Avaya J169 User manual

Using Avaya J169/J179 IP Phone SIP in a
Call Center
Release 2.0
Issue 1
April 2018

© 2018, Avaya Inc.
All Rights Reserved.
Note
Using a cell, mobile, or GSM phone, or a two-way radio in close
proximity to an Avaya IP telephone might cause interference.
Documentation disclaimer
“Documentation” means information published in varying mediums
which may include product information, operating instructions and
performance specifications that are generally made available to users
of products. Documentation does not include marketing materials.
Avaya shall not be responsible for any modifications, additions, or
deletions to the original published version of Documentation unless
such modifications, additions, or deletions were performed by or on
the express behalf of Avaya. End User agrees to indemnify and hold
harmless Avaya, Avaya's agents, servants and employees against all
claims, lawsuits, demands and judgments arising out of, or in
connection with, subsequent modifications, additions or deletions to
this documentation, to the extent made by End User.
Link disclaimer
Avaya is not responsible for the contents or reliability of any linked
websites referenced within this site or Documentation provided by
Avaya. Avaya is not responsible for the accuracy of any information,
statement or content provided on these sites and does not
necessarily endorse the products, services, or information described
or offered within them. Avaya does not guarantee that these links will
work all the time and has no control over the availability of the linked
pages.
Warranty
Avaya provides a limited warranty on Avaya hardware and software.
Refer to your sales agreement to establish the terms of the limited
warranty. In addition, Avaya’s standard warranty language, as well as
information regarding support for this product while under warranty is
available to Avaya customers and other parties through the Avaya
Support website: https://support.avaya.com/helpcenter/
getGenericDetails?detailId=C20091120112456651010 under the link
“Warranty & Product Lifecycle” or such successor site as designated
by Avaya. Please note that if You acquired the product(s) from an
authorized Avaya Channel Partner outside of the United States and
Canada, the warranty is provided to You by said Avaya Channel
Partner and not by Avaya.
“Hosted Service” means an Avaya hosted service subscription that
You acquire from either Avaya or an authorized Avaya Channel
Partner (as applicable) and which is described further in Hosted SAS
or other service description documentation regarding the applicable
hosted service. If You purchase a Hosted Service subscription, the
foregoing limited warranty may not apply but You may be entitled to
support services in connection with the Hosted Service as described
further in your service description documents for the applicable
Hosted Service. Contact Avaya or Avaya Channel Partner (as
applicable) for more information.
Hosted Service
THE FOLLOWING APPLIES ONLY IF YOU PURCHASE AN AVAYA
HOSTED SERVICE SUBSCRIPTION FROM AVAYA OR AN AVAYA
CHANNEL PARTNER (AS APPLICABLE), THE TERMS OF USE
FOR HOSTED SERVICES ARE AVAILABLE ON THE AVAYA
WEBSITE, HTTPS://SUPPORT.AVAYA.COM/LICENSEINFO UNDER
THE LINK “Avaya Terms of Use for Hosted Services” OR SUCH
SUCCESSOR SITE AS DESIGNATED BY AVAYA, AND ARE
APPLICABLE TO ANYONE WHO ACCESSES OR USES THE
HOSTED SERVICE. BY ACCESSING OR USING THE HOSTED
SERVICE, OR AUTHORIZING OTHERS TO DO SO, YOU, ON
BEHALF OF YOURSELF AND THE ENTITY FOR WHOM YOU ARE
DOING SO (HEREINAFTER REFERRED TO INTERCHANGEABLY
AS “YOU” AND “END USER”), AGREE TO THE TERMS OF USE. IF
YOU ARE ACCEPTING THE TERMS OF USE ON BEHALF A
COMPANY OR OTHER LEGAL ENTITY, YOU REPRESENT THAT
YOU HAVE THE AUTHORITY TO BIND SUCH ENTITY TO THESE
TERMS OF USE. IF YOU DO NOT HAVE SUCH AUTHORITY, OR IF
YOU DO NOT WISH TO ACCEPT THESE TERMS OF USE, YOU
MUST NOT ACCESS OR USE THE HOSTED SERVICE OR
AUTHORIZE ANYONE TO ACCESS OR USE THE HOSTED
SERVICE.
Licenses
THE SOFTWARE LICENSE TERMS AVAILABLE ON THE AVAYA
WEBSITE, HTTPS://SUPPORT.AVAYA.COM/LICENSEINFO,
UNDER THE LINK “AVAYA SOFTWARE LICENSE TERMS (Avaya
Products)” OR SUCH SUCCESSOR SITE AS DESIGNATED BY
AVAYA, ARE APPLICABLE TO ANYONE WHO DOWNLOADS,
USES AND/OR INSTALLS AVAYA SOFTWARE, PURCHASED
FROM AVAYA INC., ANY AVAYA AFFILIATE, OR AN AVAYA
CHANNEL PARTNER (AS APPLICABLE) UNDER A COMMERCIAL
AGREEMENT WITH AVAYA OR AN AVAYA CHANNEL PARTNER.
UNLESS OTHERWISE AGREED TO BY AVAYA IN WRITING,
AVAYA DOES NOT EXTEND THIS LICENSE IF THE SOFTWARE
WAS OBTAINED FROM ANYONE OTHER THAN AVAYA, AN AVAYA
AFFILIATE OR AN AVAYA CHANNEL PARTNER; AVAYA
RESERVES THE RIGHT TO TAKE LEGAL ACTION AGAINST YOU
AND ANYONE ELSE USING OR SELLING THE SOFTWARE
WITHOUT A LICENSE. BY INSTALLING, DOWNLOADING OR
USING THE SOFTWARE, OR AUTHORIZING OTHERS TO DO SO,
YOU, ON BEHALF OF YOURSELF AND THE ENTITY FOR WHOM
YOU ARE INSTALLING, DOWNLOADING OR USING THE
SOFTWARE (HEREINAFTER REFERRED TO
INTERCHANGEABLY AS “YOU” AND “END USER”), AGREE TO
THESE TERMS AND CONDITIONS AND CREATE A BINDING
CONTRACT BETWEEN YOU AND AVAYA INC. OR THE
APPLICABLE AVAYA AFFILIATE (“AVAYA”).
Avaya grants You a license within the scope of the license types
described below, with the exception of Heritage Nortel Software, for
which the scope of the license is detailed below. Where the order
documentation does not expressly identify a license type, the
applicable license will be a Designated System License as set forth
below in the Designated System(s) License (DS) section as
applicable. The applicable number of licenses and units of capacity
for which the license is granted will be one (1), unless a different
number of licenses or units of capacity is specified in the
documentation or other materials available to You. “Software” means
computer programs in object code, provided by Avaya or an Avaya
Channel Partner, whether as stand-alone products, pre-installed on
hardware products, and any upgrades, updates, patches, bug fixes,
or modified versions thereto. “Designated Processor” means a single
stand-alone computing device. “Server” means a set of Designated
Processors that hosts (physically or virtually) a software application
to be accessed by multiple users. “Instance” means a single copy of
the Software executing at a particular time: (i) on one physical
machine; or (ii) on one deployed software virtual machine (“VM”) or
similar deployment.
License types
Designated System(s) License (DS). End User may install and use
each copy or an Instance of the Software only: 1) on a number of
Designated Processors up to the number indicated in the order; or 2)
up to the number of Instances of the Software as indicated in the
order, Documentation, or as authorized by Avaya in writing. Avaya
may require the Designated Processor(s) to be identified in the order
by type, serial number, feature key, Instance, location or other
specific designation, or to be provided by End User to Avaya through
electronic means established by Avaya specifically for this purpose.
Shrinkwrap License (SR). You may install and use the Software in
accordance with the terms and conditions of the applicable license
agreements, such as “shrinkwrap” or “clickthrough” license
accompanying or applicable to the Software (“Shrinkwrap License”).
Heritage Nortel Software
“Heritage Nortel Software” means the software that was acquired by
Avaya as part of its purchase of the Nortel Enterprise Solutions
Business in December 2009. The Heritage Nortel Software is the
software contained within the list of Heritage Nortel Products located
at https://support.avaya.com/LicenseInfo under the link “Heritage
Nortel Products” or such successor site as designated by Avaya. For
Heritage Nortel Software, Avaya grants Customer a license to use
Heritage Nortel Software provided hereunder solely to the extent of
the authorized activation or authorized usage level, solely for the
purpose specified in the Documentation, and solely as embedded in,
for execution on, or for communication with Avaya equipment.
Charges for Heritage Nortel Software may be based on extent of
activation or use authorized as specified in an order or invoice.

