a folder in a shuffled order. Each song in the folder is played only once.
Random: Play songs in a folder in a random order. Each song in the folder is played only once.
Music Intor: Play each song in order in the folder for 10 seconds
Remark-- The purpose of the Music Intro function is to provide the user with a sample of each song for 10 seconds, thereby making it easy
to select and listen to a favorite song.
Random and
Music Play ing
Music Play ing
