Avanti EWC2410DZ User manual

INSTRUCTION MANUAL
MANUAL DE INSTRUCCIONES
Model Number / No. de Modelo: EWC2410DZ
WINE CHILLER / VINERA
(Image may vary)
BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING
INSTRUCTIONS.
La sección en español empieza en la página 15.
Avanti Products has a policy of continuous improvement on its products and reserves the right to change materials and
specifications without notice.
Avanti Products, A Division of The Mackle Co., Inc.
P.O. Box 520604 -Miami, Florida 33152
www.avantiproducts.com

2
THIS PAGE LEFT BLANK INTENTIONALLY

3
TABLE OF CONTENTS
Appliance Safety
4
Important Safeguides
5
Help Us Help You
6
Parts and Features
7
Important Safety Instructions
8
Installation Instructions
8
Before Using Your Wine Chiller
8
Installation of Your Wine Chiller
8
Electrical Connection
9
Extension Cord
9
Operating Your Wine Chiller
10
Temperature Control
10
Storage Capacity
11
Interior Light
11
Care and Maintenance
11
Cleaning Your Wine Chiller
11
Power Failure
11
Moving Your Wine Chiller
11
Energy Saving Tips
12
Troubleshooting Guide
12
Service for Your Appliance
13
Wiring Diagram
13
Your Avanti Products Warranty
14
Instrucciones en Español
15 – 18
Registration Information and Registration Card
19

4
APPLIANCE SAFETY
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always
read and obey all safety messages.
This is the Safety Alert Symbol. This symbol alerts you to potential hazards that
can kill or injure you and others. All safety messages will follow the Safety
Alert Symbol and either the words “DANGER”, “WARNING” or “CAUTION”.
Danger means that failure to heed this
safety statement may result in severe
personal injury or death.
Warning means that failure to heed this
safety statement may result in extensive
product damage, serious personal injury, or
death.
Caution means that failure to heed this
safety statement may result in minor or
moderate personal injury, or property or
equipment damage.
All safety messages will alert you do what the potential hazard is, tell you how to reduce the chance of
injury, and let you know what can happen if the instructions are not followed.

5
IMPORTANT SAFEGUIDES
Before the appliance is used, it must be properly positioned and installed as
described in this manual, so read the manual carefully. To reduce the risk of fire,
electrical shock or injury when using the appliance, follow basic precaution,
including the following:
•Plug into a grounded 3-prong outlet, do not remove grounding prong, do not use an adapter, and
do not use an extension cord.
•Replace all panels before operating.
•It is recommended that a separate circuit, serving only your appliance be provided. Use
receptacles that cannot be turned off by a switch or pull chain.
•Never clean appliance parts with flammable fluids. These fumes can create a fire hazard or
explosion. And do not store or use gasoline or other flammable vapors and liquids in the vicinity of
this or any other appliance. The fumes can create a fire hazard or explosion.
•Before proceeding with cleaning and maintenance operations, make sure the power line of the
unit is disconnected.
•Do not connect or disconnect the electric plug when your hands are wet.
•Unplug the appliance or disconnect power before cleaning or servicing. Failure to do so can result
in electrical shock or death.
•Do not attempt to repair or replace any part of your appliance unless it is specifically
recommended in this material. All other servicing should be referred to a qualified technician.
FOLLOW WARNING CALL OUTS BELOW ONLY WHEN APPLICABLE TO YOUR MODEL
•Use two or more people to move and install appliance. Failure to do so can result in injury.
•To ensure proper ventilation for your appliance, the front of the unit must be completely
unobstructed. Choose a well-ventilated area with temperatures above 60°F (16°C) and below
90°F (32°C). This unit must be installed in an area protected from the element, such as wind, rain,
water spray or drips.
•The appliance should not be located next to ovens, grills or other sources of high heat.
•The appliance must be installed with all electrical, water and drain connections in accordance with
state and local codes. A standard electrical supply (115 V AC only, 60 Hz), properly grounded in
accordance with the National Electrical Code and local codes and ordinances is required.
•Do not kink or pinch the power supply cord of appliance.
•The fuse (or circuit breaker) size should be 2.5 amperes.
•It is important for the appliance to be leveled in order to work properly. You may need to make
several adjustments to level it.
•Never allow children to operate, play with or crawl inside the appliance.
•Do not use solvent-based cleaning agents of abrasives on the interior. These cleaners may
damage or discolor the interior.
•Do not use this apparatus for other than its intended purpose.