Copyright
Except where expressly stated otherwise, no use should be made of
materials on this site, the Documentation, Software, Hosted Service,
or hardware provided by Avaya. All content on this site, the
documentation, Hosted Service, and the product provided by Avaya
including the selection, arrangement and design of the content is
owned either by Avaya or its licensors and is protected by copyright
and other intellectual property laws including the sui generis rights
relating to the protection of databases. You may not modify, copy,
reproduce, republish, upload, post, transmit or distribute in any way
any content, in whole or in part, including any code and software
unless expressly authorized by Avaya. Unauthorized reproduction,
transmission, dissemination, storage, and or use without the express
written consent of Avaya can be a criminal, as well as a civil offense
under the applicable law.
Virtualization
The following applies if the product is deployed on a virtual machine.
Each product has its own ordering code and license types. Note,
unless otherwise stated, that each Instance of a product must be
separately licensed and ordered. For example, if the end user
customer or Avaya Channel Partner would like to install two
Instances of the same type of products, then two products of that
type must be ordered.
Third Party Components
“Third Party Components” mean certain software programs or
portions thereof included in the Software or Hosted Service may
contain software (including open source software) distributed under
third party agreements (“Third Party Components”), which contain
terms regarding the rights to use certain portions of the Software
(“Third Party Terms”). As required, information regarding distributed
Linux OS source code (for those products that have distributed Linux
OS source code) and identifying the copyright holders of the Third
Party Components and the Third Party Terms that apply is available
in the products, Documentation or on Avaya’s website at: https://
support.avaya.com/Copyright or such successor site as designated
by Avaya. The open source software license terms provided as Third
Party Terms are consistent with the license rights granted in these
Software License Terms, and may contain additional rights benefiting
You, such as modification and distribution of the open source
software. The Third Party Terms shall take precedence over these
Software License Terms, solely with respect to the applicable Third
Party Components to the extent that these Software License Terms
impose greater restrictions on You than the applicable Third Party
Terms.
T9 Text Input and other products are covered by one or more of the
following patents: U.S. Pat. Nos. 5,187,480,5,818,437, 5,945,928,
5,953,541, 6,011,554, 6,286,064, 6,307,548, 6,307,549, and
6,636,162,6,646,573, 6,970,599; Australia Pat. Nos. 727539,
746674, 747901; Austria Pat. Nos. AT225534, AT221222; Brazil P.I.
No. 9609807-4; Canada Pat. Nos. 1,331,057, 2,227,904,2,278,549,
2,302,595; Japan Pat. Nos. 3532780, 3492981; United Kingdom Pat.
No. 2238414B; Hong Kong Standard Pat. No. HK1010924; Republic
of Singapore Pat. Nos. 51383, 66959, 71979; European Pat. Nos. 1
010 057 (98903671.0), 1 018 069 (98950708.2); Republic of Korea
Pat. Nos. KR201211B1, KR226206B1, 402252; People's Republic of
China Pat. No. ZL96196739.0; Mexico Pat. Nos. 208141, 216023,
218409; Russian Federation Pat. Nos. 2206118, 2214620, 2221268;
additional patent applications are pending
The following applies only if the H.264 (AVC) codec is distributed with
the product. THIS PRODUCT IS LICENSED UNDER THE AVC
PATENT PORTFOLIO LICENSE FOR THE PERSONAL USE OF A
CONSUMER OR OTHER USES IN WHICH IT DOES NOT RECEIVE
REMUNERATION TO (i) ENCODE VIDEO IN COMPLIANCE WITH
THE AVC STANDARD (“AVC VIDEO”) AND/OR (ii) DECODE AVC
VIDEO THAT WAS ENCODED BY A CONSUMER ENGAGED IN A
PERSONAL ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO
PROVIDER LICENSED TO PROVIDE AVC VIDEO. NO LICENSE IS
GRANTED OR SHALL BE IMPLIED FOR ANY OTHER USE.
ADDITIONAL INFORMATION MAY BE OBTAINED FROM MPEG LA,
L.L.C. SEE HTTP://WWW.MPEGLA.COM.
Service Provider
THE FOLLOWING APPLIES TO AVAYA CHANNEL PARTNER’S
HOSTING OF AVAYA PRODUCTS OR SERVICES. THE PRODUCT
OR HOSTED SERVICE MAY USE THIRD PARTY COMPONENTS
SUBJECT TO THIRD PARTY TERMS AND REQUIRE A SERVICE
PROVIDER TO BE INDEPENDENTLY LICENSED DIRECTLY FROM
THE THIRD PARTY SUPPLIER. AN AVAYA CHANNEL PARTNER’S
HOSTING OF AVAYA PRODUCTS MUST BE AUTHORIZED IN
WRITING BY AVAYA AND IF THOSE HOSTED PRODUCTS USE
OR EMBED CERTAIN THIRD PARTY SOFTWARE, INCLUDING
BUT NOT LIMITED TO MICROSOFT SOFTWARE OR CODECS,
THE AVAYA CHANNEL PARTNER IS REQUIRED TO
INDEPENDENTLY OBTAIN ANY APPLICABLE LICENSE
AGREEMENTS, AT THE AVAYA CHANNEL PARTNER’S EXPENSE,
DIRECTLY FROM THE APPLICABLE THIRD PARTY SUPPLIER.
WITH RESPECT TO CODECS, IF THE AVAYA CHANNEL
PARTNER IS HOSTING ANY PRODUCTS THAT USE OR EMBED
THE G.729 CODEC, H.264 CODEC, OR H.265 CODEC, THE
AVAYA CHANNEL PARTNER ACKNOWLEDGES AND AGREES
THE AVAYA CHANNEL PARTNER IS RESPONSIBLE FOR ANY
AND ALL RELATED FEES AND/OR ROYALTIES. THE G.729
CODEC IS LICENSED BY SIPRO LAB TELECOM INC. SEE
WWW.SIPRO.COM/CONTACT.HTML. THE H.264 (AVC) CODEC IS
LICENSED UNDER THE AVC PATENT PORTFOLIO LICENSE FOR
THE PERSONAL USE OF A CONSUMER OR OTHER USES IN
WHICH IT DOES NOT RECEIVE REMUNERATION TO: (I) ENCODE
VIDEO IN COMPLIANCE WITH THE AVC STANDARD (“AVC
VIDEO”) AND/OR (II) DECODE AVC VIDEO THAT WAS ENCODED
BY A CONSUMER ENGAGED IN A PERSONAL ACTIVITY AND/OR
WAS OBTAINED FROM A VIDEO PROVIDER LICENSED TO
PROVIDE AVC VIDEO. NO LICENSE IS GRANTED OR SHALL BE
IMPLIED FOR ANY OTHER USE. ADDITIONAL INFORMATION
FOR H.264 (AVC) AND H.265 (HEVC) CODECS MAY BE
OBTAINED FROM MPEG LA, L.L.C. SEE HTTP://
WWW.MPEGLA.COM.
Compliance with Laws
You acknowledge and agree that it is Your responsibility for
complying with any applicable laws and regulations, including, but not
limited to laws and regulations related to call recording, data privacy,
intellectual property, trade secret, fraud, and music performance
rights, in the country or territory where the Avaya product is used.
Preventing Toll Fraud
“Toll Fraud” is the unauthorized use of your telecommunications
system by an unauthorized party (for example, a person who is not a
corporate employee, agent, subcontractor, or is not working on your
company's behalf). Be aware that there can be a risk of Toll Fraud
associated with your system and that, if Toll Fraud occurs, it can
result in substantial additional charges for your telecommunications
services.
Avaya Toll Fraud intervention
If You suspect that You are being victimized by Toll Fraud and You
need technical assistance or support, call Technical Service Center
Toll Fraud Intervention Hotline at [phone] for the United
States and Canada. For additional support telephone numbers, see
the Avaya Support website: https://support.avaya.com or such
successor site as designated by Avaya.
Security Vulnerabilities
Information about Avaya’s security support policies can be found in
the Security Policies and Support section of https://
support.avaya.com/security.
Suspected Avaya product security vulnerabilities are handled per the
Avaya Product Security Support Flow (https://
support.avaya.com/css/P8/documents/100161515).
Downloading Documentation
For the most current versions of Documentation, see the Avaya
Support website: https://support.avaya.com, or such successor site
as designated by Avaya.
Contact Avaya Support
See the Avaya Support website: https://support.avaya.com for
product or Hosted Service notices and articles, or to report a problem
with your Avaya product or Hosted Service. For a list of support
telephone numbers and contact addresses, go to the Avaya Support
website: https://support.avaya.com (or such successor site as
designated by Avaya), scroll to the bottom of the page, and select
Contact Avaya Support.

