Automatic Technology GDO-9 Dynamo Gen 2 User manual

Home Owner’s Manual
Doc #: 160016_00
Part #: 13305
06/05/2013
GDO-9 Dynamo™Gen 2
Overhead Garage Door Opener
Featuring TrioCode™Technology

GDO-9 DynamoTM GEN2 Home Owner’s Manual
2
Table of Contents
1. Safety Rules 3
2. Features 4
3. Specifications 5
4. Operating your door 6
5. User Operating Controls 7
6. Opener Safety & Security 8
6.1 Manual Door Operation 8
6.2 Emergency Evacuations 8
6.3 Power Failure 8
6.4 Re-Engaging the Opener 8
6.5 Security - Inbuilt Locking Facility 8
7. Safety Testing 9
7.1 Test the Close Cycle 9
7.2 Testing the Open Cycle 9
7.3 Test the Manual Door Operation 9
7.4 Test the Battery Back Up (Optional Accessory) 9
8. Coding Transmitters 10
8.1 Storing the Transmitter Code 10
8.2 Setting the Transmitter to Operate the Courtesy Light 10
8.3 Setting the Transmitter to Operate Vacation Mode 11
8.4 To Erase Programmed Codes 11
8.5 Installation of the Wall Mounted Transmitter 11
9. Troubleshooting Guide 12
10. Maintenance 14
10.1 Door Maintenance 14
10.2 Lubrication (every 3 - 6 months) 14
10.3 Door Service and Repair 14
10.4 Opener Maintenance 15
10.5 Service Indicator 15
10.6 Removing the Battery From the Transmitter 15
11. Warranty 16
12. Optional Accessories 18
13. Service Schedule 19
WARNING! • When operating the manual release while the door is open, the
door may fall rapidly due to weak or broken springs, or due to being
improperly balanced.
• Do not disengage the opener to manual operation with children/persons
or any objects including motor vehicles within the doorway.
• If the door is closing and does not re-open when obstructed,
discontinue use. Do not use a door with faulty obstruction sensing.
ELECTROCUTION! • Place opener in protected area so that it does not get wet.
• Do not spray with water .
• Do not open the protective covers.
• Do not operate opener if cable is damaged.
CAUTION:
Emergency access • If your garage has no pedestrian entrance door, an emergency access
device should be installed. This accessory allows manual operation of
the garage door from outside in case of power failure.
Entrapment under
operating door
• Watch the moving door and keep people away until the door is
completely opened or closed. Do not operate door when persons are
near the door.
• Do not allow children to play with door controls or transmitters.
• Regularly conduct Open and Close cycle testing.
• Ensure the garage door is in good working order by undertaking regular
servicing.
• Wall transmitters should be installed in a location where the garage door
is visible, but out of the reach of children at a height of at
least 1.5m.
• Install Photo Electric Beams (recommended).
Fall from Ladder • Ensure ladder is the correct type for the job.
• Ensure ladder is on flat ground.
• Ensure user has 3 points of contact while on ladder.
Entanglement in or
laceration from
moving door
• Keep hands and loose clothing clear of door and guides at all times.
• Keep hands clear of moving door as sharp edges can cause cuts or
lacerations.
DO NOT DO IT
YOURSELF
• Keep the garage door balanced. Sticking or binding doors must be
repaired. Garage doors, door springs, brackets and their hardware are
under extreme tension and can cause serious personal injury. Do not
attempt any garage door adjustment. Do not use if repair or adjustment
is needed. Call for a professional garage door service.

