BALDR B0389WST4H4-V3 User manual

USER MANUAL MODEL:B0389WST4H4-V3
DIGITAL WIRELESS WEATHER STATION
WITH 3 REMOTE SENSORS
English Deutsche Français Italiano Español
We thank you for your purchase of Baldr digital wireless weather
station with 3 remote sensors.It has been designed and constructed
using innovative components and techniques to enable the perfect
display. Please read the instructions carefully to become familiar with
the properties and functions before you use the unit.If your BALDR
product does not operate properly after trying the troubleshooting
steps, please contact the seller on your order page or shoot an email
to: [email protected].

English -------------------------------------------03 ~ 15
Deutsche -------------------------------------------16 ~ 29
Français -------------------------------------------30 ~ 42
Italiano -------------------------------------------43 ~ 55
Español -------------------------------------------56 ~ 68
For the start-up of this device:
Main unit by AC adapter (included) or 3 x AAA batteries (not included)
Sensor by 6 x AA batteries (not included)
CONTENTS
English
Für den Start dieses Geräts:
Hauptgerät über Netzteil (im Lieferumfang enthalten) oder
3 AAA-Batterien (nicht im Lieferumfang enthalten)
Sensor mit 6 x AA-Batterien (nicht im Lieferumfang enthalten)
Deutsche
Pour la mise en service de cet appareil :
Unité principale par adaptateur CA (inclus) ou 3 piles AAA (non incluses)
Capteur par 6 piles AA (non incluses)
Français
Per l'avvio di questo dispositivo:
Unità principale tramite adattatore AC (incluso) o 3 batterie AAA (non incluse)
Sensore con 6 batterie AA (non incluse)
Italiano
Para iniciar este dispositivo:
Adaptador AC para la unidad principal (Incluido) o 3 pilas x AAA (No incluidas)
Sensor de 6 pilas x AA (No incluidas)
Español

MAIN UNIT
3
OVERVIEW
EN
1. Temperature and humidity
of Channel 1/2/3
2. Max/min record of Channel
1/2/3
3. Indoor temperature and
humidity
4. Max/min record of indoor
temperature and humidity
11. “SET” button
Switch C/F or enter into
time setting
12.“▲/CH” button
Clear sensors data and
re-registration or increase
the data
10
1
8
6
9
5
4
3
2
7
11
13
12 14
15
18
16
17

4
OUTDOOR SENSOR
12
3
4
1. Signal light 2. Hanging hole
3. Battery compartment 4. Channel 1-2-3 switch
EN
Weather forecast for next
12-24 hours
5. Three comfort level
indication
6. Weather forecast
13.“▼” button
Decrease the data or switch
12H/24H display format
14. “MEM” button
Check or clear Max/min record
15. “ ” button
Check alarm time, turn on/off
alarm, enter into alarm setting
16. Angle adjustable stand bracket
17. Hanging hole
18. Battery compartment
7. Low battery indication
8. Calendar display
Default date: June 15, 2021
9. Current time
12/24 hour format selectable
10. “ ” touch button
Note: The top button is touch button.

5
FEATURES
PACKAGE CONTENT
GETTING START
MAIN UNIT INSTALLATION
Following contents are included in the package:
1 x Weather Station Main Unit
3 x Remote Sensors
1 x AC Adaptor
1 x User Manual
Powered by AC Adaptor:
Connect the power adaptor with DC hole on side of the main unit and
plug the adaptor to a powered outlet.
EN
• Simple and clear LCD display
• Weather forecast for next 12-24 hours
• Measures in/out humidity and temperature (℃/℉)
• Four groups of temperature & humidity data
• Max/min record of temperature & humidity
• Temperature tendency display in arrows
• Comfort level indication
• Indoor temperature range: -10℃~+50℃(+14 ℉~+122℉)
• Outdoor temperature range: -40℃~+60℃(-40℉~+140℉)
• In/outdoor humidity range: 1%-99%
• Calendar, alarm and snooze function
• Time display in 12/24H
• White backlight with dimmer
• Color DIY location stickers provided
BALDR recommends high quality alkaline or lithium batteries
for the best product performance. Heavy duty or recharge-
able batteries are not recommended.

