BALDR B0360WST2H2PR-V2 User manual

COLOR RADIO-CONTROLLED
WEATHER STATION
USER MANUAL
MODEL:B0360WST2H2PR-V2
English Deutsche Français Italiano Español

For the start-up of this device you require:
Main unit by AC Adaptor(included)or 3xAAA batteries(not included)
Sensor by 2xAA batteries(not included)
English
Deutsche
Français
Italiano
Español
English ------------------------------------------03 ~ 24
Deutsche ------------------------------------------25 ~ 46
Français ------------------------------------------47 ~ 68
Italiano ------------------------------------------69 ~ 90
Español ------------------------------------------91 ~ 112
CONTENTS
Für die Inbetriebnahme dieses Gerätes benötigen Sie:
Hauptgerät mit Netzadapter (im Lieferumfang enthalten) oder
3xAAA-Batterien (nicht enthalten)
Sensor mit 2xAA-Batterien (nicht enthalten)
Pour la mise en service de cet appareil, vous avez besoin :
Unité principale avec adaptateur secteur (inclus) ou 3 piles AAA
(non incluses)
Capteur par 2xAA batteries (non incluses)
Per l'avvio di questo dispositivo: Unità principale con
adattatore CA (incluso) o 3 batterie AAA (non incluse) e un sensore
con 2 batterie AA (non incluse).
Para la puesta en marcha de este dispositivo necesitas: Unidad
principal con adaptador CA (incluido) o 3 pilas AAA (no
incluidas) y un sensor con 2 pilas AA (no incluidas).

USER MANUAL
MODEL:B0360WST2H2PR-V2
COLOR RADIO-CONTROLLED
WEATHER STATION
3
We hereby thank you for purchasing Baldr Color radio-controlled
Weather Station.We design and manufacture the item using
innovative components and techniques to enable the perfect display
of temperature and humidity by this device. It is also equipped with
weather forecast functions. Please read the instructions carefully to
become familiar with the properties and functions properly before
usage.
For the start-up of this device you require:
Main unit by AC Adaptor(included)or 3xAAA batteries(not includ-
ed)
Sensor by 2xAA batteries(not included)
ENEN

Product Overview
MAIN UNIT
4
24
2
3
4
56
8
7
9
10
12
11
13
14
15
16
18
19
17
2021
22
23
261 25
1. Sensor signal indication
2. Outdoor sensor channel
Switch channel from CH1--
CH2--CH3--Channel scan
3. Current outdoor temperature
Arrow icon indicates the
direction temperature is
trending
4. Max/min records for outdoor
temperature and humidity
14.Moonset time
15.Moonrise time
16.Current time
12/24 hour format selectable
17.RCC indicator
18.Alarm indicator
19.Snooze indicator
20.Frosting point icon
21.Current indoor humidity
EN

5
5. Current outdoor humidity
Arrow icon indicates the
direction humidity is trending.
6. Weather forecast
Weather forecast for next
12-24 hours
7. Barometric pressure
Barometer display in hPa/mb
8. Calendar display
9. Weekday display
Weekdays in 7 languages
10.Sunrise time
11.Moon phase
Moon phase will change
automatically with above
time setting
12.Sunset time
13.City abbreviation
Set your city (limited to 150
cities in Europe) to get the
correct sunrise and sunset
time
Max/min temperature &
humidity records will
update each 24 hour and
recorded from midnight
Arrow icon indicates the
direction humidity is trending
22.Max/min records for indoor
temperature and humidity
Max/min temperature &
humidity records will update
each 24 hour and recorded
from midnight
23.Current indoor temperature
Arrow icon indicates the
direction temperature is
trending.
24.Low battery indicator of
main unit
Battery power is lower than
3.6V or only connect AC
adaptor
25.Low battery indicator of
sensor
Battery power is lower than
2.5V
26.Outdoor temperature alert
Outdoor high/low temperature
alert with the symbol /
ENEN

6
5
2
3
4
1
1. Hanging Hole 2. Sensitive vents
3. Battery Compartment 4. Stand Bracket
5. DC Hole
Backlight/Snooze touch button
Press to switch backlight brightness among 100%, 50% ,10%,3%
and off
EN

