SecuraLift®Trio
INSTALLATION INSTRUCTIONS | OWNER’S COPY
DC Overhead Garage Door Opener

2SecuraLift® Trio Overhead Garage Door Opener Owner Installation Instructions
WARNING: It is vital for the safety of all persons to follow
these instructions. Failure to comply with the installation
instructions and safety warnings may result in serious
personal injury and/or property damage.
Please save these instructions for future reference.
Automatic Technology (Australia) Pty Ltd to the extent that such may be lawfully excluded hereby expressly disclaims all
conditions or warranties, statutory or otherwise which may be implied by laws as conditions or warranties of purchase of an
Automatic Technology (Australia) Pty Ltd Garage Door Opener. Automatic Technology (Australia) Pty Ltd hereby further
expressly excludes all or any liability for any injury, damage, cost, expense or claim whatsoever suffered by any person as a
result whether directly or indirectly from failure to install the Automatic Technology (Australia) Pty Ltd Garage Door Opener
in accordance with these installation instructions.

Owner Installation Instructions SecuraLift® Trio Overhead Garage Door Opener 3
SecuraLift® Trio
Overhead Garage Door Opener
Important Safety Instructions 04
Features 06
Operating Controls 08
Kit Contents 10
Installation 12
C-Rail Assembly 12
Determine Door Type 14
Mounting on a Track Type Door 15
Mounting on a Non-Track Type Door 16
Mounting Door Bracket & Arms 17
Setting Travel Limits 18
Testing Safety Obstruction Force 19
Coding Transmitters 20
Door 20
Courtesy Light 20
Vacation Mode 21
Auxiliary Output 21
Pet (Pedestrian) Mode 22
Erasing Transmitter Codes 22
Mounting Wall Transmitter 22
Battery Back Up Installation 23
Accessories 24
P.E. Beams 24
Electric Key Switch 24
Remote Aerial 25
Terminal Block 25
Troubleshooting Guide 26
Default Settings & Specifications 27
Parameters 28
Maintenance 30
Parts List 32
Warranty 34

4SecuraLift® Trio Overhead Garage Door Opener Owner Installation Instructions
CAUTION: If your garage has no pedestrian entrance door, an emergency access device should be
installed. This accessory allows manual operation of the garage door from outside in the event of a
power failure.
For additional protection we strongly recommend fitting of Photo Electric (P.E.) Beams.
In most countries P.E. Beams are mandatory on all automated garage doors. For a small
additional outlay Automatic Technology recommends that P.E. Beams be installed with the SecuraLift®
Trio Overhead Garage Door Opener.
DO NOT operate the SecuraLift® Trio Overhead Garage Door Opener unless the garage door is
in full view and free from objects such as cars and children/people. Make sure that the door has
finished moving before entering or leaving the garage.
DO NOT operate the SecuraLift® Trio Overhead Garage Door Opener when persons are
in or near the doorway. Children near an moving garage door must be supervised at all
times. Serious personal injury and/or property damage can result from failure to follow
this warning.
DO NOT allow children to operate the garage door opener. Serious personal injury
and/or property damage can result from failure to follow this warning.
Regularly check that the safety obstruction force is tested and set as per page
19 of this manual. Failure to follow this could result in serious personal injury
and/or property damage. This must be repeated at regular intervals and
adjustments made as required.
DO NOT disengage the SecuraLift® Trio Overhead Garage Door
Opener to manual operation with persons or any other objects,
including motor vehicles, within the doorway.
The SecuraLift® Trio Overhead Garage Door Opener is not
intended for use by young children or infirm persons. Children
should be supervised to ensure that they do not play with the
remote transmitters or the opener.
Keep hands and loose clothing clear at all times.
The unit should be installed so that it is protected from
the elements. It should not be exposed to water or
rain, immersed in water or sprayed directly by a
hose or other water carrying device.
WARNING: It is vital for the safety of all persons to follow
these instructions. Failure to comply with the following
safety rules may result in serious personal injury and/or
property damage.
Important Safety Instructions

