2GDO-10V3L2 Toro™Owner Installation Instructions
GDO-10V3L2 Toro™
Roll Up Garage Door Opener
Contents
1. Important Safety Instructions 3
2. Controller Input And Outputs 4
3. Operating Controls 5
4. Set Up Requirements 6
4.1 Kit Contents 6
4.2 Choosing your Set up 6
5. Pre-Installation Requirements 7
5.1 Door Operation 7
5.2 Unsuitable Door Types 7
5.3 Position 7
5.4 Power Supply 7
5.5 Sideroom 7
5.6 Forks 7
6. Installation 8
6.1 Preparation 8
6.2 Fitting The Opener 8
6.3 Mounting The Opener 8
6.4 Installing The Wall Mounted Control Unit 9
7. Programming The Opener 9
8. Setting Limits 10
8.1 Setting Travel Limits 10
8.2 Code A Transmitter For Limit Setting 11
8.3 Setting Limits Via Transmitter 11
9. Coding Transmitter 12
9.1 Coding Transmitter Button 12
9.2 Selecting Function Of The Button 12
9.3 Returning To Main Screen 12
10. Remotely Coding Transmitters 13
10.1 Selecting The Function To Be Coded 13
10.2 Activate Remote Code Set Mode 13
11. Setting Pedestrian Position 13
11.1 Setting Pedestrian Position 13
11.2 Checking Pedestrian Position 13
11.3 Error Displays 13
12. Safety Obstruction Force Test 14
12.1 Testing Close Cycle 14
12.2 Testing Open Cycle 14
12.3 Adjusting the Safety Obstruction Force. 14
12.4 To Recalculate Force Margins 14
13. Safety Close & Auto-Close Mode 15
13.1 Safety Close Mode 15
13.2 Setting Up Satndard Auto-Close Mode 15
13.3 Safety Beam Triggered Auto Close 15
13.4 Pedestrian Auto-Close 15
13.5 Auto-Close After Obstruction: 15
14. Time Clock 16
14.1 Time Clock Operation 16
14.2 Time Clock Settings 16
14.3 Day Light Saving Time Adjustment 17
15. Accessories Installation 17
15.1 Fitting Courtesy Lights 17
15.2 Fitting Solenoid Or Magnetic Locks 17
16. Battery Replacement 18
16.1 Replacing Backup Batteries 18
16.2 Replacing Transmitter Batteries 18
17. Battery Disposal 18
18. Specifications 19
19. Troubleshooting 20
20. Maintenance 21
20.1 Door Maintenance 21
20.2 Lubrication (every 3 - 6 months) 21
20.3 Door Service and Repair 21
20.4 Opener Maintenance 21
20.5 Service Indicator 21
21. Appendix 22
A - Console Menu Structure 22
B - Viewing & Editing Logic Console Parameters 24
C - Control Board Adjustments 25
D - Diagnostic Tools 27
E - Memory Tools 28
F- Transmitter Editing 29
G - Transmitter Management 31
22. Warranty and Exclusion of Liability 32
Automatic Technology Australia Pty Ltd to the extent that such may be lawfully excluded hereby expressly disclaims all conditions or warranties, statutory or
otherwise which may be implied by laws as conditions or warranties of purchase of an Automatic Technology Australia Pty Ltd Garage Door Opener. Automatic
Technology Australia Pty Ltd hereby further expressly excludes all or any liability for any injury, damage, cost, expense or claim whatsoever suffered by any
person as a result whether directly or indirectly from failure to install the Automatic Technology Australia Pty Ltd Garage Door Opener in accordance with these
installation instructions.
WARNING! • The door may operate unexpectedly, therefore do not allow anything to stay in the path
of the door.
• For Safety protection, a Safety Beam must be fitted with logic console. Failure to comply
will void the warranty and may result in serious personal injury and/or property damage .
• The drive must not be used with a door incorporating a wicket door, unless the drive cannot
be operated with the wicket door open.
• The drive is intended to be installed at least 2.5m above the floor.
• DO NOT allow children to operate the opener. Any device that can operate the opener,
make sure it is out of reach of children and that the doorway is in full view at all times. Serious
personal injury and/or property damage can result from failure to follow this warning.
• When using auto close mode, a Safety (Photo Electric) Beam must be fitted correctly and
tested for operation at regular intervals. Extreme caution is recommended when using
auto close mode. All safety rules must be followed.
ELECTROCUTION! • Place opener in protected area so that it does not get wet.
• Do not spray with water .
• Disconnect the power cord from mains power before making any repairs or removing
covers. Only experienced service personnel should remove covers from the opener.
• If the power supply cord is damaged, it must be replaced by an Automatic Technology
service agent or suitably qualified person.
• Electrical wiring must be compliance with the local building an electrical codes.

