EA713MN Product Guide
Table of Contents
1. Scope & Product Outline
2. Features
3. Hardware
4. Software
5. Firmware
6. ID Specifications
7. Reliability
1


















Russia: IDSolution LLC, [phone], www.idsolution.ru AVerMedia®Technologies, Inc. Product Guide
1. Scope & Product Outline
This document describes the detailed specifications and design parameters of Xavier
Carrier Board with Multiple Video Sources Support. AVerMedia internal product model
name is EA713MN and current PCB revision is A. It can operate with NVIDIA Xavier
module to build up a high performance embedded system. EA713MN is fully compliance
with RoHS. All components and all production procedures have already followed current
RoHS rule to produce.
2. Features
Carrier Board Feature List
Connection to J ets on Module
699-pin (11x65) Board-Board Connector
Storage
Micro SD Card Slot
USB
Micro USB (For Install JetPack) https://developer.nvidia.com/jetpack
2 x USB 3.1 Gen1 Type A (Host only)
Wired Network
2 x Gigabit Ethernet (RJ45 Connector w/LEDs)
M.2 Key E Connector
PCIe X1 Lane, USB 2.0
I2S, UART, I2C, Control
M.2 Key M Connector
1 x PCIe X4 Lane, Control
2 x PCIe X4 Lane (Share Mini Card Bandwidth)
PCIe (Mini Card)
4 x full-height miniPCIe expandability of connecting AVerMedia frame grabbers.
(Share 2 x M.2 Slot Bandwidth)
HDMI Type A
HDMI 2.0 output up to 3840 x 2160 p60
Audio
Microphone input
Speaker output
Controller
CAN Bus
RS485
Expansion Header
40-pin (2x20) header
I2C, SPI, UART, I2S, CAN , D-MIC
2









AVerMedia®Technologies, Inc. Product Guide
UI & Indicators
Power & Recovery Buttons
LEDs: Power On/Off Indication
Debug/Serial
Serial Port Signals (UART, 1x4 header)
Mis cellaneous
SOM Fan Connector: 12V, PWM & Tach
M.2 Fan Connector: 5V
Mini-54 MCU for power on control
Power
DC Jack: 9V-15V or ATX power 24 P
RTC Battery
3. Hardware
3.1 Key Component List
Table 1
Top View
U61
U57
J1
U55
Bottom View
3

AVerMedia®Technologies, Inc. Product Guide
U59
U32 U43
:
Table 2:
Locations Descriptions of Components
J1 SOCKET_699PIN_for NVIDIA Jetson Xavier System-on-Module
U57 3Port-12Lane PCI Express Gen 2 Switch
U59 3Port-12Lane PCI Express Gen 2 Switch
U61 6-Port/ 8-Lane PCI Express Gen 2 Switch
U55 Intel Ethernet Controller
U43 Integrated 10/ 100/ 1000 Mbps Energy Efficient Ethernet Transceiver
U32 USB 3.1 Gen 1 Hub Controller
4

AVerMedia®Technologies, Inc. Product Guide
3.2 Block Diagram
Figure1. Block Diagram.
5