6
Powered by batteries:
1. Remove the battery compartment cover.
2. Insert 3x AAA battery matching the polarity(+and-).
3. Replace the battery cover.
SENSOR INSTALLATION
SENSOR SETUP
1. Remove the battery compartment cover.
2. Insert 2 x AA batteries in each sensor matching the polarity（+and-).
3. Replace the battery cover.
EN
● Power the main unit prior to load the batteries of sensor.
● Switch the button of 3 sensors to CH1 , CH2 and CH3 ( the
channel of each sensor should be different from others).
Note: 1. Main unit will auto receive outdoor signal after power on,
the receiving status will last for max 3 minutes. The receiving
antenna signal will flash. If no signal received in 3 minutes, it
will stop receiving outdoor signal.
2. If the main unit is out of 3 minutes’ signal receiving window,
you need to press and hold the “▲/CH” button to enter signal
receiving again.
MAIN UNIT SETUP
RF Signal Receiving
When power on or reset, the LCD will full display for 3 seconds with
“BI” sound,then enter into RF Signal Receiving.the main unit will
start receiving 3 outdoor sensors’ signal for 3 minutes. After all 3
channels signal received within 3 minutes or receiving window
ends,please do the Manual Settings.

7
EN
Manual Settings
After signal received, Please follow bellow steps for manual setting.
1. Press “▼” button to switch the 12H/24H display format.
2. Press “ SET ” button to switch the temperature unit ℃/℉.
3. Press and hold “ SET ” button to enter into setting, press “ SET ”
button to skip setting steps or go to the next setting option.
*Tips: press and hold “▲/CH” or “ ▼ ” button will quickly
change the value by 8 steps.
4. Press “ SET ” button to select Year. Press “▲/CH” or “ ▼ ” button
to adjust the value.
5. Press “ SET ” button to select Month&Date display format. Press
the “▲/CH” or “▼” button to select M/D or D/M format.
(M: Month ,D: Date)
6. Press “ SET ” button to select the Month. Press “▲/CH” or “▼”
button to adjust the value.
7. Press “ SET ” button to select the Date. Press “▲/CH” or “▼”
button to adjust the value.
8. Press “ SET ” button to select Hours. Press “▲/CH” or “▼” button
to adjust the value.
9. Press “ SET ” button to select Minutes. Press “▲/CH” or “▼”
button to adjust the value.
10.Press “ SET ” button to select Beep ON/OFF .Default setting :ON.
Press the “▲/CH ” or “▼” button to select ON/OFF.
11.Press “ SET ” button to confirm and exit.
12.During setting, touch top button to save and exit setting.
13.During setting, if no operation for 20 seconds, it will automatically
save and exit setting.

8
EN
ALARM FUNCTION
Alarm Time Setting
Alarm ON/OFF Setting
SNOOZE FUNCTION
1. When in time display mode, press “ ” button to check alarm
time. Press “ ” button again to turn ON/OFF alarm by the
ON/OFF of symbol .
2. When in alarm time display mode, press “ ” button to turn on/off
the alarm by the ON/OFF of symbol .
3. If no operation for 5 seconds, it will automatically save and exit
setting.
1. Press and hold “ ” button to enter into alarm time setting.
2. Press “▲/CH ” or “ ▼ ” button to adjust data; press and hold
“▲/CH ” or “ ▼ ” button will quickly change the value by 8 steps.
3. The setting order is: Hour → Minute→ Exit.
4. Press “ ” button to skip setting steps or go to the next setting
option.
5. During setting, touch top button to save and exit setting.
6. During setting, if no operation for 20 seconds, it will automatically
save and exit setting.
7. The alarm is default ON after setting the alarm time. Alarm symbol
will display on screen.
1. When the alarm is ringing, press any other button except top
button to stop the alarm. And the alarm will restart next day.
2. Or when alarm is ringing, press the top button to activate snooze
function. The alarm will ring again in 5 minutes snooze interval.
And the “ ” symbol will be flashing on screen to indicate the
snooze mode. Press any other button except top button to exit the
snooze mode. And the alarm will restart next day.

