BALDR B0359WST2H2PR User manual

USER MANUAL MODEL:B0359WST2H2PR
(EU VERSION)
WIRELESS COLOR WEATHER STATION
WITH TEMPERATURE ALERTS
English Deutsche FrançaisItaliano Español

www.baldr.com
[e-mail]
English -------------------------------------------04 ~ 24
Deutsche -------------------------------------------25~ 46
Français -------------------------------------------47 ~ 68
Italiano -------------------------------------------69 ~ 90
Español -------------------------------------------91 ~ 115
CONTENTS

USER MANUAL MODEL:B0359WST2H2PR
(EU VERSION)
WIRELESS COLOR WEATHER STATION
WITH TEMPERATURE ALERTS
For the start-up of this device:
Main unit by AC adaptor (included) and 1x CR2032 (included)
Sensor by 2 x AA batteries (not included)
We thank you for your purchase of Baldr wireless color
weather station with temperature alerts. It has been designed
and constructed using innovative components and techniques
to enable the perfect display. Please read the instructions
carefully to become familiar with the properties and functions
before you use the unit.
4
ENEN

1. Weather forecast
2. Calendar display
3. Weekdays in 7 languages
4. Dual alarm function
PRODUCT OVERVIEW
MAIN UNIT
18
19
20
21
22
23
17
25
24
26
1
10111516
12
6
8
7
9
13
14
2
5
3
4
Weather forecast for next 12-24 hours
5
ENENENEN

17. “ ” button
18. “ SET ” button
19.“▲/ CH ” button
22.“ ALERTS ” button
23.“ MEM ” button
21. “ ” button
24.Stand bracket
25.Hang ing hole
26.Battery compartment
5. Current time
6. Indoor temperature and humidity
7. Outdoor temperature and humidity
8. Max/min record of indoor temperature and humidity
9. Max/min record of outdoor temperature and humidity
10. Low battery indication
11. High/ low temperature warning
12. Indoor comfort level indication
13. Channel indication
14. Channel scan
15. Frost-point warning
16. Barometric pressure
12/24 hour format selectable
Barometer display in
mmHg, inHg or hPa mb
with max/min record
Enter into time setting
Switch C/F, Clear sensors
data and re-registration or
increase the data
Check or enter into
alarm setting
RCC function or decrease
the data
Check or clear Max/min record
Check or enter into
temperature alerts setting
20. “▼/RCC ” button
6
EN

1. The default year is 2020, if the weekday display is incorrect .
Please confirm year was set correctly. (for manual setting only)
2. The CR2032 cell battery is for memory function (included),
Please do not used as power supply. If you need to replace
the cell battery, please take out the part device as shown in
the figure below, load new battery matching the polarity
（+and-).
THIS PRODUCT CONTAINS A BUTTON-CELL BATTERY.
IF SWALLOWED, IT COULD CAUSE SEVERE INJURY OR
DEATH IN JUST 2 HOURS.SEEK MEDICAL ATTENTION
IMMEDIATELY IF INGESTED.
WARNING:
Notes:
Pick out Positive
pole
7
EN

1. Signal light 2. Hanging hole
3. Battery compartment 4. Channel 1-2-3 switch
OUTDOOR SENSOR
12
3
4
FEATURES
● DCF radio controlled time
● Up to 3 RF channels for outdoor sensors (only one sensor included)
● Comfort level indication
● Calendar, alarm and snooze function
● Time display in 12/24H
● Frost-point warning indication
● Temperature tendency display in arrows
● Weekdays in 7 languages: GER (German), ENG (English),
FRE(French),ITA(Italian),SPA(Spanish), DUT(Dutch),DAN(Danish)
● Indoor and outdoor high/ low temperature warning
8
EN

