Automatic Technology GDO-4 EasyRoller User manual

AUTOMATIC TECHNOLOGY AUSTRALIA PTY LTD
GDO-4 EasyRoller®
ROLL UP GARAGE DOOR OPENER
OWNERS COPY Warning: It is vital for the safety of persons to
follow all instructions. Failure to comply with the
installation instructions and the safety warnings
may result in serious personal injury and/or
property and remote control opener damage.
Please save these instructions for future reference.
Installation Instructions
FFeeaattuurriinngg
SecuraCode®
Code Hopping
Technology
FFeeaattuurriinngg
SecuraCode®
Code Hopping
Technology

IMPORTANT SAFETY INSTRUCTIONS
Automatic Technology Australia Pty Ltd to the extent that such may be lawfully excluded hereby expressly disclaims all conditions or warranties, statutory
or otherwise which may be implied by laws as conditions or warranties of purchase of an Automatic Technology Australia Pty Ltd Roll Up Garage Door
Opener. Automatic Technology Australia Pty Ltd hereby further expressly excludes all or any liability for any injury, damage, cost, expense or claim
whatsoever suffered by any person as a result whether directly or indirectly from failure to install the Automatic Technology Australia Roll Up Garage Door
Opener in accordance with these installation instructions.
2
For ADDITIONAL SAFETY protection we
STRONGLY recommend the fitting of a Photo Electric
Beam. In most countries Photo Electric Beams are
mandatory on all garage doors fitted with automatic
openers. For a small additional outlay ATA recommends
that Photo Electric Beams be installed with the
automatic opener ensuring additional safety and peace
of mind.
DO NOT operate the garage door opener unless the
garage door is in full view and free from objects such as
cars and children/persons. SERIOUS PERSONAL
INJURY and/or property damage can result from failure
to follow this warning.
DO NOT operate the garage door opener when
children/persons are near the door. Children must be
supervised near the garage door at all times when the
door opener is in use. SERIOUS PERSONAL
INJURY and/or property damage can result from failure
to follow this warning.
DO NOT allow children to operate the garage door
opener. SERIOUS PERSONAL INJURY and/or
property damage can result from failure to follow this
warning.
Regularly check to make sure that the SAFETY
OBSTRUCTION FORCE is working correctly, and is
TESTED (by placing a 40mm high object on the floor)
and set as per the installation instruction manual. Failure
to follow the manual may result in SERIOUS
PERSONAL INJURY and/or property damage. This
test must be repeated at regular intervals and the
necessary adjustments made as required.
DO NOT disengage the door opener to manual
operation with children/persons or any other objects
including motor vehicles within the doorway.
Install the wall switch or wall mounted transmitter in a
LOCATION/POSITION where it is out of reach of
children and the garage door is visible.
The door opener is not intended for use by young
children or infirm persons without adequate supervision.
Young children should be supervised to ensure that they
do not play with the equipment.
Keep hands and loose clothing CLEAR of the garage
door and opener at all times.
Warning - It is vital for the safety of persons to follow all instructions. Failure to comply
with the following Safety Rules may result in serious personal injury and/or property damage.
The unit should be installed so that it is protected from
the elements. It should not be exposed to water or rain.
It is not to be immersed in water or sprayed directly by
a hose or other water carrying device.
The garage door must be WELL BALANCED.
Sticking or binding doors must be repaired by a
qualified garage door installer prior to installation of the
opener .
Frequently examine the installation, in particular
cables, springs and mountings. DO NOT attempt to
repair the door yourself as hardware is under extreme
tension and can cause SERIOUS PERSONAL
INJURY and/or property damage.
REMOVE OR DISENGAGE all garage doors locks
and mechanisms prior to installation of the opener.
Connect the garage door opener to a properly
EARTHED general purpose 240V mains power outlet
installed by a qualified electrical contractor.
DISCONNECT THE POWER CORD from mains
power before making any repairs or removing covers.
Only EXPERIENCED service personnel should
remove covers from the garage door opener.
When using auto close mode, a PHOTO ELECTRIC
BEAM must be fitted correctly and tested for operation
at regular intervals. EXTREME CAUTION is
recommended when using auto close mode. ALL
SAFETY RULES must be followed.
In order for the garage door opener to SENSE an object
obstructing the door way, some FORCE must be
exerted on the object. As a result the object, door and/or
person may suffer DAMAGE or INJURY.
If the power supply cord is damaged, it MUST be
replaced by an ATA service agent or suitably qualified
person.
Make sure that the door is fully open before driving in
or out of the garage.
Make sure the door is fully closed before leaving the
driveway.

