Avery Dennison Monarch 9419 User manual

PACKET
REFERENCE
MANUAL
Avery Dennison®
Monarch®
9419 Printer
TC9419PR Rev. AB 3/18
© 2016 Avery Dennison Corp.
All rights reserved.

Each product and program carries a respective written warranty, the only warranty on which the
customer can rely. Avery Dennison Corp. reserves the right to make changes in the product, the
programs, and their availability at any time and without notice. Although Avery Dennison Corp.
has made every effort to provide complete and accurate information in this manual, Avery
Dennison Corp. shall not be liable for any omissions or inaccuracies. Any update will be
incorporated in a later edition of this manual.
2016 Avery Dennison Corp. All rights reserved. No part of this publication may be reproduced,
transmitted, stored in a retrieval system, or translated into any language in any form by any
means, without the prior written permission of Avery Dennison Corp.
Trademarks
Monarchand MPCL are trademarks of Avery Dennison Retail Information Services LLC.
Avery Dennison® is a trademark of Avery Dennison Corp.

Table of Contents i
TABLE OF CONTENTS
GETTING STARTED............................................................................................1-1
About This Manual ....................................................................................................1-1
Before You Begin......................................................................................................1-1
Creating an MPCLII Format Packet............................................................................. 1-2
Sample Batch Packet.............................................................................................. 1-2
Designing a Format...................................................................................................1-3
Determining the Print Area......................................................................................... 1-3
Using Supply Layout Grids...................................................................................... 1-4
About Field Types ..................................................................................................1-4
Using the Format Worksheet...................................................................................... 1-4
Filling in the Format Worksheet ............................................................................... 1-4
CONFIGURING THE PRINTER.............................................................................2-1
Setting Serial Communication Parameters .................................................................. 2-1
Using MPCLII Conventions ........................................................................................ 2-1
MPCLII Punctuation................................................................................................ 2-1
Standard Syntax Guidelines .................................................................................... 2-2
Using Online Configuration Packets............................................................................ 2-3
Configuration Packet Header................................................................................... 2-3
Configuration Syntax Guidelines.............................................................................. 2-4
Making Print Adjustments .......................................................................................... 2-5
Defining the System Setup Packet.............................................................................. 2-5
Defining the Supply Setup Packet............................................................................... 2-6
Defining the Print Control Packet ............................................................................... 2-7
Defining the Monetary Formatting Packet.................................................................... 2-8
Defining the Control Characters Packet ...................................................................... 2-9
Resetting Control Characters ................................................................................ 2-10
Using Immediate Commands ................................................................................. 2-10
Enabling Immediate Commands............................................................................. 2-10
Sending Immediate Commands.............................................................................. 2-10
Defining the Communication Settings Packet............................................................. 2-12
Defining the Backfeed Control Packet....................................................................... 2-13
Clearing Packets from Memory................................................................................. 2-13
Using the Font Packet ............................................................................................. 2-14
Uploading Format Header Information....................................................................... 2-16
DEFINING FIELDS ..............................................................................................3-1
Defining the Format Header....................................................................................... 3-1

ii Packet Reference Manual
Defining Text Fields .................................................................................................. 3-2
Defining Bar Code Fields........................................................................................... 3-7
Defining Non-Printable Text Fields ........................................................................... 3-18
Defining Constant Text Fields .................................................................................. 3-19
Defining Line Fields ................................................................................................ 3-23
Line Types........................................................................................................... 3-23
Defining Box Fields ................................................................................................. 3-25
DEFINING FIELD OPTIONS .................................................................................4-1
Applying Field Options .............................................................................................. 4-1
Combining Field Options......................................................................................... 4-1
Restrictions............................................................................................................ 4-1
Using Option 1 (Fixed Data)....................................................................................... 4-2
Using Option 4 (Copy Data) ....................................................................................... 4-3
Merging Fields .......................................................................................................4-3
Sub-Fields .............................................................................................................4-4
Using Option 30 (Pad Data) ....................................................................................... 4-4
Sample Use for Padding ......................................................................................... 4-4
Using Option 31 (Calculate Check Digit) ..................................................................... 4-4
Using Option 42 (Price Field)..................................................................................... 4-5
Using Option 50 (Bar Code Density) ........................................................................... 4-5
Using Option 51 (PDF417 Security/Truncation)............................................................ 4-6
Using Option 52 (PDF417 Width/Length)..................................................................... 4-7
Using Option 60 (Incrementing/Decrementing Fields)................................................... 4-7
Fixing the First Number in the Incrementing Sequence.............................................. 4-7
Using Option 61 (Re-image Field)............................................................................... 4-8
Using Check Digits....................................................................................................4-9
Sum of Products Calculation ................................................................................. 4-10
Sum of Digits Calculation...................................................................................... 4-11
CREATING GRAPHICS........................................................................................5-1
Overview of Bitmapped Images .................................................................................. 5-1
Determining a Method............................................................................................. 5-1
Designing Bitmapped Images..................................................................................... 5-1
Special Considerations ........................................................................................... 5-2
Using the Hex Method............................................................................................. 5-2
Using the Run Length Encoding Method................................................................... 5-4
Determining How to Store the Image .......................................................................... 5-5
Using Volatile RAM................................................................................................. 5-5
Using Temporary Storage........................................................................................ 5-5

