Bachmann BlueNet BN3000 Instruction manual

BlueNet PDU
BN3000/3500/5000/7000/7500
Assembly and installation instructions
Read the instructions prior to performing any task!

Bachmann GmbH
Ernsthaldenstraße 33
70565 Stuttgart
Germany
Telephone: [phone] Fax:
[phone]
email: [email protected]
Internet: www.bachmann.com
Bach-30131-DE, 5, en_GB
© Bachmann GmbH 2015
25.09.2015BlueNet PDU BN3000/3500/5000/7000/75002

These instructions facilitate the safe and efficient assembly and
installation of the BlueNet power distribution unit (hereinafter called
“PDU”). These instructions constitute an integral part of the PDU
and must be retained. If the PDU is transferred to a third party,
these instructions must also be transferred with the PDU.
Persons who are entrusted to work on the PDU must have care-
fully read and understood these instructions prior to starting any
work. Compliance with all the safety information and instructions
set out in these instructions is an essential prerequisite for safe
operation.
The illustrations in these instructions are provided for purposes of
basic understanding and can deviate from the actual version.
The contents of these instructions are protected by copyright. Their
use is permitted in conjunction with the assembly and installation of
the PDU. Any use that exceeds this is not permitted, unless the
written approval of Bachmann GmbH has been obtained.
The software contains components that are protected by copyright
and are licensed in terms of various license models. A copy of the
terms of the licenses is included with the PDU as of software ver-
sion V1.01.XX and can be accessed via the web interface for the
PDU. With older software versions, a copy of the license texts can
be requested by sending an email to [email protected].
In addition to these instructions, the following additional documents
apply:
nOperating instructions
nData sheet
nSafety information
Telephone: [phone]
email: [email protected]
About the assembly and installa-
tion instructions
Copyright
Software licenses
Other applicable documents
Customer service
Supplemental directives
25.09.2015 BlueNet PDU BN3000/3500/5000/7000/7500 3

Table of contents
1 Overview.............................................................................. 5
1.1 Overview of the PDU.................................................... 5
1.2 Short description........................................................... 8
1.3 Displays and controls.................................................... 8
1.4 Communication........................................................... 11
1.5 Scope of delivery........................................................ 12
1.6 Optional accessories.................................................. 12
2 Explanation of symbols.................................................... 13
3 Personnel requirements and responsibilities................ 14
4 Unpacking the PDU........................................................... 15
5 Installing and connecting the PDU.................................. 16
5.1 Safety instructions for the installation......................... 16
5.2 Requirements of the installation location.................... 16
5.3 Installing the PDU....................................................... 16
5.3.1 Overview.................................................................. 16
5.3.2 Installing the PDU with the mounting brackets........ 18
5.3.3 Installation with plug-in brackets via the rear of the
PDU......................................................................... 19
5.3.4 Installation with plug-in brackets via the sides of the
PDU......................................................................... 20
5.3.5 Installation with the mounting solution in the rack... 21
5.4 Connecting the PDU to the power supply................... 23
5.5 Connecting the network cable.................................... 23
5.6 Connecting the sensors.............................................. 24
5.7 Cascading the PDUs.................................................. 24
6 Putting the PDU into operation........................................ 27
6.1 Adjusting the display orientation................................. 27
6.2 Querying the network address of the PDU................. 28
6.3 Configuring the PDU via the web interface (software
version V1.00.XX)....................................................... 29
6.4 Configuring the PDU via the web interface (as of soft-
ware version V1.01.XX).............................................. 34
7 Operation........................................................................... 39
8 Troubleshooting................................................................ 40
9 Cleaning the PDU.............................................................. 41
10 Dismantling and disposing of the PDU........................... 42
10.1 Dismantling............................................................... 42
10.2 Disposal.................................................................... 42
11 Technical specifications.................................................. 43
12 Index................................................................................... 44
Table of contents
25.09.2015BlueNet PDU BN3000/3500/5000/7000/75004

