Automatic Technology Syncro ATS-3 User manual

1
Sectional Door Opener
Installation Manual
Doc # 160420_04
Released 22/04/21
ATS Series
SYNCRO ATS-3
SMART SECTIONAL DOOR OPENER
TEMPO ATS-2
SECTIONAL DOOR OPENER

ATS Series Installation Manual2
Table of Contents
1. Installation Safety Warnings! 3
2. Before you Begin 4
3. Tools Required 4
4. Kit Contents 5
5. Position 5
6. Fit the Opener 6
7. Bracket Position 6
7.1 Wall Bracket Position: 6
7.2 Mounting The Wall Bracket: 6
7.3 Attach The Rail To The Wall Bracket 6
8. Perforated Angle 7
9. Mounting Brackets and Arms 7
10. Safety Beam Kit (ATS-3 Only) 8
10.1 Assemble the Mounting Bracket 8
10.2 Mounting the Bracket 8
10.3 Connect the Safety Beams 8
11. Specifications 9
12. Setting Limits 10
12.1 Set the Limit Positions & adjust drive speed: 10
12.2 Clearing the Door Limit Positions 11
12.3 Re-profiling the Door 11
12.4 Controller memory reset 11
13. Safety Testing 12
13.1 Test the Close Cycle 12
13.2 Testing the Open Cycle 12
13.3 Test the Manual Door Operation 12
13.4 Test the Battery Backup 12
14. Auto-Close & Accessories 13
14.1 Auto-Close 13
14.2 Terminal Block 13
14.3 Connecting or Disconnecting Accessories 13
15. Coding a Transmitter 14
15.1 Storing the Transmitter Code 14
15.2 Remotely Coding Transmitters 14
15.3 Erasing All Transmitter Codes 14
15.4 Vacation Mode 14
15.5 Installation of the Wall Mounted Transmitter 14
16. Smart Phone Control (ATS-3 Only) 15
Installation Instructions
Home Owner Instructions
WARNING! IMPORTANT SAFETY INSTRUCTIONS
FOLLOW ALL INSTRUCTIONS SINCE INCORRECT INSTALLATION CAN LEAD TO SEVERE INJURY.
•before installing the drive, remove all unnecessary ropes or chains and disable any equipment, such as locks, not needed for
powered operation;
•before installing the drive, check that the door is in good mechanical condition, correctly balanced and opens and closes
properly;
•install the actuating member for the manual release at a height less than 1,8 m;
•install any fixed control at a height of at least 1,5 m and within sight of the door but away from moving parts;
•permanently fix the labels warning against entrapment in a prominent place or near any fixed controls;
•permanently fix the label concerning the manual release adjacent to its actuating member;
•after installation, ensure that the mechanism is properly adjusted and that the drive reverses when the door contacts a 40
mm high object placed on the floor.
•necessary information for the safe handling of a drive weighing more than 20 kg. This information shall describe how to use
the handling means, such as hooks and ropes;
•the drive must not be used with a door incorporating a wicket door (unless the drive cannot be operated with the wicket door
open);
•after installation, ensure that parts of the door do not extend over public footpaths or roads.
•vertical doors and gates need an anti-drop feature or device;
•information if a hazardous part of the drive is intended to be installed at a height of at least 2.5 m above floor level or other
access level;
•except for horizontally moving pedestrian doors, ensure that entrapment due to the opening movement of the driven part
is avoided
17. Home Owner Safety Warnings! 16
18. Opener Safety & Security 17
18.1 Your Door CAN NOT be used when: 17
18.2 Your Door CAN be used when: 17
18.3 To Disengage the Opener: 17
18.4 To Re-Engage the Opener: 17
19. Operating your Opener 17
20. User Operating Controls 18
21. Troubleshooting 19
22. After Installation Care 21
22.1 Service Checklist 21
22.2 Battery Replacement 22
22.3 Battery Disposal 22
22.4 Warranty 22
23. Appendix 23
A - Status Indication during Operating Mode. 23
B - Adjustment Mode Instructions 24
C - Adjusting Force Margins 25
D - Battery Functions 25
E - Setting the PET Mode position 25
F - Setting up Tilt Door 25
G - Setting limits via Transmitter 26

