Baileigh IP-208 User manual

PLANER
MODEL: IP-208
© 2012 Baileigh Industrial, Inc.
REPRODUCTION OF THIS MANUAL IN ANY FORM WITHOUT WRITTEN APPROVAL OF BAILEIGH INDUSTRIAL, INC.
IS PROHIBITED. Baileigh Industrial, Inc. does not assume and hereby disclaims any liability for any damage or loss
caused by an omission or error in this Operator’s Manual, resulting from accident, negligence, or other occurence.
Rev. 10/2012
Baileigh Industrial, Inc.
P.O. Box 531
Manitowoc, WI 54221-0531
Phone: [phone]
Fax: [phone]
[email protected]
OPERATOR’S
MANUAL

Table of Contents
THANK YOU & WARRANTY..........................................................................................1
INTRODUCTION ............................................................................................................3
GENERAL NOTES..........................................................................................................3
SAFETY INSTRUCTIONS..............................................................................................4
SAFETY PRECAUTIONS...............................................................................................6
SPECIFICATIONS..........................................................................................................9
TECHNICAL SUPPORT ................................................................................................. 9
UNPACKING AND CLEANING..................................................................................... 10
Cleaning .................................................................................................................... 10
INSTALLATION and ASSEMBLY ................................................................................. 11
ASSEMBLY EXTENSION TABLE................................................................................. 12
DUST CHUTE ASSEMBLY........................................................................................... 13
ELECTRICAL................................................................................................................ 13
Extension Cord Safety............................................................................................... 14
ELECTRICAL DIAGRAM.............................................................................................. 15
CONTROL THE DEPTH OF CUTTING ........................................................................16
CHECKING PULLEY .................................................................................................... 16
Adjusting Motor Mount............................................................................................... 16
ADJUSTING BELT TENSION....................................................................................... 17
FEED ROLL SPEED RATE .......................................................................................... 17
ROLL TRANSMITTING................................................................................................. 18
CONNECTING DUST COLLECTOR ............................................................................ 18
FEEDROLL PRESSURE AJDUSTMENT .....................................................................18
ADJUSTMENT TRANSMITTING ROLLER................................................................... 19
ADJUSTING TABLE ROLLER...................................................................................... 19
ADJUST ROLLER......................................................................................................... 19
CONSTRUCTING GAUGE BLOCK.............................................................................. 20
ASSEMBLING CHAIN................................................................................................... 20
ADJUSTING CUTTING HEAD PARALLEL TO TABLE................................................. 21
ADJUSTING SPRING TENSION OF FEED ROLLER .................................................. 22
Adjusting Infeed and Outfeed Roller.......................................................................... 22
Infeed Roller.............................................................................................................. 23
Outfeed Roller ........................................................................................................... 23
CHECK HEIGHT OF PRESSURE BAR........................................................................ 24
CHECK HEIGHT OF CHIPBREAKER ..........................................................................24
DIGITAL READOUT...................................................................................................... 25
MAINTENANCE............................................................................................................ 27
Parts Lubrication Required........................................................................................ 28
Change Lubricant...................................................................................................... 29
PARTS DIAGRAM –SHEET 1 ..................................................................................... 30
PARTS DIAGRAM –SHEET 2 ..................................................................................... 31
PARTS DIAGRAM –SHEET 3 ..................................................................................... 32
PARTS DIAGRAM –SHEET 4 ..................................................................................... 33
Parts List ................................................................................................................... 34

