Automatic Technology GDO-8V2 EasyRoller II User manual

GDO-8V2 EasyRoller®II
INSTALLATION INSTRUCTIONS | OWNERS COPY
Weather Resistant Roll Up Door Opener
PN13240

2GDO-8V2 EasyRoller® II Owner Installation Instructions
WARNING: It is vital for the safety of persons to follow all
instructions.Failuretocomplywiththeinstallationinstructions
and the safety warnings may result in serious personal injury
and/or property and remote control opener damage. Please
save these instructions for future reference.
Automatic Technology Australia Pty Ltd to the extent that such may be lawfully excluded hereby expressly disclaims all
conditions or warranties, statutory or otherwise which may be implied by laws as conditions or warranties of purchase of
an Automatic Technology Australia Pty Ltd Roll Up Garage Door Opener. Automatic Technology Australia Pty Ltd hereby
further expressly excludes all or any liability for any injury, damage, cost, expense or claim whatsoever suffered by any
person as a result whether directly or indirectly from failure to install the Automatic Technology
Australia Roll Up Garage Door Opener in accordance with these installation instructions.

Owner Installation Instructions GDO-8V2 EasyRoller® II 3
Safety Warnings 4
Product Features 6
Operating Controls 8
Package Contents 10
Side Room Requirements 11
Fixing Weight Bar 11
Fitting Locking Bar Covers 11
Mounting The Opener 12
Fixing Curtain To Drum 13
Setting Limits Via Control Panel 13
Setting Limits Via Transmitter 14
Setting Obstruction Force Margin (ISS) 15
Re-Calculating Force Margin Sensitivity 15
Coding Transmitters 16
Deleting Transmitters 16
Locking the Control Panel 16
Connecting Photo Electric Beam 17
Connecting External Secure Light Module 17
Using Manual Release 17
Resetting Factory Defaults 17
Door Status Indicators 18
Buttons and Functions 18
Supplier/Installer Information 18
Factory Default Settings 19
Technical Specifications 19
Trouble Shooting Guide 20
Parts List 22
Warranty 23
GDO-8v2 EasyRoller®II
Roll Up Garage Door Opener

4GDO-8V2 EasyRoller® II Owner Installation Instructions
FOR ADDITIONAL SAFETY protection we strongly recommend the fitting of a
Photo Electric (P.E.) Beam. In most countries P.E. Beams are mandatory on all
garage doors fitted with automatic openers. For a small additional outlay
Automatic Technology recommends that P.E. Beams be installed with the
EasyRoller® II ensuring additional safety and peace of mind.
DO NOT operate the EasyRoller® II unless the garage door is in full view and free
from objects such as cars and children/people. Make sure that the door has finished
moving before entering or leaving the garage.
DO NOT operate the EasyRoller® II when children/persons are near the
door. Children must be supervised near the garage door at all times when
the EasyRoller® II is in use. serious personal injury and/or property
damage can result from failure to follow this warning.
DO NOT allow children to operate the EasyRoller® II. Serious personal
injury and/or property damage can result from failure to follow this
warning.
Regularly check to make sure that the safety obstruction force
is working correctly, and is tested and set as per page 15 of this
Manual. Failure to follow this could result in serious personal
injury and/or property damage. This test must be repeated
at regular intervals and the necessary adjustments made
as required.
DO NOT disengage the EasyRoller® II to manual
operation with children/persons or any other objects
including motor vehicles within the doorway. Install
the wall switch or wall mounted transmitter in a
location where it is out of reach of children and
the garage door is visible.
WARNING: It is vital for the safety of persons to follow
all instructions. Failure to comply with the following
Safety Rules may result in serious personal injury
and/or property damage.
Important safety instructions