7
1
2
3
4
5
6
1. “SET / ’’ button
Short press to receive RCC
signal
Long press to enter into time
setting
2. “ ’’button
Short press to check alarm
time, turn on/off alarm
Long press to enter into
alarm setting
’’ button
Short press to switch channel
Long press to enter into signal
receiving
’’ button
Short press to check Max/min
record
Long press to clear the
max/min
record
5. “CITY ’’ button
Short press to glance the city
Long press to set the city
6. “ALERT ’’ button
Short press to check the
temperature alert value
Long press to enter into
temperature alert value setting
Note:
The default year is 2020, if the weekday display is incorrect . Please
confirm year was set correctly. (for manual setting only)
ENEN

1. Signal light 2. Hanging hole
3. Battery compartment 4. Channel 1-2-3 switch
OUTDOOR SENSOR
12
3
4
8
FEATURES
1. Measures indoor and outdoor temperature(C/F) and humidity
2. Indoor temperature range:-10℃~50℃（14℉~122℉）
3. Outdoor temperature range:-40℃~60℃（-40℉~140℉）
4. Indoor and outdoor humidity range:1%-99%
5. Max/min record of temperature & humidity(in and out)
6. Weather forecast for next 12-24 hours with barometer
7. Temperature tendency display in arrows
8. Calendar function with moon phase
9. Time, alarm and snooze function
10. Time display in 12/24H
11. Weekdays in 7 languages: GER (German), ENG (English), FRE
(French),ITA(Italian), SPA(Spanish),DUT(Dutch),DRN(Denmark)
EN

9
PACKAGE CONTENT
GETTING STARTED
12. Up to 3 RF channels(channel scan or fixed to one channel)for
outdoor sensors (only one sensor included in the package)
13. Sunrise and sunset time of 150 European cities
14. Moon rise and moon set time of 150 European cities
15. Frosting point warning function
16. Outdoor high/low temperature alert
17. Indoor temperature, humidity and barometer data can be
calibrated manually
18. White backlight with dimmer
19. Key tone ON/OFF selectable
Following contents are included in the package：
1xDigital Weather Station
1xRemote Sensor
1xAc Adaptor
1xUser Manual
Connect the power adaptor with DC hole on side of the main unit
and plug the adaptor to a powered outlet.
BALDR recommends high quality alkaline or lithium batteries
for the best product performance. Heavy duty or rechargeable
batteries are not recommended.
MAIN UNIT INSTRALLATION
Powered by AC Adaptor:
ENEN

10
Powered by batteries:
SENSOR INSTRALLATION
SENSOR SETUP
1. Remove the battery compartment cover.
2. Insert 3x AAA battery matching the polarity(+and-)
3. Replace the battery cover
1. Remove the battery compartment cover
2. Insert 2xAA batteries matching the polarity（+and-)
3. Replace the battery cover
.
For example, you can set to Channel 1 for the sensor. But please
ensure the main unit are set to the same channel before
’’button on the main
unit to set the channel.The setting order is CH1--CH2--CH3--
Channel scan（from CH1 to CH2 to CH3,8 seconds intervals）,
you must select the same number choices for both the sensor and
the main unit in order to synchronize)
Auto synchronization: after power on both units, the receiving
status will last for max 3 minutes,the receiving antenna signal will
flash, if no signal received in 3 minutes, the antenna signal
willdisappear and stop receiving outdoor signal.
’ signal receiving window, you
’’ button to enter signal receiving
again.
EN
MAIN UNIT SETUP
When power on or reset, LCD will full display for 3 seconds with“BI” sound.

RF signal will not receive during the RCC reception,please exit the
RCC receiving first by pressing the “SET/ ”Button.
Pressure Unit
hPa/mb GER 0:00
(24H format) ON 2020.01.01
Weekday
Language Display Time Key tone Display Date
Temperature
Unit
℃ON 0hr AM6:30(OFF)
RCC
Function Time zone Alarm Time
11
RF SIGNAL RECEIVING
RCC RECEIVING
1. After RF signal receiving, it will start searching radio signal for 7
minutes with the antenna symbol “ ’’displaying on screen.
2. There are daily automatic DCF receiving at 1:00AM,2:00AM, 3:00
AM, 4:00AM, 5:00AM. It will first start receiving DCF time at 1:00
AM, 2:00AM, 3:00AM each day. If DCF time is not received till
3:00AM, it will start receiving again at 4:00AM and 5:00AM. If the
time is not successfully received at 5:00AM, there will be no
receiving the day, It will start searching for signal at 1:00AM the
next day.
The default value is :
After barometer setting, it will start receiving outdoor sensor’s signal
for 3 minutes. If all 3 channels signal received within 3 minutes or
receiving window ends, it will enter into DCF signal receiving window.
ENEN
3. On normal time mode, press “SET /RCC’’ button to enter DCF
signal receiving.

