Axiom AX2010A User manual

USER MANUAL
AX2010A
acve vercal array loudspeaker
KEY FEATURES
• High output line array element • Transmission Line back loading for clean mid-bass reproducon
• Compact size, very good output-to-weight rao • Natural sound Transmission Line HF projecon wave-forming device
• High quality, low compression, low distoron HF driver • 96KHz / 40 bit oang point CORE processing with PRONET remote control
• Very stable horizontal coverage • Digitally controlled Class D amplier module with SMPS
INTRODUCTION
The AX2010A Vercal Line Array element is designed for a wide range of sound reinforcement applicaons where a exible and easy to use vercal
array systems is needed. The AX2010A has been designed both for rental live sound applicaons and for xed installaons and has been engineered
for the simplest use possible but without sacricing anything in sound
quality and performance.
The high frequency range is reproduced by two low-distortion
compression drivers, equipped with very light-weight diaphragms. Two
transmission line waveforming waveguides have been used to load
the HF drivers, in order to provide a detailed and natural sound and to
achieve a long-distance HF projecng capacity.
The two 10” woofers employed in the reproducon of the mid-bass
range are equipped with very light-weight cones. The lightness of the
diaphragm is furthermore improved by the use of aluminium voice
coil instead of convenonal copper. This ensure a fast reproducon of
the mid range and of mid-bass musical passages, improving also the thermal capacity of the voice
coil and, consequently, controlling the overall power compression. The two 10” woofers are back
loaded by a short hybrid transmission line that minimizes the eect of the box resonances and eliminates the “boxy” mid-bass sound commonly
obtained from regular bassreex enclosures. The crossover lter approach is based on a “Constant Power” technique. Thanks to a parcular phase
combinaon between the two ways around the crossover frequency, this approach is able to provide a very stable horizontal coverage and a very
stable o-axys sound image, also minimizing unwanted eects around the crossover frequency. The further applicaon of phase linearizaon
techniques, combined to constant power crossover, yield a linear phase response and a coherent me response. This allows for a natural percepon
of acousc instruments and voices and for an improved depth of the sound image.
TECHNICAL SPECIFICATION
Acouscal Remote Controls PRONET control soware
System type
Line Array Element
Short Transmission Line LF Back Loading
Acousc Transmission Line HF Waveguide
Network protocol CANBUS
Amplier Type Class D with Variable Switching Frequency
and SMPS
Low frequency transducer Two 10” (260 mm), 2.5” (64 mm) aluminium
voice coil, 16Ω each, paralleled
Output Power 2x 1000 W
Mains Voltage Range (Vac) 230 V~ ±15% or 115 V~ ±15% 50/60 Hz
High frequency transducer
Two 1.4” drivers, 2.5” (64 mm) edgewound
voice coil, tanium diaphragm,
16Ω each, paralleled
Mains Connector PowerCon® (NAC3MPA + NAC3MPB)
Consumpon* 700 W (nominal) 1700 W (max)
IN / OUT Connectors Neutrik XLR-M / XLR-F
Frequency response (±3 dB) 75 Hz – 18 kHz (Processed) IN / OUT Network Connectors ETHERCON® (NE8FAV)
Horizontal Coverage Angle 110° (-6 dB) Mechanical
Vercal Coverage Angle 10° (-6 dB) Width 746 mm (29.37”)
Maximum Peak SPL @ 1m 138 dB Height 341 mm (13.42”)
Electrical Depth 530 mm (20.86”)
Input Impedance 20 kΩ balanced Taper angle 5°
Input Sensivity +4 dBu / 1.25 V Construcon 15 mm, reinforced Phenolic Birch
Signal Processing CORE processing, 96kHz / 40bit oang
point SHARC DSP, 24 bit AD/DA converters
Paint High resistance, water based paint
Suspension system
Direct access Controls
4 Presets: Standard, Long Throw, Down Fill-
Single Box, User.