1
1
THANK YOU & WARRANTY
Thank you for your purchase of a machine from Baileigh Industrial. We hope that you find it
productive and useful to you for a long time to come.
Inspection & Acceptance. Buyer shall inspect all Goods within ten (10) days after receipt thereof. Buyer’s
payment shall constitute final acceptance of the Goods and shall act as a waiver of the Buyer’s rights to inspect or
reject the goods unless otherwise agreed. If Buyer rejects any merchandise, Buyer must first obtain a Returned
Goods Authorization (“RGA”) number before returning any goods to Seller. Goods returned without a RGA will be
refused. Seller will not be responsible for any freight costs, damages to goods, or any other costs or liabilities
pertaining to goods returned without a RGA. Seller shall have the right to substitute a conforming tender. Buyer will
be responsible for all freight costs to and from Buyer and repackaging costs, if any, if Buyer refuses to accept
shipment. If Goods are returned in unsalable condition, Buyer shall be responsible for full value of the Goods.
Buyer may not return any special order Goods. Any Goods returned hereunder shall be subject to a restocking fee
equal to 30% of the invoice price.
Specifications. Seller may, at its option, make changes in the designs, specifications or components of the Goods
to improve the safety of such Goods, or if in Seller’s judgment, such changes will be beneficial to their operation or
use. Buyer may not make any changes in the specifications for the Goods unless Seller approves of such changes
in writing, in which event Seller may impose additional charges to implement such changes.
Limited Warranty. Seller warrants to the original end-user that the Goods manufactured or provided by Seller
under this Agreement shall be free of defects in material or workmanship for a period of twelve (12) months from
the date of purchase, provided that the Goods are installed, used, and maintained in accordance with any
instruction manual or technical guidelines provided by the Seller or supplied with the Goods, if applicable. The
original end-user must give written notice to Seller of any suspected defect in the Goods prior to the expiration of
the warranty period. The original end-user must also obtain a RGA from Seller prior to returning any Goods to
Seller for warranty service under this paragraph. Seller will not accept any responsibility for Goods returned without
a RGA. The original end-user shall be responsible for all costs and expenses associated with returning the Goods
to Seller for warranty service. In the event of a defect, Seller, at its sole option, shall repair or replace the defective
Goods or refund to the original end-user the purchase price for such defective Goods. Goods are not eligible for
replacement or return after a period of 30 days from date of receipt. The foregoing warranty is Seller’s sole
obligation, and the original end-user’s exclusive remedy, with regard to any defective Goods. This limited warranty
does not apply to: (a) die sets, tooling, and saw blades; (b) periodic or routine maintenance and setup, (c) repair or
replacement of the Goods due to normal wear and tear, (d) defects or damage to the Goods resulting from misuse,
abuse, neglect, or accidents, (f) defects or damage to the Goods resulting from improper or unauthorized
alterations, modifications, or changes; and (f) any Goods that has not been installed and/or maintained in
accordance with the instruction manual or technical guidelines provided by Seller.
EXCLUSION OF OTHER WARRANTIES. THE FOREGOING LIMITED WARRANTY IS IN LIEU OF ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED. ANY AND ALL OTHER EXPRESS, STATUTORY OR IMPLIED
WARRANTIES, INCLUDING BUT NOT LIMITED TO, ANY WARRANTY OF MERCHANTABILITY OR FITNESS
FOR ANY PARTICULAR PURPOSE ARE EXPRESSLY DISCLAIMED. NO WARRANTY IS MADE WHICH
EXTENDS BEYOND THAT WHICH IS EXPRESSLY CONTAINED HEREIN.
Limitation of Liability. IN NO EVENT SHALL SELLER BE LIABLE TO BUYER OR ANY OTHER PARTY FOR
ANY INCIDENTIAL, CONSEQUENTIAL OR SPECIAL DAMAGES (INCLUDING, WITHOUT LIMITATION, LOST
PROFITS OR DOWN TIME) ARISING FROM OR IN MANNER CONNECTED WITH THE GOODS, ANY BREACH
BY SELLER OR ITS AGENTS OF THIS AGREEMENT, OR ANY OTHER CAUSE WHATSOEVER, WHETHER
BASED ON CONTRACT, TORT OR ANY OTHER THEORY OF LIABILITY. BUYER’S REMEDY WITH RESPECT
TO ANY CLAIM ARISING UNDER THIS AGREEMENT IS STRICTLY LIMITED TO NO MORE THAN THE
AMOUNT PAID BY THE BUYER FOR THE GOODS.