1 Overview
1.1 Overview of the PDU
Functions Measurement per
phase
Measurement per
socket
Identification Switching
Product name
BN3000 x – – –
BN3500 x x x –
BN5000 – – x x
BN7000 x – x x
BN7500 x x x x
Fig. 1: Product overview (16 amp version)
ACEE connector plug
BSockets
CConnector panel for network, Modbus and
sensors
DControl panel
EFitting slots for plug-in bracket
Fig. 2: Product overview (32 amp version)
ACEE connector plug
BSockets
CCircuit breaker / automatic fuse
DConnector panel for network, Modbus and
sensors
EControl panel
FFitting slots for plug-in bracket
Overview of functions
Example of a 16-amp version
Example of a 32-amp version
Overview
Overview of the PDU
25.09.2015 BlueNet PDU BN3000/3500/5000/7000/7500 5

ASensor port S1 (to connect a sensor via a cat 5e cable)
BModbus port M1 (to connect a slave PDU via a cat 5e cable)
CLAN port
DUSB port
EPort M2 (for connecting future applications)
FSensor port S2 (to connect a sensor via a cat 5e cable)
ASensor port S1 (to connect a sensor via a cat 5e cable)
BModbus port M1 (to connect a master PDU and upstream
slave PDUs via a cat 5e cable)
CModbus port M2 (to connect a slave PDU via a cat 5e cable)
DSensor port S2 (to connect a sensor via a cat 5e cable)
Connector panel for a master PDU
Fig. 3: Connector panel (master PDU)
Connector panel for a slave PDU
Fig. 4: Connector panel (slave PDU)
Overview
Overview of the PDU
25.09.2015BlueNet PDU BN3000/3500/5000/7000/75006

Fig. 5: Control panel
AStatus LED
BOperating button 1
CDisplay
DOperating button 2
EOperating button 3
FOperating button 4
GModbus LED
Fig. 6: Overview of the fitting options for the PDU
AFitting slots for plug-in bracket
BAttachment for the mounting bracket
CAttachment for the mounting solution in the
rack
DPlug-in bracket for mounting the PDU via the
back (2 each)
EPlug-in bracket for mounting the PDU via the
sides (2 each)
FMounting bracket (x 2)
Control panel
Fitting options on the back
Overview
Overview of the PDU
25.09.2015 BlueNet PDU BN3000/3500/5000/7000/7500 7

1.2 Short description
The power supply of a data centre can be monitored and controlled
remotely via the PDU. The PDU can be set up for single-phase or
three-phase systems. The individual phases can be distinguished
by their colours. The PDU is supplied with electricity via a CEE
plug.
The current, power (active, apparent and reactive power), power
consumption, voltage and frequency of all phases are monitored
via the PDU. This enables the efficient planning of resources and
the issuing of an alarm in the event of a fault. The PDU is designed
for a power range of 3.6 to 22 kW.
The PDU is integrated into the company network via the LAN port
(only available on the master PDU). Up to 10 slave PDUs can be
cascaded with a master PDU via the Modbus port.
The PDU can be operated locally via the display, via SNMP access
or with a web browser over a network, and the HTTP, HTTPS,
SSH, SNMP and Modbus-TCP protocols can be used.
The PDU is made of a sturdy aluminium profile and is installed
directly into the rack.
Depending on the type, the PDU has a variety of features such as
safety-plug sockets or IEC320 C14 and C20 type non-heating
appliance connectors, and external sensors (temperature/
humidity).
A connector inserted into the PDU can be secured with the non-
heating appliance locking device (C13/C19).
1.3 Displays and controls
The PDU can be operated locally via the display using the control
keys:
nDisplay system data (hardware and software version,
serial number, MAC address and item no.)
nDisplay the measured data
nSet the duration and orientation of the display
nDisplay and adjust the network settings as well as enabling or
disabling the DHCP protocol
Display with control keys
Fig. 7: Display with control keys
Overview
Displays and controls
25.09.2015BlueNet PDU BN3000/3500/5000/7000/75008