Owner Installation Instructions SecuraLift® Trio Overhead Garage Door Opener 5
The garage door must be well balanced. Sticking or binding doors must be repaired by a qualified garage door
installer prior to installation of the SecuraLift® Trio Overhead Garage Door Opener.
Frequently examine the installation, in particular cables, springs and mountings for signs of wear, damage or
imbalance. DO NOT use if repair or adjustment is needed since a fault in the installation or an incorrectly
balanced door may cause injury. DO NOT attempt to repair the door yourself as hardware is under extreme
tension.
Remove or disengage all garage door locks and mechanisms prior to installation of
the opener.
Connect the SecuraLift® Trio Overhead Garage Door Opener to a properly earthed general
purpose 240V mains power outlet installed by a qualified electrical contractor.
Disconnect the power cord from mains power before making any repairs or removing
covers. Only experienced service personnel should remove covers from the SecuraLift®
Trio Overhead Garage Door Opener.
When using auto-close mode, a P.E. Beam must be fitted correctly and tested for
operation at regular intervals. Extreme caution is recommended when using auto-
close mode. All safety rules must be followed - see page 24 for full details.
In order for the SecuraLift® Trio Overhead Garage Door Opener to sense an
object obstructing the doorway, some force must be exerted. As a result the
object, door and/or person may suffer damage or injury.
If the power supply cord is damaged, it must be replaced by an Automatic
Technology service agent.
Make sure that the door is fully open before driving in or out of the
garage and fully closed before leaving the driveway.
Make sure that remote controls are kept out of reach of
children.
Install the wall mounted transmitter in a location where it is
out of reach of children and the garage door is visible.
Important Safety Instructions

6SecuraLift® Trio Overhead Garage Door Opener Owner Installation Instructions
Operation
To open or close the door simply press a button on a TrioCode™ handheld
transmitter, or optional wall switch for two seconds. During open and close cycles
the door can be stopped by pressing the button again. The next actuation will
move the reverse the door’s direction.
TrioCode™ Code Hopping Technology
Every time a TrioCode™ transmitter is used a new security code is generated from
over 4.29 billion possibilities. This greatly enhances the security of the system and
makes “code grabbing” a thing of the past.
These transmitters also overcome interference issues by simultaneously sending a
signal over three slightly different frequencies. Even if two of the three signals are
jammed, the third will communicate with the opener.
ALPS (Automatic Limits Positioning System)
ALPS does away with manual adjustment of the door’s limits position using mechanical
parts, such as cams and microswitches.
ISS (Intelligent Safety obstruction System)
While the opener is performing a close cycle, should the door hit an obstacle or be restricted
in some manner, it will automatically reverse. The amount of force the door should encounter
before reversing is automatically adjusted during the initial installation of the automatic door
opener. The door will also stop if restricted whilst opening. The safety obstruction force should be
checked at least once a month. See page 19 for instructions.
Security Code Store
The SecuraLift® Trio Overhead Garage Door Opener will store up to 14 different transmitters codes.
Overload Indicator
When the maximum opening and closing force capacity of the SecuraLift® Trio Overhead Garage Door
Opener is exceeded an audible beeper will sound to indicate that an overload has occurred.
Features
Thank you for purchasing the SecuraLift® Trio
Overhead Garage Door Opener. Designed to suit
sectional, overhead and one piece tilt up doors, the
components and materials used ensure this opener
will provide years of smart, simple and secure
operation. Listed below are just some of the
many world leading features:

Owner Installation Instructions SecuraLift® Trio Overhead Garage Door Opener 7
LED Courtesy Light
The SecuraLift® Trio Overhead Garage Door Opener’s courtesy light illuminates automatically
whenever the door is activated. The light can also be switched on and off without operating
the door by pressing the button on any transmitter which has been coded to operate the
light. The light will stay on for approximately three minutes then switch off. These LED
lights have a super long life and virtually never require replacement.
Battery Back Up (optional)
The SecuraLift® Trio Overhead Garage Door Opener can be fitted with a battery
back up kit, allowing continued operation in the event of a power outage
NOTE: If the garage door is the only entrance to the garage and a Battery Back
Up kit is not fitted to the SecuraLift® Trio Overhead Garage Door Opener a keyed
cable release should be fitted to the exterior of the garage.
Vacation Mode
A transmitter can be coded to block out all other transmitters that have been
programmed into the opener’s memory. Vacation mode is ideal for homes with
non-permanent tenancy or when the door is to be left idle for long periods of
time.
Pet (Pedestrian) Mode
A transmitter can be programmed to open the door partially so that the family pet can
enter and exit the garage at any time.
Auto-Close Mode
The opener can be programmed to automatically close after an open cycle. It is compulsory
to install P.E. Beams if this mode is selected, otherwise the door may cause personal injury or
damage to property.
Photo Electric (P.E.) Beams (optional)
The opener has an input for a Photo Electric (P.E.) Beam to be connected for extra protection and use of the
auto-close mode.
Manual Operation
The opener is equipped with a unique manual disengaging device. If power to the SecuraLift® Trio Overhead
Garage Door Opener is disrupted for any reason, the door can be put into manual mode by pulling down on the
string handle on an angle towards the door. This will allow you to manually open or close the door. To re-engage
pull the string handle away from the door.