3
GDO-9 DynamoTM GEN2 Home Owner’s Manual
Table of Contents
1. Safety Rules
Automatic Technology (Australia) Pty Ltd to the extent that such may be lawfully excluded hereby expressly disclaims all conditions or warranties, statutory or otherwise which may be
implied by laws as conditions or warranties of purchase of a Automatic Technology (Australia) Pty Ltd Garage Door Opener. Automatic Technolofy (Australia) Pty Ltd hereby further
expressly excludes all or any liability for any injury, damage, cost, expense or claim whatsoever suffered by any person as a result whether directly or indirectly from failure to install the
Automatic Technology ( Australia) Pty Ltd Garage Door Opener in accordance with the installation instructions.
Please read these important safety rules
This automatic garage door opener is designed and tested to offer safe service provided it is
installed and operated in strict accordance with the following safety rules. Failure to comply with
the following instructions may result in death, serious personal injury or property damage.
WARNING! • When operating the manual release while the door is open, the
door may fall rapidly due to weak or broken springs, or due to being
improperly balanced.
• Do not disengage the opener to manual operation with children/persons
or any objects including motor vehicles within the doorway.
• If the door is closing and does not re-open when obstructed,
discontinue use. Do not use a door with faulty obstruction sensing.
ELECTROCUTION! • Place opener in protected area so that it does not get wet.
• Do not spray with water .
• Do not open the protective covers.
• Do not operate opener if cable is damaged.
CAUTION:
Emergency access • If your garage has no pedestrian entrance door, an emergency access
device should be installed. This accessory allows manual operation of
the garage door from outside in case of power failure.
Entrapment under
operating door
• Watch the moving door and keep people away until the door is
completely opened or closed. Do not operate door when persons are
near the door.
• Do not allow children to play with door controls or transmitters.
• Regularly conduct Open and Close cycle testing.
• Ensure the garage door is in good working order by undertaking regular
servicing.
• Wall transmitters should be installed in a location where the garage door
is visible, but out of the reach of children at a height of at
least 1.5m.
• Install Photo Electric Beams (recommended).
Fall from Ladder • Ensure ladder is the correct type for the job.
• Ensure ladder is on flat ground.
• Ensure user has 3 points of contact while on ladder.
Entanglement in or
laceration from
moving door
• Keep hands and loose clothing clear of door and guides at all times.
• Keep hands clear of moving door as sharp edges can cause cuts or
lacerations.
DO NOT DO IT
YOURSELF
• Keep the garage door balanced. Sticking or binding doors must be
repaired. Garage doors, door springs, brackets and their hardware are
under extreme tension and can cause serious personal injury. Do not
attempt any garage door adjustment. Do not use if repair or adjustment
is needed. Call for a professional garage door service.
DIY

GDO-9 DynamoTM GEN2 Home Owner’s Manual
4
Warranty
Two (2) year/5,000 cycles full parts and labour
warranty on motor, electronics and mechanical
components of the opener when installed by an
Automatic Technology Dealer.
TrioCode Frequency Hopping Technology
Every time a transmitter is used, it simultaneously
sends a signal over three different frequencies,
reducing the chance of interference from other
radio frequency sources.
Code Hopping Technology
Every time a transmitter is used a new security
code is generated from over 4.29 billion possible
code combinations. This greatly enhances the
security of the system and makes “code grabbing”
a thing of the past!
Multi-Channel Transmitter
Multi-channel transmitters allow you to operate
other devices such as an adjoining garage door
or automated gate from the same handy unit.
Safety Reversing System
The automatic safety reverse system significantly
reduces the risk of death or serious injury if
trapped by a closing door. The safety reverse force
can be adjusted for environmental conditions
such as windy areas.
Memory Retention
In case of a power failure the opener does not
lose the transmitter codes or limit settings.
Soft Start/Soft Stop
The opener eases into and out of each cycle
making for smoother and quieter operation, as
well as reducing wear and tear on the door and
opener.
Manual Release
The manual release handle allows the door to be
operated by hand in the event of a power failure.
Self Locking
There is no need to manually lock your garage
door, as the opener ‘positively’ locks the door
when closed.
Service Indicator
The opener has a built in service counter. From
factory this is loaded with 3000 cycles. When
this counter expires, the service yellow LED will
light up and at the start of each door movement
the beeper will sound three times. Contact your
dealer/installer for service. (Refer to 10.5 for
information).
Service Fault Indicator
Flashing LEDs on the control panel easily identify
operational problems or service requirements.
Dynamic Door Profiling
Changing door characteristics are automatically
compensated for and “learnt” with each
operation of the door.
Safety Beam (Optional)
The opener has an input to connect a Safety
Beam for extra safety and use of the Auto-Close
mode. Safety Beam PE 3 kit or Wireless Safety
Beam kit can be used with this opener.
SmartSolar™ and Battery Backup
Compatibility (Optional)
The opener can be fitted with a SmartSolar™ or
Battery Backup kit for operation in the event of
a power outage, or where mains power access is
not available.
Auto Courtesy Light
The courtesy light comes on automatically for
three minutes whenever the door is activated.
The light can also be operated independently
of the door by coding in a dedicated button on
a transmitter. (Refer to 8.2 for information)
Vacation Mode
A transmitter can be programmed to disable
the garage door opener radio receiver. This is
ideal if the door is to be left idle for prolonged
periods. (Refer to 8.3 for information)
Pet (Pedestrian) Mode
A transmitter can be programmed to open
the door partially to allow pets access to the
garage. The door opening height is adjustable
via a handheld programmer (contact your
dealer for further information).
2. Features

