Balt 42551 Alekto-3 User manual

#42551 Alekto
Adjustable Tri-Level Computer Workstation
Assembly Instructions
Choose the
“Smart One®”

AFlat Head Screw 28 EA
A2 Long Wood Screw 4 EA
A3 Wood Screw 3 EA
BInteriorThreadedPost 20 EA
D3” Locking Caster (for Front) 2 EA
E3” Caster (for Back) 2 EA
F Allen Wrench 1 EA
GCaster Wrench 1 EA
HFlat Washer 4 EA
JBlack Plastic Spacer 2 EA
KHex Nut 4 EA
Part Drawing Description Qty Part Drawing Description Qty
Alekto-3 ComputerWorkstation
#42551
P1 Leg 2 EA
P2 Bottom Shelf 1 EA
P3 Stability Panel 1 EA
P4 Right Top Support 1 EA
P5 Left Top Support 1 EA
P6 Shelf Support 2 EA
P7 Top Panel 1 EA
P8 Shelf Panel 1 EA
P9 Cable Tray 1 EA
P10 Keyboard Shelf 1 EA
P11 CPU Sleeve 1 EA
P12 CPU Rod 2 EA
Hardware List
We recommend that you assemble
this unit on a table.
Tools required: Philips Head Screw Driver,
AdjustableCrescentWrench

#42551ALEKTO-3
AssemblyDiagram
To Assemble:
1. Identify and Separate all the
Parts and Hardware.
2. Attach Bottom Shelf (P2) and
Stability Panel (P3) to 2 Legs
(P1) using 8 Flat Head
Screws (A) and 8 Interior
Threaded Posts (B) as shown in
Illustration # 1.
(Do not tighten screws all the way)
3. Attach Casters to 2 Legs (P1).
2 Locking casters (D) in the
front and 2 Casters (E) in the
back. Tighten Casters using
Caster Wrench (G).
Illustration # 2
Illustration # 1
4. Attach 1 Right Top Support (P4) and Left
Top Support (P5) to 2 Legs (P1) at
desired location (see Options below) using
6 Flat Head screws (A) and 6 Interior
Threaded Posts (B) as shown in
illustration # 2.
5. Attach 2 Shelf Suport (P6) to 2 Legs (P1)
at desired location using 6 Flat Head
screws (A) and 6 Interior Threaded
Posts (B) as shown in illustration.
Option # 1
TopPanel
Option # 2
Shelf Panel
B
P2
P3
P1 P1
A
E
D
Shelf Panel Top Panel
B
A
P4
P1
P6
P6
P5
P1
Missing Parts or UPS Damaged Parts
ForYourConvenienceyoucan
EMAILusat
[email protected]
24HOURS 7 DAYSAWEEK

Illustration # 3
Illustration # 5
6. Attach Top Panel (P7) to the Top
Supports (P4 & P5), and Shelf
Panel (P8) to the Shelf Supports
(P6) using 8 Flat Head screws (A)
as shown in Illustration # 3.
7. Attach cable Tray (P9) to the Top
Panel (P7) using 3 Wood Screws
(A3).
8.
9. Attach 2 CPU Rods (P12) to
the Right Leg or Left Leg as
shown in illustration #5.
Secure each Rod with 2 Hex Nuts
(K), 2 Flat Washers (H), and
1 Black Plastic Spacer (J).
K
H
J
HK
P12
A3
P6
P8
P5
P7
A
P9
P4
Illustration # 4
ExtendSlides on Top Supports(P4 &
P5)and attachKeyboardShelf (P10)
usingfourScrews(A2)asShownin
Illustration#4.
P5
P4
P10
A2

Should you require assistance during
assembly, please call our
Customer Service Department
Monday - Friday 8 a.m. - 5 p.m. Central
Standard Time
Toll-Free Customer Service
1-800-749-2258
Illustration # 6
10. Slide CPU Sleeve P11over ends of CPU Rods (P12) as shown in illustration # 6.
11. Tighten all screws securely.
42551_06-21-10
TheBaltproductyouhavepurchasedisguaranteedagainstmaterialandworkmanshipdefects. This
guaranteeextends1yearfromdateofpurchase. Shouldthisproductfailtofunction satisfactorily under normal
usedueto defect orimperfection,thedefectivepart or productwillbereplaced. Damage caused by common
carriersduringshipmentisnotincludedinthis guarantee.
This guarantee sets forth all applicable guarantees and remedies. No other warranty, expressed
orimplied shallapply. Failuretofollowinstructionsfoundin ImportantInformationSectionofOwner
Sheetshall voidthe guarantee. Consequentialor incidentaldamages andor costsare notrefundable.
Important
Do not use unless all screws are
tight. At least every six months,
check all screws to be sure they
are tight.
If parts are missing, broken,
damaged, or worn, stop use of
the product until repairs are
made by your dealer using
factory authorized parts.
P11
P12
