AVGear AVG-MS44-HDBT User manual

AVG-MS-44HDBT
The MS-44HDBT includes 4 HDMI inputs, 4
HDBaseT outputs, 2 local HDMI outputs, 4 de-
embedded stereo audio & 4 de-embedded digital
audio outputs.
Features
Support for 1080P@60Hz &
1080p 3D.
HDCP Compliant and DVI
compatible, supporting HDMI
1.4a & DVI1.0.
Powerful EDID & HDCP
management.
HDBaseT outputs, to transmit
HDMI, IR & RS232 up to 60
meters distance over a Cat5E/6
cable.
Supports PoC which provides
power for all the receivers
connected to the HDBaseT
outputs.
Supports multiple control options,
including front panel buttons,
RS232 and IR.

AVG-MS-44HDBT
PLEASE READ THIS PRODUCT MANUAL CAREFULLY
BEFORE USING THIS PRODUCT.
This manual is only for operation instruction only, and
not to be used in a maintenance capacity. The
functions described in this version are current till
March 2015. Any changes of functions and
operational parameters will be updated in future
manual versions. Please refer to your dealer for the
latest product details.
Version 1.0 1/3/15

AVG-MS-44HDBT
SAFETY OPERATION GUIDE
In order to guarantee the reliable operation of the equipment and safety of the
user, please abide by the following procedures in installation, use and
maintenance:
1. The system must be earthed properly. Please do not use two blade plugs
and ensure the alternating power supply ranges from 100v to 240v and from
50Hz to 60Hz.
2. Do not install the switcher in an environment where it will be exposed to hot
or cold temperatures.
3. This unit will generate heat during operation, please ensure that you allow
adequate ventilation to ensure reliable operation.
4. Please disconnect the unit from mains power if it will be left unused for a
long time.
5. Please DO NOT try to open the casing of the equipment, DO NOT attempt to
repair the unit. Opening the unit will void the warranty. There are high
voltage components in the unit and attempting to repair the unit could result
in serious injury.
6. Do not allow the unit to come into contact with any liquid as that could result
in personal injury and product failure.

AVG-MS-44HDBT
TABLE OF CONTENTS
Introduction ..............................................................................................................1
About the MS-44HDBT.................................................................................1.1
Features.......................................................................................................1.2
What’s in the Box.....................................................................................................2
Product Appearance................................................................................................3
Front View of MS-44HDBT...........................................................................3.1
Rear View of MS-44HDBT............................................................................3.2
Connection with RS232 Communication Port...............................................3.3
Twisted Pair Cable Connection....................................................................3.4
System Connection..................................................................................................4
Usage Precautions.......................................................................................4.1
System Diagram...........................................................................................4.2
Connection Procedure..................................................................................4.3
Connection with AVG-HD300R.....................................................................4.4
Appearance of AVG-HD300R.........................................................4.4.1
POC Solution..................................................................................4.4.2
Application....................................................................................................4.5
System Operations...................................................................................................5
Button Control...............................................................................................5.1
IR Control.....................................................................................................5.2
Usage of IR Remote .......................................................................5.2.1
IR Operations..................................................................................5.2.2
RS232 Control..............................................................................................5.3
RS232 Commands .........................................................................5.3.1
Controlling the MS-44HDBT ...........................................................5.3.2

AVG-MS-44HDBT
Control of 3
rd
Party Devices Locally................................................5.3.3
Bi-Directional RS232 Control..........................................................5.3.4
USB Firmware Updating...............................................................................5.4
Specification.............................................................................................................6
Panel Drawing ..........................................................................................................7
Troubleshooting & Maintenance.............................................................................8

AVG-MS-44HDBT
1. Introduction
1.1 Introduction to the MS-44HDBT
The MS-44HDBT includes 4 HDMI inputs, 4 HDBaseT outputs, 2 local HDMI
outputs, 4 de-embedded stereo audio & 4 de-embedded digital audio outputs.
It enables cross-point switching from any input to any output, and supports high
resolution 1080P, 1080p 3D. HDBaseT output ports can work with the HDMI PoC
Twisted Pair Receiver, to transmit HDMI, IR, RS232 and PoC over a Cat5e/Cat6
cable. Transmission distance is up to 60 meters.
1.2 Features
Support for 1080P@60Hz & 1080p 3D.
HDCP Compliant and DVI compatible, supporting HDMI 1.4a & DVI1.0.
Powerful EDID & HDCP management.
HDBaseT outputs, to transmit HDMI, IR & RS232 up to 60 meters distance over a
Cat5E/6 cable.
Supports PoC which provides power for all the receivers connected to HDBaseT
outputs.
Supports multiple control options, including front panel buttons, RS232and IR.
IR OUT signal switching follows with the video signal, can also be separated from
video switching.
Supports remote control from receiver by IR & RS232.
Supports centralized IR control to control all the remote display devices.
Supports PCM, Dolby, and DTS5.1 surround sound.
LCD indicator shows connection status, switching status, HDCP status, and
output resolution.

AVG-MS-44HDBT
2. What’s in the Box
1 x MS-44HDBT
2 x Mounting ears
10 x Screws
1 x RS232 cable
4 x IR converting cables (12V)
8 x Pluggable Terminal Blocks
4 x Plastic cushions
1 x IR remote
1 x Power adapter (DC 48V)
1 x Power cord
1 x User manual
Note: Please confirm that the product and accessories are all included, if not please
contact your dealer.

AVG-MS-44HDBT
3. Product Appearance
3.1 Front Panel
No.
Name
Description
①Firmware Micro USB port for firmware update.
②
Power
Indicator Illuminates red when power on.
③IR Receiver In-built IR sensor, receive control signal from IR remote.
④LCD Screen Shows real-time system status.
⑤
INPUTS/
Menu buttons
Normal mode: Input buttons, ranging from "1" to "4".
Inquiry mode: Press “AV” and hold for more than 3 seconds to
enter this mode. Dial to change menus, to change
different channels.
⑥Function
buttons

AV
synchr
onous
button: To transfer AV and IR signal
(from IR
OUT port) synchronously by the switcher.
Note: The 4 IR OUT ports correspond with the 4 HDMI INPUT
ports separately.
Example: To transfer both AV and IR signals from Input 1 to
Output 3.
Operation:
Press buttons in this order “Input 1”, “AV”, “Output 3”.

ALL
outputs button: To transfer
one
input to all outputs.
Example: To transfer both AV and IR signals from Input 1 to all
output channels.
Operation:
Press buttons in this order “Input 1”, “ALL”.

EDID
management button: manually capture and
learn
the EDID
data from output device.
Example: Input 2 captures and learns the EDID data from Output
4.
Operation: Press buttons in this order “EDID”, “Input 2”, “Output
4”.
⑦
OUTPUTS
Output
buttons, ranging from "1" to "4"
, correspond to the 4
HDBaseT outputs ports.
With the front control panel, the switcher can be controlled directly by pressing the
buttons in this order: “Input Channel” + “AV” + “Output Channel”
“Input Channel”: Select the number of input channel to be controlled.
“Output Channel”: Select the the number of output channel to be controlled.

AVG-MS-44HDBT
3.2 Rear Panel
No.
Name
Description
①IR ALL IN IR control signal input port, connect with IR receiver, pass
through to all the HDBaseT ports to control remote devices.
②HDMI
INPUTS HDMI input ports, 4 in total, type A female HDMI connector, connect with HDMI input source devices.
③IR OUT
Connect with IR transmitter, to emit the IR signal sent from the
HDBaseT ports of the far-end Receiver. These IR OUTs make
up an IR matrix with the IR INs on the HDBaseT receivers, and
all IR signals can be switched synchronously with the AV
signal, or separately switched.
④OUTPUTS
IR IN
: Connect with IR receiver, fixed IR input for the output,
cannot be switched separately. It makes up an IR bi-directional
transmission with the IR OUT on the corresponding HDBaseT
receiver.
HDMI: HDMI output port, connect with HDMI displayers,
deliver same input signals with HDBaseT ports, split HDMI
output for local monitoring.
COAX: HDMI de-embedded digital audio output.
HDBaseT: Works with HDBaseT receivers, such as the HDMI
twisted pair receiver & HDMI PoC twisted pair receiver. It can
extend AV, IR and RS232 signal to 60m distance. Meanwhile, it

AVG-MS-44HDBT
can provide power for the receivers which support PoC.
RS232: Serial port to communicate with the RS232 port on
corresponding HDBaseT receiver. When controlled by
HDBaseT receiver, the communication protocol must be the
same with the MS-44HDBT.
AUDIO: HDMI de-embedded stereo audio output
⑤ RS232 Serial port for unit control, 9-pin female connector, connects
with control device such as a PC.
⑥ Power
Indicator Illuminates red when powered on.
⑦ 48V DC Connect with 48V DC power adaptor.
⑧ GROUND Connect to grounding, make the unit ground well.
⑨ TCP/IP TCP/IP port for unit control, optional function.
⑩ IR EYE Connect with extended IR receiver, use the IR remote to control
the MS-44HDBT.
3.3 Connection with RS232 Communication Port
The MS-44HDBT can be controlled by a 3
rd
Party control system through the
RS232 communication port. This RS232 communication port is a female 9-pin D
connector. The definition of its pins is listed in the table below.
F5-1. 9HDF
No.
Pin
Function
1 N/C Unused
2 Tx Transmit
3 Rx Receive
4 N/C Unused
5 Gnd Ground
6 N/C Unused
7 N/C Unused
8 N/C Unused
9 N/C Unused

AVG-MS-44HDBT
3.4 Twisted Pair Cable Connection
The cables for HDBaseT ports must be straight-through ones, using T568A or T568B
standard. The connectors can be T568A or T568B, but both sides must be the same.
4. System Connection
4.1 Usage Precautions
1. System should be installed in a clean environment with temperature and humidity
maintained to within equipment specification.
2. All of the power switches, plugs, sockets and power cords should be insulated and
safe.
3. All devices should be connected before power on.
TIA/EIA T568A
TIA/EIA T568B
Pin Cable color Pin Cable color
1 green white 1 orange white
2 green 2 orange
3 orange white
3 green white
4 blue 4 blue
5 blue white 5 blue white
6 orange 6 green
7 brown white 7 brown white
8 brown 8 brown
1st Ground 4--5 1st Ground 4--5
2nd Ground
3--6 2nd Ground
1--2
3rd Group 1--2 3rd Group 3--6
4th Group 7--8 4th Group 7--8

AVG-MS-44HDBT
4.2 System Diagram
4.3 Connection Procedure
Step 1. Connect HDMI source devices (e.g. DVD) to HDMI input ports of the AVG-
MHD44TP with HDMI cables.
Step 2. Connect HDMI displays (e.g. HDTV) to HDMI output ports of the MS-
44HDBT with HDMI cables.
Step 3. Connect speakers/ headphones to AUDIO output ports (3-pin captive screw
connectors).
Step 4. Connect the HDBaseT ports of HDBaseT receiver and the MS-44HDBT with
twisted pair cable
Step 5. Connect the RS232 port (9 pin female D) of the MS-44HDBT with control
device (e.g. PC).
Step 6. Connect the RS232 port of the device to be controlled to the RS232 port of
the HDBaseT Receiver or MS-44HDBT. The control signal can be
transmitted bi-directionally.

AVG-MS-44HDBT
Step 7. MS-44HDBT can be controlled by its built-in IR receiver or the external IR
receiver connected to the IR EYE port. IR signals can be transmitted bi-directionally
between MS-44HDBT’s IR OUT/ IR IN and HDBaseT Receiver’s IR IN / IR OUT.
In this mode, we can control MS-44HDBT remotely with the MHD44TP’s IR
Remote.
Note: The IR IN port has built-in infrared carrier receiver.
Step 8. Connect a DC48V power adaptor to the power port of MS-44HDBT.
4.4 Connection with HD300R
MS-44HDBT can work with HD300R to extend transmission distance up to 70m.
4.4.1 Appearance of HD300R
No.
Name
Description
①ON
Working status indicator
,
blink
s
green
to indicate device processor is
operational.
②LINK
Twisted Pair
l
ink status indicator
, illuminate
s
green when
the
connection is successful.
③OUT
Output indicator, when the connected display works normally, it will
illuminate: stays on when the display supports HDCP and blinks if
not.
④Power Illuminates when power on
⑤ HDBT IN
Connects
with the HDBT
OUT
port of
MS
-
44HDBT
by using a
single
CAT5e/6 cable (60m length in max).
⑥ HDMI OUT
HDMI
output
port, connect with HDMI
display
.
⑦ IR IN
Connect with
the
IR receiver,
the IR signal received from this port
is
available on the MS-44HDBT rear panel.
⑧ IR OUT
Connect with
an
IR
E
mitter
to control end device.
⑨ RS232
Serial port,
connect
s
with the control
terminal to control
the
controlled terminal, supports bi-directional RS232 control between
MS-44HDBTand HD300R.
⑩ DC 24V
Connect with
a DC
24
V
power
adapter
.
(Not
necessary
when
connecting with MS-44HDBT)

AVG-MS-44HDBT
4.4.2 PoC Solution
For convenience, both the MS-44HDBT & HD300R support PoC this eliminates the
need for a power supply for the HD300R. Connect the MS-44HDBT & HD300R as
per the figure below:
4.5 Application
The MS-44HDBT’s performance and transmission distance makes it perfect for use
in the computer realm, security monitoring, big screen displays, conference system,
television, education and banking institutions etc.
5. System Operations
5.1 Button Control
The operation examples are showed in 3.1 Front Panel. Here we make a brief
introduction to the system inquiry operations.
Press and hold the button “AV” for 3 seconds, it will enter into the system inquiry
menu. Use the Left and Right direction buttons to check the previous/next item.
Function Items
Example
Description
Check the
connection status
of inputs
Y means the corresponding port is
connected with input device, N
means not.
Check the
connection status
of outputs
Y means the corresponding port is
connected with output device, N
means not.
Correspondence
between inputs
and outputs
Shows the correspondence
between the 4 inputs and 4 outputs.
Check if the input
is with HDCP
Y means the input signal is with
HDCP, N means not.
Check if the output
is with HDCP
Y means the output signal is with
HDCP, N means not.
Check the output
resolution
Use the UP and DOWN direction
button to check all the 4 output
resolutions.
In
1 2 3 4
Connect Y Y
Y
Y
Out
1 2 3 4
Connect Y Y
N N
Out
1 2 3 4
Input 1 2 3 3
In
1 2 3 4
HDCP Y Y Y N
Out
1 2 3 4
HDCP Y Y Y N
Resolution
Out 1 1920x1080

AVG-MS-44HDBT
5.2 IR Control
By using IR & HDBaseT transmission technology, the MS-44HDBT has the following
IR control options.
Control of the far-end output device from the MS-44HDBT.
Control the local input/output device remotely.
Control the MS-44HDBT locally/remotely.
The MS-44HDBTcan be controlled by its built-in IR receiver or through the IR EYE
port by connecting with an extended IR receiver. It can also be controlled remotely
by a far-end IR device through the twisted pair.
5.2.1 Usage of IR Remote
Input channels, range from 1~4, IR signals are
switched synchronously with HDMI signal
correspondingly.
Menu buttons, button
AV
and
ALL
have the
same function as the front panel. THROUGH:
To transfer the signals directly to the
corresponding output channels
Example: Press “3”, “THROUGH”, the result will
be IN 3OUT 3. Press “ALL”, “THROUGH”, the
result will be: 11, 22, 33, 44
Output channels, range from 1~4.
Each channel has 1 IR IN, 1 COAX, 1
HDBaseT, 1 RS232, and 1 AUDIO output, and
channel No.1 & No.2 has 1 HDMI output.
Standby button, press it to enter / exit standby
mode.

AVG-MS-44HDBT
5.2.2 IR Operations
1) IR Matrix Switching
The 4 “IR OUT” ports make up a 4x4 IR matrix with the “IR IN” ports of the far-end
receivers. See as below:
Control of Local Devices or the MS-44HDBT Remotely
The IR signal is received from a corresponding IR remote, then transferred to the
HDBaseT receiver, then to corresponding zone of the matrix through the twisted pair
and finally transferred to the IR OUT port and received by the controlled device.
Switching Operation:
a) Sending command (reference to 5.3 RS232 Control): [x1]R[x2].
x1: Corresponding to the 4 IR OUT ports of the matrix, The IR transmitter
connected to this port can be placed at the IR receiving area of the output
device or the matrix itself.
x2: Corresponding to the zone number (IR signal transmit to the HDBaseT receiver
and then gets to the HDBaseT port of this zone via the twisted pair)
E.g.: Command “3R2.” means to transfer IR signal received from zone 2 to IR
OUT port 3.
b) Using the IR remote: Input channelbutton IROutput channel
Input channel: the 4 INPUT buttons, corresponding to the 4 IR OUT ports of the
matrix.

AVG-MS-44HDBT
Output channel: the 4 OUTPUT buttons, corresponding to the zone (receive IR
signal from HDBaseT receiver with IR IN port connects with IR receiver) number
of the matrix.
E.g.: Press buttons “3”, “IR”, “1” in order, “3” in OUTPUTS area, “1” in INPUTS
area, to transfer IR signal received from zone 3 to IR OUT port 1.
Note: When switching all the 4 IR input signal channels to a same IR out
channel, it is not able to control the controlled device(s) at the same time.
2) IR Carrier Enforcing
a) Only if the IR receiver connected with HDBaseT receiver has IR carrier, the
received IR signal can be transferred to the IR OUT port of the matrix.
b) Only if the IR receiver connected with IR ALL IN port of the matrix is with IR
carrier, the received IR signal can then be transferred to IR OUT port of the
matrix.
If the IR receiver connected with HDBaseT receiver or IR ALL IN port of the
matrix is not with IR carrier, you need to send the command “%0901.”, and then
you are able to transfer the IR signal to IR OUT port.
3) Control far-end output devices from local IR Port
When you need to control a remote display from local, the IR receiver used must
have an IR carrier. The IR signal is transferred to the corresponding zone connected
with HDBaseT receiver connected with the IR transmitter. When the IR receiver is
connected to IR ALL IN port, the IR signal can be finally transferred to all the 4 IR
transmitters connected with HDBaseT receivers.
As per the figure below:
Controlling a far-end device from Local Matrix location

AVG-MS-44HDBT
1) Controlling far-end devices through the IR ALL IN port
The IR signal received from the IR ALL IN port will be transmitted to all the four far-
end HDBaseT receivers connected to HDBaseT ports of the MS-44HDBT. See as
per figure below:
Controlling far-end devices through the IR ALL IN port
2) Controlling a local device from far end remote
A user can control local devices such as DVD, matrix etc. remotely. When using, the
IR signal received from the HDBaseT receiver it will be transmitted to the
corresponding IR OUT port of the MS-44HDBT. See below:
Control of local device from remote
3) Controlled by a Third-party IR Control Device
Use the included IR converting cable (see as below), connect the 3-pin end to the IR
input port of the MS-44HDBT, the 2-pin end to the IR output port of the third-party
control device. The IR signal is able to be transmitted via the twisted pair, and finally
gets to the remote output device.

AVG-MS-44HDBT
5.3 RS232 Control
5.3.1 RS232 Commands
Through the RS232 communication port, a user can control a far-end device whose
baud rate is 2400, 4800, 9600, 19200, 38400, 57600 or 115200. Default setting of
the MS-44HDBT: baud rate is 9600, data bit is 8, stop bit is 1 and parity bit is none.
Communication protocol: RS232 Communication Protocol
Baud rate: 9600 Data bit: 8 Stop bit: 1 Parity bit: none
Command
Types
Command Codes
Functions
System
Command
/*Type;
Inquire the models information.
/%Lock;
Lock the
front
panel
buttons
on the Matrix.
/%Unlock;
Unlock the
front panel buttons
on the Matrix.
/^Version;
Inquire the version of firmware
/:MessageOff;
Turn off the feedback command from the com port.
It will
only show the “Switch Ok”.
/:MessageOn;
Turn on the feedback command from the com port.
Demo.
Switch to the “demo” mode, 1
-
>1, 2
-
>2, 3
-
>3 … and so
on .The switching interval is 2 seconds.
Undo.
To cancel the previous operation.
Operation
Command
[x]All.
Transfer signals from the input channel [x] to all output
channels
All#.
Transfer all input signals to the corresponding output
channels respectively.
All$.
Switch off all the output channels.
[x]#.
Transfer signals from the input
channel [x] to the output
channel [x].
[x]$.
Switch off the output channel [x].
[x]@.
Switch on the output channel [x].
All@.
Switch on all output channels.
[x1] V[x2].
Transfer the
AV
signal from the input channel [x1] to the
output channel [x2].
[x1] B[x2].
Transfer the
AV
and
IR
signal from the input channel
[x1] to the output channel [x2].
Status.
Inquire the input channel to the output channels one by
one.
Save[X].
Save the present operation to the preset command [
X
]
,
ranges from 0 to 9.
Recall[Y].
Recall the preset command [Y].
Clear[Y].
Clear the preset command [Y].
PWON.
Work in normal mode.

AVG-MS-44HDBT
PWOFF.
Enter into standby mode and cut off the power supply to
HDBaseT receivers.
STANDBY.
Enter into
standby
mode.
/%[Y]/[X]:[Z].
HDCP management command. [Y] is for input
(value: I)
or output (value: O). [X] is the number of one port, if the
value of X is ALL, it means all ports. [Z] is for working
status (value: 1 or 0).
Y=I & Z=1, means the input port is compliant with
HDCP.
Y=O & Z=1, means output with HDCP.
Y=I & Z=0, means the input port is not compliant with
HDCP.
Y=O & Z=0, means output without HDCP.
[x1] R[x2].
Transfer the
IR
signal from the input channel [x1] to the
output channel [x2].
DigitAudioON[x].
Enable HDMI
audio output of port x.
X=1, 2, 3, 4, enable this one port.
X=5, enable all the 4 ports.
DigitAudioOFF[x].
Disable HDMI audio output of port x.
X=1, 2, 3, 4, disable this one port.
X=5, disable all the 4 ports.