5
GDO-9 DynamoTM GEN2 Home Owner’s Manual
3. Specifications
Technical Specifications
Power supply 230V - 240Va.c. 50Hz
Maximum door opening:
Width:
Height:
Weight:
5500mm (16.5m2)
3000mm
100kg
Minimum headroom 25mm
Short Term Peak Force 800N (80kg)
Rated force 500N (50kg) with Chain
450N (45kg) with Timing Belt
Nominal force 150N (15kg)
Receiver type UHF Multi-frequency FM Receiver
Receiver code storage capacity 64 X 4 button Transmitter Codes
Transmitter frequency TrioCodeTM Type
Coding type Mulit-frequency Code Hopping
Number of code combinations Over 4.29 billion random codes
Code generation Non-linear encryption algorithm
Transmitter battery CR2032 (3 Volts)
Courtesy light Bright LED
Note: Intermittent operations may occur in areas which experience very strong winds. The strong wind
puts extra pressure on the door and tracks which may in turn intermittently trigger the safety obstruction
detection system.

GDO-9 DynamoTM GEN2 Home Owner’s Manual
6
Fig. 4.1
Transmitter
•To operate the opener, press the programmed
transmitter button until your door begins to move
(usually 2 seconds). Make sure you can see the
door when you use the transmitter.
•If you are in a vehicle you should aim the
transmitter through your windscreen (Fig. 4.1).
•Check that the door is fully closed before you
drive away.
•If you press the transmitter whilst the door is
moving the door will stop. The next press of the
transmitter will move the door in the opposite
direction.
The transmitter may also be programmed to operate
the following features (Refer to Section 8 for full
details):
•Turn the courtesy light on and off without
operating the door,
•Put the garage door opener into “Vacation Mode”
where it will not respond to any transmitters.
NOTE: Additional transmitters may be purchased at
any time.
CAUTION: Activate the opener only
when the door is in full view, free of
obstructions and with the opener
properly adjusted. No one should enter
or leave the garage while the door is in
motion. Do not allow children to play
with or near the door.
ELECTROCUTION! This opener is a
mains voltage plug-in domestic appliance
and there are no user serviceable parts
inside this opener.
For maximum efficiency of your opener, your garage
door must be in good operating condition.
An annual service of your garage door by an
Approved Dealer is recommended.
4. Operating your door

7
GDO-9 DynamoTM GEN2 Home Owner’s Manual
Door Status Indicators OPEN LED (green) CLOSE LED (red) Beeper
Open On
Close On
Opening Flashing
Closing Flashing
Door travel stopped Flashing Flashing
Door obstructed when opening Flashing Beeps while door is
moving
Door obstructed when closing Flashing Beeps while door is
moving
Opener overloaded Alternating flashes Alternating flashes
Door in open position with
Auto-Close mode selected
One second flashes
Mains power interrupted Rapid flashes
5. User Operating Controls
Button (Fig 5.1) Function
1. OPERATE Opens/stops/closes the door
2. CODING LED (Red) Flashes when a code is being stored or when the transmitter button is
pressed
3. LIGHT CODE (White) Is used for storing or erasing the transmitter button (code) you wish to use
to switch the courtesy light on the opener on or off.
4. DOOR CODE (Blue) Is used for storing or erasing transmitter buttons for door operation
5. OPEN LED (Green) Illuminates and flashes as the door opens and remains on when the open
limit position has been reached.
6. DOOR STATUS LED (Yellow) Illuminates when Service is due.
7. CLOSE LED (Red) Illuminates and flashes as the door opens closes, and remains on when the
close limit position has been reached.
Fig. 5.1
05
06
07
01
02
03
04

