EGF-P100 Series

1 枚 / 台使用

GFP-B403-01-EN Rev.1.0 BALMUDA Europe GmbH: Immermannstr. 13, 40210 Dusseldorf, Germany

Warranty

IMPORTANT

Thank you for purchasing the Battery & Dock.

Please be sure to read this manual, especially “Safety Precautions” , before using the product.

Also be sure to take note of content marked with a on individual pages.

The warranty is included in this manual. Keep this manual somewhere safe after reading it.

No AC adapter is included with this product. Be sure to use the

AC adapter included with The GreenFan.

Use of a different AC adapter may cause a malfunction or breakdown.

Battery Pack (1),

EGF-P200 Series

Dock (1),

EGF-P300 Series

Instruction Manual/Warranty (1)

The number in the parentheses indicates the number of products.

EGF-P100 Series Package Contents

Intended for Use with The GreenFan in Europe Only

This product cannot be used outside of Europe. In addition, warranty and repair services will not be provided outside of Europe.

WARRANTY VOID IF USED OUTSIDE EUROPE

FOR USE IN EUROPE ONLY

Instruction Manual

With Warranty

EGF-P100 Series

Do not place the product next to a heat source such as a stove.

Doing so may cause overheating, rupture, or ignition.

Do not disassemble or modify the product.

Doing so may cause battery leakage, electric shock, overheating,

rupture, or ignition.

Do not place the product in fire or heat the product.

Doing so may cause overheating, rupture, or ignition.

The product is not fully charged at purchase.

Be sure to charge the product before using for the first time.

Note also that the product will discharge even when not in use.

If the product has not been used for an extended period, charge

the product before use.

Do not use the product with wet hands.

Do not allow the product to get wet from water, sea water, juice,

or any other liquid. Doing so may cause electric shock,

overheating, rupture, or ignition.

Do not subject the product to strong impacts or throw the product.

Doing so may cause overheating, rupture, or ignition.

Do not puncture with a nail, hit with a hammer, or step on the product.

Doing so may cause electric shock, overheating, rupture, or ignition.

Do not allow metal or other materials to come into contact with

the metal terminal.

Do not transport or store with metallic necklaces, hair pins, etc.

Doing so may cause overheating, rupture, or ignition.

WARNING

Do not solder directly onto the metal terminal.

The heat from soldering may cause the insulation to melt or

damage the gas discharge valve or the safeguards, resulting in

overheating, rupture, or ignition.

Do not charge the product near fire.

Doing so may have an effect on the safeguards, causing

overheating, rupture, or ignition.

Do not place the product inside a microwave or a high-pressure

container. Doing so may cause overheating, rupture, or ignition.

Do not use the Battery Pack if an abnormal situation such as

abnormal odor, overheating, discoloration, and deformation

occurs during use, charging, or storage. Doing so may cause

overheating, rupture, ignition, or electric shock.

When transporting the product, pack it firmly to prevent drops

and short-circuits with the metal terminal. Failure to do so may

cause overheating, rupture, or ignition.

Do not place the product on uneven or unstable surfaces such as

thick carpets. Doing so may cause poor contact between the

Dock and the main unit, resulting in overheating.

Avoid using the product in rooms with pets whenever possible.

Because incorrect use of the product may cause an accident or

fire, keep an eye on any pets in the room where the product is

being used.

Do not use, charge, or store in a location accessible by young

children.

Unsupervised handling of the product can be dangerous.

Stop charging after the specified charging time even if charging is

not complete.

Charging beyond the specified charging time may cause

overheating, rupture, or ignition.

Be sure to use, charge, and store the product in a location with

minimal humidity or dust. Failure to do so may cause overheating,

fire, or electric shock.

When recycling the Battery Pack, use plastic tape or some other

means to cover the metal terminals. Failure to do so may cause a

short-circuit resulting in fire or smoke.

WARNING

If the battery leaks, do not allow the leaked fluid to come into

contact with skin or the eyes. If the fluid comes into contact with

the skin, inflammation may occur. Rinse the area with a small

amount of soap and plenty of water. If the fluid enters the eye,

inflammation may occur. Immediately rinse the eye, and seek

immediate medical assistance. If the fluid is ingested,

inflammation may occur in the respiratory organs.

Seek immediate medical assistance.

Use the cell or battery only in the application for which it was

intended.

Use a dry cloth to regularly wipe off any dust or dirt that adheres

to the Dock. Do not use organic solvents or other cleaning agents.