Owner Installation Instructions GDO-8V2 EasyRoller® II 5
The EasyRoller® II is not intended for use by young children or infirm persons without adequate supervision.
Children should be supervised to ensure they do not play with the remote transmitters or the EasyRoller® II.
Keep hands and loose clothing clear of the door and EasyRoller® II at all times.
The unit is rated to IP24, however, it should be installed so that it is protected from the elements. Where
possible it should not be exposed to water or rain. It is not to be immersed in water or sprayed directly
by a hose or other water carrying device.
The garage door must be well balanced. Sticking or binding doors must be repaired by a qualified
garage door installer prior to installation of the EasyRoller® II.
Frequently examine the installation, in particular cables, springs and mountings for signs of
wear, damage or imbalance. DO NOT use if repair or adjustment is needed since a fault in
the installation or an incorrectly balanced door may cause injury. DO NOT attempt to repair
the door yourself as hardware is under extreme tension.
Remove or disengage all garage door locks and mechanisms prior to installation of
the EasyRoller® II.
Connect the EasyRoller® II to a properly earthed general purpose 240V mains
power outlet installed by a qualified electrical contractor. The outlet (and
EasyRoller® II) must be positioned so that it is easily accessible.
Disconnect the power cord from mains power before making any repairs
or removing covers. Only experienced service personnel should remove
covers from the EasyRoller® II.
In order for the EasyRoller® II to sense an object obstructing the
door way, some force must be exerted on the object. As a result
the object, door and/or person may suffer damage or injury.
If the power supply cord is damaged, it must be replaced by
an Automatic Technology service agent or suitably qualified
person.
Make sure that the door is fully open before
driving in or out of the garage and fully closed
before leaving the driveway.
Make sure that remote controls are
kept out of reach of children.
Important safety instructions

6GDO-8V2 EasyRoller® II Owner Installation Instructions
Operation
To open or close the door simply press a button on a SecuraCode® handheld
transmitter, a wall mounted transmitter, or optional wall switch for two seconds.
During open and close cycles the door can be stopped by pressing the button
again. The next actuation will move the reverse the door’s direction.
SecuraCode® Code Hopping Technology
Every time a SecuraCode® transmitter is used a new security code is generated
from over 4.29 billion possible code combinations. This greatly enhances the
security of the system and makes “code grabbing” a thing of the past!
Security code store
The GDO-8v2 EasyRoller® II Garage Door Opener uses evolutionary technology to
securely store eight (8) different transmitters in its memory.
Weatherproof design
The opener’s control board is housed in a weather-proof enclosure rated to IP24. This
offers protection from rain and the elements. PLEASE NOTE - the unit should not be
sprayed by a hose or any other water carrying device.
ALPS (Automatic Limits Positioning System)
The ALPS system automatically calculates the door’s travel limits and stores it in memory. If the door is
moved manually within the travel limits during a power failure, the ALPS will recognise this once the power
is restored and stop at the correct limit position if the door is activated. During installation the hand held
transmitter can be programmed to set the door limits positions.
ISS (Intelligent Safety Obstruction System)
While the door is performing a close cycle, should it hit an obstacle or be restricted in some manner, it will
automatically reverse. The amount of force the door should encounter before reversing is automatically
adjusted by the doors control system during the initialisation of the automatic door opener. The door will
also stop if restricted whilst opening. The Safety Obstruction Force should be checked at least once a month.
See pahe 15 of this manual for instructions.
Features
Thank you for purchasing the Automatic Technology
EasyRoller® II Automatic Garage Door Opener.
Designed by our renowned engineers to suit vertical
operating continuous curtain roll up doors, the
EasyRoller® will provide years of smart, simple
& secure convenience to your home.

Owner Installation Instructions GDO-8V2 EasyRoller® II 7
Lockable control panel
The control panel can be locked and disabled to prevent tampering. This is
useful if the opener is to be mounted on an exposed carport or a perimeter
door. Locking the control panel will prevent operating the door via the Operate
button, reprofiling the door, clearing limits, clearing transmitters, changing force
margins, and coding transmitters.
Overload indicator
When the maximum opening and closing capacity of the opener is exceeded an
audible beeper will sound to indicate that an overload has occurred.
Photo Electric (P.E.) beam (optional)
The opener has an input for a P.E. beam to be connected for extra safety protection
Secure Light Module (optional)
external secure light module is available to connect to the gdo8 opener
light stays on for approximatly four minutes after the operation of opener
Manual operation
The opener is equipped with a unique patented manual disengaging device. If the power to the
opener is disrupted for any reason the door can be put into manual mode by pulling down on the
string handle, then releasing. This will allow you to manually open or close the door. When power is
restored, by pulling down on the string handle and releasing, the opener is put back into automatic mode.
Security lock for manual release handle (optional)
For added security the manual release handle can be locked out or disabled. This is ideal if the opener is to
be mounted on a perimeter door in an exposed carport.

