B&D Roll-A-Door R1D User manual

These instructions are intended for professional garage door installers.
B&D encourages recycling of packaging as is reduces waste to landfill
and achieves environmental benefits.
Auto-Lock Kit
Doc # 161071_00
Released 12/11/21
Auto-Lock Contents Bracket Kit (Kit sold separately)
WARNING! This lock has been designed
to work with B&D Roll-A-Door garage
doors.
If you t this lock to other branded garage door, we
cannot guarantee the performance of the lock and
any performance warranties will not apply. This is
subject to any Statutory Guarantees that may apply.
Please refer to our warranty terms and conditions
set out in the B&D Owners Opener Handbook.
For B&D Roll-A-Door®R1D.
Important Safety Instructions
WARNING! • DO NOT attempt to disassemble, repair or modify the product.
This will invalidate the warranty.
• DO NOT allow children to play with the Auto-Lock.
• DO NOT install in garages that have only one exit.
• DO NOT cover, paint or lubricate the product.
CAUTION:
Burns • DO NOT handle damaged or leaking batteries
• The Auto-Lock Kit contains sealed lead-acid batteries that must be disposed of
properly at the end of their useful life.
Muscle strain • DO NOT attempt to lift the door manually when the Auto-lock is engaged.
This device will slide a bolt into the guide
track automatically when the door is
closed. DO NOT install in garages that
have only one exit.
For emergency lock / unlock press the lock / unlock
button on the Auto-Lock.This will disengage the lock
from the guide track and allow you to disengage the
opener and open the door. The lock will automatically
re-engage after the next complete cycle.
It is our strong recommendation that
your opener be tted with SAFETY BEAMS.
Safety Beams detect any obstructions in the door/
gate’s path and override automatic operation
if one presents. These must be installed as in
accordance with AS/NZS 60335-2-95:2012.
GARAGE DOOR LOCK - ORDER NO. 87835
ITEM DESCRIPTION QTY
1 GARAGE DOOR LOCK 2
2 BUTTON HEAD SCREW ZN M6 X 10 4
3 TAPTITE “P” BLACK SCREW M3 X 14 8
4 BATTERY C-LR14 4
5 WIRELESS BASESTATION MODULE 1
6 VELCRO 1
WARNING! Ensure the opener is not engaged
when the Auto-lock is being used with only
the bolt unit. Failure to do so may void the
warranty of the opener.
CAUTION: Ensure bolt on Auto-lock is free to
move during limit setup.
STANDARD BRACKET KIT - ORDER #MC0123
ITEM DESCRIPTION: QTY
7 LOCK STRIKER 2
8 WALL BRACKET 2
9 CORRUGATED PLATE 1
10 ALCOHOL WIPES 2
LIMITED SIDEROOM BRACKET KIT - ORDER #MC0115
ITEM DESCRIPTION: QTY
7 LOCK STRIKER 2
8 WALL BRACKET 2
9 CORRUGATED PLATE 1
10 ALCOHOL WIPES 2
11 60mm HEAD STOP 1
Auto-Lock compatible with RDO-1V4
openers with rmware #59

prior to installation
Preparation - setting the door limits
Ensure the door limits have been set on the opener,
prior to installing the Auto-lock. Refer to the opener
manual for instructions.
install batteries
a. Insert batteries 4into drive unit.
b. Place cover back on drive unit
and secure with 4 x screws 3.
4
3
WARNING! remove all manual locking
systems prior to installing lock. Any damage
as a result of a manual lock will void the
warranty for the door,Auto-lock and opener.
a. Before the guides are installed on the door,
place the lock striker 7into the second
bottom curtain corrugation, pushing
striker towards the door edge,whilst sliding
the legs under the Nylofelt®and hooking
them over the curtain edge, before
snapping into position as per diagram.
b. Repeat for second lock striker at other
side of door.
c. Continue with door installation before
proceeding.
install striker & corrugated plate
7
W
9
mark position &
clean with wipe 10
d. Measure the middle point of the door. Place
corrugated plate 9over middle point and mark
position on door. including holes at bottom.
e. Pre-drill holes in door.
f. Use Alcohol wipe 10 to clean surface where plate is
to be tted.
g. Remove tape from corrugated plate and place on
door.
h. Take the weight bar W, nuts and screws from the
opener box and install as shown.
program lock
a. Press and hold the info button i on drive
unit until the light goes red.
b. Then press the lock/unlock button to test
the drive unit.
MINIMUM SIDEROOM REQUIRED FROM INSIDE GUIDE TO
EDGE OF BRACKET/AUTO-LOCK
INSTALLATION STANDARD
(side mount)
LIMITED SIDE ROOM
(front mount)
R1D 125mm 80mm
2
Auto-Lock Kit - Installation instructions