MANUAL SETTINGS
12
1. After signal received, if there is no need for other settings, you
can just finish reading here. If there is other setting requirements.
Please check the following steps. Or if there is no signal received,
you can follow bellow steps for manual setting.
2. Press and hold “SET /RCC’’ button to enter into setting, press
“SET /RCC’’ button to skip setting steps or go to the next setting
option, the setting datawill be flashing in 1Hz.
3. Press “SET /RCC’’ to select key tone ON/OFF. Press ’’ or
’’button to select.Default setting : key tone ON
4. Press “SET /RCC’’ to select Weekday Language. Press the
CH’’ or ’’ button to select languages: ENG、GER、ITA、
4. During DCF reception, press “SET /RCC’’ button to exit RCC
receiving.
5. The time will be converted to the current time of corresponding
time zone after receiving the RCC .(Except 0 time zone)
Remark: It will exit RCC receiving automatically when the alarm is
activated during DCF reception , you can repeat step 3 to enter
DCF signal receiving after turning off the alarm.
RCC symbol display:
a. When receiving signal , RCC icon“ ’’will be flashing by“1HZ”
b. When signal successfully received, LCD will display complete
RCC icon“ ’’and exit RCC receiving.
c. If no signal is received, the RCC icon will disappear.
EN
FRE、DUT、SPA、DAN、DUT、DRN optional . (English/German
/Italian/French/Dutch/Spanish/ Danish),Default setting :GER.

13
*T ’’ ’’ button will quickly
change the value by 8 steps.
5. Press “SET /RCC’ ’’ ’’
button to select OFF or ON. Default setting : RCC ON.
6. Press “SET /RCC’’ to select T ’’
MEM’’ button to select time zone from -12 H to + 12 H.Default
setting : 0 hr Remark:If RCC is set off , there is no Time zone option
7. Press “SET /RCC’’ to select Year ’’ ’’
button to adjust the value.
8. Press “SET /RCC’’ ’’ ’’
button to adjust the value.
button to adjust the value.
10. Press “SET /RCC’’ ’’ or
’’ button to select 12hr or 24hr.Default setting : 24hr
format.
11. Press “SET /RCC’’ ’’ ’’
button to adjust the value.
12. Press “SET /RCC’’ ’’
MEM’’ button to adjust the value.
13. Press “SET /RCC’’ ’’ or
’’ button to select ℃or ℉.Default setting : ℃.
14. Press “SET /RCC’’ to select weather ’’ ’’
button to select weather: Sunny, Sunny To Cloudy, Cloudy, Rainy
optional.
15. Press “SET /RCC’’ to confirm and exit.
16. During the setting, if no operation for 20 seconds, it will
automatically save and exit setting.
ENEN
Remark: There are 7 languages selectable for weekday display:
FRE、SPA、ENG、GER、ITA、DUT、DRN

14
Language German
GER
Sunday
English
ENG
French
FRE
Italian
ITA
Spanish
SPA
Dutch
DUT
Denmark
DRN
SON SUN DIM DOM DOM ZON ZON
Monday MON MON LUN LUN LUN MRR MRN
Tuesday DIE TUE MAR MAR MAR DIN TIR
Wednesday MIT WED MER MER MIE WOE ONS
Thursday DON THU JEU GIO JUE DON TOR
Friday FRE FRI VEN VEN VIE VRI FRE
Saturday SAM SAT SAT SAB SAB ZRT LOR
ALARM FUNCTION
SET ALARM TIME:
1. Press and hold “ ” button to enter into alarm time setting mode.
2. Press ’’ or ’’ button to adjust data; press and hold
’’ or ’’ button will quickly change the data by 8 steps.
3.
4. During setting, touch top button to save and exit setting
5. During setting, if no operation for 20 seconds, it will automatically
save and exit setting.
6. The alarm is default ON after setting the alarm time. Alarm symbol
will display on screen.
TURN ON/OFF ALARM:
1. When in time display mode, press “ ” button once to check alarm
time. Press “ ” button second time to turn on/off alarm by the
ON/OFF of symbol . If on operation for 20 seconds, it will
automatically return to current time display.
EN
2. When in alarm display mode, press the “ ” button to turn on/off
the alarm by the ON/OFF of symbol If on operation for 20
seconds, it will automatically return to current time display.

