Audiovox D1929B User manual

D1929B
9 inch Portable DVD Player
Reproductor DVD Port til de 9 pulgadas

2
English
ImportantSafety Instructions
Some ofthefollowing information maynotapplyto yourparticularproduct;
however, as withanyelectronic product, precautions should be observed
duringhandlingand use.
lRead these instructions.
lKeep these instructions.
lHeed allwarnings.
lFollowall instructions.
lDo notuse this apparatus nearwater.
lClean onlywith dry cloth.
lDo notblockanyventilation openings.Install in accordance withthe
manufacturer s instructions.
lDo notinstall near anyheat sourcessuch as radiators,heat
registers, stoves,orother apparatus(including amplifiers)that pro-
duce heat.
lDo notdefeatthesafetypurpose ofthe polarized orgrounding-type
plug. Apolarized plughas twoblades withone widerthan the other.
A grounding type plughastwobladesandathird groundingprong.
Thewideblade or thethird prong isprovidedforyoursafety. If the
providedplug does not fit into youroutlet, consultanelectricianfor
replacementofthe obsolete outlet.
lProtect the power cordfrom being walked onor pinchedparticu-
larly at plugs, convenience receptacles, and the point where they
exit from the apparatus.
lOnly use attachments/accessories specified bythe manufacturer.
lUse onlywith thecart, stand, tripod,
bracket, or table specifiedby the
manufacturer, or sold withthe apparatus.
When a cart is used, use caution when
movingthe cart/apparatus combinationto
avoid injuryfrom tip-over.
lUnplugthis apparatusduringlightning storms or when unused for
longperiods oftime.
lReferall servicingtoqualified service personnel.Servicing is re-
quired when the apparatus has been damagedin any way,suchas
power-supply cord or plug is damaged, liquid has been spilled or
objects havefallen into the apparatus,theapparatus hasbeenex-
posed to rain or moisture, does not operate normally,or has been
dropped.
]

3
AdditionalSafety Information
lApparatus shall not be exposed to dripping or splashing and no
objects filled with liquids, suchas vases, shall be placed on the
apparatus.
lAlwaysleave sufficientspacearound theproductfor ventilation.Do
not placeproductinor on a bed, rug, ina bookcase or cabinetthat
may prevent air flow throughvent openings.
lDo notplace lighted candles,cigarettes,cigars,etc.on the product.
lConnect power cordonlyto AC power sourceas marked onthe
product.
lCareshouldbe takensothat objectsdo not fall into the product.
lDo not attempt to disassemble the cabinet. This product does not
contain customer serviceable components.
lDonot use the unit immediately after transportation from a cold
place toa warm place; condensation problems mayresult. Wait
foraboutonehour tillthemoisture evaporatesbefore operating
theunit.
lWhen using your portable DVD player, donot sit or stand too
close to the screen.
lTouse aheadset safely,pleasekeep thefollowingin mind:
-Do not play your headset at a highvolume. Hearing experts
advise against continuousextendedplay.
-If you experienceringing inyourears,turn down the volume or
stop usingthe headset.
-Do not usea headset while driving a motorized vehicle or riding
abike. It maycausea traffichazard andisillegal in many areas.
-Even ifyourheadset is anopen-airtype designed tolet youhear
outside sounds, don tturnupthe volume so high that can t hear
sounds around you.
lCAUTION! CD and DVD products utilize alaser. Do not tryto
open the product. Referall servicingto qualifiedservice
personnel.
lCAUTION! Danger of explosion if batteryisincorrectlyreplaced.
Replace only withthe sameor equivalent type.
lWarning:Your DVD player contains a batteryand charging sys-
tem which is designed to workin temperatures that donot ex-
ceed50oC (122oF). Leavingthis product in a closed automobile
or inthe trunk of anautomobilewhere temperature mayexceed
50oCmayresult inpermanentbattery damage, fire, or explosion.
Pleaseremove your product from the automobile when youexit,
do not place yourproductinthe trunkof yourautomobile,anddo
not leave your product in any location where temperature may
exceed 50oC.

