Baby Jogger PERFORMANCE SINGLE User manual

Important, Keep For
Future Reference
Assembly
Instructions
The Ultimate High Performance Jogging Stroller
Performance Single
Performance Single (Assem) 12/14/04 10:57 AM Page 1

2 1
• To assemble, simply unfold frame and insert the front of handle assembly into Front Tube
Connector and lock together, securing with Snap Locks.
Frame
Front
Tube
Connector
Snap
Locks
• Important, keep this booklet for future reference.
• Accessories which are not approved by the manufacturer or distributor
should not be used.
• WARNING: Prevent serious injury to your child by always using the
safety harness.
• WARNING: Any load attached to the handle affects the stability of the stroller.
• WARNING: It may be dangerous to leave child unattended.
• Always use your wrist strap – these strollers can really roll, and the
wrist strap gives you control if you should slip or fall down.
• The passenger should remain seated (no standing in the stroller).
• Watch out for cars – never assume that a driver can see you and your child.
• Never use Roller Blades while using a Baby Jogger Stroller.
• Intended for passengers up to five years of age weighing no more
than 100 pounds.
• This Jogger seats one passenger.
• WARNING: Recommended weight for seat pocket is 2 pounds and basket
is 10 pounds. Excessive weight may cause a hazardous unstable
condition to exist.
• It may be unsafe to use replacement parts other than those supplied or
approved by the manufacturer.
For the sake of your precious cargo, please read
these warnings before using your Baby Jogger.
Performance Single (Assem) 12/14/04 10:57 AM Page 2

2 3
1 Insert the footplate tab
into the footplate
holder slot
Footplate
3 Using a phillips head
screwdriver, attach
footplate to Jogger frame.
You will need to rest the
Jogger Handle on the floor
in order to get to the
bottom of the footplate.
2 Snap down onto
Jogger frame.
1 To install front wheel, lay
stroller back so handle is
resting on floor. Open the
calipers by flipping the
caliper lever toward the
rear wheels while pinching
calipers together.
2 Insert the front wheel into
the fork tips by aligning
the axle flats with the
fork tip flats.
3 Tighten by turning the
wheel lever while holding
the opposite side.
4 Close the wheel lever
making sure that it is
facing toward the back
of the stroller.
5 Close caliper by flipping
the caliper lever toward
the fork tips.
Front Wheel
Caliper
Lever
Wheel
Lever
Wheel
Lever
Performance Single (Assem) 12/14/04 10:57 AM Page 2

4 5
• To install, gently slide the
wheel’s axle into the hole
in the axle end until you
hear it click into place.
• To remove, simply push in
the spring lock while
pulling out the wheel.
Rear Wheels
• Simply adjust seat straps to
desired degree of recline.
• Pull on strap when you
want to return the seat to
its upright position.
Reclining Seat
Be sure to remove the board from the back of the seat before washing.
Spring
Lock
Spring
Lock
Performance Single (Assem) 12/14/04 10:57 AM Page 4

6 7
Adjusting safety harness:
• Loosen the shoulder straps from their plastic guides.
• Slide the end of each strap through pair of seat loops closest to your child’s shoulder.
Safety Harness
• Slide the end of the shoulder strap back into plastic guide.
Please note: If you feel the straps are too tight, you may adjust their length by sliding the
plastic guides toward the top of the seat.
• Lock both sides of the strap mechanism into the center buckle. To adjust the center strap,
move its plastic guide up or down.
WARNING: Avoid serious injury from falling or sliding out.
Always use safety harness!
Performance Single (Assem) 12/14/04 10:57 AM Page 6

1 Using a phillips head screwdriver, screw brackets to Jogger frame.
2 Fasten upper velcro straps
Canopy
Image shown with seat fabric removed for clearer viewing.
3 Snap to Jogger frame.
8 9
Adjusting the Brake
• If you don’t have good braking action, simply
squeeze the brake handle five or six times. If the
problem persists, loosen the brake’s cylinder ring
to adjust the small ring, and then move the small
ring away from the handle to tighten the cable.
(Please do not over tighten!) To lock the rings,
tighten the cylinder ring against the handle while
holding the small ring in place.
Hand Brake with Parking Button
• To use the parking button feature, simply squeeze the brake handle and push the park brake button.
Rear Wheel
Parking Brakes
• Simply push brake pedal down to engage
brake and lift up to release.
Brakes
Brake
Pedal
Small
Ring
Cylinder
Ring
Parking
Button
NOTE: Some Joggers
are shipped with the
Canopy, Seat and
Basket pre-assembled.
Assembly instructions
are given if any
pre-assemble items are
removed for cleaning
or replacement.
Performance Single (Assem) 12/14/04 10:57 AM Page 8

10 11
2 Fasten the two bottom velcro straps. One is located near
the front of seat and the other is near the footplate.
Seat
1 Snap eight frame snaps
to frame.
• Snap rear basket straps around frame.
• Fasten front velcro strap.
Basket
• Basket installation or removal requires releasing the bottom
section of seat as shown on previous page to reveal velcro strap.
Performance Single (Assem) 12/14/04 10:57 AM Page 10

12 13
Washing
• You can machine wash your stroller’s seat in cold water with a mild detergent.
To minimize shrinkage, simply reattach the seat to the frame to dry.
(Please do not put the seat in the dryer!)
• Be sure to remove the board from the back of the seat
before washing.
• You may clean the stroller frame using a soft, dry cloth, and
an occasional spray of household wax will maintain its
healthy glow.
Wheel Care
• Moisture – especially from the beach – can rust the wheel bearing case.
Spraying regularly with a silicone lubricant will keep your wheels looking healthy.
• Also, if you jog massive amounts of miles, your stroller will benefit from a
yearly visit to the bike shop for wheel alignment. Refer to the number
on the tire wall for the optimum pressure for your tires.
Storing
• Sunshine can fade seat fabric and dry out tires, so storing
your stroller indoors will prolong its good looks. However,
if you do store it outside, using a tarp will protect against
weather wear.
Stroller Care
Steering
• Steering your stroller is simple: it’s balanced to
turn with just a light touch on the handlebar.
For tighter turns, push down on the handlebar
and raise the front wheel to steer.
Wrist Strap
• Make sure wrist strap is around your wrist whenever
your baby is in the stroller. The Baby Jogger is
lightweight and ready to roll – with or without you – and
the wrist strap helps you gain control over your stroller.
In the Dark
• Since we are concerned about the safety of you and your
baby, we recommend that you not use your stroller at
night. However, if you choose to, please attach
reflective strips to the wheel spokes and the seat.
Bicycle lights can also be mounted on the handlebar.
In Motion
Performance Single (Assem) 12/14/04 10:57 AM Page 12

We wish you many happy journeys with your new
Baby Jogger! Your stroller is a great product, and
we are proud to manufacture it. If you have any
questions or comments, please give us a call at.
BJC P/S 08.10.04 (R1–12/04)
1.800.241.1848
Baby Jogger is a Division of Dynamic Brands
2042 Westmoreland Street • Richmond, VA 23230
T: 800.241.1848 • F: 804.262.6277
www.babyjogger.com
