AXIOMTEK ICS-415V User manual

ICS-415V
Industrial Workstation
with 15” LCD and 8 Slot Backplane
User’s Manual

ii
Disclaimers
The information in this manual has been carefully checked and is
believed to be accurate. AXIOMTEK Co., Ltd. assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
AXIOMTEK assumes no responsibility for any inaccuracies that may
be contained in this document. AXIOMTEK makes no commitment to
update or to keep current the information contained in this manual.
AXIOMTEK reserves the right to make improvements to this document
and/or product at any time and without notice.
No part of this document may be reproduced, stored in a retrieval
system, or transmitted, in any form or by any means, electronic,
mechanical, photocopying, recording, or otherwise, without the prior
written permission ofAXIOMTEK Co., Ltd.
©Copyright 2006 by Axiomtek Co., Ltd.
All rights reserved.
September 2006, Version A2
Printed in Taiwan

Table of Contents iii
Table of Contents
Disclaimers................................................................................ii
Chapter 1
Introduction.....................................................................1
1.1 Features...............................................................................2
1.2 Specification .......................................................................3
1.2.1 General............................................................................. 3
1.2.2 Environmental Specifications........................................ 4
1.2.3 Touchscreen.................................................................... 4
1.3 Dimension ...........................................................................5
1.4 Package list.........................................................................6
Chapter 2
Hardware Installation......................................................8
2.1 Backplane Installation........................................................8
2.2 HDD / CD-ROM Installation.............................................. 11
2.3 CPU card and I/O ports Installation................................18
2.3.1 CPU card Installation.................................................... 18
2.3.1 I/O ports Installation ..................................................... 20
2.4 Touch Screen & VGA interface Installation...................21
2.4.1 VGA Installation ............................................................ 21
2.4.2 Touch Screen interface Installation ............................ 21
2.5 Power Supply Installation................................................22
2.6 System Filter Maintenance..............................................26
2.7 Power cord Fixing Kit Installation ..................................27
Chapter 3
Touch Screen Driver Installation .................................29
3.1 Specification .....................................................................29
3.2 Driver Installation- Windows 98/2000/XP.......................30

Table of Contents
iv
3.3 Driver Installation- DOS...................................................32
3.3.1 Install PenMount software driver................................. 32
3.3.2 Communication port and IRQ number ....................... 32
3.3.3 Do Calibration ............................................................... 33
3.3.4 Initializing the PenMount driver .................................. 33
3.4.5 Demonstration............................................................... 33
AppendixA
Power Supply Specification.........................................35

ICS-415V User’s Manual
Introduction
1
Chapter 1
Introduction
The ICS-415V is a multi-functional 15” TFT LCD workstation,
full/half-size CPU cards, and 8 PCI/ISA slots. The system also
provides a front-access design for CD-ROM/FDD/USB/PS2 to allow
users to maintain easily. The ICS-415V is a cost-effective workstation
for users to meet harsh environment needs, such as measurement
control, industrial machiney, oil pipe and more.
Easy-to-Maintain : Front access design for
CD-ROM/FDD/USB/PS2/OSD
With the front-access design, users can easily maintain, control, adjust
display position, and upgrade software. In addition, if the front I/O ports
are not in use, the ICS-415V is a IP65 compliant workstation with a
water-proof front panel.
Easy-to-Control : Touchpad and membrane keypad
The ICS-415V provides 24 function keys and 60 membrane keys,
which are easily used to set-up the overall system. The ICS-415V also
features a water-proof touchscreen and touchpad.
Easy-to-Backup：2 x 3.5” HDD
The ICS-415V supports two 3.5” HDD to let users backup data easily.
Industrial-Grade Product Design
The ICS-415V adopts a strong design and can be used in different
industrial harsh environments.
• Steel back chassis and Aluminum front bezel meets the
IP-65/NEMA4 standard.
• Supports a power bracket, which helps prevent the power core
coming off.
• Anti-vibration design for HDD
• Fan filter prevents dust from influencing system stability

ICS-415V User’s Manual
Introduction
2
1.1 Features
z15” TFT LCD workstation supports full/half-size CPU card &
8 PCI/ISA slots.
zFront accessible CD-ROM/FDD/USB/PS2/OSD.
zBuilt-in touchpad, 24 function keys and 60 membrane
keypads.
zCost-effective choice：supports 3.5” HDD/FDD/5.25”
CD-ROM
zEasy to expand：VGA interface
zFriendly I/O port：reserves parallel and COM port on chassis
zAnti-vibration design for HDD

ICS-415V User’s Manual
Introduction
3
1.2 Specification
1.2.1 General
zConstruction：Heavy-duty steel chassis, hardened aluminum
alloy front panel
zLCD：
Display Type: 15” TFT LCD active matrix
Resolution: 1024 x 768
Luminance: 250 cd/m2
Contrast Ratio: 150:1
Viewing Angle (Degree): 90° (V), 120° (H)
Backlight MTBF: 25000 hours
zDrive Capacity：Expose 1 x 5.25", 1 x Built-in 3.5" FDD, and
internal 2 x 3.5" drive
zData Entry：Sealed membrane programmable keypads
- 60 data-entry keys & 24 function keys
zLCD interface：VGA
zFront Panel I/O：Two USB, one keyboard/mouse port, power
switch
zFront Panel controls：Brightness adjustment and Backlight on/off
zMaximum acceptable card size：185 mm x 122 mm
zCooling system：One 18cm ball bearing fan
zDimensions：482.8mm(W) x 354.8mm(H)x 256mm(D)
zWeight：44 lbs (20kg)
zPassive Backplane：
ATX6022/8GP7 7 PCI slots Support AXIOMTEK PCI Full/Half-size
CPU Card
ATX6022/8 4 PCI & 3 ISA slots Support AXIOMTEK Full/Half-size
CPU Card

ICS-415V User’s Manual
Introduction
4
zPower Supply：
AC input: 300W
Input voltage‧：1000 VAC ~ 240 VAC
Output voltage‧：+3.3 V@20 A , +5 V@20 A, +12 V@14 A
MTBF:‧100,000 hours
1.2.2 Environmental Specifications
zOperating temperature：32° to 122°F (O° to 50° C)
zRelative humidity：10% to 95% @ 40° C, non-condensing
zAltitude：10,000 ft. (3,000 meters)
zVibration (operating)：5 to 500 Hz, 1 G random
1.2.3 Touchscreen
zType：8-wire Analog resistive
zResolution：Continuous
zLight transmission：79%
zController：RS-232 interface
zPower consumption：+5 V @200 mA
zSoftware driver：Supports both DOS and Windows 98/2000/XP

ICS-415V User’s Manual
Introduction
5
1.3 Dimension

ICS-415V User’s Manual
Introduction
6
1.4 Package list
When you receive the ICS-415V, there are following items in the
package. If you can not find it, please contact AXIOMTEK distributors.
1. ICS-415V *1
2. 45 cm VGA cable *1
3. 22 cm T/S male to female cable* 1
4. Panel mount kit * 8
5. Panel mount screw * 8
6. AC power cord *1
7. Power cord fixing kit *1
8. HDD screw * 8
9. CD-ROM screw * 8
10. Drive CD *1

ICS-415V User’s Manual
Introduction
7
Panel Mount * 8
Screw * 8
HDD screw * 8
CD-ROM screw * 8

ICS-415V User’s Manual
Hardware Installation
8
Chapter 2
Hardware Installation
The ICS-415V provides lots of flexible ways for you to select different
configuration such as backplane, CPU, I/O ports and more. The
chapter will show you how to install the hardware.
2.1 Backplane Installation
To access the backplane, remove the cover first and follow the steps.
1. Remove the screws which secure the back chassis.

ICS-415V User’s Manual
Hardware Installation
9
2. Select the backplane. ICS-415V supports two backplanes.
ATX6022/8 4 PCI + 3 ISA slots
ATX6022/8GP7 7 PCI slots

ICS-415V User’s Manual
Hardware Installation
10
3. Put twelve screws in the right place and screw the backplane.
The places of screwing ATX6022/8GP7 & ATX6022/8 are the same.

ICS-415V User’s Manual
Hardware Installation
11
2.2 HDD / CD-ROM Installation
The ICS-415V offers a convenient drive bay module for users to install
HDD/FDD/CD-ROM. When you receive the ICS-415V, a 3½” floppy
drive is already installed. Besides, the ICS-415V also offers two 3.5”
and one 5.25” drive for users to install. Please follow the steps.
1. Unscrew two screws at the secure kit and then unscrew four screws
at two drive bay module of the ICS-415V.

ICS-415V User’s Manual
Hardware Installation
12

ICS-415V User’s Manual
Hardware Installation
13
2. Take two drive bay modules out.

ICS-415V User’s Manual
Hardware Installation
14
3. Unscrew four screws in the drive bay module for CD-ROM.
4. Install and screw the CD-ROM.

ICS-415V User’s Manual
Hardware Installation
15
5. Put the HDD in the HDD drive bracket and fix it by four screws.
6. Take off the HDD bracket from the other drive bay and fix the HDD
by four screws.

ICS-415V User’s Manual
Hardware Installation
16
7. Finish the HDD and CD-ROM installing.
8. Before put these drive bay module in the ICS-415V, please notice
that there are three tracks for drive module each and install drive
module along the tracks.
