Avalue Technology ARC-1238 User manual

Part No. E2017A280A0R
ARC-1238
12.1" 11th Gen. Intel® Core™ Processor i7/i5/i3 Fanless
Rugged Touch Panel PC with IET Expansion
Quick Reference Guide
1st Ed –05 December 2022
Copyright Notice
Copyright 2022 Avalue Technology Inc., ALL RIGHTS RESERVED.

ARC-1238
2 ARC-1238 Quick Reference Guide
FCC Statement
THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION IS
SUBJECT TO THE FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE.
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING
INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS
FOR A CLASS "A" DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.
THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST
HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A
COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN
RADIATE RADIO FREQUENCY ENERGY AND, IF NOT INSTATLLED AND USED IN
ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL
INTERFERENCE TO RADIO COMMUNICATIONS.
OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE
HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO
CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.
A Message to the Customer
Avalue Customer Services
Each and every Avalue’s product is built to the most exacting specifications to ensure
reliable performance in the harsh and demanding conditions typical of industrial
environments. Whether your new Avalue device is destined for the laboratory or the factory
floor, you can be assured that your product will provide the reliability and ease of operation
for which the name Avalue has come to be known.
Your satisfaction is our primary concern. Here is a guide to Avalue’s customer services. To
ensure you get the full benefit of our services, please follow the instructions below carefully.
Technical Support
We want you to get the maximum performance from your products. So if you run into
technical difficulties, we are here to help. For the most frequently asked questions, you can
easily find answers in your product documentation. These answers are normally a lot more
detailed than the ones we can give over the phone. So please consult the user’s manual
first.
To receive the latest version of the user’s manual; please visit our Web site at:
http://www.avalue.com.tw/

Quick Reference Guide
ARC-1238 Quick Reference Guide
3
Content
1. Getting Started...................................................................................................................................... 7
1.1 Safety Precautions................................................................................................................................ 7
1.2 Packing List .......................................................................................................................................... 7
1.3 System Specifications........................................................................................................................... 8
1.4 System Overview................................................................................................................................ 13
1.4.1 I/O View................................................................................................................................. 13
1.5 System Dimensions............................................................................................................................ 14
2. Hardware Configuration...................................................................................................................... 15
2.1 ARC-1238 connector mapping ........................................................................................................... 16
2.1.1 Serial port 1 connector (COM1)............................................................................................. 16
2.1.2 Serial port 2 connector (COM2)............................................................................................. 16
2.2 Installing Memory................................................................................................................................ 17
2.3 ARC-TGL Overviews.......................................................................................................................... 18
2.4 ARC-TGL Jumper and Connector list................................................................................................. 19
2.5 ARC-TGL Jumpers & Connectors settings......................................................................................... 20
2.5.1 Clear CMOS (JBAT1)............................................................................................................ 20
2.5.2 LCD backlight brightness adjustment (JSBKL1) ................................................................... 20
2.5.3 AT/ATX Input power select (JSATX1)................................................................................... 21
2.5.4 Serial port 1 in RS-232/422/485 mode (JCOM_SEL1).......................................................... 21
2.5.5 M.2 KEY power select (JBAT1)............................................................................................. 22
2.5.6 LCD Inverter connector (JBKL1) ........................................................................................... 22
2.5.7 On-board header for USB2.0 (JUSB1).................................................................................. 23
2.5.8 Touch connector (JTP1) co-lay USB2.0 header (JUSB3)..................................................... 23
2.5.9 LVDS connector (LVDS1)...................................................................................................... 24
2.5.10 AMPLIFIER_R (JSPKR1)...................................................................................................... 25
2.5.11 AMPLIFIER_L (JSPKL1) ....................................................................................................... 25
2.5.12 Battery connector (BT1) ........................................................................................................ 26
2.5.13 SPI connector (JSPI1)........................................................................................................... 26
2.5.14 B2B connector (JB2B1)......................................................................................................... 27
2.5.15 General purpose I/O connector (JGPIO1)............................................................................. 28
2.5.16 SATA Power connector (SATAPW1)..................................................................................... 28
2.5.17 LPC connector (JLPC1)......................................................................................................... 29
2.5.18 Front Panel connector (JFP1) ............................................................................................... 29
2.6 ARC-BYT DB-A/B/C/D/G/H/K Overviews........................................................................................... 30

