Baileigh JP-1250 User manual

JOINTER / PLANER
MODEL: JP-1250
© 2013 Baileigh Industrial, Inc.
REPRODUCTION OF THIS MANUAL IN ANY FORM WITHOUT WRITTEN APPROVAL OF BAILEIGH INDUSTRIAL, INC.
IS PROHIBITED. Baileigh Industrial, Inc. does not assume and hereby disclaims any liability for any damage or loss
caused by an omission or error in this Operator’s Manual, resulting from accident, negligence, or other occurrence.
Rev. 4/2013
Baileigh Industrial, Inc.
P.O. Box 531
Manitowoc, WI 54221-0531
Phone: [phone]
Fax: [phone]
[email protected]
OPERATOR’S
MANUAL

Table of Contents
THANK YOU & WARRANTY..........................................................................................1
INTRODUCTION ............................................................................................................3
GENERAL NOTES..........................................................................................................3
SAFETY INSTRUCTIONS..............................................................................................4
SAFETY PRECAUTIONS...............................................................................................7
UNPACKING................................................................................................................. 10
SPECIFICATIONS........................................................................................................ 11
TECHNICAL SUPPORT ............................................................................................... 11
TRANSPORTING AND LIFTING .................................................................................. 12
INSTALLATION ............................................................................................................ 13
Cleaning .................................................................................................................... 14
GETTING TO KNOW YOUR MACHINE....................................................................... 15
ASSEMBLY................................................................................................................... 17
Fence Installation ...................................................................................................... 17
Jointer Guide/Guard Installation................................................................................ 18
ELECTRICAL................................................................................................................ 19
ELECTRICAL DIAGRAM.............................................................................................. 21
Connection Diagram..................................................................................................21
Control Panel Functions............................................................................................ 22
Bridge Guard/Guide................................................................................................... 22
Anti-Kickback Guards................................................................................................ 22
DUST-COLLECTING.................................................................................................... 23
OPERATIONAL ADJUSTMENTS................................................................................. 24
Jointer Depth of Cut Adjustment................................................................................ 24
Determining Correct Table Height............................................................................. 25
Jointer Outfeed Table Adjustment............................................................................. 26
Jointer Fence Adjustment.......................................................................................... 27
Planer Table Height Adjustment................................................................................ 28
Changeover from a Jointer to a Planer......................................................................29
Changeover from a Planer to a Jointer......................................................................30
JOINTER OPERATION................................................................................................. 31
Surface Planing- Workpieces Less Than 75mm Thick..............................................33
Surface Planing - Workpieces Over 75mm Thick...................................................... 34
Jointing...................................................................................................................... 35
Thickness Planing ..................................................................................................... 39
MAINTENANCE............................................................................................................ 41
ANTI-KICKBACK FINGERS.......................................................................................... 42
Cleaning the Feed Rollers......................................................................................... 42
Tighten/Replacing the Drive Belt............................................................................... 43
REPLACING OR ROTATING KNIFE INSERTS ........................................................... 44
TROUBLESHOOTING.................................................................................................. 45
CABINET PARTS DIAGRAM........................................................................................ 46
Cabinet Parts List...................................................................................................... 47
JOINTER TABLE PARTS DIAGRAM............................................................................ 48
Jointer Table Parts List.............................................................................................. 49
CUTTER HEAD AND FEED ROLLER PARTS DIAGRAM............................................ 50
Cutter Head and Feed Roller Parts List..................................................................... 51

FEED ROLLER DRIVE PARTS DIAGRAM................................................................... 52
Feed Roller Drive Parts List....................................................................................... 53
PLANER TABLE PARTS DIAGRAM.............................................................................54
Planer Table Parts List .............................................................................................. 55
LIMIT SWITCH PARTS DIAGRAM............................................................................... 56
Limit Switch Parts List ............................................................................................... 56
BRIDGE GUARD/GUIDE PARTS DIAGRAM ............................................................... 57
Bridge Guard/Guide Parts List................................................................................... 57
FENCE PARTS DIAGRAM........................................................................................... 58
Fence Parts List......................................................................................................... 59