Dust and moisture may cause insulation failure, resulting in

overheating or fire.

Do not remove the Battery Pack while the power is turned on.

Doing so may cause injury.

CAUTION

WARNING

Do not clean or inspect the product without first removing the

Battery Pack and disconnecting the AC adapter from the power

outlet. Doing so may cause injury.

Do not use the device in a location where temperatures may fall

below 10°C or exceed 35°C. Doing so may cause battery

leakage, overheating, rupture, or ignition.

Do not place any objects on top of the product, or place the

product in a location from where it can fall. Doing so may cause a

malfunction, damage to the product, or injury.

Do not place in direct sunlight or other high-temperature locations.

Doing so may cause deformation, discoloration, or leakage of the

battery.

Be sure to lock the Battery Pack in place after attachment.

Failure to do so may result in the Battery Pack being dropped,

causing injury.

Connect the Battery Pack and Dock to The GreenFan slowly.

Forceful connections may cause damage, overheating, fire, or

electric shock.

The product includes safeguards to prevent dangerous situations.

Do not use, charge, or store the product in a location where static

electricity may affect these safeguards. Doing so may cause

overheating, rupture, or ignition.

CAUTION

Do not use the product if the AC adapter cable is damaged or if

the plug cannot be firmly inserted into the terminal.

Doing so may cause fire or electric shock.

When not using the Battery Pack for an extended period, remove

it from the main unit, and store it in a cool, dry location.

Failure to do so may cause overheating, fire, or electric shock.

Insert the AC adapter plug securely into the Dock.

Failure to insert the plug securely may cause fire or electric shock.

When unplugging the AC adapter from the Dock, be sure to pull

on the plug only. Pulling on or bending the power cord may

cause a break in the cord or other damage.

This product is for use only with BALMUDA products. Please see

the individual instruction manual to determine compatibility with

this product.

Please use only under the specified charging conditions. Charging

under any other conditions (such as at temperatures outside the

specified range, voltages/current greater than the specified rating,

or with a modified charger) may cause overheating, rupture,

or ignition, resulting in injury or damage to the product.

Indicates actions that may cause death or serious injury.

Indicates possibility of minor injury or damage to buildings,

property, etc.

WARNING

CAUTION

Indicates actions that must not be

done. Indicates actions that must be done.

Read these safety precautions carefully before use to ensure correct use.

The precautions described in this manual must be followed to ensure safe use of this product

and prevent hazards to you and other people, as well as damage to the product.

The following classifications indicate hazards or damage that could result from improper use.

The following symbols indicate precautions that must be followed.

Safety Precautions

Important Precautions

Model: EGF-P100 Series Purchase date: (YYYY/MM/DD) *Customer

Name

Address

Phone number

Dealer name / address / phone number

*Dealer

Warranty period: 2 years from date of purchase Covers: Battery Pack, Dock

Product

Specifications

Battery Pack EGF-P200 Series EGF-P300 Series

Dock

Purpose

Weight

External dimensions

Number of charges

Operating temperature

Safeguards

Charge time

Output

Input

Battery capacity

Internal battery

Household use

Approx. 270 g

W164 × D17.5 × H86 (mm)

Approx. 500 charges (depending on usage)

10°C to 35°C

0 V battery charge prevention control, Charging temperature control

Overcharge/overcurrent/overdischarge prevention control,

Output short-circuit protection

Approx. 8 hours

12 VDC 1.3 A

12 VDC 3 A max.

4500 mAh 7.4 V (33.3 Wh)

Rechargeable lithium-ion polymer battery

Purpose

Weight

External dimensions

Output

Input

Household use

Approx. 40 g

φ80 × H23.5 (mm)

12 VDC 3 A max.

* Specifications and appearance are subject to change without notice for improvement purposes.

Do not dispose of the product along with regular

household garbage.

Doing so may cause fire or smoke.

1. BALMUDA Inc. (hereinafter “BALMUDA”) may use personal information for customer service and repairs, and may keep a record of

the inquiries.

2. BALMUDA will not disclose personal information to third parties, except in the following cases:

a. When repairs or confirmation of repairs are entrusted to third parties.

b. In cases pursuant to the provisions of laws and regulations.

3. For inquiries on personal information, please contact the BALMMUDA Europe Service Center.

Customer Service (for inquiries on usage, maintenance, repair)

BALMUDA Europe Service Center

9:00-16:30, weekdays & business days only

040-897 25 35 15

BALMUDA,

Online Inquiries

(* Call charge required)

* Please check the product model before inquiry.