Network Terminaon, GND Link
Front Suspension Aluminium Fast Link structure with ¼ Fast Pin
Back Suspension High Strength Steel with ¼ Fast Pin
Net Weight 40.3 Kg (88.7 lbs.)
* Nominal consumpon is measured with pink noise with a crest factor of 12
dB, this can be considered a standard music program.
revision 2019-03-29

MECHANICAL DRAWING
OPTIONAL ACCESSORIES
AXCASE02 Carrying Case for 2 box unit USB2CAN PRONET network converter
NAC3FCA Neutrik Powercon® BLUE PLUG KPTAX2012P Fly bar for Axiom AX2010 Loudspeakers
NAC3FCB Neutrik Powercon® WHITE PLUG AXFEETKIT Kit Of 6pcs BOARDACF01 M10 foot for stacked installaon
NE8MCB Neutrik Ethercon PLUG RAINCOV2010 Rain protecon for signal connectors
NC3MXXBAG Neutrik XLR-M RAINCOV2010PW Rain protecon for power connectors
NC3FXXBAG Neutrik XLR-F
see hp://www.axiomproaudio.com/ for detailed descripon and other available accessories.
SPARE PARTS
95AXM014 Powercon® sockets kit with internal wiring 91DSPKIT3 DSP & Control PCBA (specify AX2010A rmware)
NAC3MPA Neutrik Powercon® BLUE SOCKET 91PCAG00031 DSP Interface PCBA
NAC3MPB Neutrik Powercon® WHITE SOCKET 91PCALED1 Posion check LED PCBA
95AXM014 Locking Pin for AX2010 98AXM10WZ8 10’’ woofer - 2.5” VC
PLG716 Straight Shackle 16 mm for Fly bar 98DRI1424 1.4’’ - 2.5” compression driver
91DA2000 DA2000 Power amplier module 98MBN1424 tanium diaphragm for 1.4” driver
91CRAX2010 Input-Link PCBA
746 mm
29.37”
341 mm
13.42”
230 mm
9.06"
530 mm
20.86”
5.0°

POWER PANEL
MAINS IN - Powercon® NAC3FCA power input connector (blue). To switch the
amplier on, insert the Powercon® connector and turn it clockwise into the ON
posion. To switch the amplier o, pull back the switch on the connector and
turn it counter-clockwise into the POWER OFF posion.
WARNING! In the case of product failure or fuse replacement, disconnect
the unit completely from the mains power. The power cable must only be
connected to a socket corresponding to the specicaons indicated on the
amplier unit. The power supply must be protected by a suitably rated
thermo-magnec breaker. Preferably use a suitable switch to power on
the whole audio system leaving the Powercon® always connected to each
speaker, this simple trick extend the life of the Powercon® connectors.
POWER OUT - Powercon® NAC3FCB power output connector (grey). This is connected in parallel with the MAINS ~ / IN. The maximum load
applicable depends on the mains voltage. With 230V~ we suggest to link a maximum of 4 AX2010A loudspeakers, with 120V~ we suggest to link
a maximum of 2 AX2010A loudspeaker.
CONTROL PANEL
ON - This LED indicates power on
status.
PROT - This red LED lights when
the amplier module is in protect
mode for an internal fault and,
consequently, the amplifier is
muted.
SIGN LIMIT - This LED lights in
green to indicate the presence of
the signal and lights in red when
an internal limiter reduces the
input level.
INPUT - Audio signal input with
locking XLR connector. It has a
fully electronically balanced
circuitry including AD conversion
for the best S/N rao and input
headroom.
LINK - A direct connection from
the input connector to link other
speakers with same audio signal.
GND LIFT - This switch lift the
ground of the balanced audio
inputs from the earth-ground of
the amplier module.
PRESET BUTTON - This buon has two funcon:
1) Pressing it while powering on the unit:
ID ASSIGN the internal DSP assigns a new ID to the unit for the PRONET remote control operaon. Each loudspeaker must have a unique
ID to be visible in the PRONET network. When you assign a new ID, all the other loudspeakers with the ID already assigned
must be ON and connected to the network.