2
2
Force Majuere. Seller shall not be responsible for any delay in the delivery of, or failure to deliver, Goods due to
causes beyond Seller’s reasonable control including, without limitation, acts of God, acts of war or
terrorism, enemy actions, hostilities, strikes, labor difficulties, embargoes, non-delivery or late delivery of materials,
parts and equipment or transportation delays not caused by the fault of Seller, delays caused by civil authorities,
governmental regulations or orders, fire, lightening, natural disasters or any other cause beyond Seller's reasonable
control. In the event of any such delay, performance will be postponed by such length of time as may be reasonably
necessary to compensate for the delay.
Installation. If Buyer purchases any Goods that require installation, Buyer shall, at its expense, make all
arrangements and connections necessary to install and operate the Goods. Buyer shall install the Goods in
accordance with any Seller instructions and shall indemnify Seller against any and all damages, demands, suits,
causes of action, claims and expenses (including actual attorneys’ fees and costs) arising directly or indirectly out
of Buyer’s failure to properly install the Goods.
Work By Others; Safety Devices. Unless agreed to in writing by Seller, Seller has no responsibility for labor or
work performed by Buyer or others, of any nature, relating to design, manufacture, fabrication, use, installation or
provision of Goods. Buyer is solely responsible for furnishing, and requiring its employees and customers to use all
safety devices, guards and safe operating procedures required by law and/or as set forth in manuals and instruction
sheets furnished by Seller. Buyer is responsible for consulting all operator’s manuals, ANSI or comparable safety
standards, OSHA regulations and other sources of safety standards and regulations applicable to the use and
operation of the Goods.
Remedies. Each of the rights and remedies of Seller under this Agreement is cumulative and in addition to any
other or further remedies provided under this Agreement or at law or equity.
Attorney’s Fees. In the event legal action is necessary to recover monies due from Buyer or to enforce any
provision of this Agreement, Buyer shall be liable to Seller for all costs and expenses associated therewith,
including Seller’s actual attorneys' fees and costs.
Governing Law/Venue. This Agreement shall be construed and governed under the laws of the State of
Wisconsin, without application of conflict of law principles. Each party agrees that all actions or proceedings arising
out of or in connection with this Agreement shall be commenced, tried, and litigated only in the state courts sitting in
Manitowoc County, Wisconsin or the u.s. Federal Court for the Eastern District of Wisconsin. Each party waives
any right it may have to assert the doctrine of “forum non conveniens” or to object to venue to the extent that any
proceeding is brought in accordance with this section. Each party consents to and waives any objection to the
exercise of personal jurisdiction over it by courts described in this section. Each party waives to the fullest extent
permitted by applicable law the right to a trial by jury.
Summary of Return Policy.
10 Day acceptance period from date of delivery. Damage claims and order discrepancies will not be accepted
after this time.
You must obtain a Baileigh issued RGA number PRIOR to returning any materials.
Returned materials must be received at Baileigh in new condition and in original packaging.
Altered items are not eligible for return.
Buyer is responsible for all shipping charges.
A 30% re-stocking fee applies to all returns.
Baileigh Industrial makes every effort to ensure that our posted specifications, images, pricing and product
availability are as correct and timely as possible. We apologize for any discrepancies that may occur. Baileigh
Industrial reserves the right to make any and all changes deemed necessary in the course of business including but
not limited to pricing, product specifications, quantities, and product availability.
For Customer Service & Technical Support:
Please contact one of our knowledgeable Sales and Service team members at:
[phone] or e-mail us at [e-mail]

3
3
INTRODUCTION
The quality and reliability of the components assembled on a Baileigh Industrial machine
guarantee near perfect functioning, free from problems, even under the most demanding
working conditions. However if a situation arises, refer to the manual first. If a solution cannot be
found, contact the distributor where you purchased our product. Make sure you have the serial
number and production year of the machine (stamped on the nameplate). For replacement parts
refer to the assembly numbers on the parts list drawings.
Our technical staff will do their best to help you get your machine back in working order.
In this manual you will find: (when applicable)
Safety procedures
Correct installation guidelines
Description of the functional parts of the machine
Capacity charts
Set-up and start-up instructions
Machine operation
Scheduled maintenance
Parts lists
GENERAL NOTES
After receiving your equipment remove the protective container. Do a complete visual
inspection, and if damage is noted, photograph it for insurance claims and contact your
carrier at once, requesting inspection. Also contact Baileigh Industrial and inform them of the
unexpected occurrence. Temporarily suspend installation.
Take necessary precautions while loading / unloading or moving the machine to avoid any
injuries.
Your machine is designed and manufactured to work smoothly and efficiently. Following proper
maintenance instructions will help ensure this. Try and use original spare parts, whenever
possible, and most importantly; DO NOT overload the machine or make any unauthorized
modifications.
Note: This symbol refers to useful information throughout the manual.