Regulatory Statements
Japan Statements
Class B Statement
This is a Class B product based on the standard of the VCCI Council.
If this is used near a radio or television receiver in a domestic
environment, it may cause radio interference. Install and use the
equipment according to the instruction manual.
Denan Power Cord Statement
Danger:
Please be careful of the following while installing the
equipment:
• Please only use the connecting cables, power cord, and
AC adapters shipped with the equipment or specified by
Avaya to be used with the equipment. If you use any
other equipment, it may cause failures, malfunctioning,
or fire.
• Power cords shipped with this equipment must not be
used with any other equipment. In case the above
guidelines are not followed, it may lead to death or
severe injury.
本製品を安全にご使用頂くため、以下のことにご注意ください。
•接続ケーブル、電源コード、AC アダプタなどの部品は、必ず
製品に同梱されております添付品または指定品をご使用くだ
さい。添付品指定品以外の部品をご使用になると故障や動作
不良、火災の原因となることがあります。
•同梱されております付属の電源コードを他の機器には使用し
ないでください。上記注意事項を守らないと、死亡や大怪我
など人身事故の原因となることがあります。
México Statement
The operation of this equipment is subject to the following two
conditions:
1. It is possible that this equipment or device may not cause
harmful interference, and
2. This equipment or device must accept any interference,
including interference that may cause undesired operation.
La operación de este equipo está sujeta a las siguientes dos
condiciones:
1. Es posible que este equipo o dispositivo no cause
interferencia perjudicial y
2. Este equipo o dispositivo debe aceptar cualquier
interferencia, incluyendo la que pueda causar su operación
no deseada.
Power over Ethernet (PoE) Statement
This equipment must be connected to PoE networks without routing
to the outside plant.
U.S. Federal Communications Commission (FCC) Statements
Compliance Statement
The changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate
the equipment.
To comply with the FCC RF exposure compliance requirements, this
device and its antenna must not be co-located or operating to
conjunction with any other antenna or transmitter.
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received,
including interferences that may cause undesired
operation.
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designated to provide reasonable protection against
harmful interferences in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interferences to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for
help.
Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth
for an uncontrolled environment . This equipment should be installed
and operated with minimum distance of 8 in or 20 cm between the
radiator and your body. This transmitter must not be co-located or
operating in conjunction with any other antenna or transmitter.
EU Countries
This device when installed complies with the essential requirements
and other relevant provisions of the EMC Directive 2014/30/EU,
Safety LV Directive 2014/35/EU, and Radio Equipment Directive
2014/53/EU. A copy of the Declaration may be obtained from http://
support.avaya.com or Avaya Inc., 4655 Great America Parkway,
Santa Clara, CA 95054–1233 USA.
General Safety Warning
• Use only the Avaya approved Limited Power Source power
supplies specified for this product.
• Ensure that you:
- Do not operate the device near water.
- Do not use the device during a lightning storm.
- Do not report a gas leak while in the vicinity of the leak.
Trademarks
The trademarks, logos and service marks (“Marks”) displayed in this
site, the Documentation, Hosted Service(s), and product(s) provided
by Avaya are the registered or unregistered Marks of Avaya, its
affiliates, its licensors, its suppliers, or other third parties. Users are
not permitted to use such Marks without prior written consent from
Avaya or such third party which may own the Mark. Nothing
contained in this site, the Documentation, Hosted Service(s) and
product(s) should be construed as granting, by implication, estoppel,
or otherwise, any license or right in and to the Marks without the
express written permission of Avaya or the applicable third party.
Avaya is a registered trademark of Avaya Inc.
All non-Avaya trademarks are the property of their respective owners.
Linux® is the registered trademark of Linus Torvalds in the U.S. and
other countries.