6
HELP US HELP YOU...
Read this guide carefully.
It is intended to help you operate and maintain
your new Wine Chiller properly.
Keep it handy to answer your questions.
If you don't understand something or you
need more assistance, please call:
Avanti Customer Service
800-220-5570
Keep proof of original purchase date (such as
your sales slip) with this guide to establish the
warranty period.
Write down the model and serial numbers.
You'll find them on a plate located on the rear
outside wall of the Wine Chiller.
Please write these numbers here:
____________________________________
Date of Purchase
____________________________________
Model Number
____________________________________
Serial Number
Use these numbers in any correspondence or
service calls concerning your Wine Chiller.
If you received a damaged Wine Chiller,
immediately contact the dealer (or builder) that
sold you the Wine Chiller.
Save time and money. Before you call for
service, check the Troubleshooting Guide. It
lists causes of minor operating problems that
you can correct yourself.
IF YOU NEED SERVICE
We're proud of our service and want you to be
pleased. If for some reason you are not happy
with the service you receive, here are some
steps to follow for further assistance.
FIRST, contact the people who serviced your
Wine Chiller. Explain why you are not pleased.
In most cases, this will solve the problem.
NEXT, if you are still not pleased, write all the
details, including your telephone number, and
send it to:
Customer Service
Avanti Products
10880 NW 30 Street
Miami, FL 33172 USA
CAUTION:
THIS WINE CHILLER IS NOT
DESIGNED FOR THE STORAGE
OF MEDICINE OR OTHER
MEDICAL PRODUCTS.

7
PARTS & FEATURES
EWC2410DZ
1
Cabinet
6
Upper Door Hinge w/ Cover
2
Ventilation holes
7
Door gasket
3
Cold sink fan cover
8
Glass door
4
Shelf(Total 4)
9
Bottom hinge
5
Leveling Legs

8
IMPORTANT SAFETY INSTRUCTIONS

WARNING

To reduce the risk of fire, electrical shock,
or injury when using your appliance, follow
these basic precautions:
•Read all instructions before using the Wine Chiller.
•DANGER or WARNING: Risk of child entrapment.
Child entrapment and suffocation are not problems of the past. Junked or abandoned
appliances are still dangerous . . . even if they will “just sit in the garage a few days”.
•Before you throw away your old Wine Chiller: Take off the door. Leave the
shelves in place so that children may not easily climb inside.
•Never allow children to operate, play with, or crawl inside the appliance.
•Never clean appliance parts with flammable fluids. The fumes can create a fire
hazard or explosion.
•Do not store or use gasoline or any other flammable vapors and liquids in the vicinity
of this or any other appliance. The fumes can create a fire hazard or explosion.
•Do not repair or replace any part of the wine chiller or attempt any servicing unless
specifically recommended in the user-maintenance instructions or in published user-
repair instructions. Replace the fuse with the same type.
-Save these instructions-
INSTALLATION INSTRUCTIONS

•Remove the exterior and interior packing.
Before Using Your Wine Chiller
•Check to be sure you have all of the following parts:
(4) Shelves
(1) Instruction manual
•Clean the interior surface with lukewarm water using a soft cloth.

•This Wine Chiller is designed to be free standing installation only, and should not be recessed or
built-in (Fully recessed).
Installation of Your Wine Chiller
•Place your Wine Chiller on a surface that is strong enough to support it when it is fully loaded.
•Allow 5 inches of space between the back and sides of the wine chiller, which allows the proper
air circulation to cool the heat sink.
•Locate the Wine Chiller away from direct sunlight and sources of heat (stove, heater, radiator,
etc.). Direct sunlight may affect the acrylic coating and heat sources may increase electrical
consumption. Extreme cold ambient temperatures may also cause the unit not to perform
properly.
•This Wine Chiller uses superconductor refrigeration technology (no compressor) and is not
designed for storage in hot areas like garages, warehouses or outdoors since it is designed to
operate at a maximum of 30 degrees below the ambient temperature.
•Avoid locating the unit in moist areas.
•Plug the Wine Chiller into an exclusive, properly installed-grounded wall outlet. Do not under any
circumstances cut or remove the third (ground) prong from the power cord. Any questions
concerning power and/or grounding should be directed toward a certified electrician or an
authorized Avanti Products service center.
•After plugging the Wine Chiller into a wall outlet, allow the unit to cool down for 2-3 hours before
placing any items in the compartment.