ATS Series Installation Manual3
WARNING! • The door may operate unexpectedly, therefore do not allow anything to stay in the path of
the door.
• When operating the manual release while the door is open, the door may fall rapidly due
to weak or broken springs, or due to being improperly balanced.
• The drive must not be used with a door incorporating a wicket door, unless the drive cannot
be operated with the wicket door open.
• The drive is intended to be installed at least 2.5m above the floor.
• Do not disengage the opener to manual operation with children/persons or any objects
including motor vehicles within the doorway.
• If the door is closing and is unable to re-open when obstructed, discontinue use. Do not
use a door with faulty obstruction sensing
• When using auto close mode, a Photo Electric beam must be fitted correctly and tested
for operation at regular intervals. Extreme caution is recommended when using auto close
mode. All safety rules must be followed.
ELECTROCUTION! • Place opener in protected area so that it does not get wet.
• Do not spray with water .
• Disconnect the power cord from mains power before making any repairs or removing covers.
Only experienced service personnel should remove covers from the opener.
• If the power supply cord is damaged, it must be replaced by an Automatic Technology
service agent or suitably qualified person.
• Connect the opener to a properly earthed general purpose 240V mains power outlet
installed by a qualified electrical contractor.
CAUTION:
Emergency Access • If garage has no pedestrian entrance door, an emergency access device should be
installed. This accessory allows manual operation of the garage door from outside in case
of power failure.
Muscular strain • Practice correct lifting techniques (carton weighs approx 9kgs)
• Practice correct lifting techniques when required to lift the door as per installation instructions.
Fall from ladder • Ensure ladder is the correct type for job.
• Ensure ladder is on flat firm ground that will take the weight without the legs sinking.
• Ensure user has 3 points of contact while on ladder.
Crush injury from unsecured
door
• Place a 2 metre exclusion zone around area under the door while it is unsecured.
• Follow the installation instructions
Garage Door • Examine the door installation, in particular, springs and mountings for signs of wear, damage
and imbalance.
• The garage door must be well balanced. Sticking or binding doors must be repaired by a
qualified garage door installer prior to installation of the opener.
• Remove or disengage all garage door locks and mechanisms prior to installation of the opener.
Entanglement • Never plug in and operate opener prior to installation.
• Keep hands and loose clothing clear of door and guides at all times.
Entrapment under
operating door
• DO NOT operate the opener unless the garage door is in full view and free from objects
such as cars and children/people. Make sure that the door has finished moving before
entering or leaving the garage
• In order for the opener to sense an object obstructing the door way, some force must be
exerted on the object. As a result the object, door and/or person may suffer minor damage
or injury.
• Ensure the garage door is in good working order by undertaking regular servicing.
• Install the optional wall transmitter in a location where the garage door is visible, but out
of the reach of children at a height of at least 1.5m.
• Photo Electric beams must be installed if the closing force at the bottom edge of the door
exceeds 400N (40kg)
1. Installation Safety Warnings!
This automatic garage door opener is designed and tested to offer safe service provided it is
installed and operated in strict accordance with the following safety warnings. Failure to comply
with the following instructions may result in death, serious personal injury or property damage.

ATS Series Installation Manual4
3. Tools Required
2. Before you Begin
2.2 Test the following before commencing installation:
a. The door MUST BE in good operating condition.
b. Manually move the door up and down, the door should move freely without
binding or sticking. When the door is fully closed it should raise itself by 10cm
off the floor. Re-tension door if necessary.
c. The maximum force required to move the door should not exceed 20kg.
d. Lift the door to about halfway. When released, the door should stay in place.
DIY
DO NOT DO IT YOURSELF:
If any of the above door requirements are not met, DO
NOT attempt to fix yourself. Please contact a garage door
professional. (P) 13 62 63
2.1 Examine the conditions in the garage:
a. Look at the ceiling:
i. Is it plastered? The opener is mounted to a perforated angle which MUST be securely fastened to a structural support.
You will need to locate the structural beams in the ceiling which are generally 400mm apart.
ii. Does it have exposed beams? The opener is mounted to a perforated angle which must be securely fastened to a
structural support like the exposed beams. You may need to install a 40mm thick board (not supplied) between structural
supports.
b. Look at the wall above the garage door.
i. Is it brick? The wall bracket MUST be securely fastened to the wall with suitable screws and ensure it does not move.
Screwdrivers
Adjustable End Wrench
Sockets and Wrench
Pencil
Drill
2 x Screws
(M6 x 20mm)
Stepladder
Perforated Angle
Metal pieces
(32 x 32 x 1.5mm) x 1200mm length
4 x Screws
(M8 x 20mm)
4 x Bolts and Nuts
(M8)
Drill Bits
Pliers
Hack saw
Tape Measure
Level
ii. Is it timber? The wall bracket MUST be securely fastened to a structural
support. You may need to install a 40mm thick board (not supplied) between
structural supports to fasten the wall bracket to.

ATS Series Installation Manual5
4. Kit Contents
1
2
3
4
5
6
7
8
9
10
11
12
13
14
16
15
1. 1 x ATS drive unit
2. 1 x Wall mount transmitter
3. 2 x Transmitters and batteries
4. 1 x Bent arm door attachment
5. 1 x Straight arm door attachment
6. 1 x Wall bracket TS01
7. 1 x Door bracket Locator
8. 1 x Door bracket
9. 3 x Pin Snap SSP 8 ZNU 31080
10. 2 x Hex Head screw M8x25
11. 1 x Pin 0890
12. 2 x Clevis Pin 0829
13. 2 x Hex Serration flange nut M8
14. 4 x Hex flange screw taptite ‘S’ M4 x 10
PLUS
15. 2 x Track Bracket
16. 1 x Pre-Assembled Rail
10.00°
min
MINIMUM HEAD
ROOM FOR STEEL
RAIL 57mm
DOORS HIGHEST
POINT
Rail no Extension Kit 3156mm
Rail + 1 Extension Kit 3946mm
Rail + 2 Extension Kits 4736mm
* Rail refers to 3160 rail
170mm
3156mm*
3374mm
150mm
353mm
15
1
16
5
4
6
7
12
8
14
11 9
13
10
5. Position
Perforated
Angle
5.1 The Opener:
a. MUST BE installed in a dry position, protected from weather.
b. REQUIRES properly earthed 3 pin single phase power on the ceiling within an arms length of the opener.
c. Requires a MINIMUM HEADROOM of 57mm between the highest point of the door’s travel and the ceiling.
d. Use the diagram below as a reference when completing the installation.
129
9

