Awntech RN22 Original instructions

Page | 1
New Yorker Style Awning (5’-20)
OWNER’S MANUAL & INSTALLATION INSTRUCTIONS
⚠Warning: Adult Assembly Required; Kit Contains Parts with Sharp Points and Edges, and Components
are Packed in Plastic Bags That Can Present a Choking Hazard to Children.⚠
NOTE: Please inspect the parts for damage from shipping and/or any missing parts. If you suspect there
may be damage or a shortage, contact us within 5-days of delivery to report shipping damage or within
30-days of delivery to report missing or incorrect parts for a warranty replacement at no cost and we
will send replacement parts if needed. At this time, visualize how the components fit together and
determine if you have identified all necessary parts.
Models with Valance: RN22, EN23, EN24, CN32, CN33, CN34, CN43, CN44, EN2442, EN1836, EN1030
Awning Size
Width in Inches
Awning Size
Width in Inches
3
40.5
12
148.5
4
52.5
13
160.5
5
64.5
14
172.5
6
76.5
15
184.5
7
88.5
16
196.5
8
100.5
17
208.5
9
112.5
18
220.5
10
124.5
19
232.5
11
136.5
20
244.5
Due to the variety of construction materials, building surfaces, and mounting applications, Awntech
does not supply the hardware to install your awning. You will need to consult a contractor or purchase
installation hardware from your local hardware store. We advise you on different surface applications as
follows:
CONCRETE/STUCCO: 1/4” x 3” Masonry anchor bolts or Tapcon screws with washers.
WOOD/SIDING: 1/4” x 3” Lag screws/bolts plus nuts and washers.
OTHER MATERIALS: CONSULT A PROFESSIONAL

Page | 2
Before you begin, take inventory of all parts included by comparing the contents of your package to the
parts list corresponding to the size of awning you received. Each piece should be identifiable by a label.
Awning Size in Feet
3-4
5
6-7
8-10
11-12
13-18
Custom
(TB) Top Bar
1
1
2
2
3
3
(FB) Front Bar (preassembled)
2
2
4
4
6
6
(CS) Cover Support
2
3
3
5
4
7
(PB) Projection Bar
2
2
2
2
2
2
(PBS) Projection Bar Support
2
2
2
2
2
2
(BB) Back Bar
2
2
2
2
2
2
(WS) Wall Supports
0
1
1
3
5
5
*(CS) count includes Center Cover Supports (CCS)
Parts:
Hardware package includes: Z-brackets and self-tapping screws.
NOTE: You will find that fittings have been pre-installed in the frame parts as we have pre-assembled
and inspected the awning for you in the factory.
Tools required: Electric Impact Drill, Rubber Hammer, Installation Anchors (as per your surface
material), Tape Measure, Safety Glasses, Level, Ladder, and #2 Pencil. You may also wish to have an
assistant depending on the size and weight of the awning.
You will want to assemble the frame on a flat surface with room to reposition the frame as you
complete each section.

Page | 3
ASSEMBLY
NOTE: All awning sizes over 6’ wide come in multiple sections. Example: Size 6’ Top Bar (TB) consists of
TB1 & TB2. Front Bar (FB) is fully pre-assembled on 3’-5’ New Yorker awnings, 2 pre-assembled sections
on 6’-10’ awnings and 3 pre-assembled sections on 11’-20’ awnings.
Step 1) Using a Rubber Hammer, attach Projection Bars (PB) to bottom and Projection Bar Supports
(PBS) to top of each side of Front Bar (FB) with Velcro on FB and PB facing upwards. Velcro across FB will
be on bottom rail.
Step 2) Using a Rubber Hammer, attach Back Bars (BB) to Projection Bars (PB). Secure BB to PBS with
self-tapping screws. Velcro on Back Bars (BB) will face front.

Page | 4
Step 3) Using a Rubber Hammer, attach Top Bar (TB) to Back Bars (BB). NOTE: the C-Channel across the
top of the Top Bar (TB) should be oriented towards the back/wall side.
Step 4) Orient awning frame on its back with Front Bar up towards the sky. Using a Power Drill and self-
tapping screws, locate the pre-drilled holes and attach Cover Supports (CS) to Top Bar (TB). NOTE:
Larger awnings have additional Cover Supports (CCS) and Wall Supports (WS).

Page | 5
Step 5) Orient awning frame flat on its bottom with Front Bar forward. Using a Power Drill and self-
tapping screws, attach Cover Supports (CS) to Front Bar (FB). Attach Wall Support (WS) to top level of
back side of Front Bar (FB). There are no pre-drilled holes for the Wall Supports (WS).
The New Yorker frame is now complete.

Page | 6
INSTALLING THE COVER
Step 7) Insert tubing of fabric into C-Channel on Top Bar (TB) and slide cover across the top into correct
position. Wrap fabric around frame tightly and secure to Velcro.