3
FEATURES
Your EasyRoller®Automatic Garage
Door Opener has many features which
you will appreciate. The components
and materials used in this Automatic
Opener are of the latest technology and
highest quality. Listed below are some
of the many features.
OPERATION
To open or close the door simply press
the hand held transmitter, the wall
mounted transmitter, or optional wall
switch for two seconds. During an open
cycle the door can be stopped by
pressing the button while the door is in
motion. If it is interrupted during a close
cycle the door will pause briefly then
return to the fully open position. The
next actuation will move the door in the
opposite direction.
HOPPING CODE
Every time a transmission is made from
the remote transmitter a new security
code is generated at random. The
number of possible code combinations
is over 4.29 billion. This greatly
enhances the security of the system
making code “grabbing” a thing of the
past.
ISS (INTELLIGENT SAFETY
OBSTRUCTION SYSTEM)
The door will automatically reverse
should it encounter an obstacle or be
restricted in some manner while
performing a close cycle. The amount
of force the door should sense before
reversing is automatically adjusted by
the door’s control system during the
initial installation of the automatic door
opener. The door will also stop if
restricted whilst opening. The Safety
Obstruction Force should be checked at
least once a month.
SECURITY CODE STORE
The EasyRoller Garage Door Opener
uses state of the art technology in
storing your selected transmitter
security code. Up to 27 different
transmitters can be stored in the openers
memory.
To store any code simply press and hold
the Door Code button on the opener and
press the transmitter button twice. Each
or all codes can be deleted and changed
at any time. The codes can also be
stored via the transmitter from a remote
location.
OVER LOAD INDICATOR
When the maximum opening and
closing capacity of the opener is
exceeded the courtesy light will flash
ten times to indicate that an overload
has occurred.
SERVICE INDICATOR
The opener features a service indicator.
When the Overload LED flashes and
the beeper sounds at the start of a door
cycle, this means that the opener and/or
garage door requires service.
AUTO COURTESY LIGHT
The courtesy light on the opener comes
on automatically whenever the door is
activated. The light can also be
switched on and off without operating
the door. This is done by pressing the
button on any hand held or wall
mounted transmitter which has been
stored with the light code. The light will
stay on for approximately three minutes
then switch off. This time is also
adjustable.
CAS (COLOUR ASSISTED
SETTINGS)
To make the installation of the opener
more user friendly Automatic
Technology Australia has developed the
CAS (Colour Assisted Settings) system.
This unique colour coded system (red
for close, green for open) allows for all
the adjustments and settings to be
easier and simpler for the user or
installer to complete the installation
OPEN AND CLOSE DRIVE
BUTTONS
Developed by ATA to aid the
installation of the opener is the Open
and Close Drive Buttons. These buttons
are used to help set the open and close
limit positions. A quicker setting time
and a more precise limit position can be
achieved by using this system.
INITIALISATION
The Reset button on the opener is used
to initialise or re-initialise the
obstruction force settings and door
travel counters. See installation manual
for instructions.
AUTO CLOSE MODE
The opener can be programmed to
automatically close after an open cycle.
The auto close time is adjustable. It is
compulsory to install a Photo Electric
Beam if this mode is selected, otherwise
the door may cause personal injury or
damage to property.
SAFETY AUTO RUN TIME
If the opener does not complete its cycle
within thirty seconds it will
automatically stop if opening, or
reverse to the fully open position if
closing.
PHOTO ELECTRIC BEAM
(OPTIONAL)
The opener has an input for a photo
electric beam to be connected for extra
safety protection and use of the auto
close mode.
MANUAL OPERATION
The opener is equipped with a unique
patented manual disengaging device. If
the power to the opener is disrupted for
any reason the door can be put into
manual mode by pulling down on the
string handle, then releasing. This will
allow you to manually open or close the
door. When power is restored, by
pulling down on the string handle and
releasing, the opener is put back into
automatic mode.

4
OPERATING CONTROLS
1. LIGHT CODE button (White) is
used for storing or erasing the
transmitter button (code) you wish to
use to turn the opener’s courtesy light
on and off.
2. DOOR CODE button (Blue) is
used for storing or erasing the
transmitter button (code) you wish to
use to command the door to open, stop
or close.
3. CLOSE DRIVE button (Red) is
used during installation to help set the
close limit stop position. Pressing this
button will move the door in the close
direction. Movement stops when the
button is released.
NOTE: The close safety obstruction
detection is disabled when the Close
Drive button is used to move the door.
4. CLOSE LIMIT LED (Red) the
LED is very helpful during installation,
it illuminates and flashes while the door
is closing and remains steady on when
the close limit is reached.
5. AUTO CLOSE TIME button
(White) is used to adjust the auto close
time. While holding Auto Close and
pressing the Open button the time delay
is increased (each press will increase
the time by 5 seconds). Pressing the
Close button will decrease the time
delay.
6. RESET button is used to initialise
and set the door/opener operating
parameters, including cycle times and
obstruction force settings.
7. O/S/C button (Yellow) is used
during installation to test the Open, Stop
and Close cycles for the Opener. The
opener has to be initialised by the Reset
button before the O/S/C button becomes
operable.
8. CLOSE LIMIT ADJUST
SCREW (Red) is used to fine adjust the
close limit stop position.
9. OPEN LIMIT ADJUST SCREW
(Green) is used to fine adjust the open
limit stop position.
10. OPEN LIMIT CAM (Green) is
used to set the open limit stop position.
11. OPEN Drive button (Green) is
used during installation to help set the
open limit stop position. Pressing this
button will move the door in the open
direction. Movement stops when the
button is released.
NOTE: The open safety obstruction
detection is disabled when the Open
Drive button is used to move the door.
12. OPEN LIMIT LED (Green) the
LED is very helpful during installation,
it illuminates and flashes while the door
is opening and remains steady on when
the open limit is reached.
13. CLOSE LIMIT CAM (Red) is
used to set the close limit stop position.
14. FORCE MARGIN SET button
(White) is used to change the force
pressure when the door encounters an
obstruction. Pressing the Force Margin
Set button and Open or Close button
will increase or decrease the force.
Normally the force pressure is set
automatically. Force Margin Set is
only used if other environmental factors
(wind, etc.) effect the operation of the
Door/Opener.
15. P.E. INPUT is for connection of
Photo Electric Beams (optional extra)
for extra safety obstruction protection,
or compulsory when used with Auto
Close mode.
NOTE: P.E. SHUNT must not be
removed otherwise the opener will not
function correctly. Remove only when a
P.E. Beam is to be connected.
16. EXTERNAL RECEIVER
INPUT is the input where an external
receiver can be connected (optional
extra). It can supply 30mA @ 24 volts
DC maximum to power an external
receiver.
17. O/S/C INPUT is for connecting
the wired Wall Switch (optional extra) .
18. P. E. SHUNT The shunt has to be
removed when connecting a Photo
Electric Beam.
19. ENGAGE/DISENGAGEMENT
HANDLE when pulled down and
released will select manual mode on the
opener when there is a power failure.
Pulling down and releasing again will
switch the opener to automatic mode.
20. EASY ACCESS
TRANSMITTER The “manual release”
engage/disengagement handle has with-
in its housing a wireless transmitter. If
the button is pressed it will open, stop or
close the garage door.