GDO-9 DynamoTM GEN2 Home Owner’s Manual
8
Fig. 6.2
6. Opener Safety & Security
Shuttle Assembly
Chain Index
Fig. 6.1
WARNING! When operating the
manual release (while the door is
open) the door may fall rapidly due
to weak or broken springs, or due to
being improperly balanced.
Do not disengage the opener to
manual operation with children/
persons or any objects including
motor vehicles within the doorway.
6.2 Emergency Evacuations
In emergencies the garage door can be disengaged
from the opener, via the manual release cord and
the door opened manually. The manual release cord
should be a maximum of 1.8m from the ground. The
cord can be adjusted for special considerations.
6.3 Power Failure
When there is a power failure, the opener will be
unable to automatically open or close your garage
door. To use your door whilst there is no power you
will need to disengage the opener and use the door
manually – see 6.1 Manual Door Operation.
6.4 Re-Engaging the Opener
When the door has been disengaged from the
opener, the shuttle assembly, attached to the manual
release cord, can move up and down the chain.
Re-engage the opener (Fig 6.1) (preferably with
the door open to waist height) and then press the
programmed transmitter button, the motor will run
until the shuttle assembly engages the chain index
(Fig 6.2), you will hear it click into place. Then the
door will operate as normal.
CAUTION: When the opener is manually
disengaged, the door is no longer locked.
To lock the door manually, re-engage the
opener after the door is closed.
6.1 Manual Door Operation
To disengage the opener from the door (preferably
with the door in the closed position), pull down
on the string handle on an angle towards the door
(Fig 6.1). This will allow you to manually open or
close the door.
To re-engage the opener pull the string handle away
from the door - see 6.4 Re-Engaging the Opener.
6.5 Security - Inbuilt Locking Facility
DO NOT lock your door when your opener is
engaged as it has inbuilt locking facility. With the
opener engaged your door will be locked whether
the power is on or off.
CAUTION: Do not use the string handle
as a mechanism to open the door. Failure
to comply may cause serious injury.

9
GDO-9 DynamoTM GEN2 Home Owner’s Manual
7.4 Test the Battery Back Up (Optional
Accessory)
a. Press the transmitter to activate.
b. Whilst the door is in motion disconnect mains
power - the opener should continue to operate.
c. Press the transmitter to activate the door.
d. Whilst the door is in motion re-connect
power. The door should complete the cycle
as normal.
6. Opener Safety & Security
7. Safety Testing
7.1 Test the Close Cycle
a. Press the transmitter to open the door. (Fig 7.1)
b. Place a piece of timber approximately 40mm high on
the floor directly under the door (Fig 7.2).
c. Press the programmed transmitter to close door.
d. The door should strike the object and re-open.
7.2 Testing the Open Cycle
a. Press the transmitter to close the door (Fig. 7.1).
b. Press again to open the door.
c. When the door reaches approximately half way,
firmly grab the door’s bottom rail - the door should
stop.
If the door does not reverse readily when closing, or
stop when opening, put the door into manual and
contact your installer immediately for a door service.
CAUTION: Take care when
completing a safety test. Failure
to follow this warning can result
in serious personal injury and/or
property damage.
40mm
WARNING! If the door is closing
and is unable to re-open when
obstructed, discontinue use.
Do not use a door with faulty
obstruction sensing. Contact
your dealer for support.
Fig. 7.2
7.3 Test the Manual Door Operation
Periodically disengage the opener (Section 6.1)
and manually operate the door. The door must be
smooth to operate by hand. The force required on
the bottom rail should not exceed 15 kg.
Select the button on
the transmitter that has
been programmed to
operate the door.
If transmitter is not programmed,
Refer to Section 8 to program
transmitter.
Fig. 7.1
NOTE: Wait for the door to complete its travel
before proceeding to the next step.

GDO-9 DynamoTM GEN2 Home Owner’s Manual
10
8. Coding Transmitters
Press and hold
DOOR CODE
button
Select one of the
four buttons you
wish to use to
control the door
Press and hold
LIGHT CODE
button
Select one of the
four buttons (not
programmed yet ) you
wish to use to control
the courtesy light
Fig. 8.1
8.1 Storing the Transmitter Code
The opener can only operate from transmitters that
have been programmed into its receiver. The receiver
needs to learn the codes of any transmitter that will be
used with the operator. Up to sixty four (64) codes can
be stored in the receiver’s memory.
a. Ensure that the battery is inserted into the
transmitter, the button cover has been removed
(see Electrocution caution) and the opener is
turned on.
b. Press and hold the DOOR CODE button. The DOOR
CODE LED will illuminate and beep to indicate the
opener is in Code Learn mode. If a valid code is
not stored within 15 seconds the opener will exit
Code Learn (Fig. 8.1).
c. Press and hold the transmitter button that you want
to control the door for two (2) seconds, pause for
two (2) seconds, then press the same button again
for two (2) seconds and release.
d. Release the DOOR CODE button.
e. The transmitter is now coded to operate the
door - press the button to test.
8.2 Setting the Transmitter to Operate the
Courtesy Light
Although the courtesy light comes on with each
operation of the opener, it may also be controlled by a
transmitter without operating the door.
a. Press and hold the LIGHT CODE button. The LIGHT
CODE LED will illuminate and the courtesy light will
turnontoindicatethatthelightcodelearningisactive
(Fig. 8.2).
b. Choose a transmitter button not already coded
into the receiver. Press and hold this button for
two (2) seconds, pause for two (2) seconds, then
press the same button again for two (2) seconds
and release.
c. Release the LIGHT CODE button.
d. Press the transmitter button to test.
Fig. 8.2
ELECTROCUTION! The button
cover is the only cover that should
be removed. All other covers must
remain in place.
CAUTION: Be careful not to press
the operate button while removing
the button cover as the door will
start to move.