PACKAGE CONTENT
Following contents are included in the package:
1 x Weather Station Main Unit
1 x Remote Sensor
1 x AC Adaptor
1 x CR2032 Cell Battery
1 x User Manual
GETTING START
MAIN UNIT INSTALLATION
Remove the cell battery’s Insulating strip ,then plug the adaptor
to a powered outlet.
BALDR recommends high quality alkaline or lithium
batteries for the best product performance. Heavy
duty or rechargeable batteries are not recommended.
● Indoor temperature/humidity and barometric pressure value can
be calibrated manually
● Key tone on or off selectable
● Weather forecast for next 12-24 hours with barometer
● Measures indoor/outdoor humidity and temperature (°C/°F)
● Max/min record of indoor /outdoor temperature & humidity
● Indoor temperature range: -10°C~50°C (14 °F~122°F )
● Outdoor temperature range: -40°C~60°C(-40°F~140°F)
● In/outdoor humidity range: 1%-99%
● White backlight with dimmer
9
EN

Notes:
SENSOR INSTALLATION
1. Remove the battery compartment cover;
2. Insert 2 x AA batteries in each sensor matching the polarity
（+and-);
3. Replace the battery cover.
SENSOR SETUP
● Switch the Channel 1-2-3 of the senor to any channel you want.
For example, you can set to Channel 1 for the sensor. But please
ensure the main unit are set to the same channel before
synchronization. Special note: Press “▲/ CH” button on the main
unit to set the channel. The setting order is CH1--CH2--CH3--
Channel scan(from CH1 to CH2 to CH3, 10 seconds intervals),
you must select the same number choices for both the sensor
and the main unit in order to synchronize.
● Power the main unit prior to load the battery of sensor.
1. Main unit will auto receive outdoor signal after power on, the
receiving status will last for max 3 minutes. The receiving
antenna signal will flash. If no signal received in 3 minutes,
it will stop receiving outdoor signal.
2. If the main unit is out of 3 minutes’ signal receiving window,
you need to press and hold the “▲/ CH ” button to enter
signal receiving again.
10
EN

MAIN UNIT SETUP
RF Signal Receiving
DCF Signal Receiving
Pressure Unit
hPa mb GER ON D/M
0:00
(24H format)
Weekday
Language Display Time Date FormatBeep
Display Date
1st.Jan 2020 ℃ON
Sunny To Cloudy0
Temperature
Unit
Zone Weather
RCC Function
Alarm Time
(From Monday to Friday) 7:00
(From Saturday to Sunday) 8:00
Alarm OFF
The default value is :
After power on, It will start receiving outdoor sensors’ signal for 3
minutes. If all 3 channels signal received within 3 minutes or receiving
window ends, it will enter into DCF Signal Receiving window.
When power on or reset, LCD will full display for 3 seconds with “BI”
sound. Then display Indoor temperature and humidity, barometric
pressure.
1. After RF signal receiving, it will start searching radio signal for 7
minutes with the antenna symbol “ ” flashing on screen.
Meanwhile, the backlight brightness will automatically turn to 3%
brightness (default brightness: 100%).
11
EN

Manual Settings
* Tips: press and hold “▲/ CH ” or “ ▼/RCC ” button will
quickly change the value by 8 steps.
* RCC symbol display:
a. When receiving signal , RCC symbol “ ” will be flashing by“1HZ”.
b. When signal successfully received, LCD will display complete RCC
symbol “ ” and exit RCC receiving.
c. If no signal is received, the RCC symbol will disappear.
1. After signal received, if there is no need for other settings,
you can just finish reading here. If there is other setting
requirements. Please check the following steps. Or if there is
no signal received, you can follow bellow steps for Manual Setting.
2. Press and hold “ SET ” button to enter into setting, press “ SET ”
button to skip setting steps or go to the next setting option.
2. Once signal received, the main unit will display the received time/
month/date/weekday with symbol “ ” displaying on screen.
3. Daily RCC signal receiving: there are regular radio signal receiving
at 1:00AM,2:00AM, 3:00AM, 4:00AM, 5:00AM each day. It starts
receiving signal at 1:00AM everyday. For each day, once signal
received at any one receiving time, it will stop receiving signal
that day.
4. Manual receiving: press and hold “ ▼/RCC ” button to enter RCC
signal receiving.
5. During receiving, no response if press other buttons, you can press
and hold “ ▼/RCC ” button to exit RCC receiving.
12
EN

