#27531 Wide Body LCD TV Cart

with 2 Pull-out Shelves & Locking Cabinet

Assembly Instructions

SUPPORTS UP TO A 54” FLAT PANEL TV

P13 Laptop Shelf 19x18 1 EA

P14 Left Support Tubes 1 EA

P15 Right Support Tubes 1 EA

P16 Top LCD Bracket 1 EA

P17 Bottom LCD Bracket 1 EA

P18 Cord Winder 1 EA

P19 Electrical Outlet 1 EA

P1 FormedLeg”O” 2 EA

P2 FormedLeg”X” 2 EA

P3 TopShelf 2 EA

P4 Middle Shelf 1 EA

P5 Bottom Shelf 1 EA

P6 Side Panel w/brackets 2 EA

P7 Back Panel 1 EA

P8 Left Door 1 EA

P9 Right Door w/Lock 1 EA

P10 Angle Bracket-Lap Shelf 4 EA

P11 Shelf Support 4 EA

P12 Cabinet Shelf 1 EA

Part Drawing Description Qty Part Drawing Description Qty

#27531 Wide Body LCD Cart

Do not use unless all screws are tight. At least every six months, check all screws to be sure

they are tight. If parts are missing, broken, damaged, or worn, stop use of the product

until repairs are made by your dealer using factory authorized parts.

Toolsrequired: Phillips Head Screwdriver,

AdjustableCrescentWrench

Missing Parts or UPS Damaged Parts

ForYourConvenience youcan

EMAILusat

[email protected]

24HOURS 7 DAYSAWEEK

w/Verticle Slots

Hardware List

A1 Sq Hd Screw M8x15mm 24 EA

A2 Screw M5X70mm Pan Hd 2 EA

A3 Screw M6X35mm Pan Hd 4 EA

A4 Screw M8X20mm SocketHd 2 EA

A5 Screw M8X25mm Dog Point 2 EA

A6 Screw M8X25mm Cone Point 2 EA

A7 Screw Pan HD M5X10mm 24 EA

A8 Screw Pan HD M6X15mm 4 EA

electrical

back of monitor tube-Bottom

kb hangers

for inside cabinet

kb hangers

electrical

#27531 Wide Body LCD Cart

8EA

installed in end of monitor tubes

back of monitor tube-Top

B1 Hex nut M8 w/Flange 24 EA

B2 Hex nut M5 w/Flange 2 EA

B3 Hex nut M6 8 EA

C1 Flat Washer M5 24 EA

D 4” Locking Caster 2 EA

E 4” Caster 2 EA

TheBaltproductyou havepurchasedisguaranteed against materialandworkmanship defects. This guarantee

extends1year from dateofpurchase. Should thisproductfail to functionsatisfactorilyunder normalusedue to

defectorimperfection, thedefective part orproduct willbereplaced. Damage causedbycommon carriersduring

shipmentisnotincludedinthisguarantee.

This guarantee sets forth all applicable guarantees and remedies. No otherwarranty, expressed or

impliedshallapply. Failuretofollow instructionsfound inImportant InformationSectionofOwnerSheet

shallvoid the guarantee. Consequential or incidental damagesandorcosts are not refundable.

Important

Should you require assistance

duringassembly,

please call our Customer Service Department

Monday - Friday

8 a.m. - 5 p.m.

CentralStandard Time

1-800-749-2258

#27531 Wide Body LCD Cart

Assembly Diagram

Identifyand Separateall the Partsand Hardware.

Illustration # 1

1.)

2.)

EAD

HROUGH

NSTRUCTIONS

FROM

BEGINNING

END

BEFORE

STARTING

ASSEMBLE

UNIT

Attach 2 Legs (P-1) and 2 Legs

(P-2)to theTopShelf(P-3) using 8

screws(A1), and 8Nuts(B1).

P-3

P-1

Illustration #2B

3.)

P-1

P-2

Note-“X”or “O”

stamped in Bracket on

eachleg

P-3

P-1

P-2

P-5

P-4

Door stop

P-3

P-4

SlideMiddleShelf (P-4) in between

the 4 Legs (P1 & P-2) and attach

using8 screws (A1), and8Nuts (B1)

asshown in illustrations#2A& 2B.

SlideBottomShelf (P-5) in

between the 4 Legs (P1 & P-2) as

shownin illustrations#2A& 2B.

Note Shelf & Doorstop

Locations

Illustration #2A

4.)

Note-“X”or “O”

stamped in Bracket on

eachleg

2Holes

intop

Shelf

Press 2 Locking Casters

(D)and 2non-locking

casters(E) into the

factoryinstallednylon

insertsin the Base

Cabinet(P-1) as shown

inillustration #3B.

Note: Be sure that Door stop on Bottom Shelf

(P5)is oriented toward thefrontof cart and

grommet in Middle Shelf (P4) is toward the back

asshown inillustration# 3A.

Door stop

Grommet

P-5 E

Illustration #3A

Illustration #3B

5.)

6.)

7.)

P-5

P-3

P-4

P-1

P-2

P-1

P-2

P-6

P-7

P-6

Slide 2 side Panels (P-6) and Back

Panel(P-7) between legsandinto slot

in bottom of Middle Shelf (P-4) as

shownin illustration# 4.

Secure Bottom Shelf (P-5) to the 4 Legs (P-1 &

P-2) using 4 screws (A1) and 4 Nuts (B1) as

shownin illustration#3A and3B.

Illustration #4

P-5

P-4