8GDO-8V2 EasyRoller® II Owner Installation Instructions
Operating controls
Prog input is used for the connection of the Automatic Technology PG-3 Universal Programmer for the
purpose of editing control and receiver functions.
P.E.ShuntTheshunthas tobe removedwhen connectinga PhotoElectric (P.E.)Beam. NOTE:THE P.E.Shunt
must not be removed otherwise the opener will not function correctly. Remove only when a P.E. beam is to
be connected.
Status LED (yellow) indicates when the datum adjustment screw has reached correct position.
Datum Adjust Screw Used to set mid-point of door travel during limits set up.
Door Code button (blue) is used for storing or erasing the transmitter button you wish to use to command
the door to open, stop or close.
Coding LED (red) light indicates whether a code is being stored or when a transmitter button is
pressed.
Set button (orange) is used during the installation phase together with the Plus and Minus buttons to set
the door limit positions. The Set button is also used to re-initialise the Opener.
Operate button (blue) is used during installation to test the open, stop and close cycles for the opener.
The opener has to be initialised by the Set button before the OPERATE button becomes operable.
Force Margin Set The obstruction force pressure is set automatically by the opener during installation.
The pressure can be adjusted manually using the Force Margin Set button (White). Pressing the force
margin set button and open or close button will increase or decrease the amount of force. The Force
Margin Set is only ever used if other environmental factors (wind, etc.) affect the operations of the door/
opener.
Plus button (green - for limits setting and force margin) can be used during installation to set the open
limit position. Pressing this button will move the door in the open direction. Movement stops when the
button is released. NOTE: The open safety obstruction detection is inoperable whenever the Close Drive
button is used to move door. This button is disabled after initialisation. This button is also used to increase
the force margin sensitivity.
Open Limit LED (green) theled is very helpful during installation. It illuminates and flashes when the
door is opening and remains steady on when the open limit position has been reached.
Minus button (red - for limits setting and force margin) can be used during installation to set the close
limit position. Pressing this button will move the door in the close direction. Movement stops when the
button is released. NOTE: The close safety obstruction detection is inoperable whenever the Close Drive
button is used to move door. This button is disabled after initialisation. This button is also used to decrease
the force margin sensitivity.
Close Limit LED (red) the led is very helpful during installation. It illuminates and flashes when the door
is closing and remains steady on when the close limit position has been reached.
Engage/Disengagement Cord is used to switch the door into manual mode especially in case of a
power failure. The length of the string is also adjustable.
Security Lock for Manual Release (where fitted) prevents the manual release handle being pulled
to disengage the opener into manual mode.
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15

Owner Installation Instructions GDO-8V2 EasyRoller® II 9
01
02
03
04
05
06
07 08 09 10
11
12
14
15
13
Operating controls

10 GDO-8V2 EasyRoller® II Owner Installation Instructions
Package contents
GDO-8 Easyroller® drive unit 1
PTX-4 SecuraCode® keyring transmitter 1
Alkaline battery A23 12V 1
Weight bar (not included in some models) 1
Pan head screw M4x50mm (not included in some models) 2
Nilock hex nut M4 (not included in some models) 2
Flat washer I.D. 3
/
16 x ½ (not included in some models) 2
Locking bar covers 2
Installation manual 1
Pan head screw M4x50
Securacode PTX-4
Alkaline
battery A23 12V Locking bar covers
Saddle*
Drive unit
Weight bar
Door drum*
Hex nut Nilock nut M4
Washer 3
/
16
x ½
Reinforcement plate*
Flat washer*
Spring washer*
Nuts
Bracket*
*Not included