3. Press “ SET ” to select Weekday Language.
Default setting :GER. Press the “▲/ CH ” or “ ▼/RCC ” button to
select languages: ENG、GER、ITA、FRE、DUT、SPA、DAN
optional . (English/German/Italian/French/Dutch/Spanish/ Danish)
4. Press “ SET ” to select Beep ON/OFF.Default setting:ON. Press
the “▲/ CH ” or “ ▼/RCC ” button to select ON/OFF.
5. Press “ SET ” to select the Barometric Unit. Default setting:hPa mb.
Press “▲/ CH ” or “ ▼/RCC ” button to select unit: mmHg, inHg or
hPa mb optional.
6. Press “ SET ” to select Temperature Unit.Default setting:︒C.Press
the “▲/ CH ” or “ ▼/RCC ” button to select︒C/︒F.
7. Press “ SET ” to select the RCC. Default setting:ON. Press the
“▲/ CH ” or “ ▼/RCC ” button to select OFF or ON.
8. Press “ SET ” to select Time Zone. Default setting:0. Press “▲/ CH ”
or “ ▼/RCC ” button to select time zone from -12 H to + 12 H.
9. Press “ SET ” to select Year. Setting range: 2000-2099.
Press “▲/ CH ” or “ ▼/RCC ” button to adjust the value.
10. Press “ SET ” to select Month & Date display format.
Default setting : D/M. Press the “▲/ CH ” or “ ▼/RCC ” button to
select M/D or D/M format. (M: Month ,D: Date)
11. Press “ SET ” to select the Month. Press “▲/ CH ” or “ ▼/RCC ”
button to adjust the value.
12. Press “ SET ” to select the Date. Press “▲/ CH ” or “ ▼/RCC ”
button to adjust the value.
13. Press “ SET ” to select 12/24H Time Format. Default setting :24 H.
Press the “▲/ CH ” or “ ▼/RCC ” button to select 12H or 24H.
14. Press “ SET ” to select Hours. Press “▲/ CH ” or “ ▼/RCC ”
button to adjust the value.
15. Press “ SET ” to select Minutes.
Press “▲/ CH ” or “ ▼/RCC ” button to adjust the value.
13
EN

ALARM FUNCTION
Dual alarms for both weekdays and weekends: 1-5 (From
Monday to Friday) ,6-7 (From Saturday to Sunday).
1. When in time display mode, press “ ” button to check first alarm
time (1-5).
2. Press the “ ” button again to confirm and move to the next
alarm time. The checking order is :
(1-5)→ (6-7)→ (1-5)→ (6-7) →Exit.
3. Touch top button to exit and return to time display mode.
4. If no operation for 5 seconds, it will automatically exit .
Check Alarm Time
16. Press “ SET ” to select Weather. Default setting : Sunny To Cloudy.
Press “▲/ CH ” or “ ▼/RCC ” to select weather : Sunny, Sunny To
Cloudy, Cloudy, Rainy or Snow optional.
17. Press “ SET ” to confirm and exit.
18. During setting, touch top button to save and exit setting.
19. During setting, if no operation for 20 seconds, it will automatically
save and exit setting.
Alarm Time Setting
1. When in alarm time display mode ,press “ ” button to select
alarm mode you want (the selecting order is (1-5)→ (6-7)
→ (1-5)→ (6-7)),
then press and hold “ ” button to enter alarm time setting.
2. The setting order is: Hour →Minute→ON/OFF→Exit.
3. Press “▲/ CH ” or “ ▼/RCC ” button to adjust the value.
Hold to adjust quickly.
14
EN