2) Pressing it with the unit ON you can select the DSP PRESET. The selected PRESET is indicated by the corresponding LED:
STANDARD This PRESET is suitable for vercal own arrays that may range from 4 to 8 boxes or for the centre region of a bigger own array.
It can be used also for stacked arrays.
LONG THROW This PRESET can be used in arrays bigger than 6 or 8 boxes and loaded in the top 1 or 2 boxes in order to obtain a more even
distribuon of the sound pressure, especially if they point very far away or to the upper deck of a large theatre.
DOWN FILL / This PRESET, which features a much smoother high frequency response, can be loaded in the boom boxes (usually 1 or 2
SINGLE BOX boxes) of a large own array, in order to reach conveniently the audience close to the stage. This preset could be very useful
also when the box is used just on its own as a Front Fill element in the front of very large stages.
USER This LED lights when the USER PRESET is loaded. This preset corresponds to USER MEMORY no. 1 of the DSP and, as a factory
seng, it’s the same to STANDARD. If you want to modify it, you have to connect the unit to a PC, edit the parameters with
PRONET soware and save the PRESET into USER MEMORY no. 1.
Note: see also the example further on this manual.
NETWORK IN/OUT - These are a standard RJ45 CAT5 connectors (with oponal NEUTRIK NE8MC RJ45 cable connector carrier), used for PRONET
network transmission of remote control data over long distance or mulple unit applicaons.
TERMINATE - In a PRONET network the last loudspeaker device must be terminated (with an inner load resistance) especially in a long run cabling:
press this switch if you want to terminate the unit.

POWER AMPLIFIERS
The AX2010A is powered by DA SERIES digital power modules, a new generaon of CLASS D power amplier with digitally-controlled SMPS.
The innovave technology used for these ampliers (including also the use of a variable switching frequency) oers performances at the top of
the range, such as a superior sound denion at any audio frequency, very high dynamics also for low level signals and very low distoron even at
the maximum power The superior sound quality can be compared with top-of-the-range AB-class analog systems, while the DA modules feature
a higher dynamics, very compact size and light weight and eciency above 90%. The DA module employed for powering the AX2010A deliver in
an ultra-compact package a maximum power of 2000W.
SIGNAL PROCESSING
The system processing is based on the CORE DSP plaorm, which has been designed by the PROEL R&D Laboratories using one of the most
advanced SHARC DSP for audio applicaon. It features 40bit, 96kHz oang point resoluon and high quality 24bit AD/DA converters, for a perfect
signal integrity, a dynamic range in excess of 110dB and a superior sonic performance. Thanks to its massive processing power, the CORE plaorm
is capable of providing the most sophiscated algorithms for speaker processing, together with remote control and networking capability.
The PRONET control soware, working on a solid and reliable CANBUS based network protocol, provides an intuive interface for the remote
control of the whole system, with the possibility of eqing, delaying, increasing the protecons and monitoring the status of the amplier.
PRONET Network
PRONET soware has been developed in collaboraon with sound engineers and sound designers, in order to oer an “easy-to-use” tool to setup
and manage your audio system. With PRONET you can visualize signal levels, monitor internal status and edit all the parameters of each connected
device.
Download the PRONET app from the AXIOM website at hp://www.axiomproaudio.com/ clicking on downloads secon of the product.
The AXIOM acve loudspeaker devices
can be connected in a network and
controlled by the PRONET software.
For the network connecon the PROEL
USB2CAN converter oponal accessory
is needed. The rst me you connect
a device with the USB2CAN converter,
Windows O.S. will ask you to install
the driver les, which you can nd in
the Driver folder within the Pronet
application folder (by default is C:\
Program Files\Proel\Pronet\Driver, or
if you changed it <your path>\Driver).
Please refer also to “Installaon” and
“Drivers” paragraphs in the Pronet
documentaon.
The PRONET NETWORK is based on a
robust, reliable and fast communicaon
protocol called CANBUS. The devices
in a PRONET NETWORK are connected
together with a “linear bus topology”.
