Height Adjustable Flipper
Half Round
Assembly Instructions

2
Part Drawing Description Qty Part Drawing Description Qty
HeightAdjustable Flipper - Half Round
We recommend that you assemble this
unit on a table.
Do not use unless all screws are tight. At least every six months, check all screws to be sure
they are tight. If parts are missing, broken, damaged, or worn, stop use of the product
until repairs are made by your dealer using factory authorized parts.
P1 TableTop 1 EA
P2 LeftLeg 1 EA
P3 RightLeg 1 EA
P4 Bottom Support 1 EA
P5 Top Support 1 EA
Hardware List
AM6*8mm Socket Screw 4 EA
A1 M6*10mm Socket Screw 4 EA
B M6*15mm Socket Screw 4 EA
B1 M6*38mm Socket Screw 1 EA
C2” Locking Caster 2 EA
D 2” Caster 2 EA
EAllenWrench 1 EA
FCaster Wrench 1 EA
G Spring Washer 4 EA

3
AssemblyDiagram
Illustration # 1
1.)
2.)
R EAD T HROUGH I NSTRUCTIONS FROM BEGINNING
TO END BEFORE STARTING TO ASSEMBLE UNIT .
3.)
Identifyand Separate allthe Parts andHardware.
Attachthe RightLeg(P3) andthe LeftLeg (P2)to theBottom Support(P4) usingtwo Screws
(A)for each legas showninIllustrstion #1. Tighten Screws(A)using Allen Wrench(E).
InserttheTopSupport(P5) betweenthe RightLeg (P3)and LeftLeg (P2)top tubesand attach
using two SocketScrews (A1)througheach legasshown inIllustration#2.
TightenScrews (A1)usingAllenWrench(E).
Illustration # 2
A
P3 P2
P4
A
P2
P5
A1
P3
A1

4
4.) PlaceTableTop (P1) upside down on a padded surface. Place the assembly from Step 3 over
theembedded threadedinsertsintheTopPanel(P1) asshownin Illustration#3. Attachthe
frameassembly totheTopPanel(P1)using twoScrews (B)througheach Leg’stop tubeand
oneScrew (B1) throughtheTopSupprt (P5).
Illustration #3
5.) Placea SpringWasher(G)on thestem ofeach LockingCaster (C) and screw the caster into
thefront holeineach legasshown inIllustration #4. PlaceaSpring Washer (G) onthe stem
ofeach Caster (D)and screwinto the rearhole ineach leg. Use CasterWrench (F)to
tighteneachcaster.
Illustration #4
B
B1
B
P1
P5
G
D
D
G
C
C

5
Illustration #5
Toadjust theheightof yourtable,remove the twoscrews ontheback ofeach leg. Movetheupper
leginsert upor downtofind thenew height’stapped holes. Replaceand tighten
thescrewsusingAllenWrench(E)asshown inIllustration #5.
6.)
Height Adjustment
Screws
Table
B
90178_1-10-12