Page | 7
MOUNTING THE AWNING:
Step 8) Place awning temporarily in desired location on intended mounting surface. Using a #2 pencil,
mark the wall along the inside of the frame and then remove awning.
Model
Space Between
TB and P
Height w/
Valance
Projection
Model
Space Between
TB and P
Height w/
Valance
Projection
RN22
31
31
24
NY1618
22
22
18
CN32
44
44
24
NY1624
22
22
24
CN33
44
44
36
NY1630
22
22
30
CN34
44
44
48
NY1818
24
24
18
CN43
56
56
36
NY1824
24
24
24
CN44
56
56
48
NY1830
24
24
30
EN2442
24
24
42
NY2430
31
24
30
EN12
12
12
24
NY2436
31
31
36
EN1836
18
18
36
NY3024
37
37
24
EN1230
12
12
30
NY3030
37
37
30
EN1030
16
16
30
NY3036
37
37
36
EN23
24
24
36
NY3048
38
38
48
EN24
24
24
48
Step 9) Using the marks on the wall, install two (2) Z-brackets into desired mounting location to hold Top
Bar (TB).
Step 10)Drop Top Bar (TB) into mounted Z-brackets and check the fit. Once position is satisfactory, use
Power Drill to attach Top Bar (TB) to Z-brackets with self-tapping screws. After Top Bar (TB) is secured to
the mounting surface, install one (1) Z-bracket on the inside of each Back Bar (BB) with self-tapping
screws. NOTE: There are no pre-drilled holes for Z-brackets, they may be placed anywhere along the
surface of the Top Bar (TB) and Back Bars (BB) to accommodate your mounting surface’s stud location.

Page | 8
WARRANTY
https://awntech.com/contact/product-warranty/
5-Year Manufacturer's Limited Warranty
Obtaining necessary permits is the sole responsibility of the purchaser. Purchaser/customer agrees he/she/company will NOT hold Awntech
liable for improper installation, maintenance and repairs.
A. WARRANTY: 5 Year Limited Manufacturer’s Warranty (Prorated by the month)
B. WHO GIVES THIS WARRANTY? Awntech Corporation, 10950 S. Pipeline Road, Euless, TX 76040
C. WHO IS ENTITLED TO THIS WARRANTY? This Warranty applies only to the original purchaser who paid for the product and may not be
assigned or transferred to subsequent owners. This Warranty applies only to products purchased and installed in the United States.
D. WHAT ARE THE RESPONSIBILITIES OF AWNTECH UNDER THIS WARRANTY? Subject to the terms and conditions set forth herein, Awntech
Corporation will furnish replacements for parts found by Awntech Corporation to be defective in design, manufacture or assembly, under each
specific component or product warranty as set forth below.
E. WHAT ARE THE RESPONSIBILITIES OF THE ORIGINAL PURCHASER UNDER THE WARRANTY?
•Before any claims may be made under this Warranty, the original purchaser must have paid in full for the product covered under the
Warranty, according to the terms and conditions of the pay-plan defined in the original order. IF THE PURCHASER HAS FAILED TO MAKE FULL
PAYMENT, THIS WARRANTY SHALL BE NULLIFIED AND AWNTECH CORPORATION SHALL BE RELIEVED FROM ANY RESPONSIBILITY OR LIABILITY
UNDER THIS WARRANTY. The purchaser agrees and acknowledges that this Warranty agreement constitutes an executor contract.
•The purchaser must use care in installation, maintenance, operation, use, and storage of the product in accordance with the instructions
contained in the owner’s manual. ANY FAILURE TO INSTALL, MAINTAIN, OPERATE, USE AND STORE THE PRODUCT IN ACCORDANCE WITH THE
INSTRUCTIONS CONTAINED IN THE OWNER’S MANUAL WILL NULLIFY THIS WARRANTY AND RELIEVE AWNTECH CORPORATION FROM ANY
RESPONSIBILITY OR LIABILITY UNDER THIS WARRANTY.
•Promptly notify Awntech Corporation of any claims.
•At Awntech’s request the purchaser may be required to provide a photographs or videos (if necessary) of any defective parts. The purchaser
may also be required to pay a deposit until the defective parts are returned to Awntech Corporation for inspection. The purchaser must obtain
a return authorization form from Awntech Corporation’s customer service department prior to the return of any merchandise and after having
received such authorization, return the part or product, freight prepaid, to Awntech Corporation.
F. WHAT IS COVERED UNDER THIS WARRANTY? The following components of Awntech Beauty-Mark® models and their accessories (defined as
accessories attached to the awning) are covered under this Warranty, subject to the limitations set forth below. These components have a five
(5) year limited (prorated) warranty, against manufacturer’s defects as outlined below: (a) Should the purchaser promptly notify Awntech
Corporation of such defects within one year (12 months) from the date of the original purchase, the defective component will be replaced at no
charge to the purchaser. Awntech reserves the right to ask for the defective part to be returned and/or photos/videos of the defective part. (b)
After one year but within five years (60 months) from the date of the original purchase, a defective component will be replaced upon the
purchaser's payment of 1/60th of the full retail cost of the component for each month of use prior to the claim.
FIXED AWNINGS – COVERED COMPONENTS
Structural supports - all supporting components are warranted not to fail for five (5) years prorated. Acrylic fabric - warranted for five (5) years
prorated against:
a) Excessive fading under normal conditions if maintained, operated, used, and stored in accordance with the instructions contained in the
owner’s manual.
b) Mildew on acrylic fabric. Mildew will not form on the fabric itself, but may form on dirt and dust that have not been removed from it. Please
see maintenance instructions for proper cleaning—outlined in owner’s manual.
G. WHAT IS NOT COVERED UNDER THIS WARRANTY?

