AXIOMTEK Qseven Q7B300 User manual

Q7B300
Qseven Module Development Board
User’s Manual

ii
Disclaimers
This manual has been carefully checked and believed to contain accurate information.
Axiomtek Co., Ltd. assumes no responsibility for any infringements of patents or any third
party’s rights, and any liability arising from such use.
Axiomtek does not warrant or assume any legal liability or responsibility for the accuracy,
completeness or usefulness of any information in this document. Axiomtek does not make any
commitment to update the information in this manual.
Axiomtek reserves the right to change or revise this document and/or product at any time
without notice.
No part of this document may be reproduced, stored in a retrieval system, or transmitted, in
any form or by any means, electronic, mechanical, photocopying, recording, or otherwise,
without the prior written permission of Axiomtek Co., Ltd.
CAUTION
If you replace wrong batteries, it causes the danger of explosion. It is recommended by the
manufacturer that you follow the manufacturer’s instructions to only replace the same or
equivalent type of battery, and dispose of used ones.
Copyright 2017 Axiomtek Co., Ltd.
All Rights Reserved
September 2017, Version A1
Printed in Taiwan

iii
ESD Precautions
Computer boards have integrated circuits sensitive to static electricity. To prevent chipsets
from electrostatic discharge damage, please take care of the following jobs with precautions:
Do not remove boards or integrated circuits from their anti-static packaging until you are
ready to install them.
Before holding the board or integrated circuit, touch an unpainted portion of the system
unit chassis for a few seconds. It discharges static electricity from your body.
Wear a wrist-grounding strap, available from most electronic component stores, when
handling boards and components.
Trademarks Acknowledgments
Axiomtek is a trademark of Axiomtek Co., Ltd.
Intel®and Celeron®are trademarks of Intel Corporation.
Windows®is a trademark of Microsoft Corporation.
AMI is a trademark of American Megatrend Inc.
IBM, PC/AT, PS/2, VGA are trademarks of International Business Machines Corporation.
Other brand names and trademarks are the properties and registered brands of their
respective owners.

iv
Table of Contents
Disclaimers.....................................................................................................ii
ESD Precautions...........................................................................................iii
Chapter 1 Introduction............................................. 1
1.1 Features...............................................................................................1
1.2 Specifications......................................................................................2
Chapter 2 Board and Pin Assignments.................... 5
2.1 Board Dimensions and Fixing Holes.................................................5
2.2 Board Layout.......................................................................................6
2.3 Installing Qseven Module and Thermal Solution..............................7
2.4 Jumper Settings..................................................................................8
2.4.1 PWR_OK Signal Source Selection (JP1).................................................... 9
2.4.2 LPC/GPIO Selection (JP2).......................................................................... 9
2.4.3 Enable/Disable COM function (JP3) ........................................................... 9
2.4.4 I2S/HDA Selection (JP4)............................................................................. 9
2.4.5 Route USB 2.0 Port 1 Signals (JP5)........................................................... 9
2.4.6 USB Port 1 OTG/Host Mode Selection (JP6) ........................................... 10
2.4.7 LVDS/eDP Function Selection (JP7)......................................................... 10
2.4.8 LVDS Voltage Selection (JP8)................................................................... 10
2.4.9 Boot BIOS Selection (JP9)........................................................................ 10
2.4.10 Restore BIOS Optimal Defaults (JP10)..................................................... 10
2.4.11 AT/ATX Power Mode Setting (JP11) ..........................................................11
2.5 Connectors ........................................................................................12
2.5.1 COM Connectors (CN1 and CN39)........................................................... 13
2.5.2 Front Panel Connector (CN2) ................................................................... 14
2.5.3 SMBus Connector (CN4) .......................................................................... 14
2.5.4 I2C Connector (CN5) ................................................................................ 15
2.5.5 CAN Connector (CN6) .............................................................................. 15
2.5.6 eDP Connector (CN7)............................................................................... 16
2.5.7 LVDS Connector (CN9)............................................................................. 17
2.5.8 ATX Power Connectors (CN10 and CN15)............................................... 18
2.5.9 Fan Connector (CN11) .............................................................................. 18
2.5.10 Inverter Connector (CN12)........................................................................ 19
2.5.11 SATA Power Connector (CN13)................................................................ 19
2.5.12 SATA Connectors (CN19 and CN21) ........................................................ 19
2.5.13 USB 3.0 Wafer Connector (CN20)............................................................ 20
2.5.14 SD Card Slot (CN22)................................................................................. 20
2.5.15 Qseven Connector (CN23)........................................................................ 21

v
2.5.16 PCI-Express Mini Card Connector (CN25) ............................................... 24
2.5.17 I2S Connector (CN26)............................................................................... 25
2.5.18 Digital I/O Connector (CN31) .................................................................... 25
2.5.19 PCI-Express x1 Slots (CN32~CN34) ........................................................ 26
2.5.20 Ethernet and USB 3.0 Ports (CN37 and CN41)........................................ 27
2.5.21 Audio Jack (CN38).................................................................................... 28
2.5.22 DisplayPort Connector (CN40).................................................................. 28
2.6 Push Buttons.....................................................................................29
2.7 LED Indicators...................................................................................29

vi
This page is intentionally left blank.