9
ELECTRICAL CONNECTION
This appliance should be properly grounded for your safety. The power cord of this appliance is
equipped with a three-prong plug which mates with standard three prong wall outlets to minimize the
possibility of electrical shock.
Do not under any circumstances cut or remove the third ground prong from the power cord supplied.
For personal safety, this appliance must be properly grounded.
This appliance requires a standard 115/120 Volt AC ~/60Hz electrical ground outlet with three-prong.
Have the wall outlet and circuit checked by a qualified electrician to make sure the outlet is properly
grounded. When a standard 2-prong wall outlet is encountered, it is your responsibility and obligation
to have it replaced with a properly grounded 3-prong wall outlet.
The cord should be secured behind the appliance and not left exposed or dangling to prevent
accidental injury.
The appliance should always be plugged into its own individual electrical outlet which has a voltage
rating that matches the rating label on the appliance. This provides the best performance and also
prevent overloading house wiring circuits that could cause a fire hazard from overheated. Never
unplug the appliance by pulling the power cord. Always grip the plug firmly and pull straight out from
the receptacle. Repair or replace immediately all power cords that have become frayed or otherwise
damaged. Do not use a cord that shows cracks or abrasion damage along its length or at either end.
When moving the appliance, be careful not to damage the power cord.
EXTENSION CORD
Because of potential safety hazards under certain conditions, it is strongly recommended that you do
not use an extension cord with this appliance. However, if you must use an extension cord it is
absolutely necessary that it be a UL/CUL-Listed, 3-wire grounding type appliance extension cord
having a grounding type plug and outlet and that the electrical rating of the cord be 300 volts and at
least 10 amperes.
SURGE PROTECTOR
Most electrical appliances use a series of electric control boards to operate. These boards are very
susceptible to power surges and could be damaged or destroyed.
If the appliance is going to be used in an area or if your city / country is prone to power surges /
outages; it is suggested that you use a power surge protector for all electrical devices / appliances
you use. The surge protector that you select must have a surge block high enough to protect the
appliance it is connected to. If you have any questions regarding the type and size of surge protector
needed contact a licensed electrician in your area.
Damages due to power surges are not considered a manufacturer covered defect and will void your
product warranty.

Warning

Improper use of the grounded plug can result in the risk of electrical shock. If the power cord is
damaged, have it replaced by an authorized Avanti Products service center.

10
OPERATING YOUR WINE CHILLER
It is recommended you install the Wine Chiller in a place where the ambient temperature is between
23º-26ºC/ 72º-78ºF. If the ambient temperature is above or below recommended temperatures, the
performance of the unit may be affected. For example, placing your unit in extreme cold or hot
conditions may cause interior temperatures to fluctuate. The range of 8º-18ºC/46º-64ºF may not be
reached. The default temperature set at the factory is 12ºC / 54ºF.
Recommended Temperatures for Chilling Wine.
Red Wines
14º - 18º C
57– 64º F
Dry/White Wines
9º - 14º C
49 – 58º F
Rose Wines
10º - 11º C
51 – 53º F
Sparkling Wines
7º - 9º C
46 – 49º F
Temperature Ranges For Your Wine Chiller
Upper Zone
8 º - 18º C
46 º – 64º F
Lower Zone
9 º - 18º C
48 º – 64º F

CONTROL PANEL

Upper zone and bottom zone are each controlled separately
SETTING THE TEMPERATURE CONTROL
Your Wine Cellar has been equipped with an “automatic” control panel lock, that will activate 12
seconds after the last time a button has been touched.
Push the and button simultaneously for 3 seconds to unlock the control panel. You will
hear a “BEEP” sound to alert you that the control is now active.
You can set the temperature as you desire by pushing the or button on the control
panel for each zone. The temperature that you desire to set will increase 1ºF or 1ºC if you push
the button once, on the contrary the temperature will decrease 1ºF or 1ºC if you push the
button once.
Temperature settings applicable when storing mostly one type of wine:
Red Wines
14º - 18º C
57– 64º F
White / Rose / Dry Wines
9º - 14º C
49 – 58º F
Sparkling Wines
7º - 9º C
46 – 49º F
You can select temperature display setting from Fahrenheit to Celsius degree by
pushing this button approximately for 3 seconds. The degrees will appear in blue
color in the temperature display window.

