Introduction
This is the user guide for Prostate Biplane Transducer Type 8808e and must be used
together with Care and Cleaning which contains important safety information.
Indications for Use
Prostate Biplane Transducer Type 8808e is designed for transrectal prostate imaging.
Figure 1. Prostate Biplane Transducer Type 8808e.
Imaging Plane
The transducer contains two convex arrays — one for transverse (T) imaging, and one
for sagittal (S) imaging (see Figure 2). The advantage of being able to view two planes
simultaneously with one transducer is that the true position of the needle can be seen
during puncture and biopsy and a suspicious lesion can be viewed in both planes.
Figure 2. Imaging planes for Prostate Biplane Transducer Type 8808e.
General Information
Product specifications for this transducer can be found in the Product Data sheet that
accompanies this user guide.
Acoustic output data and data about EMC (electromagnetic compatibility) for this
transducer are in Technical Data (BZ2100) that accompanies this user guide. A full
explanation of acoustic output data is given in your system user guide.
Sagittal Button
Transverse Button
Sagittal Plane
Transverse Plane

6 March 2017 8808e User Guide (BB1856-F)
Service and Repair
Caring for the Transducer
The transducer may be damaged during use or processing, so it must be checked
before use for cracks or irregularities in the surface. It should also be checked
thoroughly once a month following the procedure in Care and Cleaning .
Cleaning and Disinfection
To ensure the best results when using BK Medical equipment, it is important to
maintain a strict cleaning routine.
Full details of cleaning and disinfection procedures can be found in
Care and
Cleaning that accompanies this user guide. A list of disinfectants and disinfection
methods that the transducer can withstand are listed in the Product Data sheet.
Sterile covers are available. See the Product Data sheet for more information.
WARNING
If at any time the system malfunctions, or the image is severely distorted or degraded, or you
suspect in any way that the system is not functioning correctly:
• Remove all transducers from contact with the patient.
• Turn off the system. Unplug the system from the wall and make sure it cannot be used
until it has been checked.
• Do not try to repair the system yourself.
• Contact your BK Medical representative or hospital technician.
WARNING
Always keep the exposure level (the acoustic output level and the exposure time) as low as
possible.
WARNING
Service and repair of BK Medical electromedical equipment must be carried out only by the
manufacturer or its authorized representatives. BK Medical reserves the right to disclaim all
responsibility, including but not limited to responsibility for the operating safety, reliability
and performance of equipment serviced or repaired by other parties. After service or repairs
have been carried out, a qualified electrical engineer or hospital technician should verify the
safety of all equipment.
WARNING
Users of this equipment have an obligation and responsibility to provide the highest degree
of infection control possible to patients, co-workers and themselves. To avoid cross
contamination, follow all infection control policies for personnel and equipment established
for your office, department, or hospital.

8808e User Guide (BB1856-F) StartingImaging 7
Starting Imaging
All equipment must be cleaned and disinfected before use.
Connecting the Transducer
The transducer is connected to the system using the array Transducer Socket on the
system . To connect, the transducer plug’s locking lever should first be in a horizontal
position. Align the plug to the system socket and insert securely. Turn the locking
lever clockwise to lock in place.
When connected, the transducer complies with Type BF requirements of EN60601-1
(IEC 60601-1).
Changing Frequency
The Multi-Frequency Imaging (MFI) facility enables you to select the imaging
frequency. See the applicable system user guide for instructions. The selected
frequency is displayed at the top of the screen.
Using a Transducer Cover
The transducer should be enclosed in a transducer cover or a standard condom. See
the Product Data sheet for a list of available transducer covers.
Apply sterile gel to the tip of the transducer or fill the cover with 1 to 2 ml of sterile
water. This improves the screen images by preventing image artifacts caused by air
bubbles.
Pull the transducer cover over the transducer.
Gel also creates a good acoustic contact between the skin and the transducer;
therefore, apply a small amount to the outside of the cover prior to imaging. Re-apply
the gel frequently to ensure good screen images.
WARNING
Keep all plugs and sockets absolutely dry at all times.
WARNING
Because of reports of severe allergic reactions to medical devices containing latex ( natural
rubber), FDA is advising health-care professionals to identify their latex-sensitive patients
and be prepared to treat allergic reactions promptly.
WARNING
Use only water-soluble agents or gels. Petroleum or mineral oil-based materials may harm
the cover materials.

8 March 2017 8808e User Guide (BB1856-F)
Using the Transducer Control Button
To change the imaging plane, press the button corresponding to that plane (see Figure
1). Pressing the button activates (starts) or freezes (stops) imaging in that plane. One
button enables the sagittal or longitudinal array. A second button enables the
transverse array. Each time a button is pressed, a beep is emitted.
Changing Orientation
To change the orientation of the image on the monitor, refer to the applicable system
user guide for instructions.
Imaging with Type 8808e
Simultaneous Biplane Imaging
8808e can transmit transverse (T) and sagittal (S) images simultaneously. When you
press the system’s Split key, simultaneous imaging is automatically activated.
Transverse or Sagittal Imaging
Click Simultan to toggle simultaneous imaging on or off. When simultaneous
imaging is off, you can change which plane is active and which is frozen by pressing
the Split key or by placing the cursor on the image you want to be active and pressing
the
Select key.
WARNING
Do not use excessive force during insertion. Do not make excessive lateral movements
during or after insertion. Risk of injury or tissue damage to the patient could occur under
certain circumstances. A digital palpation of the rectum may need to be carried out by a
clinician prior to insertion or use of the probe as a precautionary measure.

8808e User Guide (BB1856-F) Imaging Without Puncture or Biopsy 9
Imaging Without Puncture or Biopsy
When 8808e is used for transrectal imaging without the puncture facilities, the
dummy bracket UA1325 must be in place. This clicks into position on the transducer
to cover the open channel (see Figure 3).
Figure 3. Type 8808e and the dummy channel bracket UA1325.
Note: The dummy bracket must be removed before 8808e is prepared for disinfection.
The bracket can be disinfected using the same methods as explained later under
UA1326.
Puncture and Biopsy Facilities
Transrectal and transperineal puncture and biopsy are possible with 8808e. The
following pages illustrate the various transrectal and transperineal puncture
accessories available and briefly describe usage and operating instructions. The
transducer has an open channel into which the appropriate puncture accessories fit
when the dummy channel bracket (UA1325) has been removed (see Figure 3).
For Transrectal Puncture
With 8808e, you can perform transrectal puncture and biopsy by imaging in
simultaneous biplane (imaging in both the transverse and sagittal planes).
The biopsy guide is available in both a non-sterile reusable version (light green) and
a sterile-packed single-use version (dark green).
Non-sterile biopsy guides (light green)
The dummy channel bracket UA1325 and the reusable biopsy guide (UA1326) are
non-sterile when supplied. They must be reprocessed following the procedure in
Care and Cleaning .
WARNING
It is essential for the patient’s safety that only the correct puncture attachments, as described
in this guide, are used. Never use unauthorized combinations of transducers and puncture
attachments or other manufacturers’ puncture attachments.

10 March 2017 8808e User Guide (BB1856-F)
The dummy channel bracket and reusable biopsy guide may be damaged during use
or processing, so they must be checked before use for cracks or irregularities in the
surface. They should also be checked thoroughly once a month following the
procedure in Care and Cleaning .
Sterile biopsy guides (dark green)
The sterile single-use biopsy guide UA1322-S and UA1322-S14 come assembled in
peel packs. Contents are only sterile if the package is intact.
The sterile-packed biopsy guides must be stored at a temperature range from +5 °C
(+41°F) to +25 °C (+77 °F) and at a storage humidity of 0% to 80% .
Please refer to Care and Cleaning for an example of how to open a sterile-packed
product.
Simultaneous Biplane
The sterile biopsy guide UA1322-S, UA1322-S14 and reusable biopsy guide
UA1326 are used for simultaneous biplane imaging.
Figure 4. Reusable biopsy guide UA1326.
WARNING
Disposable components are packaged sterile and are intended for single-use only.
Do not use if:
• Integrity of packaging is violated
• Expiration date has passed
• Package label is missing
WARNING
Sterile-packed components must be stored in a safe environment and kept out of direct
sunlight. Large temperature changes during storage may cause condensation and violate
the integrity of the packaging.

8808e User Guide (BB1856-F) Puncture and Biopsy Facilities 11
The puncture line for UA1322-S, UA1322-S14 and UA1326 on 8808e is shown in
Figure 5. UA1322-S and UA1326 have a bore diameter of 1.6 mm, suitable for 17-
gauge needles. UA1322-S14 has a bore diameter of 2.1 mm, suitable for 14-gauge
needles.The puncture line is angled at 19° to the transducer’s axis.
Figure 5. Illustration of the puncture line for biopsy guide UA1322-S, UA1322-S14 and UA1326.
Mounting a Transrectal Biopsy Guide
To mount a biopsy guide on 8808e:
1 If a dummy channel bracket is mounted on the transducer, remove it.
2 Pull a transducer cover or a standard condom containing a suitable amount of
imaging gel over the transducer.
3 Slide the needle guide into the biopsy channel bracket.
4 Insert the assembled needle guide and biopsy channel bracket into the open
channel on the transducer. A small nodule on the end of the channel bracket fits
into an indentation in the channel on the transducer to help you place the bracket
correctly. Click the channel bracket into position on the transducer and lock it
into place (see Figure 6).
Figure 6. Biopsy channel bracket and needle guide mounted on 8808e.
WARNING
Do not use excessive force when inserting the needle guide.
WARNING
Ensure that the channel bracket and needle guide are correctly positioned. Never insert the
needle guide while the transducer is inside the patient.

12 March 2017 8808e User Guide (BB1856-F)
For Transperineal Puncture
The metal puncture attachment UA1324, shown in Figure 7, is designed for
transperineal puncture and biopsy. When UA1324 is being used, the dummy channel
bracket UA1325 (shown in Figure 3) must be in place.
Puncture attachment UA1324 must be autoclaved or disinfected by immersion in a
suitable solution.
UA1324 consists of a needle guide and a mounting ring with clamp. The needle guide
comprises 9 parallel guide channels, spaced 5mm apart, each with an internal
diameter of 2.1mm, suitable for a 14-gauge needle. The guide is parallel to the
centerline of the transducer.
Note: The needle guide can be adjusted 70 mm lengthwise with respect to the
mounting ring, using the adjustment screw.
Figure 7. Puncture attachment UA1324.
Mounting the Transperineal Puncture Attachment
To mount the transperineal puncture attachment, ensure that the dummy channel
bracket UA1325 is in place. Pull a sterile transducer cover over the transducer.
Loosen the clamp on UA1324, and slide the attachment over the tip of the transducer
until it meets the steel stud on the side of the transducer. The puncture attachment
should be correctly positioned so that the groove slides easily over stud. No force
should be used when attaching the puncture attachment to the transducer.
Figure 8. Puncture attachment UA1324 mounted on 8808e.

8808e User Guide (BB1856-F) Puncture and Biopsy Facilities 13
The puncture lines for UA1324 on 8808e are shown in Figure 9.
Figure 9. Illustration of the puncture line for puncture attachment UA1324.
Performing Puncture and Biopsy
If the transducer cover is damaged when attaching the puncture attachment, replace
it with a new cover.
See the Product Data sheet for a list of available transducer covers.
Superimpose
puncture line
Press the system Puncture or Biopsy control button to superimpose a puncture line
on the image.
If more than one puncture line is available, refer to the applicable system user guide
for instructions on how to change which one appears.
Move the transducer until the puncture line transects the target. Insert the needle and
monitor it as it moves along the puncture line to the target. The needle tip echo will
be seen as a bright dot on the screen.
The puncture line will differ depending on the imaging plane orientation. In the
sagittal plane, the puncture path is indicated by a line of dots. The distance between
each puncture dot is 5mm.
WARNING
It is essential for the patient’s safety that only the correct puncture attachments, as described
in this guide, are used. Never use unauthorized combinations of transducers and puncture
attachments or other manufacturers puncture attachments.
Before beginning a puncture or biopsy procedure, always check that the type number of the
transducer and the type number or description of the puncture attachment match exactly
those displayed on the system monitor.
WARNING
The puncture line on the image is an indication of the expected needle path. The needle tip
echo should be monitored at all times so any deviation from the desired path can be
corrected.

14 March 2017 8808e User Guide (BB1856-F)
In the transverse plane, a single dot indicates the point at which the needle will
transect the imaging plane.
To remove the puncture line from the scan image, refer to the applicable system user
guide for instructions.
Cleaning after Puncture and Biopsy
If biological materials are allowed to dry on the transducer, disinfection and
sterilization processes may not be effective. Therefore, you must clean transducers
immediately after use.
Use a suitable brush to make sure that biological material and gel are removed from
all channels and grooves. See Care and Cleaning for cleaning instructions.
Disposal
When the transducer is scrapped at the end of its life, national rules for the relevant
material in each individual land must be followed. Within the EU, when you discard
the transducer, you must send it to appropriate facilities for recovery and recycling.
See the applicable system user guide for further details.
WARNING
If the needle guide is detached from the transducer during interventional procedures, cover
the transducer with a new transducer cover.
If the cover is damaged during interventional procedures, follow the policies of the hospital
or clinic for treatment of the patient under such circumstances.
WARNING
When performing a biopsy, always make sure that the needle is fully drawn back
inside the needle guide before moving the probe.
WARNING
For contaminated disposals such as transducer covers or needle guides, follow disposal
control policies established for your office, department or hospital.