1
1
THANK YOU & WARRANTY
Thank you for your purchase of a machine from Baileigh Industrial. We hope that you find it
productive and useful to you for a long time to come.
Inspection & Acceptance. Buyer shall inspect all Goods within ten (10) days after receipt thereof. Buyer’s
payment shall constitute final acceptance of the Goods and shall act as a waiver of the Buyer’s rights to inspect or
reject the goods unless otherwise agreed. If Buyer rejects any merchandise, Buyer must first obtain a Returned
Goods Authorization (“RGA”) number before returning any goods to Seller. Goods returned without a RGA will be
refused. Seller will not be responsible for any freight costs, damages to goods, or any other costs or liabilities
pertaining to goods returned without a RGA. Seller shall have the right to substitute a conforming tender. Buyer will
be responsible for all freight costs to and from Buyer and repackaging costs, if any, if Buyer refuses to accept
shipment. If Goods are returned in unsalable condition, Buyer shall be responsible for full value of the Goods.
Buyer may not return any special order Goods. Any Goods returned hereunder shall be subject to a restocking fee
equal to 30% of the invoice price.
Specifications. Seller may, at its option, make changes in the designs, specifications or components of the Goods
to improve the safety of such Goods, or if in Seller’s judgment, such changes will be beneficial to their operation or
use. Buyer may not make any changes in the specifications for the Goods unless Seller approves of such changes
in writing, in which event Seller may impose additional charges to implement such changes.
Limited Warranty. Seller warrants to the original end-user that the Goods manufactured or provided by Seller
under this Agreement shall be free of defects in material or workmanship for a period of twelve (12) months from
the date of purchase, provided that the Goods are installed, used, and maintained in accordance with any
instruction manual or technical guidelines provided by the Seller or supplied with the Goods, if applicable. The
original end-user must give written notice to Seller of any suspected defect in the Goods prior to the expiration of
the warranty period. The original end-user must also obtain a RGA from Seller prior to returning any Goods to
Seller for warranty service under this paragraph. Seller will not accept any responsibility for Goods returned without
a RGA. The original end-user shall be responsible for all costs and expenses associated with returning the Goods
to Seller for warranty service. In the event of a defect, Seller, at its sole option, shall repair or replace the defective
Goods or refund to the original end-user the purchase price for such defective Goods. Goods are not eligible for
replacement or return after a period of 30 days from date of receipt. The foregoing warranty is Seller’s sole
obligation, and the original end-user’s exclusive remedy, with regard to any defective Goods. This limited warranty
does not apply to: (a) die sets, tooling, and saw blades; (b) periodic or routine maintenance and setup, (c) repair or
replacement of the Goods due to normal wear and tear, (d) defects or damage to the Goods resulting from misuse,
abuse, neglect, or accidents, (f) defects or damage to the Goods resulting from improper or unauthorized
alterations, modifications, or changes; and (f) any Goods that has not been installed and/or maintained in
accordance with the instruction manual or technical guidelines provided by Seller.
EXCLUSION OF OTHER WARRANTIES. THE FOREGOING LIMITED WARRANTY IS IN LIEU OF ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED. ANY AND ALL OTHER EXPRESS, STATUTORY OR IMPLIED
WARRANTIES, INCLUDING BUT NOT LIMITED TO, ANY WARRANTY OF MERCHANTABILITY OR FITNESS
FOR ANY PARTICULAR PURPOSE ARE EXPRESSLY DISCLAIMED. NO WARRANTY IS MADE WHICH
EXTENDS BEYOND THAT WHICH IS EXPRESSLY CONTAINED HEREIN.
Limitation of Liability. IN NO EVENT SHALL SELLER BE LIABLE TO BUYER OR ANY OTHER PARTY FOR
ANY INCIDENTIAL, CONSEQUENTIAL OR SPECIAL DAMAGES (INCLUDING, WITHOUT LIMITATION, LOST
PROFITS OR DOWN TIME) ARISING FROM OR IN MANNER CONNECTED WITH THE GOODS, ANY BREACH
BY SELLER OR ITS AGENTS OF THIS AGREEMENT, OR ANY OTHER CAUSE WHATSOEVER, WHETHER
BASED ON CONTRACT, TORT OR ANY OTHER THEORY OF LIABILITY. BUYER’S REMEDY WITH RESPECT
TO ANY CLAIM ARISING UNDER THIS AGREEMENT IS STRICTLY LIMITED TO NO MORE THAN THE
AMOUNT PAID BY THE BUYER FOR THE GOODS.