Contents
Chapter 1: Introduction............................................................................................................ 7
Purpose.................................................................................................................................. 7
Chapter 2: Phone Icons and display ...................................................................................... 8
Call center related icons........................................................................................................... 8
Agent status line display ....................................................................................................... 10
Incoming calls display............................................................................................................ 10
Message Waiting Indicator..................................................................................................... 11
Chapter 3: Getting started...................................................................................................... 12
Logging in as an agent........................................................................................................... 12
Logging out as an agent......................................................................................................... 13
Agent work modes and states................................................................................................ 13
Chapter 4: Call Center Agents operations............................................................................ 15
Activating After Call Work................................................................................................... 15
Activating Auxiliary Work........................................................................................................ 15
Activating Interruptible Auxiliary Work..................................................................................... 16
Activating Auto In.................................................................................................................. 17
Activating Manual In.............................................................................................................. 17
Chapter 5: Call Center phone opertions............................................................................... 19
Answering and ending a call................................................................................................... 19
Handling a call by using MDA................................................................................................. 19
Stroke counts........................................................................................................................ 20
Sending Stroke Counts.................................................................................................... 20
Call Work Codes................................................................................................................... 21
Sending Call Work Codes................................................................................................ 21
Queue Stats.......................................................................................................................... 22
Viewing Queue Stats....................................................................................................... 22
Enabling wireless headset bidirectional signaling..................................................................... 23
Presence.............................................................................................................................. 23
Presence icons............................................................................................................... 23
Viewing the Presence status of your contacts.................................................................... 24
Changing your Presence status........................................................................................ 25
Enabling SAC when DND is active.......................................................................................... 25
Sending Stroke Counts.......................................................................................................... 26
Sending Call Work Codes...................................................................................................... 26
Vu Stats................................................................................................................................ 27
Viewing Vu Stats............................................................................................................. 27
Supervisor assist................................................................................................................... 28
Viewing ASAI UUI................................................................................................................. 28
Call observation.................................................................................................................... 29
April 2018 Using Avaya J169/J179 IP Phone SIP in a Call Center 5
Comments on this document? [email protected]