Owner Installation Instructions GDO-10V3L2 Toro™3
WARNING! • The door may operate unexpectedly, therefore do not allow anything to stay in the path
of the door.
• For Safety protection, a Safety Beam must be fitted with logic console. Failure to comply
will void the warranty and may result in serious personal injury and/or property damage .
• The drive must not be used with a door incorporating a wicket door, unless the drive cannot
be operated with the wicket door open.
• The drive is intended to be installed at least 2.5m above the floor.
• DO NOT allow children to operate the opener. Any device that can operate the opener,
make sure it is out of reach of children and that the doorway is in full view at all times. Serious
personal injury and/or property damage can result from failure to follow this warning.
• When using auto close mode, a Safety (Photo Electric) Beam must be fitted correctly and
tested for operation at regular intervals. Extreme caution is recommended when using
auto close mode. All safety rules must be followed.
ELECTROCUTION! • Place opener in protected area so that it does not get wet.
• Do not spray with water .
• Disconnect the power cord from mains power before making any repairs or removing
covers. Only experienced service personnel should remove covers from the opener.
• If the power supply cord is damaged, it must be replaced by an Automatic Technology
service agent or suitably qualified person.
• Electrical wiring must be compliance with the local building an electrical codes.
The safety alert symbols below indicate a personal safety or property damage instruction
exists. READ THESE INSTRUCTIONS CAREFULLY.
This automatic Door opener is designed and tested to offer safe service provided it is installed
and operated in strict accordance with the following safety rules. Failure to comply with the
following instructions may result in death, serious personal injury or property damage.
1. Important Safety Instructions
CAUTION:
Emergency access • If your facility has no pedestrian entrance door, an emergency access device should be
installed.
Entrapment under
operating door • DO NOT operate the opener unless the door is in full view and free from objects such as
cars and children/people. Make sure that the door has finished moving before entering or
leaving the premises.
• Do not allow children to play with door controls or transmitters.
• Ensure the door is in good working order by undertaking regular servicing.
• For ADDITIONAL SAFETY protection we STRONGLY recommend the fitting of a Safety
(Photo Electric) Beam.
• Safety beams must be installed if the closing force at the bottom edge of the door exceeds
400N (40kg)
Installation • Frequently examine the installation, in particular, springs and mountings for signs of wear,
damage or imbalance. DO NOT use if repair or adjustment is needed since a fault in the
installation or an incorrectly balanced door may cause injury. DO NOT attempt to repair
the door yourself as hardware is under extreme tension.
•The door must be well balanced and in good working order. Door springs, brackets and their
hardware are under extreme tension and can cause serious personal injury. Do not attempt
to adjust them. A faulty Door must be repaired by a industrial roller Door professional prior
to opener installation.
• Remove or disengage all Door locks and mechanisms prior to installation of the opener.
• Ensure no parts of the Door or installation extend over public paths or roads.
• After installation a full function test of the system and safety devices must be done.
Security • Make sure the door is fully closed before leaving the driveway. .
Entanglement in
or laceration from
moving door
• Keep hands and loose clothing clear of door and opener at all times.
• Keep clear of door during operation as severe lacerations can occur on sharp edges of door..

4GDO-10V3L2 Toro™Owner Installation Instructions
2. Controller Input And Outputs
Light Relay Output N/O, Com,
N/C Contact
Lock Relay Output N/O, Com,
N/C Contact
Serial Interface Connector
12 volts 6 Amp - Hr Batteries
Engage/Disengagement Handle
Standby Battery Charger/Solar
Connector
11
03
12
06
07
04
02
01
05
08
01
02
09
03
04
05
06
07
08
09
10
11
12
Fig 2.1
10
Solar Shunt
Standby Battery Shunt
Motor Connector
10 Amps Slow Blow Fuse
24 Volts Ac In Connector
Position Sensor Connector

Owner Installation Instructions GDO-10V3L2 Toro™5
16
15
20
14
13 21
19
18 17
Terminal Block ( From Left To Right )
AUX OUT Receiver’s Auxiliary Output
V+ Accessory Supply
SB3 Third Safety Beam Input
SB2 Second Safety Beam Input
SB1 First Safety Beam Input
0V Common For Safety Beams
0V Common Terminal For Control Inputs
FIRE N/O , N/C Input Terminal
GPI N/O Input Terminal
OPN N/O , N/C Input Terminal
STP N/O , N/C Input Terminal
CLS N/O Input Terminal
Programmer PG-3 Input
Console Previous Button
Liquid Crystal Display
Console Next Button
Console Open Button
Console Stop Button
Console Set Button
Console Close Button
13 14
15
16
17
18
19
20
21
3. Operating Controls
Fig 3.1

6GDO-10V3L2 Toro™Owner Installation Instructions
4. Set Up Requirements
Fig 4.1
Fig 5.1
Fig 5.2
Fig 5.3
4.1 Kit Contents
4.2 Choosing your Set up
The GDO-10V3L2 can be set up in various ways and therefore may
require additional items. Common Set ups are as follows;
ITEM DESCRIPTION QTY ORDER
CODE
1 GDO-10V3L2 POWER DRIVE UNIT 1 60233
2 COMMUNICATION CABLE 1 61909
3 WALL CONTROL UNIT L2 1 61565
4 TRIO-CODE 4B PTX-5 TRANSMITTER 2 61161
5 LOCKING BAR COVER 2 71040
6 FORK EXTENSION 6 61486
ACCESSORY PACK (61480)
7 CLIP CABLE CLIPSAL NO 564/1 5 72845
8 SCREW-EYE 2 10595
9 SELF TAPPING SCREW 6 X 25 (1”) 2 10672
10 PLASTIC WALL PLUG 6.9 X 25 (1”) 4 11152
1
23
4
5
6
7
8
9
10
Set Up Items Required
Dead Man Set Up Drive Unit, console
Automated Set Up Drive Unit, console and transmitter
Automated Set Up
with Safety Beams
Drive Unit, console, transmitter and safety beams
(optional extra)

Owner Installation Instructions GDO-10V3L2 Toro™7
5. Pre-Installation Requirements
IMPORTANT SAFETY INSTRUCTIONS FOR INSTALLATION
Warning: Incorrect installation can lead to severe injury.
Follow ALL installation instructions.
NOTE: Planetary chain equipment must be removed from the door
prior to installation of GDO-10V3L2 Toro™.
5.1 Door Operation
The door must be in good operating condition. The maximum effort
to move the door up or down, from stationary, should not exceed 150
Newtons (15 kg force) at the bottom rail.
Lift the door to about halfway. When released, the door should stay in
place supported entirely by its springs. Raise and lower the door to check
for binding or sticking.
The door may need to be serviced to meet these requirements – refer
to the door manufacturer’s servicing instructions or contact an authorised
dealer.
5.2 Unsuitable Door Types
The fitting of an opener to doors with removable mullions or doors
incorporating a wicket door is not recommended.
5.3 Position
The opener can be installed on either the right or left hand side of the
door (when viewed from inside the garage). The opener is factory set for
right hand side installation.
This opener must be installed in a dry position that is protected from the
weather. Moisture or corrosion damage is not covered by the Warranty.
5.4 Power Supply
Properly earthed 3 pin single-phase power is required.
WARNING! Using a portable power generator is not
recommended. The opener may appear to malfunction
due to spikes, surges and fluctuations in the generated
voltage.
5.5 Sideroom
Sideroom For Right Hand Side Installation
The minimum sideroom required from the edge of the door curtain is 140
mm to the inside of the door bracket when the opener is mounted on the
door bracket (Fig. 5.1).
NOTE: The door axle diameter must not exceed 35mm.
• Sideroom For Left Hand Side Installation
The minimum sideroom required from the edge of the door curtain is 127
mm to the inside of the door bracket when the opener is mounted on the
door bracket (Fig. 5.2).
5.6 Forks
Attach and secure all six (6) forks 6to the drive unit 1 with screws
supplied (Fig. 5.3).All the six (6) forks must be used and properly engaged
into the drum of the door for the opener to work effectively.
140
185
182
127
Fig 5.1
Fig 5.2
Fig 5.3
6
1