8SecuraLift® Trio Overhead Garage Door Opener Owner Installation Instructions
Operating Controls
Terminal is used to connect Va.c. power to the
control board.
10 Amp fuse to protect the electronic circuit
board.
SBY-3 Battery Charger connection to attach
a Battery Back Up kit.
24Vd.c. Motor Connection.
OPERATE button (Blue) is used during
installation to test the open, stop and close
cycles for the opener. The opener has to be
initialised by the LIMIT SET button to make the
OPERATE button operable. The OPERATE
button also can be used in lieu of a transmitter
to activate the opener.
PLUS (+) button (Green) is used during
installation to set the open limit position.
Pressing and holding this button will move the
door in the open direction. Movement stops
when the button is released.
NOTE: The safety obstruction system is
inoperable whenever the PLUS (+) button is
used to move the door.
PROG INPUT is used to connect the PG-3
Universal Handheld Programmer to edit control
and receiver functions.
OPEN LIMIT LED (Green) is used during
installation to help set the open limit position. It
also illuminates and flashes as the door opens,
and remains on when the open limit position
has been reached.
FORCE MARGIN SET button. The
obstruction force margin is set automatically
during installation. The margin can be adjusted
manually using the FORCE MARGIN SET
button (White). Holding the FORCE MARGIN
SET button and pressing PLUS (+) or MINUS (-)
buttons will increase or decrease the amount of
force. The FORCE MARGIN SET button should
only be used if environmental factors, such as
high winds, affect the door’s operation.
CLOSE LIMIT LED (Red) is used during
installation to set the close limit position. It also
illuminates and flashes as the door closes, and
remains on when the close limit position has
been reached.
MINUS (-) button (Red) is used during installation to set
the close limit position. Pressing and holding this button
will move the door in the close direction. Movement
stops when the button is released. This button is also
used for storing or erasing the transmitter button you
wish to use to command the door to open, stop or
close.
NOTE: The safety obstruction system is inoperable
whenever the MINUS (-) button is used to move the
door.
CODE SET LED (Red) flashes when a transmitter button
is stored.
LIMIT SET button (Blue) is used during installation,
together with the PLUS (+) and MINUS (-) buttons, to set
the door limit positions. The LIMIT SET button is also
used to re-initialise the opener.
SERVICE LED (Yellow) indicates when the opener
requires service or repairs.
Courtesy Light LED Module connects the 24V LED
lighting modules.
Terminal Block:
30V PWR - Used to power devices such as P.E.
Beams and external receiver (100
milliamp max).
P.E - Input to connect to P.E. Beams.
P.E 0V - 0 volt connection for P.E. Beams.
GND - Common -ve ground for accessories
OPERATE - Used for the connection of a wired
switch (momentary contact). This
switch can then be used to open,
stop or close the door. Install the
wall switch in a location where the
switch is out of reach of children and
the garage door is visible.
AUX OUT - This function allows the opener to
operate other devices such as
external lights, or an alarm system.
01
02
03
04
05
06
07
08
09
10
12
13
14
15
16
11

Owner Installation Instructions SecuraLift® Trio Overhead Garage Door Opener 9
Operating Controls
01
02
03
04 05
06
07
08
09
10
11
12
13
14
15
16

