Bang & Olufsen Beo4 User manual

Beo4
Guide
Downloaded from ManualsNet.com search engine

Downloaded from ManualsNet.com search engine

Using your Beo4 remote control, 4
Beo4 buttons in detail, 6
 • DailyandadvancedoperationwithBeo4
buttons
Customise Beo4, 9
 • SetupBeo4
 • Addanextra‘button’
 • Moveextra‘buttons’
 • Removeanextra‘button’
 • CongureBeo4forusewithanother
audioorvideosystem
Maintenance, 16
 • CleaningtheBeo4
 • Changingthebatteries
Contents
Technicalspecications,featuresandtheuse
thereofaresubjecttochangewithoutnotice.
This product is in conformity with the provisions
of the Directives 1999/5/EC and 2006/95/EC.
3
Downloaded from ManualsNet.com search engine

Using your Beo4 remote control
TV LIGHT RADIO
DTV DVD CD
V MEM RECORD A MEM
789
456
TEXT 0MENU
123
LIST EXIT
STOP
GO
4
The Beo4 display tells you which source
you are operating. It is also used for
calling up extra “buttons” for different
functions or sources.
Source buttons and buttons for recording.
Number keys; and buttons for Teletext
and on-screen menus.
Control buttons within the star-shaped
button.
Volume, stop and exit buttons; and LIST
button for calling up extra “buttons” in
the Beo4 display.
Downloaded from ManualsNet.com search engine

TheBeo4isahand-heldremotecontrol
whichgiveseasyaccesstoremoteoperation
ofyourBang&Olufsenaudioand/orvideo
system.
Dailyoperationsarecarriedoutbypressinga
singlebuttonontheBeo4,orbypressinga
fewbuttonsinalogicalandstraightforward
sequence.
ThedisplayonBeo4keepsyouinformedof
whichsourceyouareoperating,suchasTV,
RADIO,aDVDplayer,oreventhelights…
ButtheBeo4remotecontrolincorporates
morefunctionsthanjusttheactualbuttons:
Extrasourcescanbeswitchedon,and
additionalfunctionscanbeobtainedviathe
display.“Buttons”forthesefunctionscanbe
calledupontheBeo4displayviatheLIST
button.
WhetheryouusetheBeo4buttonsfordaily
operation,orcallupextra“buttons”for
functionsorsourcesinthedisplay,youwill
ndthatBeo4remoteoperationiseasy…
On the Bang & Olufsen web-site you can nd a
lexicon of extra Beo4 buttons.
456
TEXT 0MENU
123
LIST
STOP
GO
5
The Beo4 remote control
– you will nd all the
buttons you need for
daily operation centred
in and around the
star-shaped button.
Downloaded from ManualsNet.com search engine

Daily and advanced operation with Beo4
buttons
ThebuttonsontheBeo4remotecontrolare
convenientlygroupedfordailyoperation…
Source buttons … TV, DTV (SAT*), VMEM
(V TAPE*), RADIO, DVD, CD, AMEM (A TAPE*),
and LIGHT are used for switching on your
Bang & Olufsen audio and video products,
other audio/video integrated systems and the
Bang & Olufsen light control. Some externally
connected products may have to be switched
on via the LIST button and subsequent relevant
“buttons” or cues shown in the Beo4 display.
RECORD button … is situated close to the
source buttons to enable easy recording on a
video or audio recorder.
Number keys … 0 through to 9 are used
whenever you have to key in numbers, for
example, to select an exact TV or radio program
number, to select Teletext pages, to select
specic tracks on a CD or DVD, and to select
a specic audio or video recording.
TEXT and MENU buttons … gives access to
Teletext on your Bang & Olufsen TV and calls up
the on-screen menus for your Bang & Olufsen
video products.
NOTE! Buttons marked with an * apply only to
previous versions of the Beo4 remote control.
Beo4 buttons in detail …
TV LIGHT RADIO
DTV DVD CD
V MEM RECORD A MEM
789
V MEM RECORD A MEM
789
456
TEXT 0MENU
123
6
Downloaded from ManualsNet.com search engine

Control buttons within the star-shaped
button …
and … allow you to step through program
numbers or tracks. On some audio systems,
they act as On or Off buttons respectively for
a Random, Repeat or Edit function.
and … allow you to wind through or change
between recordings or discs. The buttons have
different functions depending on your Bang &
Olufsen audio or video system. Refer to the
Guide enclosed with your system for further
information.
GO button … is used for accepting various types
of operations; and to resume playing the source
which is shown in the Beo4 display.
Coloured buttons … are for special operations.
It will be explained in the Guide for your Bang &
Olufsen product when and how to use the buttons.
Volume, stop and exit buttons; and LIST
button for calling up extra “buttons” in the
Beo4 display …
Volume button … and in the centre turns
the sound in the loudspeakers up or down.
Press the volume button right on the middle to
mute the speakers completely, press the button
again to bring the sound back.
STOP button … is used for various stop functions,
for example, to stop playback on a source.
EXIT button … exits Beo4 display operation; and
removes on-screen menus.
LIST button … pressing it repeatedly displays
extra “buttons” for functions or sources in the
Beo4 display.
Standby button • …the red standby button
switches your Bang & Olufsen system off.
TEXT 0MENU
LIST EXIT
GO
LIST EXIT
STOP
GO
7
Downloaded from ManualsNet.com search engine

