BakeMax BMPM007
7 Quart Planetary Mixer
Operations Manual
Questions? OEM Parts, Contact Us:
Toll Free: 1-800-565-2253
Email: [e-mail]
www.BakeMax.com
Warranty Registration
www.BakeMax.com/Warranty-Registration

Warning & Safety
PLEASE READ AND FOLLOW INSTRUCTIONS BELOW TO PREVENT
INJURY OR DAMAGE TO THE PRODUCT
BakeMax® (a registered trademark of Titan Ventures International Inc or TVI) is
not responsible for any harm or injury caused due to any person’s improper or
negligent use of this equipment. The product shall only be operated by someone
over the age of 18, of sound mind, and not under the influence of any drugs or
alcohol, who has been trained in the correct operation of this machine, and is
wearing authorized, proper safety clothing. This machine is intended for
commercial use only. Any modification or miss use to the machine voids any
warranty and may cause harm to individuals using the machine or in the area of
the machine while in operation.
•
When using the machine, please ensure that you have read all of the instructions within
this manual.
•
Be aware of your surroundings when using this machine, ensure there are no children
or any other persons who are near the machine before operating.
•Do not put hand near moving parts.
•Remove all obstacles, which may interfere with machine functions.
•Keep work area clean and clear of clutter.
•Do not sit or stand on machine.
•
Do not wear loose clothing or jewellery when operating machine as it may get caught in
moving parts and cause injury.
•
Stop using the machine and have it checked by an authorized service personal if it is not
working properly.
•
Disconnect from power source before performing and maintenance or cleaning on the
machine.
•When the machine is not in use, please clean and store properly,
•Do not place any electrical parts or plug / cord in water or liquid.
•
If the supply cord is damaged it must be replaced by an authorizedservice agent in order
to avoid any electrical hazards.
•Keep power cord away from heat.
•Always ensure to follow local laws when operating your machine.

Cleaning
•This unit has been coated for shipping purposes, please clean before use.
•Do not use any liquid pressurized cleaning equipment on this machine.
•Disconnect power supply before cleaning.
•Only use food grade non abrasive cleaning agents.
•Follow any additional cleaning / maintenance listed below.
Features:
The BakeMax BMPM007 - 7Qt Planetary Mixer is designed to work as a countertop unit.With its space saving
design and digital speed control, it provides durability, long life and excellent mixing performance. It’s safe,
easy to use and capable of a broad range of food mixing applications.
•100% gear driven
•Professional countertop style
•1/3 HP motor offers enough power to mix stiffer doughs and larger batches
•30 minute digital timer.
•All metal and die-cast aluminum body
•Transmission is made of hardened alloy steel gears
•All shafts are mounted in ball bearings
•Automatic electronic 5 speed control (100 to 500 RPM.)
•Planetary mixing action ensures perfect results
•Simple hand lift for tool change and bowl removal
•Includes dough hook, flat beater and wire whip
•Safety guard is standard for model BMPM007 and provides with automatic shut-off when guard is
opened at any speed.
•1 year limited warranty
Technical Specifications:
•Exterior Dimensions (WDH): 18.1" x 13.4" x 20.5"
•110v / 6amps / 650watts / 60Hz / 1Ph
•Nema 5-15P Plug
•Net Weight 45 lb
Shipping Specifications:
•Packaged Dimensions (WDH): 20” x 15” x 24”
•Packaged Weight 50 lb
** Due to continuous product improvement, specifications are subject to change without notice.

3-1 CONTROLS
All models are furnished with a digital Timer and electronic 5-speed
Timer:
Digital set by 1-30 minutes or non-timer service.
Speed:
Speed 1 - For slow beating, mashing and kneading yeast dough. Speed 2 - For mixing
cookie and cake batters. Speed 3 - For beating, creaming and medium fast whipping.
Speed 4 - For whipping heavy cream, egg whites and boiled frostings. Speed 5 - For
whipping small amounts of heavy cream and egg whites.
3-2 HOW TO INSTALL AN AGITATOR
To install an agitator, the bowl must be installed and fully lowered. Place the agitator in
the bowl, push it up on the agitator shaft, and turn it clockwise to seat the shaft pin in
the slot of the agitator shank.
3-4 HOW TO INSTALL A BOWL
The bowl must be installed before the agitator. To install the bowl, fully lower the bowl
support. Position the bowl so the alignment bracket on the back of the bowl is in the
bowl retainer and the locating pins on the front of the bowl support fit in the holes on the
sides of the bowl.