10 SecuraLift® Trio Overhead Garage Door Opener Owner Installation Instructions
Kit Contents
Drive Unit
1 x SecuraLift® Trio drive unit (Fig. 01)
1 x Transmitter pack (Fig. 01)
(Pack includes two keyring transmitters and batteries)
1 x Wall mount transmitter with battery (Fig. 01)
2 x Door attachment arms (Fig. 01)
1 x Accessory and hardware pack (Fig. 01)
1 x Manual Disengage Cord (Fig. 01)
1 x Installation Manual
Single Piece Track With Pre-Assembled
Chain
NOTE: The chain in one piece rail has been tensioned by
the factory. Do not adjust the tension of the chain.
IMPORTANT NOTE: If a modification to the length of the
track is required, the adjustment must be made from the
drive unit end only.
Single Piece Track With
Pre-Assembled Timing Belt
Note: The timing belt in one piece rail has been
tensioned by the factory. Do not adjust the tension of
the timing belt.
IMPORTANT NOTE: If modification to the track length
is required, adjustment must be made only from drive
unit end only.
OR
PLUS
01
fig
02
fig
03
fig
OR

Owner Installation Instructions SecuraLift® Trio Overhead Garage Door Opener 11
Three Piece Knockdown Track With
Pre-Assembled Chain
IMPORTANT NOTE: If a modification to the length of the
track is required, the adjustment must be made from the
drive unit end only.
Three Piece Knockdown Track With
Pre-Assembled Timing Belt
IMPORTANT NOTE: If a modification to the length of the
track is required, the adjustment must be made from the
drive unit end only.
Kit Contents
OR
04
fig
05
fig

12 SecuraLift® Trio Overhead Garage Door Opener Owner Installation Instructions
Knockdown C-Rail Assembly
Step 1 (Knockdown C-Rail units only)
Unpack and assemble the C-Rail as shown (Fig 06).
06
fig
To adjust the chain/belt tension, move the shuttle to middle of track, then using a
spring scale measure the force required to pull the shuttle (The recommended pull
force is 8kg (80N)). Adjust the 1/2” hex bolt to tension chain.
Screws10 Screws
Turn tracks around 9Tension 1/2” hex bolt 8
Swing and straighten 6
Slide sleeve
7
5Swing
Slide sleeve
34 Cut cable tie
2Swing and straighten
Start Swing
1

Owner Installation Instructions SecuraLift® Trio Overhead Garage Door Opener 13
C-Rail Assembly
08
fig
09
fig
Step 2 - Attach Manual Disengage Cord
If not already disengaged, flick the yellow clutch
lever up so it sits perpedicular to the rail.
Thread the loose end of the cord through the hole
in the yellow clutch lever (Fig. 07).
Thread the cord down to red toggle and knot
through the spare hole.
Test if secured properly by pulling back towards
sprocket end to engage, and the towards door end
to disengage.
Step 3 - Secure C-Rail to Drive Unit
Locate and insert the shaft of drive unit into the C-
Rail’s sprocket (Fig. 08).
Fix the two track brackets with four screws supplied
in accessory pack (Fig. 09).
a.
b.
c.
d.
a.
b.
Locate shaft into sprocket
Shaft
Hex flange screw taptite ‘S’ M4 X 10
Track bracket (x2)
07
fig

14 SecuraLift® Trio Overhead Garage Door Opener Owner Installation Instructions
Determine the Door Type
Step 4
Determine which type of garage door you have as
illustrated (Fig. 10 - 12).
For a sectional (panel) door on tracks (Fig. 10) proceed
with the installation from Step 5.
For a one piece door on tracks (Fig. 11) proceed with
the installation from Step 5.
For a one piece door without tracks (on springs) (Fig. 12)
proceed with the installation from Step 9.
10
fig
11
fig
12
fig
Proceed from Step 5
Door
Track
Sectional door with track
Proceed from Step 5
One piece door with track
Door
Track
Proceed from Step 9
One piece door without track