4
4
LEARN TO RECOGNIZE SAFETY INFORMATION
This is the safety alert symbol. When you see this symbol
on your machine or in this manual, BE ALERT TO THE
POTENTIAL FOR PERSONAL INJURY!
Follow recommended precautions and safe operating
practices.
UNDERSTAND SIGNAL WORDS
A signal word –DANGER, WARNING, or CAUTION is
used with the safety alert symbol. DANGER identifies a
hazard or unsafe practice that will result in severe Injury
or Death.
Safety signs with signal word DANGER or WARNING are
typically near specific hazards.
General precautions are listed on CAUTION safety signs.
CAUTION also calls attention to safety messages in this
manual.
IMPORTANT
PLEASE READ THIS OPERATORS MANUAL CAREFULLY
It contains important safety information, instructions, and necessary operating procedures.
The continual observance of these procedures will help increase your production and
extend the life of the equipment.
SAFETY INSTRUCTIONS

5
5
SAVE THESE INSTRUCTIONS.
Refer to them often and use them to instruct others.
PROTECT EYES
Wear safety glasses or suitable eye
protection when working on or around
machinery.
BLADE HAZARD
Keep hands and fingers away from the rotating knife blades. These
rotating knives can be extremely dangerous if you do not follow proper
safety procedures. NEVER place hands closer than 3” (76mm ) to the
rotating cutting knives.
ENTANGLEMENT HAZARD –ROTATING BLADES
Contain long hair, DO NOT wear jewelry or loose fitting clothing.
PROTECT AGAINST NOISE
Prolonged exposure to loud noise can cause impairment or loss of
hearing. Wear suitable hearing protective devices such as ear muffs or
earplugs to protect against objectionable or uncomfortable loud noises.
BEWARE OF PINCH POINTS
Keep hands and fingers clear of all
potential pinch points. These include
sprockets and chains along with belts and
pulleys.

6
6
HIGH VOLTAGE
USE CAUTION IN HIGH VOLTAGE AREAS. DO NOT assume the
power to be off.
(FOLLOW PROPER LOCKOUT PROCEDURES)
SAFETY PRECAUTIONS
Wood working can be dangerous if safe and proper operating procedures are not followed. As
with all machinery, there are certain hazards involved with the operation of the product. Using
the machine with respect and caution will considerably lessen the possibility of personal injury.
However, if normal safety precautions are overlooked or ignored, personal injury to the operator
may result.
Safety equipment such as guards, push sticks, hold-downs, feather boards, goggles, dust
masks and hearing protection can reduce your potential for injury. But even the best guard won’t
make up for poor judgment, carelessness or inattention. Always use common sense and
exercise caution in the workshop. If a procedure feels dangerous, don’t try it.
REMEMBER: Your personal safety is your responsibility.
1. FOR YOUR OWN SAFETY, READ INSTRUCTION MANUAL BEFORE OPERATING THE
MACHINE. Learn the machine’s application and limitations as well as the specific hazards.
2. Only trained and qualified personnel should operate this machine.
3. Kickback. Become familiar with the term “Kickback” and how it occurs before operating
this planer. Kickback happens when the piece part is thrown towards the operator at a high
rate of speed with the potential for serious injury.
4. Kickback Zone. The path directly behind the end of the in-feed table is referred to as the
“Kickback zone”. NEVER stand or allow others to stand in this area while the machine is
running. Position yourself to one side of the machine while the planer is running.
5. Reaching Inside Planer. To avoid serious personal injury from rotating knives, NEVER
remove guards or reach inside the planer while it is connected to power. Always Follow
proper lockout /tagout procedures.
WARNING:
FAILURE TO FOLLOW THESE RULES MAY RESULT IN
SERIOUS PERSONAL INJURY