15
SNOOZE FUNCTION
1. When the alarm is ringing, press any other button except top
button to stop the alarm. And the alarm will restart next day.
2. OR when alarm is ringing, press “ ” button to activate snooze
function. And the alarm will repeat in 5 minutes. The “ ” symbol
will be flashing on screen to indicate the snooze mode. Press any
other button except top button to exit the snooze mode. And the
alarm will restart next day.
3. When alarm rings, the ascending “Bibi” alarm sound will last for 2
minutes if no operation.
PLACEMENT INSTRUCTION
BALDR sensors are sensitive to surrounding environmental
conditions. Proper placement of both the main unit and outdoor
sensor are critical to the accuracy and performance of this product.
Main Unit Placement
Place main unit in a dry area free of dirt and dust. To help ensure an
accurate indoor temperature measurement, be sure to place the
Main unit away from heat sources or vents.
Outdoor Sensor Placement
Sensor must be placed outside to observe outdoor conditions.
is water resistant for water splashes and is designed for general
Sensor
outdoor use, however, to extend its life place the sensor
protected from direct weather elements.
in an area
The best location is 4 to 8
plenty of fresh air to circulate around the sensor.
ENEN
Important placement guidelines
ast
5~6.5 feet (1.5~2 meters) away from any interfering sources such
as computer monitors or TV sets.
feet(1.2 to 2.4 meters) above the ground with permanent shade and

16
OPERATION GUIDELINE
To maximize wireless range, place units away from large metallic
items, thick walls, metal surfaces, or other objects that may limit
wireless communication
s
or speakers operating on the same signal frequency.
al
frequency can also cause interference.
TEMPERATURE&HUMIDITY
Outdoor temperature range:-40℃~60℃（-40℉~140℉),LL.L or
HH.H will display when out of range
Accuracy: For temperature between 10℃~30℃,the accuracy is±
1 ℃,if out of this range the accuracy will be±1.5℃; For humidity
between 40-70%RH,the accuracy is±5%RH,if out of this range,the
accuracy will be±8%RH.
Arrow indication for temperature changes:
will display when temperature changes less than 1℃within
onehour or compared with last reading.
will display when the reading increase by 1℃within one hour or
compared with last reading.
will display when the reading decrease by 1℃within one hour or
compared with last reading.
EN
● Place the main unit more than 1.2 meters away from the power
source for better usage. (including the power source of the product
itself or any other electrical appliances)

17
Arrow indication for humidity changes:
will display when humidity changes less than 3%RH within one
hour or compared with last reading.
will display when the reading increase by 3%RH within one hour
or compared with last reading.
will display when the reading decrease by 3%RH within one hour
or compared with last reading.
Remark: The reading will be more accurate standing still for half an
hour after power on.
TEMPERATURE ALERT FUNCTION
SET OUTDOOR TEMPERATURE ALERT
1. Press and hold “ALERTS” button to enter into outdoor temperature
alert value ; the setting data will be flashing in 1Hz.
2.
3. Press ’’ or ’’ button to adjust data; press and hold
’’ or ’’ button will quickly change the data by 8
steps.
4. If no operation for 20 seconds, it will automatically save and exit
setting.
TURN ON/OFF TEMPERATURE ALERT
1. The temperature alert function will be ON after setting the alert
values.
2. Press“ALERTS”button to check the high temperature alert value.
3. Press ’’ or ’’ button to turn on/off the high
temperature alert function with on/off of the symbol / .
4. Press “ALERTS” button again to check the low temperature alert
value.
ENEN

18
5. Press ’’ or ’’ button to turn on/off the low
temperature alert function with on/off of the symbol / .
6. Default setting : High temperature alert value 35℃;Low
temperature alert value 10℃.
7. The ascending “Bibi” alarm will ring for 5 seconds per minute with
the symbol flashing when the outdoor temperature reaches the
alert value and will stop ringing when out of alert range.
FROSTING POINT WARNING FUNCTION
1. When outdoor temperature reading is between 0℃~2.9℃,the icon
will be flashing to indicate the frosting point.
2. When outdoor temperature reading is lower than 0℃, the icon
will always display.
MAX AND MIN RECORD
1. Press ’’ to have maximum temperature and humidity
(within 24 hours), the value will display for 5 seconds.
2. Press ’’ second time to have the minimum temperature
and humidity(within 24 hours), the value will display for 5 seconds.
3. Press ’’ third time will return to standard mode.
4. Press and hold ’’ will clear the max and min record and
reactivate the memory.
5. Normally, the Max and Min record will update every 24 hours at
0:00.
There are 5
kinds of weather modes: Sunny, Sunny To Cloudy, Cloudy, Rainy,
Snow. The weather icon displays are based on the hourly
calculation of indoor/ outdoor temperature, humidity and barometer
data. The forecast is for next 12 hours with 70%-75% accuracy .
BAROMETER&WEATHER FORECAST
EN