AVerMedia®Technologies, Inc. Product Guide
3.3 Board Dimensions
Table 3:
Form Factor Customization
PCB Size 170 mm x 220mm
Thickness 1.6 mm
3.4 I/O Connector
Table 4: (Please refer to mechanical drawing for more detail)
J26 DC jack x1 OD:5.5/ 2.5 with lock
J8 USB 2.0 Micro B (For Install JetPack)
J9 Micro SD card slot x1
J4 HDMI 2.0 Output (Type A) from Xavier
J13-1(top)
J13-2(down)
External J5-1, J5-2
Gigabit Ethernet X1 (RJ45) from Ethernet
Controller
Gigabit Ethernet X1 (RJ45) from Ethernet PHY
Transceiver
USB3.1 Gen1 type A x2 from USB 3.1 Gen 1
Hub Controller
J10-1(top) Microphone input X1 (3.5mm Phone Jack)
J10-2(down) Speaker output X1 (3.5mm Phone Jack)
J14
GPIO Expand 40pin
(2x20 1.27mm pitch Pin header)
I/O
Connector
BSW1 Power Button with LED
BSW3 Recovery Button with LED
BJ2 RS485 (3 circuits eurostyle terminal block)
BJ3 CAN Bus (3 circuits eurostyle terminal block)
J27 ATX 24Pin (ATX Power input)
J3 RTC power input wafer (RTC Battery)
Internal
J22
J23
J24
J25
J7
J19
J20
J6
J2
full-height minicard slot, MiniPCIe 0 PCI
Express Gen2.0 from PCI Express Switch
full-height minicard slot, MiniPCIe 1 PCI
Express Gen2.0 from PCI Express Switch
full-height minicard slot, MiniPCIe 2 PCI
Express Gen2.0 from PCI Express Switch
full-height minicard slot, MiniPCIe 3 PCI
Express Gen2.0 from PCI Express Switch
2280 M.2 KEY M PCI Express Gen4.0 (PCIe X4
Lane) from Xavier
2280 M.2 KEY M PCI Express Gen2.0 (PCIe X4
Lane) from PCI Express Switch
2280 M.2 KEY M PCI Express Gen2.0 (PCIe X4
Lane) from PCI Express Switch
2230 M.2 KEY E PCI Express Gen4.0 (PCIe X1
Lane) from Xavier
FAN 1*4pin 1.25mm pitch wafer for Xavier
(Joint Tech _A1250WV-04PNLNT1N00B)
6

AVerMedia®Technologies, Inc. Product Guide
J21
FAN 1*2pin 1.25mm pitch wafer for M.2 device
(MOLEX 53047-0210)
SOM Fan connector (J2) Pin Descriptions
Wafer type : Joint Tech_A1250WV-04PNLNT1N00B
Pin# Signal Name Usage/Description Type/Dir Default
1 GND Ground Ground
2 VCC 12V Power Supply Power
3 FAN_TACH Fan Tachometer signal Input
4 FAN_PWM Fan Pulse Width Modulation signal Output
M.2 Fan connector (J21) Pin Descriptions
Wafer Type : MOLEX_53047-0210
Pin# Signal Name Usage/Description Type/Dir Default
1
2
VCC 5V Power Supply Power
GND Ground Ground
7