OPERATING CONTROLS
5
1) LIGHT CODE BUTTON (WHITE)
2) DOOR CODE BUTTON (BLUE)
3) CLOSE DRIVE BUTTON (RED)
4) CLOSE LIMIT LED (RED)
5) AUTO CLOSE BUTTON (WHITE)
6) RESET BUTTON
7) O/S/C BUTTON (YELLOW)
8) CLOSE LIMIT ADJUST SCREW (RED)
9) OPEN LIMIT ADJUST SCREW (GREEN)
10) OPEN LIMIT CAM (GREEN)
11) OPEN DRIVE BUTTON (GREEN)
12) OPEN LIMIT (RED)
13) CLOSE LIMIT CAM (RED)
14) FORCE MARGIN SET BUTTON
15) P.E. INPUT
16) EXTERNAL RECEIVER INPUT
17) O/S/C INPUT
18) P.E SHUNT
19) ENGAGE / DISENGAGE HANDLE
20) EASY ACCESS TRANSMITTER

PACKAGE CONTENTS
6
ITEM QUANTITY
GDO-4 EASYROLLER DRIVE UNIT 1
EASY ACCESS TRANSMITTER EAT-1 (NOT INCLUDED IN SOME MODELS) 1
KEY RING TRANSMITTER PTX-4 2
PTX-4 WALL MOUNT BRACKET 1
ALKALINE BATTERY A23 12V 2
WEIGHT BARS (NOT INCLUDED IN SOME MODELS) 2
SCREW M5x40mm (NOT INCLUDED IN SOME MODELS) 4
HEX NUT M5 (NOT INCLUDED IN SOME MODELS) 4
SPRING WASHER I.D 5 (NOT INCLUDED IN SOME MODELS) 4
SCREW #6x1” 2
PLASTIC WALL PLUGS 2
INSTALLATION MANUAL 1

BEFORE INSTALLATION
7
IMPORTANT SAFETY INSTRUCTIONS FOR
INSTALLATION
Warning: Incorrect installation can lead to severe injury.
Follow ALL installation instructions.
SIDE ROOM REQUIREMENTS
Fig. 1 shows the minimum side room that is required. The
distance between the edge of the door curtain and the inside of
the bracket is 85mm minimum, and the distance between the
edge of the door curtain and the outside of the bracket is
135mm minimum.
Fig. 2 shows the recommended side room. The distance
between the edge of the door curtain and the inside of the
bracket should be 110mm , and the distance between the edge
of the door curtain and the outside of the bracket is 160mm.
1. CHECK OPERATION OF DOOR
BEFORE BEGINNING THE INSTALLATION OF THE
EASYROLLER®AUTOMATIC OPENER CHECK THE
OPERATION OF THE DOOR.
The door must be well balanced and be in a reasonable
operating condition. You should be able to lift the door
smoothly and with little resistance. It should stay open around
900mm to 1200mm above the floor. The door should not stick
or bind in the guide tracks. The ideal operational effort in
raising or lowering the door should not exceed a force of 10kg
(22 lbs.). Make sure that all door locks are either removed, or
disabled and remove unnecessary accessories.
2. FIXING OF DOOR WEIGHT BARS
Move the door manually to the mid open position. Place the
weight bars equally apart on the bottom rail of the door and
secure them with the fasteners provided (Fig. 3). Check the
operation of the door again. If the door feels heavy it may
require extra tension to be added to the door springs. Refer to
the door Installation manual from the manufacturer on how to
tension the door.
3. LEFT OR RIGHT HAND INSTALLATION
The EasyRoller Automatic Opener can be installed on the left
or right hand side of the door (when looking out from the inside
of the garage). If your opener is to be installed on the RIGHT
HAND side of the door then no change needs to be made as the
opener is factory set for RIGHT HAND installation. If LEFT
HAND side installation is required the next step is to move the
motor wire connector on the control board. The connector plug
has to be removed and reconnected to the LEFT side of the
connector (Fig. 4). If you have made an error in selection and
wish to install to the RIGHT HAND side of the door, then
reconnect the connector plug to the RIGHT side of the
connector (Fig. 5).
FIG. 3
FIG. 2
FIG. 1MINIMUM SIDE ROOM
RECOMMENDED SIDE ROOM
FIG. 4
FIG. 5
Connect the middle and left
hand side pins for left
hand side installation.
Connect the middle and
right hand side pins for
right hand side installation.
WEIGHT BARS