11
NOTE:
•Default Temperature Setting: 54ºF (This is the default temperature set at the factory).
•When you use the wine chiller for the first time or restart the wine chiller after having been shut off
for a long time, there could be a few degrees variance between the temperature you select and
the one indicated on the LED readout. This is normal and it is due to the length of the activation
time. Once the wine chiller is running for a few hours everything will be back to normal.
Storage Capacity
You can place 24 standard bottles in this wine chiller.
Upper zone: 8 bottles
Bottom zone: 16 bottles
Many bottles may differ in size and dimensions. As
such the actual number of bottles you may be able to
store may vary. Bottle capacities are approximate
maximums when storing traditional Bordeaux 750ml
bottles.
Interior Light
You can turn the interior light ON or OFF by pushing the button marked with the “Light”
symbol. The light will be turned off automatically if it remains ON for 10 minutes. You have
to push the button marked with the “Light” symbol again and the light will turn back on.
CARE AND MAINTENANCE

•UNPLUG the Wine Chiller, and remove all items including shelves.
Cleaning Your Wine Chiller
•Wash the inside surfaces with a warm water and baking soda solution. The solution should be
about 2 tablespoons of baking soda to a quart of water.
•Wash the shelves with a mild detergent solution.
•Wring excess water out of the sponge or cloth when cleaning area of the controls, or any
electrical parts.
•Wash the outside cabinet with warm water and mild liquid detergent. Rinse well and wipe dry with
a clean soft cloth.
Failure to unplug the Wine Chiller could result in electrical shock or personal injury.
CAUTION

•Most power failures are corrected within a few hours and should not affect the temperature of
your appliance if you minimize the number of times the door is opened. If the power is going to be
off for a longer period of time, you need to take the proper steps to protect your contents.
Power Failure
•Your wine chiller is designed to return to the factory default temperature setting once power the
unit is plugged in or once the power has returned after an outage.

•Remove all bottles.
Moving Your Wine Chiller
•Securely tape down all loose items (shelves) inside your appliance.
•Tape the door shut.
•Protect outside of appliance with a blanket, or similar item.

12
Energy Saving Tips
•The Wine Chiller should be located in the coolest area of the room, away from heat producing
appliances, and out of the direct sunlight.
•One characteristic of superconductor units is the length of time it requires to recover from having
the door opened and shut frequently. It may be necessary to wait longer for the temperature to
return to its former level once the door has been opened for too long. This is normal for this type
of unit.
PROBLEMS WITH YOUR WINE CHILLER?
You can solve many common Wine Chiller problems easily, saving you the cost of a possible service
call. Try the suggestions below to see if you can solve the problem before calling the servicer.
TROUBLESHOOTING GUIDE
PROBLEM
POSSIBLE CAUSE
Wine Chiller does not operate or cool.
Not plugged in.
The circuit breaker tripped or a blown fuse.
Control panel is locked
Push the and button simultaneously for
3 seconds to unlock the control panel.
Wait for beep sound.
Wine Chiller is not cold enough.
Check the temperature control setting.
External environment may require a higher
setting.
The door is opened too often.
The door is not closed completely.
The door gasket does not seal properly.
The Wine Chiller does not have the correct
clearances.
Abnormal voltage.
The light does not work.
Not plugged in.
The circuit breaker tripped or a blown fuse.
The light button is “OFF”.
Vibrations.
Check to assure that the Wine Chiller is level.
The door will not close properly.
The Wine Chiller is not level.
The door was not properly installed.
The gasket is dirty.
The shelves are out of position.

