Avantree Audition User manual

1. Headset overview
NOTE: All accessories are also available on avantree.com
2. Connect
2.1 Connect with mobile phone
STEP 1 Turn Audition off (press and hold MFB button for 4s).
STEP 2 Press and hold MFB button for 7-10s until LED indicator flashes blue and red alternately.
STEP 3 Activate Bluetooth on your phone and select “Avantree Audition”.
2.2 Connect with NFC enabled mobile phone
STEP 1 Make sure NFC function is turned on from your phone and that the screen is active and
unlocked.

STEP 2 Hold the NFC mobile phone against the NFC zone of the headset (the NFC logo).
NOTE: Since NFC antenna is located in different position of phone, it is helpful to know the
position for fast pairing. For details on NFC, see your phone’s user manual.
2.3 Connect with non Bluetooth enabled devices
When the device is not Bluetooth enabled, or battery of headset is low, you can use the 3.5mm
audio cable to stream music, just connect the cable to the device.
NOTE: The buttons and microphone on the headphones will not work under this situation.
2.4 Connect with two mobile phones simultaneously
STEP 1 Connect headset with the first phone as above. Then Turn off Bluetooth of the first phone.
STEP 2 Connect headset with the second phone as above. Then turn off the headset.
STEP 3 Turn on Bluetooth of the first phone. Then Turn on the headset.
STEP 4 It will automatically connect with the second phone, after that please tap from the first
phone to manually connect it.
2.5 Connect with PC/notebook
STEP 1 Turn Audition off (press and hold MFB button for 4s).
STEP 2 Press and hold MFB button for 7-10s until LED indicator flashes blue and red alternately.

STEP 3 Activate Bluetooth on your PC/notebook and select “Avantree Audition”.
NOTE: Make sure PC/notebook is Bluetooth enabled and supports A2DP profile, otherwise you
may need a Bluetooth audio adapter to add the feature on PC/notebook that do not. For details
on how to set up with PC/notebook, please see support.avantree.com
3. How to use
MFB
On/Off
Press and hold MFB 4s
MFB
Answer a call
Press MFB once
MFB
End a call
Press MFB once
MFB
Reject a call
Double click MFB
MFB
Redial last number
Double click MFB
“V+”and “V-”
Voice Dial / Command
Short press “V+”and “V-”
MFB
Play music
Press MFB once
MFB
Pause music
Press MFB once
V+
Volume up
Press and hold “V+”
V-
Volume down
Press and hold “V-”
V+
Next track
Press “V+”once
V-
Previous track
Press “V-”once
4. How to charge
When the LED blinks red, you should recharge your headphones. Please remove the micro-USB
protector and charge the headphones via the supplied USB to AC adapter or PC USB port. It
normally takes about 3 hours to fully charge the battery. The LED will stay red when charging and
will turn off when charging is complete.
NOTE: AC adapter requirement 5V / 500mA-2A.
5. Product specifications
Bluetooth version: 4.0

Support profiles: Headset, Handsfree, A2DP, AVRCP
Operational range: Class 2, 10 meters
Battery: rechargeable lithium battery
Talk time: up to 50 hrs
Music time: up to 40 hrs
Standby time: up to 20 days
Headset weight: 180g
Headset size: 170mm(W)x180mm(H)X80mm(D)
NOTE: The talk and standby times may vary when used with different mobile phones or other
compatible Bluetooth devices and are also dependant on different usage styles, settings and
operating environment.