8GDO-10V3L2 Toro™Owner Installation Instructions
6.1 Preparation
a. Check the door’s operation:
i. The door must travel smoothly and be easy to operate
by hand.
ii. Adjust any tight or twisted guides.
iii. Clean the guides if there is any oil or wax present using a
suitable white spirit. The only lubricant suitable for use on
door guides is silicon spray. DO NOT use WD-40, RP-7,
petroleum grease, or similar.
b. Install the locking bar covers 5if there are locking bar holes in
the guides.
CAUTION - Do not lock your door with the locking bars
after installing the opener. Remove or disable the lock.
Security is not affected as the opener has an inbuilt
locking facility.
c. Affix the warning labels supplied with this opener in a prominent
place where they are clearly visible.
d. Choose the side where the opener will be installed ensuring
there is sufficient sideroom.
Check that the door is still balanced and smooth to operate. If it
is not, the door may require servicing (refer to door manufacturer’s
instructions).
6.2 Fitting The Opener
a. At the end opposite to where the opener will be fitted, check that
the door axle is tightened to the bracket securely. (Fig. 6.1)
b. Open the door completely and tie safety ropes around the door
roll approximately 300 mm from each end. Do not tie the ropes
too tight as damage to the curtain may ensue.
c. At the end where the opener is to be fitted, support the door with
a safe and suitable lifter.
WARNING! Make sure the support is snug under the
door, is stable and will not move.
d. At the end where the opener will be fitted, use pen to mark the
position of the saddle on the door bracket and the position of the
door bracket on the wall to assist in reassembling.
e. Remove the bolts and saddle from the door bracket.
f. Remove the door bracket allowing the door to rest on the support
6.3 Mounting The Opener
a. If the internal gear does not rotate freely, switch the opener to
manual by pulling the disengagement handle down (there will be
a click), so the ring gear can be rotated by hand.
b. Slide the opener over the door axle and into the drum of the
door (Fig. 6.2).
c. Ensure the internal gear is pushed in as far as possible (without
interfering with the door curtain) and that all of the door drum’s
wheel spokes are completely between the opener’s drive forks.
6. Installation
NOTE - For minimum sideroom installations,
the door may have to be taken down.
WARNING! The opener must not
be used with a door incorporating a
wicket door.
WARNING! The door and its springs
are under significant tension.
Adjustments should only be carried
out by experienced persons, as
this function can be dangerous if
not performed under strict safety
procedures.
Fig 6.1
Fig 6.2
Tighten U bolts

Owner Installation Instructions GDO-10V3L2 Toro™9
6.4 Installing The Wall Mounted Control Unit
a. Remove the face cover from the wall mount control unit 3.
b. Affix the wall mount control unit 3at a height of 1.5 metres within sight of the door but away from moving parts.
Make sure this location of the wall control unit is out of reach of children and convenient to the customer.
c. Replace the face cover.
d. Connect the network cable 2from the wall control unit to the GDO-10V3L2 powerhead unit 1and secure with
p clips 7.
e. Connect the power cord to a suitable power point, but DO NOT SWITCH ON.Secure the power cord away from
any moving object (e.g. the door) with the cable clips.
f. With the opener still disengaged, pull the door up and down to make sure it runs freely.
Fig 6.1
Fig 6.2
Fig 6.3
Tighten Nuts
7. Programming The Opener
The three most common programs are;
Program Menu’s required Function Section
Dead Man Set Up Menu 10.1 Setting the Limits 11.1
Safety Obstruction Force 12.1 and 12.2
Menu 1 Coding the Transmitter 13.1
Automated Set Up Menu 10.1 Setting the Limits 11.1
Safety Obstruction Force 12.1 and 12.2
Menu 1 Coding the Transmitter 13.1
Menu 6.1 Safety Close Mode 16.1
Automated Set Up with
Safety Beams
Menu 10.1 Setting the Limits 11.1
Safety Obstruction Force 12.1 and 12.2
Menu 1 Coding the Transmitter 13.1
Menu 3 Auto Close Times 16.3, 16.4 and 16.5
For the Dead Man Set Up and the Automated Set Up the door can not be closed by Auto-Close or by transmitters. When
Safety Beams are not installed, the controller will display the following message;
ATTENTION! No Safety Beams have been detected. “Safety Close’ mode has been turned on. See
Manual for details.
Press SET to continue.
If the closing force as measured on the bottom of the door is over 400N (40kg), a Safety Beam must be installed. The
Safety Close mode can be turned off by changing the parameter in menu 6.1 (Section 16.1).
NOTE: Fitting Safety Beams enables the Auto-Close feature to become active.
d. Re-attach the door bracket using your reference marks as a guide
and tighten the bolts. Ensure that the slots in the mounting bracket
of the opener align with the slots in the door bracket, otherwise
the door bracket may have to be relocated. If the bracket cannot
be relocated, the opener may be fitted onto the axle using the
opener’s saddle and bolts as follows:
i. Using your reference marks as a guide, sit the opener on
the door mounting bracket and secure with the opener’s
bolts and saddle and tighten firmly (Fig. 6.3).
ii. Adjust the door position (if necessary) on the brackets so
that the door feeds smoothly into the guides. Make sure
that the centre of the door doesn’t hit the lintel and that
the curtain is not pushed forward hard into the guide.
e. Remove the support and safety ropes.
NOTE - If the manual release handle is more than 1.8 metres from floor
level when the opener is installed, extend the handle to a height less
than 1.8 metres.