standard installation for Roll-A-Door
(side mount)
a. After limits are set on the opener,
measure the position Xof each
lock striker from the ground to
the middle of the lock striker. (as
shown).
b. Once both lock strikers are
installed, test manual operation
of the door to ensure no sticking
or scraping within the guide.
c. Open the door, place some
tape inside each guide and
transfer measure Xto middle
of guide.
d. Using an 18mm stepped drill,
drill a hole through the guide
and remove any burs from hole.
e. Assemble both AutoLocks 1to the
wall brackets 8using 2 x button
head screws 2, ensuring the at
side of the lock bolt is facing the
door.
lock bolt ush
with inside of
guide
mark
2
8
1
mark
X
f. Place bracket on wall up against the guide and
ensure the body of the lock bolt is ush with the
inside of the guide.
g. Mark the position of the bracket holes on the wall.
Predrill holes and afx to wall with 2 x coach screws
and washers. (not supplied)
lock bolt
engages without
interference
X
h. With the door closed, test the operation of each
AutoLock by pressing the lock/unlock button to
ensure the lock bolt fully engages through the guide
and into the striker without interference.
PROCEED TO CONNECTING WIRELESS BASE STATION TO
THE OPENER.
3
Auto-Lock Kit - Installation instructions

mark
X
limited side room installation for Roll-A-Door
(front mount)
2
8
1
mark
lock bolt ush with
inside of guide
side view
front view
lock bolt
engages without
interference
11 side view
X
a. After limits are set on the opener,
measure the position Xof each
lock striker from the ground to
the middle of the lock striker. (as
shown).
b. Once both lock strikers are
installed, test manual operation
of the door to ensure no sticking
or scraping within the guide.
c. Open the door, place some
tape inside each guide and
transfer measure Xto middle
of guide.
d. Using an 18mm stepped drill,
drill a hole through the guide
and remove any burs from hole.
e. Assemble both AutoLocks 1to the
wall brackets 8using 2 x button
head screws 2, ensuring the at
side of the lock bolt is facing the
door.
f. Remove the old head stop and
replace with longer head stop 11 .
g. Unscrew the bottom rail stop on
each side of the door and move
into the inner hole and ret screw
as shown.
h. Place bracket on wall up against
the guide and ensure the body of
the lock bolt is ush with the inside
of the guide.
i. Mark the position of the bracket
holes on the wall.Predrill holes and
afx to wall with 2 x coach screws
and washers. (not supplied)
j. With the door closed, test the
operation of each AutoLock by
pressing the lock/unlock button to
ensure the lock bolt fully engages
through the guide and into the
striker without interference.
PROCEED TO CONNECTING WIRELESS
BASE STATION TO THE OPENER.
4
Auto-Lock Kit - Installation instructions

a. Disconnect the power supply to the opener.
b. Remove the light diffuser via screw at the bottom.
c. Remove the grommet out of the back cover.
d. Cut (1) one side of the grommet with a knife or scissors.
e. Connect harness to basestation 5, before sliding into
the cut in the grommet.
f. Ret grommet to back cover by inserting the harness
through hole before tting grommet.
connect basestation to opener
emergency operation
Press the emergency lock/unlock button on the front of each Auto-Lock
to disengage the locking bolt from the guide track and allow you to
disengage the opener and open the door.
WARNING! The emergency lock/unlock button on
this product is not to be used as a primary means of
locking the door under normal circumstances.
The emergency lock/unlock button is to be used only in case of power
outage or emergency.
If a PE Beam is installed ensure that the channels on the basestation on each device are different.
The channel on the basestation can be changed by sliding the switch in either direction.
5
ACC Pin
Light diffuser
Grommet
Light diffuser
screw
g. Place the velcro 6onto the basestation 5and secure
to the back of the opener as shown.
h. Connect the harness to the ACC 4 pin on the control
board.
i. Ret the light diffuser.
j. Reconnect power to the opener and test operation via
the opener.
k. Upon completion of a full cycle the lock will engage
into the track.
tip
5
Auto-Lock Kit - Installation instructions