2
2
Force Majuere. Seller shall not be responsible for any delay in the delivery of, or failure to deliver, Goods due to
causes beyond Seller’s reasonable control including, without limitation, acts of God, acts of war or
terrorism, enemy actions, hostilities, strikes, labor difficulties, embargoes, non-delivery or late delivery of materials,
parts and equipment or transportation delays not caused by the fault of Seller, delays caused by civil authorities,
governmental regulations or orders, fire, lightening, natural disasters or any other cause beyond Seller's reasonable
control. In the event of any such delay, performance will be postponed by such length of time as may be reasonably
necessary to compensate for the delay.
Installation. If Buyer purchases any Goods that require installation, Buyer shall, at its expense, make all
arrangements and connections necessary to install and operate the Goods. Buyer shall install the Goods in
accordance with any Seller instructions and shall indemnify Seller against any and all damages, demands, suits,
causes of action, claims and expenses (including actual attorneys’ fees and costs) arising directly or indirectly out
of Buyer’s failure to properly install the Goods.
Work By Others; Safety Devices. Unless agreed to in writing by Seller, Seller has no responsibility for labor or
work performed by Buyer or others, of any nature, relating to design, manufacture, fabrication, use, installation or
provision of Goods. Buyer is solely responsible for furnishing, and requiring its employees and customers to use all
safety devices, guards and safe operating procedures required by law and/or as set forth in manuals and instruction
sheets furnished by Seller. Buyer is responsible for consulting all operator’s manuals, ANSI or comparable safety
standards, OSHA regulations and other sources of safety standards and regulations applicable to the use and
operation of the Goods.
Remedies. Each of the rights and remedies of Seller under this Agreement is cumulative and in addition to any
other or further remedies provided under this Agreement or at law or equity.
Attorney’s Fees. In the event legal action is necessary to recover monies due from Buyer or to enforce any
provision of this Agreement, Buyer shall be liable to Seller for all costs and expenses associated therewith,
including Seller’s actual attorneys' fees and costs.
Governing Law/Venue. This Agreement shall be construed and governed under the laws of the State of
Wisconsin, without application of conflict of law principles. Each party agrees that all actions or proceedings arising
out of or in connection with this Agreement shall be commenced, tried, and litigated only in the state courts sitting in
Manitowoc County, Wisconsin or the U.S. Federal Court for the Eastern District of Wisconsin. Each party waives
any right it may have to assert the doctrine of “forum non conveniens” or to object to venue to the extent that any
proceeding is brought in accordance with this section. Each party consents to and waives any objection to the
exercise of personal jurisdiction over it by courts described in this section. Each party waives to the fullest extent
permitted by applicable law the right to a trial by jury.
Summary of Return Policy.
10 Day acceptance period from date of delivery. Damage claims and order discrepancies will not be accepted
after this time.
You must obtain a Baileigh issued RGA number PRIOR to returning any materials.
Returned materials must be received at Baileigh in new condition and in original packaging.
Altered items are not eligible for return.
Buyer is responsible for all shipping charges.
A 30% re-stocking fee applies to all returns.
Baileigh Industrial makes every effort to ensure that our posted specifications, images, pricing and product
availability are as correct and timely as possible. We apologize for any discrepancies that may occur. Baileigh
Industrial reserves the right to make any and all changes deemed necessary in the course of business including but
not limited to pricing, product specifications, quantities, and product availability.
For Customer Service & Technical Support:
Please contact one of our knowledgeable Sales and Service team members at:
[phone] or e-mail us at [e-mail]