OPERATION GUIDELINES
SNOOZE FUNCTION
MAX AND MIN RECORD
6. If no operation for 5 seconds, it will automatically exit .
4. To set other three alarm time, please repeat the above steps.
5. During setting, touch top button to save and exit setting.
6. During setting, if no operation for 20 seconds, it will automatically
save and exit setting.
7. Alarm symbol will display on screen after setting.
1. When the alarm is ringing, press any other button except top
button to stop the alarm. And the alarm will restart next day.
2. Or when alarm is ringing, press the “ ” button to activate
snooze function. The alarm will ring again in 5 minutes snooze
interval. And the “ ” symbol will be flashing on screen to indicate
the snooze mode. Press any other button except top button to exit
the snooze mode. And the alarm will restart next day.
3. When alarm rings, the related alarm mode’ symbol will flashing
and ascending “Bibi” alarm sound will last for 2 minutes if no
operation.
1. Press “MEM” button to check outdoor and indoor max/min
temperature and humidity.
2. The checking order is : Max Record→Min Record→Exit.
The value will display for 5 seconds.
3. When in Max Record or Min Record display mode.
Press and hold the “MEM” button to clear the max or min record.
4. Normally, the Max and Min record will update every 24 hours
at 0:00.
5. Touch top button any time to exit.
15
EN

TEMPERATURE
TEMPERATURE ALERTS
Check and Turn ON/OFF Alerts
1. After power on ,the indoor temperature will display automatically,
it will update reading each 30 seconds and start to receive outdoor
signal which lasts for max 3 minutes.
2. Indoor temperature display range:-10°C~ 50.0°C(14°F~ 122°F);
for temperature lower than -10°C,the reading will be :”LL.L”;
for temperature higher than +50°C,the reading will be :”HH.H”.
3. Outdoor temperature display range :-40°C~60°C(-40°F~140°F);
for temperature lower than -40°C,the reading will be :”LL.L”;
for temperature higher than +60°C,the reading will be :”HH.H”.
4. Arrow indication for temperature changes:
will display when temperature changes less than 1°C
within one hour or compared with last reading.
will display when the reading increase by 1°C within one hour
or compared with last reading.
will display when the reading decrease by 1°C within one hour
or compared with last reading.
5. Accuracy: For temperature between 0°C~50°C,the accuracy is ± 1°C,
if out of this range the accuracy will be ± 2°C; Temperature resolution
is 0.1°C(0.1°F).
6. Press “SET ” button to select the temperature unit °C/°F
(Refer to Manual Settings point 6).
1. When in time display mode, press “ALERTS ” button to check
temperature alerts .
2. Press and release the “ALERTS” button to check alerts by the order:
Outdoor High Temperature Alert→ Outdoor Low Temperature
Alert→ Indoor High Temperature Alert →Indoor Low
Temperature Alert→ Exit.
16
EN

● When in channel scan display mode, check or set the alerts ,
it will automatically exit channel scan display mode.
● When in current outdoor sensor channel, the alert symbol will
continue flashing on the screen until alert value is out of alert range.
● Four temperature alerts setting: indoor and outdoor 3 channels.
Notes:
Temperature Alerts Setting
Default setting : High Temperature Alert: 35°C(95°F),
Low Temperature Alert: 10°C(50°F).
3. When in temperature alert display mode, press “ALERTS ”
button to select the alert you want to turn on/off
(alerts checking order in the above step 2).
Press “▲/ CH ” or “ ▼/RCC ” button to select ON or OFF.
(Default setting : OFF)
4. Temperature alerts symbol will display on screen after alerts
turned on.
5. Press any button to stop the alert sound when alert rings.
6. Touch top button any time to save and/or exit.
7. If no operation for 5 seconds, it will automatically save and/or exit .
1. When in time display mode, press and hold “ALERTS ” button to
enter temperature alerts setting. The temperature alert value will
be flashing.
2. Alerts setting order: Outdoor High Temperature Alert→ Outdoor
Low Temperature Alert → Indoor High Temperature Alert →Indoor
Low Temperature Alert → Exit.
3. Press “▲/ CH ” or “ ▼/RCC ” button to adjust the value.
Hold to adjust quickly.
4. Press “ALERTS” button to confirm and move to next alert setting.
5. During setting, touch top button to save and exit setting.
6. During setting, if no operation for 20 seconds, it will automatically
save and exit setting.
17
EN

