1
BLT-82493 ERGO-E.EAZY
True Adjust® Pneumatic Computer Desk
Assembly Instructions

2
P1 Top Platform 1EA
P2 Upper Leg Insert 2EA
P3 Leg Receiver (Right) 1EA
P4 Leg Receiver (Left) 1 EA
P5 Height Adjust Bracket 1EA
P6 Leg Brace 1EA
P7 CPU Platform 1EA
P8 CPU Support Leg 1EA
P9 CPU Foot 2EA
P-10Cylinder Extension 1 EA
Part DrawingDescription Qty Part Drawing Description Qty
Computer Desk
ERGO-E.EAZY
P11 Cable Management Tray 1 EA
P12Keyboard Platform 1 EA
P13Metal Keyboard Track 1 EA
P14Keyboard Mechanism 1 EA
P15Metal Mouse Platform 1 EA
P16Metal Mouse Bar 1 EA
P17Wrist Rest1 EA
P18Printer Platform 1 EA
P19 Shelf Bracket 2 EA
P20 Wire CD/Book Support 2 EA
We recommend that you assemble
this unit on a table.
Tools required:
Philips Head Screw Driver
( Power Screw Driver Preferred )

3
A Screw 6MM x 13 19 EA
A1 Screw 6MM x 40 8 EA
A2 Screw 8MM x 40 4 EA
B Short Wood Screw 21 EA
B1 Long Wood Screw 2 EA
CHex Head Screw2 EA
D Flat Washer 2 EA
Hardware List
Part Drawing Description Qty
E Cylinder w/Plastic cover 1 EA
FRubber Bumber 2 EA
GDesk Glide2 EA
HLarge CPU Glide 2 EA
J Small CPU Glide 2 EA
KAllen Wrench1 EA
LAdjustment Knob2 EA
R EAD T HROUGH I NSTRUCTIONSFROMBEGINNING TO END BEFORE STARTING TO ASSEMBLEUNIT .
1.
2.
3.
4.
5.
Computer Desk
ERGO-E.EAZY
H
A1
D
J
A 1
P-8
P-7
P-9
Identify and Separate all Parts and Hardware.
Attach 2 each CPU Feet (P-9) to
the CPU Platform (P-7) using 2
each Screws ( A1) and 2 each
washers (D) as shown in
illustration #1.
Attach 1 each CPU Support Leg
(P-8) to the 2 each CPU Feet (P-9)
using 2 Screws ( A1) as shown in
illustration #1.
Insert 2 each large CPU Glides (H)
into the 2 each CPU Feet (P-9) as
shown in illustration #1.
Insert 2 each small CPU Glides (J)
into the bottom of 1 each CPU
Support Leg (P-8) as shown in
illustration #1.
Illustration # 1
CPU

4
Illustration # 2
Ergo E.Eazy
AssemblyDiagram
PlacetheTopPlatform(P-1)withtheinsertnutsfacingup. AttachCableManagementTray
(P-11)totheTopPlatform(P-1) using 3 (A)Screwsas shown inillustration #2.
AttachHeightAdjust Bracket (P-5)to theTop Platform (P-1) using 4(A)Screws as shownin
illustration #2. (Do not tighten screws all the way)
HeightAdjustmentLevermaybe mounted to theleftor theright side of theTop Platform(P-1).
[KeyboardPlatform is mounted onthe opposite side.]
Afterchoosing which side,secure HeightAdjust Lever(attachedtoP-5) to theTopPlatform
(P-1) using3(B) Screws asshown in illustration#2.
P11
P1
A
A
P5
Do not use unless all screws are tight. At least every six months, check all screws
to be sure they are tight. If parts are missing, broken, damaged, or worn, stop use
of the product until repairs are made by your dealer using factory authorized parts.
6.
7.
8.
Missing Parts or UPS Damaged Parts
ForYourConvenienceyoucan
EMAILusat
[email protected]
24HOURS 7 DAYS A WEEK
Height Adjust
Lever
B

