Axis T8342 User manual

AXIST8342Door/WindowSensor
UserManual

AXIST8342Door/WindowSensor
TableofContents
Solutionoverview...........................................3
Productoverview...........................................4
HowtoaddadevicetoaZ-WaveNetwork......................5
HowtotesttheZ-Wavedevice................................6
Operationalguidelines...........................................6
HowtoprogramtheZ-Wavedevice............................7
Troubleshooting............................................10
Specications..............................................11
2

AXIST8342Door/WindowSensor
Solutionoverview
Solutionoverview
ThedeviceisZ-Wave®enabledandfullcompatiblewithanZ-Waveenablednetwork.ThedevicecanbesetupinaZ-Wave
networktocommunicatedirectlwithotherenddevicessuchaslightingcontrollers,ortoreportdirectltoaZ-Wavecontrollerlike
theAXISM5065PTZNetworkCamera.
3

AXIST8342Door/WindowSensor
Produtoverview
Produtoverview
1.LED
2.Batter
3.Tamperswitch
4.Magnet
5.Detector
6.Screwhanger
7.Batterprotectionlm
4

AXIST8342Door/WindowSensor
HowtoaddadevietoaZ-WaveNetwork
HowtoaddadevietoaZ-WaveNetwork
Autoinclusion
ThedetectorsupportstheautoinclusionfeaturewhereitwillautomaticallenterInclusionmodewhenrstpoweredup.
1.PutaZ-Wavecontrollerintoinclusionmode.
2.Removethestripofbatterprotectionlmstickingoutfromthebattercoveronthefrontofthecasing.TheLEDon
thedeviceshouldturnON.
3.EnterPINnumberintotheZ-Wavecontroller.ThePINnumbercanbefoundonthedevice.Seewhereintheinstallation
guide.
4.TheinclusionprocessshouldbecompletedwhentheLEDstopsblinking.
5.Performtestbeforeouretthebattercover.SeeHowtotesttheZ-Waveevice.
Manualinclusion
YoucanalsochoosetomanualladdtheZ-Wavedevicetoacontroldevice.Pleasefollowthestepsdescribedbelow.
Note
Forbestresults,excludethedevicebeforestartingtheinclusionprocess.Formoredetailsseetheinstallationguide.
1.Removethebattercover.
2.Pressthetamperswitch3timeswithin1.5secondstoputtheunitintolearning(inclusion/exclusion)mode.
3.EnterPINnumberintotheZ-Wavecontroller.ThePINnumbercanbefoundonthedevice.Seewhereintheinstallation
guide.
4.TheinclusionprocessshouldbecompletedwhentheLEDstopsblinking
5.Performtestbeforeouretthebattercover.SeeHowtotesttheZ-Waveevice.
Manualexclusion
1.Removethebattercover.
2.Pressthetamperswitch3timeswithin1.5secondstoputtheunitintolearning(inclusion/exclusion)mode.
3.TheexclusionprocessshouldbecompletedwhentheLEDstopsblinking
4.Retthebattercover.
5

AXIST8342Door/WindowSensor
HowtotesttheZ-Wavedevie
HowtotesttheZ-Wavedevie
•Removethebattercoverwiththetamperswitchnotbeingpressedonthedetector(testmode)
•Separatethemagnetfromthedetector.Thedetectorshouldthenash.
•Putthebattercoverbackonthedetector,andthedetectorwillenternormalmode.
Note
Ifouhaveremovedthebatteries,wait5secondsbeforeouretthem.
Operationalguidelines
•Duetothelimitedpowersuppliedfromthebatteries,thedevicemanotoperatecontinuouslforanextendedperiodof
time.Therefore,thesetuptimefordeviceshouldbeminimized,andrepeatedpressesofthetamperswitchshouldbe
avoided,inordertopreventincidentscausedbaquickbattervoltagedrop.
•Youcanentertestmodebreleasingthetamperswitch.Ifthemagneticsensoristriggeredduringthattime,thentheLED
willbeilluminated.Youcanconrmwhetherthetamperswitchhasbeenpressedproperlbtestingthisfunction.
•Whenthetamperswitchhasbeenpressedandthedevicehasenterednormalmode,theLEDwillnotbeilluminatedeven
ifthemagneticsensoristriggered,unlesslowbatterisdetected.
6

AXIST8342Door/WindowSensor
HowtoprogramtheZ-Wavedevie
HowtoprogramtheZ-Wavedevie
Note
ProgrammingZ-WavedevicesusingaZ-Wavecontrollerisrecommendedforexperiencedusersonl.
Z-WaveGroup
ThedetectorsupportseitheroneoftwoZ-WaveAssociationGroups:
Group1:Associationwith1controllernode.
Group2:Associationwith4nodes(i.e.enddevicessuchassmartplugsandotherlightingcontrollers).Thisallowsthedetectorto
transfercommandsdirectltoenddeviceswithouttheparticipationofthecontroller.Thishastheeffectthatwhenthedetector
triggers,alldevicesassociatedwithdetectorwillbeoperated.
Note
Association-groupsupportcanvaramongZ-WaveControllers.TheAXISM5065supportsZ-WaveAssociationGroup1.
Group1commands:
•IfthedevicealreadisapartofaZ-Wavenetworkwhenpoweredup,thedevicewillsendaNoticationReportto
thenodeinGroup1.
•Whensettingupthedeviceorchangingthedevice’sstatus,thedevicewillsendaBinarSwitchReporttothenodeof
Group1.WhenthedeviceisturnedOFF,theSwitchBinarReportValue=0x00.WhenthedeviceisturnedON,the
SwitchBinarReportValue=0xFF.
•DeviceReset:WhenperformingFactorReset,thedevicewillsendDeviceResetLocallNoticationtothenodeofGroup1.
Group2commands:
•Whenthebuttononthedeviceispressed,thedevicewillsendaBasicSetcommandtothenodesofGroup2.Whenthe
deviceisOFF,BasicSetValue=0x00.WhentheunitisON,BasicSetValue=0xFF
Z-WavePlus® ®
®info
RoletypeNodetypeInstallerIconUserIcon
SlaveSleepingreportZ-WavePlusnodeSensorNoticationDeviceTpe
(AccessControl)
SensorNoticationDeviceTpe
(AccessControl)
Version
Protocollibrary3(Slave_Enhance_232_Librar)
Protocolversion4.6(6.71.00)
Manufacturer
ManufacturerIProductTypeProductI
0x03640x00030x0001
AGI(AssociationGroupInformation)table
7

AXIST8342Door/WindowSensor
HowtoprogramtheZ-Wavedevie
GroupProleCommandClass&Command
(List)Nbytes
GroupName(UTF-8)
1GeneralNoticationReport
DeviceResetLocallNotication
Lifeline
2ControlBasicSetPIRControl
Notication
EventTpeEventEventParameters
Length
EventParameters
Thepowerisappliedforthersttime0x080x01null
ThebatterisLow0x080x0Anull
DoorsensortriggerOPEN0x060x16null
DoorsensordetectortriggerClose0x060x17null
Tamperswitchpressedformorethan10seconds
andthenreleased
0x070x03null
Tamperswitchpressed0x070x00null
Battery
BatterReport(value)Description
0x64Batterishigh
0x10Batterisnormal
0xFFBatterislow
Commandclasses
Thisproductsupportsthefollowingcommandclasses:
•COMMAND_CLASS_ZWAVEPLUS_INFO_V2
•COMMAND_CLASS_ASSOCIATION_V2
•COMMAND_CLASS_ASSOCIATION_GRP_INFO
•COMMAND_CLASS_TRANSPORT_SERVICE_V2
•COMMAND_CLASS_VERSION_V2
•COMMAND_CLASS_MANUFACTURER_SPECIFIC_V2
•COMMAND_CLASS_DEVICE_RESET_LOCALLY
•COMMAND_CLASS_POWERLEVEL
•COMMAND_CLASS_SECURITY
•COMMAND_CLASS_SECURITY_2
•COMMAND_CLASS_SUPERVISION
•COMMAND_CLASS_FIRMWARE_UPDATE_MD_V4
•COMMAND_CLASS_BATTERY
8

AXIST8342Door/WindowSensor
HowtoprogramtheZ-Wavedevie
•COMMAND_CLASS_WAKE_UP_V2
•COMMAND_CLASS_NOTIFICATION_V4
Wakeupcommandclass
AfterthedetectorhasbeenincludedintoaZ-Wavenetworkitwillgotosleep,butitwillsendawake-upnoticationcommandto
thecontrollerperiodicallatapresetperiod.Thedetectorwillstaawakeforatleast10secondsandthengobacktosleepto
conservebatterlife.
Thetimeintervalbetweenwakeupnoticationcommandscanbesetinthewakeupcommandclassbasedontherangevaluesbelow:
Minimumwakeupinterval600s(10minutes)
Maximumwakeupinterval86400s(1da)
Defaultwakeupinterval14400s(4hours)
Wakeupintervalstepseconds600s(10minutes)
9

AXIST8342Door/WindowSensor
Troubleshooting
Troubleshooting
ThetablebelowexplainsthestatusintheZ-WavecontrolleraswellastheLEDindicationonthedevice.
Action/StatusescriptionLEindication
NonodeID.TheZ-Wavecontrollercouldnotndthedeviceanddidnot
provideanodeID.
2-secondon,2-secondofffor2
minutes.
1.Pressthetamperswitch3timeswithin1.5secondstoputthe
unitintoexclusionmode.
2.Within1secondofstep1,pressthetamperswitchagainand
holdfor5seconds.
FactorReset
(Thisprocedure
shouldonlbeused
whenthecontroller
isinoperable.)3.NodeIDisexcluded.Thedevicerevertstofactordefaultstate.2-secondon,2-secondofffor2
minutes.
Failedorsuccessfulresultsinincluding/excludingtheIDcanbeviewedontheZ-WaveController.
Tablebelowliststpicalproblemsencountered:
SymptomPossiblecauseRecommendation
Cannotcarroutinclusion
andassociation.
1.Thedeviceisstillconnected,orhasbeen
accidentallincluded,toapreviousnetwork.
2.TheenteredPINcodeisincorrect
3.Thebatterhasrunoutofpower.
4.Batterpolaritisreversed.
5.Detectorismalfunctioning.
1.Excludethedevicebefore
includingitagain.
2.Makesureouhave
enteredthecorrectPIN
code
3.Replacethebatter.
4.Retthebatterwiththe
correctpolarit.
5.Ensurethedetectoris
workingproperl.
Cannotcontroltheconnected
modules.
1.Thedeviceisstillconnected,orhasbeen
accidentallincluded,toapreviousnetwork.
2.Thebatterhasrunoutofpower.
3.Detectorismalfunctioning.
1.Excludethedevicebefore
includingitagain.
2.Replacethebatter.
3.Ensurethedetectoris
workingproperl.
Thedetectorisnotworking.1.Thedeviceisstillconnected,orhasbeen
accidentallincluded,toapreviousnetwork.
2.Thebatterhasrunoutofpower.
3.DistancebetweentheAlertButtonandthe
receiver(s)toofar.
4.Detectorismalfunctioning.
1.Excludethedevicebefore
includingitagain.
2.Replacethebatter.
3.Moveclosertothe
receivers.
4.Ensurethedetectoris
workingproperl.
Note
Forbestresults,excludethedevicebeforestartingtheinclusionprocess.Formoredetailsseetheinstallationguide.
0

AXIST8342Door/WindowSensor
Speifiations
Speifiations
Tondthelatestversionoftheproduct’sdatasheet,gototheproductpageonaxis.comandlocateSupport&ocumentation.
Specications
BatterCR24503.0VLithiumBatterx2
Batterlife1ear*
RangeUpto100meterslineofsight
Frequencrange908.42MHz(US),922.5MHz(JP)
Specicationsaresubjecttochangewithoutnotice
*measuredat10triggersperda

UserManualVer.M1.7
AXIST8342Door/WindowSensorDate:Januar2018
©AxisCommunicationsAB,2017-2018PartNo.T101 17078