Owner Installation Instructions SecuraLift® Trio Overhead Garage Door Opener 15
Mounting on a Track Type Door
14
fig
13
fig
15
fig
16
fig
Track
Door
Track
Level
Level
Door
Drilled holes
Structural member
WARNING: Make sure concrete, brick wall or
timber lintels are solid and sound so as to form a
secure mounting platform. The opener must be securely
fastened to structural supports otherwise serious
personal injury and/or property damage may ensue.
Step 5 - Determine Bracket Position
Open the door and find the highest point of travel of
the top door panel.
Using a level, transfer this height to the wall above
the door (Fig. 13) and mark a line 60mm above it.
Determine the centre point on the wall above and on
top of the door. Then draw two (2) lines extending
21.5mm from each side of the centre point. (Fig. 14)
Step 6 - Mounting the Wall Bracket
Centre the bracket over the intersection of these two
lines. Mark centres for at least two holes (Fig. 14).
Ensure a solid mounting point is behind these
holes.
Drill holes into the wall with an appropriate sized bit.
Secure bracket to the wall using if:
CONCRETE/BRICK - 8mm or 5/6 loxins or
dynabolts
IF TIMBER - wood screw #20 or
equivalent min. 50mm
long).
Step 7 - Attach the C-Rail to the Wall Bracket
Attach the C-Rail assembly to the wall bracket
with the 90mm long clevis pin and secure with the
supplied snap pin (Fig. 15).
Leave the drive unit in its packing box for protection
during installation.
Step 8 - Securing the Drive Unit to the Ceiling
Raise the drive unit from the packing box and support
it in the horizontal position with a ladder.
Open the garage door. Rest the opener on the open
door and use a scrap piece of wood to bring it to
horizontal level.
Line up the track perpendicular to the wall.
Secure the perforated angle (not supplied) to the
ceiling above where drive unit’s mounting holes will
be once fully installed. A representative mounting is
shown (Fig. 16).
Connect the drive unit to the ceiling mounted
perforated angle with M8x20mm screws and nuts.
Strips should not extend more than 18mm below
centre of drive unit mounting holes (Fig. 16)
For an alternative mounting option, see Step 12.1
a.
b.
c.
a.
b.
c.
a.
b.
a.
b.
c.
d.
e.

16 SecuraLift® Trio Overhead Garage Door Opener Owner Installation Instructions
Mounting on a Non-Track Type
Door
18
fig
17
fig
19
fig
20
fig
Centre of door
Step
Ladder
Step
Ladder
C rail
Door
Highest point
of door travel
WARNING: Make sure concrete, brick wall or
timber lintels are solid and sound so as to form a
secure mounting platform. The opener must be securely
fastened to structural supports otherwise serious
personal injury and/or property damage may ensue.
Step 9 - Determine the Door’s Centre
Find the centre of the door and mark this location
both above the door and on top of the door.
Draw two lines 21.5mm either side of this (Fig. 17).
Step 10 - Prepositioning the Opener
Raise the door to open position.
Rest the opener on the top edge of the door with
end of the C-Rail against the wall (Fig. 18).
Support the drive unit level with the lowest point of
the open door (Fig. 18).
NOTE: Do not slide C-Rail along the face of the door.
Step 11 - Mounting the C-Rail
Close the door slowly. The C-Rail will be elevated by
the top edge of the door as it moves.
Stop the door when it is at its highest point of travel.
Allow 25mm additional height for clearance between
the door and the track (Fig. 19).
Support the C-Rail in this position and close the door
The height determined in Step 11(b) will be the
height at which to mount the wall bracket.
Centre the bracket along the lines drawn in Step 9.
Using the bracket as a template, mark a minimum of
two holes and drill with appropriate size bit. For a
more secure fitting, the wall bracket can be anchored
using more than two holes.
Secure bracket to the wall using if:
CONCRETE/BRICK - 8mm or 5/6 loxins or
dynabolts
IF TIMBER - wood screw #20 or
equivalent min. 50mm
long).
Attach the wall bracket to the C-Rail with the 90mm
long clevis pin (Fig. 15) and secure by a snap pin.
Step 12 - Secure the Drive Unit to the Ceiling
Secure the perforated angle (not supplied) to the
ceiling above where drive unit’s mounting holes will
be. See (Fig. 20) for a representative mounting.
Connect the drive unit to the ceiling mounted
perforated angle with M8x20mm screws and nuts.
Strips should not extend more than 18mm below
centre of drive unit mounting holes (Fig. 20).
For an alternative mounting option, see Step 12.1
a.
b.
a.
b.
c.
a.
b.
c.
d.
e.
f.
g.
h.
a.
b.
Structural member

