Aztech MF801C User manual

MF801C
Aztech Multifunction Cooker
USER MANUAL
PLEASE RETAIN THIS USER MANUAL FOR FUTURE USE.

3
SAFETY INSTRUCTIONS
Only use the intended cooking pot included in the product
package.
Position the Multifunction Cooker on a smooth, dry, and stable
ground. Placing the appliance on unstable surfaces such as
softly cushioned carpets or sofa, may make the appliance lose its
balance.
Do not position the appliance in hot places or in places commonly
exposed to multiple sources of heat such as stoves, refrigerators, or
ovens. It is also important to keep it away from ammable materials
such as curtains and cloths.
Remove the power plug before doing any cleaning or relocation of
the appliance.
Do not use wet hands in operating the appliance, and in inserting or
removing its power plug to prevent electrical shocks. It is suggested
to thoroughly dry your hands rst before using the Multifunction
Cooker.
During use, keep the Multifunction Cooker and its wiring away from
children to avoid injuries
Should damages be found in the appliance, please do not use the
appliance and immediately bring the appliance to the maintenance
center for repair.
When unplugging the power plug, do not pull its cord. Hold the
power plug properly on its base to unplug it from the power outlet.
Before using, check if the power voltage of your Multifunction
Cooker corresponds to your home’s power supply.
If the power cord is damaged, do not replace it by yourself. Always
use the dedicated power cord supplied by the manufacturer.
After cooking, allow the cooking pot to cool down before removing
the cooking pot for cleaning.
Do not immerse the power cord and Multifunction Cooker’s body
into water to avoid breakage which may affect safety usage.
Avoid any external or heavy impact on the glass lid.
Do not use hard objects in cleaning the cooking pot. These materials
may scratch the nonstick surface of the cooking pot, rendering it
useless over time.
•
•
•
•
•
•
•
•
•
•
•
•
•
•

4
PACKAGE CONTENTS
• Multifunction Cooker
• Fry Basket
• Steam Rack
• Power Supply
APPLIANCE OVERVIEW
CONTROL PANEL BUTTONS
• User Manual
• Easy Start Guide
• Warranty Policy
Glass Lid
Non Stick
Cooking Pot
Body LCD Control
Panel
Base
Touch Screen
Buttons
TIME
Adjustment
Buttons
PRESET
Button
FUNCTION
Button
START/
STOP Button
TEMP
Adjustment
Buttons
START/STOP Button1.
After connecting and plugging the power supply, a BEEPING SOUND
would be heard. Adjust the Time and Temperature using the +/- buttons as
preferred then press this button to conrm and start cooking.
•

5
After plugging the Multifunction Cooker to a power outlet, press the START/
STOP button and it will return to its last setting. Press the FUNCTION button
and it would renew the last function menu. Double press this button to stop
the cooking and return the Multifunction Cooker to STANDBY mode.
Short Time Memory Function. If the product has nished cooking, and you
want to use the same preset again, press the START/STOP button again to
use the previously used preset. Do take note that if you have unplugged the
device or if you did not press this button within one minute after cooking,
you would not be able to use the previous preset used.
•
•
TIME & TEMPERATURE (+/-) Button2.
After choosing the preferred function, adjust the TIME using the TIME + or
TIME – button. For each press, the cooking time shall increase or decrease
by 1 minute. If you press and hold the TIME + or TIME - button, the time shall
increase or decrease by 10 minutes. The maximum cooking time you can
set is up to 9 hours and 59 minutes.
Press the TEMP + or TEMP – button to adjust the temperature used in cooking.
For each press, the temperature is increased or decreased by 10 degrees.
If you press and hold the TEMP + or TEMP – button, the temperature shall
increase or decrease by 10 degrees. The highest temperature you can set
is up to 240 and the lowest temperature can be set up to 40.
•
•
PRESET Button3.
Allows you to select or use your preferred cooking preset. After selecting the
preferred cooking function, including the cooking time and temperature,
press the PRESET button. The display screen would show the preset time
and the PRESET button would start blinking to indicate that you have now
entered Preset mode.
In Preset mode, adjust the TIME and TEMPERATURE preset using each
respective (+/-) buttons. Press the START/STOP button and the Multifunction
Cooker would start cooking using the entered preset. If the preferred
preset time or temperature has not been completed within 10 seconds,
the Multifunction Cooker would return to the Preset Status and you would
have to press the Preset button again if you want to adjust the Time and
Temperature.
•
•
FUNCTION Button4.
The Multifunction Cooker is capable of providing you 18 Functions you would
surely enjoy using.
Simply press the FUNCTION button and you would now be able to select
the preferred function in a circular motion using the corresponding order :
(1) Fry, (2) Cake, (3) Snacks, (4) Defrost, (5) Chocolate, (6) Keep Warm, (7)
Pizza, (8) Soup, (9) Toast, (10) Vegetable, (11) Yoghurt, (12) Deep Fry, (13)
Porridge, (14) Stir Fry, (15) Hot Pot, (16) Steam, (17) Meat, and (18) Grill.
•