Table of Contents iii
Using a Memory Card ............................................................................................. 5-5
Using Flash............................................................................................................ 5-5
Creating a Graphic Packet......................................................................................... 5-6
Positioning the Graphic Image................................................................................. 5-6
Defining the Graphic Header...................................................................................... 5-7
Creating Bitmap Fields .............................................................................................. 5-8
Creating Next-Bitmap Fields ...................................................................................... 5-9
Creating Duplicate Fields........................................................................................... 5-9
Sample Hex Graphic Packet..................................................................................... 5-10
Sample Run Length Graphic Packet.......................................................................... 5-10
Placing the Graphic in a Format ............................................................................... 5-11
Defining the Graphic Field ....................................................................................... 5-12
Sample Bitmap Graphic Image ................................................................................. 5-12
PRINTING...........................................................................................................6-1
Downloading Files..................................................................................................... 6-1
About Batch Packets (Print Jobs) ............................................................................... 6-2
Defining the Batch Header......................................................................................... 6-2
Defining the Batch Control Field................................................................................. 6-3
Defining Batch Data Fields ........................................................................................ 6-4
Using Special Characters in Batch Data...................................................................... 6-4
Sample Batch Data with Special Characters ............................................................. 6-4
Merged or Sub-Fields ............................................................................................. 6-4
Incrementing Fields ................................................................................................ 6-4
Entering Batch Data for QR Code............................................................................... 6-5
Structured Append Mode......................................................................................... 6-6
Structured Append QR Code Packet ........................................................................ 6-6
Downloading Methods ............................................................................................... 6-7
Sequential Method.................................................................................................. 6-7
Batch Method.........................................................................................................6-7
Batch Quantity Zero Method.................................................................................... 6-7
Modifying Formats..................................................................................................... 6-8
Optional Entry Method ............................................................................................ 6-8
Creating Batch Files for Downloading ......................................................................... 6-8
DIAGNOSTICS ....................................................................................................7-1
Printing a Test Label ................................................................................................. 7-1
Using Dump Mode..................................................................................................... 7-2
If the PC and Printer Are Not Communicating.............................................................. 7-2
Resetting the Printer ................................................................................................. 7-2

iv Packet Reference Manual
Calling Technical Support.......................................................................................... 7-3
PRINTER OPTIMIZATION ....................................................................................8-1
Adjusting the Print Quality ......................................................................................... 8-1
Reducing Imaging Time............................................................................................. 8-2
General Format Tips and Hints................................................................................... 8-3
SAMPLES .......................................................................................................... A-1
Sample Codabar Packet ............................................................................................A-1
Sample Code 16K Packet ..........................................................................................A-1
Sample Code 39 Packet ............................................................................................A-1
Sample Code 93 Packet ............................................................................................A-2
Sample Code 128 Packet...........................................................................................A-2
Sample Data Matrix Packets ......................................................................................A-2
Square Data Matrix Packet......................................................................................A-2
Rectangular Data Matrix Packet...............................................................................A-3
Sample Data Matrix with Function 1.........................................................................A-3
Sample EAN Packet ..................................................................................................A-3
Sample I 2 of 5 with Barrier Bar Packet ......................................................................A-3
Sample MaxiCode Packets.........................................................................................A-4
Mode 0 (Obsolete) Sample......................................................................................A-5
Mode 2 Sample ......................................................................................................A-6
Mode 3 Sample ......................................................................................................A-7
Sample MSI Packet...................................................................................................A-8
Sample PDF417 Packet.............................................................................................A-8
Sample POSTNET Packet..........................................................................................A-8
Sample Quick Response Packets ...............................................................................A-8
Sample QR Code Packet.........................................................................................A-9
Sample QR Code with URL Packet...........................................................................A-9
Structured Append QR Code Packet ........................................................................A-9
Sample UPCA Format Packet.....................................................................................A-9
Sample Batch Packet..............................................................................................A-9
Sample Receipt Format ...........................................................................................A-10
Sample Label..........................................................................................................A-10
FONTS............................................................................................................... B-1
Bitmap Font Information ............................................................................................B-4
Monospaced Font Magnification .................................................................................B-4
Proportional Font Magnification..................................................................................B-4
Scalable Font Information..........................................................................................B-5
TrueType Font Information.........................................................................................B-5

Table of Contents v
Downloading TrueType Fonts ..................................................................................B-5
Using International Fonts...........................................................................................B-6
Selecting a Symbol Set...........................................................................................B-6
International Font Sample .......................................................................................B-7
Licensing Fonts ........................................................................................................B-7
Locating the Font Number in a Font Packet.................................................................B-7
SYMBOL SETS/CODE PAGES............................................................................ C-1
Supported Symbol Sets and Code Pages ....................................................................C-1
Selecting a Symbol Set or Code Page......................................................................C-1
Using Code 128 Function Codes ................................................................................C-1
Entering Extended Characters....................................................................................C-1
Using International Character Sets/Code Pages........................................................C-2
Internal Symbol Set ................................................................................................C-2
ANSI Symbol Set....................................................................................................C-3
Bold Character Set .................................................................................................C-3
OCRA Character Set...............................................................................................C-4
Code Page 437 (Latin U.S.).....................................................................................C-4
Code Page 850 (Latin 1) .........................................................................................C-5
Code Page 852 (Latin 2) .........................................................................................C-5
Code Page 855 (Russian) .......................................................................................C-6
Code Page 857 (IBM Turkish)..................................................................................C-6
Code Page 860 (MS-DOS Portuguese).....................................................................C-7
Code Page 1250 (Latin 2) .......................................................................................C-7
Code Page 1251 (Cyrillic) .......................................................................................C-8
Code Page 1252 (Latin 1) .......................................................................................C-8
Code Page 1253 (Greek).........................................................................................C-9
Code Page 1254 (Turkish).......................................................................................C-9
Code Page 1255 (Hebrew) ....................................................................................C-10
Code Page 1256 (Arabic)......................................................................................C-10
Code Page 1257 (Baltic) .......................................................................................C-11
Code Page 1258 (Vietnamese) ..............................................................................C-11
ASCII to Hexadecimal Conversion Chart ...................................................................C-12
Binary to Hex Conversion Chart ...............................................................................C-15
Dot to Run Length Encoding Chart ...........................................................................C-17
ON (Black) Dots ...................................................................................................C-17
Off (White Dots) ...................................................................................................C-17
FORMAT DESIGN TOOLS .................................................................................. D-1
Online Configuration Worksheet.................................................................................D-2

vi Packet Reference Manual
Batch Worksheet.......................................................................................................D-3
Check Digit Worksheet ..............................................................................................D-4
Supply Layout Grids (English)....................................................................................D-5
Supply Layout Grids (Metric)......................................................................................D-6
Supply Layout Grids (Dots)........................................................................................D-7
Format Worksheet.....................................................................................................D-8
Sample Format Worksheet.........................................................................................D-9
GLOSSARY........................................................................................................G-1

Getting Started 1-1
GETTING STARTED
This manual provides the necessary information to design, write and print a
Monarch® Printer Control Language II (MPCLII) format on the Avery Dennison® Monarch® 9419
printer. The 9419 printer supports both thermal direct and thermal transfer printing. Review the
printer information in the Equipment Manual or Online Mode System Administrator’s Guide.
Note: Formats created for the 9416 and 9416XL printer print on the 9419 printer.
About This Manual
You do not need to be a programmer to use this manual, but you must be familiar with creating
text files and using basic commands. This chapter describes how to
♦create and download a sample MPCLII packet.
♦use the Supply Layout Grid and Format Worksheet.
♦categorize data into field types and select fonts to use in a format.
See “Defining Text Fields” in Chapter 3 for a list of available fonts for the printer. See Chapter 4,
“Defining Field Options,” for a list of available options for the printer.
Before You Begin
1. Connect the printer to the host. Refer to the Online Mode System Administrator’s Guide for
more information.
2. Load supplies in the printer. Refer to the Equipment Manual for more information.
3. Turn on the printer.
4. Set the communication parameters and configure the printer. The communication parameters
at the printer must match those at the host. See Chapter 2, “Configuring the Printer,” for more
information.
5. Design the format. See “Designing a Format” for more information.
6. Download the format to the printer. See Chapter 6, “Printing,” for more information.
1

1-2 Packet Reference Manual
Creating an MPCLII Format Packet
A format defines which fields appear and where the fields are printed on the label. The printer
requires this information in a special form, using Monarch® Printer Control Language II (MPCL).
This section describes how to create a sample MPCLII format packet.
For detailed information about the format header, text, constant text, and bar code fields, see
Chapter 3, "Defining Fields." For information about batch packets, see Chapter 6, “Printing.”
1. Type the following format header in any text editor:
{F,25,A,R,E,200,200,"FMT-25" |
2. Type the following constant text field:
C,140,40,0,1,2,1,W,C,0,0,"SAMPLE FORMAT",0 |
3. Type the following bar code field:
B,1,12,F,85,40,1,2,40,5,L,0 |
4. Type the following text field:
T,2,18,V,50,50,1,1,1,1,B,L,0,0,1 | }
This is an MPCLII format packet. Next, create a batch packet before printing the format.
5. Type the following batch header, after the text field line:
{B,25,N,1 |
6. Type the following bar code data:
1,"02802811111" |
7. Type the following text field data:
2,"TEXT FIELD" | }
8. Save the file as SAMPLE.FMT.
9. Type MODE COM1:9600,N,8,1 at the Command prompt when using serial communications.
This sets the communication parameters at the host. These communication parameters must
match those at the printer. See “Setting Serial Communication Parameters,” in Chapter 2, or
the host’s documentation for more information.
10.Type COPY SAMPLE.FMT COM1. The following 2 inch by 2 inch
label prints:
{F,25,A,R,E,200,200,"Fmt 25" |
C,140,40,0,1,2,1,W,C,0,0,"SAMPLE FORMAT",0 |
B,1,12,F,85,40,1,2,40,5,L,0 |
T,2,18,V,50,50,1,3,1,1,B,L,0,0,0 | }
Sample Batch Packet
{B,25,N,1 |
1,"02802811111" |
2,"TEXT FIELD" | }

Getting Started 1-3
Designing a Format
Determine the supply size, fonts, bar codes, and graphics being used. Labels are available from
Avery Dennison in a wide variety of sizes. The application and the amount of printed data
determine the supply size. Contact your Account Manager or Technical Support for more
information.
1. Draw a rough sketch of the label. Note any areas that are preprinted on the label, such as a
logo.
2. Identify the field types that appear on the label. See “About Field Types” for more
information.
3. Decide which fonts to use. When working with fonts, there are three considerations: font
appearance, font size (scalable or bitmapped), and font spacing (monospaced or
proportional). The TrueType® scalable font, EFF Swiss Bold™ (font 50) is standard on the
printer. See Appendix B, “Fonts,” for samples of each font.
4. Fill out the Format Worksheet. See “Using the Format Worksheet” for more information.
At this point, send the design to the printer. To do this:
5. Create a format packet, based on the completed format worksheet. See Chapter 3, “Defining
Fields,” for more information.
6. Download the format packet to the printer. See Chapter 6, “Printing,” for more information.
Keep backup copies of the format, batch data, check digit, and graphic packets.
Determining the Print Area
The “bottom” (or leading edge) is the edge that exits the printer first. The 0,0 point is at the
bottom left corner of the label. The print area varies, depending on the size of your supply. When
designing formats, the following non-print zone is recommended: 0.04 inches at the top and
bottom of the label.
Unit of Measure Min. Supply
(Wid x Len)
Max. Supply
(Wid x Len)
Min. Print Area
(Wid x Len)
Max. Print Area
(Wid x Len)
English
(1/100 inch) 75 x 20 440 x 1000 75 x 20 425 x 1000
Metric (1/10 mm) 191 x 50 1120 x 2540 191 x 50 1079 x 2540
Dots (203) 152 x 41 893 x 2030 152 x 41 863 x 2030
Dots (300) 225 x 60 1320 x 3000 225 x 60 1275 x 3000
Note: Peel mode minimum feed length is 1.0 inches (25 mm) and the maximum feed length is
6.0 inches (152 mm).
The minimum feed width with 300 dpi is 4.17 inches (106mm)
Use the following formulas to convert inches to dots and metric:
Dots = inches x 203 (or 300 dots per inch)
Metric (1/10mm) = inches x 254
English (1/100 inch) = 100 x (dots/203) or (dots/300)
Dots = Metric (1/10 mm) x 799/1000 (or 1181/1000)
300 dpi depends on the printer.

1-4 Packet Reference Manual
Using Supply Layout Grids
A supply layout grid contains measurement markers, which help accurately position information
on the label. Decide whether to design formats using English, Metric, or Dot measurements.
English The English grid is measured in 1/100 inches.
Metric The Metric grid is measured in 1/10 millimeters (mm).
Graphic The printer uses dots to print images on a label. The printhead has 203 dots per inch
(dpi) or an optional 300 dots per inch printhead.
Choose English or Metric units when designing formats to use with different printers. English or
Metric units allow more direct use of formats on printers with different density printheads.
Supply layout grids are in Appendix D, “Format Design Tools.”
About Field Types
Decide what information to print on the format from the following categories.
Field Type Description Examples
Text Contains letters, numbers, or symbols. item number, item description,
department number, price, date
Non-
Printable
Text
Holds data for use later, such as for
merging into another field. The printer
does not print non-printable text fields.
city, state,
and zip code to be included in
a bar code
Bar Code Used for printing bar codes that can be
scanned. item or serial numbers, zip codes, information not visible to customers
Constant
Text Prints fixed characters that do not change. company name, company address
Line or Box Highlights or separates items. line marking out the regular price, border
around the supply
Graphic Contains a bitmap image or a
compliance label overlay. logos
All of the above field types except graphics are discussed in Chapter 3. See Chapter 5,
“Creating Graphics” for information on including graphics in the format.
Using the Format Worksheet
The Format Worksheet is divided into sections that list the field types. Each section has boxes to
fill in with parameters that define a format. A format worksheet is included in Appendix D,
“Format Design Tools.”
Filling in the Format Worksheet
Decide what type of field to use on the label.
1. Make a copy of the Format Worksheet.
2. Define the Format Header. See “Defining the Format Header” in Chapter 3 for more
information.
3. Define all non-printable text fields before defining printable ones. See “Defining Non-
Printable Text Fields” in Chapter 3 for more information.
4. Define options (copy data, pad data, etc.) as needed. See Chapter 4, “Defining Field Options”
for more information.

Configuring the Printer 2-1
CONFIGURING THE PRINTER
This chapter discusses how to
♦set communication parameters.
♦upload the printers configuration or font information.
♦configure the printer using online configuration packets.
♦use immediate commands to control the printers operation at any time.
Setting Serial Communication Parameters
For serial communications, the communication settings at the printer must match those at the
host.Use the Communication Settings Packet to set these parameters.
Use the MODE command (from the Command prompt) to set communication values on the PC.
For example,MODE COM1:9600,N,8,1
Sets the host’s communication values to: 9600 baud, no parity, an 8 bit word length, 1 stop bit.
Using MPCLII Conventions
Follow these guidelines with MPCLII.
MPCLII Punctuation
Use the following default symbols when creating MPCLII packets:
Character Decimal
Value Description
{ (left bracket) 123 start of header
} (right bracket) 125 end of header
| (vertical bar) 124 field separator*
, (comma) 044 parameter separator
"ABC" (quotation
marks) 034 Quotation marks enclose character strings. Empty quotes (" ") identify null strings or unused fields.
‘comment’
(single quotation
marks)
039 Grave accents enclose comments. Any data enclosed in grave
accents is ignored. Do not embed comments within a quoted
string. Grave accents are also used to reject mainframe data.
*The field separator is the split vertical bar (|). The decimal value is 124. To enter this
character, use the Shift key plus the Split Vertical Bar key on the computer’s keyboard.
Depending on the text editor, it may appear as a solid vertical bar or as a split vertical bar.
2

2-2 Packet Reference Manual
Standard Syntax Guidelines
When creating MPCLII packets:
♦Begin each packet with a start of header ({).
♦End each packet with an end of header (}).
♦Define no more than 1000 fields in a format. Each | indicates one field. However, options are
not counted as fields. The actual number of fields a format can have may be less, because the
number of fields is limited by the available memory.
♦The field number (0to 999) must be unique. Start at 1, instead of 0.
♦Do not use a field number more than once per format.
♦Define all fields in the order to image/print them. The printer does not print in field number
order.
♦Separate all parameters with a Parameter Separator (,).
♦End each field with a Field Separator (|).
♦Enter all information in CAPITAL letters, except words or phrases within quotation marks.
♦Include all parameters for a field unless documented as optional.
♦Define non-printable text fields before the field to which they apply.
♦Define options immediately after the field to which they apply.
♦Multiple options can be used with most fields. Options can be used in any combination except
as noted with each definition. Options are processed in the order they are received.
♦Keep in mind that proportionally spaced fonts need wider fields than monospaced fonts. For
variable field data, use a letter W to determine the maximum field size.
♦Do not place a new line (return) or any other non-printing character within a field definition.
However, a carriage return or line break after each | makes formats easier to read.
T,1,20,V,30,30,1,1,1,1,B,C,0,0,0 |
T,2,10,V,50,30,1,1,1,1,B,C,0,0,0 |
♦Spaces are ignored, except within character strings.
♦Indenting options improves readability of formats.
T,1,18,V,30,30,1,1,1,1,B,C,0,0,0 |
R,42,1 |
♦Use a tilde (~) followed by a 3-digit ASCII code in a quoted string to send function codes or
extended characters or send the 8-bit ASCII code.
Modify formats and fields with the optional entry method. See “Optional Entry Method” in Chapter
6 for more information.

Configuring the Printer 2-3
Using Online Configuration Packets
Use online configuration packets to change the printer’s settings. Send an individual
configuration packet or a single packet containing all the configuration packets. Supply all
parameters for each packet. Leave the parameters blank that do not need to change. For
example,
{I,A,,,,1 | }
prints a slashed zero and uses the last sent online System Setup parameters.
Make a copy of the online configuration worksheet in Appendix D, “Format Design Tools,” and
save the original. Packets A-M are listed on the worksheet.
When turning off the printer, all the information in the online configuration packets is saved and
used when the printer is turned back on. After changing the printer’s configuration, resend the
format, batch, or graphic to the printer before the changes take effect.
Configuration Packet Header
Always include an I, immediately after the left bracket {and before the packet identifier (A, B, C,
etc.). The Iparameter identifies the data stream as a configuration packet.
Note: Include the Iparameter with each packet if sending them individually. Include it only at
the beginning of a data stream if sending multiple packets.
Use this syntax to create online configuration packets:
Syntax
{Start of Header
I,Configuration Header
1 - 9 optional records
A, parameter 1...parameter 5 | System Setup
B, parameter 1...parameter 6 | Supply Setup
C, parameter 1...parameter 7 | Print Control
D, parameter 1...parameter 3 | Monetary Formatting
E, parameter 1...parameter 9 | Control Characters
F, parameter 1...parameter 5 | Communication Settings
} End of Header
Syntax for single packet
{Start of Header
I,Configuration Header
A, parameter 1...parameter 5 | System Setup
}End of Header
Add a configuration to RAM or specify units for supply, print, margin, and cut positions. If using
the optional parameters with the Ipacket, any online configuration packets following the split
vertical bar (|) must specify distances using the selected units. However, the test labels display
the units in dots, even if entered in English or Metrics units.

2-4 Packet Reference Manual
Syntax {header,ID#,action,device | }
1. header Constant I.
2. ID# ID. Use 0.
3. action Action. Options:
AAdd configuration.
UUpload User Configuration.
4. device Storage Device. Use R(Volatile RAM).
5. units Units. (Optional parameter.) Options:
EEnglish
MMetric
GDots
Example {I,0,A,R,E |
C,0,25,0,0,0 | }
Adds a configuration to volatile RAM and specifies English units. It also uses the default contrast,
moves print 0.25 inches closer to the bottom of the supply and does not change the margin
adjustment, prints at the default print speed, and uses the default printhead width.
If optional parameters are not used, the syntax for the online configuration packets does not
change. For example,
{I,C,0,50,0,0,0 | }
uses the default contrast, moves print 50 dots (0.25) inches closer to the bottom of the supply
and does not change the margin adjustment, prints at the default print speed, and uses the
default printhead width.
Example {I,0,U,R | }
Uploads the printer configuration from volatile RAM and returns the following to the host.
A,0,0,0,0,1 |
B,2,0,0,0,0 |
C,0,0,0,0,0,0 |
D,1,0,2 |
E,"~123~044~034~124~125~126","","~013~010" |
F,3,1,0,0,1 |
The parameters for each packet (A-F) are displayed. See each packet’s description later in this
chapter for more information.
Configuration Syntax Guidelines
When creating a printer configuration packet:
♦Follow the Standard Syntax Guidelines listed at the beginning of this chapter.
♦The first character after the start of header ({) is the configuration header (I).
♦Download multiple configuration packets within one packet or download a single configuration
packet.
♦If changing any of the online configuration packets, resend the format packet to the printer, so
the configuration changes take effect.
♦Include the first five ANSI codes, at a minimum, in the control characters packet.
♦Send configuration packets once per session (each time the printer is turned off and then back
on), not with every format or batch packet.
♦The printer uses the settings from the printer configuration packets until a new configuration
packet is sent; or a setting is adjusted through the printer’s menu.

Configuring the Printer 2-5
Making Print Adjustments
Horizontal and vertical adjustments can be made by adjusting the supply, print, or margin
positions. However, keep in mind the following:
♦Supply adjustments across the width of the supply, such as the margin position, are based in
dots- either 203 dpi or 300 dpi, depending on the printhead density.
♦Supply adjustments for the length of the supply, such as supply position or print adjustment,
are always measured in 1/203 of an inch, regardless of the printhead density.
Defining the System Setup Packet
Use the system setup packet (A) to select the power up mode, display language, print separators
between batches, print a slashed zero, and select the symbol set.
Syntax {I,A,powup_mode,language,sep_on,slash_zero,symbol_set | }
A1. A System Setup Packet
A2. powup_mode Printer’s powerup mode. 0is the default. Options:
0Online mode. Printer is ready to receive data and print.
1Offline mode. Operator can select a format and enter data to print.
A3. language Display Language. Enter 0. The 9419 displays prompts in 31 languages.
Refer to the Online Mode System Administrator’s Guide for more
information.
A4. sep_on Batch Separators. Enter 0. The printer does not print batch separators.
A5. slash_zero Slash Zero. 0is the default. Options:
0Print a standard zero
1Print a zero with a slash through it
A6. symbol_set Symbol Set. 0is the default. Options:
0Internal 9Code Page 1255 (Hebrew)
1ANSI 10 Code Page 1256 (Arabic)
2Code Page 437 (Latin U.S.) 11 Code Page 1257 (Baltic)
3Code Page 850 (Latin 1) 12 Code Page 1258 (Vietnamese)
4Code Page 1250 (Latin 2) 13 DOS Code Page 852 (Latin 2)
5Code Page 1251 (Cyrillic) 14 DOS Code Page 855 (Russian)
6Code Page 1252 (Latin 1) 15 DOS Code Page 857 (IBM Turkish)
7Code Page 1253 (Greek) 16 DOS Code Page 860 (Portuguese)
8Code Page 1254 (Turkish) 19 Unicode
Note: The Standard, Reduced, Bold, OCRA and HR fonts only support
the Internal Symbol Set (0). The CG Triumvirate™ typefaces only
support the ANSI (1) and DOS Code Page 437 (2) and 850 (3)
Symbol Sets. The scalable font (font#50) does not support Code
Page 1256 Arabic (10). Code pages 13-16 and 4-12 are for
downloaded TrueType fonts or the scalable font. Code page 19
requires a downloaded International TrueType font (stored on a
MicroSD card). TrueType fonts are designed to be regionally
specific; therefore, all code pages may not be supported in a given
font. See Appendix C, “Symbol Sets/ Code Pages” for more
information.
Example {I,A,0,0,0,0,0 | }
Powers up the printer in the online mode, displays prompts in English, does not print a separator
after each batch, prints standard zeros (without a slash), and uses the internal symbol set.

2-6 Packet Reference Manual
Defining the Supply Setup Packet
Use the supply setup packet (B) to select supply type, ribbon, feed mode, supply position, and
cut position.
Syntax {I,B,supply_type,ribbon,feed_mode,supply_posn,cut_posn | }
B1. B Supply Setup Packet
B2. supply_type Supply Type. 1is the default. Options:
0Black mark
1Gap/Die Cut
2Continuous (non-indexed)
Use continuous supply in continuous mode.
Print contrast adjustments may be necessary depending on the supply.
See “Defining the Print Control Packet” for more information.
B3. ribbon Ribbon. The printer automatically senses if a ribbon is installed and
switches to thermal transfer mode. 0is the default. Options:
0Ribbon not installed (thermal direct)
1Ribbon installed (thermal transfer)
B4. feed_mode Feed Mode. 0is the default. Options:
0Continuous operation
1On-demand mode
In peel mode, the minimum label length is 1.0 inches (25 mm) and the
maximum is 6.0 inches (152 mm).
B5. supply_posn Supply Position. Adjusts the position of the supply relative to the index
marks in the feed direction. Range: -149 to 300 in 1/203 inch or
-222 to 300 in 1/300 inch. 0is the default. Increase the supply position to
move print up, decrease to move print down on the label. This adjustment
accounts for mechanical tolerances from machine to machine. The supply
position adjustment only needs to be made on the initial machine setup.
You cannot change the supply position while the printer is active.
Changing the supply position affects the print position. Once the supply
position is set, use the print control packet to adjust the printer position.
B6. cut_posn Cut position. Range: -300 to 300 in 1/203 inch. 0is the default. Adjusts
where the tag is cut. The printer adjusts the cut position according to the
black marks on the supply. Your supply may need adjustments. Increase
to move the cut up, decrease to move the cut down.
Example {I,B,0,0,1,10,50 | }
Indicates black mark and thermal direct supply is loaded, causes the printer to operate in on-
demand mode, feeds the supply approximately .05 inches up before printing the format on each
label (10/203 inches), and feeds the supply .25 inches (50/203 inches) before cutting.

Configuring the Printer 2-7
Defining the Print Control Packet
Use the print control packet (C) to set the contrast, print, and margin adjustment, print speed,
and printhead width.
Syntax {I,C,contrast,print_adj,margin_adj,speed_adj,ph_width | }
C1. C Print Control Packet
C2. contrast Print Contrast. Range: -156 to 156. 0is the default. You may need to
adjust this value depending on the type of supplies you are using. To make
the print darker, use increments of 13 (for example, 0, 13, 26, 39, 52, etc.).
To make the print lighter, use increments of -129 (for example, -129, -258,
or -387). You need to use these incremental values to see a difference in
the print contrast. For example, values 1 to 13 produce the same result.
This is true for values -1 to -130. Solid black print cannot exceed 25% of
any given square inch of the supply.
C3. print_adj Print adjustment (position). Adjusts the image’s position on the supply in
the feed direction. Range: -99 to 99 in 1/203 inch for 203 dpi or 1/300 inch
for 300 dpi. 0is the default. Increase the print position to move print up,
decrease to move print down.
C4. margin_adj Margin adjustment (position). Adjusts where the format prints side to side
on the supply. Range: -99 to 99 in 1/203 inch or 1/300 inch for 300 dpi
printers). 0 is the default. Increase the margin position to move print to
the right, decrease to move print to the left. Margin and print position are
format adjustments. They do not affect the supply position.
C5. speed_adj Print Speed in inches per second (ips). 5is the default. Options:
15 the printer prints at 1.5 ips
20 uses a print speed of 2.0 ips
30 uses a print speed of 3.0 ips
40 uses a print speed of 4.0 ips
50 uses a print speed of 5.0 ips
60 uses a print speed of 2.0 ips
70 uses a print speed of 2.0 ips (not for 300 dpi)
80 uses a print speed of 2.0 ips (not for 300 dpi
C6. ph_width Width of the printhead in dots. Use 0.
Example {I,C,0,-20,-10,5,0,0 | }
Uses the default contrast, moves print 0.1 inch closer to the bottom of the supply (20/203 inches)
and .05 inch to the left on the supply (10/203 inches), the printer prints at the default speed (5.0
ips), and uses the default printhead width.

2-8 Packet Reference Manual
Defining the Monetary Formatting Packet
The monetary formatting packet (D) selects the monetary symbols to print for a price field. Use
the monetary formatting packet to select primary and secondary monetary symbols, and
designate the number of digits to appear at the right of a decimal.
Syntax {I,D,cur_sym,secondary,decimals | }
D1. D Monetary Formatting Packet
D2. cur_sym Currency Symbol. 1is the default. Options:
0No symbol 9Finland ( , Markka)
1USA ($, Dollar) 10 Austria ( , Shilling)
2UK (£, Pound) 11 India (Rs, Rupee)
3Japan (¥, Yen) 12 Russian ( , Ruble)
4Germany ( , Deutsche Mark)
5France (F, Franc) 13 Korean ( , Won)
6Spain (P, Peseta) 14 Thai ( , Baht)
7Italy (L., Lira) 15 Chinese (¥, Yuan)
8Sweden (Kr, Krona) 16 Euro ( )
Note: To use these symbols, select the internal symbol set.
D3. secondary Secondary Sign. Secondary symbols only print if at least one decimal
place is used. 0is the default. Options:
0No secondary sign
1Print secondary sign
D4. decimals Number of digits to the right of the decimal. 2is the default. Options:
0No digits
1One digit
2Two digits
3Three digits
Example {I,D,1,1,2 | }
Prints the dollar sign, uses a secondary symbol, and places two digits to the right of the decimal.