3
3
INTRODUCTION
The quality and reliability of the components assembled on a Baileigh Industrial machine
guarantee near perfect functioning, free from problems, even under the most demanding
working conditions. However if a situation arises, refer to the manual first. If a solution cannot be
found, contact the distributor where you purchased our product. Make sure you have the serial
number and production year of the machine (stamped on the nameplate). For replacement parts
refer to the assembly numbers on the parts list drawings.
Our technical staff will do their best to help you get your machine back in working order.
In this manual you will find: (when applicable)
Safety procedures
Correct installation guidelines
Description of the functional parts of the machine
Capacity charts
Set-up and start-up instructions
Machine operation
Scheduled maintenance
Parts lists
GENERAL NOTES
After receiving your equipment remove the protective container. Do a complete visual
inspection, and if damage is noted, photograph it for insurance claims and contact your
carrier at once, requesting inspection. Also contact Baileigh Industrial and inform them of the
unexpected occurrence. Temporarily suspend installation.
Take necessary precautions while loading / unloading or moving the machine to avoid any
injuries.
Your machine is designed and manufactured to work smoothly and efficiently. Following proper
maintenance instructions will help ensure this. Try and use original spare parts, whenever
possible, and most importantly; DO NOT overload the machine or make any unauthorized
modifications.
Note: This symbol refers to useful information throughout the manual.

4
4
LEARN TO RECOGNIZE SAFETY INFORMATION
This is the safety alert symbol. When you see this symbol
on your machine or in this manual, BE ALERT TO THE
POTENTIAL FOR PERSONAL INJURY!
Follow recommended precautions and safe operating
practices.
UNDERSTAND SIGNAL WORDS
A signal word –DANGER, WARNING, or CAUTION is
used with the safety alert symbol. DANGER identifies a
hazard or unsafe practice that will result in severe Injury
or Death.
Safety signs with signal word DANGER or WARNING are
typically near specific hazards.
General precautions are listed on CAUTION safety signs.
CAUTION also calls attention to safety messages in this
manual.
IMPORTANT
PLEASE READ THIS OPERATORS MANUAL CAREFULLY
It contains important safety information, instructions, and necessary operating procedures.
The continual observance of these procedures will help increase your production and
extend the life of the equipment.
SAFETY INSTRUCTIONS

5
5
SAVE THESE INSTRUCTIONS.
Refer to them often and use them to instruct others.
PROTECT EYES
Wear safety glasses or suitable eye protection
when working on or around machinery.
DUST HAZARD
Wear appropriate dust mask. Dust created while using machinery can
cause cancer, birth defects, and long term respiratory damage. Be aware
of the dust hazards associated with all types of materials.
PROTECT AGAINST NOISE
Prolonged exposure to loud noise can cause impairment or loss of
hearing. Wear suitable hearing protective devices such as ear muffs or
earplugs to protect against objectionable or uncomfortable loud noises.
DUST PARTICLES AND IGNITION SOURCES
DO NOT operate the table saw in areas where explosion risks are high.
Such areas include locations near pilot lights, open flames, or other
ignition sources.
BEWARE OF PINCH POINTS
Keep hands and fingers clear of all potential
pinch points. These include sprockets and
chains along with belts and pulleys.

6
6
BLADE HAZARD
Keep hands and fingers away from the rotating knife blades. These
rotating knives can be extremely dangerous if you do not follow proper
safety procedures. NEVER place hands closer than 3” (76mm ) to the
rotating cutting knives.
ENTANGLEMENT HAZARD –ROTATING SHAFT
Contain long hair, DO NOT wear jewelry or loose fitting clothing, and
DO NOT wear gloves.
HIGH VOLTAGE
USE CAUTION IN HIGH VOLTAGE AREAS. DO NOT assume the
power to be off.
(FOLLOW PROPER LOCKOUT PROCEDURES)