7
7
SAFETY PRECAUTIONS (cont.)
6. Clearing Jams. To avoid serious personal injury from rotating knives, ALWAYS STOP the
planer and disconnect power before removing a jammed piece part. Always follow proper
lockout/tagout procedures.
7. Using Quality Stock. Inspect the stock over carefully that you intend to plane. NEVER
plane a board that has loose knots, staples, or nails in it. DO NOT plane a piece of stock if
you have any doubts about its structural integrity.
8. Remove any adjusting tools. Before operating the machine, make sure any adjusting tools
have been removed.
9. Dull / Damaged Knives. Use only sharp, undamaged knives to avoid unnecessary kickback
of the piece part. Dull and damaged knives will also affect cut quality.
10.Looking Inside Planer. Wood chips fly around inside the planer at a high rate of speed as it
is running. To avoid possible injury from flying debris, DO NOT look inside the planer while it
is running.
11.Keep work area clean. Cluttered areas invite injuries.
12.Overloading machine. By overloading the machine you may cause injury from flying parts.
DO NOT exceed the specified machine capacities.
13.Dress appropriate. DO NOT wear loose fitting clothing or jewelry as they can be caught in
moving machine parts. Protective clothing and steel toe shoes are recommended when
using machinery. Wear a restrictive hair covering to contain long hair.
14.Use eye and ear protection. Always wear ISO approved impact safety goggles
15.Do not overreach. Maintain proper footing and balance at all times. DO NOT reach over or
across a running machine.
16.Stay alert. Watch what you are doing and use common sense. DO NOT operate any tool or
machine when you are tired.
17.Grain Direction. There is an increased chance of kickback when planing end grain or
against the grain. This could also produce chatter and excessive chip out of the material.
18.Observe work area conditions. DO NOT use machines or power tools in damp or wet
locations. Do not expose to rain. Keep work area well lighted. DO NOT use electrically
powered tools in the presence of flammable gases or liquids.
19.DO NOT bypass or defeat any safety interlock systems.
20.Know the location of the ON - OFF switch and the “E” - STOP button.
21.Keep visitors a safe distance from the work area.

8
8
SAFETY PRECAUTIONS (cont.)
22.In-feed Roller Clearance. The in-feed roller is designed to pull material into the rotating
cutterhead. To avoid serious personal injury, keep hands, jewelry, clothing, and long hair
away from the in-feed roller while operating the machine.
23.Keep children away. Children must never be allowed in the work area. DO NOT let them
handle machines, tools, or extension cords.
24.DO NOT operate machine if under the influence of alcohol or drugs. Read warning
labels on prescriptions. If there is any doubt, DO NOT operate the machine.
25.DO NOT touch live electrical components or parts.
26.Be Sure all equipment is properly installed and grounded according to national, state, and
local codes. If machine is equipped with a three-prong plug, it should be plugged into a
three-hole electrical receptacle. If an adapter is used to accommodate a two-prong
receptacle, the adapter plug must be attached to a known ground. Never remove the third
prong.
27.Inspect power and control cables periodically. Replace if damaged or bare wires are
exposed. Bare wiring can kill!
28.Maintain machine in top condition. Keep clean for best and safest performance. Follow
instructions for lubricating and changing accessories.
29.Reduce the risk of unintentional starting. Make sure switch is in “OFF” position before
plugging in power cord.
30.Never leave machine running unattended. TURN POWER OFF. Don’t leave machine until
it comes to a complete stop.
31.Make sure machine is disconnected from power supply while motor is being mounted,
connected or reconnected.
32.Using Correct Materials. Planing materials other than natural wood fiber can result in
serious personal injury and machine damage. NEVER use this machine for anything except
planing in wood.
33.Warning: The dust generated by certain woods and wood products can be injurious to your
health. Always operate machinery in well ventilated areas and provide for proper dust
removal. Use wood dust collection systems whenever possible.
EMERGENCY STOP BUTTON
In the event of incorrect operation or dangerous conditions, the machine can be stopped
immediately by pressing the E-STOP button.

9
9
SPECIFICATIONS
Cutting Capacity (W x H)
20" x 8" (508 x 203mm)
Maximum Depth of Cut
1/8” (3.1mm)
Minimum Material Thickness
1/4” (6.3mm)
Cutterhead Speed
5000 RPM
Number Of Knives
4
Cutter Head Size
3.25” (82.5mm)
Motor
5Hp (3.72kw), 1Ph, 60Hz, 220V
Shipping Weight (Approx.)
830 lbs. (376kg)
TECHNICAL SUPPORT
Our technical support department can be reached at 920.684.4990, and asking for the support
desk for purchased machines. Tech Support handles questions on machine setup, schematics,
warranty issues, and individual parts needs: (other than die sets and blades).
For specific application needs or future machine purchases contact the Sales Department at:
[email protected], Phone: [phone], or Fax: [phone].
Note:The manual cover photo illustrates the current production model. All other
illustrations are representative only and may not depict the actual color, labeling or accessories
and may be intended to illustrate technique only.
Note: The specifications and dimensions presented here are subject to change
without prior notice due to improvements of our products.

