Bang & Olufsen Beolink 1000 User manual

BEOLINK 1000

2
The Beolink 1000 remote control gives access
to all the primary functions in a Bang &
Olufsen system, including audio and video
products and special functions such as light
control.
This User’s guide gives a general introduction
into the use of Beolink 1000 in connection
with any compatible Bang & Olufsen audio or
video product.
For detailed operating instructions, please
refer to the User’s guide for the appropriate
audio or video system.

3
4 Beolink 1000
Principles of operation
5 Daily operations
Using your audio or video system with
Beolink 1000
6 Using other functions
Searching on a video tape
SHIFT functions
Beolink 1000 and BeoLink setup
Light control
8 Sound and picture
Adjusting sound and picture levels
9 On-screen menus
Using on-screen menus
10 Miscl. information
CONTENTS
User’s guide

4
Principles of operation
The Beolink 1000 remote control integrates
remote operation of your Bang & Olufsen
products.
Daily operations are carried out directly via the
Beolink 1000 by pressing a single button, or by
pressing a few buttons in a logical and
straightforward sequence.
The more advanced functions are also carried
out from the Beolink 1000 remote control but
operation of such functions may be guided by
on-screen menus on a video product.
You can rest the Beolink remote control on a
table, hold it in your hand or hang it on the
wall in a specially designed clip (an optional
accessory).
Whichever way is most convenient, you will
find that the Beolink remote control always
responds readily to your instructions.
BEOLINK 1000
3
6
9
0
2
5
8
1
4
7
MUTE
STORE
SOUND
GO TO
TEXT
PLAY
MIXLARGE
A.TAPE
PHONO
LIGHT
LINK
RECORD
SHIFT
V.TAPE
AV
STOP
RADIO
CD
TV
SAT
MENU
The Beolink 1000 remote control

DAILY OPERATIONS 5
Using your audio or video system with Beolink 1000
You can use the Beolink 1000 remote control
to switch on any video or audio sources.
Via Beolink 1000, you can search for specific
tracks* on your audio or video tapes or on
your CD or select program numbers for TV,
SAT or RADIO. Alternatively, use the wind
buttons to search through audio or video
tapes or search through a CD in a single CD
player.
If you are able to record audio or video
sources, you can instruct an audio or videotape
recorder to record the program you are
currently listening to or watching via Beolink
1000.
When you press STOP once, you stop playback
on an audio tape and pause playback on a
video tape or a CD. To stop playback entirely
on a video tape, you must press STOP again or
press the standby button to switch the system
to standby.
*Note: To search for tracks on a video tape,
you must preset your video system via its Setup
menu, please refer to the User’s guide for the
respective system for further instructions.
Note: To switch on a CDV player, press SHIFT
then SAT and operate as usual.
Switching on video sources…
Press to switch on to TV
Press to switch on to Satellite
Press to switch on the video tape
recorder
Switching on audio sources…
Press to switch on the radio
Press to start playing a CD
Press to start the audio tape
recorder
Press to start the record player
Press to step between program
numbers or tracks on audio or
video tape or on a CD
Use the number keys to select
program numbers or tracks
Press to search backwards on an
audio or video tape or on a single
CD player
Press to search forward on an audio
or video tape or on a single CD
player
To record a current source…
Press to twice to start recording
Press to pause or stop
Press to resume playing
Press to switch the system to standby
TV
SAT
V.TAPE
RADIO
CD
A.TAPE
PHONO
or
0
9
RECORD
RECORD
STOP
PLAY
through to
•

USING OTHER FUNCTIONS
6
If you have a Bang & Olufsen video tape
recorder, you can use the Beolink 1000 to
control its functions.
In addition to regular playback operations,
you can search through the tape with a picture
on the screen, search through the tape in slow
motion or search for specific counter positions,
Time left or Time used.
Please refer to the video tape recorder’s own
User’s guide for further instruction…
Press to start playing a tape
Press to play the tape from a specific
counter position
for example 2:15
While the tape is playing…
Press to cue the tape forwards
Press to cue the tape backwards
Press to pause the tape
Pressing plays the tape in slow
motion, pressing plays the tape
backwards in slow motion
To stop playback entirely…
Press to stop playback entirely
Searching on a Video tape
V.TAPE
GO TO
2
1
then
5
or
STOP
STOP
STOP
SHIFT functions
You can use the SHIFT button to call up special
functions for both video and audio sources.
You can change between the sound tracks on
a video tape, change sound type (e.g. mono or
stereo) or language for a program, change
between Radio FM and AM band or turn an
audio tape over.
Note: If your video system is equipped with a
P-in-P module, press SHIFT then PICTURE to
move the small inserted picture from corner to
corner.
With V. TAPE as source…
Press to change between sound
tracks available on a video tape
With TV or SAT as source…
Press to change between the sound
or languages available for a
programme
With RADIO as source…
Press to change from FM to AM
With A. TAPE as source…
Press to turn an audio tape over
SHIFT
SHIFT
SOUND
SHIFT
SOUND
SHIFT
SOUND