EASY ACCESS TRANSMITTER
8
PRESS BUTTON
ROTATE
FIG. 6
FIG. 7
FIG. 8
THE EASY ACCESS TRANSMITTER
(Not available on some models)
The Easy Access Transmitter is prepared ready for use with the
battery pre-installed. Before the transmitter can be operational,
the Transmitter Code has to be stored into the openers memory.
To store the code please follow the instructions in Step 8.1 on
page 14.
REMOVING THE COVER TO REPLACE BATTERY
1. Rotate the cover Clockwise to 'OPEN'
2. Rotate the cover Anti-clockwise to 'CLOSE'
REMOVING THE BATTERY
(Battery Type: 3V Lithium Battery CR1220).
Use a non-metallic object (e.g Pen) to remove the battery.
(see Fig. 8)
WARNING
Metallic objects used to remove the battery may DAMAGE the
the circuit board or the battery.
REPLACING THE BATTERY
Place one side of the battery into the battery holder (Fig. 9),
then press the battery down firmly until it clicks into a flat
position.
Note: The length of the manual release cord is user adjustable
simply by sliding the plastic toggle along the cord to achieve
the desired length.
FIG. 9

MOUNTING THE OPENER
9
4. FIXING DRIVE UNIT TO THE DOOR
The EasyRoller Drive Assembly can be fixed to the roll up
garage door in a variety of ways. Described below is one
method of fixing. Make sure there is enough side room (135mm
from the end of the door shaft to the wall) to slide the drive unit
onto the shaft.
PLEASE NOTE: THE INSTRUCTIONS FOR FIXING THE
DRIVE ASSEMBLY TO THE DOOR IS FOR RIGHT HAND
INSTALLATION.
FITTING DRIVE UNIT TO DOOR
(Fig. 10, Fig. 11 and Fig. 12).
1. Check that the door shaft U bolt is securely tightened on the
left hand side of the door.
2. Raise the door and tie a rope around the centre to secure the
roll.
3. Support the right hand end of the door with a suitable prop,
e.g. step ladder and soft padding to protect the door surface.
WARNING: DO NOT ALLOW CHILDREN/PERSONS
AROUND THE DOOR AND PROP. SERIOUS PERSONAL
INJURY AND/OR PROPERTY DAMAGE CAN RESULT
FROM FAILURE TO FOLLOW THIS WARNING.
4. Check that Steps 2 and 3 was completed. Carefully loosen
and remove the right hand door shaft U bolt.
5. Make sure that the door supporting prop is secure. While the
door is supported remove the right hand door mounting
bracket from wall.
6. Remove the drive unit from the packaging. Try to rotate the
drive gear by pushing on the fork. If the gear does not rotate
manual mode has to be selected. To select pull down on the
string handle, then release slowly. The drive gear should now
rotate freely.
7. Slide the drive unit over the door axle making sure that the
fork extends into and over one of the spokes of the door drum
wheel.
8. Refit the door mounting bracket to the wall. In some cases
the bracket may have to be re-positioned. Re-tighten the door
shaft U bolt. Remove door supporting prop and untie the rope
from the curtain.
9. Straighten the drive unit and position as per Fig. 12. Tighten
the two locking bolts firmly to secure the drive unit.
10. Check the manual operation of the door by raising and
lowering the door. The door should run smoothly and not catch
on any part of the drive unit.
11. Adjust the length of the manual release cord so that it can
be easily reached by an adult of average height (ie. less than
1.8m tall).
FIG. 10
FIG. 11
FIG. 12
CHECK IF “U”
BOLT IS TIGHT
REMOVE “U” BOLT
REMOVE BRACKET
ROPE
SUPPORT PROP
PULL MANUAL RELEASE
HANDLE IF GEAR DOES
NOT TURN FREELY.
TIGHTEN “U” BOLT
REFIT WALL BRACKET
UNTIE ROPE
REMOVE PROP
TIGHTEN LOCKING BOLTS

SETTING LIMITS
10
5. FIXING OF DOOR CURTAIN TO DRUM
WHEEL
The door curtain has to be secured to the drum wheel with
suitable fasteners.
1. With the door in the fully closed position, mark the curtain
(Fig. 13) on both ends of the door.
2. Open door slightly to have access to the marked positions.
Secure the curtain to drum wheel using self drilling screws (two
on each end). The screws should be at least 90 degrees apart
(Fig. 13).
6. SETTING DOOR TRAVEL LIMIT
POSITIONS
IMPORTANT NOTE: The O/S/C button will not function
until the open and close limits positions are set and Step 7.1
is completed.
The Limit Cams, Limit Fine Adjustment Screws and Door Inch
Open and Close buttons are colour coded to make the setting of
the limits as user friendly as possible.
The GREEN colours for OPEN LIMIT SETTING.
The RED colours for CLOSE LIMIT SETTING.
6.1 SETTING LIMITS FOR RIGHT HAND
INSTALLATION
1. With the drive unit in manual mode (Fig. 14) move the door
up by hand to the desired open position.
2. Remove the light diffuser (Fig. 14). Rotate the green limit
cam by hand in an anticlockwise direction (Fig. 15) until the
cam clicks the open limit switch.
3. Move the door down by hand to the desired closed position.
4. Rotate the red limit cam by hand in a clockwise direction
(Fig. 16) until the cam clicks the close limit switch.
5. Connect the power lead from the drive unit into, a general
purpose power outlet installed by a licensed electrical
contractor. Make sure that the power lead is safely fastened
away from any moving parts.Turn the power on.
6. Re-engage the drive gear by pulling down on the string and
then releasing slowly (Fig. 14).
OPEN LIMIT ADJUSTMENT
Press and hold the green Open button (Fig. 15) The door should
start opening. Release the green Open button when the door
reaches the desired open position. If the green LED (Fig. 15) is
illuminated and the desired limit position has been reached then
the limit adjustment is complete. If the green LED is
illuminated but you are not happy with the door’s open
position, the green Fine Adjustment Screw (Fig. 15) can be
adjusted to fine tune the open position. Turn the screw anti-
clockwise to open the door more. To open the door less turn the
screw clockwise. Each complete revolution of the adjustment
screw is equal to approximately 10mm of door travel.
FIG. 13
FIG. 14
FIG. 15
PRESS HERE
(BOTH SIDES)
AND PULL DOWN
TO REMOVE THE
LIGHT DIFFUSER
PULL MANUAL
RELEASE HANDLE
DOWN TO
DISENGAGE OR
RE-ENGAGE
DRUM WHEEL
90°