Page | 9
•Any failure or damage of the components that results from any intentional or negligent actions by the purchaser or by any other person is not
covered by this Warranty.
•It is the responsibility of the purchaser to securely fasten the awning to studs, joists, headers or other structural members. Any failure or
damage that results from the awning falling from its installed position is not covered by this Warranty.
•Labor charges connected with installation of replacement parts are not covered by this Warranty. •Freight expenses to and from Awntech
Corporation are not covered by this Warranty and must be paid by the purchaser.
•Stretching of fabric or damage to any structural component caused by wind or water pooling on the fabric or any other weather is not covered
by this Warranty, except for the limited warranty of the acrylic fabric as specifically set forth herein.
H. GENERAL PROVISIONS AND LIMITATIONS
•The warranty granted herein is the exclusive remedy for the purchaser. Awntech Corporation makes no other warranties to the purchaser,
express, statutory, implied or otherwise and all implied warranties, including without limitations, implied warranties of merchantability and
fitness for a particular purpose, are hereby disclaimed.
•To the extent permitted by law, Awntech Corporation shall have no liability to the purchaser or any other person for incidental, special,
consequential, indirect or similar damages of any kind or nature whatsoever, whether arising out of breach of warranty or other breach of
contract, negligence or other tort, or otherwise, even if Awntech Corporation shall have been advised of the possibility or likelihood of such
potential loss or damage. In no event shall Awntech Corporation be liable for loss of profits and/or wages.
•Some states do not allow limitations on how long an implied warranty lasts, or do not allow the exclusion or limitation of incidental or
consequential damages, so the above limitations may not apply to you.
•This warranty gives you specific rights, and you may have other rights, which vary from state to state. Awntech Corporation, 10950 S. Pipeline
Rd., Bldg. 1, Euless, TX 76040 / Ph 817-354-9600; Fax [phone] / [email protected]
G. RETURNS & DAMAGES
RETURN QUALIFICATION: You can only return a product if it is defective upon arrival. If you simply do not like the product or if you did not
measure correctly, you will only be qualified for a merchandise credit and you will be required to pay for shipping the product back to Awntech
in re-stockable condition. There will be a 25% restock fee applicable.
SIZES 10’ and LARGER or CUSTOM AWNINGS: Any awnings 10’ or larger or customized at Purchaser’s request are considered non-returnable
for either refund or exchange.
DAMAGED MATERIAL: Damage occasionally occurs during shipping. Scrapes dents and rips in the outer packaging that could indicate possible
damage should be described to the carrier at the time of delivery. If damage to the product seems apparent, the shipment should be refused.
FABRIC DYE-LOT AND LIGHTING VARIATION: Fabric dyes may carry slightly from run to run. This is a normal and unavoidable. Different lighting
types and lighting direction may cause the fabric you choose on the website to appear slightly different than the actual fabric does in full
sunlight.
RETURNS/ORDER EXCEPTIONS: Phone :[phone], Fax [phone], E-mail [e-mail]
TO ACQUIRE A RETURN OR REPAIR AUTHORIZATION NUMBER YOU MUST GO THROUGH THE WARRANTY PROCESS: Email Photos of damaged
parts to: [e-mail] or mail to:
Awntech Corporation
10950 S. Pipeline Rd., Bldg 1
Euless, TX 76040
Authorized returns should be shipped to: Returns Department:
Returns Department
Awntech Corporation
10950 S. Pipeline Rd., Bldg 1
Euless, TX 76040

Page | 10
CLEANING CHART FOR TYPICAL AWNING STAINS:
CLEANING & CARE: Awnings should be cleaned at least once a year in low maintenance areas or twice a
year in high maintenance areas (see high maintenance areas above). Cleaning consists of brushing off
debris with broom, brushing on a non-detergent cleaning compound (such as a solution of 1-part
vinegar to 1-part water), allowing the awnings to sit for 20 minutes, and then rinsing. Remember that
your awning is an exterior product; You’ll need to clean your awning to preserve and extend its beauty
and life. Please refer to the cleaning and care chart below if you acquire a stain from one of the
ingredients on the list.
NORMAL WEAR & TEAR: The weather in certain regions of the country contributes to wear and tear of
the awnings. If you live in these areas (High maintenance areas: FL, TX, NM, AZ, NV or high-altitude
areas) weather conditions (including sun) can take a toll. Normal wear and tear is not covered in our
warranty and should be expected. Damages caused by improper anchoring, strong winds, snow or ice
are not considered defects. We offer replacement fabric at affordable prices