ARC-1238
4 ARC-1238 Quick Reference Guide
2.6.1 ARC-BYT DB-A ..................................................................................................................... 30
2.6.2 ARC-BYT DB-B ..................................................................................................................... 30
2.6.3 ARC-BYT DB-C..................................................................................................................... 30
2.6.4 ARC-BYT DB-D..................................................................................................................... 31
2.6.5 ARC-BYT DB-G..................................................................................................................... 31
2.6.6 ARC-BYT DB-H..................................................................................................................... 31
2.6.7 ARC-BYT DB-K ..................................................................................................................... 32
2.7 ARC-BYT DB-A/B/C/D/G/H/K Connector list...................................................................................... 32
2.7.1 ARC-BYT DB-A ..................................................................................................................... 32
2.7.2 ARC-BYT DB-B ..................................................................................................................... 32
2.7.3 ARC-BYT DB-C..................................................................................................................... 32
2.7.4 ARC-BYT DB-D..................................................................................................................... 33
2.7.5 ARC-BYT DB-G..................................................................................................................... 33
2.7.6 ARC-BYT DB-H..................................................................................................................... 33
2.7.7 ARC-BYT DB-K ..................................................................................................................... 33
2.8 ARC-BYT DB-D Connectors settings................................................................................................. 34
2.8.1 Serial Port 1 connector (D_COM1)........................................................................................ 34
2.8.2 Serial Port 2 connector (D_COM2)........................................................................................ 34
2.9 ARC-BYT DB-G Connectors settings................................................................................................. 35
2.9.1 Serial Port 1 connector (G_COM1) ....................................................................................... 35
2.9.2 Serial Port 2 connector (G_COM2) ....................................................................................... 35
2.9.3 Serial Port 3 connector (G_COM3) ....................................................................................... 36
2.10 ARC-BYT DB-H Jumpers settings...................................................................................................... 36
2.10.1 USB Power selector (H_USB_PWR_SEL1).......................................................................... 36
2.11 ARC-BYT DB-H Connectors settings................................................................................................. 37
2.11.1 Serial Port 1 connector (H_COM1)........................................................................................ 37
2.11.2 Serial Port 2 connector (H_COM2)........................................................................................ 37
2.12 ARC-BYT DB-K Connectors settings ................................................................................................. 38
2.12.1 Serial Port 1 connector (I_COM1)......................................................................................... 38
2.12.2 Serial Port 2 connector (I_COM2)......................................................................................... 38
3.BIOS Setup................................................................................................................................................... 39
3.1 Introduction......................................................................................................................................... 40
3.2 Starting Setup..................................................................................................................................... 40
3.3 Using Setup........................................................................................................................................ 41
3.4 Getting Help........................................................................................................................................ 42
3.5 In Case of Problems........................................................................................................................... 42
3.6 BIOS setup ......................................................................................................................................... 43
3.6.1 Main Menu............................................................................................................................. 43
3.6.1.1 System Language ............................................................................................................. 44
3.6.1.2 System Date...................................................................................................................... 44