6
USING THE COOKING FUNCTIONS
FRYA.
Press the FUNCTION button to select the FRY function. The FRY function
indicator would start blinking.
Pour cooking oil and place the food on the cooking pot.
Press the START/STOP button and set the preferred cooking time and
temperature. The default temperature is set to 200ºC, while the Time is set
to 20 minutes. You can set the preferred frying time from 1 minute to 10
hours, while the Temperature can be set from 120ºC to 240ºC.
The Multifunction Cooker will automatically return to STANDBY mode after
cooking.
1.
2.
3.
4.
Press the FUNCTION button to select the CAKE function. The CAKE function
indicator would start blinking.
Press the START/STOP button and set the preferred cooking time. The default
temperature is set to 140ºC, while the Time is set to 1 Hour. You can set the
preferred cooking time from 1 minute to 1.5 hours, but the temperature
cannot be adjusted.
Spray or paint oil around the pot, and keep preheating for 1 minute. You
may then pour the cake mixture into the pot and place the glass lid. The
Multifunction Cooker will automatically return to STANDBY mode after
cooking.
1.
2.
3.
CAKEB.
Place the snacks that you wish to cook into the cooking pot then place
the glass lid.
Press the FUNCTION button to select the SNACKS function. The SNACKS
function indicator would start blinking.
Press the START/STOP button and set the preferred cooking time. The default
temperature is set to 160ºC, while the Time is set to 30 minutes.
You can set the preferred baking time from 1 minute to 30 minutes, but
the temperature cannot be adjusted. The Multifunction Cooker will
automatically return to STANDBY mode after cooking.
1.
2.
3.
4.
SNACKSC.
Press the START/STOP button and the Multfunction Cooker will begin
cooking using the selected function. If you wish to change the cooking
function, you would have to cancel the cooking rst by pressing the START
/ STOP button and the Multifunction Cooker would return to STANDBY
mode.
•

7
CHOCOLATEE.
Pour the chocolate mixture on the cooking pot and close using the lid.
Press the FUNCTION button to select the CHOCOLATE function. The
CHOCOLATE function indicator would start blinking.
Press the START/STOP button and set the preferred cooking time. The default
temperature is set to 60ºC, while the Time is set to 2 hours.
You can set the preferred cooking time from 30 minutes to 4 hours, and the
temperature can be set from 60ºC to 70ºC. The Multifunction Cooker will
automatically return back to STANDBY mode after cooking.
1.
2.
3.
4.
Press the FUNCTION button to select the KEEP WARM function. The KEEP
WARM function indicator would start blinking.
Press the START/STOP button and set the preferred cooking time. The default
temperature is set to 80ºC, while the Time is set to 2 hours.
You can set the preferred cooking time from 30 minutes to 4 hours, but
the temperature cannot be adjusted. The Multifunction Cooker will
automatically return back to STANDBY mode after cooking.
1.
2.
3.
KEEP WARMF.
Place the Low Rack on the non-stick cooking pot, then place the pizza on
the rack and close it with the glass lid.
Press the FUNCTION button to select the PIZZA function. The PIZZA function
indicator would start blinking.
Press the START/STOP button and set the preferred cooking time. The default
temperature is set to 160ºC, while the Time is set to 40 minutes.
You can set the preferred cooking time from 1 minute to 1 hour, but
the temperature cannot be adjusted. The Multifunction Cooker will
automatically return back to STANDBY mode after cooking.
1.
2.
3.
4.
PIZZAG.
Place the Steam Rack or Low Rack over the non-stick cooking pot.
Place the frozen food on the rack and the glass lid to close it.
Press the FUNCTION button to select the DEFROST function. The DEFROST
function indicator would start blinking.
Press the START/STOP button and set the preferred cooking time. The default
temperature is set to 80ºC, while the Time is set to 1 hour.
You can set the preferred defrosting time from 30 minutes to 3 hours,
but the temperature cannot be adjusted. The Multifunction Cooker will
automatically return back to STANDBY mode after cooking.
1.
2.
3.
4.
5.
DEFROSTD.

8
Pour some water in the cooking pot, then place the vegetables and the
glass lid to close.
Press the FUNCTION button to select the VEGETABLE function. The VEGETABLE
function indicator would start blinking.
Press the START/STOP button and set the preferred cooking time. The default
temperature is set to 140ºC, while Time is set to 25 minutes.
You can set the preferred cooking time from 10 minutes to 1 hour, and the
temperature can be set from 120ºC to 180ºC. The Multifunction Cooker will
automatically return to KEEP WARM mode after cooking.
1.
2.
3.
4.
TOASTI.
Pour fresh milk into the cooking pot, add yoghurt cultures or 10% pure
yoghurt then place the glass lid.
Press the FUNCTION button to select the YOGHURT function. The YOGHURT
function indicator would start blinking.
Press the START/STOP button and set the preferred cooking time. The default
temperature is set to 40ºC, while the Time is set to 4 hours.
You can set the preferred cooking time from 30 minutes to 10 hours,
but the temperature cannot be adjusted. The Multifunction Cooker will
automatically return to STANDBY mode after cooking.
1.
2.
3.
4.
VEGETABLESJ.
Place the low rack on the cooking pot and close it with the glass lid.
Press the FUNCTION button to select the TOAST function. The TOAST function
indicator would start blinking.
Press the START/STOP button and set the preferred cooking time. The default
temperature is set to 160ºC, while the Time is set to 20 minutes.
You can set the preferred cooking time from 1 minute to 30 minutes, but
the temperature cannot be adjusted.
Flip the bread every 10 minutes. The Multifunction Cooker will automatically
return back to STANDBY mode after cooking.
1.
2.
3.
4.
5.
SOUPH.
Place the raw mixture into the cooking pot, add the needed water and
close it with the glass lid.
Press the FUNCTION button to select the SOUP function. The SOUP function
indicator would start blinking.
Press the START/STOP button and set the preferred cooking time. The default
temperature is set to 100ºC, while the Time is set to 3 hours.
You can set the preferred cooking time from 30 minutes to 4 hours, but
the temperature cannot be adjusted. The Multifunction Cooker will
automatically return back to STANDBY mode after cooking.
1.
2.
3.
4.
YOGHURTK.

9
Place the raw food you would be cooking and pour the needed cooking
oil into the cooking pot enough to submerge the fry basket and the food
you would be frying.
Press the FUNCTION button to select the DEEP FRY function. The DEEP FRY
function indicator would start blinking.
Press the START/STOP button and set the preferred cooking time. The default
temperature is set to 210ºC, while the Time is set to 40 minutes.
You can set the preferred cooking time from 1 minute to 2 hours, while the
temperature can be set from 180ºC to 210ºC. The Multifunction Cooker will
automatically return to STANDBY mode after cooking.
1.
2.
3.
4.
Press the FUNCTION button to select the HOT POT function. The HOT POT
function indicator would start blinking.
Press the START/STOP button and set the preferred cooking time. The default
temperature is set to 220ºC, while the Time is set to 1 hour.
You can set the preferred cooking time from 1 minute to 10 hours, while the
temperature can be set from 120ºC to 240ºC. The Multifunction Cooker will
automatically return back to STANDBY mode after cooking.
1.
2.
3.
PORRIDGEN.
Put clean rice into the cooking pot, add burdening and water then place
the glass lid.
Press the FUNCTION button to select the PORRIDGE function. The PORRIDGE
function indicator would start blinking.
Press the START/STOP button and set the preferred cooking time. The default
temperature is set to 110ºC, while Time is set to 1 hour.
You can set the preferred cooking time from 1 minute to 1.5 hours, while
the temperature can be set to 100ºC to140ºC. The Multifunction Cooker will
automatically return back to STANDBY mode after cooking.
1.
2.
3.
4.
STIR FRYM.
Press the FUNCTION button to select the STIR FRY function. The STIR FRY
function indicator would start blinking.
Press the START/STOP button and set the preferred cooking time.
Pour a moderate amount of cooking oil in the pot. The default temperature
is set to 240ºC, while the Time is set to 15 minutes.
You can set the preferred cooking time from 1 minute to 30 minutes, while
the temperature can be set from 140ºC to 240ºC. The Multifunction Cooker
will automatically return back to STANDBY mode after cooking.
1.
2.
3.
4.
DEEP FRYL.
HOT POT
O.

10
Place the steam rack or the low rack on the cooking pot and place the
glass lid.
Place the marinated chicken or meat into the rack and close the lid.
Press the FUNCTION button to select the GRILL function. The GRILL function
indicator would start blinking.
Press the START/STOP button and set the preferred cooking time. The default
temperature is set to 240ºC, while Time is set to 30 minutes.
You can set the preferred cooking time from 1 minute to 30 minutes, while
the temperature can be set to 120ºC to 240ºC. The Multifunction Cooker
will automatically return back to STANDBY mode after cooking.
1.
2.
3.
4.
5.
STEAMP.
Place the Steam Rack or Low Rack over the cooking pot.
Add the right amount of water enough to keep the water below the rack
then place the raw food you plan to steam and close using the glass lid.
Press the FUNCTION button to select the STEAM function. The STEAM function
indicator would start blinking.
Press the START/STOP button and set the preferred cooking time. The default
temperature is set to 220ºC, while the Time is set to 15 minutes.
You can set the preferred cooking time from 1 minute to 30 minutes, while
the temperature can be set from 120ºC to 240ºC. The Multifunction Cooker
will automatically return back to STANDBY mode after cooking.
1.
2.
3.
4.
5.
Place the meat into the cooking pot then add the right amount of water
and close using the glass lid.
Press the FUNCTION button to select the MEAT function. The MEAT function
indicator would start blinking.
Press the START/STOP button and set the preferred cooking time. The default
temperature is set to 160ºC, while the Time is set to 30 minutes.
You can set the preferred cooking time from 1 minute to 10 hours, while the
temperature can be set from 120ºC to180ºC. The Multifunction Cooker will
automatically return back to keep warm mode after cooking.
1.
2.
3.
4.
MEATQ.
GRILL
R.

11
CARE AND CLEANING
The glass lid is frangible. Avoid exposing it to heavy external
impacts or force and continually handle it with care.
If the nonstick cooking pot has materials stuck on its surface,
use vinegar together with boiling water to remove the
attached particles.
When washing, ALWAYS use a soft sponge. Do not use steel
wire balls or any hard and abrasive materials in cleaning
the cooking pot.
Do not use any corrosive liquids in cleaning the body, the
cooking pot, or any part of the Multifunction Cooker.
If you do not have to use the product for a long time, please
completely clean and place the Multifunction Cooker into
its box and store it in a dry and well-ventilated area.
If the product is found faulty, please contact your local
dealer at once. Do not, in any kind of manner, disassemble,
dismantle, or repair the product by your own. This may void
the appliance’s warranty.
1.
2.
3.
4.
5.
6.

Copyright © 2014 Aztech Technologies Pte Ltd (CRN:199800635M ). All rights reserved.