11
GDO-9 DynamoTM GEN2 Home Owner’s Manual
Press DOOR
CODE button
twice. Select one of the
four buttons (not
programmed yet )
you wish to use to
control the Vacation
Mode
8.3 Setting the Transmitter to Operate
Vacation Mode
The opener can be programmed into a “Vacation
Mode” where the opener will not respond to any
transmitter except one preprogrammed unit.
a. Briefly press the DOOR CODE button once, then
press it again and hold (will beep two times on
second press (Fig. 8.3).
b. Press one of the four (4) buttons on the transmitter
for two (2) seconds, pause for two (2) seconds,
then press the same button again for two (2)
seconds.
c. Release DOOR CODE button.
d. Press and hold the transmitter button for six (6)
seconds to set Vacation Mode. The door code
LED will stay lit while Vacation Mode is active.
e. To reset Vacation Mode, press the same transmitter
button for two seconds.
8.4 To Erase Programmed Codes
a. Select the transmitter you want to delete.
b. Press and hold the DOOR CODE BUTTON
(Fig. 8.4).
c. Press the transmitter button you would like to
delete for two seconds, pause for two seconds,
press again for two seconds and then release.
Release the DOOR CODE BUTTON. The code
should now be deleted. Confirm this by pressing the
transmitter button - the function (e.g. door opening)
should not respond.
8. Coding Transmitters
Fig. 8.3
Fig. 8.4
Button
Fig. 8.5
8.5 Installation of the Wall Mounted
Transmitter
a. Mount the transmitter in a convenient location,
yet out of reach of children and at least 1.5m off
the ground (Fig. 8.5).
b. Make sure the door is visible from this location.
c. To set the transmitter codes refer to 8.1.

GDO-9 DynamoTM GEN2 Home Owner’s Manual
12
9. Troubleshooting Guide
Symptom Possible cause Remedy
The opener does
not work from the
transmitter
Garage door in poor condition e.g.
springs may be broken
The opener does not have power
The battery in the transmitter is flat
The opener has been put into
“Vacation Mode”
The transmitter button is not
programmed to operate the door.
Door Code LED is flashing yet the
opener is not working.
Check the door’s operation - see
monthly maintenance (Section 10.1)
Plug a device of similar voltage
(e.g. a hairdryer) into the power
point and check that it is OK
Replace the battery (Section 10.6)
Turn off “Vacation Mode”
(Section 8.3, step e)
See coding transmitter procedure
(Section 8.1)
Ensure the correct button on the
transmitter is being pressed.
The chain moves but the
door remains stationary
The opener is disengaged Re-engage the opener
(Section 6.4)
Motor is running but
chain is not moving
Damage motor assembly Contact your dealer for support.
The transmitter range
varies or is restricted
Variations are normal depending
on conditions e.g. temperature or
external interference
The battery life is exhausted
Position of the transmitter in the
motor vehicle
See instructions for correct use of
transmitter (Section 4)
Refer to battery status (Fig 10.3)
Change the position (Section 4)
The Courtesy light does
not work
LED has failed Contact your dealer for support
The door reverses for no
apparent reason
This may occur occasionally from
environmental conditions such as
areas that are windy, dusty or have
extreme temperature changes.
If Safety beams are installed they
may be partially obstructed.
Put the door into manual (Section
6.1, take note of the CAUTION) and
contact your dealer.
Ensure the beam path is not
obstructed. If continues, contact
your dealer.
The door opens but will
not close
Safety Beam (Optional Accessory)
not operating correctly
Contact your dealer for support
The door stops or moves
very slowly under battery
(Optional Battery Back
Up Accessory)
The batteries may have little to no
charge
Connect mains power and leave the
batteries to charge. The batteries
may take 24 to 48 hours to reach
their maximum charge capacity.