The status LED displays the status of the PDU. Possible states
are:
Colour Light Status
Green Continuously green All measurements are OK and the
status of the individual loads and
sensors are OK
Orange Continuously orange The measurement monitor is
issuing a warning (based on all the
measurements of the master
PDUs and sensors)
Red Continuously red The measurement monitor is
issuing an alarm (based on all the
measurements of the master
PDUs and sensors) or the signal
to a slave PDU or a sensor has
been interrupted
Yellow Continuously yellow PDU is starting up
White Continuously white Light signal to release the pressed
key (during Factory Reset)
Purple 500 ms off, 500 ms purple An update of a PDU is being car-
ried out
Purple, red 500 ms off, 500 ms purple, 500 ms off, 500 ms
red
An error occurred during the
update of a PDU
Master PDU status LED
Fig. 8: Status LED
Overview
Displays and controls
25.09.2015 BlueNet PDU BN3000/3500/5000/7000/7500 9

The status LED displays the status of the PDU. Possible states
are:
Starting process
Colour Light Status
Blue, orange 900 ms blue, 100 ms orange Connection to master PDU not yet estab-
lished or lost
Green Continuously green Connection to master PDU present
Blue, purple 500 ms blue, 500 ms purple An update of a PDU is being carried out
Blue, purple, red 500 ms blue, 500 ms purple, 500 ms
blue, 500 ms red
An error occurred during the update of a
PDU
In operation
Colour Light Status
Orange 900 ms off, 100 ms orange Connection to master PDU not yet estab-
lished or lost
Green, red 500 ms off, 100 ms green, 500 ms off,
100 ms red
Connection to master PDU present, internal
communication problems have occurred
Green 900 ms off, 100 ms green Connection to master PDU present, internal
communication functioning
Purple 500 ms off, 500 ms purple An update of the internal modules of a PDU
is being carried out
Purple, red 500 ms off, 500 ms purple, 500 ms off,
500 ms red
Error during update of the internal modules
of a PDU
Red Continuously red Measurement monitoring is issuing an alarm
Orange Continuously orange The measurement monitor is issuing a
warning
Slave PDU status LED
Fig. 9: Slave PDU status LED
Overview
Displays and controls
25.09.2015BlueNet PDU BN3000/3500/5000/7000/750010

The Modbus LED displays the activity of the PDUs connected to
the Modbus.
If the connection between the master and slave PDU is lost, the
Modbus LED on the master PDU goes out and the Modbus LED on
the slave PDU flashes.
The status LEDs (only available on the BN3500/5000/7000/7500)
display the status of the loads connected to the sockets.
See the operating instructions for further information
about the status LEDs on the sockets.
1.4 Communication
A temperature sensor and a humidity sensor can be connected to
the PDU via the ports for sensors. The values can be called up
under ‘Status è External sensors’ in the web interface.
Several PDUs can be connected to each other via the Modbus
port. This way, up to 10 slave PDUs can be cascaded with a
master PDU and managed via the web interface. The slave PDU is
connected to the master PDU via the M1 Modbus port. Further
slave PDUs are connected to each other via the M1/M2 Modbus
ports of the particular slave PDU.
The PDU can be integrated into the network via the LAN port. The
data transfer rate is controlled via the network.
There is a USB port on the PDU next to the display and control
panel. This is for updating the firmware.
Modbus LED
Fig. 10: Modbus LED
Status LED on the sockets
(only on BN3500/5000/7000/7500)
Fig. 11: Status LEDs on the sockets
Connection for sensors S1/S2
M1/M2 port for Modbus
LAN port (10/100 Mbit/s)
USB port for firmware updates
(only on the master PDU)
Overview
Communication
25.09.2015 BlueNet PDU BN3000/3500/5000/7000/7500 11