8
Downloaded from ManualsNet.com search engine

TheBeo4buttonsgivedirectremotecontrol
ofalargenumberoffunctions,andtheBeo4
displaygivesyouaccesstoevenmorefunctions.
WheneverasourceisdisplayedonBeo4
(TV,RADIO,etc.),youcanpresstheLIST
buttonandbringupextrafunctionsinthe
displaytohelpyouoperatethatsource,just
asifyouwerecallingupextrabuttons.You
canalsoswitchonextraequipmentconnected
toyourtelevision.
YoucancustomiseanewBeo4tosuityour
television,andchangetheorderinwhich
theseextrafunctionsappearwhenyoucall
themup.
NotethatBeo4containsalistofallofBang&
Olufsen’sextraaudioandvideofunctions,
butonlythosefunctionssupportedbythe
Bang&Olufsenproductworkwhenyoucall
themupintheBeo4display.
Customise Beo4 …
9
On the Bang & Olufsen
web-site you can nd
a lexicon of extra Beo4
buttons.
Downloaded from ManualsNet.com search engine

Set up Beo4
IfyoubuyanewBeo4youcansetitupfor
yourtelevisionoralso.
> Press and hold the standby button down.
> Press LIST to get access to the Beo4 setup
function.
> Let go of both buttons. ADD? appears in the
display.
> Press LISTrepeatedly to display CONFIG? on
Beo4.
> Press GOto be able to select the type of
conguration.
> Press LISTrepeatedly to display VIDEO? on
Beo4.
> Press GOto get access to the video
conguration.
> Press LISTrepeatedly to display VIDEO 4 on
Beo4.
> Press GOto store the conguration.
> STORED appears, indicating that the
conguration has been stored. You leave the
Beo4 setup function automatically.
>> Customise Beo4 …
10
Downloaded from ManualsNet.com search engine

Add an extra ‘button’
WhenyouaddanewfunctiontotheBeo4
list,youcanthenbringupthisnew‘button’
intheBeo4display.
> Press and hold the standby button down.
> Press LIST to get access to the Beo4 setup
function.
> Let go of both buttons. ADD? appears in the
display.
> Press GO to bring up the list of available
‘buttons’ to add from. The rst ‘button’
appears in the display, it ashes on and off.
> Press or to move forwards or backwards in
the list of all extra ‘buttons’.
> Press GO to add and place the ‘button’ on its
preset position or as the rst ‘button’ in the list,
or …
> … press 1 – 9 to insert the ‘button’ at a specic
position in the list.
> ADDED appears, indicating that the ‘button’
has been added. You leave the Beo4 setup
function automatically.
GO 3
11
Add an extra ‘button’
to Beo4, either to the
top of the list or to a
specic position.
Downloaded from ManualsNet.com search engine

Move extra ‘buttons’
Youcanrearrangetheorderinwhichthe
extra‘buttons’appearwhenyoupressLIST.
> Press and hold the standby button down.
> Press LIST to get access to the Beo4 setup
function.
> Let go of both buttons. ADD? appears in the
display.
> Press LISTrepeatedly to display MOVE? on
Beo4.
> Press GOto bring up the list of extra ‘buttons’.
The rst ‘button’ appears in the display.
> Press or to move forwards or backwards
in the list of extra ’buttons’.
> Press GOto move and place the displayed
‘button’ as the rst in the list, or …
> … press 1 – 9 to move the ‘button’ to a specic
position in the list.
> MOVED appears, indicating that the ‘button’
has been moved. You leave the Beo4 setup
function automatically.
>> Customise Beo4 …
GO 3
12
Move extra ‘buttons’,
either to the top of the
list or to a specic
position.
Downloaded from ManualsNet.com search engine

Remove an extra ‘button’
Youcanremoveanyoftheextra‘buttons’
thatareavailablewhenyoupressLIST.
> Press and hold the standby button down.
> Press LIST to get access to the Beo4 setup
function.
> Let go of both buttons. ADD? appears in the
display.
> Press LIST repeatedly to display REMOVE? on
Beo4.
> Press GO to bring up the list of extra ‘buttons’.
The rst ‘button’ appears in the display.
> Press or to move forwards or backwards in
the list of extra ’buttons’.
> Press GOto remove the ‘button’ shown in the
display.
> REMOVED appears, indicating that the ‘button’
has been removed. You leave the Beo4 setup
function automatically.
13
Downloaded from ManualsNet.com search engine