10 GDO-10V3L2 Toro™Owner Installation Instructions
8. Setting Limits
To Desired
CLOSE Limit,
SET
To Desired
OPEN Limit, SET
8.1 Setting Travel Limits
WARNING! Use caution when operating the manual
release with the door open since it may fall rapidly due
to weak or broken springs, or an improperly balanced
door.
WARNING! Do not disengage the opener to manual
operation with children, persons or any objects including
motor vehicles within the doorway.
WARNING! In setting the close limit position, do not
force the door into the floor with excessive force, as
this can interfere with the ease of operation of the
manual release mechanism.
a. Secure the engage/disengage handle and string with the
accessory supplied in such a manner so that the string is away
from the moving parts.
b. Move the door to half way open. If necessary, disengage the
opener by pulling the cord down (Fig.8.1).Re-engage the opener
by pulling the cord down again.
c. Unscrew the screws at the bottom of the logic console cover
(Fig.8.2) and remove the cover to access the PREV, NEXT and
SET buttons.
d. Turn on the power to the opener. The controller will go through
a start up sequence. After a short delay the MAIN SCREEN
(Fig. 8.3) will be displayed. If this is the first time the
GDO-10V3L2 is being used, the MAIN SCREEN should enter
into limit set mode and the blue close LED will be flashing. If the
display shows that an input is active, then rectify the situation
before continuing with the procedure for setting the travel limits.
Press and hold the CLOSE button - the door should start closing.
i. If the door opens, release the CLOSE button and press the STOP
button once to change the motor’s direction. Press and hold the
CLOSE button until close position of the door is reached.
ii. If the door overshoots press the OPEN button to move the door in the
open direction.
e. When the door is at the desired close position, press the SET
button to record the close limit position. The display will change
and green open LED will start to flash (Fig. 8.4).
f. Press and hold the OPEN button to open the door. When the door
is at the desired open position, release the OPEN button. If the
door overshoots, press the CLOSE button to move the door in the
CLOSE direction.
WARNING! Once the next step is performed, the door
will automatically close and open to calculate force
settings. Keep persons and objects clear of the door.
g. Press the SET button to store the open limit. The door will now
automatically close and open to calculate the safety obstruction
settings. After this, if Safety Beam is installed, the opener can be
operated with the OPEN or CLOSE button on the wall control unit
or from the transmitter. Otherwise, the controller will be loaded with
“Safety Close Mode.” See Section 13.1 for further details.
h. Place cover back on logic console and affix with screws when unit
setup is complete.
Pull Down To
Engage/Disengage
Fig 8.1
Fig 8.3
Fig 8.4
WARNING! Please test the manual
release mechanism to ensure that the
manual release is easy to operate. No
more than 15 kg of force should be
required to disengage the door using the
manual release cord. If excessive force is
required reset the close limit position.
Fig 8.2
Fig 8.5
Fig 8.6

Owner Installation Instructions GDO-10V3L2 Toro™11
Fig 8.1
Fig 8.3
Fig 8.4
Fig 8.2
8. Setting Limits: Via Transmitter
Button 1
(Inch Open)
Button 4
(Inch Close)
Button 2
(Set)
MENU 1
Code Transmitter
PR ESS
The GDO-10V3L2 Toro™ has the alternate ability to set travel
limits using a transmitter, allowing free movement around the
garage to better assess the desired limit positions. In order to use a
transmitter, it must first have at least one of its buttons coded to the
door controller. The function assigned to the transmitter’s buttons
is of no concern here as the buttons are temporally assigned to
OPEN, CLOSE and SET (Fig. 8.5).
8.2 Code A Transmitter For Limit Setting
Navigating to “code transmitter” menu
a. Press NEXT to navigate to Menu 1.
b. Press SET to enter the code set procedure (Fig. 8.6).
Storing Transmitter Code
a. Controller will prompt to press one of the transmitter’s Button.
b. Press the transmitter button you wish to use to operate the door
opener (e.g. button 1) .
c. Press the same transmitter button again as prompted by display.
d. Press the set button to store the transmitter.
Navigating To “Set Door Travel Menu”
a. Press PREV to navigate to Menu 10.
b. Press SET to display MENU 10.1.
c. Press SET two times to enter the limit setting procedure. The
close blue LED will start to flash.
8.3 Setting Limits Via Transmitter
a. Press and hold Button 4 on the transmitter to close the door
i. If the door opens, release Button 4 and press the stop button once
on the wall control unit to change the direction of the motor.
WARNING! In setting the close limit position, do not
force the door into the floor with excessive force, as
this can interfere with the ease of operation of the
manual release mechanism.
b. Then press and hold Button 4 on the transmitter to close the
door.
i. If the door is closed too far, press Button 1 to “inch” the door
towards open.
ii. When happy with the close limit position, press Button 2 to store
this in the memory. The open green LED will starts to flash.
c. Press Button 1 to open the door.
i. If the door is opened too far, press Button 4 to “inch” the door
towards close
WARNING: The door will automatically close and open
once next step is performed. Ensure that no persons
or objects are in the door’s path.
When happy with the open limit position, press Button 2 on the
transmitter to store into memory. The door will now automatically
close and open to calculate the safety obstruction settings. After this,
if Safety Beam is installed, then the opener can be operated with the
OPEN or CLOSE button on the wall control unit or from the transmitter.
Otherwise, the controller will be loaded with “Safety Close Mode”.
See Section 13.1 for further details.
Fig 8.5
Fig 8.6
IMPORTANT NOTE:
Only TrioCodeTM128 Technology Transmitters
are compatible with this product.
HELPFUL TIP: To access the PREV, NEXT
and SET buttons, unscrew the screws at
the bottom of the logic console cover
and remove cover.
tip