SETTING LIMITS
11
NOTE: If the door has not reached the desired limit position by
more then 30mm, then it is recommended that the green limits
cam be adjusted again before the green fine adjustment screw is
adjusted.
CLOSE LIMIT ADJUSTMENT
Press in and hold the red Close button. (Fig. 16). The door
should start closing. Release the red Close button when the
door reaches the desired closed position. If the red LED
(Fig. 16) is illuminated and the desired limit position has been
reached then the limit adjustment is complete. If the red LED is
illuminated but you are not happy with the door close position,
the red Fine Adjustment Screw (Fig. 16) can be adjusted to fine
tune the close position. Adjust the screw anticlockwise to close
the door less. To close the door more adjust the red Fine
Adjustment Screw clockwise. Each complete revolution of the
adjustment screw is equal to approximately 10 mm of door
travel.
NOTE: If the door has not reached the desired limit position
by more then 30mm, then it is recommended that the red
limits cam be adjusted again before the red fine adjustment
screw is turned.
6.2 SETTING LIMITS FOR LEFT HAND
INSTALLATION
1. With the drive unit in manual mode (Fig. 17) move the door
up by hand to the desired open position.
2. Remove the light diffuser (Fig. 17). Rotate the green limit
cam by hand in a clockwise direction (Fig. 18) until the cam
clicks the open limit switch.
3. Move the door down by hand to the desired closed position.
4. Rotate the red limit cam by hand in an anticlockwise
direction (Fig. 19) until the cam clicks the close limit switch.
5. Connect the power lead from the drive unit into, a general
purpose power outlet installed by a licensed qualified
electrical contractor. Make sure that the power lead is safely
fastened away from any moving parts. Turn the power on.
6. Re-engage the drive gear by pulling down on the string
and then releasing slowly (Fig. 17).
FIG. 16
FIG. 17
PRESS HERE
(BOTH SIDES)
AND PULL DOWN
TO REMOVE THE
LIGHT DIFFUSER
PULL MANUAL
RELEASE HANDLE
DOWN TO
DISENGAGE OR
RE-ENGAGE

SETTING LIMITS
12
OPEN LIMIT ADJUSTMENT
Press and hold the green Open button (Fig. 18). The door
should start opening. Release the Open button when the door
reaches the desired open limit stop position. If the green LED
(Fig. 18) is illuminated and the desired limit stop position has
been reached then the limit adjustment is complete. If the green
LED is illuminated but you are not happy with the door open
position, the green Fine Adjustment Screw (Fig. 18) can be
adjusted to fine tune the open position. To open the door more,
turn the Green Fine Adjustment Screw clockwise. To open the
door less turn the Green Fine Adjustment screw anticlockwise.
Each complete revolution of the adjustment screw is equal to
approximately 10mm of door travel.
NOTE: If the door has not reached the desired limit position
by more then 30mm, it is recommended that the green limit cam
be adjusted again before the green fine adjustment screw is
turned.
CLOSE LIMIT ADJUSTMENT
Press and hold the red Close button (Fig. 19). The door should
start closing. Release the Close button when the door reaches
the desired closed limit stop position. If the red LED (Fig. 19)
is illuminated and the desired limit position has been reached
then the limit adjustment is complete. If the red LED is
illuminated but you are not happy with the door close position,
the red Fine Adjustment Screw (Fig. 19) can be adjusted to fine
tune the close position. Turn the screw clockwise to close the
door less. To close the door more turn the screw anticlockwise.
Each complete revolution of the adjustment screw is equal to
approximately 10mm of door travel.
NOTE: If the door has not reached the desired limit position
by more then 30mm, then it is recommended that the red limit
cam be adjusted again before the red fine adjustment screw is
turned.
FIG. 18
FIG. 19