6
Auto-Lock Kit - Installation instructions
b&d group ofce locations
Head Ofce 6-8 Fiveways Blvd, Keysborough 3173 Phone [phone]
New South Wales 34 Marigold St, Revesby 2212 Phone [phone]
Queensland 17 Oasis Court, Clontarf 4019 Phone [phone]
Victoria 147-153 Canterbury Rd, Kilsyth 3137 Phone [phone]
South Australia 23 Frederick Rd, Royal Park 5014 Phone [phone]
Western Australia 96 Mulgul Rd, Malaga 6090 Phone [phone]
International/Export 34 Marigold St, Revesby 2212 Phone [phone]
New Zealand 46 Braeburn Dr, hornby, Chch 8082 Phone [phone]
www.bnd.com.au
Prefixed trademarks are the property of B&D Australia Pty Ltd. B&D Doors & Openers
is a division of B&D Australia Pty Ltd.ABN 25 010 473 971. © 2016 B&D Australia Pty Ltd.
your representative is
battery change
a. Replace lock batteries (2 x C-LR 14) immediately when
the Auto-lock LED’s red and green lights ash 3 times or
are ashing slowly.
b. Remove cover by unscrewing the four screws on the
main cover.
c. Replace batteries, ret cover and secure with screws.
d. Operate opener to complete a full open / close cycle
and ensure Auto-lock engages.
led status
lock position status
The status normally displays for 10secs
after lock movement / button press.
LED STATUS INDICATORS
RED GREEN LOCK STATUS
FLASHING RAPIDLY LOCKING
ON LOCKED
FLASHING RAPIDLY UNLOCKING
ON UNLOCKED
ON ON ERROR
FLASHING SLOWLY FLASHING SLOWLY LOW BATTERY
FLASHING ALTERNATIVELY FLASHING ALTERNATIVELY NO LINK WITH BASESTATION
Remove screws to
open main cover
troubleshooting
Symptom Possible cause Remedy
door not moving and no lights
on lock
battery dead press the (i) button on the lock to see if there is power in the battery.
no lights - change battery
lights - check LED status table.
lock is not unlocking and
preventing doors movement
lock jammed ensure the lock bracket is square to the guide (if not use packers). Check if there is
anything obstructing the lock bolt movement. Press the unlock button on each lock.
If it does not move call 13 62 63.
red and green lights both on
solid on the lock.
error with lock press the unlock button on the lock to test operation.
switch off power to opener, then switch back on after 30 secs (If a battery backup is
installed press & hold STOP/SET button on the opener until power ceases). Press the
lock/ unlock button on the lock to test operation. If it does not move call 13 62 63.
one lock has lights the other
lock has no lights
battery dead press the (i) button on the lock without lights to see if there is power in the battery.
no lights - change battery
lights - check LED status table.
red and green lights on one
lock ashing slowly
low battery change battery, then test operation of lock by pressing the lock / unlock button.
red and green lights ashing
alternatively
no link to opener Disconnect power to the opener and check connection of the basestation harness
to the control board.
Refer to our website for full warranty details;
www.bnd.com.au/repairs-service/door-warranty
WARRANTY
ACCESSORIES 1 year
If you are a consumer under the Australian Consumer Law, our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement
or refund for a major failure and for compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of
acceptable quality and the failure does not amount to a major failure. This warranty certicate and other statements contained in this document or other B&D documents given to you do not
exclude, restrict or modify the application of all or any of the provisions of the Australian Consumer Law.
Subject to your non-excludable rights under the Australian Consumer Law, B&D expressly excludes any liability for consequential loss, incidental or indirect damages (including but not limited
to damages for loss of business prots, business interruption and loss of business information) due to a defect of the Product. In particular, any loss or damage caused to other equipment or
accessories used with the product or any loss resulting from a delay in repair is excluded to the extent permitted by law.