9
OPERATION GUIDELINES
EN
3. When alarm rings, the related alarm mode’ symbol will flashing
and ascending “Bibi” alarm sound will last for 2 minutes if no
operation.
MAX AND MIN RECORD
TEMPERATURE
1. Press “MEM” button to check maximum temperature and humidity,
the value will display for 15 seconds.
2. Press “MEM” button second time to check the minimum tempera
ture and humidity, the value will display for 15 seconds.
3. Press “MEM” button third time will return to standard mode.
4. When in max record or min record display mode,press and hold the
“MEM” button to clear the max and min record.
5. Normally, the max and min record will update every 24 hours at 0:00.
1. After power on ,the indoor temperature will display automatically,
it will update reading each 30 seconds and start to receive
outdoor signal which lasts for max 3 minutes.
2. Indoor temperature display range:-10℃~ +50.0℃(14℉~ 122℉);
for temperature lower than -10℃,the reading will be :“LL.L”; for
temperature higher than +50℃,the reading will be :“HH.H”.
3. Outdoor temperature display range :-40℃~+60℃(-40℉~140℉);
for temperature lower than -40℃,the reading will be :“LL.L”; for
temperature higher than +60℃,the reading will be :“HH.H”.
4. Arrow indication for temperature changes:
will display when the reading increase by 1℃(1.8℉) within one
hour or compared with last reading.
will display when the reading decrease by 1℃(1.8℉) within one
hour or compared with last reading.

10
Display
Humidity DRY 1%- 39% COMFORT 40%-70%
(20℃-28℃)
WET 71%-99%
EN
HUMIDITY
COMFORT LEVEL INDICATOR
RF REGISTRATION
5. Accuracy: For temperature between 0℃~50℃(32℉~122℉),the
accuracy is ±1 ℃(1.8℉),if out of this range the accuracy will
be ±2℃(3.6℉); Temperature resolution is 0.1 ℃(0.1℉).
6. Press “SET” button to switch from Celsius degree to Fahrenheit
degree.
1. After power on ,the indoor humidity will display automatically, it will
update reading each 30 seconds and start to receive outdoor
signal which lasts for max 3 minutes.
2. Humidity display range: 1%-99%;for humidity lower than 1%,the
reading will be “1%”;for humidity higher than 99%,the reading will
be “99%”.
3. Accuracy: when the temperature is between 20℃~26℃
(68℉~ 78.8℉) and the humidity is between 40-80%,the accuracy
is ±5%,if out of this range the accuracy will be ±8%.
4. Arrow indication for humidity changes:
will display when the reading increase by 3% RH within one hour
or compared with last reading.
will display when the reading decrease by 3% RH within one hour
or compared with last reading.
5. Humidity resolution:1% .
● Press and hold the “▲/CH” button to clear all sensors data and
start receiving signal again.

11
BACKLIGHT FUNCTION
LOW BATTERY INDICATORS
EN
WEATHER FORECAST
● The weather forecast icon will show after power on. There are 5
kinds of weather modes: Sunny, Partly Cloudy, Cloudy, Rainy,
Snow. The weather icon displays are based on the hourly
calculation of indoor/outdoor temperature & humidity.The forecast
is for next 12 hours with 70%-75% accuracy .
Sunny Partly Cloudy Cloudy Rainy Snow
● When powered by batteries, press " " button to turn on the
backlight. The backlight will last 20 seconds.
● For continuous backlight, please connect the power adaptor.
Press " " button to switch backlight brightness among
100%,50%,3% and off.
● When Battery Indicator shows next to the Outdoor Temperature,
replace batteries in your Outdoor Sensors.
● When Battery Indicator shows next to your Indoor Temperature,
replace batteries in your Station.