13
SERVICE FOR YOUR WINE CHILLER
We are proud of our customer service organization and the network of professional service
technicians that provide service on your Avanti appliances. With the purchase of your Avanti
appliance, you can have the confidence that if you ever need additional information or assistance, the
Avanti Products Customer Service team will be here for you. Just call us toll-free.
AVANTI PRODUCTS CUSTOMER SERVICES
Product Information
800-323-5029
Whatever your questions are about our products,
help is available.
Part Orders
800-220-5570 You may order parts and accessories that will be delivered directly to your home by personal
check, money order, Master Card, or Visa.
In-Home Repair Service
800-220-5570 An Avanti Products authorized service center will provide expert repair service, scheduled at a time
that is convenient for you. Our trained servicers
know your appliance inside and out.
WIRING DIAGRAM
TECHNICAL / ELECTRICAL SPECIFICATIONS
Rated Voltage
115V
Rated Frequency
60Hz
Rated Input Power
140W
COOLING MODULE

14
YOUR Avanti Products WARRANTY
Staple your sales receipt here. Proof of
original purchase date is needed to obtain
service under warranty.
WHAT IS COVERED
LIMITED ONE-YEAR
For one year from the date of
purchase by the original owner, Avanti
Products will, at its option, repair or
replace any part of the unit, which
proves to be defective in material or
workmanship under normal use.
During this period Avanti Products will
provide all parts and labor necessary
to correct such defects free of charge,
so long as the unit has been installed
and operated in accordance with the
written instructions in this manual. In
rental or commercial use, the warranty
period is 90 days. Avanti Products will
provide you with a reasonably similar
replacement product that is either new
or factory refurbished. All Avanti
Appliances of 3.5 cubic feet capacity
or less must be brought/sent to the
appliance service shop for repair.
WARRANTY
•Content losses of food or other, due to
spoilage.
•Incidental or consequential damages.
•Parts and labor costs for the following will
not be considered as warranty:
•Door springs, and/or frames.
•Inner door panels, door rails and/or door
supports.
•Light bulbs and/or plastic housing.
•Plastic cabinet liners.
•Repairs performed by unauthorized
servicers.
•Shipping and handling costs associated
with the replacement of the unit.
•Service calls that do not involve defects in
material or workmanship such as
customer education, door reversal, or
proper installation.
•Service calls that are related to external
problems, such as abuse, misuse,
inadequate electrical power, accidents,
fire, floods, or acts of God.
•Surcharges including, but not limited to,
any after hour, weekend, or holiday
service calls, tolls, ferry trip charges, or
mileage expense for service calls to
remote areas, including the State of
Alaska
•Replacement of house fuses or resetting
circuit breakers.
•Failure of the product if it is used for other
than its intended purpose.
•This warranty does not apply outside the
Continental USA.
WHAT IS NOT COVERED

15
INSTRUCCIONES DE SEGURIDAD
ATENCION
INSTRUCCIONES PARA
LA CONEXION A TIERRA
Este aparato electrodoméstico debe estar conectado a tierra. En caso de un cortocircuito eléctrico, la
conexión a tierra reduce el riesgo de choque eléctrico proporcionando un cable a tierra con una
enchufe de conexión a tierra. Este enchufe debe estar conectado en un tomacorriente instalado
correctamente y conectado a tierra.
ADVERTENCIA – El uso inadecuado del enchufe de conexión a tierra puede resultar en un riesgo de
choque eléctrico. Consulte con un electricista o persona de reparaciones competente si no
comprenden bien las instrucciones de conexión a tierra o si existe alguna duda sobre si el aparato
esta conectado a tierra correctamente.
NO USE UN CORDON DE
PROLONGACION ELECTRICA
Use un tomacorriente de pared exclusivo. No conecte su vinera a cordones de prolongación eléctrica
o junto a cualquier otro electrodoméstico en el mismo tomacorriente de pared.
ADVERTENCIA IMPORTANTE:
Una vinera vacía es una atracción muy peligrosa para los niños. Saque todas las juntas,
pestillos, tapas o puerta de todo electrodoméstico que no esté en uso, o tome alguna
medida para asegurar que no presente peligro.
INSTRUCCIONES DE INSTALACION
Saque los embalajes exteriores, limpie bien el exterior con un paño suave seco, y el interior con un
paño húmedo y tibio. Evite colocar la vinera cerca de una fuente de calor, luz de sol directa, o lugar
húmedo.
Ubicación
1. Seleccione un lugar con su piso fuerte y nivelado.
2. Deje cinco pulgadas de espacio entre la parte posterior de la vinera y toda pared contigua.
3. Las bodegas superconductores necesitan cierto tiempo de recuperación cuando la puerta se
abre y se deja abierta por mucho tiempo. Esto es normal para este tipo de unidad.
4. Evite la luz directa del sol o calor. La luz directa del sol puede afectar la capa de acrílico.
Las fuentes de calor en su proximidad provocarán un consumo mayor de electricidad.
5. Para un mejor desempeño, nivele la vinera utilizando las patas ajustables o tornillos
niveladores.
OPERACION
Para evitar vibraciones, el compartimiento interior debe estar bien nivelado. La temperatura variará
dependiendo de la cantidad de botellas almacenadas y la frecuencia con que se abre la puerta.
Cuando la vinera no se use por un período largo, desconecte el enchufe y deje la puerta entreabierta.