SETTING SAFETY OBSTRUCTION FORCE
13
7. SETTING OPEN AND CLOSE SAFETY
OBSTRUCTION FORCE
The Safety Obstruction Force is calculated automatically and
set in memory on the EasyRoller. This applies to both the Open
Force and Close Force.
Warning: When step 7.1 is initiated the garage door will do a
full open and close cycle automatically. Please keep doorway
clear to avoid any personal injury or damage to property.
7.1 TO INITIALISE OBSTRUCTION FORCE
1. Press and hold the Close button (Fig. 20) to move the door
to the fully closed position. Check that the red LED is steady
ON, to confirm the door is set on the closed limit position
2. Press the Reset button (Fig. 20) for two seconds, the door
should start opening. When the door reaches the fully open
position it will pause momentarily then start to close. The door
has to do a complete open and close cycle without
interruptions for the safety obstruction parameters to be
calculated and set automatically.
A default safety force margin is preset in the factory. Under
normal operating conditions this default margin should not be
changed. If you are not satisfied with this setting you can adjust
it as per the procedure below.
IMPORTANT NOTE:
Whenever the limit switches or cams are adjusted the safety
obstruction force has to be re-initialised because the door’s
travel distance may have changed. To re-initialise the door
follow STEP 7.1 above.
7.2 TO INCREASE FORCE PRESSURE
1. Press and hold the Force Margin Set button (Fig. 20).
2. While holding Force Margin Set press the green Open
button. The green LED will illuminate each time the green open
button is pressed to indicate that the force pressure is being
increased. If the green LED flashes continuously when the open
button is pressed, this indicates that the maximum force
pressure setting has been reached.
7.3 TO DECREASE FORCE PRESSURE
1. Press and hold the Force Margin Set button (Fig. 20).
2. While holding down button press the red Close button. The
red LED will illuminate each time the Close button is pressed,
to indicate that the force pressure is being reduced. If the red
LED flashes continuously when the close button is pressed, this
indicates that the minimum force pressure setting has been
reached.
7.4 TO RECALL FACTORY SET FORCE
1. While holding the Force Margin Set button press the RESET
button for two seconds.
2. Release both buttons. The default setting should now be
recalled.
FIG. 21
FIG. 20
WOOD (40mm High)
7.4 SAFETY OBSTRUCTION TEST
TESTING CLOSE CYCLE
1. Open the door by pressing the Yellow O/S/C button (Fig. 20).
2. Place a length of timber 40mm high on the floor directly under
the door (Fig. 21).
3. Press the Yellow O/S/C button to close door. The door should
strike the object and start to re-open.
TESTING OPEN CYCLE
1. Close the door by pressing the Yellow O/S/C button. (Fig. 20).
2. Press again to open the door. When the door opens half way
grab the bottom rail of the door firmly, the door should stop.
If the door does not reverse readily when closing, or stop when
opening, the force may be excessive and need adjusting, refer to
STEP 7.1, 7.2, 7.3 and 7.4.
IMPORTANT WARNING: If the door is closing and is unable to
re-open when obstructed discontinue use. Do not use a door with
faulty obstruction sensing. Repair fault and re-test before using.

CODING TRANSMITTERS
14
8. STORING TRANSMITTER CODES
Make sure to connect the battery to the transmitters. The
memory in the openers receiver can store up to 27 different
remote control transmitters.
8.1 STORING TRANSMITTER CODE
1. Press and hold the Door Code button (Fig. 22).
2. Press the button (one of four) on the transmitter you would
like to use to control the door for two seconds.
3. Pause for two seconds. Press the same button again on the
transmitter for two seconds.
4. Release the Door Code button.
5. Press the transmitter button to test if it operates the door.
9. STORING TRANSMITTER(S) FROM A
REMOTE LOCATION
Using this method you don’t need to have access to the
control panel on the door opener. However, you do need a
transmitter that is pre-coded to the opener’s receiver.
IMPORTANT NOTE: The door or courtesy light will be
activated when the step below is performed. The door
moving or light switching on is to confirm, from a remote
location, that the correct button was pressed and the
transmitter is in range of the opener.
1. Take any pre-coded transmitter. Press the button for the
function you require until the door is activated and release.
2. Then using a small needle press through the Coding Hole
and hold firmly for two seconds (Fig. 23)
3. Within 10 seconds take the additional transmitter you wish
to code.
4. Press the button (one of four) on that transmitter you would
like to use to control the door for two seconds, pause for two
seconds. Press the same button again on the transmitter for two
seconds, the button should now be recorded.
5. Wait for 10 seconds and then press the recorded transmitter
button to confirm that it operates the door.
10. INSTALLING WALL MOUNTED
TRANSMITTER BRACKET
1. Mount the bracket in a location out of reach of children and
convenient to the customer. (Fig. 24). Make sure the door is
visible from this location.
2. The transmitter can be easily clipped in and removed from
the holder as required.
3. To set the transmitter codes refer to Step 8.
FIG. 22
PRESS AND
HOLD DOOR
CODE
BUTTON
SELECT ONE OF THE
FOUR BUTTONS YOU
WISH TO USE TO
CONTROL THE DOOR.
WALL MOUNT
BRACKET
SMALL NEEDLE
CODING HOLE
FIG. 23
FIG. 24

CODING TRANSMITTERS
15
11. SETTING THE TRANSMITTER TO
OPERATE THE COURTESY LIGHT
The transmitter can be programmed to operate the courtesy
light on the door opener.
1. Press and hold Light Code button (Fig. 25).
2. Press the button on the transmitter you would like to use to
switch on the light for two seconds
3. Pause for two seconds. Press the same button again on the
transmitter for two seconds.
4. Release all buttons to store the transmitter in memory.
5. Press the transmitter button to test if it switches on the light.
12. ADJUSTING COURTESY LIGHT TIME
The preset courtesy light time on the Door Opener is 3 minutes.
This time can be changed as below.
1. Press and hold the Auto Close Time and Force Margin Set
buttons together (Fig. 26).
2. While holding the two buttons, press the green Open
button (Fig. 26). Each press will add 10 seconds to the light
time.
3. To decrease the time follow step 1 and press the red Close
button (Fig. 26). Each press will deduct 10 seconds from the
light time.
4. To recall the factory set default light time press and hold the
Auto Close Time, Force Margin Set and Reset buttons
together for about 2 seconds. (Fig. 26).
13. DELETING PROGRAMMED CODES
13.1 DELETING A STORED TRANSMITTER CODE
1. Select the transmitter you want to delete.
2. Press and hold the Door Code button (Fig. 27).
3. Press the transmitter button you would like to delete for two
seconds.
4. Pause for two seconds. Press the transmitter button again for
two seconds.
5. Release the Door Code button. The code should now be
deleted. Confirm this by pressing the transmitter button, the
door should not respond.
13.2 DELETING ALL STORED TRANSMITTER
CODES
1. Turn the power off to the opener.
2. Press and hold the Door Code button (Fig. 27).
3. Turn the power on again, while holding the Door Code
button. The Coding LED will illuminate to indicate that the
receivers memory has been deleted.
4. Release the Door Code button. All the stored codes
including the courtesy light codes should now be deleted.
Confirm this by pressing the transmitters previously used to
operate the door, the door (and light) should not respond.
FIG. 26
FIG. 25
FIG. 27