7
7
SAFETY PRECAUTIONS
Wood working can be dangerous if safe and proper operating procedures are not followed. As
with all machinery, there are certain hazards involved with the operation of the product. Using
the machine with respect and caution will considerably lessen the possibility of personal injury.
However, if normal safety precautions are overlooked or ignored, personal injury to the operator
may result.
Safety equipment such as guards, push sticks, hold-downs, feather boards, goggles, dust
masks and hearing protection can reduce your potential for injury. But even the best guard won’t
make up for poor judgment, carelessness or inattention. Always use common sense and
exercise caution in the workshop. If a procedure feels dangerous, don’t try it.
REMEMBER: Your personal safety is your responsibility.
FOR YOUR OWN SAFETY, READ INSTRUCTION MANUAL BEFORE OPERATING THE1. MACHINE. Learn the machine’s application and limitations as well as the specific hazards.
Only trained and qualified personnel should operate this machine.2. Make sure guards are in place and in proper working order before operating3. machinery.
Keep work area clean. Cluttered areas invite injuries.4. DO NOT bypass or defeat any safety interlock systems.5. Know the location of the ON - OFF switch and the “E” - STOP button.6. Overloading machine. By overloading the machine you may cause injury from flying parts.7. DO NOT exceed the specified machine capacities.
Dress appropriate. DO NOT wear loose fitting clothing or jewelry as they can be caught in8. moving machine parts. Protective clothing and steel toe shoes are recommended when
using machinery. Wear a restrictive hair covering to contain long hair.
Use eye and ear protection. Always wear ISO approved impact safety goggles.9. Respirator Use. Always use a mask or respirator approved for wood dust when using this10.machine to reduce the risk of respiratory problems.
Do not overreach. Maintain proper footing and balance at all times. DO NOT reach over or11.across a running machine.
WARNING:FAILURE TO FOLLOW THESE RULES MAY RESULT IN
SERIOUS PERSONAL INJURY

8
8
SAFETY PRECAUTIONS (cont.)
Operator Position. If kickback occurs, the blade will eject the piece part into the path of the12.operator. NEVER stand in-line with the cutting path of the blade during operation.
Awkward Positions. Avoid awkward hand and body positions where a sudden slip could13.cause your hands or body to contact the spinning blade.
Stay alert. Watch what you are doing and use common sense. DO NOT operate any tool or14.machine when you are tired.
Keep visitors a safe distance from the work area.15.Keep children away. Children must never be allowed in the work area. DO NOT let them16.handle machines, tools, or extension cords.
DO NOT operate machine if under the influence of alcohol or drugs. Read warning17.labels on prescriptions. If there is any doubt, DO NOT operate the machine.
DO NOT touch live electrical components or parts.18.Inspect power and control cables periodically. Replace if damaged or bare wires are19.exposed. Bare wiring can kill!
Be Sure all equipment is properly installed and grounded according to national, state, and20.local codes. If machine is equipped with a three-prong plug, it should be plugged into a
three-hole electrical receptacle. If an adapter is used to accommodate a two-prong
receptacle, the adapter plug must be attached to a known ground.
Maintain machine in top condition. Keep clean for best and safest performance. Follow21.instructions for lubricating and changing accessories.
Reduce the risk of unintentional starting. Make sure switch is in “OFF” position before22.plugging in power cord.
Never leave machine running unattended. TURN POWER OFF. Don’t leave machine until 23.it comes to a complete stop.
Make sure machine is disconnected from power supply while motor is being mounted,24.connected or reconnected.
Using Correct Materials. Using materials other than natural wood fiber can result in serious25.personal injury and machine damage.
Warning: The dust generated by certain woods and wood products can be injurious to your26.health. Always operate machinery in well ventilated areas and provide for proper dust
removal. Use wood dust collection systems whenever possible.
Kickback. Become familiar with the term “Kickback” before operating this jointer/planer.27.Kickback occurs when the piece part is thrown off the table by the force of the cutter head.
Always use push blocks and wear safety glasses to reduce the likelihood for serious injury.

