Balt Single floor carrel 89830 User manual

Assembly Instructions

123456789012345678901234567890121234567890123456789012345678901212345678901234

Single Floor Carrel

P-1 Left Side Panel 1 EA

P-2 Right Side Panel 1 EA

P-3 Top Panel 1 EA

P-4 Back Panel 1 EA

P-5 Keyboard Panel 1 EA

P-6 Left Leg 1 EA

P-7 Right Leg 1 EA

P-8 Left Keyboard Slide 1 EA

P-9 Right Keyboard Slide 1 EA

ASocket Screw M5X15 mm 2 EA

A1 Wood Screw #6X½ 8 EA

A2 Wood Screw #8X1¼ 2 EA

BInteriorThreadedPost 2 EA

CCamLock 14 EA

DCam Post 14 EA

EWoodDowel 4 EA

FGlide Bracket 2 EA

GGlide 4 EA

HGrommet Sleeve 1 EA

JGrommet Cap 1 EA

KAllenWrench 1 EA

Part Drawing Description Qty Part Drawing Description Qty

Single Floor Carrel

Hardware List

Toolsrequired: PhillipsHead Screwdriver

Note:Camlockscan be

turned withAllenWrench, or

LargePhillipsScrewdriver

Assembly Diagram

To Assemble:

IdentifyandSeparateall the PartsandHardware.

Illustration # 1

PlacetheLeftLeg(P-6) and Right Leg(P-7)withthethree threaded holes facingup.

Install5CamPosts(D)in each Leg as shown inillustration#1.

Install1LevelingGlide (G) in thebottomofeachleg asshowninillustration# 1.

TightenCamPosts(D) using PhillipsScrewdriver.

P-7

P-6

Illustration # 2

DP-6

P-8

P-1

Be sure that arrow on

top of Camlock (C)

alignswithcenterlineof

EdgeDrilledhole.

Phillips

Screwdriver

Centerlineof

EdgeDrilled

hole.

Arrow

ToSecure CamLocks, Insert

LargePhillips Head Screwdriver

andturn CamLock1/4 turn(90

degrees)clockwise.

s 4-8

for Left Side Panel

(P3) and Left Leg

Placethe Left Side Panel (P-1) with the Predrilled holes

facing up and install 2 each Cam Posts (D) in the 2

threadedinsertnuts (Pre-installed)

asshown inillustration #2.

Install2 eachDowels (E) intothe holes asshown in illustration# 2.

Attach Left Side Panel (P-1) to Left Leg (P-6 ) as shown in illustration # 2.

Secureby turning theCam Locks(C) 1/4turn untilthey lock.

Attach Left Keyboard Slide (P-8) to the Left Side Panel (P-1) using 2 each

Screws(A1) as shownin illustration #2.

Attach 1 Glide Bracket (F) using 1 Socket Screws (A) and 1 Interior

ThreadedPosts(B) as shownin illustration #2. Tighten Screwsusing

PhillipsScrewdriver.

Insert1 Glide (G)into the GlideBracket (F) as shownin illustration #2.

P-1

10.

Illustration # 3

P-7

P-9

P-1

Be sure that arrow on

top of Camlock (C)

alignswithcenterlineof

EdgeDrilledhole.

Phillips

Screwdriver

Centerlineof

EdgeDrilled

hole.

Arrow

12.

11.

13.

17. ToSecure CamLocks, Insert

LargePhillips Head Screwdriver

andturn CamLock1/4 turn(90

degrees)clockwise.

Placethe Right Side Panel (P-1)with the Predrilled holes

facing up and install 2 each Cam Posts (D) in the 2

threadedinsert nuts(Pre-installed) as shown

in illustration# 3.

Install2 eachDowels (E) intothe holes asshown in illustration# 3.

Attach Right Side Panel (P-2) to Right Leg (P-7 ) as shown in

illustration# 3. Secureby turning theCam Locks (C)1/4 turnuntil they lock.

AttachRightKeyboardSlide (P-9) to the Right Side Panel (P-2) using 2

eachScrews (B) asshown in illustration#3.