Activating or deactivating call observation............................................................................... 29
Assisting an agent on an observed call................................................................................... 30
Contents
April 2018 Using Avaya J169/J179 IP Phone SIP in a Call Center 6
Comments on this document? [email protected]

Chapter 1: Introduction
Purpose
This document describes how to use Avaya J100 Series IP Phones in a call center environment. It
also describes about various CC Elite features and their usability in a call center environment.
Please note that only Avaya J169/J179 IP Phone support CC Elite feature.
April 2018 Using Avaya J169/J179 IP Phone SIP in a Call Center 7
Comments on this document? [email protected]

Chapter 2: Phone Icons and display
Call center related icons
The icons of J169/J179 IP phone in a call center setup look similar. The J179 IP phone displays a
combination of colored and grayscale icons, but the J169 IP phone displays only grayscale icons.
The following table lists the icons of J179 IP phone.
Icon Icon name Where it
appears
Description
After Call
Work
Agent Status
line
The phone displays this icon when you activate
ACW.
Use this state when you are performing any after
call-related work, such as filling in paperwork after
an ACD call.
Pending ACW Top Line
display
The phone displays this icon when you activate
ACW when you are active on a call.
Aux Work Agent Status
line
The phone displays this icon when you activate Aux
Work.
Enter this state when you are performing non-ACD
activities such as taking a break, or placing an
outgoing call. You may need to enter a Reason
Code for entering the Aux Work state if this
requirement is configured by your system
administrator.
Pending Aux Top Line
display
The phone displays this icon when you activate Aux
Work while you are active on a call.
Available Agent Status
line
You are available for any incoming call.
The phone displays this icon when you are not
active on a call, in ACW, or in Aux Work.
Pending
Available
Top Line
display
The phone displays this icon when you are
changing your state to Available from Aux Work or
ACW and you are active on a call.
Forced
Logout
Top Line
display
The phone displays this icon when Forced Logout is
active for your Agent ID.
Table continues…
April 2018 Using Avaya J169/J179 IP Phone SIP in a Call Center 8
Comments on this document? [email protected]