ATS Series Installation Manual6
6. Fit the Opener
6.1 Secure C-Rail to Opener:
a. Remove the Opener from the box.
b. Locate and insert the shaft of drive unit 1into the C-Rail’s sprocket.
c. Fix the two track brackets 15 with four (4) M4 x 8 screws 14 supplied in accessory pack.
d. Place drive unit back in packing box for protection.
Locate shaft into
the sprocket
16
1
15
14
7. Bracket Position
7.1 Wall Bracket Position:
a. Determine the centre of the door and mark this point with a line on the wall
above.
b. Raise the door and find the highest point of travel of the first (top) door panel.
60mm
Level
WARNING! The Opener must be securely fastened to structural
supports, otherwise opener failure may ensue causing serious
personal injury and / or property damage.
DO NOT DO IT YOURSELF: If sufficient structural support can not
be found, contact a door professional for installation.
DIY
c. Using step ladder and a level, transfer this height to the wall above the door
and mark a line 60mm above it, across the centre line.
7.2 Mounting The Wall Bracket:
a. Draw two lines extending 21.5mm from each side of the centre point.
b. Centre the wall bracket 6over the intersection of these two lines. Mark
centres for at least two holes and ensure it is into a solid mounting point.
c. Drill holes in the wall with an appropriate bit.
d. Secure to the wall using:
i. IF CONCRETE OR BRICK:
8mm (5/6”) loxins/dynabolts.
ii. IF TIMBER:
wood screw #20 or similar (min. 50mm).
7.3 Attach The Rail To The Wall Bracket
a. Leave the drive unit in its packing box on the floor for protection and lift the
other end of the C-Rail.
b. Attach the C-Rail assembly 16 to the wall bracket 6with the
90mm long pin 11 and secure with the supplied pin snap 9.
16
11
9
6
6
WARNING!
DO NOT use tek screws
to affix rail. Only use
the screws provided,
and fix these into the
threaded holes in the
chassis.
Drilling additional
holes through chassis
could damage internal
components

ATS Series Installation Manual7
8. Perforated Angle
8.1 Attach Perforated Angle (not supplied) or equivalent
a. Measure across the ceiling from the centre point 3155mm (+/- 50mm) to find a supporting beam.
b. Create a perforated angle which best suits your site. Use a hack saw to cut the L shape metal strips. Secure the perforated
angle to a supporting beam using diagrams shown below.
c. Raise the drive unit to the ceiling mounted perforated angle and secure with M8x20mm screws and nuts (not supplied). Strips
should not extend more than 18mm below centre of drive unit mounting holes.
d. To prevent moisture on the C-rail running into the powerhead it is recommended a strip of silicon sealant is placed across the
top of the C-rail just before the opener.
Ceiling Beams that run towards the door requires:
1 x perforated L shape metal strip and
2 x shorter perforate L shape metal drop down strips.
Ceiling Beams that run parallel to the door requires:
2 x perforated L shape metal strips and
2 x shorter perforate L shape metal drop down strips.
(Not supplied)
9. Mounting Brackets and Arms
9.1 Mounting The Door Bracket:
a. The door bracket locator 7is placed over the door bracket
8, on the door’s centre line one-third down the top panel and
mounted using M6 or equivalent screws (not supplied),
b. STEEL DOORS ONLY: Bracket can be welded in place.
NOTE: If in doubt about the door’s strength, reinforcement
may be added to the door’s frame where necessary. Door
damage may occur if the bracket is installed on a panel
with insufficient strength. The opener’s warranty does not
cover damage caused to the door and/or door panels.
9.2 Attaching the Arms
a. Assemble the bent arm 4(connecting to the door) to the
right side of the straight arm 5with bolts 10 and nuts 13
supplied in the accessory pack. Connect the straight arm 5to
8
7
7
12
9
4
13
6
10
9
12
8
5
the shuttle with a clevis pin 12 and a pin snap 9. Always use both bent and straight arms.
b. Connect the assembled arm to the bracket with clevis pin 12 and pin snap 9. The angle “A” must be more than 10°.
A
Straighten the antenna on the opener, by pulling
straight down to ensure optimal reception.
tip

ATS Series Installation Manual8
10. Safety Beam Kit (ATS-3 Only)
10.1 Assemble the Mounting Bracket
The Safety Beam Kit provides additional safety by preventing the door
closing when the beam is blocked by a car, child etc. When the Safety Beam
Kit is installed the Auto-close feature can be enabled if required.
a. Attach the PE 2000TS Bracket 1to the Safety Beam Transmitter (TX)
using four (4) M3 x 5 Taptite screws 4.
b. Connect the mounting bracket 3to the adjustment bracket 2with
two (2) of the M5 x 10 Pan Head Screws 5.
c. Repeat steps (a) and (b) to assemble the Safety Beam Receiver (RX).
d. Mount the receiver on the side of the doorway in shade and the
transmitter on the other side in line with the receiver. The mounting
surface should be rigid. Affix with a minimum of four (4) screws
(not supplied).
10.2 Mounting the Bracket
The transmitter and receiver need to be placed in line of sight, with the beam
100mm above the ground level (as per AS/NZS 60335-2-95:2020). This can
be achieved by ensuring the bottom of the receiver and transmitter are
65mm above ground level. They should also be placed as close as possible
to the door opening with the receiver (RX) in shade and the transmitter (TX)
in sun or shade.
10.3 Connect the Safety Beams
Refer to the Safety Beam installation manual inside the kit for wiring
diagrams, battery installation and how to connect the specific safety beam.
WARNING! The Opener must be fitted with Safety Beams if:
• the closing force at the bottom edge of the door exceeds 400N (40kg) and/or;
• the opener has a smart device fitted to operate the door, when not in line-of-sight.
4
15
2
3
5
Right side
bracket
CAUTION! The Safety Beam must be installed and connected
before the travel limits are set.
65mm
100mm
TX
Sun or Shade