Quick Reference Guide
ARC-1238 Quick Reference Guide
5
3.6.1.3 System Time ..................................................................................................................... 44
3.6.2 Advanced Menu..................................................................................................................... 44
3.6.2.1 Connectivity Configuration ................................................................................................ 45
3.6.2.2 CPU Configuration ............................................................................................................ 45
3.6.2.3 Power & Performance....................................................................................................... 46
3.6.2.3.1 CPU –Power Management Control.................................................................................. 47
3.6.2.4 PCH-FW Configuration...................................................................................................... 48
3.6.2.4.1 Firmware Update Configuration ........................................................................................ 48
3.6.2.5 Trusted Computing............................................................................................................ 49
3.6.2.6 APCI Settings.................................................................................................................... 49
3.6.2.7 Super IO Configuration...................................................................................................... 50
3.6.2.7.1 Serial Port 1 Configuration................................................................................................ 51
3.6.2.7.2 Serial Port 2 Configuration................................................................................................ 51
3.6.2.7.3 Serial Port 3 Configuration................................................................................................ 52
3.6.2.7.4 Serial Port 4 Configuration................................................................................................ 52
3.6.2.7.5 Serial Port 5 Configuration................................................................................................ 53
3.6.2.8 HW Monitor ....................................................................................................................... 53
3.6.2.9 S5 RTC Wake Settings ..................................................................................................... 54
3.6.2.10 USB Configuration............................................................................................................. 54
3.6.2.11 Network Stack Configuration............................................................................................. 55
3.6.2.12 NVMe Configuration.......................................................................................................... 56
3.6.3 Chipset................................................................................................................................. 56
3.6.3.1 System Agent (SA) Configuration ..................................................................................... 57
3.6.3.1.1 Memory Configuration....................................................................................................... 57
3.6.3.1.2 Graphics Configuration...................................................................................................... 58
3.6.3.1.3 VMD Configuration............................................................................................................ 58
3.6.3.2 PCH-IO Configuration ....................................................................................................... 59
3.6.3.2.1 PCI Express Configuration................................................................................................ 59
3.6.3.2.1.1 PCI Express Root Port 5(LAN2-I225)...................................................................... 60
3.6.3.2.1.2 PCI Express Root Port 6(M.2 KeyE)........................................................................ 61
3.6.3.2.1.3 PCI Express Root Port 8(JB2B1)............................................................................. 62
3.6.3.2.2 SATA And RST Configuration........................................................................................... 63
3.6.3.2.3 HD Audio Configuration .................................................................................................... 64
3.6.3.3 Board & Panel Configuration............................................................................................. 64
3.6.3.3.1 SHOW DMI INFO.............................................................................................................. 66
3.6.4 Security................................................................................................................................ 66
3.6.4.1 Secure Boot....................................................................................................................... 67
3.6.4.1.1 Key Management ................................................................................................................ 68
3.6.5 Boot...................................................................................................................................... 69
3.6.6 Save and exit....................................................................................................................... 70

ARC-1238
6 ARC-1238 Quick Reference Guide
3.6.6.1 Save Changes and Reset ................................................................................................. 70
3.6.6.2 Discard Changes and Reset ............................................................................................. 70
3.6.6.3 Restore Defaults................................................................................................................ 70
3.6.6.4 Launch EFI Shell from filesystem device.......................................................................... 70

Quick Reference Guide
ARC-1238 Quick Reference Guide
7
1. Getting Started
1.1 Safety Precautions
Warning!
Always completely disconnect the power cord from your
chassis whenever you work with the hardware. Do not
make connections while the power is on. Sensitive
electronic components can be damaged by sudden power
surges. Only experienced electronics personnel should
open the PC chassis.
Caution!
Always ground yourself to remove any static charge before
touching the CPU card. Modern electronic devices are very
sensitive to static electric charges. As a safety precaution,
use a grounding wrist strap at all times. Place all electronic
components in a static-dissipative surface or static-shielded
bag when they are not in the chassis.
1.2 Packing List
1 x ARC-1238 Panel PC
1 x Power Adapter
4 x screws for VESA

ARC-1238
8 ARC-1238 Quick Reference Guide
1.3 System Specifications
Component
Mother Board
ARC-TGL
CPU
On board 11th Gen. Intel® Core™ i7/i5/i3 BGA Processor
Intel® Core™ i7- 1185G7E (15W, 12M Cache, up to 2.80 GHz), ST
Intel® Core™ i5- 1145G7E (15W, 8M Cache, up to 2.60 GHz), ST
Intel® Core™ i3- 1115G4E (15W, 6M Cache, up to 3.00 GHz), ST
CPU Cooler
(Type)
Fanless Heatsink
Memory
1 x 260-pin SODIMM socket Max. up to 32GB DDR4 3200MT/s
Power Supply
Wide Range DC Power Input from 12~ 24v in
Adapter
AC/DC adapter 19V/3.78A Screw Type, 72W power adaptor,
(ACC-ADP-072N-02R)
System Fan
Fanless
Speaker
2W*2
Wireless LAN
Default N/A; Optional support by M.2 Key-E 2230 slot
(Support PCIe/USB Wi-Fi/BT module & CNVi Wi-Fi/BT module)
Bluetooth
Default N/A; Optional support by M.2 Key-E 2230 slot
(Support PCIe/USB Wi-Fi/BT module & CNVi Wi-Fi/BT module)
Operating System
Windows 10
Linux
Expansion Card
2 x M.2 Slots:
1 x M.2 Key-E 2230 (PCIeIII x1, USB2.0 x1, CNVi) for Wi-Fi & BT Module
(Support PCIe/USB Wi-Fi/BT module & CNVi Wi-Fi/BT module)
1 x M.2 Key-B 2242/3042/3052 with SIM card slot
SATA3/PCIeIII x1 (auto detect by switch IC)
USB3.2 Gen1x1 (5Gbp/s)/PCIeIII x1 (BOM option, default is USB3.2 Gen1x1
(5Gbp/s))
USB2.0 x1
(3052 for 5G module, PCIeIII x 2 for NVMe)
1 x 80-pin Expansion IET interface
Other Component
SIM card slot (for 4G or 5G module) for M.2 Key-B 2242/3042/3052
Onboard NuvoTon NPCT754AABYX support TPM 2.0 (by option)
Storage
Hard Disk Drive
1 x 2.5” Drive Bay (7mm HDD Restricted)