Owner Installation Instructions SecuraLift® Trio Overhead Garage Door Opener 17
Mounting Door Bracket and Arms
21
fig
22
fig
23
fig
Step 12.1 - Alternative Mounting Option
The opener can be fastened to the roof by driving a bolt
through the C-Rail into a structural timber support. The
bolt head’s height must not exceed 6mm (Fig. 21).
Step 13 - Mounting Door Bracket
The door bracket comes in two parts. The bottom plate
with two mounting holes is used on its own for one piece
doors. For sectional doors, the top plate is placed over
the bottom plate and is fixed with four (4) screws (Fig. 22).
Mount the door bracket, or bracket assembly, on the
door’s centre line one-third down the top panel (Fig.
22) using M6 or equivalent screws (not supplied),
STEEL DOORS ONLY: Bracket can be welded on.
NOTE: If in doubt about the door’s strength,
reinforcement may be added to the door’s
frame where necessary. Door damage may occur if the
bracket is installed on a panel with insufficient strength.
The opener’s warranty does not cover damage caused
to the door and/or door panels.
Step 14 - Attaching the Arms
FOR TRACK TYPE DOORS
Assemble the bent and straight arms with bolts and
nuts supplied in the accessory pack (Fig. 23). Always
use both bent and straight arms.
Connect the assembled arm to the bracket and the
disengaged trolley with clevis and snap pins.
WARNING: Connecting the bent arm other way
around may damage the door.
FOR NON-TRACK TYPE DOORS
Assemble the bent and straight arms as shown in
(Fig. 23) with bolts and nuts supplied in the accessory
pack. Always use both the bent and straight arms.
Connect the assembled arm to the bracket and the
disengaged trolley with clevis and snap pins (Fig.
24).
If installing on a door with a bad wave action,
lengthening the arm will reduce this effect.
a.
b.
a.
b.
a.
b.
c.
X
A
M
m
m6 )
D
A
E
H
T
L
O
B
FO
THG
I
EH
(
Drill hole at centre of
track (recommended bolt
size M6 or M8)
Ceiling
Aluminium rail
Shuttle VP2 assembly
24
fig
TRACK TYPE DOORS
NON-TRACK TYPE DOORS

18 SecuraLift® Trio Overhead Garage Door Opener Owner Installation Instructions
26
fig
25
fig
27
fig
Setting Travel Limits
IMPORTANT NOTE: The OPERATE button will not
function until the open and close limit positions
are set.
NOTE: The door and shuttle must be engaged
into the chain index. The door should be open
approximately half way.
Step 15.1 - Setting Limits Positions
Remove the controls cover to access the controls
panel as shown in (Fig. 25). Replace it when setup
is completed.
Press and hold the MINUS (-) button to start the door
closing. Release the button once you have reached
your desired closed limit position (Fig 26).
Press the LIMIT SET button. This action will store the
close limit position into memory.
Press and hold the PLUS (+) button to start the door
opening. Release the button once you have reached
your desired open limit position.
Read the WARNING below.
IMPORTANT WARNING: The garage door will
automatically close, open and close again once
the LIMIT SET button is pressed. Ensure there are no
persons or objects in the door’s path before pressing
the LIMIT SET button.
Press the LIMIT SET button to store into memory the
open limit position. The door will now automatically
close to its limit position then fully open to calculate
the Safety Obstruction Forces
BE AWARE OF THE ABOVE WARNING.
The opener can now be operated via the OPERATE
button.
Step 15.2 - Resetting Door Limit Positions
To enter new limit positions the existing settings must be
deleted as follows:
Press and hold the LIMIT SET button (Fig. 27) for
six (6) seconds, until you hear three beeps and the
CLOSE LIMIT LED starts to flash.
Release the button.
Follow Step 15.1 to set new limit positions.
a.
b.
c.
d.
e.
f.
a.
b.
c.