7
Beolink 1000 and BeoLink setup
If you have a BeoLink setup with audio and
video products in different rooms and want to
watch a decoded TV programme from your
main room system on your link room TV, you
must transfer this particular video source from
the main room video system to your link room
TV.
Note: For further information about BeoLink,
please contact your Bang & Olufsen dealer.
Note: If you have an integrated audio/video
system, you can use the AV button to shift the
sound control from the audio to the video
system and vice versa.
Press to transfer a video source from
a main room system to link room
system
To transfer TV…
Then operate the sources as usual
via your Beolink 1000…
Light control
Press to be able to control the light
Press to adjust the light intensity
– turn the lights up or down
Use the number keys to select the
light picture you want
If you have a Bang & Olufsen light Control or
several such light controls, you can control
most household lights via your Beolink 1000.
You can switch an individual lamp or several
lamps on or off, adjust the light intensity or
programme light settings for a room.
LINK
TV
then
LIGHT
then
0
9
through
or
or

SOUND AND PICTURE
8
Adjusting sound and picture levels
On your video system, you can adjust sound as
well as picture levels via Beolink 1000.
You can adjust sound levels such as volume,
bass, treble and loudness for your audio or
video system. For your video system, you can
adjust the picture levels brilliance, color and
contrast, in some instances additional levels
may be available*.
For further information about sound and
picture adjustment, please refer to the
respective User’s guides for your audio or
video systems…
*Note: If your TV video system is mounted on
a motorised stand, pressing PICTURE once will
display Stand instead of Brilliance on-screen
and access a function which turns your TV. So
in order to adjust brilliance, color and contrast,
you have to press PICTURE two, three, and
four times respectively.
Note: If you wish to reset your sound and
picture levels to their preset levels, press SHIFT,
then MUTE to do so.
Adjust volume at any time…
Press to raise the volume
Press to lower the volume
Press to mute the speakers
Press again to demute the speakers
Adjusting sound levels…
Press repeatedly to access volume,
bass, treble, and loudness
A cue appears on-screen or on the
display which informs you of the
level you can now adjust…
Press to raise the level
Press to lower the level
Press to store the sound levels
Adjusting picture levels…
Press repeatedly to access brilliance
color and contrast
A cue appears on-screen or on the
display which informs you of the
level you can now adjust…
Press to raise the level
Press to lower the level
Press to store the picture levels
STORE
STORE
MUTE
SOUND
or
then
SOUND
STORE
STORE
or
then

ON-SCREEN MENUS 9
Using on-screen menus
Press to call up the main menu for
the source you selected
The main menu appears…
Press until the item/menu you want
is highlighted
Press to call up the menu
The menu in question appears…
Press to move the cursor from item
to item in the menu
Press to reveal other options for the
highlighted item
Or
Use the number keys to fill in
information for the highlighted item
Press to store the information you
have entered
Alternatively…
Press at any time to return to the
previous menu without storing the
information you have entered
Press a source button e.g. V.TAPE to
remove the menus from the screen
Programming of your Bang & Olufsen video
system and certain TV and VCR functions are
operated via on-screen menus that you call up
on the TV.
These functions are all described in the User’s
guide and in the Setting-up guide for your
Bang & Olufsen video system.
MENU
PLAY
then
STOP
V.TAPE
or
or
PLAY
then
or
then
0
9
through

MISCL. INFORMATION
10
Environmental information
This Bang & Olufsen product was delivered in
a packing made to protect and transport the
product safely from the factory to your home.
In the design of our packing, we use the most
conserving and recyclable materials known
today, and we constantly work to reduce any
negative side effects our packing material may
have on the environment . We observe any
progress with great interest.
Corrugated cardboard Made of at least 45%
recycled material. The printing ink contains
no heavy metals, and the box is reusable for
paper production.
Foamed plastic parts Made without use of
injurious inert gasses. Can be recycled or
incinerated, liberating carbon dioxide and
water. Usable for soil improvement in
granular form.
Plastic bags All plastic parts are free of PVC
and can be recycled or incinerated,
liberating carbon dioxide and water.
Batteries We urge you to show consideration
when changing the batteries in your remote
control terminal. Used-up batteries should
be disposed of and kept separately.
International Guarantee
This Bang & Olufsen product carries a
guarantee against defects in workmanship and
materials. The terms of the guarantee apply to
the country of purchase but will be met by
authorized Bang & Olufsen dealers in other
countries.
The guarantee period applying to the country
of purchase takes priority over guarantee
periods applying in other countries, even
where differences exist. In order to obtain
service under this guarantee, a certificate
stating the following information is required:
– Name of product and type number
– Serial number
– Date of purchase
– Guarantee period
– Dealer’s or supplier’s signature
If you intend to use the product in a country
other than that in which it was bought, it may
be necessary for you to have the product
modified to suit the transmission system, or
mains supply etc., used in the country you are
moving to. We therefore recommend that you
contact your Bang & Olufsen dealer before
moving to another country. No costs incurred
in this connection will be covered under the
terms of the guarantee.

11
Date purchased
Contact person
Dealer
Telephone
Address
Beolink 1000 remote control serial number
Dear Customer,
Your needs as the user of our products are always
given careful consideration during the design and
development process, and we strive to make our
products easy and comfortable to operate.
We therefore hope that you will take time to
drop us a line, telling us about your experiences
with your Bang & Olufsen system. Anything which
you consider important – positive or negative –
may help us in our constant efforts to refine our
products.
Thank you!
Please write to:
Customer information
Bang & Olufsen a/s
DK-7600 Struer
Denmark
3500734 0973
Printed in Denmark
by Bogtrykkergården a-s, Struer

www.bang-olufsen.com