Owner Installation Instructions GDO-8V2 EasyRoller® II 11
Before installation
Side Room Requirements
Fig. 01 shows the minimum and recommended side
room that is required to mount the opener. The
distance between the edge of the door curtain and the
inside of the bracket must be at least 40mm. However,
for easier access it is recommended that at least 95mm
is allowed.
1. Check operation of door before
beginning the installation of the
EasyRoller® II.
The door must be well balanced and be in a
reasonable operating condition. You should be able
to lift the door smoothly and with little resistance. It
should stay open around 900mm to 1200mm above
the floor. The door should not stick or bind in the
guide tracks. The ideal operational effort in raising
or lowering the door should not exceed a force of
10kg (22lb). Make sure that all door locks, ropes,
chains etc. are either released or disabled and remove
unnecessary accessories.
2. Fixing Of Door Weight Bar
Move the door manually to the half open position.
Place the weight bar on the bottom rail in the middle
of the door and secure with the fasteners provided
(Fig. 02). Check the operation of the door again. If
the door feels heavy it may require extra tension to
be added to the door springs. IMPORTANT - Door
springs are under extreme tension and should only
be adjusted by a garage door professional
3. Installing Locking Bar Covers
To protect against entrapment of fingers etc. inserted
into door guides – remove the protective backing of
the double sided tape and install the locking bar covers
over the holes in each door guide.
IMPORTANT SAFETY INSTRUCTIONS FOR INSTALLATION
Warning: Incorrect installation can lead to severe injury.
Follow ALL instructions.
01
fig
02
fig
03
fig
85
40
135
95
Side room Side room
Weight bar
Door side guide
Double sided tape
Locking bar hole

12 GDO-8V2 EasyRoller® II Owner Installation Instructions
Mounting the opener
4. Fixing drive unit to the door
The EasyRoller® can be fixed to the roll up garage door
in a variety of ways. Described below is one method of
fixing. Make sure there is enough side room to slide the
drive assembly onto shaft.
PLEASE NOTE: The instructions for fixing the drive
assembly to the door is for right hand installation.
Fitting drive unit to door (Fig. 04, Fig. 05 and Fig. 06).
1. Check that the door shaft U bolt is securely tightened
on the left hand side of the door.
2. Raise the door and tie a rope around the centre to
secure the roll.
3. Support the right hand end of the door with a suitable
prop, e.g. step ladder and soft padding to protect
door surface.
WARNING: Do not allow children/persons around
the door and prop. Serious personal injury and/
or property damage can result from failure to
follow this warning.
4. Carefully loosen and remove the right hand door shaft
U-bolt.
5. Make sure that the door supporting prop is secure.
While the door is supported remove the right hand
door mounting bracket from wall.
6. Remove the drive assembly from the packaging. Try
to rotate the drive gear by pushing on the fork. If
the gear does not rotate the manual mode has to
be selected. To select pull downward on the string
handle, then release slowly. The drive gear should
now rotate freely.
7. Slide the drive assembly over the door axle making
sure that the fork extends into and over one of the
spokes of the door drum wheel.
8. Refit the door mounting bracket to the wall. In some
cases the bracket may have to be re-positioned. Re-
fit and tighten the door shaft U-bolt. Remove door
supporting prop and untie the rope from the curtain.
9. Straighten the drive assembly and position as per Fig.
06. Tighten the two locking bolts firmly to secure the
Drive Unit.
10. Check the manual operation of the door by raising
and lowering the door. The door should run smoothly
and not catch on any part of the drive assembly.
11. Adjust the length of the manual release cord so that
it can be easily reached by an adult of average height
(ie. less than 1.8m tall).
NOTE: After installation, ensure that parts do not
extend over public footpaths or roads.
04
fig
05
fig
06
fig
Remove U bolt
Remove bracket
Pull string handle
if gear is not
turning freely
Re-fit right bracket
Tighten
“U bolt nuts”
Remove prop
Untie rope