9
9
SAFETY PRECAUTIONS (cont.)
Kickback Zone. The path directly behind the end of the in-feed table is referred to as the28.“Kickback zone”. NEVER stand or allow others to stand in this area while the machine is
running. Position yourself to one side of the machine while the jointer/planer is running.
Using Quality Stock. Inspect the stock over carefully that you intend to joint or plane.29.NEVER joint or plane a board that has knots, staples, or nails in it. DO NOT joint or plane a
piece of stock if you have any doubts about its structural integrity.
Remove any adjusting tools. Before operating the machine, make sure any adjusting tools30.have been removed.
Support the piece part. Supporting the piece part adequately while cutting, is crucial to31.making safe cuts and avoiding possible operator injury.
Proper cutting. While cutting, always keep the piece part moving towards the out-feed table32.until it has completely passed over the cutterhead. NEVER back the piece part toward the in-
feed table.
Dull / Damaged Knives. Use only sharp, undamaged knives to avoid unnecessary kickback33.of the piece part. Dull and damaged knives will also affect cut quality.
Maximum Cutting Depth. The maximum cutting depth for one pass is 1/8” (3.2mm). Never34.set the machine to cut deeper than this in one pass.
Grain Direction. There is an increased chance of kickback when jointing or planing end35.grain or against the grain. This could also produce chatter and excessive chip out of the
material.
Observe work area conditions. DO NOT use machines or power tools in damp or wet36.locations. Do not expose to rain. Keep work area well lighted. DO NOT use electrically
powered tools in the presence of flammable gases or liquids.
Cutterhead Alignment. Keep the top edge of the out-feed table aligned with the cutterhead37.knife at top dead center (TDC). This will help to avoid kickback and possible operator
injuries.
Clearing Chips and Debris. Chips and dust build-up can present an injury hazard and38.affect the cut. Turn the machine OFF, allow the tooling to cool, and vacuum away the debris.
Feeding the Piece Part. ALWAYS feed the piece part against the rotation of the cutter.39.NEVER force materials through the shaper. Excessive force against the shaper cutter will
cause dangerous kickback conditions and can result in poor cuts.
Hand Positioning. NEVER place hands directly over or in front of the cutter. ALWAYS keep40.hand at least 6” (150mm) away from the cutter while operating.

10
10
SAFETY PRECAUTIONS (cont.)
Blade Height. Adjust the blade to the correct height41.above the piece part so it does not kickback toward
the operator causing injury.
Supporting Piece Part. Provide adequate support to42.the sides and rear of the table for material that is
extra wide and long.
Push Blocks. Push blocks or push sticks43.should be used in situations where it is
necessary to push the piece part against the
fence. Such as when machining narrow
stock, where there is a risk of your hands
and fingers contacting the rotating blade,
resulting in serious personal injury, or
when surface planing. DO NOT pass your
hands directly over the cutterhead without
using a push block.
EMERGENCY STOP
This machine has an emergency stop (E-Stop) button located on the front left edge of the
machine.
In the event of incorrect operation or dangerous conditions, the machine can be stopped
immediately by pressing the E-Stop Button. Twist the button to unlock and reset the
emergency stop button. Resetting the e-stop will not start the machine.
UNPACKING
This jointer/planer is shipped complete in one crate. Inspect the entire crate for the components
to be installed onto and complete the machine. Remove the machine from the shipping crate.
Check for damage and ensure all parts are intact. Any damage should be reported immediately
to your distributor and shipping agent. Before assembling, read the manual thoroughly,
familiarizing yourself with correct assembly and maintenance procedures and proper safety
precautions.