5. MAINTENANCE
NOTE: ALL MAINTENANCE WORK SHOULD BE DONE ONLY AFTER UNIT HAS
BEEN DISCONNECTED FROM ELECTRICAL POWER AND GROUNDING.
Never use a metal or stiff brush to clean the mixer. Never clean the mixer with a
water hose or any fluid pressure.
•The mixer should be thoroughly cleaned after using.
•Bowls and agitators should be removed from the mixer and cleaned.
•The transmission case and planetary gears are filled special grease that will last
for several years. When grease is needed for replacement, it should be ordered
from our authorized service representative.
•If the attachment strikes bowl, stop the mixer. The original seller will help you to
make adjustment.
If your mixer should malfunction or fail to operate, check the following.
•Is the mixer plugged in?
•Is the fuse in the circuit to the mixer in working order? If you have a circuit
breaker box, be sure the circuit is closed.
•If the problem is not due to one of the above items, please contact your dealer.

BMPM007 PARTS BREAKDOWN
IMAGE: BM007-01

Part #
PARTS NAME
QTY
1
Top Cover
1
2
Retainer
3
Mixer Head and Column
1
4
Center Shaft
5
Gear-Center Shaft
1
6
Spacer
1
7
Worm Gear Shaft
8
Worm Gear
9
Gear-Worm Gear Shaft
10
Motor (100-120V)
1
11
Control Board
1
12
IC Board (100-120V)
1
13
Planetary Gear
1
14
Internal Gear
15
tiead Ring [for BMPM007 model only)
1
16
Planetary Head
1
17
Planetary Shaft
1
18
Tapered Pin
1
19
Rear Plate of Column
1
20
Apron
1
21
Base
1
22
Bowl Support
23
Bowl Pin
24
Lifting Bar
25
Fixed Angle Plate
1
26
Lifting Bracket
1
27
Lifting Handle
1
28
Compression Spring
29
7 Liter Bowl
1
30
Flat Beater
1
31
Spiral Hook
1
32
Wire Whip
1
33
Cover Plug
2
34
Cover Fixed Tube
1
35
Ball Bearing
1
36
Ball Bearing
1
37
Ball Bearing
2
38
Ball Bearing
1
39
Ball Bearing
1
40
O-Ring
1
41
Oil Seal
1
42
Oil Seal
1
43
Oil Seal
1
44
Spring Pin
2
45
Spring Pin
2
46
C-Ring
1
47
C-Ring
48
C-Ring
1
49
C-Ring
1
50
C-Ring

51
Key
3
52
Key
1
53
Key
1
54
Plastic Plug 3/4"
2
55
Plastic Plug 53mm
1
56
Cable Connector
1
57
Cable
1
58
Plastic Tube
1
59
Bolt
4
60
Bolt
5
61
Screw
3
62
Screw
3
63
Screw
2
64
Screw
1
65
Mach. Screw
1
66
Mach. Screw
4
67
Mach. Screw
6
68
Mach. Screw
2
69
Mach. Screw
1
70
Screw
2
71
Nut
1
72
Nut
4
73
Nut
1
74
Flat Washer
1
75
Flat Washer
2
76
Flat Washer
2
77
Spring Washer
2
78
Spring Washer
6
79
Sticker of Control Panel
1
80
Back Cover (for CE model only)
81
Front Cover (for CE model only)
1
82
Seat of Micro Switch (for CE model only)
83
Fixed Ring
84
Mach. Screw
4
85
Screw
2
86
Mach. Screw
4
87
Micro Switch
2
91
Carbon of Motor
2
92
Carbon Cover
2
93
Limit Switch Seat
1