12
TROUBLE SHOOTING
Problem
No outdoor sensor
reception
Inaccurate
temperature/
humidity
Flashing of the outdoor reading is generally an
indication of wireless interference.
1. Bring both the sensor and display indoors, side
by side and remove batteries from each.
2. Make sure the 1-2-3 switch on both units match.
3. Reload batteries in outdoor sensor.
4. Reload batteries in main unit.
5. Let both units sit within a couple feet of each
other for a few minutes to gain a strong connection
before taking sensor to outdoor area.
1.Reload the batteries of both outdoor sensor and
main unit. Please refer to the SENSOR SETUP
section.
2.Relocate the main unit and/or the outdoor sensor.
The units must be within 100m(328ft) of each other.
3.Make sure both units are placed at least 0.9 m
(3 ft) away from electronics that may interfere with
the wireless communication (such as TVs,
microwaves, computers, etc).
4.Use standard alkaline batteries. Do not use heavy
duty or rechargeable batteries. NOTE: It may take
a few minutes for main unit and sensor to
synchronize after batteries are reloaded.
Possible Solution
1.Place the whole set device at the same position
for half an hour after power on.
2.Place the main unit and sensor horizontally,
meanwhile ,Please place the sensor at a height
of 2-2.5 meters above the ground.
3.Make sure both the main unit and sensor are
placed out of direct sunlight and away from any
heat sources or vents.
EN
Outdoor reading is
flashing or showing
dashes

13
“HH.H/LL.L” display
in indoor and/or
outdoor temperature
If the temperature is higher than the detection range,
“HH.H” will display on screen for indication; if lower
than the detection range, “LL.L” will display on
screen for indication.
EN
If your BALDR product does not operate properly after trying the
troubleshooting steps, please contact the seller on your order page or shoot
an email to: [email protected].
PLACEMENT INSTRUCTION
BALDR sensors are sensitive to surrounding environmental
conditions. Proper placement of both the main unit and outdoor
sensor are critical to the accuracy and performance of this
product.
Main Unit Placement
Place main unit in a dry area free of dirt and dust. To help ensure an
accurate indoor temperature measurement, be sure to place the
Main unit away from heat sources or vents.
Outdoor Sensor Placement
Important Placement Guidelines
Sensor must be placed outside to observe outdoor conditions.
Sensor is water resistant for water splashes and is designed for
general outdoor use, however, to extend its life place the sensor in
an area protected from direct weather elements. The best location is
1.2 to 2.4 meters (4 to 8 feet) above the ground with permanent
shade and plenty of fresh air to circulate around the sensor.
● The distance between main unit and transmitter should be at least
1.5~2 meters (5~6.5 feet) away from any interfering sources such
as computer monitors or TV sets.
● To maximize wireless range, place units away from large metallic
items, thick walls, metal surfaces, or other objects that may limit
wireless communication.

14
PRECAUTIONS
WARRANTY
EN
● Please do not use other electrical products such as headphones
or speakers operating on the same signal frequency.
● Neighbors using electrical devices operating on the same signal
frequency can also cause interference.
● Do not clean any part of the product with benzene, thinner or other
solvent chemicals. When necessary, clean it with a soft cloth.
● Never immerse the product in water. This can cause electrical
shock and damage the product.
● Do not subject the product to extreme force, shock, or fluctuations
in temperature or humidity.
● Do not tamper With the internal components.
● Do not mix new and old batteries or batteries of different types.
● Do not mix alkaline, standard or rechargeable batteries with this
product.Remove the batteries if storing this product for a long
period of time.
● Do not dispose of this product as unsorted municipal waste.
Collection of such waste separately for special treatment is
necessary.
BALDR provides a 1-year limited warranty on this product against
manufacturing defects in materials and workmanship.
Warranty service can only be performed by our authorized service
center. The original dated bill of sale must be presented upon
request as proof of purchase to us, or our authorized service center.
The warranty covers all defects in material and workmanship with
the following specified exceptions:(1) damage caused by accident,
unreasonable use or neglect (including the lack or reasonable and
necessary maintenance); (2) damage occurring during shipment

15
EN
(claims must be presented to the carrier); (3) damage to, or deterio-
ration of any accessory or decorative surface;(4) damage resulting
from failure to follow instructions contained in your owner’s manual.
This warranty covers only actual defects within the product itself, and
does not cover the cost of installation or removal from a fixed
installation, normal set-up or adjustments, claims based on misrepre-
sentation by the seller or performance variations resulting from
installation-related circumstances.
To receive warranty service, the purchaser must contact with
BALDR nominated service center for the problem determination and
service procedure.
Thank you for your choice of BALDR products!