11
11
SPECIFICATIONS
Electrical Power
220V Single Phase
Motor
3hp (2.2kw) 220V, 1ph, 12A
Width
26" (661mm)
Height
46" (1169mm)
Length
65" (1651mm)
Weight
715lbs. (324.3kg)
Cutterhead Diameter
3" (76mm)
Cutterhead Width
12” (305mm)
RPM
5500
Knives
Helical Head (78 Carbide Cutters)
Jointer Working Table
15.75" x 59" (305 x 1524mm)
Jointer Maximum Table Adjustment
1/8" (3.1mm)
Jointer Cutting Angle
0°~45°
Jointer Maximum Cutting Width
12” (305mm)
Planer Working Table
11.8" x 26" (300 x 660mm)
Planer Feed Speed
23 fpm (7mpm)
Planer Maximum Working Width
11.75” (298.5mm)
Planer Maximum Working Height
8.5" (216mm)
Planer Minimum Working Height
1/8" (3.1mm)
Planer Maximum Cutting Depth
1/8" (3.1mm)
TECHNICAL SUPPORT
Our technical support department can be reached at 920.684.4990, and asking for the support
desk for purchased machines. Tech Support handles questions on machine setup, schematics,
warranty issues, and individual parts needs: (other than die sets and blades).
For specific application needs or future machine purchases contact the Sales Department at:
[email protected], Phone: [phone], or Fax: [phone].
Note: The photos illustrations using in this manual are representative only and
may not depict the actual color, labeling or accessories and may be intended to illustrate
technique only.
Note: The specifications and dimensions presented here are subject to change
without prior notice due to improvements of our products.

12
12
TRANSPORTING AND LIFTING
Follow these guidelines when lifting:
Always lift and carry the machine with straps on each end for balance.
Use straps capable of lifting 1.5 to 2 times the weight of the machine.
Take proper precautions for handling and lifting.
Check if the load is properly balanced by lifting it an inch or two.
Lift the machine, avoiding sudden accelerations or quick changes of direction.
Locate the machine where it is to be installed, and lower slowly until it touches the floor.
Use Lift Truck To Transport Machine
Place the wooden crate in the middle of the forks and keep at least 2” (50.8mm) distance
between the front of the forks and the wooden crate to avoid the case collapsing and secure
safe transport.
The lift truck must be able to lift at least 1.5 –2 times the machines gross weight.
Make sure the machine is balanced. While transporting, avoid rough or jerky motion, and
maintain at least 6 ft. (2m) safe clearance zone around the transport area.
Use Gantry Or Crane To Move Machine
Lift the machine from the base, NEVER use the jointer
tables as lifting point.
When lifting, verify that the lifting straps are long enough
to maintain a full spread toward the outer edges of the
machine as well as toward the lift hook to allow the straps
to lift as straight as possible.
DO NOT allow the lifting straps to pinch or bend lite
weight components.
Protect the lifting straps from sharp edges and corners
that may wear or cut on the lifting straps.
CAUTION:Lifting and carrying operations should be carried out by skilled
workers, such as a truck operator, crane operator, etc. If a crane is used to lift the
machine, attach the lifting chain carefully, making sure the machine is well balanced.
Choose a location that will keep the machine free from vibration and dust from other
machinery. Keep in mind that having a large clearance area around the machine is
important for safe and efficient working conditions.

13
13
INSTALLATION
IMPORTANT:
Consider the following when looking for a suitable location to place the machine:
Overall weight of the machine.
Weight of material being processed.
Sizes of material to be processed through the machine.
Space needed for auxiliary stands, work tables, or other machinery.
Clearance from walls and other obstacles.
Maintain an adequate working area around the machine for safety.
Have the work area well illuminated with proper lighting.
Keep the floor free of oil and make sure it is not slippery.
Operating/room temperature: +50° to +104°F (+10° to +40°C).
Remove scrap and waste materials regularly, and make sure the work area is free from
obstructing objects.
It is important to maintain free area around the machine,
which is required for the working place. If any long material is
machined, it is necessary to have a sufficient room in front of
the machine as well behind it in the places of material input
and output.
In order to maintain and operate the machine properly, it
must be set up at least 20” (508mm) away from the wall,
parallel to the work direction.
Before beginning assembly, take note of the following precautions and suggestions.
The machine is bolted to the pallet. Before attempting any of the assembly procedures
remove all of the loose parts and hardware from the inside of the machine and unbolt the
machine from the pallet.
FLOOR: This tool distributes a large amount of weight over a small area. Make certain that
the floor is capable of supporting both the weight of the machine and the operator. The floor
WARNING: Before operating; make sure it is positioned firmly on a solid
work surface. If it tips over on you, it could cause severe injury or death.