Owner Installation Instructions GDO-8V2 EasyRoller® II 13
Setting limits
5. Fixing of door curtain to drumwheel
The door curtain has to be secured to the drum wheel
with suitable fasteners. This prevents unauthorised
access through the door by pushing the curtain up and
off the drum.
1. With the door in the fully closed position, mark the
curtain (Fig. 07) on both ends of the door.
2. Open door slightly to have access to the marked
positions. Secure the curtain to drum wheel using
self drilling screws (two on each end). The screws
should be at least 90 degrees apart.
6. Setting door travel limits
IMPORTANT NOTE: The OPERATE button will
not function until the open and close limits
positions are set.
6.1 Coding transmitter for setting limits
1. Press and hold the Door Code button (Fig. 09).
2. Press button 1 (Fig. 11) on the transmitter for
two seconds.
3. Release and pause for two seconds.
4. Press the same button transmitter again for
two seconds.
5. Release the Door Code button.
6.2 Setting datum position
1. Switch the opener into manual mode (Fig. 08).
2. Move the door by hand to an approximately mid
open position.
3. Re-engage the opener.
4. Using a small blade screw driver turn the datum
adjust screw slowly until the yellow status LED just
illuminates.
NOTE: If the status LED is already illuminated when
power is connected then turn the datum adjust screw
until the LED goes off then turn back one notch to
illuminate again.
07
fig
08
fig
09
fig
Drum wheel
90°
Pull handle down to
disengage or re-engage

14 GDO-8V2 EasyRoller® II Owner Installation Instructions
Setting limits
6.3 Setting limits via remote control
PLEASE NOTE: The opener is factory preset for
installation on the RIGHT HAND SIDE. When the opener
is mounted on the left side of the door the opener will
travel in reverse.
1. Press button 4, the door will start closing. If the door
starts to open - press the Operate button (Fig. 10)
within two (2) seconds. Press button 4 again - the
door should now close. Release the button once you
are 1 to 2cm from your desired closed limit position.
2. Press button 3 for two (2) seconds to switch to slow
inching mode.
3. Press button 4, each press will enable you to inch the
door to your desired closed position.
4. Once you are happy with the position press button 2,
to store the closed limit position into memory.
5. Press button 1, the door will start opening. Release
the button once you are 1 to 2cm from your desired
open limit position.
6. Press button 3 for two (2) seconds to switch to slow
inching mode.
7. Press button 1. Each press will enable you to inch the
door to your desired closed position.
IMPORTANT WARNING: Please be aware that
the garage door will start closing automatically
once step 8 is performed. The door will also
automatically re-open after fully closing with a
short pause between the cycles.
8. Once you are happy with the position press button 2,
to store the open limit position into memory.
The door will now automatically close to its limit position
then fully open to calculate the safety obstruction forces
(ISS). Please be aware of the above warning.
7. Resetting door limits positions
The door curtain has to be secured to the drum wheel
with suitable fasteners.
The door limit positions can be deleted for new
positions by following the steps below:
1. Press and hold the Minus button (Fig. 10) for six (6)
seconds until you hear three beeps and the red Close
Limit LED starts to flash. Release the button.
2. Follow STEP 6.3 above to set new travel limit
positions.
IMPORTANT: There is no need to re-code the
transmitter used for setting the limit positions. After
the limits are set the transmitter will automatically
reset to normal operation.
Go to STEP 8 and test the Safety Obstruction Force.
10
fig
11
fig
Inch close
button 4
Inch open
button 1 Set
button 2
Switch between
fast and slow
inching
button 3