19
Sunny Sunny to Cloudy Cloudy Rainy Snow
5 Weather Modes
SUNRISE/SUNSET AND MOONRISE/MOONSET TIMES
SET CITY NAME
1. In time display mode, press and hold “CITY” button to enter into
city setting mode.
2. Press ’’ or ’’ button to adjust letter from A to Z;
press and hold ’’ or ’’ button will quickly change
the letter by 8 steps.
3.
4. During setting, sunrise/sunset and moonrise/moonset timewill
display “--:--”
5. After setting saved and exit, sunrise/sunset and moonrise/moonset
time will display “--:--”,which means they are being calculated.
6. When the city is out of the range of 150 cities, the sunrise/sunset
and moonrise/moonset time will display "--:--", which means no
information.
MOON PHASE
1. There are 12 kinds of moon phases calculated by the lunar
calendar
2. Moon phase update at 17:00 daily.
Remark: The icon of full moon is whole black.
ENEN

20
City Name Abbr City Name Abbr City Name Abbr
1 Aachen AAC 51 Cherbourg CHE 101 Oslo OSL
2 Berlin BER 52 Lyon LYO 102 Stavanger STA
3 Dusseldorf DUS 53 Marseille MAR 103 Amsterdam AMS
4 Dresden DRE 54 Monaco MON 104 Eindhoven EIN
5 Erfurt ERF 55 Metz MET 105 Enschede ENS
6 Frankfurt FRA 56 Nantes NAN 106 Groningen GRO
7 Flensburg FLE 57 Nice NIC 107 The Hague HAG
8 Freiburg FRE 58 Orleans ORL 108 Rotterdam ROT
9 Hannover HAN 59 Paris PAR 109 Evora EVO
10 Bremen BRM 60 Perpignan PPA 110 Coimbra COI
11 Hamburg HAM 61 Lille LIL 111 Faro FAR
12 Rostock ROS 62 Rouen ROU 112 Leiria LEI
13 Stralsund STR 63 Strasbourg STB 113 Lisbon LIS
14 Cologne COL 64 Toulouse TOU 114 Porto POR
15 Kiel KIE 65 Helsinki HEL 115 Gdansk GDA
16 Kassel KAS 66 Aberdeen ABD 116 Krakow KRA
17 Leipzig LPZ 67 Belfast BEL 117 Poznan POZ
18 Munich MNI 68 Birmingham BIR 118 Szczecin SZC
19 Magdeburg MAG 69 Bristol BRI 119 Warsaw WAR
20 Nuremberg NUR 70 Edinburgh EDI 120 Russia St Petersburg PET
21 Regensburg REG 71 Glasgow GLA 121 Gothenburg GOT
22 Stuttgart STU 72 London LON 122 Stockholm STO
23 Saarbrucken SAA 73 Manchester MAN 123 Slovakia Bratislava BRV
24 Schwerin SCH 74 Plymouth PLY 124 Slovenia Ljubljana LJU
25 Aalborg ALB 75 Hungary Budapest BUD 125 Serbia Belgrade BGD
26 Aarhus ARH 76 Croatia Zagreb ZAG 126 Graz GRZ
27 Copenhagen COP 77 Ancona ANC 127 Innsbruck INN
28 Odense ODE 78 Bari BAI 128 Linz LIN
29 Alicante ALI 79 Bologna BOL 129 Salzburg SZB
30 Andorra AND 80 Cagliari CAG 130 Vienna VIE
German
Denmark
Spain
France
FFinland
U.K
Italy
Norway
Netherland
s
Portugal
Poland
Sweden
Austria
CHECK CITY NAME
1. In time display mode, press “CITY” button once to check the city
name. Press ’’ or ’’ button to select.
2. City name will display the first three letters , 150 cities of Europe
as shown in the table below.
EN
