BAFANG H500F User manual

1
DEALER MANUAL FOR MOTOR
BF-DM-C-RM G060-DC-EN November 2019
6.1 Introduction 
6.2 Specifications 3
6.2.1 Outline and geometric size 3
6.2.2 Surface 3
6.2.3 Storage Information 3
6.3 Drive Unit Installation 4
6.3.1 List of Tools to be used 4
6.3.2 Motor Installation 4
6.4 Maintenance 5
CONTENT
6 DEALER MANUAL FOR H500F
(RM G060.350.DC)

2BF-DM-C-RM G060-DC-EN November 2019
6.1 INTRODUCTION
•Product Model
RM G060.350.DC
•Scope
Applies only to electrically powered pedelecs
developed or licensed by Bafang. It is suitable
for fat bikes or all terrain bikes, which have been
developed for off road on gravel or sand use.
The engine is not suitable for sport competi-
tions.
•Identification
The following graphic, is the identification
numbers of the product, which are shown on
the housing:
Note: Content in the label is important informa-
tion about this product. Please do not remove
the information from the motor.

3
DEALER MANUAL FOR MOTOR
BF-DM-C-RM G060-DC-EN November 2019
6.2 SPECIFICATIONS
Motor model: RM G060.350.DC
Rated power (W) 350
Rated voltage (V) 36
Waterproof IP65
Certification CE - EMC
Outdoor Temperatures -20℃~45℃
6.2.1 Outline and geometric size
OLD: 175mm
Shaft length: 235mm
Motor cable length: L=250mm
6.2.2 Surface
Shockproof black coating
6.2.3 Storage Information
The pedelec should be stored in a ventilated dry room. Avoid storing the pedelec near strong magnetic
objects.

4BF-DM-C-RM G060-DC-EN November 2019
6.3 DRIVE UNIT INSTALLATION
6.3.1 List of Tools to be used
Use of the Tools Tools
To tighten/loosen the M5*8 screws onto the disc brake. Internal hex wrench
To tighten/loosen the M12 flange nuts. Open spanner
6.3.2 Motor Installation
1. First mount the cassette on the cassette
seat.
2. Tighten the disk brake with six screws onto
motor.
3. Insert the stop pin into on the shaft.
4. Insert the motor into the frame.
5. Mount the 4mm washer on both sides of
the frame.

5
DEALER MANUAL FOR MOTOR
BF-DM-C-RM G060-DC-EN November 2019
6. Tighten clockwise M12 flange nuts with
open spanner at both sides of the motor.
(torque requirement: 47-60 N.m.)
7. Mount the shaft end sheath on both sides
of the shaft ends.
6.4 MAINTENANCE
• Maintenance must be carried out by autho-
rized personnel with the correct equipment.
• Do not disassemble the motor.
• Do not use thinners or other solvents to
clean the components. Such substances can
damage the surfaces.
• Avoid water submerging, to keep the com-
ponents protected.
• Avoid using high-pressure cleaning jets.
• For prolonged storage, turn off the battery
and avoid storing near heat sources.