5
Attach 2 each Upper Leg Inserts (P-2) to the Top Platform (P-1) using 4 ( A) Screws as shown in
illustration #3. (Do not tighten screws all the way)
Align the Keyboard Track (P-13) in desired location on the Top Platform (P-1) and attach it using
8Short Wood Screws (B) as shown in illustration # 3.
Attach Rubber Bumper (F) at the back end of the Keyboard Track (P-13) using1 Long Wood
Screw (B1) . Slide the Adjustment Mechanism (P-14) into the track as shown in illustration #3.
Align screw holes in Adjustment Mechanism (P-14) with screw holes in the Keyboard Platform
(P-12) and attach using 10 each Wood Screws (B) as shown in illustration # 3.
Mouse Platform(P-15) may be installed on the right or left side of Keyboard Mechanism (P-14).
Slide Mouse Bar (P-16) through Keyboard Mechanism (P-14) and attach to Mouse Platform
(P-15) using 2 each Hex Head Screws (C) as shown in illustration #3.
Attach Wrist Rest (P-17) to the Keyboard Platform (P-12) using 2Screws (A1) as illustrated.
P14
P13
P1
P2 A
B
P15
P17
P-16
P12
B
A 1
F
B1
Illustration # 3
9.
10.
11.
12.
13.
14.
Computer Desk
ERGO-E.EAZY
C

6
Slide the Adjustment Mechanism (P-14)
towards the back end of the Track (P-13)
and rotate 30 degrees as shown.Attach
the second Rubber Bumper (F) at
the front end of Track (P-13)
using1 each Long Wood
Screw (B1) as shown
in illustration # 4.
15.
To raise height of unit, loosen both adjustment knobs (K) and press handle on height
adjustment lever to the left and down. This locks the pneumatic cylinder in the acti-
vated position and it will begin lifting the unit. When the unit reaches the desired
height, move handle up and to the right. This locks the pneumatic cylinder in the closed
position. Secure unit at desired height by tightening both adjustment knobs (K).
To lower height of unit, loosen both adjustment knobs (K) and press handle on height
adjustment lever to the left and down. Press on center of Top Platform using body
weight. Top Platform will lower and you can release handle by moving handle up and
to the right at the desired height. Secure unit at desired height by tightening both
adjustment knobs (K).
Height Adjustment
Illustration # 4 ERGO-E.EAZY
P13
P14
F
B1
16.Attach 1 each Right Leg Receiver (P-3) and 1 each Left Leg
Receiver (P-4) to the Leg Brace(P-6) using 4 ( A2) Screws as
shown in illustration #5. (Do not tighten screws all the way)P4
P-6
A2
P3
Illustration # 5
Cylinder
Unactivated
Cylinder
Activated &
Locked
Cylinder
Activated
L
L

7
Insert Cylinder w/Plastic Cover (E) into Height Adjust Bracket (P-5) as
shown in illustration #6.
Slide Cylinder Extension (P-10) over Cylinder(E).
Slide Lower Leg Assembly over the Upper Leg Inserts (P-2) as shown in illustration #5.
(Make sure Cylinder Extension (P-10)slides into hole in Leg Brace (P-6) as shown
in illustration #6.)
Secure using 2 each Adjustment Knobs (L) as shown.
Attach CPU Assembly to the Leg Brace (P-6) using 2 each Screws ( A1)
as shown in illustration #6.
Tighten all screws using Allen Wrench (K).
P-2P-2
P-5
E
P-6
Illustration # 6
P-10
17.
18.
19.
20.
21.
22.
.ERGO-E.EAZY
A1
CPU
Assembly
Be sure the Adjustment
Knobs (L) are secured
before rotating unit to
the upright position.
L
L

8
A
P19
23. Place the Printer Platform (P-18) with the insert
nuts facing up. Attach 2 each Shelf Brackets
(P-19) to the Top Platform (P-18) using 8 each
( A) Screws as shown in illustration #7.
EazyShelf
Assembly Diagram
Place the Printer Shelf over the back edge
of the Desktop and secure by tightening
the knobs as shown in illustration #8.
Attach 2 each CD/Book Supports (P-20)
by sliding them over the back edge of shelf
(P-18) as shown in illustration #9.
03/13/03
Illustration # 8 P20
24.
25.
Printer
Shelf
Illustration # 7
Illustration # 9
Tighten Knobs
Desktop
P18
P18

9
ERGO-E.EAZY
Adjustable Pneumatic
Computer Desk
For more information
1-800-749-2258
41-½"
29-½"
ADJ
29” to 39"
10
7” X 8"
20” X 11"
11-¾"
9"Clearance7-¾"
25-½"
36”
27”
10”
45”
32”
2”
Leg Base
5.6 Cubic Feet
72 lbs.
Wood Top
1.7 Cubic Feet
27 lbs.
Shipping Information
7.3 Total Cubic Feet
99 lbs. total weight