12 GDO-10V3L2 Toro™Owner Installation Instructions
HELPFUL TIP: To access the PREV, NEXT
and SET buttons, unscrew the screws at
the bottom of the logic console cover
and remove cover.
tip
9. Coding Transmitter
The GDO-10V3L2 can store up to five hundred and eleven (511)
transmitters in its memory. Each transmitter can be allocated an
alpha-numeric ID label up to eleven (11) characters in length and
each button can be assigned to one of several control functions.
The settings for a transmitter are represented in (Fig. 9.1). It
shows the transmitter’s store number, ID label or serial number
and the functions assigned to each of its four buttons. To toggle
between ID/SN display, press UP/DOWN with the cursor on the
ID/SN indicator. The procedures below code, delete, replace,
edit and copy transmitter records.
IMPORTANT NOTE: Only TrioCodeTM128 Technology
Transmitters are compatible with this product.
9.1 Coding Transmitter Button
Navigating To Menu 1 “Code Transmitter”
a. Press NEXT to navigate to Menu 1).
b. Press SET to enter the code set procedure.
Storing Transmitter Code
a. The logic console will prompt to press one of the transmitter’s
buttons.
b. Press the transmitter button you wish to use to operate the
opener (e.g. button 1) (Fig. 9.2) .
c. Press the same transmitter button again as prompted by the
display.
9.2 Selecting Function Of The Button
The logic console will now show the transmitter’s record, with
a cursor on the field for the button being coded (Fig. 9.3).
Use OPEN/CLOSE to select the function for the button.
Available functions:
OSC (Open/Stop/Close) PED (Pedestrian access)
SWP (Swipe) CLS (Close)
OPN (Open) STP (Stop)
LGT (Courtesy Light) VAC (Vacation Mode)
AUX (Auxiliary ) OFF (No action)
NOTE: OSC can change to OS and CLS (Close) function, but is
not available in the case where PE Beams are not installed.
Press SET to save the settings or STOP to abort without saving.
9.3 Returning To Main Screen
Press STOP to return to the MAIN SCREEN and test the
transmitter.
NOTE: To edit the other settings, refer to transmitter edit
procedure in Appendix F.
123ID Name/SN
OSC PED LGT VAC
# 1 [No Name]
OSC OFF OFF OFF
PRESS
PRESS
Press Tx’er
Button! List
PR ESS
I.D label/Serial
number
Button 4
function
Button 3
function
Button 2
function
Button 1
function
Store
number
ID/SN display
indicator
Fig 9.1
Fig 9.2
Fig 9.3

Owner Installation Instructions GDO-10V3L2 Toro™13
Fig 9.1
Fig 9.2
Fig 9.3
Existing
transmitter
If a transmitter is already coded into the opener, additional transmitters
can be coded without being in direct contact with the opener’s wall
console unit.
NOTE: Only the function of the existing transmitter button can be
assigned to new transmitter. Please read instructions prior to proceeding
- there is a time-out facility for security reasons.
10.1 Selecting The Function To Be Coded
a. Using the existing transmitter, operate the Door with the transmitter
button which has the function to be coded (Fig. 10.1) (e.g. Button 1
has been coded with the OSC function assigned).
b. If the button’s function activates the Door (PED, SWP, OSC, CLS, STP
or OPN) wait for the Door to complete its cycle.
After completing the limit setup procedure the Pedestrian Access position is automatically set to a position which is
approximately in the middle of the door travel. The position can be manually set by following the Setting Pedestrian
Position procedure.
11. Setting Pedestrian Position
MENU 10.3
Set Pedestrian
PR ESS
Ped’n Access
FRI 11:06:44 STD
Fig 11.1
Fig 11.2
HELPFUL TIP: To access the PREV, NEXT
and SET buttons, unscrew the screws at
the bottom of the logic console cover and
remove cover.
tip
PRESS
New
transmitter
Fig 10.3
10.2 Activate Remote Code Set Mode
a. Use a small pin / pen to press and hold through the Coding Hole of the
existing transmitter for 2 seconds (Fig. 10.2).
b. Within 10 seconds, press the button on the new transmitter you wish
to code for 2 seconds (Fig. 10.3).
c. Press the same button again (within 10 seconds) for confirmation.
d. Test Operation. The new transmitter button should now function as
the existing transmitter.
NOTE: To Manage your Transmitters, refer to Transmitter Management
in Appendix G.
10. Remotely Coding Transmitters
11.1 Setting Pedestrian Position
a. Drive and stop the door at the desired Pedestrian Access
position by using a transmitter or wall control unit.
b. Press PREV to navigate to Menu 10.
c. Press SET. MENU 10.1 will be displayed.
d. Press NEXT to go to MENU 10.3
e. Press SET on the wall control unit to save the Pedestrian
Access position (Fig. 11.1).
f. Press the STOP button to exit to the main screen.
11.2 Checking Pedestrian Position
When activated by a transmitter button which is coded as Ped
mode, the opener drives the door to the preset position from
either above or below. Ped Mode’s active status is indicated
on the display (Fig. 11.2).If a Ped Mode button is pressed
while the door is moving, the door will stop. If a Ped Mode
button is pressed when the door is in the Ped position, then
the door will close.
11.3 Error Displays
During the above procedure many error checks are performed.
If an error is detected, a message will be displayed indicating
the error.
PRESS
Existing
transmitter
Fig 10.2
Fig 10.1

14 GDO-10V3L2 Toro™Owner Installation Instructions
12. Safety Obstruction Force Test
40mm Block of
wood
WARNING! Take care when testing or adjusting the
Safety Obstruction Force. Excessive force may cause
SERIOUS PERSONAL INJURY and/or PROPERTY
DAMAGE.
12.1 Testing Close Cycle
a. Press the OPEN button to open the door.
b. Place a piece of timber approximately 40mm high on the floor
directly under the door (Fig. 12.1).
c. Press the CLOSE button to close the door. The door should strike
the object and start to re-open.
12.2 Testing Open Cycle
d. Press the CLOSE button to close the door.
e. Press the OPEN button to open the door. When the door reaches
the half open point, grab the bottom rail of the door firmly and
the door should stop.
f. If the door does not reverse readily when closing, or stop when
opening, the force may be excessive and need adjusting.
WARNING! If the door fails these tests, put the opener
into manual mode, only operate the door by hand and
call for service.
Fig 12.1
12.3 Adjusting the Safety Obstruction Force.
The Safety Obstruction Force is calculated automatically during setup.
Adjusting this is normally only necessitated by environmental conditions
such as windy or dusty areas, and areas with extreme temperature changes.
1: CLOSE Margin
(Amps) 0.7
2: OPEN Margin
(Amps) 0.9
Fig 12.2
Fig 12.3
HELPFUL TIP: To access the PREV,
NEXT and SET buttons, unscrew the
screws at the bottom of the logic
console cover and remove cover.
tip
Force Pressure For Close Cycle.
Navigating To “Current Trips”
a. Press NEXT or PREV to navigate to Menu 2 Current Trips.
b. Press SET.
c. MENU 2.1: CLOSE Margin is displayed (Fig. 12.2).
d. Press OPEN to increase or CLOSE to decrease the value.
e. Press SET to save the new value.
f. Test the force again as per “Safety Obstruction Force Test” in Section 12.1.
Force Pressure For OPEN Cycle.
Navigating To “Current Trips”
a. Press NEXT to navigate to the Menu 2 Current Trips.
b. Press SET.
c. Press NEXT.
d. MENU 2.2: OPEN Margin is displayed (Fig. 12.3).
e. Press OPEN to increase or CLOSE to decrease the value.
f. Press SET to save the new value.
g. Test the force again as per “Safety Obstruction Force Test” in Section 12.2.
12.4 To Recalculate Force Margins
a. Reprofiling is a simplified way of re-learning the travel characteristic of a previously setup Limit Switch travel installation.
Re-profiling can be used when the travel characteristics of the door change due to mechanical adjustments etc. To
initiate a re-profile, simply locate “MENU 10.2 Reprofile Travel”, press SET and follow the prompts. The door will start
to move and re-calculate force margins. The door can move between the open and close limit positions up to two (2)
times (depending on the position of the door and the power up condition).
b. A single beep will be heard once the process is complete.
c. Test the force again as per “Safety Obstruction Force Test” (Section 12.1 and 12.2).