Attach 1 Glide Bracket (F) using 1 Socket Screw (A) and 1 Interior

ThreadedPost (B)asshown inillustration #3. Tighten Screws usingPhillips

Screwdriver.

Insert1 Glide (G)into the Glide Bracket (F)

as shownin illustration#3.

P-2

14.

15.

16.

Illustration # 4

P-1

Slide Top Panel (P-3) over the Wood

Dowels(E) and the Camposts (D) in the

Left Side Panel (P-1) as shown in

illustration#4.Secure byturning the

CamLocks (C)1/4 turnuntil theylock.

Slide Back Panel (P-4) over the

Campost (D) in the Left Leg (P-6) as

shown in illustration# 4.Secure by

turning theCam Locks(C) 1/4turn until

theylock.

Secure Back Panel (P-4) toTop Panel

(P-3) using 2 Wood Screws (A2) as

shown in illustration# 4.TightenScrews

usingPhillipsScrewdriver.

Illustration # 5

P-1

P-3

P-4

P-6

AttachRight Side Panel (P-2)

and Right Leg (P-7 ) to Top

Panel (P-3) and Back Panel

(P-4)as shown in

illustration# 5.

Secureby turning theCam

Locks(C)1/4 turnuntilthey

lock.

P-2

P-4

P-7

P-3

ToSecure Cam Locks,Insert Large

PhillipsHead Screwdriverand turn Cam

Lock1/4 turn (90 degrees)clockwise.

17.

18.

19.

20.

21.

P-1

P-2

P-5

P-8

AttachKeyboard(P-5) to

LeftKeyboardSlide (P-8)

and RightKeyboardSlide

(P-9)using4Wood Screws

(A1)asshown in

illustrations# 6.

TightenScrews(A1) using

PhillipsScrewdriver.

Illustration # 6

Keyboard SlideAssembly

22.

23.

89830,90124_06-30-14

Grommet(B) installation

Illustration #7

24.

25.

ToinstallGrommets:

Insert GrommetSleeve (H)in Roundopenings inTopPlatforms(P-2) asshown

inillustration#7.

Snap GrommetCap (J) intoGrommet Sleeve (H)as shown inillustration #7.

Assembly Instructions

123456789012345678901234567890121234567890123456789012345678901212345678901234

Add-On Floor Carrel

P-1 Middle Side Panel 1 EA

P-2 Top Panel 1 EA

P-3 Back Panel 1 EA

P-4 Keyboard Panel 1 EA

P-5 Middle Leg 1 EA

P-6 Left Keyboard Slide 1 EA

P-7 Right Keyboard Slide 1 EA

P-8 Ganging Bracket 2 EA

ASocket Screw M5X15 mm 1 EA

A1 Wood Screw #6X½ 12 EA

A2 Wood Screw #8X2¼ 2 EA

BInteriorThreadedPost 1 EA

B1 Washer 4 EA

CCamLock 11 EA

DCam Post 11 EA

ELong Wood Dowel 2 EA

FGlide Bracket 1 EA

GGlide 2 EA

HGrommet Sleeve 1 EA

JGrommet Cap 1 EA

KAllenWrench 1 EA

Part Drawing Description Qty Part Drawing Description Qty

Add-On Floor Carrel

Hardware List

Toolsrequired: PhillipsHead Screwdriver

Note:Camlocks can be

turned withAllenWrench, or

LargePhillipsScrewdriver

Assembly Diagram

To Assemble:

Identifyand Separateall the Partsand Hardware.

Illustration # 1b

Placethe Middle Leg(P-5) with the threethreaded

holesfacing up. Install 7Cam Posts (D)

in Leg as shown in illustration # 2.

Install1 LevelingGlide (G)in the bottom

ofleg as shownin illustration #2.

Tighten CamPosts (D)using

PhillipsScrewdriver.

DP-5

Illustration # 2

RemoveKeyboard from StarterCarrel asshown

in illustration #1a. Remove left legAssembly

fromStarter Carrelas shown in illustration# 1b.

Illustration # 1a

Illustration # 3

DP-5

P-6

P-1

Be sure that arrow on

top of Camlock (C)

alignswithcenterlineof

EdgeDrilledhole.

