SGM-1X — perfect for mid-sized cameras
Designed for cameras similar to the XL-2 and PD-170, the SGM-1X
is 298mm (11.75") long and comes with a foam windscreen, shock-
mount with integral shoe-mount, low impedance XLR output and
features a switchable low frequency filter. A single “AAA” battery can
operate the mic for approximately to 1000 hours.
At 216mm (8.5"), the mini SGM-X is a complete shotgun solution for
small, Mini DV cameras. Included is a shoe-mount holder, windscreen,
battery (LR-44) and mini-to-mini jack cable.
SMX-10 – high-performance stereo microphone
Now you can record in stereo directly with Azden’s SMX-10. The 160mm (6.3")
long dual uni-directional electret-condensor mic is powered by a single “AAA”
battery (not included), features a built-in cable with a 3.5mm stereo mini plug and
comes with a windscreen and camera shoe-mount.
SGM-1000 Phantom-Powered Shotgun Microphone
Use either 12-48V Phantom power or a single internal “AA” battery
•new, high performance mic element • 310mm (12.2") long
•wide frequency response • highly directional pick-up pattern
•high sensitivity and low noise • XLR output • switchable low
frequency filter • foam windscreen • shock-mount holder with
integral shoe-mount
Two microphones in one, the SGM-2X can be configured as either a
400mm (15.75") long shotgun or, by changing to the included short
barrel, a 206mm (8.125") long general purpose omni-directional mic.
Its low-noise, wide frequencyresponse element provides a low
impedance output (XLR) and uses a single “AAA” battery. The mic
comes with a switchable low frequency filer, a shock-mount with
built-in shoe-mount and windscreens for both configurations.
SGM-X — designed for today’s
Mini DV cameras
SGM-2X — Ideal for full sized cameras
PROFESSIONAL SHOTGUN MICROPHONES

Azden Corp., P.O. Box 10, Franklin Square, NY 11010
tel: [phone] • fax: [phone]
email: [email protected] • web: www.azdencorp.com
* Due to constant improvements, specifications are subject to change without notice.
SpecificationsSpecifications
SpecificationsSpecifications
Specifications**
**
*
SGM-1000
Frequency Response: 80-20,000Hz
Low-Cut Roll-Off: 6dB/Octave@ 200Hz
Sensitivity: Super Cardioid -33dB re1v/PA
Impedance: 1.5k Ohms @ 1kHz
Max.Spl Input Level: 120dB
Signal To Noise Ratio: 70dB
Dynamic Range: 96dB
Battery Type: "AAA" (1.5V) - UseAlkaline Battery
Battery Current: 0.2mA
Battery Life: 1000 Hours w/Alkaline Battery
Weight w/o Battery: 4.94oz (140grams)
Dimensions: 12.2 in. (310mm) length, 0.83 in. (21mm) diameter
Output Type: 3-Pin XLR Type
SuppliedAccessories: 1Shock Mount Mic Holder,Windscreen, Carry-Pouch
SGM-2X
Frequency Response: 40-20,000Hz
Low-Cut Roll-Off: 6dB/Octave @ 200Hz
Sensitivity: Super Cardioid -39dB re 1V/Pa
Omni-directional -45dB re 1V/Pa
Impedance: 680 Ohms @ 1Khz
Max. SPL Input Level: 110dB
Signal to Noise Ratio: 70dB
Dynamic Range: 85dB
Battery Type: “AAA” (1.5V) - useAlkaline battery
Battery Current: 0.2mA
Battery Life: 1000 Hours w/Alkaline Battery
Weight w/o Battery: Long + Short Barrel 6.5oz (185grams)
Short Barrel 3.9oz (110grams)
Dimensions: Long + Short Barrel 16 in. (400mm) length
Long + Short Barrel 0.83 in. (21mm) diameter
Short Barrel 8.4 in. (212.5mm) length
Short Barrel 0.83 in. (21mm) diameter
Output Type: 3-Pin XLR type
SuppliedAccessories: Shock mount mic holder, 2 Windscreens
SGM-1X
Frequency Response: 80-18,000Hz
Sensitivity: Super Cardioid -41dB re 1V/Pa
Impedance: 680 Ohms @ 1Khz
Max. SPL Input Level: 110dB
Signal to Noise Ratio: 65dB
Dynamic Range: 80dB
Battery Type: “AAA” (1.5V) - useAlkaline battery
Battery Current: 0.2mA
Battery Life: 1000 Hours w/Alkaline Battery
Weight w/o Battery: 4.76oz (135grams)
Dimensions: 11.8 in. (300mm) length
0.83 in. (21mm) diameter
Output Type: 3-Pin XLR type
SuppliedAccessories: Shock mount mic holder, 1 Windscreen
SGM-X
Frequency Response: 80-18,000Hz
Sensitivity: SUPER CARDIOID -33dB re: 1V/PA
Impedance: 1.5k Ohms @ 1KHz
Max. SPL Input Level: 103dB
Signal to Noise Ratio: 65dB
Dynamic Range: 78dB
Battery Type: LR-44 - use Alkaline battery
Battery Current: 0.5 mA
Battery Life: 150 HOURS w/Alkaline battery
Weight w/o Battery: 3.75oz (106grams)
Dimensions: 8.34 in. (212mm) length
0.83 in. (21mm) diameter
Output Type: 3.5mm mini-jack
SuppliedAccessories: Shoe-Mount Microphone Holder
1-Windscreen
1-Output Cable (3.5mm mini-plug - 3.5mm mini-plug)
1-LR-44 Battery
SMX-10
Type: Stereo Electret Condenser
Frequency Response: 100-18,000Hz
Sensitivity: -40dB @1kHz (1V/Pa)
Output Impedance: 1.5 k ohm @ 1kHz
Signal-to-Noise Ratio: 60dB (1kHz @ 1Pa)
Dynamic Range: 66dB
Power Supply: 1.5VDC ("AAA" size battery) - not included
Max. SPL: 100dB
Battery Current Drain: 0.5mA
Battery Life: 400 hours withAlkiline battery
Weight w/o battery: 1.83oz (52grams)
Dimensions: 6.96 in. L (177mm) x 0.72 in. Diameter (18.2mm)
Output cable: attached with 3.5mm plug
SuppliedAccessories: Camera hot-shoe mic holder, windscreen
