Balt Study carrel 89789 User manual

123456789012345678901234567890121234567890123456789012345678901212345678901234

#89789 Study Carrel

Adjustable Height Workcenter

Assembly Instructions

P8 Stability Brace 1 EA

P9 Metal Angle Bracket 8 EA

P1 Right Side Panel 1 EA

P2 LeftSidePanel 1 EA

P3 TopPlatform 1 EA

P4 UpperShelfPlatform 1 EA

P5 Back Panel 1 EA

P6 UpperLegReciever 2 EA

P7 LowerLegInsert 2 EA

Part Drawing Description Qty Part Drawing Description Qty

WOW

Adjustable Height Workcenter

Study Carrel

Hardware List

A½” Socket Screw 4 EA

A1 1-½” Socket Screw 8 EA

BThreadedNut 4 EA

CWoodScrew 24 EA

DPlastic Grommet 2 EA

ELevelingGlide 4 EA

FAllen Wrench 1 EA

GCam Lock 16 EA

HCam Post 16 EA

We recommend that you assemble this

unit on a table.

Toolsrequired: Adjustable CrescentWrench

Do not use unless all screws are tight. At least every six months, check all screws to be sure

they are tight. If parts are missing, broken, damaged, or worn, stop use of the product

until repairs are made by your dealer using factory authorized parts.

Should you require assistance during assembly,

please call our Customer Service Department

Monday - Friday 8 a.m. - 5 p.m.

Central Standard Time 1-800-749-2258

Missing Parts or UPS Damaged Parts

ForYourConvenienceyoucan

EMAILusat

[email protected]

24HOURS 7 DAYS AWEEK

StudyCarrel

AssemblyDiagram

IdentifyandSeparatealltheParts

andHardware.

Illustration # 1

Illustration # 2

1.)

2.)

EAD

HROUGH

NSTRUCTIONS

FROM

BEGINNING

END

BEFORE

STARTING

ASSEMBLE

UNIT

PlacetheBack Panel (P5) with theinsertnuts facing up and install 4

eachCamLocks (G) into the largeholes as shown inillustration # 2.

Install4eachCamPosts(H) in the 4 threaded insert nuts

(Pre-installed) asshown in illustration#2.

Be sure that arrow on

top of Camlock (G)

alignswithcenterlineof

EdgeDrilledhole.

Phillips

Screwdriver

Centerlineof

EdgeDrilled

hole.

Arrow

PlacetheUpper Shelf Platform (P4)withthe Holesfacing up and install 6each

CamLocks(G) into the large holesas shown in illustration#1.

4.)

3.)

Illustration # 3

Illustration # 4

5.)

To Secure Cam Locks,Insert Large

PhillipsHeadScrewdriverand turn Cam

Lock1/4 turn (90 degrees)clockwise.

Placethe Left Side Panel (P2) with the

insertnutsfacingup.

Install6each Cam Posts (H) inthe6

threadedinsertnuts(Pre-installed) as

shown in illustration#3.

Repeat Steps 5 & 6 for the Right Side

Panel(P6).

Placethe Back Panel (P5)with the

insertnutsfacing up. Slide 1 each

UpperShelfPlatform(P4)overthe

CamPosts(H) as shown in

illustration# 5. Securebyturning

theCamLocks(H)1/4Turn

untiltheylock.

Slide 1 each Top Platform (P3) over

theCamPosts (H) as shown in

illustration#5andsecureby turning

theCamLocks(H)1/4Turn until they

lock. (Finger tighten only)

PlacetheTopPlatform(P3)withthe

Holesfacingup and install 6 each

CamLocks (G) into the large holes

asshowninillustration#4.

6.)

7.)

8.)

9.)

10.)

Illustration # 5

Illustration #6

Attach tothe Right Side Platform(P1) and the Left

Side Panel (P2) to the Top Platform (P-3), the Back

Panel(P5),andtheUpperShelf Platform (P-4) as

showninillustration #6.

11.)

Illustration #8

Attach2 each Metal Angle Brackets

(P9)using 6 each (C) screws as

showninillustration #8.

P2 P3

12.)

13.)

(C)Screw#6X½

For Scale only

(C)Screw#6X½

For Scale only

Attach6 each Metal Angle Brackets

(P9)using 18 each(C) screws as

showninillustration #7.

Illustration #7

Slide 2 Lower Leg Inserts (P7)

intotheUpper Leg Receivers

(P6).Secure at desired height

using (4) each (A) Screws as

showninillustration#10.

(Tighten all the screws at this

time using Allen Wrench (F)).

Attach4each (E) Leveling

Glides to the 2 each Lower

LegInserts(P7).

BA1

16.)

14.)

15.)

Illustration #10

P7 P7

Illustration #9

Rotatethe CarrelAssembly

sothat theTop Platform(P-3)

isfacing up.Attach2each

UpperReceivers(P6) to the

Top Platform(P-3)using4

each(A1)screwsasshown

inillustration#9.

(Finger tighten only)

AttachStabilityBrace(P8)to

the2each Upper Receivers

(P6) using 4 Screws (A1) and

4ThreadedNuts (B) as

shownin illustration#6.

17.)

(A1)ScrewM6X 1-½”

For Scale only

ForScaleonly

789789A-02/25/08

TheBaltproductyouhavepurchasedis guaranteed against material and workmanshipdefects. This

guaranteeextends1yearfrom date of purchase. Shouldthisproductfailtofunctionsatisfactorilyundernormal

usedueto defect or imperfection, thedefectivepartorproduct will be replaced. Damagecausedbycommon

carriersduringshipmentisnotincludedinthisguarantee.

This guarantee sets forth all applicable guarantees and remedies. No other warranty, expressed or

impliedshallapply. Failuretofollowinstructions foundinImportantInformationSectionofOwner

Sheetshall voidthe guarantee. Consequentialor incidentaldamages andor costsarenot refundable.

Important

Cap

Grommet(D) installation

Illustration #11

Sleeve

Grommet (D)

Sleeve

Cap

To installGrommet (D), separatepartsandpress

GrommetSleeveinRoundopeningsinTop

Platform(P3) and Back Panel(P4) as shown in

illustration#8.

Snap plastic Caps into Sleeves as shown in

illustration#11.

19.)

18.)