13
GDO-9 DynamoTM GEN2 Home Owner’s Manual
9. Troubleshooting Guide
If You Need a Service Call
If the opener needs a service please call the dealer who installed the garage door opener (their contact details
are usually on a sticker on the back of your garage door). For product assistance contact 13 62 63 within Australia.
Symptom Possible cause Remedy
Courtesy Light flashes
and the opener beeps
5 times after each
operation
The opener has reached
the number of cycles
recommended before servicing.
See (Section 10.5) Contact your
dealer and arrange a door service.
Alternatively press SET button once
to reset the service counter.
The SERVICE LED has
started to flash and is
beeping numerous times
A Fault has been detected. The
fault will be active each time an
attempt is made to operate the
door.
Record opener function in (Fig 9.1)
then press the SET button once
to reset the opener. If the fault
continues to be tripped contact your
dealer for support.
The Open (Green) LED
and Close (Red) LED are
flashing alternatively
Opener is overloaded Discontinue use and Contact your
dealer for support.
The Open (Green) LED
continues to flash
Door obstructed when opening Clear away any obstructions and
test door opens correctly. (If door is
damaged, contact your dealer).
The Close (Red) LED
continues to flash
Door obstructed when closing
Limits may be cleared
Clear away any obstructions and
test door closes correctly. (If door is
damaged, contact your dealer).
Remove all power sources (including
the battery backup). Wait till all lights
are out (10-15 secs), then reconnect
power. If Red LED is flashing,
limits are not set. Contact dealer
immediately and discontinue use.
BEFORE CALLING you should have the following information to assist in providing the appropriate service:
1. Has anything happened since the opener last operated OK, e.g. a storm, a jolt to the door etc.?
2. What is the current light status on the opener?
3. Manually disengage the door (Section 6.1).
How easy is it to manually open and close the door?
4. What model is the opener? (Model no. information is located at the rear of the opener)
5. Who installed the opener? (Dealer details should be on a sticker on the back of your garage door)
6. When was it installed? (If known)
Date Time Number of Beeps
Fig. 9.1

GDO-9 DynamoTM GEN2 Home Owner’s Manual
14
10. Door Maintenance
10.1 Door Maintenance
Whilst your opener does not require any periodic
maintenance, the door that it is fitted to, does. Your
garage door is a large, heavy, moving object and
should be tested regularly to ensure it is in good
condition. A poorly maintained door could cause
fatal / serious injuries or damage to property.
•Frequently examine the door, particularly the
cables, springs and mountings for signs of wear,
damage or imbalance. DO NOT USE if repair
or adjustment is needed since a fault in the
installation or an incorrectly balanced door may
cause injury.
10.2 Lubrication (every 3 - 6 months)
To ensure a long and trouble free life for your door
the following is recommended:
•Guide Tracks: Clean the internal sections of
the guide tracks with a cloth dampened with
mineral turps or methylated spirits.
•Steel Hinges (if fitted): Sparingly lubricate with
an all-purpose machine oil. Also lubricate wheel
to axle bearings.
•Plastic Hinges: No lubrication is generally
required; however silicon spray may be used if
necessary.
•Springs: If accessible wipe over with an oily rag.
10.3 Door Service and Repair
If correct maintenance and servicing are not carried
out, warranty may be void. To keep your door
running well, it is recommended that your door
be serviced by an experienced technician, every
12 months or earlier if required:
•Lifting Cables (if fitted): Check for wear
through rubbing. If there is fraying or signs of
corrosion contact your dealer immeditately
and discontinue use, leaving door in the closed
position.
•Fasterners: Check all screws, nuts and bolts to
ensure they are secure.
•Spring Tension: It is natural for springs to lose
tension. Should the door become hard to
operate or completely inoperative, contact your
dealer.
DO NOT DO IT YOURSELF:
Door adjustments should only be
carried out by experienced persons,
as this function can be dangerous
if not performed under strict safety
procedures.
WARNING! Failure to maintain your
garage door may void the warranty
on your garage door opener.
DIY
ELECTROCUTION! Disconnect the
opener power cord from the mains
power before making any door
repairs / maintenance or removing
the opener button cover.