Quick Reference Guide
ARC-1238 Quick Reference Guide
9
Solid State Drive
1 x 2.5” Drive Bay (2.5”SATA3 SSD)
Other Storage
Device
1 x M.2 Key-B 2242/3042/3052 for M.2 SATAIII SSD by default,
(PCIeIII x 2 for NVMe by BOM option)
Panel
LCD Panel
Resistive Touch(ARC-1238):
12.1" XGA LED PANEL InnoLux G121XCE-L01
P-cap Touch:
12.1" XGA LED PANEL InnoLux G121XCE-L01
B/L
Inverter/Converter
Panel built in
Touch Screen
Resistive Touch(ARC-1238):
Touch panel 5 wire Analog RoHS/T121S-5RB014N-0A18R0-200FH
P-cap Touch:
12.1" PCAP H8573C+EETI EXC84H4254
Touch Controller
Resistive Touch(ARC-1238):
PenMount 6000
P-cap Touch:
N/A
Others
Bonding Panel:
Resistive Touch(ARC-1238):
12.1" Innolux G121XCE-L01+ 5-wire
P-cap Touch:
12.1" Inno G121XCE-L01+PCAP H8573C
External I/O
Serial Port
1 x DB-9 COM1 (RS-232/422/485, selectable by BIOS & JUPMER, RS-485
supports Auto Flow, Pin-9 selected for Ring(default)/+5V/+12V by BOM option)
1 x DB-9 COM2 (RS-232, Pin-9 selected for Ring(default)/+5V/+12V by BOM
option)
USB Port
4 x USB3.2 Gen2x1 (10Gbp/s) (2 x Double deck)
DIO Port
1 x 16-bit GPIO (by ARC-BYT DB-E)
Video Port
(Option By IET module only, (DB-B, DB-C)
(Option By IET module only, AUX-080 (for 2xHDMI)
Audio Port
Realtek ALC888S & 897 co-layout (or other option decided by Avalue)
LAN Port
1 x Intel® I225LM 2.5 Gigabit Ethernet
1 x Intel® I219LM Gigabit Ethernet PHY
Wireless LAN
Antenna
5 x Antenna + 2 x antenna by IET bracket
(5G needs 4~6 antenna)
Indicator Light
HDD LED, Power LED (Green for Power, Yellow for HDD)

ARC-1238
10 ARC-1238 Quick Reference Guide
Expansion Slots
2 x M.2 Slots:
1 x M.2 Key-E 2230 (PCIeIII x1, USB2.0 x1, CNVi) for Wi-Fi & BT Module
(Support PCIe/USB Wi-Fi/BT module & CNVi Wi-Fi/BT module)
1 x M.2 Key-B 2242/3042/3052 with SIM card slot
USB2.0 x1
SATA3/PCIeIII x1 (auto detect by switch IC)
USB3.2 Gen 1x1 (5Gbp/s)/PCIeIII x1
(BOM option, default is USB3.2 Gen 1x1 (5Gbp/s)/ PCIeIII x 2 for NVMe)
(3052 for 5G module)
1 x 80-pin Expansion IET interface
Mechanical
Power Type
ATX/AT by jumper (Default ATX)
Power button
1 x Power Switch on the side
Power Connector
Type
Lockable DC in power jack
(phoenix connector by option)
Dimension
A Type: 283 x 221.1 x 51.2 mm
Weight
2.4 Kgs
Color
A Type: Front: Silver Aluminum; Rear: Black Casting-Aluminum
B Type: Die Casting with Cover lens
Fanless
Full System Fan-less
OS Support
Linux, Windows 10
Reliability
EMI Test
CE/ FCC class B
Dust and Rain
Test
Front Panel IP65, Rear IP41 except I/O
Vibration Test
Random Vibration Operation:
1. PSD: 0.00454G²/Hz , 3 Grms
2. operation mode
3. Test Frequency : 5-500Hz
4. Test Axis : X,Y and Z axis
5. 30 minutes per each axis
6. IEC 60068-2-64 Test:Fh
7. Storage : SSD or M.2 SSD
Sine Vibration test (Non-operation)
1 Test Acceleration : 2G
2 Test frequency : 5~500 Hz
3 Sweep：1 Oct/ per one minute. (logarithmic)