Please search the net with the keyword “BALMUDA,”

or visit https://www.balmuda.com/de/support/.

Disposal of waste batteries and electrical and

electronic equipment

This symbol on the product, the battery or on the packaging indicates that the product and the battery shall not be treated as

household waste. On certain batteries this symbol might be used in combination with a chemical symbol. The chemical symbols for

mercury (Hg) or lead (Pb) are added if the battery contains more than 0.0005% mercury or 0.004% lead. By ensuring these products

and batteries are disposed of correctly, you will help prevent potentially negative consequences for the environment and human

health which could otherwise be caused by inappropriate waste handling. The recycling of the materials will help to conserve natural

resources. Hand the battery over to the applicable collection point for the recycling of waste batteries. For more detailed information

about recycling of this product or battery, please contact your local Civic Office, your household waste disposal service or the shop

where you purchased the product or battery.

Notice for lithium batteries : Please hand only discharged batteries over to the collection point. Due to danger of short circuit, please

patch the terminals of the battery with tape. Lithium batteries can be identified by the Li or CR marking on the battery.

Do not remove battery from its original packaging until required

for use.

Wipe the battery terminals with a clean dry cloth if they

become dirty.

Handling of Personal Information

For inquiries on repairs, usage, or maintenance, please call the BALMUDA Europe Service Center ( ), or contact your dealer.

1. Please receive the warranty card from your dealer with the purchase date and the dealer name filled in.

2. The warranty is valid for 2 years from the date of purchase. For repairs, please contact the BALMUDA Europe Service Center or

your dealer. The repair will be carried out according to the warranty.

3. Contact the BALMUDA Europe Service Center or your dealer for out-of-warranty repairs. You can request for a repair with charge,

if it enables the product to function properly.

4. Never attempt to repair or modify the product by yourself.

Warranty and After-Purchase Service

This warranty promises that free repairs will be performed as described in this warranty in the event of a malfunction occurring during normal use according to the Instruction Manual, labels

on the unit and other caution notes during the warranty period.

1) The following cases are not covered by the warranty even during the warranty period, and BALMUDA accepts no responsibility in such cases.

(a) Malfunction or damage caused by failure to follow the instructions in the Instruction Manual, the labels on the unit or any other written precautions (including any use overseas).

(b) Malfunction or damage resulting from misuse, modification or unauthorized repair. (c) Malfunction or damage resulting from moving the product (either within the home or to a new home),

dropping it or mailing it. (d) Malfunction or damage resulting from a fire, earthquake, wind or water damage, lightning or other natural phenomena, or from pollution, salt damage, abnormal

voltage or other external factors. (e) Malfunction or damage resulting from loading on a vehicle or boat or from using in extremely hot, cold, humid or dusty areas, etc. (f) Malfunction or

damage resulting from use outside a standard household (e.g. for commercial purposes.) (g) Failure to present this warranty. (h) If there is no proof of purchase of this product, such as a

receipt, and it is not possible to confirm the date of purchase, customer name and dealer name, or if this information has been altered. (i) Accessories and consumables (unless the damage

was caused by defects in the material or manufacturing). (j) Damage caused to the surface of the product (including scratches and dents). (k) Defects caused by age, natural wear or

improper storage such as in a hot or humid place. (l) If a false declaration was made about the cause of the malfunction.

2) Customers will be responsible for covering shipping fees when shipping a device to a BALMUDA Europe Service center or travel expenses when requesting repairs by a BALMUDA

representative even if within the warranty period.

3) A replacement product may be given instead of repairing, depending on the nature of the malfunction and other circumstances.

4) Recycled parts or replacement parts may be used in the repair. If parts are replaced during the repair, the old parts will be collected by BALMUDA and then processed or disposed of as

appropriate.

5) The warranty period from the time of the original purchase continues to apply after free repairs given according to this warranty (including replacement of the product).

6) BALMUDA will not provide compensation for any damages resulting from being unable to use the purchased product due to the malfunction.

7) Keep this warranty in a safe place and take care not to lose it, as it cannot be reissued.

8) This warranty is valid only within Europe. Effective only in Europe.

This warranty promises free repair for the period and conditions specified in this warranty.

It does not limit the legal rights of the customer against the party issuing (in charge of) the warranty or any other dealer.