ATS Series Installation Manual9
11. Specifications
Technical Specifications SYNCRO
ATS-3V2 TEMPO ATS-2V2
Rated voltage range: 230V - 240V 230V - 240V
Rated frequency: 50Hz / 60Hz 50Hz / 60Hz
Rated power input: 225W 165W
Door opening:
Maximum Door Area:
Maximum Door Weight:
Door must be well balanced and able to
be operated by hand, as per warranty
conditions and AS/NZS 4505:2012
18m2
236kg* 18m2 200kg*
Minimum headroom 57mm 57mm
Rated Operating Time 4 mins 4 mins
Rated Temp +5oC to +40oC+5oC to +40oC
Short Term Peak force: 1100N 1100N
Rated load 400N 400N
Nominal force 200N (20kg) 200N (20kg)
Receiver type Multi-frequency UHF Multi-frequency UHF
Receiver code storage capacity 64 X 4-button Transmitters 64 X 4-button Transmitters
Transmitter battery CR2032 (3 Volts) CR2032 (3 Volts)
Main light LED (Light Emitting Diodes) LED (Light Emitting Diodes)
Network connectivity Network ready,
Smart hub already installed
Network compatible,
(requires optional Smart Phone Control
Kit)
* Gross door weight, including all fittings
Note: Intermittent operations may occur in areas which experience very strong winds. The strong wind puts extra pressure on the
door and tracks which may in turn intermittently trigger the safety obstruction detection system.

ATS Series Installation Manual10
12. Setting Limits
12.1 Set the Limit Positions and adjust drive speed:
When setting the Close limit, ensure the position is when the door
makes first contact with the ground. Alternatively for the Open
limit the position should be at the height of the garage opening.
NOTE: The drive speed is set to the fastest setting by default.
This may not be suitable for larger doors or for single piece doors.
For tilt doors (J-Type only), please refer to Appendix F for initial
setup.
a. Switch power on, the beeper will sound twice and the BLUE
LED on the CLOSE button will start to flash and the GEAR
LED is lit to indicate that the opener is ready to set the
Close travel limit.
b. Press either the CLOSE or OPEN button to move the door
to the halfway point.
WARNING! In setting the close limit position, do
not force the door into the floor with excessive
force, as this can interfere with the ease of
operation of the manual release mechanism.
Door Opener
Speed Mode
STATUS BEEPER &
MAIN LIGHT
Fast (Default) On 3 Beeps & Flashes
Medium On 2 Beeps & Flashes
Slow On 1 Beep & Flash
WARNING! The door will automatically close,
open and close again after the next step.
Ensure that nothing is in the door’s path.
CLOSE limit:
i. Press and hold the CLOSE button to start closing
the door, taking note of the speed the door moves.
ii. If the close speed is not suitable, to make a change,
press and hold the CLOSE button and by pressing the
STOP / SET button on the opener it will cycle through all
three speed modes as shown in table.
iii. Once at the desired speed, release the CLOSE button.
iv. To set the close limit, inch the door by making single
presses of the CLOSE button to the desired
position. We recommend the CLOSE limit position
being the first point of contact of the rubber strip
(at the bottom of the door) with the ground.
v. If the door overshoots, press the OPEN button to
move the door in the OPEN direction.
vi. When the door is at the desired CLOSE position, press
the STOP / SET button on the opener, the beeper will
sound once and the GREEN LED on the OPEN button
will now flash.
OPEN limit:
i. Press and hold the OPEN button to start opening
the door, taking note of the speed the door moves.
ii. If the open speed is not suitable, to make a change,
press and hold the OPEN button and by pressing the
STOP / SET button on the opener it will cycle through all
three speed modes as shown in table.
iii. Once at the desired speed, release the OPEN button.
iv. Continue inching the door to the desired position.
v. To set the open limit, inch the door by making single
presses of the OPEN button to the desired position.
We recommend the OPEN limit position being the height
of the garage opening.
vi. If the door overshoots, press the CLOSE button to
move the door in the CLOSE direction.
vii. When the door is at the desired OPEN position, press
the STOP / SET button The door will now automatically
close and open to calculate the safety obstruction
settings.
Refer to Appendix B & C for adjustments to
margins.
tip
CAUTION! Limit setup is not available when running on
battery backup
Refer to Appendix G for setting limits via a transmitter.
NOTE - Speed of the opener can not be adjusted when
using this method.
tip

ATS Series Installation Manual11
12. Setting Limits
NOTE: If unhappy with the speed or travel limit setting, restart this
procedure by resetting the door limit positions as per below first.
12.2 Clearing the Door Limit Positions
Limit positions can be deleted by:
a. Press the MODE button repetitively until the GEAR LED is lit.
b. Press and hold the MODE button for 10 secs, let the MODE button
go when the beeper stops and main light stops flashing.
c. The close LED will flash continuously to indicate limits have been
cleared.
NOTE: If no action is taken within 30 seconds, the opener will return
to normal operating mode and restore the original settings.
d. Follow from CLOSE limit: above to set new limit positions,
remembering to reset the tracklock.
12.3 Re-profiling the Door
Re-profiling is a simplified way of re-learning the travel characteristic
of a previously setup Limit Switch travel installation. Re-profiling can
be used when the travel characteristics of the door change due to
mechanical adjustments etc. To initiate a re-profile:
a. Limits must be set.
b. Press the MODE button repetitively until the GEAR LED is lit.
c. Press and hold the CLOSE button for two seconds, the door
will open and close by itself to record profile.
12.4 Controller memory reset
To clear the controller by:
a. Pressing and holding MODE button for 10secs while in limit set
mode will cause all control memory to be set to factory defaults.
b. This excludes transmitters, history log and cycle counters.
If limits are already set, clear limits first by using 12.2
Clearing the door limit positions and then clear controller
via 12.4 Controller memory reset.
tip