Owner Installation Instructions GDO-8V2 EasyRoller® II 15
Setting safety obstruction force
8. Safety obstruction test
Please take care when testing the Safety
Obstruction Force. Due to Excessive forces
failure to follow this warning may cause SERIOUS
PERSONAL INJURY and/or property damage. The
test below should be repeated at regular intervals
(approximately every two months).
8.1 Testing close cycle
1. Open the door by pressing the OPERATE button
(Fig. 12).
2. Place a length of timber approximately 50mm high
on the floor directly under the door (Fig. 13).
3. Press the OPERATE button to close door. The door
should strike the object and start to re-open.
NOTE: If the door stops and fails to reopen, it is possible
that the motor direction is set incorrectly. Change the
motor direction and retest.
IMPORTANT WARNING: If the test fails, there
may be a problem with the door, discontinue
use, put the door into manual operation and
call for service.
8.2 Testing open cycle
1. With the door closed - press the OPERATE button.
to open the door. When the door is approximately
one metre above the hold the bottom rail of the
door firmly, the door should stop.
Adjusting safety obstruction force
The Safety Obstruction Force is calculated automatically
and set in memory on the EasyRoller®. It is usually not
necessary to adjust the Safety Obstruction Force. The
only time the force may need to be increased is due to
environmental conditions, for example, windy or dusty
areas, and areas with extreme temperature changes. If
adjustments are made you must retest the obstruction
force margin as per above.
8.3 To increase force pressure
1. Press and hold the Force Margin Set button (Fig. 12)
2. While holding down the Force Margin button, press
the Plus button. Each press increases the force
margin in both directions. The Open Limit LED will
illuminate each time the Plus button is pressed. Each
press increases the force margin. Test the force as
per step 8.1 and 8.2. If the Open Limit LED flashes
continuously when the Plus button is being pressed,
this indicates that the maximum force pressure
setting has being reached.
8.4 To decrease force pressure
1. Press and hold the Force Margin Set button (Fig. 12).
2. While holding down the Force Margin button, press
the Minus button. Each press decreases the force
12
fig
13
fig
margin. The Close Limit LED will illuminate
each time the Minus button is pressed. Test
the force as per step 8.1 and 8.2. If the Close
Limit LED flashes continuously when the Minus
button is being pressed, this indicates that
the maximum force pressure setting has been
reached.
8.5 To recall factory set force
1. While holding down the Force Margin Set
button (Fig. 12) press the SET button for
two (2) seconds.
2. Release both buttons. The default setting
should now be recalled.
8.6. To re-calculate force margin (iss)
Press and hold the Set Button for two (2) seconds,
the beeper will sound once. The door will start to
move and re-calculate force margins. The door can
move between the open and close limit positions
up to four (4) times (depending on the position of
the door and the power up condition). A single
beep will be heard once the process is complete.
The door is now ready for use.
IMPORTANT NOTE: After installation ensure
that the opener stops or is prevented from
opening when the door is loaded with a mass
of 20kg fixed centrally at the bottom edge of
the door.
Wood (50mm high)

16 GDO-8V2 EasyRoller® II Owner Installation Instructions
Coding transmitters
9. Setting transmitters codes
Make sure to insert the battery into the transmitters.
The memory in the openers receiver can store up to
eight remote control transmitters.
9.1 Storing the transmitters code
1. Press and hold the Door Code button (Fig. 14).
2. Press the button (one of four) on the transmitter
you would like to use to control the door for
two seconds, pause for two seconds. Press the
same button again on the transmitter for two
seconds.
3. Release the Door Code button.
4. Press the transmitter button to test if it operates
the door.
10. Storing transmitter(s) from
a remote location
Using this method you don’t need to have access
to the control panel on the Door Opener. However,
you do need a transmitter that is pre coded to the
controller’s receiver.
14
fig
15
fig
IMPORTANT NOTE: The door must be activated
when the step below is performed. The moving door
confirms that the correct button was pressed and
the transmitter was in range of the opener.
1. Take any pre-coded transmitter. Press the button for
the function you require until the door is activated
and release.
2. Using a small needle press the button through the
Coding Hole for two seconds (Fig. 15).
3. Within 10 seconds take the additional transmitter you
wish to code.
4. Press the button (one of four) on the new transmitter
you would like to use to control the door for two
seconds, pause for two seconds. Press the same
button again on the transmitter for two seconds, the
button should now be stored.
5. Wait for 10 seconds and then test the new transmitter
to see if it operates the door.
11. Deleting programmed codes
11.1 deleting a stored transmitter code
1. Select the transmitter you want to delete.
2. Press and hold the Door Code button (Fig. 14).
3. Press the transmitter button you would like to delete
for two seconds. Pause for two seconds. Press the
transmitter button again for two seconds.
4. Release the Door Code button. The code should now
be deleted. Confirm this by pressing the transmitter
button, the door should not respond.
11.2 Deleting all stored transmitter codes
1. Turn the power off to the opener.
2. Press and hold the Door Code button (Fig. 14).
3. Turn the power on again while holding the Door Code
button. The Open Limit, Close Limit and Door Status
LED’s will illuminate for about five seconds. These
LED’s will turn Off and the Coding LED will illuminate.
Release the Door Code button. All the stored codes
should now be deleted. Confirm this by trying
to operate the door by pressing the transmitters
previously used to control the door, the door should
not respond.
12. Locking the control panel
To lock or disable the control panel a transmitter button
must be coded to operate the door.
1. Press and hold coded button of transmitter to operate
the door and Plus (+) button on the opener together
until you hear a beep (approx. four (4) seconds).
2. Release both buttons.
3. The control panel should now be locked. Press the
Operate button on the opener to confirm the door
does not move.
To unlock the control panel repeat the above steps.
Press and hold
Door Code button
Select one of the four
buttons you wish to use
to control the door
Coding hole
Small needle