4
English
WARNING: TO PREVENTFIREORELECTRICALSHOCK HAZARD,DO NOT
EXPOSE THIS PRODUCT TO RAINORMOISTURE.
FCC Information
Thisdevicecomplies with part 15 oftheFCC rules.Operationissubject
tothe following two conditions: (1)This device maynot cause harmful
interference,and(2)This devicemustacceptanyinterferencereceived,
includinginterferencewhich maycause undesired operation.
Thisequipmenthas been tested and found tocomply withthe limitsfora
Class Bdigitaldevice, pursuantto Part15of the FCCRules.These
limits aredesigned to provide reasonable protectionagainst harmful
interferenceinaresidential installation.Thisequipmentgenerates,uses
and can radiate radio frequency energy and, ifnot installed andused in
accordancewiththeinstructions,maycauseharmfulinterferencetoradio
communications.However, there is no guarantee that interference will
not occur in a particular installation.
Ifthis equipment does cause harmfulinterference to radio or television
reception,which can be determined byturningthe equipmentoff and on,
the user is encouragedto tryto correct the interference byone or more
ofthe followingmeasures:
-Reorientor relocate the receiving antenna.
-Increase theseparationbetween theequipment andreceiver.
CAUTION

5
Service Information
This productshould be servicedonly bythose specially trained in appro-
priate servicing techniques. For instructions on howto obtain service,
refer to the warrantyincluded in thisuser manual.
Manufacturer/Responsible Party
Audiovox Electronics Corp.,
150Marcus Blvd., Hauppauge,NY11788
For Your Records
Keep your sales receiptfor proofofpurchase to obtain warrantyparts
and service.
In theevent thatservice shouldberequired,you mayneedboth themodel
numberandtheserialnumber. Inthe space below,recordthe date and
place ofpurchase, and the serial number:
Model No.
Date of Purchase
Placeof Purchase
SerialNo.
-Connect the equipment into an outlet ona circuit different from that to
which the receiver is connected.
-Consult the dealer or an experienced radio /TVtechnicianfor help.
In accordance with FCC requirements, changes ormodificationsnot
expresslyapprovedby manufacturer could voidtheuser s authorityto
operate thisproduct.
This class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme àla norme
NMB-003duCanada.

6
English
Content
A. Introduction .............................................................................7
B.DVDandDiscInformation.................................................... 7
C.Contents.................................................................................8
D.Poweringand installation ....................................................... 8
E.VehicleInstallation ..................................................................9
F.Controls,Indicators,and Connectors....................................10
G.Loadingand PlayingaDisc ..................................................11
H.BasicOperation....................................................................... 12
I.Menu ....................................................................................... 13
J.Display..................................................................................... 13
K.Playing AudioCDs..................................................................19
L.PlayingJPEGFiles.................................................................20
M.Connectingto Other Equipment.............................................21
N.Setup ..................................................................................... 22
O.Specifications .........................................................................30
P.RechargeableBuilt-inBattery use..........................................30
Q.Troubleshooting ...................................................................... 32

7
A.Introduction
Thankyou for choosingtheD1929B portable DVD player. The main
features include a9" wide Screen (16:9 Aspect Ratio) Liquid Crystal
Display (LCD) monitor anda DVD player. Theunit appliesthe latest
state ofthe art electronics and is designed for use in hotels, offices
or your home. Theunit is constructed toprovide years of reliable,
trouble-free service and is compact so that you cantake it with you
anywhereand is designed forquickand easyinstallation.Please read
theentire instructionmanual suppliedwith thisproductprior to using.
Thedocumentation will assist youinusing the system properlyto
obtain thebest equipment performance. Please savethismanual for
later use.
B. DVD andDisc Information
DVD CopyProtection -This Productincorporates copyright
protection technologythat is protected by method claims of certain
U.S. Patents and other intellectualproperty rights owned by
Macrovision Corporation and other rights owners. Use ofthis
copyright protection technology must be authorized byMacrovision
Corporation, and is intended forhome and other limited viewing
uses onlyunless otherwise authorized byMacrovision Corporation.
Reverse engineeringor disassemblyis prohibited.
DVDRegional Code - Your DVD player
has been designed to process regional
management information that is stored
on DVD discs. Theregional code for your player is1 (The U.S.,U.S.
Territories andCanada). OnlyDVDdiscs that haveregional codesof
1or ALL(for all regions) canbe played by your player.
Disc - Do not use irregularly shapeddiscs such asheart orstar-
shaped discs as they maycause theunitto malfunction. Do notstick
paper, tapeorglue onthe disc. Do notexpose the discto direct sun-
light or heat sources suchas hot air ducts. Do not touch the surface
ofdisc.Handle the discby its edge. Cleanthe discby wipingthedisc
from thecenter out with a cleaning cloth. Removethe disc from the
unit andstoreitinitscaseafterplaying. Some playback operationsof
discs maybeintentionallyfixedby software producers. Since this
unit plays discs accordingto the disc contents the software produc-
ersdesigned,someplayback features may not beavailable. Also
refer to the instructions suppliedwith the discs.