PE BEAM AND AUTO CLOSE
16
14. FITTING THE SAFETY PHOTO
ELECTRIC BEAM SENSOR (OPTIONAL)
Locate the Photo Electric Beam (P.E.) normally closed contact
type in a strategic location within doorway. We recommend
150mm above the floor level and as close as possible to the
door opening, inside the garage. Remove shunt from P.E
connector (Fig. 28) and connect the plug from the P.E. wiring
harness to P.E. connector (Fig. 29). The wiring diagram is for
Model PHBE (Order Code 90214).
Make sure to align the beams correctly. Follow the manual
supplied with the Photo Electric Beam.
WARNING; When using Auto Close Mode and P.E. beams,
the doorway must be clear of all obstructions and persons
at all times. The location of the beam and manner in which
it is installed might not give safety protection at all times.
Check to make sure that the height of the beam and type
used give maximum protection possible.
15. SETTING AUTO CLOSE TIME
IMPORTANT NOTICE: IT IS COMPULSORY TO
INSTALL A PHOTO ELECTRIC BEAM BEFORE USING
THE AUTO CLOSE MODE.
The Auto Close timer will only start after the Photo Electric
Beams (P.E.) path is broken and the auto close time has been
set. If the P.E. path is not broken the door will remain open until
the path is broken. If the door opener incurs an obstruction (not
from the P.E.) while closing the door will re-open and not auto
close until the path of the P.E. beam is broken again.
1. Press and hold the Auto Close Time button (Fig. 28).
2. While holding the Auto Close Time button, press the Open
button (Fig. 28). Each press of this button will add five seconds
to the auto close delay time.
3. To decrease the delay time follow Step 1 and press the Close
button. Each press will deduct five seconds from the auto close
time.
4. Press the O/S/C button (Fig. 28) or transmitter to open the
door. When the door is fully opened the Open Limit green LED
will flash to indicate that the auto close mode is in operation.
5. Break the path of the P.E. Beam momentarily, this will
initialise the auto close mode. The door will close once the set
auto close time has elapsed.
FIG. 28
FIG. 29
FACTORY DEFAULT SETTINGS
DEFAULT STEP MAXIMUM
MAXIMUM MOTOR RUN TIME 30 Secs. — —
COURTESY LIGHT TIME 3 Mins. 10 Secs. 10 Mins.
OBSTRUCTION FORCE MARGIN 10 1 20
AUTO CLOSE TIME 0 Secs. 5 Secs. 4 Mins.

PARAMETERS & SPECIFICATIONS
17
DOOR STATUS INDICATORS
DOOR OPENER STATE OPEN LED
GREEN
CLOSE LED
RED
DOOR STATUS
LED YELLOW BEEPER
OPEN ON
CLOSE ON
OPENING FLASHING
CLOSING FLASHING
DOOR TRAVEL STOPPED FLASHING FLASHING
DOOR OBSTRUCTED WHEN OPENING FLASHING
DOOR OBSTRUCTED WHEN CLOSING FLASHING BEEPS WHILE
DOOR IS MOVING
DOOR OVERLOADED ALTERNATING
FLASHES
ALTERNATING
FLASHES
DOOR IN OPEN POSITION WITH
AUTO CLOSE MODE SELECTED
ONE SECOND
FLASHES
MAINS POWER INTERRUPTED RAPID
FLASHES
TECHNICAL SPECIFICATIONS
INPUT VOLTAGE: 230V- 240V AC 50Hz
(Other voltages available upon request
e.g. 110V AC 60Hz)
TRANSFORMER PRIMARY VOLTAGE: 230V / 240VAC
SECONDARY VOLTAGE: 24V AC 100 VA
CONTROLLER VOLTAGE: 24V DC
MAXIMUM DOOR OPENING:1,2 WIDTH: 5100mm
HEIGHT: 3100mm
RATED LOAD: 200N
OPENER OPENING/CLOSING LIMITS TRAVEL: 3.5 Turns of Door Drum Wheel
OPENER MAXIMUM
OPENING/CLOSING RUN TIME: 30 Secs.
RECEIVER TYPE: UHF 433.92 MHz. AM Receiver
RECEIVER CODE STORAGE CAPACITY: 27 x 4 Button Transmitter Codes
TRANSMITTER FREQUENCY: 433.92 MHz
CODING TYPE: Code Hopping
No. of CODE COMBINATIONS: Over 4.29 Billion Random Codes
CODE GENERATION: Non-linear Encryption Algorithm
PTX-4 TRANSMITTER BATTERY: A23 Alkaline 12 Volts
EAT-1 TRANSMITTER BATTERY: CR1220 Lithium 3 Volts
MOTOR TYPE: Permanent Magnet Direct Current
MOTOR VOLTAGE: 24V DC
GLOBE: Festoon Type - 15w 24V DC
Note:
1. The maximum Roll Up Door (Domestic) opening that the EasyRoller can be installed on is 5100mm wide by 3100mm high The
door must be well balanced. A person should be able to lift the door up manually with very little effort in case of an emergency.
2. Intermittent operations may occur in areas which experience very strong winds. The strong wind puts extra pressure on the door
and tracks which may in turn trigger the safety obstruction detection system intermittently.