Icon Icon name Where it
appears
Description
Forced
Logout
Override
Top Line
display
The phone displays this icon if you activate Forced
Logout Override.
Pending
Logout
Top Line
display
The phone displays this icon if you press the Log
Out button while you are active on a call or when
the Forced Logout time arrives and you are active
on an ACD call.
Alerting icon Agent Status
line
The phone displays this icon when you receive an
incoming call. When you receive an ACD or DAC
call, the icon displays the respective text, ACD or
DAC, horizontally beside the bell.
On call Agent Status
line
The phone displays this icon when you are active
on a call. When you receive an ACD or DAC call,
the icon displays the respective text, ACD or DAC,
horizontally.
If you are active on an ACD call, the On ACD call
icon is displayed, otherwise, the On non-ACD call
icon is displayed.
Held call Agent Status
line
The phone displays this icon when you have placed
a call on hold. When you place an ACD or DAC call
on hold, the icon displays the respective text, ACD
or DAC, vertically.
Queue Stats Agent
Information
line
The phone displays this icon when you activate
Queue Stats.
The clock icon appears before the oldest call time
and the calls icon appears before the number of
calls in the queue.
Time in
Queue
Threshold
warning
Queue Stats
feature button
The phone displays this icon to indicate when the
time threshold for the oldest call in the queue has
been reached.
Call threshold
warning
Queue Stats
feature button
The phone displays this icon when the number of
calls in the queue has reached the maximum
configured by your system administrator.
Collected
Digits
Information
Agent Status
line
If the incoming call has collected digits information,
the phone displays this icon before the digits.
Collected digits are digits that the caller entered
before reaching you.
Call center related icons
April 2018 Using Avaya J169/J179 IP Phone SIP in a Call Center 9
Comments on this document? [email protected]

Agent status line display
The Agent Status line of the phone screen displays the current agent work mode, for example idle,
active, held or attending incoming calls.
Use this chart as a guide to possible agent status line display .
• ACD=Automatic Call Distribution
• ACW=After Call Work
• Auto=Auto In
• Aux=Auxiliary Work state
• DAC=Direct Agent Call
• Man=Manual In
• RC=Reason Code #
Agent Work Mode Agent Status icon Description
Auto or Man You are ready to receive DAC or ACD calls.
Auto or Man You have an incoming ACD call.
Auto or Man You have an incoming DAC call.
Auto or Man You are on an ACD call.
Auto or Man You are on a DAC call.
Auto or Man You have an ACD call on hold.
Auto or Man You have a DAC on hold.
Incoming calls display
An incoming call displays the information about the call type as configured for your system.
VDN information
According to the vector programming configuration for your system, an incoming call may traverse
multiple VDNs(Vector Directory Number) or stay within the original VDN that received them.
Note:
A Vector Directory Number (VDN) is a contact number in CM that is used as a point of entry of
a call into a Call Center. In many cases, it is the mapping of an 1–800 telephone number that
a caller dials to access the services provided by a Call Center.
If the calls traverse multiple VDNs, one of these VDNs is configured as the active VDN for the call.
The active VDN controls what information is displayed on the phone that receives the call.
Phone Icons and display
April 2018 Using Avaya J169/J179 IP Phone SIP in a Call Center 10
Comments on this document? [email protected]

Your phone displays the following information: “caller_ID info→ VDN_name”, where “caller_ID
info” is the calling party identification, if available, and “VDN_Name” is the administered name of
the active VDN before delivery to you. The active VDN for an unanswered redirected call, along
with a Call Redirected (CR) indicator, is displayed for an incoming call, as is the case for calls that
are received from Routing On No Answer (RONA) redirection.
ASAI UUI
When you receive a call with User-to-User Information (UUI), the UUI Info feature button is lit on
the phone screen. When you press the UUI Info key, the UUI icon is displayed, followed by the
UUI information. The UUI icon is used to distinguish UUI information from other call information,
such as collected digits.
Collected digits
If collected digits are associated with the incoming call, the digits are displayed on the Agent
Status line, without requiring any action on your part. The Info icon is displayed, followed by the
collected digits information.
When this information is cleared from the Agent Status line is dependent on your system
configuration.
Incoming call ring alert type
• All internal ACD or DAC calls rings with an internal alert type.
• All external ACD or DAC calls rings with an external alert type.
• All internal ACD or DAC priority calls rings with a priority alert type.
• All phones while receiving a supervisor assist call rings with priority alert.
Message Waiting Indicator
An illuminated red LED in the upper-right corner of your phone and the Message Button on the
phone faceplate indicate you have unopened voice mail messages. If Visual Alerting is enabled,
the corner LED also flashes when you receive an incoming call. Depending on your system
configuration, the message waiting indicators indicate messages either for the phone extension, or
for the Agent LoginID after agent login. When configured for Agent LoginID, the message waiting
indications are for the agent when the agent is logged in. Immediately after agent login, the screen
displays MWI is indicated for the Agent ID or MWI is indicated for the
extension.
Message Waiting Indicator
April 2018 Using Avaya J169/J179 IP Phone SIP in a Call Center 11
Comments on this document? [email protected]