1. Temperatur und
Luftfeuchtigkeit von
Kanal 1/2/3
2. Max / min Aufnahme von
Kanal 1/2/3
3. Innentemperatur und
Luftfeuchtigkeit
4. Max / min Aufzeichnung
der Innentemperatur und
Luftfeuchtigkeit
11. “ SET ” Taste
Schalten Sie C / F um oder
geben Sie die Zeiteinstellung ein
12.“ ▲/CH ” Taste
Löschen Sie die Sensordaten
und registrieren Sie sie neu
oder erhöhen Sie die Daten
13.“ ▼ ” Taste
Verringern Sie die Daten oder
wechseln Sie das 12H / 24H-
Anzeigeformat
16
HAUPTEINHEIT
ÜBERBLICK
DE
10
1
8
6
9
5
4
3
2
7
11
13
12 14
15
18
16
17

5. Drei Komfortstufenanzeige
6. Wettervorhersage
Wettervorhersage für die
nächsten 12-24 Stunden
14. “ MEM ” Taste
Überprüfen oder löschen Sie
die Max / Min-Aufzeichnung
15. “ ” Taste
Überprüfen Sie die Alarmzeit,
schalten Sie den Alarm ein / aus
und geben Sie die
Alarmeinstellung ein
16. Winkel verstellbare
Ständerhalterung
17. Hängeloch
18. Batteriefach
7. Niedrige Batterieanzeige
8. Kalenderanzeige
Standarddatum: 15. Juni 2021
9. Aktuelle Uhrzeit
12/24 Stunden Format wählbar
10. “ ” Touch-Taste
1. Signalleuchte 2. Aufhängeloch
3. Batteriefach 4. Schalter Kanal 1-2-3
12
3
4
17
DE
Hinweis: Die obere Taste ist eine Touch-Taste.
SENSOR FÜR AUßEN

EIGENSCHAFTEN
18
DE
PAKETINHALT
ERSTE SCHRITTE
INSTALLATION DER HAUPTEINHEIT
Folgende Inhalte sind im Paket enthalten:
1 x Hauptgerät der Wetterstation
3 x Fern-Sensoren
1 x AC-Adapter
1 x Benutzerhandbuch
Stromversorgung über Netzteil:
Schließen Sie das Netzteil mit der Gleichstrombohrung an der Seite
des Hauptgeräts an und schließen Sie es an eine Steckdose an.
BALDR empfiehlt hochwertige Alkali- oder Lithiumbatterien
für die beste Produktleistung. Hochleistungsbatterien oder
wiederaufladbare Batterien werden nicht empfohlen.
• Einfache und übersichtliche LCD-Anzeige
• Wettervorhersage für die nächsten 12-24 Stunden
• Misst die Luftfeuchtigkeit und Temperatur ein / aus (℃/℉)
• Vier Gruppen von Temperatur- und Feuchtigkeitsdaten
• Max / Min-Aufzeichnung von Temperatur und Luftfeuchtigkeit
• Anzeige der Temperaturtendenz in Pfeilen
• Anzeige des Komfortniveaus
• Innentemperaturbereich: -10 ℃~ + 50 ℃(+14 ℉~ + 122 ℉)
• Außentemperaturbereich: -40 ℃~ + 60 ℃(-40 ℉~ + 140 ℉)
• Luftfeuchtigkeitsbereich im Innen- und Außenbereich: 1% -99%
• Kalender-, Alarm- und Schlummerfunktion
• Zeitanzeige in 12 / 24H
• Weiße Hintergrundbeleuchtung mit Dimmer
• Farbe DIY Standort Aufkleber zur Verfügung gestellt