Quick Reference Guide
ARC-1238 Quick Reference Guide
11
4 Test Axis : X,Y and Z axis
5 Test time :30 min. each axis
6 System condition : Non-Operating mode
7. Reference IEC 60068-2-6 Testing procedures
Package vibration test
1. PSD: 0.026G²/Hz , 2.16 Grms
2. Non-operation mode
3. Test Frequency : 5-500Hz
4. Test Axis : X,Y and Z axis
5. 30 min. per each axis
6. IEC 60068-2-64 Test:Fh
Mechanical Shock
Test
1. Wave form：Half Sine wave
2. Acceleration Rate：20g for operation mode
3. Duration Time：11ms
4. No. of Shock：+/- X,Y,Z axis 3 times
5. Test Axis: +/- X,Y,Z axis
6. Operation mode
7. Reference IEC 60068-2-27 Testing procedures Test Eb : Shock Test
Drop Test
Package drop test
Reference ISTA 2A, Method : IEC-60068-2-32 Test:Ed
Test Ea : Drop Test
1 Test phase : One corner, three edges, six faces
2 Test high : 96.5cm
3 Package weight : 5Kg
4 Test drawing
4-feet drop resistance without package
MIL-STD-810G
Operating
Temperature
Standard temp. -10°C ~ 50°C (14°F ~ 122°F)
Operating
Humidity
40°C @ 95% Relative Humidity, Non-condensing
Storage
Temperature
Standard temp.-20°C ~ 60°C (-4°F ~ 140°F)
Compliant with following Flexible Expansion Modules
Optional IET Module list:
ACC-ARC-USB-1R
IET DB-A 4 x USB3.0 kit for ARC Series

ARC-1238
12 ARC-1238 Quick Reference Guide
ACC-ARC-AUDIO-1R
IET DB-B HDMI + 5.1 CH Audio Kit for ARC Series
ACC-ARC-MPCIE-1R
IET DB-C HDMI + MPCIE w/SIM Kit for ARC Series
ACC-ARC-COM-1R
IET DB-D 2 x Isolated RS-232 Kit for ARC Series
ACC-ARC-COM-2R
IET DB-G 3 x RS-232 Kit for ARC Series
ACC-ARC-COM-3R
IET DB-H 2 x RS-232 + USB Kit for ARC Series
ACC-ARC-COM-4R
IET DB-K 2 x RS-232 + LAN Kit for ARC Series
ACC-ARC-GPIO-1R
IET DB-E 12-bit GPIO + 2-pin CAN Bus Kit for ARC Series
ACC-ARC-OBDII-1R
IET DB-F OBDII - CAN Bus Kit for ARC Series (OBDII/EOBD for Small
Vehicle)
ACC-ARC-OBDII-2R
IET DB-F OBDII - CAN Bus Kit for ARC Series (J1939J1708 for Large Vehicle)
ACC-ARC-OBDII-3R
IET DB-F OBDII - CAN Bus Kit for ARC Series (ISO15765-4 for Special Large
Vehicle)
Note: Specifications are subject to change without notice.

Quick Reference Guide
ARC-1238 Quick Reference Guide
13
1.4 System Overview
1.4.1 I/O View
Connectors
Label
Function
Note
DC-IN
DC Power-in connector
Default: Lockable DC Jack
Option: Phoenix Connector(MOQ apply)
COM1/2
Serial port 1/2 connector
DB-9 male connector
USB
4 x USB 3.2 connector
LAN1/2
RJ-45 Ethernet 1/2
LED
HDD/Power LED indicator
Power Switch
Power on button

ARC-1238
14 ARC-1238 Quick Reference Guide
1.5 System Dimensions
(Unit: mm)

Quick Reference Guide
ARC-1238 Quick Reference Guide
15
2.Hardware
Configuration
For advanced information, please refer to:
1- ARC-TGL, ARC-BYT DB-A/B/C/D/G/H/K included in this manual.
Note: If you need more information, please visit our website:
http://www.avalue.com.tw