14
14
should also be a level surface. If the unit wobbles or rocks once in place, be sure to eliminate
by using shims.
WORKING CLEARANCES: Take into consideration the size of the material to be processed.
Make sure that you allow enough space for you to operate the machine freely.
OUTLET PLACEMENT: Outlets should be located
close enough to the machine so that the power cord
or extension cord is not in an area where it would
cause a tripping hazard. Be sure to observe all
electrical codes if installing new circuits and/or
outlets.
If necessary, the machine can be bolted down to the
floor with the transport brackets.
Remove the oxidation protective layer from all blank
machine parts. 1) Transport brackets
Cleaning
Your machine may be shipped with a rustproof waxy oil coating and grease on the exposed
unpainted metal surfaces. To remove this protective coating, use a degreaser or solvent
cleaner. For a more thorough cleaning, some parts will occasionally have to be removed. DO
NOT USE acetone or brake cleaner as they may damage painted surfaces.
Follow manufacturer’s label instructions when using any type of cleaning product. After cleaning,
wipe unpainted metal surfaces with a light coating of quality oil or grease for protection.
WARNING:DO NOT USE gasoline or other petroleum products to clean
the machine. They have low flash points and can explode or cause fire.
CAUTION:When using cleaning solvents work in a well-ventilated area.
Many cleaning solvents are toxic if inhaled.
GAS

15
15
GETTING TO KNOW YOUR MACHINE
T
S
Q
N
K
J
I
H
G
E
D
C
R
P
O
M
B
A
U
L
F
D
X
B
AB
Z
V
P
W
AA
Y
H
G
K

16
16
Item
Description
A
Emergency Stop Button
B
Planer Table Height Adjustment Hand Wheel
C
Jointer Outfeed Table Lock Lever
D
Planer Dust Collection Adaptor (stowed position)
E
Bridge Guard Rotation Lock Lever
F
Jointer Outfeed Table
G
Bridge Guard Tension Knob
H
Bridge Guard Arm
I
Bridge Guard Adjustment Knob
J
Bridge Guard
K
Fence
L
Jointer Infeed Table
M
Fence Position Lock Handles
N
Fence Rail
O
Jointer Table Lift Handle (2)
P
Jointer Infeed Table Height Adjustment Knob
Q
Jointer Dust Collection Adaptor
R
Jointer Infeed Table Lock Lever
S
On Push Button
T
Off Push Button
U
Power Cord
V
Motor and Belts Access Cover
W
Fence Adjustment Knobs
X
Jointer Outfeed Table Height Adjustment Knob
Y
Planer Table, Infeed Side
Z
Planer Table Height Adjustment Lock Knob
AA
Electrical Enclosure Cover
AB
Planer Feed Roller Engagement Lever

17
17
ASSEMBLY
Once this machine has been properly located, leveled, and safe working space has been
provided, the table may be assembled. This procedure will describe the assembly and
installation of all the components and safety equipment for this machine. Not all components will
be installed for every operation.
It is the operator’s responsibility to have the proper equipment installed for the workstation that
will be used. Likewise, it is the operator’s responsibility to remove those components that will
interfere with the workstation that is being operated.
Under NO circumstance should the knives, blades, or tools of a workstation be unguarded while
operating any other workstation.
Fence Installation
Note: Infeed table in the up position for
clarity. The table may be in either position for
assembly.
Mount the fence rail assembly (A) to the end of the1. infeed table so that the rail is even with the front
edge of the infeed table.
Mount the fence extension support (B) to the back2. edge of the infeed table.
Secure all fasteners.3. Place the fence arm onto the fence rail and secure4. with the position lock handles (C).
Slide the T-bar of the fence pivot assembly into5. the slot on the fence arm and secure in place with
the hand knobs (D).
WARNING:For your own safety, DO NOT connect the machine to the
power source until the machine is completely assembled and you read and
understand the entire instruction manual.
B
A
D
C