TROUBLE SHOOTING
18
*Please Note: Some areas may be prone to excessive radio interference brought on by devices such as cordless telephones, wireless
stereo headphones and baby monitors. It is possible that these devices could cause a degree of interference such as to greatly reduce
the range of the transmitter. In such an instance please contact your ATA dealer for an alternative frequency replacement kit. As this is
not a warrantable situation but an environmental issue charges may apply for the changeover.
SYMPTOM POSSIBLE CAUSE REMEDY
Door will not operate. Mains power not switched on.
Door is obstructed.
Door is locked or motor jammed.
Door tracks/hardware damaged.
Switch on mains power.
Remove obstruction.
Unlock door or remove jam.
Door requires service/repair by qualified
technician.
Door starts to close but automatically
reverses to open position.
Adverse weather conditions (wind or cold)
causing door to stiffen and become tight in
the tracks.
Possible obstruction in the doorway.
Increase force margin setting and/or re-
initialise the door. See Step 8 on page 11.
Remove obstruction.
Door operates from drive unit (O/S/C)
button but not from transmitter.*
See note.
Transmitter code not stored in memory.
Flat Battery.
Code transmitter in to openers memory.
Refer Step 8.1 on page 14.
Replace battery - A23 Alkaline 12V.
Door will not close fully. Door limit positions need to be reset. Reset limit positions. See Step 6 Page 10.
Door will not open fully. Door limit positions need to be reset. Reset limit positions. See Step 6 Page 10.
Courtesy light not working. Globe blown. Replace globe - festoon type 15W 24V DC.
Globe keeps blowing. Incorrect globe voltage - must be 24V DC. Replace globe - festoon type 15W 24V DC.
Auto close not working. PE Beam or wiring faulty
PE Beam not aligned correctly.
PE Beam is obstructed.
Door obstructed when closing.
Auto close time not set.
Repair PE Beam or replace wiring.
Re-align optics.
Remove obstruction from the path of PE.
Remove obstruction.
See Step 15 on page 16.
DATE MAINTENANCE PERFORMED BY SIGNATURE AMOUNT INV. No.
Please Note: Failure to maintain your garage door may void the warranty for your garage door opener.

SPARE PARTS LIST
19
WHEN ORDERING SPARE PARTS
PLEASE QUOTE THE ORDER
CODE NUMBER TO YOUR YOUR
INSTALLER/DISTRIBUTOR

WARRANTY AND EXCLUSION OF LIABILITY
Subject to all of the matter set out below, Automatic Technology Australia Pty Ltd (“ATA”) warrants for twenty four (24) months
from the date of purchase (specified in the receipt sales docket) that the Garage Door Opener System contained in the
accompanying packaging (the “Product”) is free of any defects in material and workmanship rendering it unmerchantable.
This warranty referred to above applied only where:
a) the consumer seeking to rely on the said warranty;
1) returns the Product which it claims to be defective; and
2) presents the relevant sales docket and this warranty document, to the retailer from whom the Product was purchased
to confirm that date of purchase; and
b) the purchaser notified ATA or the retailer from whom the Product was purchased of the alleged defect in the Product
immediately upon experience or learning of the alleged defect.
Except for the warranty against defects in material and workmanship set out above, ATA gives no warranties of any kind
whatsoever, whether express or implied or whether statutory or at common law, in relation to the Product, and all warranties of
fitness for particular purpose and other warranties of whatsoever kind relating to the Product are hereby disclaimed. Without
limiting the generality of the foregoing, ATA disclaims any liability of whatsoever nature in respect of any claim or demand loss
or damage which arise out of;
a) accidental damage to or normal wear and tear to the Product or to the Product’s components;
b) flood, rain, water, fire or lightning;
c) incorrect, improper or unreasonable maintenance and/or use;
d) installation, adjustment or use other than ATA which is not in accordance with the instructions set out in installation
instructions incorporated in the document;
e) attempted or complete modification or repairs to the Product carried out by a person who is not authorised by ATA to carry out
such modification or repairs;
f) faulty or unsuitable wiring of structure to which the Product is fixed or connected; and
g) radio (including citizen band transmission) or any electronic interference.
h) blown fuses or damage caused by electrical surges.
i) damage caused by insects.
j) lack of proper maintenance and care for the garage door and garage door opener. Failure to have the door serviced annually may
void this warranty.
k) installation of the opener on a commercial or industrial door or in a commercial or industrial situation.
ATA’s liability under the warranty set out above is limited, at ATA’s absolute option, to replacing or repairing the Product which
ATA, in its unfettered opinion, considers to the defective either in material and/or workmanship or to credit the consumer with the
price at which the Product was purchased by the consumer.
Where the Product is retailed by any person other than ATA, except for the warranty set out above, such person has no authority
from ATA to give any warranty or guarantee on ATA’s behalf in addition to the warranty set out above.
AUTOMATIC TECHNOLOGY AUSTRALIA PTY LTD
ABN 11 007 125 368
17-19 Advantage Rd, Highett, Victoria, Australia 3190
Tel: [phone] Fax: [phone]
Web: www.ata-aust.com.au Email: [email protected]
©January 2004 Automatic Technology Australia Pty Ltd. All Rights Reserved. SecuraCode®and EasyRoller®are registered trademarks of Automatic Technology
Australia. In an ongoing commitment to product quality ATA reserve the right to change specifications without notice. E&OE. Printed For Export.
Purchased From ___________________________________ Phone ______________________
Installed By _______________________________________ Date _______________________
Serial No. ________________________________________