>> Customise Beo4 …
Congure Beo4 for use with another audio
or video system
YourBeo4isconguredforVIDEO4fromthe
factory,butyoucancongureBeo4foruse
withanytypeofBang&Olufsenaudioor
videosystem.
To be able to recongure Beo4 …
> Press and hold the standby button down.
> Press LIST to get access to the Beo4 setup
function.
> Let go of both buttons. ADD? appears in the
display.
> Press LIST repeatedly to display CONFIG? on
Beo4.
> Press GO to be able to select the type of
conguration – video or audio.
> Press LIST until VIDEO? or AUDIO? appears in
the display.
> Press GO to get access to video or audio
congurations.
> Press LIST until the conguration you want
appears in the display.
Or, press any of the control buttons, , ,
or to move forwards or backwards in the
list of available congurations.
> Press GO to store the conguration shown in
the display.
When STORED appears in the display, the
conguration has been changed and you then
leave the Beo4 setup automatically …
14
Downloaded from ManualsNet.com search engine

VIDEO1:BeoVision9,BeoVision5,
BeoVision4,BeoSystem1,BeoVision 3 – 32-
inch screen,BeoVisionAvant,
BeoCenterAV5,BeoCenterAV9000,
Earlier BeoVision MX models
VIDEO2:BeoVision6,BeoVision 3 – 28-inch
screen,BeoVision1,BeoVision1Link,
BeoCenter1,BeoVisionMX4200/8000
VIDEO3: Video products for the
American Taiwanese markets
VIDEO4:BeoVision8,BeoSystem3
AUDIO1: Audio systems other than
BeoSound9000
AUDIO2:BeoSound9000
AUDIO
BASIC: all audio systems other than
BeoSound9000
BS9000:BeoSound9000
VIDEO
AVANT:BeoVisionAvant
AVANTUS:BeoVisionAvantUS
AV5:BeoCenterAV5
BC1:BeoCenter1
BV1:BeoVision1
MX:BeoVisionMX
NONE: For audio setups.
No video functions are included
15
Other options than
those listed here may
appear in the display
when you select
VIDEO? or AUDIO?.
These other options are
listed below. Refer to
the Beo4 lexicon on
our web-side for
further information.
In order to use teletext
on a television you have
set to Option 4, you
must set up Beo4 to
‘VIDEO 3’, but this
limits the Beo4
functions that can be
used with televisions
set to other Options.
For further information,
refer to the Guide for
the television.
Downloaded from ManualsNet.com search engine

Cleaning the Beo4…
WipetheBeo4remotecontrolwithasoft,
lint-free,wetclothwhichiswrungrmly.
Changing the batteries
WhenBATTERYappearsintheBeo4display,
itistimetochangethebatteriesinthe
remotecontrol.
TheBeo4requiresthreebatteries(placed
underthelidontheback).Werecommend
thatyouuse1.5volt(sizeAAA)Alkaline
batteriesonly.
Replacethebatteriesasshownonthenext
page.
Whenyouhavereplacedthebatteries,you
mustwaitforabout10secondsuntilthe
displayreadsTV.TheBeo4remotecontrolis
thenreadytooperateagain.
Note: We recommend that you keep a nger on
top of the batteries until the lid is replaced.
Maintenance …
1
2
3
1
2
16
CAUTION! Do not
expose batteries to
excessive heat such as
sunshine, re or the
like!
Downloaded from ManualsNet.com search engine

English (English)
Electrical and electronic equipment, parts and batteries marked
with this symbol must not be disposed of with normal household
wastage, it must be collected and disposed of separately to
protect the environment.
Your Bang & Olufsen retailer will advise you of the correct way of disposal in
your country.
If a product is too small to be marked with the symbol, it will appear in the
User Guide, on the Guarantee certicate, or on the packaging.
For the US-market only!
NOTE: This equipment has been tested and found to comply with the limits
for a class B digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference in
a residential installation.
This equipment generates, uses and can radiate radio frequency energy and,
if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
– Consult the retailer or an experienced radio/TV technician for help.
For the Canadian market only!
This class B digital apparatus meets all requirements of the Canadian
Interference-Causing Equipment Regulations.
This product is in conformity with the provisions of the Directives
2004/108/EC and 2006/95/EC.
All Bang & Olufsen products comply with applicable environmental
legislation throughout the world.
17
Downloaded from ManualsNet.com search engine

18
Downloaded from ManualsNet.com search engine

Downloaded from ManualsNet.com search engine

3501025 0912
Downloaded from ManualsNet.com search engine