● The weather forecast icon will show after power on. There are 5
kinds of weather modes: Sunny, Sunny To Cloudy, Cloudy, Rainy,
Snow. The weather icon displays are based on the hourly
calculation of indoor/outdoor temperature & humidity and
barometer data. The forecast is for next 12 hours with 70%-75%
accuracy after 48 hours of data accumulation .
1. After power on ,the indoor humidity will display automatically, it
will update reading each 30 seconds and start to receive outdoor
signal which lasts for max 3 minutes.
2. Humidity display range: 1%-99%;for humidity lower than 1%,the
reading will be “1%”;for humidity higher than 99%,the reading will
be “99%”.
3. Accuracy: when the humidity is between 30-80%,the accuracy is
±5%,if out of this range the accuracy will be ±7%.
4. Arrow indication for humidity changes:
will display when humidity changes less than 5% RH within one
hour or compared with last reading.
will display when the reading increase by 5% RH within one hour
or compared with last reading.
will display when the reading decrease by 5% RH within one hour
or compared with last reading.
5. Humidity resolution:1% .
HUMIDITY
WEATHER FORECAST
Sunny
Sunny To Cloudy
Cloudy Rainy Snow
18
EN

● When current outdoor channel’s temperature is in the range of
0°C~ 2.9°C(32°F~37.22°F),the alert symbol “ ” will be flashing
until the temperature reading is out of alert range; the symbol will
keep displaying on screen if temperature is lower than 0°C.
Notes:
1. When in time display mode, press and hold “ALERTS” and
“MEM” button at the same time to enter Calibration mode.
2. Press and release the “SET” button to confirm and move to
the next setting:
Indoor Temperature →Indoor Humidity→ Barometer →Exit.
3. Press “▲/ CH ” or “ ▼/RCC ” button to adjust the value.
4. Barometer range: 850-1050hPa/mb (637-787mmHg,25.1-31 inHg ).
COMFORT LEVEL INDICATOR
FROST-POINT ALERT
CALIBRATION
Display
Humidity TOO WET
84-99%
WET
76-83%
COMFORT
40%-75%
DRY
26-39%
TOO DRY
1-25%
Baldr weather stations were calibrated precisely at our
manufacturing facility, but if you want the data of this
product to be consistent with the reading of the
equipment you are more trusted or more used to, you
can manually calibrate the indoor temperature,
humidity and barometer values.
Calibrated value’s reset method: unplug the main unit power supply
at first, remove the cell battery, press and hold the “ ” button, then
power on to reset.
!
19
EN

TROUBLE SHOOTING
Problem
Outdoor reading
is flashing or
showing dashes
Flashing of the outdoor reading is generally an
indication of wireless interference.
1. Bring the sensor and main unit indoors,
side by side and remove batteries from
each.
2. Make sure the CH 1-2-3 switch on both
units match.
3. Reload batteries in outdoor sensor.
4. Reload batteries in main unit.
5. Let both units sit within a couple feet of
each other for a few minutes to gain a
strong connection before taking sensor
to outdoor area.
Possible Solution
ADJUSTABLE BACKLIGHT
LOW BATTERY INDICATORS
● After powering on, touch “ ”button to adjust the brightness
of the backlight.
● Backlight brightness can be selected from 3%,10%,50%,100%
and off.
● About Outdoor Sensor: When battery indicator shows next to the
outdoor temperature, replace batteries in your outdoor sensor.
● About Cell Battery in Main Unit: The CR2032 cell battery is only
for memorizing the setting during sudden power outage.
When battery indicator shows next to your Indoor Temperature,
replace battery.
20
EN
