STANDARD FEATURES
CERTIFICATIONS
BAKERS PRIDE EP-EB Series Electric Deck Ovens are designed for
high volume pizza, baking, roasting and all-purpose operations.
Interior decks are 28” (711mm) deep and 28” (711mm) wide.
Overall dimensions are 33 1/4” (845mm) deep by 42” (1067mm)
wide.
Each oven has two decks with separate tilt-up doors.
Ovens may be stacked two
high.
Oven exteriors are all heavy-gauge, type 430 stainless steel and are
fully insulated for cooler outer temperatures and consistent interior
temperatures. Over interiors are manufactured of high-heat resistant
18-gauge aluminized steel.
Each deck features independent, operator controlled top & bottom
heat for perfectly balanced results and a 200°-750° F (100°-400° C)
thermostat. 5 1/4" (133mm) interior deck height with 3/4" (19mm)
thick Cordierite hearth decks (steel decks optional).
EP (pizza) models feature a 15 minute timer. The EB (bake)models
feature a 60-minute electric timer. Both models have continuous-
ring, audible timer alarms and manual shut-offs.
2828 Models are 9KW and feature 7 electric elements (4 top and 3
bottom). Voltages are available in 208v, 220-240v 1Ø or 3Ø as well
as 230-400v in 3Ø with neutral.
1 Year limited part and labor warranty standard.
Each door has
glass windows and are spring balanced.
1Ø or
q
q
q
q
q
q
q
q
q
q
q
2828 Models @ 9,500 watts in 208v, 220-240v, or 230-400v
200°-750° F (100°-400°C) thermostat
Infinite Top & Bottom heat controls per deck
Electric, 15 or 60-minute timer with continuous ring alarm
and manual shut-off. Timers not provided on export models
Interior oven lights
2 each 5 1/4" (133mm) Interior deck heights with Cordierite
hearth decks
All stainless steel exteriors
Aluminized steel interiors
Spring balanced, doors with windows
Fully insulated
1 Year limited part and labor warranty
OPTIONS & ACCESSORIES
q
q
q
q
q
Steel decks in lieu of Cordierite
Solid Doors
Set of 4" legs for countertop use
Set of 30" legs, with or without casters
Set of 16" legs, with or without casters for double stacked
ovens
BAKERS
PRIDE
Continuous product improvement is a policy of Bakers Pride Oven Company.
Therefore, specifications and design are subject to change without notification
BAKERS PRIDE OVEN COMPANY, INC.
30 Pine Street, New Rochelle, NY 10801
914/576-0200 • 1-800-431-2745 • fax [phone]
www.bakerspride.com
Job ____________ Item # ___________
ELECTRIC DECK OVENS
2828 SERIES
ELECTRIC DECK OVENS
BAKERS
PRIDE
SPECIFICATIONS
NEW
PIZZA BAKE
qEP-2-2828 Single
qEP-4-2828 Double
qEB-2-2828 Single
qEB-4-2828 Double
Model EP-2-2828
CANADIAN GAS ASSOCIATION
C
L
A
S
S
I
F
I
E
D
EPH
®
ULCUS
LISTED
GAS-FIRED
UL
®

BAKERS
PRIDE
Continuous product improvement is a policy of Bakers Pride Oven Company.
Therefore, specifications and design are subject to change without notification
TSW:09/05
BAKERS PRIDE OVEN COMPANY, INC.
30 Pine Street, New Rochelle, NY 10801
914/576-0200 • 1-800-431-2745 • fax [phone]
www.bakerspride.com
SHIPPING INFORMATION
Model
EP-2828 600 43.543.5 46 37.5
273 1.23 1105 1168 952
Shipping Weight Crate SizeCarton Dimensions
Lbs. Cubic
Feet
Inches
Width Depth Height
Inches Inches
Kilos Cubic
Meter
mm mm mm
Shipping Class # 85
Each oven ships separately
ALL DIMENSIONS NOMINAL
MINIMUM CLEARANCES
Left Side
Right Side
Rear
1
1
1
1
1
1
25
25
25
25
25
25
* In European Community Countries and North America. In NON-COMBUSTABLE locations only.
** In European Community Countries only in COMBUSTIBLE locations. NOT for North America.
Inches Inches
Non-Combustible Construction* Combustible Construction**
mm mm
POWER SUPPLY
Model VOLTAGEWATTS PHASE AMPS
L1 L2 L3 N
Each oven requires separate electrical connection
Specify v 1Ø or 3Ø when ordering
SPECIFICATIONS
Model
EP-2-2828
EP-4-2828
EB-2-2828
EB-4-2828
28x28
28x28
28x28
28x28
711x711
711x711
711x711
711x711
2
4
2
4
Deck Size #
Decks
Overall Dimensions
Inches mm Inches
Width Depth HeightHeight
Inches InchesInches mm mm mmmm
33 1/4
33 1/4
33 1/4
33 1/4
29
58
29
58
51/4
51/4
51/4
51/4
42
42
42
42
845
845
845
845
737
1473
737
1473
133
133
133
133
1067
1067
1067
1067
* Height excludes legs
4" (102 mm) available for countertop application
16" legs (406mm) available for double stack ovens with or without casters
30" legs (762mm) available for single deck ovens with or without casters
All Models 9,500
9,500
9,500
9,500
9,500
9,500
208
220-240
208
220-240
230
230-400
3
3
1
1
1
3
19
15
24
21
40
14
19
15
24
21
–
16
19
15
–
–
–
15
–
–
–
–
–
–
TOP VIEW
FRONT VIEW
SIDE VIEW
SIDE VIEW
28"
(711mm) 28"
(711mm)
5 1/4"
(133mm)
28"
(711mm)
42"
(1067mm)
33 1/4"
(845mm)
29"
(737mm)
2 1/2"
(64mm)