Owner Installation Instructions GDO-10V3L2 Toro™15
13. Safety Close & Auto-Close Mode
Fig 12.1
Fig 12.2
Fig 12.3
13.1 Safety Close Mode
The controller has a built in Safety Beam detection. If Safety
Beams are not installed, the controller will automatically turn
on the Safety Close Mode. By enabling this parameter, the
Door can only be closed by holding the close button on the
wall control unit.
In order to facilitate an Automated Set Up and enable to
Door to be closed by a transmitter proceed by;
Navigate to “Safety Close Mode (Menu 6.1)”
a. Press the OPEN button.
b. Warning will display.
DANGER! Read Manual before turning off Safety
Close Mode. Press SET to continue.
c. Press SET to accept the warning.
d. Press either the OPEN or CLOSE arrows to change to OFF.
e. Press SET to Save the change.
WARNING! The Auto-Close function is not
available unless Safety Beam is installed.
13.2 Setting Up Satndard Auto-Close Mode
Menu 3. Auto-Close Times
The Auto-Close modes automatically close the Door after it
has been operated. To implement this the controller starts a
timer once the Door has reached its desired open position.
The timer then counts down and when it expires the controller
starts to close the Door. Details about the four Auto-Close
modes follow. Automatic Technology strongly recommend
using a Safety Beam for added safety.
Menu 3.1 Standard Auto Close
This mode is selected by entering a non-zero time for the
STD Auto-Close parameter. When selected, the Door will
Auto-Close after being fully opened (except when the Door
has reversed to the open position after a motor obstruction
or overload. Countdown is suspended by: S.B., OPN or SWP
input being active. The countdown is aborted if the STP input
is activated. If the Door is already open and the OPN or the
SWP input is activated, then the countdown will start.
13.3 Safety Beam Triggered Auto Close
Menu 3.2 (SB AC Trig)
This mode is selected by entering a non-zero time for the
“Safety Beam Auto-Close” parameter. This mode is used
to Auto-Close the Door but only after an object has passed
through the doorway and has triggered the Safety Beam
input. Any Safety Beam or combination of Safety Beams can
be configured to activate Safety Beam Auto-Close mode and
combinations are:
One Beam only
i. Safety Beam 1
ii. Safety Beam 2
iii. Safety Beam 3
Either Beam
i. Safety Beam 1 or Safety Beam 2
ii. Safety Beam 1 or Safety Beam 3
iii. Safety Beam 2 or Safety Beam 3
iv. Safety Beam 1 or Safety Beam 2
or Safety Beam 3
Combination
i. Safety Beam 1 and Safety Beam 2
ii. Safety Beam 1 and Safety Beam 3
iii. Safety Beam 2 and Safety Beam 3
iv. Safety Beam 1, Safety Beam 2 and Safety Beam 3
NOTE: The swipe input can be used to clear the Safety
Beam triggered status so that the Safety Beam input must
be activated again before the countdown will start. As with
the other Safety Beam modes, the STP input will abort
countdown and the OPN and SWP inputs will restart the
countdown if the Door is OPEN.
Menu 3.3 Directional Auto-Close (SB Auto Close)
This mode is selected by entering a non-zero time for the
“S.B. Auto-Close” parameter. S.B 3 Beam must be installed
and configured to EXIT WITH SB1. Sub in menu 6.5. This
mode is used to Auto-Close the Door only after a vehicle
has passed through the Safety Beam 3 and then through
Safety Beam 1 to exit the premises . This mode is useful for
fire brigade, ambulance stations etc.
13.4 Pedestrian Auto-Close
Menu 3.4 Pedestrian Auto-Close
This mode is selected by entering a non-zero time for the
“Ped’n A/C” parameter. When selected, the door will Auto-
Close after being opened for pedestrian access unless it
was following a reverse from an obstruction.
Menu 3.5 (Safety Beam) Pedestrian Triggered Auto-Close
Any Safety Beam or combination of Safety Beams can be
configured to activate Safety Beam Auto-Close mode.
Menu 3.6 (Safety Beam) Pedestrian Auto-Close
This mode is selected by entering a non-zero time for the
“Ped’n A/C” parameter. When selected, the door will Auto-
Close after being opened for pedestrian access unless it
was following a reverse from an obstruction.
13.5 Auto-Close After Obstruction:
Three parameters are provided to enable the Auto-Close
feature to be activated after obstructions and power up.
Normally the Auto-Close feature is not enabled after
obstructions for safety reasons. Safety Beams must be used
for these features to be activated. The three parameters
are:
Menu 3.7 (Auto-Close after close overload)
This mode enables the Auto-Close feature to be activated
when a close overload occurs (requires Safety Beams).
Menu 3.8 (Auto-Close after open overload)
This mode enables the Auto-Close feature to be activated
when an open overload occurs.
Menu 3.9 (Auto-Close after power up)
This mode enables Auto-Close feature after power up.