15
GDO-9 DynamoTM GEN2 Home Owner’s Manual
10.4 Opener Maintenance
To ensure a long and trouble free life for your opener
the following is recommended:
•Monthy: Run the Safety Testing procedures in
Section 7 to ensure garage door is fit for use.
NOTE: If the door does not operate smoothly, call
your nearest Approved Dealer.
10.5 Service Indicator
While the door opener does not require regular
servicing, to function correctly the door must be
in good operating condition. As a reminder the
DynamoTM has a built in maintenance counter. This
counter has a factory default of 3000 cycles, which is
the recommended service interval.
When this counter expires the yellow SERVICE LED
will light up and opener beep three times at the start
of each cycle (Fig. 10.1). In addition the courtesy
light will flash and opener beep five times at the end
of open cycle (when the door is fully open).
These warning signals will self extinguish after 30
cycles. When this service counter is triggered it is
strongly recommended you contact your garage
door dealer to arrange a door service. See Section
13 for Recommended Service Schedule.
However, if you choose not to have your door
serviced the counter can be reset simply by pressing
the LIMIT SET button.
10.6 Removing the Battery From the
Transmitter
(Battery Type: 3V Lithium Battery CR2032).
Use a non-metallic object (e.g. pen) to remove the
battery. (Fig. 10.2). To test the battery is working,
press and hold a transmitter button; (Fig. 10.3).
Light Status Battery Status
Solid OK
Flashing Requires replacement
No light Requires replacement
REPLACE BATTERY WITH CR2032 ONLY
10. Opener Maintenance
Fig. 10.2
BEEP
Fig. 10.1
Fig. 10.3
Use finger nails
to lift both tabs
and release
battery

GDO-9 DynamoTM GEN2 Home Owner’s Manual
16
Product: GDO-9 DynamoTM GEN2
Purchased from:______________________________Purchaser:___________________________________
(described as “you” below)
Address:_____________________________________Installed by:__________________________________
Installed on (date):____________________________Invoice No:__________________________________
This Warranty is given by Automatic Technology (Australia) Pty Ltd (ABN 11 007 125 368) (ATA), 6-8 Fiveways Boulevard,
Keysborough, VIC, 3173, 1300 133 944, [e-mail]
2. The Competition and Consumer Act 2010 (including the Australian Consumer Law) and other relevant statutes provide
a set of statutory consumer guarantees and other legal rights that cannot be excluded, restricted or modified by
contract. This Warranty is in addition to and does not affect any of your rights under the Australian Consumer Law and
other relevant statutes.
3. Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a
replacement or refund for a major failure and for compensation of any other reasonably foreseeable loss or damage.
You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure
does not amount to a major failure.
4. Subject to your non-excludable rights under the Australian Consumer Law, ATA expressly excludes any liability for
consequential loss, incidental or indirect damages (including but not limited to damages for loss of business profits,
business interruption and loss of business information) due to a defect of the GDO-9 Dynamo™Gen 2 (Product).
In particular any loss or damage caused to other equipment or accessories used with the product or any loss resulting
from a delay in repair is excluded to extent permitted by law.
5. Subject to all of the matters set out below, ATA warrants in relation to the Product that:
(a) the Product’s drive units will be free of any defects in material and workmanship for at least 24 months after the date of
purchase (as evidenced by the sales docket receipt), or 5000 cycles, which ever occurs first; and
(b) the Product’s other components and accessories will be free of any defects in material and workmanship for at least 12
months after the date of purchase (as evidenced by the sales docket receipt).
6. No additional warranty will apply for Products repaired during the relevant warranty period.
7. For all Products repaired outside the warranty period, a six (6) month warranty that the Product will be free of any
defects in material and workmanship will apply from the date of dispatch of the Product to you. ATA may charge you
for any repairs undertaken outside the warranty period, and will provide you with a quotation in relation to any such
costs for your approval before proceeding with any repairs.
8. This Warranty applies only where you:
(a) immediately notify ATA at the contact details provided in paragraph 1 above or notify the or the retailer that you
purchased the Product from of the alleged defect;
(b) return the product to the retailer that you purchased the Product from; and
(c) present the relevant sales docket and this Warranty document to the retailer to confirm the date of purchase.
9. Except for this Warranty, ATA gives no warranties of any kind whatsoever (whether express or implied), in relation to
the product, and, subject to paragraph 1 above, all warranties of whatsoever kind relating to the product are hereby
excluded.
11. Warranty

