AXIOMTEK GOT-3571T User manual

GOT-3571T
5.7 VGATFT Fanless
TouchPanel computer
User’s Manual

ii
Disclaimers
The information in this manual has been carefully checked and is believed to
be accurate. AXIOMTEK Co., Ltd.assumes no responsibility forany
infringementsof patentsor other rightsofthird parties,which may result from
itsuse.
AXIOMTEK assumes no responsibility for any inaccuracies thatmay be
contained in this document.AXIOMTEK makes no commitment to update or to
keep current the information contained in this manual.
AXIOMTEK reserves the right to make improvementsto this document and/or
product atany time and without notice.
No part of this document may be reproduced,stored in aretrieval system, or
transmitted, in any form or by any means, electronic, mechanical,
photocopying, recording, or otherwise, without the prior written permission of
AXIOMTEK Co., Ltd.
Copyright 2008 byAXIOMTEK Co., Ltd.
All rights reserved.
November 2008, Version A1
Printed in Taiwan

iii
SafetyApprovals
uCE Marking
uFCC Class A
FCC Compliance
This equipment has been testedandcomplies withthelimitsfor a
Class Adigitaldevice, pursuant toPart 15 ofthe FCCRules. These
limitsare designedtoprovidereasonableprotectionagainst harmful
interference inaresidential installation. Ifnot installed and usedin
accordance with proper instructions, this equipment might generate or
radiateradio frequency energy andcause harmful interference to radio
communications. However,there is no guarantee that interference will
not occur in aparticular installation.Ifthis equipment doescause
harmful interference toradioor televisionreception,which canbe
determined byturningtheequipment offand on,theuser is
encouraged totryto correct the interference byoneor more ofthe
following measurers:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment intoan outlet on acircuit different from
that towhich the receiver isconnected.
4. Consult the dealer or an experienced radio/TV technician for help.
Shieldedinterface cables must be used in order to complywith
emission limits.

iv
SafetyPrecautions
Before gettingstarted, read thefollowingimportantcautions.
1. The GOT-3571Tdoes not comeequippedwithan
operatingsystem.An operating systemmust be loaded first
before installing anysoftware into the computer.
2. Be sure to groundyourselfto prevent static chargewhen
installing the internalcomponents. Use agroundingwrist
strap andplaceall electronic components inany
static-shieldeddevices. Most electronic componentsare
sensitive to static electricalcharge.
3. Disconnect thepower cord fromthe GOT-3571Tbefore
making anyinstallation.Besure boththesystemand the
external devices are turnedOFF. Sudden surge ofpower
could ruin sensitive components. Makesurethe
GOT-3571Tis properlygrounded.
4. The brightness ofthe flat paneldisplaydecreases with
usage. However, hours of use varydepending onthe
applicationenvironment.
5. Turn OFF the systempower before cleaning. Cleanthe
systemusing acloth only.Do not sprayanyliquid cleaner
directlyonto the screen. The GOT-3571Tcomes with a
touch screen.Althoughthe touch screen is chemical
resistant,itis recommended thatyouspraytheliquid
cleaner on acloth first before wipingthescreen. In case
your systemcomes without the touch screen,youmust
followthesameprocedure and not sprayanycleaneron
the flat panel directly.
6. Avoidusing sharp objects to operatethe touch screen.
Scratches onthetouch screen maycausemalfunction or
internal failureto the touch screen.
7. The flat panel displayisnotsusceptible toshock or
vibration. When assembling theGOT-3571T,makesure it
is securelyinstalled.

v
8. Do notopenthesystem sbackcover. Ifopeningthecover
for maintenance is amust, onlyatrainedtechnicianis
allowedto do so. Integrated circuits on computer boards
are sensitivetostatic electricity.Toavoid damagingchips
fromelectrostatic discharge, observe thefollowing
precautions:
üBefore handling aboard orintegrated circuit, touch an
unpainted portion of the system unit chassis for afew
seconds. This will help to discharge any static electricity on
your body.
üWhen handling boards and components, wear a
wrist-grounding strap, available from mostelectronic
component stores.
Trademarks Acknowledgments
AXIOMTEKis a trademarkofAXIOMTEK Co., Ltd.
IBM, PC/AT,PS/2, VGAaretrademarksof International
Business Machines Corporation.
Intel andPentiumare trademarks of Intel Corporation.
MS-DOS, Microsoft CandQuickBASICaretrademarks of
Microsoft Corporation.
VIAis a trademarkofVIA Technologies, Inc.
SSTis atrademarkofSiliconStorage Technology, Inc.
UMCis atrademarkofUnited Microelectronics Corporation.
Otherbrandnames andtrademarks are theproperties oftheir
respective owners.

vi
This page does not contain anyinformation.