ARC-1238
16 ARC-1238 Quick Reference Guide
2.1 ARC-1238 connector mapping
2.1.1 Serial port 1 connector (COM1)
RS-485
Signal
PIN
PIN
Signal
DATA-
1
6
NC
DATA+
2
7
NC
NC
3
8
NC
NC
4
9
NC
GND
5
Please set BIOS & JCOM1_SEL1
RS-232
Signal
PIN
PIN
Signal
NDCDA#
1
6
NDSRA#
NRXDA
2
7
NRTSA#
NTXDA
3
8
NCTSA#
NDTRA#
4
9
NRIA#
GND
5
RS-422
Signal
PIN
PIN
Signal
TxD-
1
6
NC
TxD+
2
7
NC
RxD+
3
8
NC
RxD-
4
9
NC
GND
5
Please set BIOS & JCOM1_SEL1
2.1.2 Serial port 2 connector (COM2)
Signal
PIN
PIN
Signal
NDCDB#
1
6
NDSRB#
NRXDB
2
7
NRTSB#
NTXDB
3
8
NCTSB#
NDTRB#
4
9
NRIB#
GND
5

Quick Reference Guide
ARC-1238 Quick Reference Guide
17
2.2 Installing Memory
Step 1. Remove 2 screws to release the chassis cover, and remove it.
Step 2.1 Insert the SODIMM into the memory socket.
Step 2.2 Re-assemble your system back through previous steps to complete the installation.

ARC-1238
18 ARC-1238 Quick Reference Guide
2.3 ARC-TGL Overviews

Quick Reference Guide
ARC-1238 Quick Reference Guide
19
2.4 ARC-TGL Jumper and Connector list
Jumper
Label
Function
Note
JBAT1
Clear CMOS
3 x 1 header, pitch 2.00mm
JP1
M.2 KEY power select
3 x 1 header, pitch 2.00mm
JCOM_SEL1
Serial port 1 in RS-232/422/485 mode
4 x 3 header, pitch 2.00mm
JSBKL1
LCD backlight brightness adjustment
3 x 1 header, pitch 2.00mm
JSATX1
AT/ATX Input power select
3 x 1 header, pitch 2.54mm
Connectors
Label
Function
Note
SODIMM1
260-Pin DDR4 SO-DIMM
JBKL1
LCD Inverter connector
5 x 1 wafer, pitch 2.00mm
COM1/2
Serial Port 1/2 connector
D-sub 9 pin, male
JSPKL1
AMPLIFIER_L
2 x 1 wafer, pitch 2.00mm
JSPKR1
AMPLIFIER_R
2 x 1 wafer, pitch 2.00mm
JB2B1
B2B connector
40 x 2 wafer, pitch 0.80mm
LED1
HDD/Power LED indicator
LVDS1
LVDS connector
DIN 40-pin wafer, pitch 1.25mm
USB1/2
4 x USB3.2 connector
JUSB1
On-board header for USB2.0
5 x 2 wafer, pitch 2.00mm
JUSB3
On-board header for USB2.0
5 x 1 wafer, pitch 2.00mm
JTP1
Touch connector
5 x 1 header, pitch 2.54mm
LANL/LANR
2 x RJ-45 Ethernet
JFP1
Front Panel connector
6 x 2 wafer, pitch 2.00mm
BT1
Battery connector
2 x 1 wafer, pitch 1.25mm
JGPIO1
General purpose I/O connector
6 x 2 wafer, pitch 2.00mm
DCIN1
DC-IN connector
JSPI1
SPI connector
4 x 2 header, pitch 2.00mm
JLPC1
LPC connector
5 x 2 header, pitch 2.00 mm
SATA1
Serial ATA connector
SATAPW1
SATA Power connector
2 x 1 wafer, pitch 2.00mm
SW1
Power button
M2B1
M.2 KEY-B 2242/3042/3052 connector
M2KE1
M.2 KEY-E 2230 connector

ARC-1238
20 ARC-1238 Quick Reference Guide
USIM1
SIM card slot
2.5 ARC-TGL Jumpers & Connectors settings
2.5.1 Clear CMOS (JBAT1)
*Default
Protect*
Clear CMOS
2.5.2 LCD backlight brightness adjustment (JSBKL1)
* Default
PWM Mode*
DC Mode