16 GDO-10V3L2 Toro™Owner Installation Instructions
HELPFUL TIP: To access the PREV, NEXT and SET buttons,
unscrew the screws at the bottom of the logic console cover
and remove cover.
tip
14. Time Clock
NOTE: The most recent program that applies
to an output remains active until a new
program takes effect.
NOTE: If a Time Clock program does not have
a day selected then it can not be executed.
If a Time Clock program is taking control of
the opener, then this status is displayed on
the LCD. The MAIN SCREEN and clock status
screen flashes alternatively.
The opener provides a programmable time clock which can be used to
control the GDO-10V3L2 on a timed basis at various times of the week. This
section details the time clock operation and configuration.
14.1 Time Clock Operation
The time clock consists of a 7 day clock and storage for 32 programs. The
clock is powered by its own battery and therefore does not lose time when
the GDO-10V3L2 is turned off. Each time clock program defines the time of
the day and the days of the week it is to run and the output function to be
executed. Any combination of the days of the week can be selected.
14.2 Time Clock Settings
The Time Clock settings are accessed by selecting the Time Clock menu
(MENU 7). Press SET (Fig. 14.1) to enter the menu and then PREV or NEXT
to navigate through the options.
Menu 7.1 Set Time/date
This is where the current time, date and day are displayed and set
(Fig. 14.2).
NOTE: The time is in a 24 hour format and the Day of the week is not
automatically set with the date. To change the settings simply press UP or
DOWN to display the cursor and then move to the field to be changed
using the NEXT / PREV buttons. Then press OPEN/CLOSE to change the
setting and then the SET or STOP buttons to save.
Menu 7.2 View Programs
Select this menu to display or edit the Time Clock programs
(Fig. 14.3). When selected, program number 1 is displayed and the cursor
is shown on the program number field. The other fields shown include the
function, time and days of operation. The example
Fig. 14.4 shows that the DOOR will OPEN at 7 am on Mondays, Tuesdays,
Wednesdays, Thursdays and Fridays. Use the OPEN /CLOSE buttons to
scroll though the other programs (Fig 14.5).
To edit a program, simply press the NEXT / PREV buttons to move the cursor
onto the required field and press the OPEN/CLOSE button to change the
value. To save the program settings, press SET or to exit without saving
press STOP.
MENU 7.1
Set Time/Date
PRESS
00:00:80 STD
--- 00/00/2000
MENU 7.2
View Programs
PRESS
P#01 OPEN DOOR
07:00:00 MTWTF--
Fig 14.1
Fig 14.2
Fig 14.3
Fig 14.4
The selectable functions available are:
Function Operation
RX = Off From the time when the program with RX = OFF is
activated, all the transmitters will be disabled.
RX = On From the time when program with RX = ON is activated,
all the transmitters will be enabled.
Open Door From the time when the program with OPEN DOOR is
activated, the door will open and stay open.
Stop Door This feature will let the user activate the stop function until
the next program starts. The door will not open or close
while stop is activated.
Free Door Release the controls from the timer.
Off This will temporarily disable the program.
Fig 14.5

Owner Installation Instructions GDO-10V3L2 Toro™17
Fig 14.1
Fig 14.2
Fig 14.3
Fig 14.4
14. Time Clock
Menu 7.3 Settings
Under this menu, three sub menus are available:
a. Run Programs. The programs of the timer can be interrupted by selecting RUN PROGRAM off.
b. Configuration Of GPI Input. General Purpose Input can be configured as OSC, PED or DST setup.
c. This is activated by the GPI input terminal with the N/O switch.
i. When GPI Selected As OSC: If the door is moving, the activation of GPI input or pressing a transmitter button with the OSC
function assigned will cause the door to stop. The next trigger will move the door in the opposite direction to the last travelled.
ii. When GPI Input Is Configured As PED: The activation of the GPI input or by pressing a transmitter button with PED function
assigned will open the door partially to allow pedestrian access but prevent vehicle access. The position the door is driven to is
automatically set to halfway during setting of the travel limits, but can be adjusted to suit.
iii. When GPI Input Is Configured As DST: GPI input can be used to switch between STD time and DST (daylight savings time). The
AUX input needs to be constantly active to show day light saving time.
14.3 Day Light Saving Time Adjustment
The time selected is the amount of time added to STD time when DST is selected by AUX input. Options are OFF, 30, 60,
90 or 120 minutes.
15. Accessories Installation
LIGHT
LOCK LIGHT
NO
NC
COM
NO
NC
COM
SUITABLE
POWER
SUPPLY
15.1 Fitting Courtesy Lights
An AC or DC courtesy light can be activated via an output on the
door opener control board. Connect the light as per the diagram.
(Fig. 15.1)
WARNING: A qualified electrician must perform the
installation where 240V AC power is used.
Menu 4. Light/Lock Times
a. Press NEXT or PREV on the wall control unit to navigate to Menu 5
Light/Lock Times.
b. Press SET to select the sub menu.
c. Press NEXT or PREV to navigate through the sub menu.
d. Press OPEN to increase or CLOSE to decrease the time.
e. Press SET to save the new time.
f. Press the STOP button two times to exit.
g. Test the light operation.
15.2 Fitting Solenoid Or Magnetic Locks
Install the lock mechanism on the door as per the manufacturers
instructions. See Fig. 15.2 for the wiring diagram.
Menu 4. Light/Lock Times
Lock output can be programmed for both hold and pulse mode. The
operation of the lock can be programmed to activate prior to the door
and behave differently on open cycles to that on close cycles.
a. Press NEXT or PREV on the wall control unit to navigate to Menu 4
Light / Lock Times.
b. Press SET to select the sub menu.
c. Press NEXT or PREV to navigate through the sub menu.
d. Press OPEN to increase or CLOSE to decrease the time.
e. Press SET to save the new time.
f. Press the STOP button two times to exit and test the locks operation.
LIGHT
LOCK
LOCK
NO
NC
COM
NO
NC
COM
SUITABLE
POWER
SUPPLY
Fig 15.1
Fig 15.2
HELPFUL TIP: To access the PREV,
NEXT and SET buttons, unscrew the
screws at the bottom of the logic
console cover and remove cover.
tip

