AXISP5676-LEPTZCamera
RepaintingInstructions

AXISP5676-LEPTZCamera
Impactonwarranty
Impactonwarranty
ThisproductisapprovedforrepaintbyAxis,providedthatyoufollowtheinstructionsinthisdocumentandat
axis.com/warranty-implication-when-repainting.
Riskswithrepainting
ThereareseveralriskswhendisassemblingorassemblinganAxisproduct.Thereisalwaysacertainyieldlossduringassembly.Training
ofoperatorsandtheuseofcorrecttoolsmediatessomeoftheproblemsbuttheycanneverbefullyavoided.Someoftherisksinclude:
ESDDamage-AlwayshandletheproductinanESDsafeenvironment.EvenifprecautionsaretakenthereisalwaysariskofESD
damage.Thedamagecanremainundetectedandcauseproblemsduringthelifetimeoftheeuipment.
Dustcontamination-Openingacameramayexposethelensandsensortodustorpaint.Dustwillaffecttheopticalperformance.
Lensesneedtobedisassembledinadust-freeenvironment,preferablyacleanroom.
Paintoverspray-Maskingthedifferentcomponentsoftheeuipmentiscritical.Failuretomasksensitiveareascancauseproblems
withassemblingtheeuipment.Anyareasthatarenotpaintedatfactoryorhaveadifferentsurfacetreatmentthantherestofthe
parts(threads,groundandelectricalcontactsurfaces)mustalsobemaskedtoensurefunction.
2

AXISP5676-LEPTZCamera
Repainttheprouct
Repainttheprouct
Preparations
•Ifapplicable,disassemblethedeviceaccordingtotheinstructionsinthisdocument.
•Cleanallpartsthatwillberepaintedthoroughlytoremovegrease,dust,oroil.
•Toensurereassemblyandfunctionalityoftheproduct,maskanyopenings(forexampleforscrews,LEDindicators,
ormicrophones)beforeyoupaint.
Pretreatmentofparts
Dependingonthepartmaterialandtypeofpaintappliedatfactory,differentpretreatmentshouldbedoneforthenewpaintto
adhereaswellaspossible.Cleanthepartsproperlytoremoveoil,greaseanddust.
Powdercoatedparts-Useaprimer.Alternatively,removetheoriginalpowdercoatingdowntothebasematerial,usingne
sandpaper,andcleanthepartsbeforepainting.
Anodisedandchromatedparts-Useaprimer.
Uncoatedstainlesssteel-Nospecialpretreatmentisneeded,butmakesurethatthesurfaceiscleanbeforepainting.
Plastic-Useaprimer.
ThematerialusedinthisdeviceisASAandpolycarbonate(PC).
isassembly
1.Removethethreetopcoverscrews(T20).
2.Removethetopcover.
3

AXISP5676-LEPTZCamera
Repainttheprouct
1Topcoverscrews
2Topcover
3Triangularmarking
Repainting
1.Makesureallnecessarypreparationsofthetopcoverhavebeenmade.SeePreparationsonpage3.
2.Applyathinandevenlayerofspraypaintaccordingtotheinstructionsofthepaintmanufacturer.
3.Letthepaintdry.
4.Togetabettercoverageandclearercolor,applyasecondlayerofspraypaint.
Reassembly
1.Assemblethetopcover.Usethetriangularmarkingtopositionitcorrectly.
2.Fastenthetopcoverscrewswithatorueof0.7Nm(T20).
4

RepaintingInstructionsVer.M2.2
AXISP5676-LEPTZCameraDate:November2022
©AxisCommunicationsAB,2022PartNo.T10187657