16
Conexión Eléctrica
•Para su seguridad, esta vinera debe estar apropiadamente conectada a tierra. El cordón
eléctrico de esta vinera está equipado con un enchufe de tres puntas, el cual encaja
perfectamente en los receptáculos/enchufes de pared de tres puntas estándar, para minimizar la
posibilidad de un choque eléctrico.
•Bajo ninguna circunstancia corte o retire la tercera punta (cable a tierra) del enchufe del cordón
eléctrico.
•Nunca use un cable de extensión para conectar la unidad a la electricidad.
•Nunca use un adaptador con enchufe de solo 2 puntas.
•Si solo puede conectar la vinera a un receptáculo/enchufe de pared de 2 puntas, comuníquese
con un electricista calificado para que reemplace ese receptáculo/enchufe de pared por uno de 3
puntas, de acuerdo con los códigos de electricidad aplicables.
•Esta vinera requiere un receptáculo/enchufe de pared de tres puntas estándar de 115/120 voltios
a.c.~/60hz.
•Para prevenir cualquier daño físico o lesión, el cordón debe ser asegurado detrás de la vinera y
no estar expuesto o colgando.
Cable de Extensión
Debido al posible riesgo de seguridad causado bajo ciertas circunstancias, se recomienda
firmemente que no use un cable de extensión para este electrodoméstico. Sin embargo, si no tiene
otra opción más que usar un cable de extensión, asegúrese que este sea un cable de extensión para
electrodomésticos que este listado bajo UL/CUL, que tenga enchufe y receptáculo para enchufe de
tres puntas (cable a tierra) y que la capacidad del cordón eléctrico sea de 300 voltios y no menos de
10 amperios.
Protector contra variaciones de corriente eléctrica (Surge Protector).
La mayoría de electrodomésticos utilizan una series de paneles de control para operar. Estos
paneles son muy susceptibles a las variaciones de corriente eléctrica, las cuales causan que estos se
dañen o destruyen.
Si vive en un área o ciudad done hay muchas variaciones de corriente o apagones, se recomienda
que utilice un protector contra variaciones de corriente para todos los electrodomésticos y aparatos
eléctricos. El protector que elija debe bloquear una variación de electricidad alta para poder proteger
el electrodoméstico al cual está conectado. Por favor contáctese con un electricista licenciado en su
área si tuviera preguntas en referencia al tipo y tamaño de protector que necesita.
Daños debido a variaciones de electricidad no se consideran un defecto del fabricante y podrían
anular la garantía.
ADVERTENCIA
EL USO INAPROPIADO DEL ENCHUFE A TIERRA PUEDE OCASIONAR RIESGO DE UN
CHOQUE ELECTRICO. SI EL CORDON SE DAÑASE, LLEVELO A UN CENTRO DE
SERVICIO AUTORIZADO POR AVANTI PRODUCTS PARA QUE SE REEMPLACE.