10
10
UNPACKING AND CLEANING
Remove planer and stand from the shipping cartons. Check for damage and ensure all parts are
intact. Any damage should be reported immediately to your distributor and shipping agent.
Before assembling, read the manual thoroughly, familiarizing yourself with correct assembly and
maintenance procedures and proper safety precautions.
Cleaning
Your machine may be shipped with a rustproof waxy oil coating and grease on the exposed
unpainted metal surfaces. To remove this protective coating, use a degreaser or solvent
cleaner. For a more thorough cleaning, some parts will occasionally have to be removed. DO
NOT USE acetone or brake cleaner as they may damage painted surfaces.
Follow manufacturer’s label instructions when using any type of cleaning product. After cleaning,
wipe unpainted metal surfaces with a light coating of quality oil or grease for protection.
Although some users prefer a wax coating for the table surfaces, white talcum powder rubbed in
vigorously once a week with a blackboard eraser will fill any casting pores and form a moisture
barrier. Talcum powder will not stain wood or mar finishes.
WARNING: DO NOT USE gasoline or other petroleum products to clean
the machine. They have low flash points and can explode or cause fire.
CAUTION: When using cleaning solvents work in a well ventilated area.
Many cleaning solvents are toxic if inhaled.
GAS

11
11
INSTALLATION and ASSEMBLY
IMPORTANT:
Consider the following when looking for a suitable location to place the machine:
Overall weight of the machine.
Weight of material being processed.
Sizes of material to be processed through the machine.
Space needed for auxiliary stands, work tables, or other machinery.
Clearance from walls and other obstacles.
Maintain an adequate working area around the machine for safety.
Have the work area well illuminated with proper lighting.
Keep the floor free of oil and make sure it is not slippery.
Remove scrap and waste materials regularly, and make sure the work area is free from
obstructing objects.
If long lengths of material are to be fed into the machine, make sure that they are safely
supported and will not extend into any aisles.
The machine should be sited on a level, concrete floor. The accuracy of any machine depends
on the precise placement of it to the mounting surface. Locate the planer in an area that is level
and provides a solid foundation. Make sure that any potential kickback is not in line with aisles,
doorways, wash stations or other work areas.
Place shims under the four feet mounted in the base
as required for leveling.
There are four lifting handles (A) hidden in the bed of
the planer table. Pull the handles out for use and push
them down otherwise.
WARNING:FOR YOUR OWN SAFETY, DO NOT CONNECT THE MACHINE
TO THE POWER SOURCE UNTIL THE MACHINE IS COMPLETELY ASSEMBLED AND
YOU READ AND UNDERSTAND THE ENTIRE INSTRUCTION MANUAL.
WARNING: Before operating; make sure it is positioned firmly on a solid
level floor. If it tips over on you, it could cause severe injury or death.
Fig. 1

12
12
ASSEMBLY EXTENSION TABLE
1. Use an assistant to help lift and align the holes
on the extension table to the main table.
2. Insert the bolts and loosely secure with
washers and nuts. (Fig. 2).
3. With the fasteners in position and snug, place
straight edge through machine so that it lies
across the main table and extension table.
(Fig. 3).
4. Align the extension table to the main table.
When the tables are aligned, hold in position
and securely tighten the fasteners.
WARNING:
For your own safety, DO NOT connect the machine to the
power source until the machine is completely assembled and you read and
understand the entire instruction manual.
Fig. 2
Fig. 3

13
13
DUST CHUTE ASSEMBLY
1. Mount the dust chute to the planer hood with
hex head screws & flat washer.
2. Make sure the dust collection system has
sufficient capacity and suction for your planer.
3. Always turn on the dust collection system
before starting the planer. (Fig. 4).
ELECTRICAL
Motor Specifications
Your tool is wired for 220 volt, 60Hz alternating current. Before connecting the tool to the power
source, make sure the machine is cut off from power source.
Connections
A separate electrical circuit should be used for your tools. If an extension cord is used, use
only 3-wire extension cords, which have grounding type plugs and receptacles, which accept
the tool’s plug. Before connecting the motor to the power line, make sure the switch is in the
“OFF” position and be sure that the electric current is of the same characteristics as
indicated on the tool.
All line connections should make good contact. Running on low voltage will damage the
motor.
CAUTION: HAVE ELECTRICAL UTILITIES CONNECTED TO MACHINE BY
A CERTIFIED ELECTRICIAN!
Check if the available power supply is the same as listed on the machine nameplate.
WARNING: Make sure the grounding wire (green) is properly connected
to avoid electric shock. DO NOT switch the position of the green grounding wire if
any electrical plug wires are switched during hookup.
Fig. 4