ATS Series Installation Manual12
13. Safety Testing
13.1 Test the Close Cycle
a. Press the OPEN button or transmitter button to open the door
(If the door starts closing, press the transmitter button to stop the
door, then press transmitter again to open).
b. Place a piece of timber approximately 40mm high on the floor
directly under the door.
c. Press the transmitter button to close door.
d. The door should strike the object and re-open.
e. Remove the timber .
13.2 Testing the Open Cycle
a. Press the CLOSE button or transmitter button to close the
door.
b. Press the transmitter button again to open the door.
c. When the door reaches approximately half way, firmly grab the
door’s bottom rail - the door should stop.
If the door does not reverse readily when closing, or stop when
opening, put the door into manual by pulling down on the manual
release string to diesengage the motor and contact 1300 769 850
for support.
13.3 Test the Manual Door Operation
A poorly maintained door could cause fatal / serious injuries or
damage to property:
a. Frequently examine the door, particularly the cables, springs
and mountings for signs of wear, damage or imbalance.
DO NOT USE if repair or adjustment is needed since a fault in
the installation or an incorrectly balanced door may cause injury.
b. Fasterners: Check all screws, nuts and bolts to ensure they are
secure.
c. Spring Tension: It is natural for springs to lose tension. Should the
door become hard to operate or completely inoperative, contact
a door professional.
d. Guide Tracks: Clean the internal sections of the guide tracks
every 3 - 6 months with a cloth dampened with mineral turps or
methylated spirits.
e. Periodically disengage the opener and manually operate the
door. The door must be smooth to operate by hand. The force
required on the bottom rail should not exceed 20kg.
13.4 Test the Battery Backup
a. Press either the OPEN or CLOSE button to test the battery backup
installation.
b. Whilst door is in motion, disconnect mains power. The door should
continue to operate as normal.
c. Press either the OPEN or CLOSE button to activate the door.
Whilst door is in motion, reconnect power. The door should
complete the cycle as normal.
CAUTION: Take care when completing a
safety test. Failure to follow this warning
can result in serious personal injury and/or
property damage.
WARNING! If the door is closing and is unable to
re-open when obstructed, discontinue use Do not use a
door with faulty obstruction sensing.
Wood 40mm high
WARNING! If the door fails these tests,
put the opener into manual mode, only
operate the door by hand and call for
service.
WARNING! Safety beams must be
installed if the closing force at the
bottom edge of the door exceeds 400N
(40kg).
When running from mains power and in
operating mode, the battery condition
can be tested by pressing and holding
the STOP button for 4 secs.
tip
CAUTION! ATA App operation when power
is out will depend on availability of Wi-Fi
connectivity
Refer to Appendix A for LED status indicators for the
Battery LED.
tip

ATS Series Installation Manual13
14. Auto-Close & Accessories
Parameter Value options = Indicated by brightness of
main light (DEFAULT parameter underlined)
Name Flashes 123456
PE AUTO-CLOSE 2OFF 15sec 30sec 60sec 90sec -
AUTO-CLOSE 3OFF 15sec 30sec 60sec 90sec 120sec
WARNING! It is compulsory to have
Safety Beams installed when using
Auto-Close mode.
14.1 Auto-Close
Auto-Close mode is a function that automatically closes the door after
a pre-set time. Safety beams must be installed in order to run the Auto-
Close function. There are two types of Auto-Close available:
i. Standard auto-close - the door will Auto-Close after a programmed
time. In this mode the timer starts to countdown as soon as the
door is fully open. This function is useful in case the safety beam
does not get triggered.
ii. Safety Beam triggered auto-close - the door will auto-close after
a programmed time. In this mode the timer starts counting down
only when the safety beam is triggered. ie car leaving the garage.
To enable the Auto-Close function:
a. Press the MODE button repetitively until the GEAR LED starts
flashing.
b. Press the OPEN button until the GEAR LED flashes:
i. two (2) times to get to PE auto-close or
ii. three (3) times to get to standard auto-close.
c. Press STOP / SET button to enter parameter.
d. The default setting for Auto-Close is OFF. Press the OPEN button
to move through options and the light’s brightness will change
accordingly.
e. Press STOP / SET button to save the parameter’s new value or press
MODE to leave the value unchanged.
14.2 Terminal Block
Wired accessory items can be connected to the terminal block J4.
Terminal connections from top down are as follows:
a. +35V (Auxillary)
b. AUX (Auxillary)
c. SB (Safety Beam input, mandatory);
d. GND (Common ground for accessories and Safety Beam);
e. GND (Common ground)
f. OSC (Open/Stop/Close trigger)
14.3 Connecting or Disconnecting Accessories
When disconnecting or reconnecting accessory base station modules
(Wireless PE Beams) press the MODE button on the opener repetitively
until the GEAR LED is on, then press the STOP / SET button until the main
courtesy light stops flashing.