Owner Installation Instructions SecuraLift® Trio Overhead Garage Door Opener 19
28
fig
29
fig
Testing Safety Obstruction Force
CAUTION: Take care when testing the safety
obstruction force. Failure to do so can result in
serious personal injury and/or property damage.
16.1 Test the Close Cycle
Press the OPERATE button to open the door (Fig.
28).
Place a piece of timber approximately 50mm high
on the floor directly under the door (Fig 29).
Press the OPERATE button to close door.
The door should strike the object and start to re-
open.
16.2 Testing the Open Cycle
Press the OPERATE button to close the door (Fig.
28).
Press OPERATE again to open the door.
When the door reaches approximately half way,
firmly grab the door’s bottom rail - the door should
stop.
If the door does not reverse readily when closing, or stop
when opening, the force may be excessive and need
adjustment, refer to Step 16.4.
IMPORTANT WARNING: If the door is closing and
is unable to re-open when obstructed, discontinue
use. Do not use a door with faulty obstruction sensing.
Repair fault and re-test before using.
Adjusting Safety Obstruction Force
The safety obstruction force is calculated automatically
and normally does not require adjustment. The only
time the force may need to be adjusted is due to
environmental conditions, such as areas that are windy,
dusty or have extreme temperature changes that affect
the operability and movement of the door.
Step 16.3 - To Increase Force Pressure
Press and hold the FORCE MARGIN SET button
(Fig 28).
While holding down the FORCE MARGIN SET
button, press the PLUS (+) button.
Each press will increase the force margin one step.
The OPEN LIMIT LED will flash each time the PLUS
(+) button is pressed to indicate an increase in
force.
Test the force again as per Steps 16.1 and 16.2.
If the OPEN LIMIT LED flashes continuously when
the PLUS (+) button is being pressed, this indicates
that the maximum force setting has been reached.
a.
b.
c.
d.
a.
b.
c.
a.
b.
c.
d.
e.
Step 16.4 - To Decrease Force Pressure
Press and hold the FORCE MARGIN SET
button (Fig 28).
While holding down the FORCE MARGIN SET
button, press the MINUS (-) button.
Each press will decrease the force margin one
step. The CLOSE LIMIT LED will flash each time
the MINUS (-) button is pressed to indicate a
decrease in force.
Test the force again as per Steps 16.1 and
16.2.
If the CLOSE LIMIT LED flashes continuously
when the MINUS (-) button is being pressed,
this indicates that the minimum force setting
has been reached.
Step 16.5 - To Recall Factory Set Force
Hold down the FORCE MARGIN SET button
and the LIMIT SET button for two seconds.
Release both buttons. The default setting
should now be recalled.
a.
b.
c.
d.
e.
a.
b.

20 SecuraLift® Trio Overhead Garage Door Opener Owner Installation Instructions
30
fig
31
fig
Coding Transmitters
Press CODE SET
button once
Select one of the four
buttons you wish to
use to control the door
Press CODE SET
button twice
Select one of the
four buttons (not yet
programmed) you wish
to use to control the
courtesy light
Step 17.1 - Storing the Transmitter Code
The opener can only operate from transmitters that have
been programmed into its receiver. The receiver needs
to learn the codes of any transmitters to be used with the
opener. Up to fourteen (14) codes can be stored in the
receiver’s memory.
Ensure that the battery is inserted into the
transmitter.
Press the CODE SET button and release. The
CODE SET LED will illuminate to indicate the
opener is in Code Learn mode. If a valid code is
not stored within 15 seconds the opener will exit
Code Learn (Fig. 30).
Press the transmitter button (one of four) that you
want to control the door. The CODE SET LED will
begin to flash.
Press the same transmitter button again. The CODE
SET LED will illuminate for one second and then go
out.
The transmitter is now coded to operate the door
- press the button to test.
Step 17.2 - Setting the Transmitter to Operate
the Courtesy Light
Although the courtesy light comes on with each operation
of the opener, it may also be controlled by a transmitter
without operating the door.
Press the CODE SET button twice. The CODE SET
LED will illuminate and the courtesy light will turn on
to indicate that the light code learning is active (Fig.
31).
Choose a transmitter button not already coded into
the receiver. Press this button and the CODE SET
LED will begin to flash.
Press the same transmitter button again. The CODE
SET LED will illuminate for one second and then go
out.
The transmitter is now coded to operate the light -
press the button to test.
a.
b.
c.
d.
e.
a.
b.
c.
d.