Owner Installation Instructions GDO-8V2 EasyRoller® II 17
PE beam and final set up
13. Fitting the Photo Electric (P.E.) beam
sensor (optional)
Locate the P.E. Beam in a strategic location within
doorway. Automatic Technology recommends 150mm
above the floor level and as close as possible to the
door opening, inside the garage. Remove shunt from
P.E. connector (Fig. 16) and connect the wires from the
P.E. wiring harness as per Fig. 17.
NOTE: The wiring diagram is for an Automatic
Technology Transmitter/Receiver type P.E. beam:
model: PE-2 (Order Code 90214) with Wiring Harness
(Order Code 01900).
Make sure to align the beams correctly. Follow the
manual supplied with the Photo Electric Beam.
WARNING: The location of the beam and
manner in which it is installed might not give
safety protection at all times. Check to make
sure that the height of the beam and type
used give maximum protection possible.
External Secure Light Module
external secure light can be connected to gdo8 as
shown in fig 16. the light stays on for three minutes
after the opration of the door.built in oprate button can
be used to open or close the door
14. Manual release
To switch the opener to manual mode simply pull the
red manual release handle down and release. To re-
engage the opener repeat the above action (Fig. 18).
Note: The door may move uncontrollably if the spring
tension is weak or not set properly or the door is
unbalanced. If this occurs do not use the door and
contact your installer for service.
The manual release handle can be locked to prevent
unwanted disengagement (where fitted). This is useful
if the opener is mounted on an exposed carport or
perimeter door. To disable the manual release turn the
key clockwise to the locked position as indicated on the
label. To enable turn the key anti-clockwise.
15. Reset all factory defaults
1. Turn power off.
2. Press and hold Set button.
3. Turn power on and continue holding Set until all
LEDs are off.
NOTE: This does not erase transmitter codes stored
in memory.
16. Re-initialising the opener
To re-initialise the opener press and hold the Set
Button for two (2) seconds, the beeper will sound
once. The door will start to move and re-calculate force
margins. The door can move between the open and
close limit positions up to four (4) times (depending on
the position of the door and the power up condition).
1 2 3 4 5
0V
PE
24V
16
fig
17
fig
18
fig
Remove
PE shunt
Receiver Transmitter
Cable 1 Cable 2
Red 24V
Black 0V
Yellow
Pull down handle to
disengage or re-engage

18 GDO-8V2 EasyRoller® II Owner Installation Instructions
Parameters
Door Status Indicators
Door Opener State Open LED
Green
Close LED
Red
Door Status
LED yellow
Beeper
Open On
Close On
Opening Flashing
Closing Flashing
Door travel stopped Flashing
Door obstructed when
opening
Flashing
Door obstructed when closed Flashing Beeps
while door
is moving
Opener overloaded Alternating flashes Alternating flashes
Mains power interupted Rapid flashes
Buttons Function
Operate Opens/Stops/Closes the door
Door code Codes a transmitter button for OPERATE function
Force Margin Set + plus (+) Increases the obstruction force margin setting
Force Margin Set + Minus (-) Decreases the obstruction force margin setting
Force Margin Set (then) Set Reloads the factory set default obstruction force
margin setting
Close for 6 seconds Clears the door limits set positions. Limits then need
to be reset
Set (then power on) & hold until all LEDs are off Deletes control parameters excluding transmitter
storage memory
Door Code (then power on) & hold until all LEDs
are off
Deletes all transmitter stored in memory.
Set for 2 seconds Re-initialises the Opener to re-calculate force margins
Purchased from: Phone:
Installed by: Date:
Serial No:

Owner Installation Instructions GDO-8V2 EasyRoller® II 19
Default settings & specifications
Factory Default Settings
Default Step Maximum
Maximum motor run time 30 seconds - -
Obstruction force margin 8 1 -
Technical Specifications
Input: 230v. - 240v AC 50Hz
230V OR 115V 50 - 60 Hz ( Only In DSV Model )
Controller voltage: 24v. DC
Standby power: 2.8W
Motor power: 100W
Operating temperature +5° to +40°C
Maximum door opening: 1,2 width:
height:
weight:
5500mm
2700mm
100kg
Maximum lifting force: 450N (45kg)
Recommended lifting force: 120N (12kg)
Opener limits travel: 3.25 Turns of door drum wheel
Operating time - intermittent: 4 minutes
Reciever type: UHF 433.92 MHz. am receiver
Receiver code storage capacity: 8 x 4 button transmitter codes
Transmitter frequency: 433.92 MHz
Coding type: Code hopping
No. of code combinations: Over 4.29 billion random codes
Code generation: Non-linear encryption algorithm
PTX-4 transmitter battery: A23 Alkaline 12V
NOTE:
1. The maximum continuos curtain residential roll up door opening that the EasyRoller® can be installed on is
5500mm wide by 2700mm high. The door must be well balanced. A person of average strength should be able
to lift up the door manually with very little effort in case of an emergency.
2. Intermittent operations may occur in areas which experience very strong winds. The strong wind puts extra
pressure on the door and tracks which may in turn trigger the safety obstruction detection system intermittently.

20 GDO-8V2 EasyRoller® II Owner Installation Instructions
Door Status Indicators
Symptom Possible cause Remedy
Door will not operate Mains power not switched on.
Door is obstructed.
Door is locked or motor jammed.
Door tracks/hardware damaged.
Switch on mains power.
Remove obstruction.
Unlock door or remove jam.
Door requires service/repair by
qualified technician.
Door starts to close but
automatically reverses to
open position
Adverse weather conditions (wind
or cold) causing door to stiffen and
become tight in the tracks.
Possible obstruction in the
doorway.
Increase force margin setting
See Step 8.3 on page 13. Or re-
calculate force margin.
Remove obstruction.
Door operates from drive unit
(OPERATE) button but not from
transmitter*
See note
Transmitter code not stored in
memory.
Flat battery.
Code transmitter in to openers
memory. Refer step 9.1 on page
16
Replace battery - A23 Alkaline 12V.
Door will not open or close fully. Door limits position need to be
reset.
Door limits position need to be
reset. See Page 14.
Door is overshooting or not
reaching limits.
Datum position not set correctly. Reset datum position. See Step 6.2
Page 13
Cannot set limits. Datum position not set correctly. Reset datum position. See Step 6.2
Page 13
Door not working with PE installed. PE Beam or wiring faulty.
PE Beam not aligned correctly.
PE Beam is obstructed.
Door obstructed when closing.
Repair PE Beam or replace wiring.
Re-align optics. See PE
Instructions.
Remove obstruction from the path
of PE.
Remove obstruction.
PLEASE NOTE:
Some areas may be prone to excessive radio interference brought on by devices such as cordless telephones,
wireless stereo headphones and baby monitors. It is possible that these devices could cause a degree of
interference such as to greatly reduce the range of the transmitter. In such an instance please contact your
Automatic Technology dealer for an alternative frequency replacement kit. As this is not a warrantable situation
but an environmental issue charges may apply for the changeover.
Trouble shooting