ATS Series Installation Manual14
15. Coding a Transmitter
15.1 Storing the Transmitter Code
The opener can only be operated from remote control
transmitters that have been programmed into its memory.
Up to 64 codes can be stored in the memory.
a. Press the MODE button repetitively until the TRANSMIT
LED is lit.
b. Press and HOLD the button/s indicated in the table to
set the required transmitter function. The opener will
start to flash rapidly and beep.
c. Press one of the four (4) buttons on the transmitter until
the beeper and main light starts to flash rapidly, then
release transmitter button.
d. Press the remote control button again until the main
light stops flashing rapidly.
e. Release both buttons. Press the MODE button to exit.
The transmitter button is now coded, press to test.
NOTE: Refer to the Light indicator table for the details of
the transmitter status.
BUTTON
TRANSMITTER
FUNCTION
Open / Stop / Close HOLD
PET (Pedestrian) Mode HOLD
Open HOLD
Light HOLD HOLD
Vacation Mode HOLD HOLD
Aux Output HOLD HOLD
* The button coded for open only function can close the door if you
hold the button for 4 seconds, when the door is fully open..
MAIN LIGHT & BEEPER TRANSMITTER STATUS
Light ON & 2 short beep Button added
Light OFF & 2 short beep Button removed
Light 2 FLASHES, then OFF & 2
long beeps
Remote control deleted
4 FLASHES, then OFF & 4 long
beeps
Memory full
15.2 Remotely Coding Transmitters
Using this method transmitters can be coded without
access to the opener’s control panel as long as a
pre-coded transmitter is available.
a. Take any pre-coded transmitter. Press the button for the
function to be duplicated and release.
b. Using a small needle / pen, press and hold firmly for two
seconds the middle button, through the Coding Hole
until the unit starts flashing and beeping.
c. Within ten (10) seconds take the additional transmitter
you wish to code. Hold the new transmitter’s button
for two seconds the unit will flash and beep faster, then
release for two seconds
d. Press and hold again for two seconds until the flashing
and beeping stops and then release.
e. The opener will
falsh and beep to
indicate result. (see
table above)
f. Wait for ten (10)
seconds and then
press the new
transmitter’s button
to test.
15.3 Erasing All Transmitter Codes
a. Press the MODE button repetitively until the TRANSMIT
LED is lit.
b. Press and hold the MODE button for 10 secs, let the
MODE button go when the beeper and main light stops
flashing.
c. Follow steps a - e in Storing the Transmitter Code to
code new transmitters.
15.4 Vacation Mode
a. To turn on Vacation mode and lock out all remotes, press
the button on the remote programmed with Vacation
Mode for 4 seconds.
b. To turn off Vacation Mode, press the transmitter button
programmed to vacation mode to turn off.
15.5 Installation of the Wall Mounted Transmitter
a. Store the transmitter code as per instructions in 15.1 or
15.2.
b. Test the transmitter button.
c. Mount the transmitter in a convenient location, yet out
of reach of children and at least 1.5m off the ground.
d. Make sure the door is visible from this location.

ATS Series Installation Manual15
16. Smart Phone Control (ATS-3 Only)
This device allows for operation of the door when not in line-of-sight of the door and
opener.
The door may operate unexpectedly, therefore do not allow anything to stay in or near the path of the
door. When the door is not operating automatically, watch the door when it is moving and keep people
away until the door is completely opened or closed. Contact with the moving door can cause serious
personal injury or damage to property.
It is our strong recommendation that your opener be fitted with SAFETY BEAMS.Safety
Beams detect any obstructions in the door/gate’s path and override automatic operation if one
presents. These must be installed as in accordance with AS/NZS 60335-2-95:2020.
This is in addition to regular professional servicing, and monthly obstruction tests as detailed in
Section 12.
16.1 Connecting to Wifi
The Smart Phone Control works via your home’s WiFi network. Initial set
up involves linking your phone app, smart hub and opener to your home
network.
a. Download the ATA App.
b. Ensure the WiFi router is within range of the opener.
c. On the opener press the MODE button repetitively until the NETWORK
LED is lit.
d. Press and hold the OPEN button on the opener for 4 seconds. The NETWORK LED will
turn purple when Hot Spot is Active.
e. Go to phone settings, then WiFi and select (ATA000000).
f. Open App and tap on Start.
g. Select setup a new Smart Hub
h. When Smart hub hotspot connection appears, select OK got it.
i. Ensure WiFi network = (ATA000000) then select connect to hub.
j. The opener main light and a red NETWORK LED will start to flash.
k. Press STOP / SET button on the opener.
l. Name your smart hub on the app and select SAVE.
m.Set the time zone and SAVE.
n. Create an admin user and select “OK got it”.
o. Fill in name and password and select CREATE.
p. Fill in email and security question or select skip this step and select SAVE.
q. Select the push notification and select SAVE.
r. Select and connect to WiFi. Choose your home WiFi and fill in password and select connect.
s. The NETWORK LED will change to solid blue.
t. Now you can test the app.
Ensure limits are set prior to connecting to Wi.
tip