Chapter 3: Getting started
Logging in as an agent
Before you begin
To log in as an agent, your extension must be registered to the Avaya Aura network and you must
have your agent ID and password.
Procedure
1. Press Main menu, and scroll to Features.
2. Press one of the following:
•Select
•OK
3. Scroll to Agent Login, and press Select.
4. Type your following details:
•Agent ID
•Password
5. Press one of the following:
•Enter
•OK
6. In the Features screen, to view your skills, press
Result
The phone displays the following information:
• Whether Message Wait Indicator is configured for your Agent ID, or for the extension.
• Your assigned agent skills.
• Agent skills that is disabled due to the completion of predetermined system limit
April 2018 Using Avaya J169/J179 IP Phone SIP in a Call Center 12
Comments on this document? [email protected]

Logging out as an agent
Before you begin
Your system administrator can configure Reason Codes as “Forced” which means a Reason Code
must be entered upon Agent Log Out.
Procedure
1. Press Main menu, and scroll to Features.
2. Press one of the following:
•Select
•OK
3. If configured by your system administrator, enter the Reason Code for logout.
4. Press one of the following:
•Enter
•OK
Agent work modes and states
The Agent Status line shows your current work mode and state.
The agent states are:
State Description
Available This state is automatically assigned when you are available to receive
ACD calls. With Auto In, you are returned to Available after each call is
released. With Manual In, you must press Manual In to return to the
available state.
Aux Work You are placed in the Auxiliary Work state after agent login without a
specified work mode. You must change to Auto In or Manual In work
mode to become available to receive incoming call center calls and to
select your mode of operation. You can change back to Auxiliary Work to
indicate you are not available to receive call center calls; for example,
when you want to take a break. Depending on how your system is
administered, you might be prompted to enter a Reason Code when
changing to Aux Work
Interruptible Aux Work Interruptible Aux Work mode notifies the agents in the Aux work mode
with an interruptible reason code (RC) to become available. When the
configured threshold exceeds, the phone receives a visual as well as
audio indication of a full ring cycle.
Table continues…
Logging out as an agent
April 2018 Using Avaya J169/J179 IP Phone SIP in a Call Center 13
Comments on this document? [email protected]

State Description
After Call Work Switch to ACW to perform after-call work, such as completing a call-
related form. The call distribution system automatically changes your
agent state to ACW if you are in Manual-In mode.
You may also enter this state automatically when you are in Auto-In mode,
if your system administrator has configured automatic ACW for a preset
time period after call completion.
On Call This state is automatically assigned when you are active on a call. If you
are active on an ACD call, the “On-ACD Call” icon is displayed; otherwise,
the “On non-ACD Call” icon is displayed.
Forced Logout This state is assigned at a specified time determined by your system
administrator. The Forced Logout icon is displayed on the top line only if
the administrator has assigned a logout time for you. If you are not on a
call, you are logged out of the ACD regardless of which agent state you
are in.
Logout Override You can invoke this state if you want to continue working after your
scheduled logout time. The Logout Override icon is displayed on the top
line only if you have invoked to override the administered Forced Logout
before the scheduled time.
When an ACD call is received, the work mode changes from Aux Work to Auto In or Manual In if
ACD call is received.
Pending states are assigned whenever you request a state change while active on a call. For
example, you request to change to an Aux Work state while active on a call. When the call is
released, the pending state change become effective immediately.
Getting started
April 2018 Using Avaya J169/J179 IP Phone SIP in a Call Center 14
Comments on this document? [email protected]

Chapter 4: Call Center Agents operations
Activating After Call Work
About this task
You can activate After Call Work at any time while you are logged in as an agent. If After Call
Work is activated on a call, the phone indicates the pending status of the After Call Work when the
call is released.
Procedure
1. Press Main menu, and scroll to Features.
2. Press one of the following:
•Enter
•OK
3. From the Features list, scroll to After Call Work.
4. Press one of the following:
•Enter
•OK
Result
The After Call Work icon appears on the Agent Status Line.
Activating Auxiliary Work
About this task
Use this procedure to notify the system that you are unavailable to attend any call.
Before you begin
Ensure that you specify a reason by entering a Reason Code.
Procedure
1. Press Main menu, and scroll to Features.
April 2018 Using Avaya J169/J179 IP Phone SIP in a Call Center 15
Comments on this document? [email protected]

2. Press one of the following:
•Select
•OK
3. Scroll to Aux Work.
4. Press one of the following:
•Select
•OK
5. (Optional) If your system administrator has assigned you with a forced reason code, enter
the Reason Code.
6. Press one of the following:
•Select
•OK
Result
One of the following icon displays on the screen:
• The Aux Work icon displays on the Agent Status followed by the Reason Code.
• The Aux Work Pending icon displays on the Top followed by the Reason Code.
Activating Interruptible Auxiliary Work
About this task
Use this procedure to notify agents in Aux Work mode when the configured threshold exceeds.
Before you begin
Ensure that you specify a reason by entering a Interruptible Reason Code.
Procedure
1. Press Main menu, and scroll to Features.
2. Press one of the following:
•Select
•OK
3. Scroll to Interruptible Aux Work.
4. Press one of the following:
•Select
•OK
Call Center Agents operations
April 2018 Using Avaya J169/J179 IP Phone SIP in a Call Center 16
Comments on this document? [email protected]