17
CONTROL DE TEMPERATURA:
Se recomienda que Ud coloque su vinera en un lugar donde la temperatura ambiental se mantenga
entre 23º-26ºC / 72º-78ºF.
Si la temperatura ambiental oscila fuera de esos límites, pueda afectar la temperatura de la unidad.
Por ejemplo, si su unidad está situada en lugares donde hay temperaturas muy frías o calientes
también puede afectar la temperatura de la unidad y no alcanzará los límites 8º-18ºC/46º-64ºF).
Temperaturas recomendadas para enfriar vinos:
Vinos rojos
14º - 18º C
57º – 64º F
Vinos blancos
9º - 14º C
49º – 58º F
Vinos tintos
10º - 11º C
51º – 53º F
Vinos espumantes
7º - 9º C
46º – 49º F
Rango de Temperatura de su vinera
Zona Superior
8º - 18º C
46º – 64º F
Zona Inferior
9º - 18º C
48º – 64º F
Panel de controles
Control de temperatura
El panel de control de su vinera se anulará automáticamente 12 segundos después que cualquier
botón haya sido presionado.
Para activar el panel de control de su vinera, presione simultaneamente los botones
marcados y por 3 segundos. Espere por el sonido.
Ud. se puede seleccionar la temperatura preferida presionando los botones marcados
▲ o ▼. Cuando Ud. presione uno de los dos botones por primera vez la temperatura
seleccionada originalmente en la factoría aparecerá en la pantalla. (12ºC / 54ºF).
La temperatura que Ud. selecciona subirá 1ºC/F cada vez que presione el botón marcado ▲ al
contrario la temperatura bajará 1ºC/F cada vez que presione el botón marcado .
AVISO:
Cuando Ud. encienda su vinera por primera vez o después de un largo tiempo de estar apagado,
habrá una diferencía entre la temperatura que Ud. selecciona y la temperatura indicada en la pantalla
digital. Este situación es normal debido al tiempo de que estuvo apagado. En cuanto la unidad esté
encendida por un par de horas la temperatura volverá a su nivel normal.
Luz interior
Ud. puedes encender o apagar la luz interior presionando el botón marcado . La luz interior se
apagará automáticamente si está encendida por 10 minutos seguidos. Ud. necesita presionar el
botón de nuevo para encender la luz.

18
CUIDADO Y MANTENIMIENTO
Capacidad
24 botellas de tamaño normal (estandard)
(8 botellas en la zona superior y 16 botellas en la zona inferior).
El tamaño de las botellas puede variar y afectará la cantidad de botellas que Ud. puede almacenar.
Limpieza
Para limpiar el interior, use un paño suave con una solución de una cucharada de bicarbonato de
sodio por cada cuarto de agua, o una solución de espuma de jabón suave, o un detergente suave.
Para lavar las rejillas, sáquelas deslizándolas con cuidado, y use una solución de detergente suave;
luego séquelas con un paño suave. Limpie el exterior con un paño húmedo suave y un poco de
detergente suave o productos de limpieza para electrodomésticos.
Corte de corriente
La mayoría de los cortes de corriente se corrigen en una o dos horas y no afectarán las temperaturas
de su vinera. Sin embargo, Ud. deberá reducir la cantidad de veces que abra la puerta cuando la
corriente esté apagada. Durante los cortes de corriente de larga duración, tome medidas para
proteger sus botellas de vino.
Si Ud. se muda
Saque o asegure todos los artículos dentro de su vinera. Para evitar que los tornillos nivelantes se
averíen, gírelos completamente hacia la base.
Algunas reglas importantes para el uso correcto de la vinera.
•Las bebidas deben guardarse en botellas cerradas.
•No sobrecargue el compartimiento interior.
•No abra la puerta a menos que sea necesario.
•Nunca cubra los estantes del compartimiento para vinos con papel de aluminio o cualquier otro
material para cubrir estantes que puedan obstruir la circulación del aire.

19
Registration Information
Thank you for purchasing this fine Avanti product. Please fill out this form and return it to the
following address within 100 days from the date of purchase and receive these important benefits:
Avanti Products, A Division of The Mackle Co., Inc.
P.O.Box 520604 – Miami, Florida 33152
Protect your product:
We will keep the model number and date of purchase of your new Avanti product on file to
help you refer to this information in the event of an insurance claim such as fire or theft.
Promote better products:
We value your input. Your responses will help us develop products designed to best meet
your future needs.
-------------------------------------------------------(detach here)--------------------------------------------------------------
Avanti Registration Card
Name
Model # Serial #
Address
Date Purchased Store / Dealer Name
City State Zip
E-mail Address
Area Code Phone Number
Occupation
Did You Purchase An Additional Warranty
As your Primary Residence, Do You:

Extended

Own

Rent

None
Your Age:
Reason for Choosing This Avanti Product:
Please indicate the most important factors
That influenced your decision to purchase
this product:

under 18

18-25

26-30
31-35 36-50 over 50
Marital Status:

Married

Single
Price
Product Features
Avanti Reputation
Product Quality
Salesperson Recommendation
Other: ___________________
Friend / Relative Recommendation
Warranty

Other: ___________________
Is This Product Used In The:
Home Business
How Did You Learn About This Product:
Advertising
In-Store Demo
Personal Demo
Comments:

20
AV 01
PRINTED IN CHINA