ATS Series Installation Manual16
This automatic garage door opener is designed and tested to offer safe service provided it is installed and operated
in strict accordance with the following safety warnings. Failure to comply with the following instructions may result in
death, serious personal injury or property damage.
17. Home Owner Safety Warnings!
WARNING! IMPORTANT SAFETY INSTRUCTIONS
IT IS IMPORTANT FOR THE SAFETY OF PERSONS TO FOLLOW ALL INSTRUCTIONS.
SAVE THESE INSTRUCTIONS
WARNING! • Automatic Door - the door may operate unexpectedly, therefore do not allow anything to stay in
the path of the door.
• Details on how to use manual release. When operating the manual release while the door is open,
the door may fall rapidly due to weak or broken springs, or due to being improperly balanced.
• DO NOT disengage the opener to manual operation with children/persons or any objects
including motor vehicles within the doorway.
• If the door is closing and does not re-open when obstructed, discontinue use. DO NOT use a
door with faulty obstruction sensing.
• Frequently examine the installation, in particular check cables, springs and mountings for signs
of wear, damage or imbalance. DO NOT use if repair or adjustment is needed since fault in the
installation or an incorrectly balanced door may cause injury.
ELECTROCUTION! • Place opener in protected area so that it does not get wet.
• DO NOT spray with water .
• DO NOT open the protective covers.
• DO NOT operate opener if cable is damaged. It must be replaced by the manufacturer, its service
agent or similarly qualified person in order to avoid a hazard.
• Disconnect the supply(s) when cleaning or other maintenance is being carried out.
DO NOT DO IT
YOURSELF • Keep the garage door balanced. Sticking or binding doors must be repaired. Garage doors, door
springs, brackets and their hardware are under extreme tension and can cause serious personal
injury. DO NOT attempt any garage door adjustment. DO NOT use if repair or adjustment is
needed. Call for a professional garage door service.
BATTERY
WARNING!
• This product contains a lithium button/coin cell battery in the transmitters. If a new or used lithium
button/coin cell battery is swallowed or enters the body, it can cause severe internal burns and
can lead to death in as little as 2 hours. Always completely secure the battery compartment. If
the battery compartment does not close securely, stop using the product, remove the battery and
keep it away from children. If you think batteries might have been swallowed or placed inside any
part of the body, SEEK IMMEDIATE MEDICAL ATTENTION.
CAUTION:
Emergency access • If your garage has no pedestrian entrance door, an emergency access device should be installed.
This accessory allows manual operation of the garage door from outside in case of power failure.
Entrapment under
operating door
• Watch the moving door and keep people away until the door is completely opened or closed.
DO NOT operate door when persons are near the door.
• DO NOT allow children to play with door controls or transmitters. Keep remote controls away
form children.
• The appliance is not to be used by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision
or instruction.
• Children being supervised not to play with the appliance.
• Regularly conduct Open and Close cycle testing.
• Each month check that the drive reverses when the door contacts a 40mm high object placed on
the floor. Adjust if necessary and recheck since an incorrect adjustment may present a hazard.
• Ensure the garage door is in good working order by undertaking regular servicing.
• Wall transmitters should be installed in a location where the garage door is visible, but out of the
reach of children at a height of at least 1.5m.
• Install Safety Beams (recommended).
Fall from Ladder • Ensure ladder is the correct type for the job.
• Ensure ladder is on flat ground.
• Ensure user has 3 points of contact while on ladder.
Entanglement in or
laceration from
moving door
• Keep hands and loose clothing clear of door and guides at all times.
• Keep hands clear of moving door as sharp edges can cause cuts or lacerations.
DIY

ATS Series Installation Manual17
18. Opener Safety & Security
18.1 Your Door CAN NOT be used by the opener when:
a. There is a locking device installed.
b. There is a power failure.
18.2 Your Door CAN be used when:
a. There is an emergency, by disengaging the opener.
b. There is a power failure, by disengaging the opener.
18.3 To Disengage the Opener:
a. It is recommended to do so with the door in the closed position.
b. Pull the manual release cord towards the door, until you hear a click.
c. Move the door manually.
18.4 To Re-Engage the Opener:
a. Check the door has not been locked by a locking device.
b. Pull the manual release cord away from the door, until you hear a click.
c. The door will now operate from the opener.
CAUTION: When the opener is manually disengaged,
the door is no longer locked. To lock the door
manually, re-engage the opener after the door is
closed.
19. Operating your Opener
19.1 To Operate the opener:
a. Press the programmed transmitter button until your
door begins to move (usually 2 seconds). Make sure
you can see the door when you use the transmitter.
b. If you are in a vehicle you should aim the transmitter
through your windscreen as shown.
c. Check that the door is fully open or closed before you
drive in or away.
d. If you press the transmitter whilst the door is moving
the door will stop. The next press of the transmitter
will move the door in the opposite direction.
WARNING! When operating the manual
release (while the door is open) the door
may fall rapidly due to weak or broken
springs, or due to being improperly
balanced.
Do not disengage the opener to manual
operation with children/persons or any
objects including motor vehicles within
the doorway.
CAUTION: Do not use the string handle as a
mechanism to open the door. Failure to comply may
cause serious injury.

ATS Series Installation Manual18
20. User Operating Controls
05 06 07
01
02
03 04
Button Function
1. DOWN ARROW (Blue) Closes the door
2. DOWN ARROW LED (Blue) Illuminates when the door is closed and flashes when the door is obstructed on close
or stopped.
3. STOP (Red) Stops the door
4. UP ARROW (Green) Opens the door
5. UP ARROW LED (Green) Illuminates when the door is open and flashes when the door is open with the auto-
close timer running, obstructed on opening or stopped.
6. MODE (Yellow) Enables Load Diagnostics Mode
7. MODE STATUS LED (Yellow) Illuminates when in Diagnostics Mode
8. BATTERY STATUS LED (Yellow) Illuminates when battery is charged and flashes when battery is charging, in use or
battery failed. Battery function not available with ATS-2 model.
9. REMOTE CONTROL
STATUS LED (Red)
Flashes on remote lockout and flickers on remote control activity
10. ADJUSTMENT LED (Yellow) Flashes a certain number of times depending on the parameter being changed.
11. NETWORK LED
( ATS-3 Only)
Is a dual colour LED. Illuminates purple when hot spot active, blue when connected to cloud and
red when in production mode. Flashes different colour depending on the activity.
08091011