The USB2CAN converter must be
connected to the network input of the
rst device, the network output of the
rst device is connected to the input of
the second and so on. For the network
connecons simple RJ45 cat.5 or cat.6
ethernet cables can be used (please
don’t confuse a ethernet network with
a PRONET network these are completely
dierent and must be fully separated also both use the same kind of cable).
The beginning and the end of a PRONET NETWORK must be terminated. One side is terminated by the USB2CAN converter, the other side must
be terminated pressing the TERMINATE switch on the last device. All devices between these two points must have the TERMINATE switch lied.
Assign the ID number
To work properly in a PRONET network each connected device must have a unique idener number, called ID. By default the USB2CAN PC
controller has ID=0 and there can be only one PC controller. Every other device connected must have its own unique ID equal or greater than 1:
in the network cannot exist two devices with the same ID.
An ID number is assigned automacally to each devices when they are turned on for the rst me connected to a network.
In order to correctly assign a new available ID to each device for working properly in a Pronet network, follow these instrucons:
1. Switch o all the devices.
2. Connect them correctly to the network cables.
3. “TERMINATE” the latest device in the network connecon.
4. Switch on the rst device keep pressed “PRESET” buon on the control panel.
5. Leaving the previous device switched on, repeat the previous operaon on the next device, unl the latest device is turned on.
do not
pressed
pressed
last device
network
network
AX2010A
USB2CAN
PC NOTEBOOK
USB 2.0 port
STAT US
CONVERTER
USB2CAN
CODE: S/N: RATINGS: RoHS COMPLIANT MADE IN ITALY
USB2CAN 00001 5V --- 200mA
EXAMPLE OF PRONET NETWORK WITH AX2010A AND SW218A

The “Assign ID” procedure for a device makes the internal network controller to perform two operaons: reset the current ID; search the rst free
ID in the network, starng from ID=1. If no other devices are connected (and powered on), the controller assume ID=1, that is the rst free ID,
otherwise it searches the next one le free.
These operaons ensure that every device has it’s own unique ID, if you need to add a new device to the network you simply repeat the operaon
of step 4. Every device maintains its ID also when it is turned-o, because the idener is stored in the internal memory and it is cleared only by
another “Assign ID” step, as explained above. This means that if your network is made always of the same devices the assigning ID procedure must
be executed only the rst me the system is turned on.
For more detailed instrucon about PRONET see the PRONET USER’S MANUAL included with the soware.
Useful tools to set up properly a vercal array system
This is a list of tools that can be very useful to set properly a vercal array system.
CABLE TESTER
It is a good pracce to check all cables before each installaon, because even one faulty cable can compromise heavily the
system performance.
INCLINOMETER WITH LEVER
This tool can be used to verify the vercal array angle. It can be used at the top or at the boom of the array In this
case you have to sum all splay angles, so the maximum precision is needed for aiming the vercal array, parcularly
for long throw applicaons.
LASER DISTANCE METER
This instrument can be useful to measure the height of the vercal array and to know the distance between FOH-Subs and FOH-Array
for seng the delay me.
SMAART or similar acousc measurement system
These are useful to measure delays, phase and response of the system.
EXAMPLE OF INSTALLATION IN A THEATRE WITH BALCONY
Here below you can see an example of the use of dierent PRESETS in an AX2010 own array installed in a big theatre with balcony. The TOP BOXES
of the array are aiming at the balcony while the DOWN FILL box is aiming at the audience close to the stage.
TOP BOXES: the power level at the end of
the balcony is lower, as well as the high
frequency level.
DOWN FILL BOXES: the power level in the
proximity of the stage is higher, as well as
the high frequency level.
PRESET USING EXAMPLE
In order to opmize the array performances for this specic applicaon, the
PRESETS should be used in the following way.
Load the STANDARD preset in the central boxes.
Load the LONG THROW preset in the TOP 1 or 2 boxes, in order to compensate
the loss of power level and high frequencies of the program sent the upper
deck of the theatre.
Load the DOWN FILL / SINGLE BOX preset in the BOTTOM box in order to
smooth the high frequency content of the program sent to the audience close
to the stage.
+15
dB
+10
+5
0
-5
-10
-15
-20
-25
-30
-35
20 50 100 200 500 1K 2K 5K 10K 20K Hz
LONG THROW
STANDARD
SINGLE/DOWNFILL
AX2010A - PRESET RESPONSE
TOP BOX
DOWN FILL BOX

PREDICTION: EASE Focus 2
To aim correctly a complete system we suggests to use always the Aiming Soware - EASE Focus 2:
The EASE Focus 2 Aiming Soware is a 3D Acousc Modelling Soware that serves for the conguraon
and modelling of Line Arrays and convenonal speakers close to reality. It only considers the direct
eld, created by the complex addion of the sound contribuons of the individual loudspeakers or
array components.
The design of EASE Focus is targeted at the end user. It allows the easy and quick predicon of the array
performance in a given venue. The scienc base of EASE Focus stems from EASE, the professional
electro- and room acousc simulaon soware developed by AFMG Technologies GmbH. It is based
on the EASE GLL loudspeaker data le required for its use: AXIOM_AX Series_v2_1.GLL, please note
that the version must be 2.0 or more. The GLL le contains the data that denes the Line Array with regard to its possible conguraons as well
as to its geometrical and acouscal properes.
Download the EASE Focus 2 app from the AXIOM website at hp://www.axiomproaudio.com/ clicking on downloads secon of the product.
Use the menu opon Edit / Import System Denion File to import the le AXIOM_AX Series_v2_1.gll from the installaon Data folder, the
detailed instrucons to use the program are located in the menu opon Help / User’s Guide.
Note: Some windows system can require the .NET Framework 4 that can be download from microso website at hp://www.microso.com/en-
us/download/default.aspx.
WARNING! CAREFULLY READ THE FOLLOWING INSTRUCTIONS AND CONDITION OF USE:
• This loudspeaker is designed exclusively for Professional audio applicaons. The product must be installed by qualied personal only.
• Proel strongly recommends that this loudspeaker cabinet be suspended taking into consideraon all current Naonal, Federal, State and
Local regulaons. Please contact the manufacturer for further informaon.
• Proel do not accept any liability for damage caused to third pares due to improper installaon, lack of maintenance, tampering or
improper use of this product, including disregard of acceptable and applicable safety standards.
• During assembly pay aenon to the possible risk of crushing. Wear suitable protecve clothing. Observe all instrucons given on the
rigging components and the loudspeaker cabinets. When chain hoists are in operaon ensure that there is nobody directly underneath or
in the vicinity of the load. Do not under any circumstances climb on the array.
AIMING and SUSPENDING INSTRUCTIONS
Fly Bar and accessories
The AX2010 Systems are built to allow the suspension of array with variable shape and dimensions. Thanks to a suspension mechanism designed
to be funconal, exible and safe, each system must be suspended or stacked using the KPTAX2012P y bar. The loudspeakers are linked together
in a column using a series of couplers integrated in the frame of each enclosure. Each system is set up properly both acouscally and mechanically
only using the aiming soware.
Coupling system in the front does not require any adjustment: using two
locking pins, each loudspeaker box is xed to the previous. The sloed bar in
the back is inserted in a U-shaped frame which features a series of numbered
holes. Sliding the sloed bar in the U-shaped frame of the next loudspeaker
and inserng a locking pin in one of the numbered holes, it is possible to
adjust the relave splay angle between two adjacent loudspeakers in the
array column.
KPTAX2012P y bar maximum capacity is 700 Kg (1540 lbs) with the 0° angle.
It can support up to 12 AX2010 loudspeakers with a safety factor of 10:1.
Follow the sequence in the gure for xing the y bar at the rst box. Usually
this is the rst step before liing up the system. Be careful to insert properly
all the locking pins (2)(3) and the shackle (5) in the right holes as specied by
the aiming soware.
When liing the system always proceed gradually step by step,
paying aenon to secure the y bar to the box (and the box to
the other boxes) before pulling up the system: this makes easier to
insert properly the locking pins. Also when the system is released
down, unlock gradually the pins.
During the liing be very careful to not let the cables enter the
space between one enclosure and the other, as their compression
could cut them.
1
2
2
3
4
1
5
KPTAX2012P FLY BAR ASSEMBLY SEQUENCE
SUSPEND HOLES
SUSPEND HOLE
INDICATOR
REAR BOX
PIN ATTACHMENT
FRONT BOX
PIN ATTACHMENT
FRONT BOX
PIN ATTACHMENT
STRAIGHT SHACKLE 16mm
M10 FOOT FOR
STACKED INSTALLATION
(OPTIONAL)
IDENTIFICATION AND
DATA LABEL
KPTAX2012P FLY BAR AND ACCESSORIES

Fly bar suspension and angle setup (centre of gravity)
The rst gure shows where the normal centre of gravity is with one box or several boxes arranged in a line. Usually the boxes are arranged to
make an arc for the best coverage of the audience, so the center of gravity moves backward. The aiming soware suggests the ideal suspension
pinpoint taking into account this behaviour: x the straight shackle in this posion.
Note that the ideal aiming angle oen doesn’t correspond to the pinpoint: there is oen a lile dierence between ideal aiming and real aiming
and its value is the remaining angle: posive remaining angle can be adjusted a lile using two ropes, negave remaining angle are self adjusted
a lile because the cables weighs on the back of the array. With some experience it’s possible to consider prevenvely these required lile
adjustments.
During the own set up you can connect the elements of
the array to their cables. We suggest to discharge the weight
of the cables from the ying pinpoint by tying them with a
texle bre rope, instead of leng them hang freely: in this
way the posion of the array will be much more similar to
the simulaon produced by the soware.
Pin locking and splay angles set up
The figure below shows how to insert correctly the
locking pin and how to set up the splay angle between
loudspeakers.
Wind loads
When planning an open-air event it is essenal to obtain current weather and wind informaon. When
loudspeaker arrays are own in an open-air environment, possible wind eects must be taken into
account. Wind load produces addional dynamic forces acng on the rigging components and the
suspension, which may lead to a dangerous situaon. If according to the forecast wind forces higher than
5 b (29-38 Km/h) are possible, the following acons have to be taken:
- The actual on-site wind speed has to be monitored permanently. Be aware that wind speed typically
increases with height above ground.
- Suspension and securing points of the array should be designed to support double the stac load in
order to withstand any addional dynamic forces.
WARNING!
Flying loudspeakers overhead at wind forces higher than 6 b (39-49 Km/h) is not recommended.
If the wind force exceeds 7 b (50-61 Km/h) there is a risk of mechanical damage to the components
which may lead to a dangerous situaon for persons in the vicinity of the own array.
- Stop the event and make sure that no person remains in the vicinity of the array.
- Lower and secure the array.
CENTRE OF GRAVITY
KPTAX2012P FLY BAR FOR FLOWN ARRAY
SINGLE PINPOINT FOR
STRAIGHT SHACKLE
KPTAX2012P FLOWN PINPOINT
< 0°/10°
< 0,5°/6,5°
Even degreesOdd degrees
1°
3°/0,5°
5°/2,5°
7°/4,5°
9°/6,5°
0°
2°
4°/1,5°
6°/3,5°
8°/5,5°
10°
Block cam
hole
Block cam
hole >
1° >
3° >
5° >
7° >
9° >
< 2°
< 4°
< 6°
< 8°
< 10°
Degrees
indicator >
Pi
n
HINGE BAR OF PREVIOUS BOX
LOUDSPEAKER SPLAY ANGLES SET UP
USE THIS HOLE TO
LOCK THE HINGE BAR
WHEN THE LOUDSPEAKER
IS REST
LOCK THE PIN IN THE
HOLE TO OBTAIN THE
REQUIRED SPLAY
ANGLE.
1° STEP HOLE
0,5° STEP HOLE
press and
insert
release and
lock
95AXM014 LOCKING PIN
press and
insert
release and
lock
95AXM014 LOCKING PIN

LIMITED WARRANTY
Proel warrants all materials, workmanship and proper operaon of this product for a period of two years from the original date of purchase. If any defects are found
in the materials or workmanship or if the product fails to funcon properly during the applicable warranty period, the owner should inform about these defects the
dealer or the distributor, providing receipt or invoice of date of purchase and defect detailed descripon. This warranty does not extend to damage resulng from
improper installaon, misuse, neglect or abuse. Proel S.p.A. will verify damage on returned units, and when the unit has been properly used and warranty is sll
valid, then the unit will be replaced or repaired. Proel S.p.A. is not responsible for any “direct damage” or “indirect damage” caused by product defecveness.
• This unit package has been submied to ISTA 1A integrity tests. We suggest you control the unit condions immediately aer unpacking it.
• If any damage is found, immediately advise the dealer. Keep all unit packaging parts to allow inspecon.
• Proel is not responsible for any damage that occurs during shipment.
• Products are sold “delivered ex warehouse” and shipment is at charge and risk of the buyer.
• Possible damages to unit should be immediately noed to forwarder. Each complaint for package tampered with should be done within eight days from product
receipt.
SAFETY INSTRUCTIONS
– To reduce the risk, close supervision is necessary when the product is used near children.
– Protect the apparatus from atmospheric agents and keep it away from water, rain and high humidity places.
– This product should be site away from heat sources such as radiators, lamps and any other device that generate heat.
– This product should be located so that its locaon or posion does not interfere with its proper venlaon and heang dissipaon.
– Care should be taken so that objects and liquids do not go inside the product.
– The product should be connected to a power supply mains line only of the type described on the operang instrucons or as marked on the product. Connect the
apparatus to a power supply using only power cord included making always sure it is in good condions.
– WARNING: The mains plug is used as disconnect device, the disconnect device shall remain readily operable.
– Do not cancel the safety feature assured by means of a polarized line plug (one blade wider than the other) or with a earth connecon.
– Make sure that power supply mains line has a proper earth connecon.
– Power supply cord should be unplugged from the outlet during strong thunderstorm or when le unused for a long period of me.
CE CONFORMITY
Proel products comply with direcve 2004/108/EC (EMC), as stated in EN 55103-1 and EN 55103-2 standards and with direcve 2006/95/CE (LVD), as stated in EN
60065 standard.
PROEL S.p.A. (World Headquarter) - Via alla Ruenia 37/43 - 64027 Sant’Omero (Te) - ITALY
Tel: [phone] Fax: [phone] www.axiomproaudio.com
Stacked installaon
WARNING!
• The ground where the KPTAX2012P Fly bar serving as ground support is
placed needs to be absolutely stable and compact.
• Adjust the feet so to lie the bar perfectly horizontal.
• Always secure ground stacked setups against movement and possible
pping over.
• A maximum of 4 x AX2010 cabinets with the KPTAX2012P Fly bar serving
as ground support are allowed to be set up as ground stack.
In the stack conguraon you have to use the three oponal BOARDAC2P feet and
the y bar must be mounted upside down on the ground.
Coupling system in the front do not require any adjustment: using two locking pins
each loudspeaker box is xed to the previous. The sloed bar in the back is inserted
in a U-shaped frame which features a series of numbered holes. Sliding the sloed
bar in the U-shaped frame of the next loudspeaker and inserng a locking pin in
one of the numbered holes, it is possible to adjust the relave splay angle between
two adjacent loudspeakers in the array column.
The opmal splay angles can be simulated using the EASE Focus 2 soware.
KPTAX2012P STACKED ARRAY
CENTER OF GRAVITY
max splay angle 5°
max splay angle 10°
max splay angle 10°
max splay angle 10°