1.5 Scope of delivery
Fig. 12: Scope of delivery
The scope of the delivery includes:
nPDU (Fig. 12/Ⓐ)
nTwo plug-in brackets for mounting the PDU via the back
(Fig. 12/Ⓑ)
nTwo plug-in brackets for mounting the PDU via the sides
(Fig. 12/Ⓒ)
nTwo mounting brackets (Fig. 12/Ⓓ)
nTwo sets of non-heating appliance locking devices (C13/C19)
(Fig. 12/Ⓔ)
The plug-in bracket for mounting the PDU via the sides
is included in the delivery as of August 2015.
1.6 Optional accessories
The temperature and humidity at the installation location of the
PDU can be measured via a temperature sensor and a humidity
sensor. The values can be displayed in the display and on the web
interface. The cat 5e cable required to connect the sensors is
included.
Temperature sensor and humidity
sensor
Overview
Optional accessories
25.09.2015BlueNet PDU BN3000/3500/5000/7000/750012

2 Explanation of symbols
Safety information is indicated by symbols in these instructions.
The safety information is introduced by signal words that express
the nature of the danger.
DANGER!
This combination of symbol and signal word indicates
that there is an imminent danger that will result in
death or serious injury if it is not avoided.
WARNING!
This combination of symbol and signal word indicates
that there is a potential danger that can result in death
or serious injury if it is not avoided.
NOTICE!
This combination of symbol and signal word indicates
that there is a potential danger that can result in
damage to property if it is not avoided.
This symbol highlights useful tips and recommenda-
tions as well as information for efficient and trouble-
free operation.
The following markings are used to highlight specific instructions,
results, lists, references and other elements in these instructions:
Marking Explanation
Step-by-step instructions
ðResults of the steps of an instruction
References to sections in these instructions
and to other applicable documents
Items in a list without a specified sequence
Safety information
Tips and recommendations
Explanation of symbols
25.09.2015 BlueNet PDU BN3000/3500/5000/7000/7500 13

3 Personnel requirements and responsibilities
WARNING!
Risk of injury if the personnel is insufficiently
qualified!
If unqualified personnel carry out the installation work
on the PDU, serious injuries or substantial damage to
property can be caused.
– The installation and the connection of the PDU
must be carried out by an IT specialist.
– Defective components on the PDU must be
repaired by a qualified electrician.
Only permit persons to work on the PDU who can be expected to
carry out their work reliably. Persons whose capacity to react is
impaired, e.g. through drugs, alcohol, or medication, cannot be
permitted to perform such work.
In these instructions, the following personnel qualifications are
required for the various tasks listed below:
IT specialist
IT specialists have obtained specialist training or the appropriate
experience in dealing with IT systems and have a basic knowledge
of electrical engineering.
Due to their specialist training, IT specialists are in a position to
assess the consequences of their actions in dealing with the
system as well as its components and the potential dangers in
respect thereof and are able to avoid these.
The duties of an IT specialist include the following tasks:
nSetting up hardware and software systems
nInstalling updates
nMaintenance work on the PDU
nAdministration of the PDU via the web interface
nSystem diagnostics
Qualified electrician
Due to their professional training, knowledge and experience, as
well as their knowledge of the relevant standards and regulations,
qualified electricians are capable of working on electrical installa-
tions and independently identify and avoid potential dangers.
Qualified electricians are specifically trained for the working envi-
ronment in which they work and know the relevant standards and
regulations.
Personnel requirements and responsibilities
25.09.2015BlueNet PDU BN3000/3500/5000/7000/750014

4 Unpacking the PDU
nUnpack the delivery and check its completeness and integrity If
there is a defect, contact Bachmann GmbH immediately.
nIf possible, keep the packaging of the PDU so that the PDU
can be safely stored and transferred in the future. Dispose of
the packaging material that is no longer required in a manner
that is environmentally responsible.
Unpacking
Unpacking the PDU
25.09.2015 BlueNet PDU BN3000/3500/5000/7000/7500 15