19
DE
HAUPT UNIT SETUP
Angetrieben durch Batterien:
1. Entfernen Sie den Batteriefachdeckel.
2. Legen Sie eine 3x AAA-Batterie ein, die der Polarität (+ und-)
entspricht.
3. Bringen Sie die Batterieabdeckung wieder an.
SENSORINSTALLATION
SENSOR SETUP
1. Entfernen Sie den Batteriefachdeckel.
2. Legen Sie 2 x AA-Batterien in jeden Sensor ein, die der Polarität
（+ und-) entsprechen.
3. Bringen Sie die Batterieabdeckung wieder an.
● Schalten Sie das Hauptgerät ein, bevor Sie die Batterien des
Sensors laden.
● Schalten Sie die Taste von 3 Sensoren auf CH1, CH2 und CH3
(der Kanal jedes Sensors sollte sich von anderen unterscheiden).
Hinweis: 1. Das Hauptgerät empfängt nach dem Einschalten
automatisch ein Außensignal. Der Empfangsstatus dauert
maximal 3 Minuten. Das Empfangsantennensignal blinkt.
Wenn innerhalb von 3 Minuten kein Signal empfangen
wird, wird der Empfang des Außensignals beendet.
2. Wenn das Hauptgerät kein 3-Minuten-Signalempfangs
fenster mehr hat, müssen Sie die Taste “▲ / CH ”
gedrückt halten, um den Signalempfang erneut aufzurufen.
RF-Signalempfang
Beim Einschalten oder Zurücksetzen wird das LCD 3 Sekunden lang
mit dem BI-Ton voll angezeigt und dann in den RF-Signalempfang
aufgenommen. Das Hauptgerät empfängt 3 Minuten lang das Signal
von 3 Außensensoren. Nachdem alle 3-Kanal-Signale innerhalb von
3 Minuten empfangen wurden oder das Empfangsfenster beendet
ist, führen Sie bitte die manuellen Einstellungen durch.

20
DE
Manuelle Einstellungen
Befolgen Sie nach dem Empfang des Signals die folgenden Schritte
für die manuelle Einstellung.
1. Drücken Sie die Taste “▼”, um das 12H / 24H-Anzeigeformat
umzuschalten.
2. Drücken Sie die SET-Taste, um die Temperatureinheit ℃/℉
umzuschalten.
3. Halten Sie die SET-Taste gedrückt, um die Einstellungen
vorzunehmen, drücken Sie die SET-Taste, um die Einstellungss
chritte zu überspringen, oder fahren Sie mit der nächsten
Einstellungsoption fort.
* Tipps: Halten Sie die Taste “▲/CH” oder “▼” gedrückt, um
den Wert schnell um 8 Schritte zu ändern.
4. Drücken Sie die Taste “SET”, um Jahr auszuwählen. Drücken Sie
die Taste “▲/CH” oder “▼”, um den Wert anzupassen.
5. Drücken Sie die Taste “SET”, um das Anzeigeformat für Monat
und Datum auszuwählen. Drücken Sie die Taste “▲/CH” oder “▼”
zur Auswahl des M / D- oder D / M-Formats. (M: Monat, D: Datum)
6. Drücken Sie die Taste “SET”, um den Monat auszuwählen.
Drücken Sie die Taste “▲/CH” oder “▼”, um den Wert anzupassen.
7. Drücken Sie die Taste “SET”, um das Datum auszuwählen.
Drücken Sie die Taste “▲/CH” oder “▼”, um den Wert anzupassen.
8. Drücken Sie die Taste “SET”, um Stunden auszuwählen. Drücken
Sie die Taste “▲/CH” oder “▼”, um den Wert anzupassen.
9 .Drücken Sie die Taste “SET”, um Minuten auszuwählen. Drücken
Sie die Taste “▲/ CH” oder “▼”, um den Wert anzupassen.
10.Drücken Sie die SET-Taste, um Beep ON/OFF auszuwählen.
Standardeinstellung: ON. Drücken Sie die Taste “▲/CH” oder “▼”,
um EIN/AUS auszuwählen.
11.Drücken Sie zur Bestätigung und zum Beenden die Taste “SET”.
12.Berühren Sie während der Einstellung die obere Taste, um die
Einstellung zu speichern und zu beenden.