8
English
C. Contents
1. 1 x9 Portable DVD Player
2. 1 xRemote Control with battery(CR2025)
3. 1 xAudio/VideoCable
4. 1 xAC to DCAdapter
5. 1 xAutomotivePowerAdapter
6. 1 xInstructionManual
7. 1 xCarryingBag
8. 1 xProductRegistration Card
9. 1 xeMusic Card
10. 1xCustomer Service Card
D. Powering and Installation
1. Powering the System Indoors (Refer to Figure 1)
Plugone endoftheACto DCadapter into theDCinputjackonthe
left side ofthe main unit, then plugthe otherend into the 100~240V
AC power receptacle.
2. Powering the System in a Car
Plugoneend ofthe DC Power adapter into the DC input jackon
theunit, thenplugthe other endinto the vehicle power outlet.
Figure1
3.ToChargethe Built-in Battery
Plug oneend oftheACto DC adapter into theDCjack on the side
oftheplayer, asshownin Figure1, then plug theotherendintothe
100~240VACpoweroutlet. Makesurethatthe player spowerslide
switch is inthe “OFF/CHG.”position, the charge indicator will be
red. Once fullycharged, the Chg. LED indicator will turn off. Once
the indicator is off, removetheAC to DC adapter wall plug.
NOTE: Yournewbatterymust becharged a minimumof 8 hours
beforethe first usage. Each full rechargetakes approxi-
mately five hours andonefullcharge canprovidepower to
the player for approximately2 hours.

9
CarryingBagClosed
VehicleHeadrest
Vehicle
Seat Back
Carrying BagOpened
Elastic
Straps
Headrest Strap
Seat Back
Strap
E. Vehicle Installation
Installing the DVD Player onto the Seat Back ina Car
(Refer to Figure 2)
1).Unfold the carrying bag, andplace the DVD playeronthebag
beneaththe elastic straps. Ensurethat the unit scornersare
secured bythe elasticstraps.
2).Securethe upper portionofthecarryingbag toheadrestsupport
barsusingthe headreststrap.Adjust the headreststrap untilthe
bag isfirmly secured.
3). Secure thelower portionofthe carrying bagto the vehicle seat
backusingthe seat backstrap. Adjust the seat backstrap until
the bagis firmlysecured.
Figure2

10
English
* Connectingto this headphonejackwill disable the internal
speakers.
9) Volume Control
10) PowerOn/Off(CHG.) Switch
11) LCD Panel Shut Off Switch
12) Wide Screen Button
13)Previous/Next/Pause
/Stop/PlayButton
14)MenuButton
15) Up/Down/Left/Right/OK Button
1)Power LED
2)Remote Control Sensor
3)CoverOpenSwitch
4) Charge Indicator
5) DC 9-12V InputJack
6) A/V Out Jack
7) Headphone Jack 2
8) Headphone Jack1*
F. Controls, Indicators, and Connectors
1. UnitView (Refer to Figure 3)
Figure3
1 2
3
4
10
11
12
13
14
5
6
8
9
15

11
2.Remote Control (Refer to Figure4)
G. Loading and Playing a Disc
a.Afterconnectingpower to theunit, applypower to the DVD player
bysliding the POWER ON/OFF switch to ON. The power indica-
tor will be green.
b.Open the disctray by slidingcover OPEN switch and place adisc
onto the tray with the labelside facing up.
c.Closethe tray by pressing thearea marked “PUSH TOCLOSE”.
The unit will load the disc and start playing.
d. Rotate VOLUME control to adjust the DVD player s volume.
e. Tostop playinga disc, press the STOPbutton.
f.To turn offtheDVD player, slide the POWER ON/OFF switchto
OFF.
Figure 4
1) SETUP Button
2) UP Button
3) PREVIOUSButton
4) ENTER Button
5) REVERSE/LEFT Button
6) DOWN Button
7)NUMERIC Buttons
8)DISPLAYButton
9) ZOOMButton
10) SUBButton
11) NEXT Button
12) A-B REPEATButton
13) FORWARD/RIGHTButton
14)1/All REPEATButton
15) STOP Button
16) MENUButton
17)AUDIO Button
18)ANGLE Button
19) PLAY/PAUSEButton

