AVstumpfl Desertscreen User manual

10IR
DESERTSCREEN
INSTRUCTION FOR DESERTSCREEN

2
• Foldable Monoblox 64 frame with patented self locking snap joints
• Foldable projection surface with reinforced border and rubber coated press buttons
(optional Invisnaps)
• Special AT-Legs with adjustable telescopic support
• Anti sway braces for perfect stability
• Projector arms with stepless projection distance adjustment
• Projector brackets (customized on request)
special AT-Legs
Anti-sway braces
projector arms with stepless distance adjustment
MONOBLOX64 frame with front projection surface
SYSTEM COMPONENTS

3
GENERAL
QUALITY AND SAFETY:
This projection screen is in accordance with the safety regulations in DIN standard 19045 and DIN
56950. The screen fabric is comply with DIN 4102 part 1 and the specications of the according data
sheet.
WARRANTY:
The warranty period for production deciencies is 5 years for the frame elements and 24 months
for the projection surface. Mobile projection screens are developed for indoor use only. Any damage
and consequential damage caused by outdoor use is not covered by warranty.
FRAME ELEMENTS:
The frame elements, legs and additional elements are maintenance-free!
PROJECTION SURFACE:
The projection surface is packed into a separate soft bag to avoid any damage by the frame parts,
bleaching and discoloration. Additionally following handling instructions have to be adhered to:
! Do not bring printed and coloring objects (instructions, magazines, etc.) in contact with the
projection surface !
! Do not mark the projection surface !
Colors penetrate the projection surface and cannot be cleaned anymore!
Store the projection surface cleaned and dry at room temperature only!
The projection surface has to be folded with the front layer inside; in order to avoid soil and
damage.
COLD BREAK
A projection foil must never be stored or transported below 0 ° C. There is a risk of a cold break!
The lm becomes very brittle and splinters like glass! When transporting the projection surface at low
temperatures, do not unfold the surface unless it has reached its full elasticity at room temperature.
Otherwise there is the risk of cold break of the projection screen. When folding the projection surface,
insert the enclosed foamed plastic foil between snap buttons and surface to avoid permanent marks.
CLEANING OF THE PROJECTION SURFACE:
Use a white clean cotton cloth saturated with clear water (optionally mild soap water) and gently
wipe the area in one direction (no circular motion). Wipe dry with another cotton cloth.
To clean a stubborn stain, use methylated spirit and follow the same procedure.
Clean rear projection surfaces in case of imperative only!
Subject to modications, errors expected !

4
21
3 4
56
FRAME SET UP
1Unfold the horizontal frame elements
Snap joints will lock automatically.
5Unfold the leg and connect the reverse tele-
scopic support to the vertical leg with the wing
screw M8x50mm (yellow cap)
6Tighten the telescopic support element with
the two wing nuts.
3Secure the vertical frame elements with the
wing screws M8x15mm. maximum stability
4Close the corner hinges for maximum stability
2Put together the vertical parts of the two frame
bars. Corner hinges have to be open for ease as-
sembly.

5
7 8
10
12
9
11
PROJECTOR ARMS
7Set up the screen with the AT64-Legs at the
predened height.
8Each AT64-Legs must be bolted to the frame
with two wing screws M8x85mm at the left and
right middle strut.
9-12 Unfold the projector arms and rotate the vertical element by 270° so that the horizontal bar is
positioned as seen on the pictures.

6
1413
15
17
16
18
13-14 Now, connect the projector arms to the three middle struts at the appropriate screwing points
with two wing screws M8x85mm each.
15-18 Maximum lateral-stability is gained by mounting the anti-sway-braces. Attach the Anti-sway brace
through the vertical leg element and open the two wing nuts to be able to adjust the telescopic length
and clamp the plates to the horizontal bottom bar of the Monoblox64 screen. Secure the telescopic
element and at last thighten the wing screw M8x85mm.
ANTI-SWAY BRACES

7
19 20
The screen surface must be attached to the frame with several people to avoid any damage. Depending
on the size of the setup area and the number of team members, the surface can be attached to the
frame either when the frame lies on the ground or right after the frame system setup is completed..
Projector brackets (black) can be positioned stepless along the projector arms. The projector mounting
itself must be adapted to the bottom plate of the projector bracket (no picture) (e.g.: rivet bolt, rivet nut,
ball end,...). We are pleased to oer you a customized solution.
SCREEN SURFACE
PROJECTOR BRACKETS

8