5 Installing and connecting the PDU
5.1 Safety instructions for the installation
NOTICE!
Risk of damage due to improper fitting and instal-
lation!
Improper fitting and installation can cause substantial
damage to property.
– All the installation work must be carried out by an
IT specialist.
– Only install the PDU while it is de-energised.
– Before starting the work, ensure that you have suf-
ficient room for the installation.
– Ensure that installation area is clean and tidy.
– Install the components properly and lay the con-
nectors and cables in a manner that is safe.
– Secure the components so that they cannot fall
down or over.
5.2 Requirements of the installation location
nThere must be enough space in the rack to install the PDU.
nThe PDU may only be operated within the environmental con-
ditions set out in the technical specifications.
nThe the PDU may not be used in potentially explosive atmos-
pheres.
nThe PDU may not be subjected to vibrations.
nA location for the installation must be selected that does not
have excessive humidity, high temperatures, sources of elec-
tromagnetic interference, moisture, solvents, flammable gases,
dust or vapours.
nThere must be sufficient lighting.
nFire protection measures must be in place.
5.3 Installing the PDU
5.3.1 Overview
There are four options for installing the PDU in the rack:
nInstallation with mounting brackets ( Ä Chapter 5.3.2 ‘Installing
the PDU with the mounting brackets’ on page 18)
nInstallation with plug-in brackets via the rear of the PDU
(
Ä Chapter 5.3.3 ‘Installation with plug-in brackets via the rear
of the PDU’ on page 19)
Improper installation
Overview of the fitting options for
the PDU
Installing and connecting the PDU
Installing the PDU > Overview
25.09.2015BlueNet PDU BN3000/3500/5000/7000/750016

nInstallation with plug-in brackets via the sides of the PDU
(
Ä Chapter 5.3.4 ‘Installation with plug-in brackets via the
sides of the PDU’ on page 20)
nInstallation with the mounting solution in the rack ( Ä Chapter
5.3.5 ‘Installation with the mounting solution in the rack’
on page 21)
Fig. 13: Overview of the fitting options for the PDU
AFitting slots for plug-in bracket
BAttachment for the mounting bracket
CAttachment for the mounting solution in the
rack
DPlug-in brackets for mounting the PDU via the
back
EPlug-in brackets for mounting the PDU via the
sides
FMounting bracket
The following tools are required for the installation:
nPhillips screwdriver
nTorx screwdriver (IP8)
Tools required
Installing and connecting the PDU
Installing the PDU > Overview
25.09.2015 BlueNet PDU BN3000/3500/5000/7000/7500 17

5.3.2 Installing the PDU with the mounting brackets
Personnel: nIT specialist
1. Fit the mounting brackets (Fig. 14/Ⓑ) onto the attachments
at the top and bottom of the PDU (Fig. 14/Ⓑ).
2. Hold the PDU in the desired position against the rack and
mark the position of the mounting holes.
3. Remove the mounting brackets (Fig. 15/Ⓐ) from the PDU
and screw them onto the rack in the positions marked.
Fig. 14: Installation with mounting
brackets
APDU
BMounting bracket
Fig. 15: Rack with mounting brackets
Installing and connecting the PDU
Installing the PDU > Installing the PDU with the mounting brackets
25.09.2015BlueNet PDU BN3000/3500/5000/7000/750018

4. Fit the PDU onto the mounting brackets (Fig. 16).
5.3.3 Installation with plug-in brackets via the rear of the PDU
Personnel: nIT specialist
1. Insert the plug-in brackets into the rear slots on both sides
(Fig. 17).
2. Position the PDU in the rack.
Fig. 16: Rack with PDU
Fig. 17: Fitting the plug-in brackets
Installing and connecting the PDU
Installing the PDU > Installation with plug-in brackets via the rear of the PDU
25.09.2015 BlueNet PDU BN3000/3500/5000/7000/7500 19

3. Fasten the PDU to the rack with screws via both plug-in
brackets (Fig. 20).
5.3.4 Installation with plug-in brackets via the sides of the PDU
Personnel: nIT specialist
1. Insert the plug-in brackets into the side slots on both sides
(Fig. 19).
2. Position the PDU in the rack.
Fig. 18: Rack with PDU
Fig. 19: Fitting the plug-in brackets
Installing and connecting the PDU
Installing the PDU > Installation with plug-in brackets via the sides of the PDU
25.09.2015BlueNet PDU BN3000/3500/5000/7000/750020
