AVLink CS-2018 User manual

User Manual
CS-2018
CS-20116
CS Series Audio/Video
Distribution Amplifier

CS Series Audio/Video Distribution Amplifier—User Manual
1
Before You Use the System
1、Read manual——Carefully read the manual before you use the system.
2、Installation environment——The system should be installed indoor only. Install either on a
sturday rack or desk in a well-ventilated place.
3、Lightning——Unplug the power cord during lightning or after a prolonged period of non-use
to avoid damage to the equipment.
4、Maintenance——Only qualified technical engineers or specified distributors are permitted to
repair or replace components and parts of the equipment upon failure.

CS Series Audio/Video Distribution Amplifier—User Manual
2
Table of Contents
1.0 Audio/Video Distribution Amplifier Overview.........................................................................3
1.1 CS Series Audio/Video Distribution Amplifier.................................................................3
1.2 Contents of Package ..........................................................................................................4
2.0 Product Description:..................................................................................................................4
3.0 Audio/Video Distribution Amplifier Application Areas............................................................4
4.0 Product Features........................................................................................................................4
4.1 Video .................................................................................................................................4
4.2 Audio .................................................................................................................................4
5.0 Product Specifications...............................................................................................................5
5.1 Video .................................................................................................................................5
5.2 Audio .................................................................................................................................5
6.0 Front/Rear Panel View ..............................................................................................................6
6.1 Front Panel View...............................................................................................................6
6.2 Rear Panel View ................................................................................................................6
7.0 Installation Steps .......................................................................................................................7
8.0 CS-2018 Distribution Amplifier and Peripheral Equipment Connection..................................7
9.0 Serial Connection Operation .....................................................................................................8
10.0 FAQ .........................................................................................................................................9

CS Series Audio/Video Distribution Amplifier—User Manual
3
1.0 Audio/Video Distribution Amplifier Overview
1.1 CS SeriesAudio/Video Distribution Amplifier
The CS-2018/CS-20116 is an 8/16 output connectors RCA distribution amplifier with 1
video and 1 pair of audio RCA female input connectors and 8/16 video and 8/16 pairs of audio
RCA female output connectors.
The CS series audio/video distribution amplifier is a professional high performance
audio/video signal distribution amplifying equipment. It is used in one audio/video signal input
to multiple audio/video signal output distribution amplification; each video signal and audio
signal are independently transmitted, thereby enabling attenuation of signal transmission to be
reduced to the minimum and ensuring high fidelity video and audio signals output.
The CS series audio/video distribution amplifier is mainly used in broadcasting and TV
engineering projects, multimedia conference rooms, large display engineering projects, TV
teaching, and command control centers. This product has power overload protection and
synchronous video functions.
Figure 1-1 CS-2018 Distribution Amplifier
Figure 1-2 CS-20116 Distribution Amplifier

CS Series Audio/Video Distribution Amplifier—User Manual
4
1.2 Contents of Package
nOne AVLINK CS-2018 or CS-20116 Audio/Video Distribution Amplifier
nUser Manual
nAC Power Cord
Please check with your distributor in case of missing parts.
2.0 Product Description:
CS-2018 or CS-20116 distribution amplifier: 1 pair of audio and 1 video RCA female
input connector, 8/16 pairs of audio and 8/16 video RCA female output connectors.
3.0 Audio/Video Distribution Amplifier Application Areas
nTest bench facilities
nTest Rooms
nInformation Desks
nHomes
nEmporia
nMass Media: Stock Price Display, Time Display, Teaching Rooms
nData Centers
nHelp Desks
4.0 Product Features
nMulti-tasking
n2U 19-inch stack design
4.1 Video
nVideo bandwith: 400MHz(-3dB)
nPermits extension of video signal to 35 meters
nPermits serial connection
nOutput connector compatible with standard RCA connector
4.2 Audio
nStereo sound
nPermits serial connection
nApplicable to RCA audio equipment

CS Series Audio/Video Distribution Amplifier—User Manual
5
5.0 Product Specifications
5.1 Video
Length of extension: maximum 35 meters
Signal type: Composite Video Signals
Input connector: 1 RCA female connector
5.2 Audio
Working frequency: 20Hz—20KHz
Input impedance: >10KΩ
Input connector: 1 pair (R,L) RCA female connectors
Function CS-2018 CS-20116
Type Composite Video
Input Impedance 75Ω
Input Connector 1 RCA female connector
Video
Output Connectors 8 RCA female connectors 16 RCA female connectors
Type Unbalanced stereo sound
Input Impedance >10KΩ
Input Connector 1 pair (R,L) RCA female connectors
Audio
Output Connectors 8 pairs (R,L) RCA female
connectors
16 pairs (R,L) RCA female
connectors
Power Transformer (Min) AC 100V～240V, 50/60Hz,Internal
Housing Aluminum
Weight 3.4Kg 3.5Kg
Measurements (L*W*H) 485*272*93mm

CS Series Audio/Video Distribution Amplifier—User Manual
6
6.0 Front/Rear Panel View
6.1 Front Panel View
Figure 6-1
1. LED power indicator.
6.2 Rear Panel View
Figure 6-2
2. Input AC power plug
NOTE: CS-2018 has 8 sets of output connectors.
CS-20116 has 16 sets of output connectors.

CS Series Audio/Video Distribution Amplifier—User Manual
7
7.0 Installation Steps
1. Turn off power to the DVD player and TV/HDTV.
2. Use the audio/video extension cord to connect the RCA female input connectors of the
CS-2018 or CS-20116 audio/video distribution amplifiers to the DVD player.
3. Use the audio/video extension cord to connect the RCA female output connectors of the
CS-2018 or CS-20116 audio/video distributin amplifiers to the TV/HDTV.
4. Connect one end of the power cord to the product and the other end to the mains.
5. Turn on the DVD player and the TV/HDTV.
8.0 CS-2018 Distribution Amplifier and Peripheral
Equipment Connection
Figure 8-1

CS Series Audio/Video Distribution Amplifier—User Manual
8
9.0 Serial Connection Operation
1. To display video on multiple TV/HDTVs you have to serially connect another distribution
amplifier.
2. Use the audio/video extension cord to connect to any RCA female output connector of the
front CS-2018/20116 audio/video distribution amplifier to the RCA female input connector of
the rear CS-2018/20116 audio/video distribution amplifier.
NOTE:
You are recommended not to connect too many distribution amplifiers because video
transmission will become unstable.
Figure 9-1
Remarks: Above figure shows serial connection of an 8-connector distribution amplifier to a
16-connector distribution amplifier. However, you can also serially connect other output
connectors to the CS-2018/20116 audio/video distribution amplifier.

CS Series Audio/Video Distribution Amplifier—User Manual
9
10.0 FAQ
1．What should I do if the distribution amplifier fails to display or the display color is abnormal
after hot plug?
Answer: The internal switching of the distribution amplifier is carried out by IC chips. There is
an electric potential difference between the input signal equipment and the distribution amplifier.
The IC chips of the distribution amplifier can be easily damaged if the difference is too big. You
are recommended to turn off power to the distribution amplifier and do not hot plug if you want
to replace wires.
2．What should I do if ghosting happens when video signal outputs to the display equipment?
Answer: Ghosting usually happens when the projector is improperly adjusted or the cable quality
is not up to standard. Generally, it is either poor cable quality or long transmission distance. You
are recommended to replace with better quality cable to avoid the problem.
3．What should I do if loss of color happens or even no video signal output?
Answer: Check if both sides of the video signal cable are correctly connected to the
corresponding connector.
4. What should I do if the power indicator does not lit?
Answer: Check if the equipment power input is properly in contact.
5. What should I do if static electricity is markedly sensed during plugging and unplugging of the
audio/video connectors?
Answer: It could be that your equipment power is not properly grounded. Make sure that you
have properly grounded your equipment to avoid damaging to the product and shorten product
life.
NOTE:
Do not replace the damaged power cord yourself. Only the distributor maintenance engineer
is authorized to replace the damaged power cord.
© C&C TECHNIC TAIWAN CO., LTD. All rights reserved.
Trademarks:
All the companies, brand names, and product names referred to this manual are the trademarks
or registered trademarks belonging to their respective companies.