17
GDO-9 DynamoTM GEN2 Home Owner’s Manual
10.This Warranty excludes damage resulting from:
(a) normal wear and tear;
(b) accidental damage;
(c) incorrect installation of the Product;
(d) blown fuses, electrical surges, power surges or power spikes;
(e) theft, fire, flood, rain, water, lightning, storms or any other acts of God;
(f) any installation, configuration or use of the Product contrary to the instructions supplied with the Product;
(g) maximum continuous operating time exceeding 1 minute in 10;
(h) the operating force exceeding 15kg* (150 Newton) when moving the door manually to the open or closed position;
(i) the door surface area exceeding 16.5m2 for GDO-9 Dynamo™Gen 2 ;
(j) the door used with the Product not being in safe working order and condition;
(k) repairs which are not authorised by ATA;
(l) any failure to install or maintain the Product in accordance with the instructions supplied with the Product;
(m)any use which is not in accordance with the instructions provided with the Product;
(n) deliberate or negligent damage to the Product;
(o) any unauthorised modification to the Product;
(p) faulty or unsuitable wiring in the building in which the Product is installed;
(q) damage caused by insects;
(r) any cost or expense relating to the recall of the Product;
(s) installation of a residential garage door opener in a commercial or industrial premises or in a dwelling other than a
single-family dwelling;
(t) radio or electrical interference; or
(u) acts or omissions of any person (including service providers approved by ATA) other than ATA.
11.ATA’s liability under this Warranty is limited, at ATA’s absolute option, to replacing or repairing the product which ATA,
in its unfettered opinion, considers to be defective either in material and/or workmanship or to credit the dealer with
the price at which the product was purchased by the dealer.
12.This Warranty does not extend to cover labour for installation of the Product following repairs, the cost of which must
be borne by you.
13.This Warranty is limited to Return-to-Base (RTB) repair and does not cover labour for on-site attendance, the cost of
which must be borne by you.
14.Except as specified in this Warranty, ATA will not charge you for any repairs or replacements conducted under the
Warranty. However, ATA will charge you for any repairs which are not within the scope of this Warranty (or which are not
required to be undertaken free of charge pursuant to the Australian Consumer Law).
15.This Warranty is void if the Product is not returned to the manufacturer in original or suitably secure packaging.
16.This Warranty is only applicable for repairs to the product carried out within Australia.
17.This Warranty does not cover consumable items including, without limitation, globes, batteries and fuses.
18.This Warranty is not transferable.
19.Where the Product is retailed by any person other than ATA, except for the warranty set out above, such person has no
authority from ATA to give any warranty or guarantee on ATA’s behalf in addition to the warranty set out above.
20.Any provision of this Warranty that is prohibited or unenforceable in any jurisdiction is ineffective as to that jurisdiction
to the extent of the prohibition or unenforceability. That does not invalidate the remaining provisions of this Warranty
nor affect the validity or enforceability of that provision in any other jurisdiction.
21.Products presented for repair may be replaced by refurbished goods of the same type rather than being repaired.
Refurbished parts may be used to repair the Product.
NOTES:
1. One (1) cycle = one (1) open and one (1) close action of the door.
2. This Warranty is to be read in conjunction with the owner’s copy of the installation instruction manual.
3. * The door that the Product is used with should be balanced in such a way that the user is able to open or close the
door manually using a force not greater than 150 Newton (15 kg), other than to initially cause the door to start moving,
which may require force in excess of that specified in this paragraph.
11. Warranty

GDO-9 DynamoTM GEN2 Home Owner’s Manual
18
•Safety Beams - Provides additional protection if the door is closing
onto your property or person. Simply breaking the beam “stops” the
door! Auto-Close is only possible when Safety Beams are installed.
When the Auto-close option is selected the garage door opener will
attempt to close the door automatically 30 seconds after opening.
•Keyring Transmitter - Ideal for personal use when entry into the
house may be via the garage.
•Wall Button Transmitter - Allows you to operate the opener within
10 metres of the door. Ideal for mounting inside the house.
•Wireless Keypad - The entry keypad allows entry to the garage
without using a transmitter.
•Battery Back-up - The opener has a provision for a Battery Back Up
kit that allows continued operation of the door in the absence of mains
power.
•External Antenna - For sites where radio range may be reduced.
12. Optional Accessories
There are a range of additional accessories for your added convenience and security. Contact your
dealer for installation of these accessory items.

19
GDO-9 DynamoTM GEN2 Home Owner’s Manual
13. Service Schedule
Year /
Approx. Cycles
Date Details
1 / 3,000
2 / 6,000
3 / 9,000
4 / 12,000
5 / 15,000
Automatic Technology (Australia) Pty Ltd
Phone: [phone]
Website: www.automatictechnology.com.au

Is your opener beeping
and flashing?
It may be time for a service
(for more details see section 10.5)
For a service contact your dealer using
the details below...
Dealer:
