RADIO-CONTROLLED WEATHER STATION
Operating instructions
FUNK-WETTERSTATION
Bedienungsanleitung

GB/IE/NI Operating instructions Page 1
DE/AT/CH Bedienungsanleitung Seite 35
Before reading, unfold both pages containing illustrations and familiarise
yourself with all functions of the device.
Klappen Sie vor dem Lesen die beiden Seiten mit den Abbildungen aus und
machen Sie sich anschließend mit allen Funktionen des Gerätes vertraut.

Port 1 to Port 2: 5V 2.1A(Total)
– +
AAA
+ −
AAA
A

+
−
–
+
AA AA
B

AFW 2 A1 GB│IE│NI │ 1 ■
Contents
Introduction ................................3
Information about these operating instructions ............. 3
Intended use ....................................... 3
Warning notices..................................... 4
Safety .....................................5
Basic safety instructions ............................... 5
Safety information for batteries ......................... 7
Package contents ............................9
Description of components ...................10
Use.......................................11
Requirements for the set-up location ....................11
Operating the outdoor sensor .........................12
Operating the weather station.........................12
Displays in basic mode. . . . . . . . . . . . . . . . . . . . . . . 15
Handling and use ...........................17
Basic settings ......................................17
Setting the alarm time and alarm day ...................19
Activate/deactivate alarm function .....................20
Switching off the alarm signal .........................20
Snooze function....................................21
NAP timer function..................................21
Display maximum/minimum temperature/humidity.........21
Background lighting.................................22
Battery display.....................................22

AFW 2 A1
■ 2 │ GB│IE│NI
Changing the radio channel ..........................23
Charging USB devices...............................24
Troubleshooting ............................25
Cleaning ..................................26
Storage ...................................26
Disposal...................................27
Appendix .................................28
Technical data .....................................28
Simplified EU Declaration of Conformity ................30
Kompernass Handels GmbH warranty ..................31
Service...........................................34
Importer ..........................................34

AFW 2 A1 GB│IE│NI │ 3 ■
Introduction
Information about these operating instructions
Congratulations on the purchase of your new device.
You have selected a high-quality product. The operating instruc-
tions are part of this product. They contain important information
about safety, usage and disposal. Before using the product, please
familiarise yourself with all operating and safety instructions. Use
the product only as described and for the range of applications
specified. Retain these instructions for future reference. Please
also pass these operating instructions on to any future owner.
Intended use
The radio weather station shows you the indoor and outdoor
temperatures in Celsius (°C) or Fahrenheit (°F) in addition to the
maximum and minimum values. The indoor and outdoor humidity
(%) and the maximum and minimum values are also displayed.
Displayed values also include the time in 12/24-hour format in
addition to the date. The radio weather station is also equipped
with two USB sockets which can be used to charge smartphones
or other mobile devices.
The device is intended solely for private households and not for
the commercial sector. The device is not intended for any other
purpose, nor for use beyond the scope described. Claims of
any kind for damage resulting from misuse, incompetent repairs,
unauthorised modification or the use of unauthorised spare parts
will not be accepted. The risk shall be borne solely by the user.

AFW 2 A1
■ 4 │ GB│IE│NI
Warning notices
The following warnings are used in these operating instructions:
DANGER
A warning at this hazard level indicates a poten-
tially hazardous situation.
Failure to avoid this hazardous situation could result in injuries
or death.
► Follow the instructions in this warning notice to prevent injury.
CAUTION
A warning notice of this hazard level indicates a
risk of property damage.
Failure to avoid this situation could result in property damage.
► Follow the instructions in this warning notice to prevent
material damage.
NOTE
► A note provides additional information that makes hand-
ling the device easier for you.

AFW 2 A1 GB│IE│NI │ 5 ■
Safety
This section contains important safety instruc-
tions for using the device. Improper use
may result in personal injury and property
damage.
Basic safety instructions
To ensure safe operation of the device,
follow the safety guidelines set out below:
■ This device may be used by children
aged 8 years and above and by persons
with limited physical, sensory or mental
capabilities or lack of experience and
knowledge, provided that they are under
supervision or have been told how to use
the device safely and are aware of the
potential risks. Do not allow children to
use the device as a toy. Cleaning and user
maintenance tasks must not be carried out
by children unless they are supervised.

AFW 2 A1
■ 6 │ GB│IE│NI
■ Before starting to operate the product, en-
sure that the product and the mains adapter
and cable connections are undamaged!
Never operate an device that is damaged.
■ The mains adapter and the welded con-
nection cable may not be repaired. In the
event of a defect, the entire mains adapter
must be replaced with another of identical
design.
■ Operate the weather station and the
mains adapter only in dry indoor
rooms.
■ Operate the weather station only with
the supplied mains adapter.
■ Before operating the device, ensure that
the existing mains voltage matches that
required by the mains adapter.
■ The mains power socket that is used must
be easily accessible at all times so that the
mains adapter can be quickly removed
from the mains power socket in the event
of an emergency.

AFW 2 A1 GB│IE│NI │ 7 ■
■ Do not expose the weather station to
moisture or direct sunlight.
Safety information for batteries
DANGER
Mishandling the batteries can cause
fires, explosions, leakages or other
hazards!
► Follow the instructions in this warning
notice to prevent injury.
► Keep batteries out of the hands of
children. Keep the batteries out of the
reach of children.
► If a battery has been swallowed, seek
medical assistance immediately.
► Batteries must never be short-circuited,
taken apart, deformed or thrown into
a fire.
► Never try to charge non-rechargeable
batteries.

AFW 2 A1
■ 8 │ GB│IE│NI
DANGER
► Chemicals from leaking or damaged
batteries can cause skin irritations when
touched, so please use suitable protec-
tive gloves in this case. In event of contact
with your skin, rinse off with plenty of
water. If the chemicals come into contact
with your eyes, rinse thoroughly with
plenty of water, do not rub and consult a
doctor immediately.
► Always use batteries of the same type.
Never mix old batteries with new ones!
► Only ever use the stated battery type.
► Ensure that the batteries are inserted
with the correct polarity. This is indicated
in the battery compartment.
► Clean the battery and device contacts
before inserting the batteries if necessary.
► Remove the batteries if you do not intend
to use the device for a long time.
► Always remove discharged batteries from
the device immediately.

AFW 2 A1 GB│IE│NI │ 9 ■
Package contents
The product includes the following components:
1 weather station
1 outdoor sensor
2 batteries type AA
2 batteries type AAA
1 mains adaptor
1 wall plug (Ø 5 mm)
1 screw
1 set of operating instructions
1 Quick-start guide
NOTE
► Check the package for completeness and signs of visible
damage.
► If the contents are incomplete or damaged due to defective pack-
aging or through transportation, contact the Service Hotline.
♦ Unpack all parts of the device from the packaging and
remove all packaging materials.
DANGER
► Do not allow children to play with packaging materials.
Risk of suffocation.
The packaging materials have been selected for
their environmental friendliness and ease of disposal
and are therefore recyclable. Dispose of packaging
materials that are no longer needed in accordance
with applicable local regulations.

AFW 2 A1
■ 10 │ GB│IE│NI
Description of components
For illustrations see fold-out pages
Figure A
Display
1Date panel
2Internal temperature panel
3External temperature panel
4USB connection panel
5Time panel
Weather station
6–/CH button
7+/MEM button
8ALARM button
9SNOOZE/LIGHT button
0MODEbutton
qNAPbutton
wBattery compartment
eBattery compartment cover
rConnector socket for mains adapter
tUSB socket (Type A)
zMains adapter

AFW 2 A1 GB│IE│NI │ 11 ■
Figure B
External sensor
uControl LED
iHanger
oTX button
pChannel selector switch
aBattery compartment
sBattery compartment cover
dFold-out stand (rear)
Use
NOTE
Before use, insert the battery first into the outdoor sensor
and then into the weather station.
Requirements for the set-up location
CAUTION
► When selecting the installation location, ensure that the
devices are not subjected to direct sunlight, vibration, dust,
heat, cold and moisture.
► Do not set the devices up in the vicinity of heat sources
such as radiators.
► Fit the outdoor sensor at a maximum distance of 100 m
from the weather station. Ensure that there are no disruptive
obstacles between the outdoor sensor and the weather
station. Otherwise, transmission can be disrupted.

AFW 2 A1
■ 12 │ GB│IE│NI
♦ Set the devices up on a horizontal, flat surface. To do this,
unfold the fold-out stand don the outdoor sensor.
♦ Alternatively, the outdoor sensor can be suspended from
a screw using the hanger i.
Operating the outdoor sensor
♦ Open the battery compartment a on the rear of the device
by pushing the battery compartment cover s in the direc-
tion of the arrow.
♦ Insert two type AA batteries into the battery compartment a
as shown.
♦ Close the battery compartment again a . The control LED u
on the front of the outdoor sensor lights up briefly.
Afterwards, the control LED ulights up once every minute
to signal that transmission is taking place.
Operating the weather station
You can either operate the weather station with the mains
adapter zsupplied or using batteries.
Mains power operation:
♦ Plug the low voltage plug on the mains adapter zinto the
connector socket ron the weather station and connect the
mains adapter zto an easily accessible mains plug.
Battery operation:
♦ Open the battery compartment w on the rear of the device
by removing the battery compartment cover e.
♦ Insert two type AAA batteries into the battery compartment w
as shown.
♦ Close the battery compartment wagain.

AFW 2 A1 GB│IE│NI │ 13 ■
Once the power supply has been established, the display will
light up and go through a brief check of the display elements.
The weather station will now attempt to connect to the outdoor
sensor. The reception symbol flashes on the outdoor tempera-
ture panel 3.
NOTE
If no outdoor temperature is displayed within around 3 minutes,
the weather station will stop the reception search. The reception
symbol goes out and and are displayed on the
outdoor temperature panel 3.
It is possible that no signal can be received due to the sur-
rounding buildings or because the distance is too great.
If you are unable to establish an automatic connection to the
outdoor sensor, you can do this manually:
♦ Press and hold the –/CH button 6until the reception
signal flashes on the outdoor temperature panel 3.
♦ Press the TX button oto initiate the outdoor sensor
radio signal manually.
The weather station automatically starts to receive the MSF
signal after 3 minutes irrespective of whether the outdoor sensor
reception search has been successful or not. The reception
symbol flashes on the time panel 5.
If the reception symbol is not flashing completely ( ) on the
display, this means that the reception of the MSF signal is too
weak and the time cannot be synchronised. Try to find a set-up
location in which the reception symbol flashes completely ( )
on the display.

AFW 2 A1
■ 14 │ GB│IE│NI
If the MSF signal is being received correctly, the current Coor-
dinated Universal Time (UTC) is displayed on the time panel 5
and the date and weekday are displayed on the date panel 1.
In addition, the reception symbol is permanently displayed on
the date panel 5.
If the device is unable to synchronise the MSF signal, you can
also manually set the time (see section Basic settings) or you
can attempt the reception again.
♦ Press the –/CH button 6simultaneously with the +/MEM
button 7to try to re-establish reception. The reception
symbol flashes on the time panel 5.
The MSF signal
The MSF radio signal is a dedicated time broadcast that pro-
vides an accurate an reliable source of UK civil time, based on
the NPL atomic clock time scale UTC (NPL). It is available across
the whole of the UK and beyond. The signal operates on a fre-
quency of 60 kHz and carries a time and date code that can be
received and decoded by the radio weather station. Reception
of these MSF signals normally takes between 3 and 5 minutes.
If reception of the MSF signal fails, the weather station will stop
trying to establish reception after around 7 minutes.
Reception can be considerably restricted by obstacles (e.g.
concrete walls) or interference sources (e.g. other electronic
devices). If necessary, you should change the location of the
weather station (e.g. put it by a window) if reception problems
continue.

AFW 2 A1 GB│IE│NI │ 15 ■
Displays in basic mode
Once the weather station has received the outdoor sensor signal
and the MSF signal, it is in basic mode.
In basic mode, the weather station shows the following informa-
tion on its display:
The date panel 1
The date of the current day
is displayed next to the ab-
breviation and the date of the current month appears next to
the abbreviation . The abbreviation for the current weekday is
shown on the right. The language for this abbreviation is preset
to English but can be changed if required. Please refer to the
section Basic settings for details.
The time panel 5
The time is shown in 12-hour
format by default. In the 12-
hour format, the abbreviation
(Latin for "post Meridiem" =
afternoon) is shown in front of
the time between 12 noon and 11.59 at night. During the sum-
mer period, (daylight saving time) is displayed. This display
is only shown if the MSF signal is being received.

AFW 2 A1
■ 16 │ GB│IE│NI
The indoor temperature panel 2
The indoor temperature measured by the weather
station is displayed with one decimal place. The
temperature unit (degrees Celsius) is shown
top right.
The temperature unit can also be changed to
(degrees Fahrenheit).
If the temperature drops below the measuring range of 0°C to
50°C (or 32°F to 122°F) is shown; is shown if the temper-
ature rises above this range. The relative humidity (in %) around
the weather station is shown below the temperature display.
The outdoor temperature panel 3
The outdoor temperature is displayed with one
decimal place. The temperature unit (degrees
Celsius) is shown top right. The temperature unit
can also be changed to (degrees Fahrenheit).
If the temperature drops below the measuring
range of -20°C to 65°C (or -4°F to 149°F)
is shown; is shown if the temperature rises above this range.
The relative humidity (in %) around the outdoor sensor is shown
below the temperature display.
The USB connection
panel 4
If you charge mobile devices
using the USB connection t, the battery symbol will
flash next to the appropriate USB connection symbol / .