Q7B300 Qseven Module Development Board
Introduction 1
Chapter 1
Introduction
The Q7B300 is a new development baseboard for embedded Qseven Module and fully
compliant with the Qseven Specification 2.0 standard. The Qseven is an open industry
standard for Qseven modules, designed to be future proof and to provide a smooth transition
path from legacy parallel interfaces to LVDS interfaces. In addition to the standard output
signals for converting, Q7B300 provides one PCI-Express Mini Card socket and one SD card
slot for expansion purposes.
This board supports various I/O features: display interfaces (DP/eDP and LVDS), one
Gigabit/Fast Ethernet, HD audio codec, two SATA-600, two USB 3.0 and two RS-232
connectors.
With Q7B300, customers can develop their own applications and upgrade the system
configuration in advance to meet faster time-to-market.
1.1 Features
1 Gigabit Ethernet port
2 SATA connectors
2 RS-232/422/485,1 RS-232
3 PCIe x1 slots
3 USB 3.0 ports / 1 micro USB 2.0 port (Optional)
1 mini PCI-Express slot (PCIe+USB+SMBus)
1 SD card slot
LVDS or eDP/DP connector

Q7B300 Qseven Module Development Board
2 Introduction
1.2 Specifications
CPU
On the Qseven module.
System Chipset
On the Qseven module.
BIOS
On the Qseven module.
System Memory
On the Qseven module.
Onboard Multi I/O
Two RS-232/422/485.
One RS232 (RX/TX/RTS/CTS).
Serial ATA
Two SATA-600 connectors.
Ethernet
LAN chip on Qseven module.
1000/100/10Mbps Gigabit/Fast Ethernet interface (depend on module).
Audio
HD audio with line-in/line-out/MIC-in.
USB Interface
One micro USB 2.0 connector (Optional).
Three USB 3.0 connectors (USB 2.0 compliant).
SPI
Not supported.
I2C
Supported.
Digital I/O
Four inputs and four outputs.
Fan
Make sure you use the matching Q7B300 heatsink (P/N:7118Q311000E) or
heatspreader (P/N : 7128Q311000E) for connecting to Axiomtek Qseven module.

Q7B300 Qseven Module Development Board
Introduction 3
Display
One 40-pin connector for 18/24-bit single/dual channel LVDS and one 8-pin inverter
connector.
One eDP connector (switchable to LVDS with jumper setting).
One DisplayPort.
Expansion Interface
Full-size PCI-Express Mini Card socket which comply with PCI-Express Mini Card
Spec. V1.2.
Battery
Lithium 3V/220mAH.
Size
293.4 x 171.5mm.
Board Thickness
1.6mm.
Operation Temperature
-20°C ~ +70°C.
Operation Humidity
10% ~ 95% relative humidity, non-condensing.
Note
All specifications and images are subject to change without notice.

Q7B300 Qseven Module Development Board
4 Introduction
This page is intentionally left blank.

Q7B300 Qseven Module Development Board
Board and Pin Assignments 5
Chapter 2
Board and Pin Assignments
2.1 Board Dimensions and Fixing Holes
Top View
Front View

Q7B300 Qseven Module Development Board
6 Board and Pin Assignments
2.2 Board Layout
Top View
Front View

Q7B300 Qseven Module Development Board
Board and Pin Assignments 7
2.3 Installing Qseven Module and Thermal Solution
For thermal dissipation, a heatsink enables the components on the Qseven module to
dissipate heat efficiently. All heat generating components are thermally conducted to the
heatsink in order to avoid hot spots. Below images illustrate how to install the heatsink.
1. There is a protective plastic covering on the thermal pads. This must be removed before
the heatsink can be mounted.
2. Each heatsink is designed for a specific Qseven module. The thermal pads on the
heatsink are designed to make contact with the necessary components on the Qseven
module. When mounting the heatsink you must make sure that the thermal pads on the
heatsink make complete contact (no space between thermal pad and component) with
the corresponding components on the Qseven module. This is especially critical for
Qseven modules that have higher CPU speeds (for example 1.46GHz or more) to ensure
that the heatsink acts as a proper thermal interface for cooling solutions.
3. This CPU module has four assembly holes for installing heatsink plate. Fix the heatsink
plate to the Qseven module and install to carrier board. Be careful not to over-tighten the
screws.

Q7B300 Qseven Module Development Board
8 Board and Pin Assignments
2.4 Jumper Settings
Jumper is a small component consisting of jumper clip and jumper pins. Install jumper clip on 2
jumper pins to close. And remove jumper clip from 2 jumper pins to open. Below illustration
shows how to set up jumper.
Properly configure jumper settings on the Q7B300 to meet your application purpose. Below
you can find a summary table of all jumpers and onboard default settings.
Note
Once the default jumper setting needs to be changed, please do it under power-off
condition.
Jumper
Description
Setting
JP1
PWR_OK Signal Source Selection
Default: From ATX Power
3-4 Close
JP2
LPC/GPIO Selection
Default: LPC
2-3 Close
JP3
Enable/Disable COM function
Default: Disable
1-2 Close
JP4
I2S/HDA Selection
Default: HDA
2-3 Close
JP5
Route USB 2.0 Port 1 Signals
Default: To Standard USB A Connector
2-3 Close
JP6
USB Port 1 OTG/Host Mode Selection
Default: Host Mode
2-3 Close
JP7
LVDS/eDP Function Selection
Default: LVDS
1-2 Close
JP8
LVDS Voltage Selection
Default: +3.3V
1-2 Close
JP9
Boot BIOS Selection
Default: Boot from Module BIOS
1-2 Close
JP10
Restore BIOS Optimal Defaults
Default: Normal Operation
1-2 Close
JP11
AT/ATX Power Mode Setting
Default: ATX Mode
2-3 Close

Q7B300 Qseven Module Development Board
Board and Pin Assignments 9
2.4.1 PWR_OK Signal Source Selection (JP1)
Use JP1 to select PWR_OK signal source.
2.4.2 LPC/GPIO Selection (JP2)
Use JP2 to select LPC or GPIO.
2.4.3 Enable/Disable COM function (JP3)
Use JP3 to enable or disable COM port function from carrier board NTC5104.
2.4.4 I2S/HDA Selection (JP4)
Use JP4 to select I2S or Intel HDA.
2.4.5 Route USB 2.0 Port 1 Signals (JP5)
Use JP5 to route USB 2.0 port 1 to standard USB A connector or to micro AB.
Function
Setting
Pull up to signal PWR_OK
1-2 close
From ATX power (Default)
3-4 close
From carrier DC/DC circuit
5-6 close
Function
Setting
GPIO
1-2 close
LPC (Default)
2-3 close
Function
Setting
Disable (Default)
1-2 close
Enable
2-3 close
Function
Setting
I2S
1-2 close
HDA (Default)
2-3 close
Function
Setting
Route to micro AB
1-2 close
Route to standard USB A connector (Default)
2-3 close

Q7B300 Qseven Module Development Board
10 Board and Pin Assignments
2.4.6 USB Port 1 OTG/Host Mode Selection (JP6)
The USB port 1 supports two modes of operation: USB Host mode and OTG
(On-The-Go) mode; they are selectable through jumper JP6.
2.4.7 LVDS/eDP Function Selection (JP7)
The JP7 is for LVDS or eDP function selection.
2.4.8 LVDS Voltage Selection (JP8)
The board supports voltage selection for flat panel displays. Use this jumper to set LVDS
connector (CN9) pin 1~6 VCCM to +3.3V, +5V or +12V. To prevent hardware damage,
before connecting please make sure that the input voltage of flat panel is correct.
2.4.9 Boot BIOS Selection (JP9)
Use JP9 to select system to boot from module BIOS or from carrier BIOS.
2.4.10 Restore BIOS Optimal Defaults (JP10)
Put jumper clip to pin 2-3 for a few seconds then move it back to pin 1-2. Doing this
procedure can restore BIOS optimal defaults.
Function
Setting
Set USB port 1 to OTG mode
1-2 close
Set USB port 1 to Host mode (Default)
2-3 close
Function
Setting
LVDS (Default)
1-2 close
eDP
2-3 close
Function
Setting
+3.3V (Default)
1-2 close
+5V
3-4 close
+12V
5-6 close
Function
Setting
On module SPI flash (Default)
1-2 close
Carrier SPI flash
2-3 close
Function
Setting
Normal (Default)
1-2 close
Restore BIOS optimal defaults
2-3 close

Q7B300 Qseven Module Development Board
Board and Pin Assignments 11
2.4.11 AT/ATX Power Mode Setting (JP11)
Use JP11 to select AT orATX power mode.
Function
Setting
AT mode
1-2 close
ATX mode (Default)
2-3 close

Q7B300 Qseven Module Development Board
12 Board and Pin Assignments
2.5 Connectors
Signals go to other parts of the system through connectors. Loose or improper connection
might cause problems, please make sure all connectors are properly and firmly connected.
Here is a summary table which shows all connectors on the hardware.
Connector
Description
CN1
COM Wafer Connector
CN2
Front Panel Connector
CN4
SMBus Connector
CN5
I2C Connector
CN6
CAN Connector
CN7
eDP Connector
CN9
LVDS Connector
CN10, CN15
ATX Power Connectors
CN11
Fan Connector
CN12
Inverter Connector
CN13
SATA Power Connectors
CN19, CN21
SATA Connectors
CN20
USB 3.0 Port 2 Wafer Connector
CN22
SD Card Slot
CN23
Qseven Connector
CN25
PCI-Express Mini Card Connector
CN26
I2S Connector
CN31
Digital I/O Connector
CN32~CN34
PCI-Express x1 Slots
CN37
Ethernet, USB 3.0 Port 0 and 1 Stack
CN38
Audio Jack
CN39
COM D-Sub Connector
CN40
DisplayPort Connector
CN41 (Optional)
USB 2.0 Port 1

Q7B300 Qseven Module Development Board
Board and Pin Assignments 13
2.5.1 COM Connectors (CN1 and CN39)
The board has three serial port connectors. The CN1 is a 2x5-pin wafer connector for
RS-232 interface from module.
CN1
The CN39 is a double-deck DB-9 connector for RS-232/422/485 interface from carrier
board. Each serial port is selectable to operate in different mode through BIOS setting.
CN39
Note
Use jumper JP3 to enable or disable COM port function on CN39, see
section 2.4.3.
Pin
Signal
1
NC
2
NC
3
Receive Data (RXD)
4
Request To Send (RTS)
5
Transmit Data (TXD)
6
Clear To Send (CTS)
7
NC
8
NC
9
Ground (GND)
10
NC
Pin
Pin
RS-232
RS-422
RS-485
1
10
Data Carrier Detect
(DCD)
TX-
Data-
2
11
Receive Data (RXD)
TX+
Data+
3
12
Transmit Data (TXD)
RX+
No use
4
13
Data Terminal Ready
(DTR)
RX-
No use
5
14
Ground (GND)
No use
No use
6
15
Data Set Ready (DSR)
No use
No use
7
16
Request to Send (RTS)
No use
No use
8
17
Clear to Send (CTS)
No use
No use
9
18
Ring Indicator (RI)
No use
No use

Q7B300 Qseven Module Development Board
14 Board and Pin Assignments
2.5.2 Front Panel Connector (CN2)
The CN2 is a 2x5-pin connector for front panel interface.
ATX Power Supply ON
Short pin 1 and pin 2, ATX power supply is forcing to turn on state. Otherwise, system
will control ATX power supply state.
Power LED
Pin 4 connects anode(+) of LED and pin 3 connects cathode(-) of LED. The power LED
lights up when the system is powered on.
Power On/Off Button
Pin 5 and 6 connect the power button on front panel to the CPU board, which allows
users to turn on or off power supply.
System Reset Switch
Pin 7 and 8 connect the case-mounted reset switch that reboots your computer without
turning off the power switch. It is a better way to reboot your system for a longer life of
system power supply.
HDD Activity LED
This connection is linked to hard drive activity LED on the control panel. LED flashes
when HDD is being accessed. Pin 9 and 10 connect the hard disk drive to the front panel
HDD LED, pin 9 is assigned as cathode(-) and pin 10 is assigned as anode(+).
2.5.3 SMBus Connector (CN4)
The CN4 is a 5-pin connector for SMBus interface. The SMBus (System Management
Bus) is a simple bus for the purpose of lightweight communication.
Pin
Signal
Pin
Signal
1
GND
2
ATX_PSON#
3
PWRLED-
4
PWRLED+
5
PWRSW-
6
PWRSW+
7
HW RST-
8
HW RST+
9
HDDLED-
10
HDDLED+
Pin
Signal
1
+3.3V
2
SMB_CLK
3
SMB_DATA
4
SMB_ALERT
5
GND