AVerMedia®Technologies, Inc. Product Guide
GPIO Expand (J14) Pin Descriptions
The carrier board includes a 40-pin (2x20, 1.27mm pitch) Expansion Header (J14).
The connector used on the carrier board is a CHAMPWAY CB25-G4024H010-03.
The GPIO Level Shift voltage is fixed on 3.3V.
The expansion connector includes various audio & control interfaces including:
I2S(See Note)
Audio Clock/ Control
Digital Microphone IF
I2C (x2) (See Note)
SPI (See Note)
UART (See Note)
CAN
Table 4:
J14
GPIO Expand 40pin
(2x20 1.27mm pitch Box header)
Note: The GPIO Level Shift voltage is fixed on 3.3V
Table 5:
Wafer type : CHAMPWAY CB25-G4024H010-03
Pi
n
Signal Name
Device Directly
Connected to Signal
Associated Jetson
Module Pin Name
Usage/Description
Type/
Direction
GPIO Max
Drive or
Power Pin
Current
Capability
Note
s
1 +5V_SYSTEM TPS51220 5V Supply - Main 5.0V Supply Power 1A 1
2 +3V3_SYSTEM TPS51220 3.3V - Main 3.3V Supply Power 1A 1
Supply
3 +5V_SYSTEM TPS51220 5V Supply - Main 5.0V Supply Power 1A 1
4 I2C_GP5_DAT_3V3 2SK3019 I2C_GP5_DATA General I2C #5 Data (3.3V) Bidir/ OD 3.3mA 2
5 GND - - Ground Ground -
6 I2C_GP5_CLK_3V3 2SK3019 I2C_GP5_CLK General I2C #5 Clock (3.3V) Bidir/ OD 3.3mA 2
7 UART1_TX_3V3 TXB0108 UART1_TX UART #1 Transmit Output 20uA 3
8 MCLK05_3V3 TXB0108 AUDIO_MCLK Audio Master Clock Bidir 20uA 3
(1.8/ 3.3V)
9 UART1_RX_3V3 TXB0108 UART1_RX UART #1 Receive Input 20uA 3
10 GND - - Ground Ground -
11 I2S2_CLK_3V3 TXB0108 I2S2_CLK Audio I2S #2 Clock Bidir 20uA 3
12 UART1_RTS_3V3 TXB0108 UART1_RTS# UART #1 Request to Send Output 20uA 3
13 GND - - Ground Ground -
14 PWM01_3V3 TXB0108 GPIO32 Pulse Width Modulation #1 Bidir 20uA 3
15 GPIO8_AO_DMIC_IN_DA Xavier GPIO8 Digital Mic Input Data(3.3V) Input 3.3mA 5
T
16 GPIO27_PWM2_3V3 TXB0108 GPIO27 GPIO/ Pulse Width
Modulation #2
17 GPIO35_PWM3_3V3 TXB0108 GPIO35 GPIO/ Pulse Width
Modulation #3
Bidir 20uA 3
Bidir 20uA 3,7
18 +3V3_SYSTEM TPS51220 3.3V - Main 3.3V Supply Power 1A 1
Supply
19 GND - - Ground Ground -
20 SPI1_MOSI_3V3 TXB0108 SPI1_MOSI SPI #1 Master Out/ Slave In Bidir 20uA 3
(1.8/ 3.3V)
21 GPIO17_40HEADER_3V3 TXB0108 GPIO17 GPIO Bidir 20uA 3
22 SPI1_MISO_3V3 TXB0108 SPI1_MISO SPI #1 Master In/ Slave Out
(1.8/ 3.3V)
23 SPI1_CS0_3V3 TXB0108 SPI1_CS0# SPI #1 Chip Select #0
Bidir 20uA 3
Bidir 20uA 3
(1.8/ 3.3V)
24 SPI1_SCK_3V3 TXB0108 SPI1_CLK SPI #1 Shift Clock (1.8/ 3.3V) Bidir 20uA 3
25 SPI1_CS1_3V3 TXB0108 SPI1_CS1# SPI #1 Chip Select#1 Bidir 20uA 3
(1.8/ 3.3V)
26 GND - - Ground Ground -
27 I2C_GP2_CLK_3V3 2SK3019 I2C_GP2_CLK General I2C #2 Clock (3.3V) Bidir/ OD 3.3mA 2
8