ATS Series Installation Manual19
21. Troubleshooting
Symptom Possible cause Remedy
The opener does not
work from the transmitter
Garage door in poor condition e.g.
springs may be broken
The opener does not have power
The battery in the transmitter is flat
The opener has turned on “Vacation
Mode”
The transmitter button is not
programmed to operate the door.
Check the door’s operation
Plug a device of similar voltage (e.g. a hairdryer) into
the power point and check that it is OK
Replace the battery
Turn off “Vacation Mode”
(Section 15)
Code in the transmitter
One transmitter works
but the other/s do not
Faulty transmitter
Flat battery
Replace transmitter
Replace battery
The chain / belt moves
but the door remains
stationary
The opener is disengaged Re-engage the opener
Motor is running but
chain / belt is not moving
Damage motor assembly Contact your dealer for support.
The transmitter range
varies or is restricted
Variations are normal depending on
conditions e.g. temperature or external
interference
The battery life is exhausted
Position of the transmitter in the motor
vehicle
Make sure you can see the door when you use the
transmitter.
Check the battery status by pressing a button
(flashing or no light, battery need changing)
Aim the transmitter through the windscreen.
The Courtesy light does
not work
LED has failed Change LED.
The door reverses for no
apparent reason
This may occur occasionally from
environmental conditions such as areas
that are windy, dusty or have extreme
temperature changes.
If Safety beams are installed they may
be partially obstructed.
Ensure the door runs smoothly before increasing the
force pressure.
Ensure the beam path is not obstructed. Check the
Alignment.
Door will not close Safety Beam not working
Safety Beam battery flat
To access safety close mode, hold the transmitter
button to close for 6 seconds and continue to hold
while the door closes.
Check Safety Beam
Auto Close not working Safety Beam or wiring faulty Repair Safety Beam or replace wiring.
Re-align optics. See Safety Beam instructions.
The door stops or moves
very slowly under battery
(Optional Battery Back
Up Accessory)
The batteries may have little or no
charge
Connect mains power and leave the batteries to
charge. The batteries may take 24 hours to reach
their maximum charge capacity.
The CLOSE (Blue) LED is
flashing
Limits are not set Set Up Limits (Section 12).

ATS Series Installation Manual20
21. Troubleshooting
Flashes Issue Remedy
x 2 PE is preventing door from moving
Clear away any obstructions. Test Door. If unable to move the
door and suspect beam is faulty, enter Safety Beam Emergency
Close by pressing and holding a pre-coded button on transmitter
for more than five seconds and the door will start closing.
x 3 NOT AVAILABLE
x 4 Wireless PE battery is low Change PE Battery
x 5 NOT AVAILABLE
x 6 Maintenance is due after pre-set number of cycles. Contact dealer to arrange service.
x 7 Backup battery is faulty Contact 1300 769 850 within Australia for assistance
x 8 Door has hit an obstruction Clear away any obstructions and test door opens/closes
correctly. (If door is damaged, contact your door professional)
x 9 Motor has overloaded or stalled
Check the doors operation by disengaging the motor and
ensuring the door runs smoothly. If necessary make door
adjustments or contact your door professional.
x 10 Battery backup activated - mains power is off
Main light will flash (3) three times at the start of the cycle to
indicate opener is running from battery backup and 10 flashes
at the end of cycle. Check power supply.
Flashes FAULT
x 2
or x 3
Failed while profiling door after setting limits. Can be caused
by any event which cause door to stop. For example P.E
beam being blocked on closing, hit an obstruction, etc. Also
can occur if battery is activated.
x 4
or x 5 Position Fault
x 6 Motor driving in wrong direction
x 7 Memory fault
x 8 Motor current sensor fault.
Connecting or Disconnecting Accessories:
When disconnecting or reconnecting accessory base station modules
(Wireless PE Beams) press the MODE button repetitively until the GEAR
LED is on, the press the STOP / SET button until the main courtesy light
stops flashing.
1. Has anything happened since the opener last
operated OK, e.g. a storm, a jolt to the door
etc.?
2. What is the current light status on the opener?
3. Manually disengage the door
(Section 18). How easy is it to manually open
and close the door?
4. What model is the opener? (Model no.
information is located at the rear of the
opener)
5. Who installed the opener? (Dealer details
should be on a sticker on the back of your
garage door)
6. When was it installed? (If known)
Main Light = FAULT Status Indicator (when MODE is on):
When MODE is ON, light flashes indicated number of times. When
first triggered, the beeper will sound the indicated number of beeps.
Attemptingtooperatethedoorwillresultinthebeepsbeingheard again.
The below table identifys the issues and remedies.
Main Light = Service / Warning Indicator:
Requirements for a service and user warnings are indicated after operation by the main light repeatably flashing
OFF a number of times followed by a pause. When the alert is first triggered the beeper will also sound
The below table identifys the issues and remedies.
If You Need a Service Call
If the opener needs a service please call the
dealer who installed the garage door opener
(their contact details are usually on a sticker on the
back of your garage door). For product assistance
contact 1300 769 850 within Australia.
BEFORE CALLING you should have the following
information to assist in providing the appropriate
service:
