Baby Jogger CITY ELITE SINGLE User manual

Read these instructions carefully
before use and keep them for
future reference. Your child’s
safety may be affected if you do
not follow these instructions.
This product complies with
ASTM F833-07a
www.babyjogger.com
CITY ELITE
ASSEMBLY INSTRUCTIONS

2
• This stroller is not suitable for running, jogging, skating or rollerblading.
• Prevent serious injury to your child by always using the safety harness.
• Parcels or accessory items, or both, placed on the unit may cause the unit to
become unstable.
• Never leave child unattended.
• Recommended weight for seat back pocket is 2 pounds and basket is 10 pounds.
Excessive weight may cause a hazardous unstable condition to exist.
• Stroller is not meant to be used for transporting children up or down stairs. Damage
resulting to stroller, will not be covered under warranty.
• Child may slip into leg openings and strangle. Never use in reclined carriage position
unless safety harness is properly fastened.
• Accessories which are not approved by the manufacturer or distributor shall not be used.
• The passenger shall remain seated (no standing in the stroller).
• Watch out for cars – never assume that a driver can see you and your child.
• This stroller is suitable from birth to 5 years (maximum weight: 75 lbs.).
• Total weight load recommended for this stroller is 75 lbs (34 kg) (combined passenger
and baggage weight).
• This stroller seats one passenger.
• It may be unsafe to use replacement parts other than those supplied or approved by
the manufacturer.
For the sake of your precious cargo, please
read these warnings before using your stroller.
WARNING:

1
1 Unpack stroller from box and set wheels aside. 2 Begin to unfold stroller by pulling the Auto-lock
lever while pushing the handle up and away from
the lower frame. The stroller will click into place.
3 Turn stroller upright. 4Snap red safety strap to frame under the fold
mechanism before use.
FRAME
Warning: Ensure all locking devices are engaged before use.

2
Swivel/Straight Feature
Turn to the left to lock front wheel.
Turn to the right for swivel action.
Note: When loading and unloading
child, lock the front wheel straight.
FRONT WHEEL
1 Lay stroller on its back so the handle is resting on the floor.
2 Align the round opening on the top of the front fork with the round metal peg underneath
the foot plate. Slide the front wheel onto the metal peg until it clicks into place.
To install front wheel:
To remove front wheel:
3 Locate the wheel release lever on the top of the
front fork and press down. Slide the wheel off.
Wheel release lever
CLICK

3
1Align wheel axle with wheel mount
on stroller frame.
2Insert the wheel axle into the wheel mount
until it clicks into place. Gently tug on wheel to
make sure the rear wheel is properly attached.
Repeat on other side.
REAR WHEELS
To install rear wheels:
To remove rear wheels:
3Press the wheel release button while gently
sliding the wheel away from the wheel mount.
Wheel release
button
Wheel mount
CLICK

4
1To attach canopy to frame, simply
slide canopy peg into top hole of
mounting bracket on the stroller
frame, until you hear it click into
place. (The bottom hole can
be used to attach Baby Jogger
accessories to your stroller).
2At the top and on the side
of the canopy, snap webbing
together around top of frame
on both sides.
1 Press gray button to release the canopy peg from
the universal mounting bracket and unfasten
snaps and Velcro at the top of the canopy.
3Once canopy is in place, secure
the console by aligning the
Velcro strips on the console
and canopy.
CANOPY
To attach canopy to frame:
To remove the canopy:
CLICK

5
To engage parking brake: Gently pull brake lever into upright position
until it clicks into place.
To release parking brake: Pinch gray tabs and pull towards you. Push brake lever down until it is parallel with
the frame.
BRAKE
Warning: Engage parking device before loading and unloading passenger.

6
SAFETY HARNESS
1Unclip top of shoulder strap
from the seat and re-clip on
the pair of seat loops closest
to child’s shoulder height.
1 Pull shoulder pads down close to main harness buckle to
expose the plastic guide.
2Hold the plastic guide and pull the strap end to tighten
or pull the upper harness strap to loosen.
To adjust harness height: To adjust harness length:
Warning:
Ensure all locking
devices are engaged
before use.
To buckle the harness:
Simply push both side
buckles into center buckle
until it locks into place.
Push one side of the center button
and pull the corresponding side
buckle away from the center buckle.
Repeat to unbuckle other side.
To unbuckle:
Warning:
Avoid serious injury
from falling or sliding
out. Always properly
adjust and fasten
safety harness.

7
1To use the raised kicker, pull up on seat flap above the footplate,
and remove the kicker stand from storage pocket. Attach the
kicker stand to the seat with the hooks provided under seat flap.
2Attach kicker stand by wrapping both sides of the webbing under
the footplate. Thread one side of the Velcro webbing through the
D-ring of the other side, and secure Velcro together.
3When not using the raised
kicker, tuck the kick stand and
the webbing straps into the
pocket provided under the seat.
RAISED KICKER

8
1 To recline: Pinch the clamp behind the seat, and slide it down
to desired recline. Pull seat down on both sides to match recline
position of clamp.
Reverse to return to the upright position.
• Weather Cover: If desired, pull
weather cover down and over
the seat back mesh. Secure
firmly over both sides of seat.
When not in use, roll weather
cover up and fasten with elastic
loop and barrel provided under
the top of the seat fabric.
RECLINING SEAT & BASKET
2 From the rear of the stroller: Unsnap the top snaps
of the basket from around the frame tubing above
the middle crossbar. Unsnap the bottom snaps of
the basket from around the frame tubing below
the middle crossbar.
To remove the basket:
1 From the front of the stroller: Unfasten Velcro on
lower seat fabric to expose the bottom front portion
of frame. Unfasten basket Velcro from around the
frame tubing. Velcro seat fabric back to stroller
frame once complete.
The basket of your City Elite comes fully attached.