18 GDO-10V3L2 Toro™Owner Installation Instructions
When batteries reach the end of their usual life in accordance with
Australian Battery Recycling Initiative please follow the next simple
steps for protecting the environment.
Refer to the Automatic Technology website for information on where
to recycle batteries in Australia.
DO NOT throw the batteries in
municipal waste. This symbol of the
crossed out wheeled bin indicates that
the battery should not be placed in
the municipal waste. Check your local
regulations for appropriate disposal of
the batteries.
Recycling all batteries will have other environmental and social benefits:
•Some batteries are less toxic but hazardous for other reasons.
Lithium batteries can explode or catch fire in landfill, while button
cells are dangerous if swallowed by children. Recycling offers a safe
and environmentally responsible solution for end of life batteries.
•Battery recycling recovers non-renewable materials such as lead,
cadmium, stella, zinc, manganese, cobalt, silver, plastics and rare
earth elements.
•Removal of batteries and other hazardous household products from
household waste facilitates the recovery of organic materials through
alternative waste technologies such as composting. Batteries and
heavy metals are known contaminants in compost.
•The community supports recycling because it reduces waste to
landfill and achieves environmental benefits.
WARNING! Prior to disposal,
recycling, or collection, all battery
terminals must be securely insulated
with a non conductive material to
prevent any two batteries from short
circuiting and generating heat during
storage or transport. Battery terminals
may be insulated with electrical tape;
or batteries may be individually
packaged in a non conductive material
(e.g., plastic bag or original packaging).
17. Battery Disposal
Fig 16.1
16. Battery Replacement
16.2 Replacing Transmitter Batteries
(Battery Type: 3V Lithium Battery CR2032).
Use a non-metallic object (e.g. pen) to remove the battery. (Fig. 16.2).
To test the battery is working, press and hold a transmitter button;
(Fig. 16.3).
Light Status Battery Status
Solid OK
Flashing Requires replacement
No light Requires replacement
REPLACE BATTERY WITH CR2032 ONLY
Fig. 16.2
Fig. 16.3
Use a pen
to push the
battery down
through the
side opening
to release
battery
16.1 Replacing Backup Batteries
a. Unplug the drive unit from mains power.
b. Disengage motor using manual release cord.
c. Remove the bottom cover by pressing in from sides and sliding
downward.
d. Remove the two screws and slide upward the top cover upwards
to remove it.
e. Remove the battery bracket by undoing the battery bracket screws.
f. Remove the batteries and replace with the same type (Fig. 16.1).

Owner Installation Instructions GDO-10V3L2 Toro™19
Technical Specifications
Power supply 230V - 240Va.c. 50Hz
Standby power 2.6 Watts
Geared Motor power 150 Watts
Motor type 24Vd.c. Permanent Magnet
Maximum door opening: Height:
Width:
Weight:
5500mm
5100mm
270kg
Opener Limits Travel 5.5 turns of Door Drum Wheel
Maximum Rated Load 500N
Nominal Load 150N
Duty Cycle 25 Operations/hr
Receiver type UHF Multi-frequency FM Receiver
Receiver code storage capacity 511 X 4 button Transmitter Codes
Receiver Sensitivity – 103 dB
Transmitter frequency UHF Multi-frequency FM Transmitter
Number of code combinations Over 100 billion random codes
Code generation Non-linear encryption algorithm
Controller fuse 10 A slow blow
Transmitter Battery CR - 2032 (3 Volts)
Real Time Clock Battery CR -1220 (1.5 Volts)
Backup Battery 12 Volts 6 Amp Hr x 2
NOTE:
1. The door must be well balanced. A person should be able to lift the door up manually with very little
effort in case of an emergency.
2. Intermittent operations may occur in areas which experience very strong winds. Strong wind puts extra
pressure on the door and tracks which may in turn trigger the safety obstruction detection system
intermittently.
3. If the Safety Beam are not installed then the controller will automatically goes into “Safety Close“
mode. Limited number of features are available in this mode please refer to Section 13.1.
18. Specifications
Fig 16.1
Fig. 16.2

20 GDO-10V3L2 Toro™Owner Installation Instructions
Symptom Possible cause Remedy
Door will not operate Mains power not switched on.
Door is obstructed.
Door is locked or motor jammed.
Door tracks/hardware damaged.
The stop function is activated
The opener is in “Vacation Mode”
Switch on mains power.
Remove obstruction.
Unlock door or remove jam.
Door requires service/repair by qualified technician.
Deactivate the stop switch/timer
Turn off “Vacation Mode”(Appendix C Menu 6.16).
Door starts to close but automatically
reverses to open position
Adverse weather conditions (wind or cold)
causing door to stiffen and become tight in
the tracks.
Possible obstruction in the doorway.
Increase force margin setting (Section 12.4)
Remove obstruction.
Door operates from wall control unit
(OPEN/CLOSE) button but not from
transmitter
Transmitter code not stored in memory. Code transmitter in to openers memory.
(Section 9.1)
Transmitter does not contain
TrioCode™128 Technology
Check the transmitter. It should have grey buttons
and the model number should display V2. Contact
dealer for support if otherwise.
Flat battery in transmitter Replace battery (Section 16))
Door does not close with transmitter Safety Close Mode is on.
Safety Beam not working properly.
Turn the Safety Close Mode off (Section 13.1)
Make sure Safety Beam are operational.
Door will not close fully. Door limit positions need to be reset.
Door obstructed and reverses.
Reset limits positions.
Clear obstruction or adjust force margin
(Section 12.3)
Door will not open fully. Door limit positions need to be reset.
Door obstructed.
Reset limits positions.
Clear obstruction or adjust force margin
(Section 12.3)
Auto-Close not working Safety Beam not installed. Install Safety Beam.
Safety Beam or wiring faulty. Repair Safety Beam or replace wiring.
Safety Beam not aligned correctly. Re-align optics.
Safety Beam is obstructed. Remove obstruction from path of Safety Beams.
Door obstructed when closing. Remove obstruction.
Auto-Close time not set. Set Auto-Close times (Section 13.3).
Auto-Close mode not set Set Auto-Close mode. (Section 13.2)
19. Troubleshooting