12
English
H. Basic Operation
POWER
OPEN
PLAY
PAUSE
STOP
NEXT
PREVIOUS
FORWARD
REVERSE
LEFT/RIGHT/UP/DOWN
ENTER
NUMBERS
MENU
REPEAT
A-B
DISPLAY
ANGLE
SUBTITLE
AUDIO
ZOOM
SETUP
Turnthe unit on/off
Remove/loadthedisc
StartPlay/Execute itemorsetting
StillPicture
(1time) Stopat thepresent playingpoint /
(2times) Stopplayback oftheDVD/CD
Gotothe nextchapter,track or scenedur-
ing playback
Goback totheprevious chapter,track or
sceneduringplayback
Scanforward at 2,4, 8,16or32xtimes
speed
Scanbackward at2, 4, 8,16 or32x times
speed
Usedfor Menu Navigation
Execute itemorconfirmsetting
Select itemorsetting
Display the mainmenuofthedisc
Repeatplayingtitle, chapter,ortrack
Repeat a specific portion from point A to
pointBofthe disc
Display information (title, chapter, track,
time,etc.)
Changetheviewing angles on thescene
Selectthe subtitle language and turniton/
off
Selectthe audiolanguage
Enlargeanimage to 2, 3,or 4times the
original size duringDVD playback.
Displaythe setup menu to select and set
items,andexitthe setupmenu.

13
I. Menu
ADVD isdividedinto sections calledtitlesand chapters. Whenyou
play a DVD,aroot menu ofthedisc will appearonthescreen ofyour
TV orMonitor. Thecontentsof themenu varyfrom disc todisc.Press
MENUduringplaybackto display themenu. SomeDVDs onlyallow
you to select disc playbackoptionsusingtheDVD root menu.
J. Display(Displaycontentsvary from discto disc.)
1.Playing Time and Remaining Time
a.During playbackpress theDISPLAY buttonto display thecurrent
TitleNumber(1), thetotalNumberofTitles (2), thecurrent Chap-
terNumber(3), the total NumberofChapters(4), and the elapsed
playingTime forthe title (5). The headingwill disappearautomati-
cally after 3 seconds ifno buttons are pressed.
b.PressDISPLAYbuttonagain todisplay theRemaining Timeof
the title. The headingwill disappear automatically in3 seconds.
Title Remaining TimeScreenDisplay
Title, ChapterNumber and Time ScreenDisplay
Tt0101Ch021700000
//::
Tt0101Ch021700000 //::

14
English
c.PressDISPLAYbuttona third time to display the ElapsedTime
forthe chapter. Theheading willdisappear automatically in3
seconds.
d. Press DISPLAYbutton afourthtime to displaythe Remaining
Time for thechapter.The headingwilldisappearautomatically in
3seconds.
e. Press DISPLAY buttona fifth timeto exit, ‘DISPLAY OFF will be
displayed and will disappear automatically in 3 seconds.
NOTE: To select the Chapter you want, enter the number ofthe
Chapteryouwant ontheremote whilein any display mode.
The information for Chapter and Title will be displayed and
thenumberoftheChapter you selected will be highlighted.
Press ENTER buttonto confirm the selection.
Chapter ElapsedTime ScreenDisplay
Chapter Remaining TimeScreen Display
Tt0101Ch021700000
//::
Tt0101Ch021700000
//::

15
*SomeDVDs only allowaccess tothis function through theDVD
menu.
3.Subtitle
Duringdisc playbackpress SUB button to select the subtitle
language youdesire*, with the current SubtitleLanguage Number
(1) and the totalNumber of SubtitleLanguages(2) displayed. If
there aremultiplelanguagespress SUBbutton againto select
another subtitle language. To turn subtitles OFF, press the SUB
button until ‘SUBTITLE OFF is displayed. The Subtitle display will
disappearautomaticallyiftheSUBbuttonisnotpressedagainwithin
3seconds.
AngleScreenDisplay
Subtitle0102 /
SubtitleScreenDisplay
2.Angle
During playbackofadisc, pressANGLEbuttonto displaythe avail-
able angles fordiscs containing multi-angles*, withthe currentangle
number (1) and the totalnumber of angles (2) displaying. Press
ANGLE button toselectotherangles.
*NOTE: Not alldiscs containthis feature.