14
14
In the event of a malfunction or breakdown, grounding provides a path of least resistance for
electric current to reduce the risk of electric shock. This tool is equipped with an electric cord
having an equipment-grounding conductor and a grounding plug. The plug must be plugged
into a matching outlet that is properly installed and grounded in accordance with all local
codes and ordinances.
Do not modify the plug provided - if it will not fit the outlet, have the proper outlet installed by
a qualified electrician.
Improper connection of the equipment-grounding conductor can result in risk of electric
shock. The conductor with insulation having an outer surface that is green with or without
yellow stripes is the equipment-grounding conductor. If repair or replacement of the electric
cord or plug is necessary, do not connect the equipment-grounding conductor to a live
terminal.
Check with a qualified electrician or service personnel if the grounding instructions are not
completely understood, or if in doubt as to whether the tool is properly grounded.
Use only 3-wire extension cords that have grounding type plugs and receptacles that accept
the tool’s plug.
Repair or replace damaged or worn cord immediately.
Extension Cord Safety
Extension cord should be in good condition and meet the minimum wire gauge requirements
listed below:
LENGTH
AMP RATING
25ft
50ft
100ft
0-6
16
16
16
7-10
16
16
14
11-12
16
16
14
13-16
14
12
12
17-20
12
12
10
21-30
10
10
No
WIRE GAUGE
An undersized cord decreases line voltage, causing loss of power and overheating. All cords
should use a ground wire and plug pin. Replace any damaged cords immediately.
WARNING:
In all cases, make certain the receptacle in question is
properly grounded. if you are not sure, have a qualified electrician check the
receptacle.

15
15
ELECTRICAL DIAGRAM

16
16
CONTROL THE DEPTH OF CUTTING
The cutting depth scale is a combination of inch / metric
scale, the cutting range is from 0 to 8" (204 mm). The
distance between upward or downward of driving
handle is 0.059" (1.5mm) one complete turn.
Before adjusting the table upward, or downward; loosen
nut (A), after positioning to required position, tighten nut
(A) again to hold in position. (Fig. 5)
CHECKING PULLEY
To verify that motor pulley (B) is in line with the shaft
pulley of (A), using the edge of a straight scale check to
see if they are on-line with each other.(Fig. 6).
Adjusting Motor Mount
If motor pulley B and shaft pulley A, are not on-line
loosen screw as shown in (Fig. 7), move shaft to left and
right until adjusted to proper position and tighten the
screw again.
CAUTION: Always wear proper eye protection with side shields, face
shield, safety footwear, and leather gloves to protect from, chips, dust, burrs, and
slivers.
Fig. 5
Fig. 7
Fig. 6

17
17
ADJUSTING BELT TENSION
Use the two bolts to adjust the belt tension (Fig. 8).
When achieved proper position of adjustment tighten
bolts to hold in place.
FEED ROLL SPEED RATE
The rate of speed is transmitted by shift gears located
in gear box.
The shift gear handle (Fig. 9) performs with three
different methods of speed by using the shift handle to
pull or push.
Position A: feed roll is functioning on 20-FPM speed
rate.
Position B: feed roll is functioning on 0-speed rate.
Position C: feed roll is functioning on 16-FPM speed
rate.
Fig. 8
Fig. 9
Fig. 10

18
18
ROLL TRANSMITTING
The purpose of the roll located on top of machine, is
transmitting stock after cutting and shaving
workpieces. This roll will save you lots of time, and will
speed up you’re working rate. (Fig. 11)
CONNECTING DUST COLLECTOR
Connect dust collector system to hood of machine,
located at the back of machine. The dust collector will
collect all dust and particles while molding in process,
this system will give a clean and safe working
environment. (Fig. 12)
FEEDROLL PRESSURE AJDUSTMENT
The pressure of the feed roll will depend on the
pressure set by the springs, and screws.
To adjust the pressure, you must loosen or tighten the
lever. There are two sets of springs on both ends of the
feed roll, to ensure great results make sure both sides
are at the same level pressure. (Fig. 13)
Fig. 11
Fig. 12
Fig. 13