Table ofContents
Tableof Contents
Disclaimers.........................................................................................................ii
Chapter 1 Introduction................................................................1
1.1 General Description.........................................................................1
1.2 Specifications...................................................................................2
1.2.1 Main CPUboard...............................................................................2
1.2.2 I/OSystem.......................................................................................2
1.2.3 System Specification........................................................................3
1.3 Dimensions......................................................................................3
1.4 I/OOutlets........................................................................................5
1.5 Package list.....................................................................................6
Chapter 2 Hardware Installation.................................................7
2.1 CompactFlashCard Installation.......................................................8
2.2 PC/104 Installation...........................................................................9
2.3 Serial Port Interface.......................................................................10
2.4 Ethernet.........................................................................................12
2.5 Mounting Way : Panel mount.........................................................12
Chapter 3 Phoenix-Award BIOS Utility....................................13
3.1 Entering Setup...............................................................................13
3.2 Control Keys..................................................................................14
3.3 GettingHelp...................................................................................14
3.4 The Main Menu..............................................................................15
3.5 Standard CMOS SetupMenu.........................................................16
3.6 Advanced BIOS Features...............................................................19
3.7 Advanced Chipset Features...........................................................22
3.8 Integrated Peripherals....................................................................24
3.9 Power Management Setup.............................................................29
3.10 PnP/PCI ConfigurationSetup.........................................................31
3.11 PC HealthStatus...........................................................................33
3.12 Load Optimized Defaults................................................................34
3.13 Set Supervisor/User Password.......................................................35
3.14 Save & Exit Setup..........................................................................36
3.15 Exit Without Saving........................................................................37
Chapter 4 Driver Installation.....................................................40
4.1 System...........................................................................................40
4.2 Touch Screen................................................................................41
4.2.1Specification.........................................................................41
4.2.2 Driver Installation - Windows Vista/XP..................................42

Table ofContents
MEMO

GOT-3571T User sManual
Introduction 1
C h a p t e r 1
Introduction
This chapter contains the general informationandthedetail
specifications oftheGOT-3571T.Chapter 1includesthe following
sections:
nGeneral Description
nSystem Specification
nDimensions
nI/O Outlets
nPackage List
1.1 General Description
The GOT-3571T is a5.7”fanless TFT VGAtouch panel computer. It is
equipped withCISI-based lowpower consumption processor,AMD
LX800.
Bysupporting the option of external batteryset, the GOT-3571T can
continue systemoperation ifamain power shortageever happens. In
addition, the PC/104 and Mini-PCIslotsare reservedfor expansion
availability.
The GOT-3571T supportsCompactFlash card and is the best choice
for applications offactoryautomation, machinerymaker,building
automation and semi-conductor.

GOT-3571T User sManual
Introduction 2
1.2 Specifications
1.2.1 Main CPU board
nCPU: AMDLX800 500MHz
nSystem Chipset: AMD LX + CS5536AD
nBIOS: Phoenix-Award 4Mbit with RPL/PXEEthernetBoot
ROM,Smartviewand customer CMOSbackup.
nSystemMemory: One 200-pin DDR SODIMM
Maximumup to1GB
1.2.2 I/O System
nStandard I/O:
−2 x serialports (1x RS-232, 1 x RS-232/422/485)
−2 x USBPorts 2.0compliant
nEthernet:
Equippedwith1 x RJ-45for 10/100base-T
nAudio:
RealtekAC 97 codec audio(Line-out)
nExpansion:
Equippedwith1 x Mini-PCI &1 x PC/104
nCompact Flash Socket:
One Compact Flash Type II Socket

GOT-3571T User sManual
Introduction 3
1.2.3 System Specification
n5.7 VGATFTLCD
nDisk drive housing:
−1 x Compact Flash Type II Socket
nDC 24V power input
nHeatdispensingdesign
nNet weight:
−2.0Kgs
nDimension (main bodysize):
−208.5x 167.3x 66.5 mm
nOperating temperature:
−O°to 45°C;Relativeumidity:50%
nRelative humidity:
−10%to85% @40°C, non-condensing
nAltitude:
−10,000 ft.(3,000 meters)
nVibration (operating):
−5 to500 Hz,2G random
nShock (operating):
−10 Gpeakacceleration (11 msec. duration)
1.3 Dimensions
The following diagramsshowthedimensions and outlines of
GOT-3571T.

GOT-3571T User sManual
Introduction 4
Note: The unit oflength is millimeter.

GOT-3571T User sManual
Introduction 5
1.4 I/O Outlets
The following figure showsthe I/O locations ofthe GOT-3571T.
1: Power Switch 6: LAN
2: DC power connector 7: USB 2.0x 2
3: COM 2 (RS-232) 8: Line-out
4: COM 1 (RS-232/422/485) 9: CompactFlash card
5: PC/104 slot

GOT-3571T User sManual
Introduction
6
1.5 Package list
When youreceivetheGOT-3571T,there are following itemsin the
package. If you can not findit, please contact AXIOMTEK distributors.
1. GOT-3571Tx 1
2. Panel mount kit x 6
3. Driver CD x1

GOT-3571T User sManual
Hardware Installation 7
C h a p t e r 2
Hardware Installation
The GOT-3571T providesrich I/O portsandflexible expansions for you
to meet different demand such as PCMCIA,WLAN module and so on.
The chapter will showyouhowto install the hardware.It includes :
nCompactFlash Card
nPC/104
nSerial Port
nEthernet
nMountingWay

GOT-3571T User sManual
Hardware Installation 8
2.1 CompactFlashCardInstallation
GOT-3571T offers one CF slot for users to install CompactFlash card.
Please refer to the following instructions and illustration:
Remove the rubber cover at left-side.
Install CompactFlash cardin theGOT-3571T.

GOT-3571T User sManual
Hardware Installation 9
2.2 PC/104 Installation
The GOT-3571Toffers aconvenientexpansionfor users to install
PC/104 module such as PCMCIA, WLAN, COM port card andso on.
Please followthe steps:
1. Unscrewscrews to remove the bracket.
2. Install PC/104 module.

GOT-3571T User sManual
Hardware Installation 10
PC/104 Bus Pin Assignment
Pin Pin Name Pin Pin Name Pin Pin Name Pin Pin Name
1 IOCHCHK 2 GND 3 SD7 4 RESETDRV
5 SD6 6 +5V 7 SD5 8 IRQ9
9 SD4 10 -5V 11 SD3 12 DRQ2
13 SD2 14 -12V 15 SD1 16 ENDXFR
17 SD0 18 +12V 19 IOCHRDY 20 GND
21 AEN 22 SMEMW23 SA19 24 SMEMR
25 SA18 26 IOW27 SA17 28 IOR
29 SA16 30 DACK3 31 SA15 32 DRQ3
33 SA14 34 DACK1 35 SA13 36 DRQ1
37 SA12 38 REFRESH 39 SA11 40 SYSCLK
41 SA10 42 IRQ7 43 SA9 44 IRQ6
45 SA8 46 IRQ5 47 SA7 48 IRQ4
49 SA6 50 IRQ3 51 SA5 52 DACK2
53 SA4 54 TC 55 SA3 56 SALE
57 SA2 58 +5V 59 SA1 60 OSC
61 SA0 62 GND 63 GND 64 GND
2.3 Serial Port Interface
The GOT-3571Thas twoonboard serial ports, COM1
(RS-232/422/485) & COM2(RS-232).
The pin assignments are listed below:
Description
1Data Carrier Detect (DCD)
2Receive Data (RXD)
3Transmit Data (TXD)
4Data Terminal Ready (DTR)
5Ground (GND)
6Data Set Ready (DSR)
7Request to Send (RTS)
8Clear to Send (CTS)
9Ring Indicator (RI)

GOT-3571T User sManual
Hardware Installation 11
In addition, COM1can be set for RS-232/422/485 byjumper.The jump
setting is listed as below:
COM1 JP12 JP10 JP11
RS-232 (default) 1-2 3-5, 4-6 3-5, 4-6
RS-422 3-4, 7-8 1-3, 2-4 1-3, 2-4
RS-485 5-6, 7-8 1-3, 2-4 1-3, 2-4
When COM1 set to RS-422or RS-485, the pin assignments are listed
below:
COM2 COM1

GOT-3571T User sManual
Hardware Installation 12
2.4 Ethernet
The GOT-3571T providesan NE2000 compatible Ethernet (RJ-45)
interface. For networkconnection, justplugin onecable endofthe
GOT-3571T 10/100 Base-THub into thestandard RJ-45 connector.
The pin assignment ofthe RJ-45 is listedbelow;
Pin Signal
1 TX+ (Data transmission positive
2 TX- (Data transmission negative)
3 Rx+(Data reception positive)
4 RJ45 termination
5 RJ45 termination
6 Rx- (Data reception negative)
7 RJ45 termination
8 RJ45 termination
2.5 Mounting Way:Panel mount
The GOT-3571Tis designedfor panelmount application. Tomount the
GOT-3571T,the standard set ofmounting kit (includedin the system
packaging) is needed.
12345678
RJ-45