5. (Optional) If your system administrator has assigned you with a forced reason code, enter
the Interruptible Reason Code.
6. Press one of the following:
•Select
•OK
Activating Auto In
About this task
The Auto In work mode enables you to go back to the Automatic Call Distribution (ACD) available
queue as soon as you end an ongoing call.
Note:
In most configurations, either the Auto In feature or the Manual In feature is available, but not
both.
Procedure
1. Press Main menu, and scroll to Features.
2. Press one of the following:
•Enter
•OK
3. From the Features list, scroll to Auto In.
4. Press one of the following:
•Enter
•OK
Result
The Manual and Available icons appear on the Agent Status line.
Activating Manual In
About this task
In an active on a call, use this procedure to make your status available to service the ACD queue.
When you are in Manual In mode, the system automatically changes your status to After Call
Work (ACW) as soon as you end the ongoing call.
Activating Auto In
April 2018 Using Avaya J169/J179 IP Phone SIP in a Call Center 17
Comments on this document? [email protected]

Note:
In most configurations, either the Auto In feature or the Manual In feature is available, not
both.
Before you begin
Ensure that depending on your provisioning, you must enter a Stroke Count or Call Work Code
before being allowed to enter the manual-in mode.
Procedure
1. Press Main menu, and scroll to Features.
2. Press one of the following:
•Select
•OK
3. Scroll down to Manual In.
4. Press one of the following:
•Select
•OK
5. (Optional) To go back to the ACD available queue, press Manual In mode again.
Result
The Manual and Available icons appear on the Agent Status line.
Call Center Agents operations
April 2018 Using Avaya J169/J179 IP Phone SIP in a Call Center 18
Comments on this document? [email protected]

Chapter 5: Call Center phone opertions
Answering and ending a call
About this task
When you are logged in, available, and receive an incoming ACD call, the phone displays a string
of up to 16 digits on the Agent Information line, if collected digits are associated with the call.
Procedure
1. When you receive an incoming call, you can:
• Press Answer to answer the call.
• Press Ignore to silence the alerting without answering the call.
2. Press Release to end the ongoing call.
Result
If the incoming call has collected digits information, it is automatically displayed on the Agent
Information line. The Information icon appears before the digits.
If the incoming call has UUI information associated with it, the UUI Info button is lit. When you
press the UUI Info button, the phone displays the UUI information on the Agent Information line,
with the UUI icon appearing before the call information. The UUI information replaces the collected
digits information for a short period of time before returning to display the collected digits
information.
When you receive an incoming call, the phone uses the Vector Directory Number (VDN) name
feature and displays certain information about the caller on the phone display screen.
To use a headset to answer the calls, connect the headset to the phone, and press the Headset
button. The handset is deactivated and the Headset button is lit.
Note:
If you press the Release softkey to end the call, the light on the headset button might turn off.
You can still use the headset to answer the next call.
Handling a call by using MDA
Before you begin
Ensure that the system administrator activates the option for your extension.
April 2018 Using Avaya J169/J179 IP Phone SIP in a Call Center 19
Comments on this document? [email protected]

Procedure
1. Answer or initiate a call from the first phone.
2. Press Bridge on the first phone to switch to the second phone.
The bridged call appears on the second MDA phone. However, limited service icon might
appear briefly if your MDA phone joining the call has a different signalling mode address
family. This will disappear automatically after the MDA phone joining the call switches and
starts using the existing calls signalling mode address family.
Stroke counts
Your administrator can define up to nine different customer-related events using keys 0 through 9
by using Stroke Counts feature.
Note:
Stroke Count 0 is used for tracking any audio quality issues. It can be entered while in any
agent state or work mode as long as you are logged in as an agent.
Use these pre-defined keys to report the number of times that a particular event occurs. On a
single call, you can send any of the configured stroke counts and repeat them as many times as
the incident occurs.
To enter a stroke count, you must be logged in and be in one of the following states:
• Active state on an ACD or DAC call.
• ACW state after disconnecting from a call.
• Timed ACW state after disconnecting from a call.
If you are not in any of these states, the phone displays INVALID STATE on the Top Line and the
Stroke Count information is not sent. As well, the LED associated with this feature or the touch
phone equivalent will flutter.
Your Feature screen displays Stroke Count (#), where # is the number from 0 to 9 that your
system administrator has defined for specific customer events.
Related links
Sending Stroke Counts on page 20
Sending Stroke Counts
About this task
Use this procedure to send the Stroke Count information to the CC Elite server.
Call Center phone opertions
April 2018 Using Avaya J169/J179 IP Phone SIP in a Call Center 20
Comments on this document? [email protected]