Phillips

Screwdriver

Centerlineof

EdgeDrilled

hole.

Arrow

ToSecure CamLocks, Insert

LargePhillips Head Screwdriver

andturn CamLock1/4 turn(90

degrees)clockwise.

Place the Middle Side Panel (P-1) with the Camlocks(C)

facing up and install 2 each Cam Posts (D) in the 2

threadedinsert nuts(Pre-installed) as shown

in illustration# 3.

Install2 eachLong Dowels (E)into the holes asshown inillustration # 3.

Attach Middle Side Panel (P-1) to Middle Leg (P-5 ) as shown in illustration

#3. Secure by turning theCam Locks(C) 1/4 turnuntil they lock.

Attach Left Keyboard Slide (P-6) to the Middle Side Panel (P-1) using 2

eachScrews (A1) asshown in illustration#3.

Attach 1 Glide Bracket (F) using 1 Socket Screws (A) and 1 Interior

ThreadedPosts(B) as shownin illustration #3. Tighten Screwsusing

PhillipsScrewdriver.

Insert1 Glide (G)into the GlideBracket (F) as shownin illustration #3.

P-1

Note: (B) screw

is in 1st HOLE

10.

Illustration # 4

P-5

11.

P-7

12.

Turn the Middle Side Panel (P-1) over and install 2 each Cam Posts (D) in the 2threaded

insertnuts(Pre-installed)asshown inillustration #4.

Attach Right Keyboard Slide (P-7) to the Middle Side Panel (P-1) using 2 each Screws

(A1)as shownin illustration#4.

P-1

Note: (B) screw

is in 2nd HOLE

Illustration # 5

Illustration # 6

P-1

ToSecure Cam Locks,Insert

Large Phillips Head Screw-

driverand turn CamLock 1/4

turn(90 degrees)clockwise.

16.

17.

Attach Middle Side Panel (P-1) to

Top Panel and the Middle Leg (P-5)

to the Back Panel of Starter Carrel

asshown in illustration # 5.

Secureby turning the CamLocks

Back Panel

StarterCarrel

P-5

Slide Top Panel (P-2) over the Wood Dowels (E) and the Camposts (D) in the Middle Side

Panel(P-1) as shown in illustration#6. Secure by turning theCam Locks (C)

1/4turnuntiltheylock.

Slide Back Panel (P-3) over the Camposts (D) in the Middle Leg (P-5) as shown in

illustration# 6.Secure byturning the CamLocks (C) 1/4turn untilthey lock.

Secure Back Panel (P-3) to

Top Panel (P-2) using 2 Wood

Screws(A2) as shown in

illustration#6.TightenScrews

usingPhillipsScrewdriver.

P-1

P-2

A2 P-3

P-5

TopPanel

StarterCarrel

13.

14.

15.

P-1

Illustration # 8

Attach Left Side Panel and Left Leg from Starter

Carrel to Top Panel (P-2) and Back Panel (P-3) as

shown in illustration# 7.

Secureby turning the CamLocks

P-3

P-2

21.

P-8

Attach 2 Ganging Brackets (P-8) to the 2 Back

Panels using 4 Screws (A1) and 4 Washers (B1)

asshown in illustration# 8.

Secureby turning the CamLocks

Illustration # 7

18.

19.

20.

Left Side Panel

StarterCarrel

Left Leg

Starter

Carrel

P-4

Attach1 Keyboard (P-4)and 1 keyboard

fromStarterCarrel to LeftKeyboardSlides

(P-8)andRight Keyboard Slides(P-9) using

4 Wood Screws (A1) and 4 Wood Screws

fromStarterCarrelasshownin illustration# 9.

TightenScrews(A1)

usingPhillipsScrewdriver.

Illustration # 9

Keyboard SlideAssembly

22.

23.

KeyboardPanel

StarterCarrel

Grommet installation

Illustration #10

ToinstallGrommets:

Insert GrommetSleeve (H)in Roundopening inTopPlatform(P-2)as shown

inillustration #10.

SnapGrommet Cap(J) into GrommetSleeve (H) asshown in illustration#10.

25.

24.

89831,90125_ 06-30-14