AVerMedia®Technologies, Inc. Product Guide
28 I2C_GP2_DAT_3V3 2SK3019 I2C_GP2_DATA General I2C #2 Data (3.3V) Bidir/ OD 3.3mA 2
29 GND - - Ground Ground -
30 CAN0_RX Xavier CAN0_DIN CAN #0 Data In (3.3V) Input 3.3mA 5
31 GPIO9_CAN1_GPIO0 Xavier GPIO9 Digital Mic Input Clock (3.3V) Bidir 3.3mA 5
32 CAN0_TX Xavier CAN0_DOUT CAN #0 Data Out(3.3V) Output 3.3mA 5
33 GND - - Ground Ground -
34 CAN1_DOUT Xavier CAN1_DOUT CAN #1 Data Out (3.3V) Output 3.3mA 5
35 UART1_CTS_3V3 TXB0108 UART1_CTS# UART #1 Clear to Send Input 20uA 3
36 I2S2_FS_3V3 TXB0108 I2S2_FS AUDIO I2S #2 Left/ Right Clock Bidir 20uA 3
37 I2S2_SDIN_3V3 TXB0108 I2S2_SDIN Audio I2S #2 Data in Input 20uA 3,7
38 CAN1_DIN Xavier CAN1_DIN CAN #1 Data In (3.3V) Input 3.3mA 5
39 I2S2_SDOUT_3V3 - TXB0108 -I2S2_SDOUT Audio I2S #2 Data Out Output 20uA 3,7
40 GND - - Ground Ground -
Legend Ground Power N/ A N/ A Reserved Unassigned on carrier board
Notes:
1. This is current capability per power pin.
2. These pins are connected to Tegra signals through either an I2C or FET level shifter.
3. Due to the design of these level translators, the output drivers are very weak so they can be overdriven by another connected device
output for bidirectional support.
4. These pins connect to a SN74LVC4T245 buffer. The voltage level at the header pins is selectable
5. These pins are directly connected to Xavier. The max drive that meets full Data Sheet VOL/ VOH is 1mA. 2mA drive is supported at
restricted VOL/ VOH levels. See the associated OEM Product Design Guide Pads section for details.
6. In the Type/ Dir column, Output is to Expansion Module. Input is from Expansion Module. Bidir is for Bidirectional signals.
7. The direction indicated matches that indicated in the reference design schematics. These signals can be bidirectional.
3.5 Ability of Power Provision
The ability of carrier board to provide power is listed in Table 5.
Table 5:
Symbol Min. Max. Total Power
DC Jack Input 9V 15V 60W(Max.)
3.6 Thermal Specifications
The case temperature of key components is listed in Table 6.
Table 6:
Components
Components Case
Temperature Specifications
3Port-12Lane PCI Express Gen 2 Switch (U57) Tcase = 95℃
3Port-12Lane PCI Express Gen 2 Switch (U59) Tcase = 95℃
6-Port/ 8-Lane PCI Express Gen 2 Switch (U61) Tcase = 95℃
Intel Ethernet Controller I210 (U55) Tcase = 95℃
Integrated 10/ 100/ 1000 Mbps Energy Efficient
Ethernet Transceiver (U43)
Tcase = 95℃
USB 3.1 Gen 1 Hub Controller (U32) Tcase = 95℃
9

AVerMedia®Technologies, Inc. Product Guide
3.8 EMI Specifications
EMI/ EMS test specification are listed in Table 7
Table 7：
Criteria Specification Reference
EMI EN55032 standard CE
EMS EN55024 standard CE
3.9 Buttons and Indicators
Buttons (Switches)
Button Description Usage
BSW1
BSW3
Power button & power
indication
Recovery button &
Status indication LED
1. Used to power system up if off, or power down
if on. If held for >7 seconds, will force a full system
power cycle.
2. Indicates when the carrier board is powered on
1. Used to enter Force Recovery Mode. Button is
held down while either system is first powered on,
or by pressing & releasing reset button while
Recovery button is pressed.
2. Status indication RGB LED (This is customized
by the user)
10

AVerMedia®Technologies, Inc. Product Guide
Gigabit Ethernet (LAN Port LEDs)
Top(B)
Activity LED(left) Link/Speed LED(right)
Status Description State Description
Green Blinking Data transmission or
receiving is occurring
Off No data transmission or
receiving is occurring
Down(A)
Yellow 1000M link Speed
Green 100M link Speed
Activity LED(left) Link/Speed LED(right)
Status Description State Description
Green Data transmission or Yellow 1000M link Speed
receiving is occurring
Off No data transmission or
receiving is occurring
Yellow 100M link Speed
Blinking
4. Software
BSP (board support package) : NVIDIA JETSON JETPACK
5. Firmware
Item Location Firmware Version Noted
Mini54 U54 19051118
Auto Power on
Function
11

12
AVerMedia®Technologies, Inc. Product Guide
6. ID Specifications

AVerMedia®Technologies, Inc. Product Guide
7. Reliability
Table 8:
Criteria Specification Reference
Low Temperature
High Temperature
High Humidity
Operating:-10 C/48 hrs
Storage: -20 C/24 hrs
Operating: 70 C/48 hrs
Storage: 85 C /24 hrs
Operating: 70C, 95%RH/48 hrs
Storage: 85C, 95%RH/24 hrs
IEC 68-2-1
IEC 68-2-2
IEC 68-2-30
Cold Start Operating: -10 C/1hr IEC 68-2-1
Hot Start Operating: 70C, 95%RH/1hr IEC 68-2-2
Package Drop According to the ISTA 2A test standard ISTA 2A
Russia: IDSolution LLC, [phone], www.idsolution.ru