16
English
4.Audio
Duringplaybackpress AUDIO button to select the audio language
youdesire*, with the currentAudioChannelNumber(1)andthe
total number ofAudio Channels (2) displayed. PressAUDIO again
to select another audio language. The audio display will disappear
automatically ifthe AUDIO button is not pressed within3seconds.
Audio Language Screen Display
* Some DVDs onlyallowaccess to this function throughthe DVD
menu.
5.Zoom
Duringplayback press ZOOM buttonto enlargethe picture by2x,
3x or4Xwiththecurrentzoommultiple.PressZOOM buttonone
time,thepicture will beenlarged2X. Press ZOOMbutton a second
time, the picture will be enlarged 3X. PressZOOMbutton athird
time,the picture will be enlarged 4X. Press ZOOMbutton a fourth
time, the picture will return to normal size.
ZOOM ScreenDisplay

17
6.A-B Repeat
a. Duringplaybackpress A-B button to set the StartingPoint A.
A-BRepeatStarting Point Screen Display
b.Press A-B button a second time to set the EndingPoint B and
theplayer will repeatedly playthe part between Point Aand
Point B.
A-BRepeat CancelledScreenDisplay
A-BRepeat Ending Point Screen Display
c. PressA-B button a third timeto cancel A-B repeat and resume
normal playback.

18
English
All
7. Repeat
a. Duringplaybackpress1/ALL button once to repeatedly play the
currentchapter.
Chapter Repeat ONScreenDisplay
b.Duringplayback press1/ALLbutton again to repeatedlyplaythe
currenttitle.
Title Repeat ON ScreenDisplay
c. During playback press1/ALLbuttonathird time torepeat all
chaptersandtitles.
All RepeatONScreenDisplay

19
d. Press 1/ALLbutton afourth time, to resume normalplayback.
Repeat OffScreenDisplay
8.Forward/Reverse Scan
a.During playbackpress uu toscan forward at2x, 4x, 8x,16x,
32xand normal speed.
b. Duringplaybackpress tt to scanbackward at 2x,4x,8x,16x,
32xand normal speed.
K. Playing Audio CDs
Toplay an audio CD, simply load it ontothedisc tray and the CD
will start playbackautomatically. Press the DISPLAYbutton repeat-
edly on the remote control to viewdisc time information.The time
information is displayed in the the followingsequence:
CD Display Mode
Single Elapsed:The current track playingand the elapsed time on
that track appears on thescreen.
Single Remain:The current trackplayingand theamount of time
remainingon that trackappears on the screen.
Total Elapsed: The currenttrack playingand the total elapsed
time on the CD appears onthe screen.
Total Remain:The current trackplayingand the amount oftime
remaining on the CD appears on the screen.
SingleElapsedSingleRemainTotalElapsed
DisplayOffTotalRemain

20
English
1. Using the RepeatFeature
Thedefaultmode forthe Repeat featureis OFF. Pressing 1/ALL button
consecutively changes the repeat options:
•Repeat Track-repeats the track that is playing.
•RepeatAll - repeats the disc that is playing.
•Repeat Off
Asyou toggle through theoptions, the repeat optionchanges.The
selected repeat option loops repeatedly until you turn itoff.
2.A-B Repeat
a. During playbackpress A-B to set the StartingPoint A.
b. Press A-B asecond time to set the EndingPoint Band the
player willrepeatedly playthe part between Point Aand Point B.
c. Press A-B a third time to cancel A-B repeat and resumethe
normal playback.
3.Forward/Reverse Scan
a.During playbackpress uu to scanfoward at 2x,4x,8x,16x,32x
andnormal speed.
b. Duringplaybackpress tt to scan backward at 2x, 4x, 8x,16x,
32xand normal speed.
L. Playing JPEG Files
1) Loada JPEG discontothedisc tray.
2) Ascreen showingfolders or picturefiles contained on the disc
will bedisplayedautomaticallyafterloading.
3) Press UP, DOWN and ENTER button to select a folder or a
picture. Ifapicture is selected, photo slideshowwill start with the
selected picture.
4) Press the DOWNbutton to rotate the picture clockwise.
5) PresstheZOOM buttonto enlarge the picture sizeby 125%,
150%, 200% or zoomoutby 75%,50%andthenreturn tothe
original size. When the imageis enlarged, you can use the
navigationbuttonsto viewblockedpartsofthepicture.
6) Press UP button toreturn to the screen showingfolders or
picture files.
7) Duringslideshow, press STOPbutton to enter Thumbnail mode.
Press navigation buttonsandENTER buttonto select a picture
you want to start the slideshowwith.
8) Press PLAY/PAUSE button then theslideshowwill pause. Press
the button again to resume the slideshow playback.
